Numark Industries DM1200, DM1285, DM1235 User Manual

Professional Disc Jockey Products

DM1200/DM1235/DM1285 STEREO MIXER

OWNER’S MANUAL

INDUSTRIES

11 Helmsman Avenue, North Kingstown, RI 02852 http://www.numark.com

DM1200/DM1235/DM1285

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE ANY COVER. NO USER- SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.

The lightning flash with arrowhead symbol within the

equilateral triangle is intended to alert the user to the presence

of un-insulated “dangerous voltage” within the product’s

enclosure that may be of sufficient magnitude to constitute

a risk of electric shock to persons.

The exclamation point within the equilateral triangle is intended

to alert the user to the presence of important operating and

maintenance (servicing) instructions in the literature

accompanying this appliance.

CAUTION

FOR USA & CANADIAN MODELS ONLY

TO PREVENT ELECTRIC SHOCK DO NOT USE THIS (POLARIZED)

PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER

OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO

PREVENT BLADE EXPOSURE.

SAFETY INSTRUCTIONS

6. Heat - Avoid placing this product too close to any high heat sources such as radiators.

7. Power Sources - This product should be connected to a power supply only of the type described in these operating instructions, or as marked on the unit.

8. Power Cord Protection - Power supply cords should be routed so that they are not likely to be walked upon or pinched by items placed on or against them. When removing the cord from a power outlet be sure to remove it by holding the plug attachment and not by pulling on the cord.

9. Object and Liquid Entry - Take care that objects do not fall into and that liquids are not spilled into the inside of the mixer.

10. Damage Requiring Service - This product should be serviced only by qualified personnel. If you have any questions about service please

contact at the number(s) shown on the back cover of this manual.

11. Grounding or Polarization - Precautions should be taken so that the grounding or polarization means built into the mixer is not defeated.

1. Read Instructions - All the safety and operating instructions should be read before this product is connected and used.

12. Internal/External Voltage Selectors - Internal or external voltage selector switches, if any, should only be reset and re-equipped with a proper plug for alternative voltage by a qualified service

2. Retain Instructions - The safety and operating

technician. Do not attempt to alter this yourself.

instructions should be kept for future reference.

NOTE: This apparatus does not exceed the

3. Heed Warnings - All warnings on this product and in these operating instructions should be followed.

Class A/Class B (whichever is applicable) limits for radio noise emissions from digital apparatus as set out in the radio interference regulations of the

4. Follow Instructions - All operating and other instructions

Canadian Department of Communications.

should be followed.

WARNING: To Reduce the risk of fire or electric

5. Water and Moisture - This product should be kept away from direct contact with liquids.

shock, do not expose this appliance to rain or moisture. Electrical equipment should NEVER be kept or stored in damp environments.

Please record the serial number of your unit as shown on the back of the chassis as well as the name of the dealer from whom you purchased the unit. Retain this information for your records. Please return the warranty card enclosed to register your mixer with us.

MODEL: __________________________ PURCHASED FROM:_________________________ SERIAL NUMBER:__________________ DATE OF PURCHASE:________________________

Numark - The Leader in DJ Technology

DM1200/DM1235/DM1285

NUMARK DM1200/DM1235/DM1285 STEREO MIXER

INDEX

Safety Information Page 2 Product Registration

Introduction Page 4 Features

System Precautions Page 5 Front Panel Diagrams Page 6 Guided Tour of Features Page 7

Operating Instructions DM1235 Beatkeeper Operation Page 10 DM1285 Sampler Operation Page 14 Rear Panel Diagram and Features Page 16 Connection Diagram Page 17 Specifications Page 18 Block Diagram Page 19 Warranty and Service Rear Cover

Numark - The Leader in DJ Technology

DM1200/DM1235/DM1285

CONGRATULATIONS!

You have purchased a quality stereo mixer designed and manufactured by . This equipment features all new circuitry and the latest in manufacturing and design technology to give you greater quality and better reliability than ever before. This mixer brings to you the finest quality of DJ equipment available today.

Thank you for buying Numark DJ products!

DM1200 FEATURES...

• User replaceable assignable ALPs™ crossfader

• Balanced XLR Outputs

• Dual 6-band graphic equalizer with In/Out switch

• Master and Zone level controls

• Neutrik™ “Combo” connector allows 1/4” or XLR plug to be used for DJ Mic

• 5-8 switchable line inputs

• Three phono inputs

DM1235 with

the

BEATKEEPER

FEATURES...

