About This Guide

This guide contains detailed information about the Remote Loader. It explains how and when you use the Remote Loader as part of your Identity Manager solution. It also contains configuration and management information for the Remote Loader.

 Chapter 1, “Remote Loader Overview,” on page 9

 Chapter 2, “Installing the Remote Loader,” on page 13

 Chapter 3, “Configuring the Remote Loader,” on page 15

 Chapter 4, “Managing the Remote Loader,” on page 39

 Appendix A, “Options for Configuring a Remote Loader,” on page 45

Audience

This guide is intended for Identity Manager administrators, partners, and consultants.

novdocx (en) 17 September 2009

Feedback

We want to hear your comments and suggestions about this manual and the other documentation included with this product. Please use the User Comments feature at the bottom of each page of the online documentation, or go to www.novell.com/documentation/feedback.html and enter your comments there.

Documentation Updates

For the most recent version of the Remote Loader Guide, visit the Identity Manager Documentation

Web site (http://www.novell.com/documentation/idm36/).

Additional Documentation

For documentation on Identity Manager, see the Identity Manager Documentation Web site (http://

www.novell.com/documentation/idm36/index.html).

Documentation Conventions

In Novell items in a cross-reference path.

A trademark symbol ( trademark.

documentation, a greater-than symbol (>) is used to separate actions within a step and

, TM, etc.) denotes a Novell trademark. An asterisk (*) denotes a third-party

About This Guide 7

novdocx (en) 17 September 2009

8 Identity Manager 3.6.1 Remote Loader Guide

Server

Identity Vault

Metadirectory engine

Dr iv er

Application

Identity Vault

Metadirectory engine

LDAP driver Remote Loader instance

Remote Loader

Active Directory driver

Active Directory

Server

Application

Server

Remote Loader Overview

Identity Manager has an additional feature that extends Identity Manager functionality across applications. It is called the Remote Loader, and it allows the driver to access the application without having the Identity Vault and the Metadirectory engine installed on the same server as the application. As part of the planning process when installing Identity Manager, you need to decide if you are going to use the Remote Loader or not. This section defines what the Remote Loader is and contains instructions for installing and configuring the Remote Loader.

There are two different ways to configure the installation of the Metadirectory engine. Figure 1-1 illustrates the first way. It shows that the Identity Vault, Metadirectory engine, and the driver shim all are installed and running on the same server. The driver shim is configured to communicate with the application and the Metadirectory engine.

Figure 1-1 All Components Installed on the Same Server

novdocx (en) 17 September 2009

Figure 1-2 illustrates both configurations. The LDAP driver is installed on the same server as the

Metadirectory engine and the Identity Vault. The Active Directory* driver is installed on different servers with the Remote Loader. The Remote Loader allows the driver to access the application without having the Identity Vault and Metadirectory engine installed on that same server.

Figure 1-2 A System Using the Remote Loader

Remote Loader Overview

The Remote Loader enables the Metadirectory engine to exchange data with the Identity Vault as different processes and in different locations, including the following:

novdocx (en) 17 September 2009

 As a separate process on the server where the Metadirectory engine is running: The

Metadirectory engine runs as part of an eDirectory

process. The Identity Manager drivers can run on the server where the Metadirectory engine is running. In fact, they can run as part of the same process as the Metadirectory engine.

However, for strategic reasons and to simplifying troubleshooting, you might want the Identity Manager driver to run as a separate process on the server.

If the driver is running as a separate process, the Remote Loader provides a communication channel between the Metadirectory engine and the driver.

 On a server that is not running the Metadirectory engine: Some of the Identity Manager

drivers are unable to run where the Metadirectory engine is running. The Remote Loader enables you to run the Metadirectory engine in one environment while running an Identity Manager driver on a server in a different environment. For example, you cannot run the Active

Directory driver on a Linux

server. The Metadirectory engine can run on the Linux Server

while the Remote Loader runs on an Active Directory server.

 Scenario: Separate Servers. The Metadirectory engine is running on a Linux Server. You

need to run the Identity Manager Driver for Active Directory. This driver is unable to run on a Linux Server because it must run in an Active Directory environment. You install and run the Remote Loader on a Windows 2003 server. The Remote Loader provides a communication channel between the Active Directory driver and the Metadirectory engine.