• Automatic BPM tracking of up to 8 input sources (4 simultaneously)

• Accurate digital BPM displays

• Visual live tracking of your mix progress, using Tempo Difference and Beat Offset Bar Graphs

• All visual displays update on every beat

• Sync Lock Button for accurate BPM tracking

• Beat Assist for locking to the correct beat

• Simple user interface

Once you've synced your Beatkeeper you've opened

a whole new dimension in mixing. The Beatkeeper has two bar graphs - one showing the tempo difference, and the other showing the beat offset. Now you can see when your mix is on track. If the beats start to drift, you'll be able to easily adjust the music before your audience can hear it.

• Dedicated DJ Mic and Second Mic Channel with 2 Band EQ and Talk-over dual control

• Split cue headphone monitoring with cross-fader

• Stereo/Mono switch on the Master and Zone

• Tape Out for direct recording

• Powerful stereo headphone output

• Push button cueing

• High-end performance audio signal

• 12V BNC light connector

DM1285 with SAMPLER FEATURES...

• True 16-bit CD quality audio and powerful recording, editing and playback options

• Re-triggering for stuttering “rap”-style effects

• Effect Level Fader

• Large Start-Stop button

• Digital processor modes: -

-Edit (allows Intro and/or Outro trimming of the

sample after it is recorded)

-Single (sample plays once)

-Repeat (loops sample until disengaged)

-Stutter (for "stutters" and "stabs" in single or repeat mode)

-Speed Control (plays sample faster or slower than originally recorded resulting in frequency shift)

-Monitor (for monitoring sample with or without program or cue audio output)

-Write (safely record a sample)

Numark - The Leader in DJ Technology

DM1200/DM1235/DM1285

IMPORTANT INFORMATION...

Please read this entire manual before connecting the DM1200 to your system. For optimum performance:

• Always make sure that AC power is OFF while making any connections.

• Do not use excessively long cables (i.e. over 50ft/14m) Be sure plugs and jacks are tightly mated. Loose connections can cause hum, noise

or intermittents that could easily damage your speakers.

• Never use spray cleaners or oils on the slide controls. Residues cause excessive dirt build-up and this will

void your warranty. In normal use slide controls can last for many years. If they malfunction (usually because of a dirty or dusty

environment) consult a professional technician.

• Never attempt to make any adjustments or repairs other than those described in this manual. Take the DM1200 to your dealer or to an authorized

Numark Service Center.

SYSTEM PRECAUTIONS

• Use appropriate cables throughout your system: Quality shielded audio cables and terminated

shielded video cables, low-capacitance preferred. Speaker cables must be 14-gauge

minimum; 12- or 10-gauge is better.

• Reliability will be enhanced through the use of banana connectors on the speaker wires.

Observe correct speaker wire polarity. If in doubt, consult your Numark dealer or a qualified technician.

• Take care to connect only one cable at a time. Pay attention to the color-coded, labeled Input

and Output jacks.

• ALWAYS remember: “TURN AMPS ON LAST AND OFF FIRST”. Begin with master faders or

volume controls on minimum and the amplifier gain/input control(s) down. Wait 8 to 10 seconds before turning up the volume. This prevents

transients which may cause severe speaker damage.

• Use restraint when operating controls. Try to move them slowly. Rapid adjustments could damage speakers due to amplifier clipping.

A NOTE ON CABLES:

Make the input and output connections with readily available low-capacitance stereo cables.

Quality cables make a big difference in audio fidelity and punch. See your Numark dealer or an electronics or audio specialist store if you are not

sure which cables to purchase.

Numark - The Leader in DJ Technology

• Avoid amplifier “clipping” at all costs: this occurs when the Red LEDs (usually on the front panel of most professional power amplifiers)

start flashing. “Clipping” is when the power amplifier is distorting and working beyond its limits. Amplifier distortion is THE major cause of speaker failure.

• To prevent fire or shock hazard, do not expose the unit to rain or moisture. Never place cans

of beer, soda, glasses of water or anything wet on top of the mixer!

DM1200/DM1235/DM1285

111213

1516171719

111213

1516171719

DM1200 FRONT PANEL DIAGRAM...

DM1235/DM1285 FRONT PANEL DIAGRAM...

Numark - The Leader in DJ Technology

BEATKEEPER

SAMPLER