 Scenario: Non-Host. The Metadirectory engine is running on Solaris*. You need to

communicate with a NIS system where you want to provision user accounts. That system usually doesn’t host the Metadirectory engine. You install the Remote Loader and the Identity Manager Driver for NIS on the NIS system. The Remote Loader on the NIS system runs the NIS driver and enables the Metadirectory engine and the NIS driver to exchange data.

Novell

recommends that you use the Remote Loader configuration for use with your drivers where possible. Use the Remote Loader even in cases where the connected system is on the same server as the Metadirectory engine. The following benefits occur by running the driver with the Remote Loader configuration:

 eDirectory is protected from any exceptions encountered by the driver shim.

 It improves the performance of the server running the Metadirectory engine, by offloading

driver commands to the remote application or database.

 It allows you to run additional drivers on the server where the Metadirectory engine is not

installed.

1.1 Java Remote Loader

The remote loader can host a remote interface shim (DirXML application shim) on the DirXML server. To control all the instances that host such remote interface shim, you use DirXML Java Remote Loader.

The DirXML Java Remote Loader is a Java application, which runs on any system with JRE 1.3.0 or

1.4.2 (for optimal performance) and Java Sockets.

10 Identity Manager 3.6.1 Remote Loader Guide

novdocx (en) 17 September 2009

NOTE: You run the DirXML Java Remote Loader by using a shell script named

dirxml_jremote

Remote Loader Overview 11

novdocx (en) 17 September 2009

12 Identity Manager 3.6.1 Remote Loader Guide

Installing the Remote Loader

The Remote Loader can be installed as a 32-bit application or a 64-bit application. The installation program detects the type of OS that is installed and then installs the corresponding version of the Remote Loader. For the installation instructions, see “Installing the Remote Loader” in the Identity

Manager 3.6.1 Installation Guide.

novdocx (en) 17 September 2009

Installing the Remote Loader

novdocx (en) 17 September 2009

14 Identity Manager 3.6.1 Remote Loader Guide

Configuring the Remote Loader

The Remote Loader uses shims to communicate with the application. A shim is the file or files that contains the code to processes the events that are synchronizing between the Identity Vault and the application.

novdocx (en) 17 September 2009

The Remote Loader can host the Identity Manager application shims contained in

.jar

files. The Java* Remote Loader hosts only Java driver shims. It won’t load or host a native

(C++) driver shim.

Configuring the Remote Loader is a two-step process; the Remote Loader requires configuration and the Driver object requires configuration. There are different configuration steps depending on if you are using Windows or Linux/UNIX.

 Section 3.1, “Configuring the Remote Loader on Windows,” on page 15

 Section 3.2, “Configuring the Remote Loader for Linux/UNIX by Creating a Configuration

File,” on page 18

 Section 3.3, “Configuring the Java Remote Loader,” on page 25

 Section 3.4, “Configuring the Identity Manager Drivers for Use with the Remote Loader,” on

page 34

 Section 3.5, “Creating a Secure Connection,” on page 35

.dll, .so

, or

3.1 Configuring the Remote Loader on Windows

You can configure the driver on Windows through a graphical utility called the Remote Loader Console utility or from the command line.

The Remote Loader Console utility enables you to manage all Remote Loader instances for Identity Manager drivers running on the Windows server. The utility is installed during the installation of Identity Manager.

If you are upgrading, the Console detects and imports existing instances of the Remote Loader. (To be automatically imported, driver configurations must be stored in the Remote Loader directory, typically

c:\novell\remoteloader

1 Double-click the Remote Loader Console icon on the desktop to launch the Remote Loader

Console.

The Remote Loader Console allows you to start, stop, add, remove, and edit each instance of a Remote Loader.

2 Click Add to add a Remote Loader instance of your driver on this server.

3 Use the information in the following table to configure the Remote Loader instance for your

driver.

Headings Description

Description Specify a description to identify the Remote Loader instance in

.) You can then use the Console to manage the remote drivers.

the Remote Loader Console utility.

Configuring the Remote Loader

Headings Description

Driver Select the Java class name for the driver. If you are using the

Active Directory driver, select ADDriver.dll. Table 3-3 on

page 33 contains a list of all of the Java class names for each

driver.

Config File Specify the name of the configuration file. The Remote Loader

Console places configuration parameters into this text file and uses those parameters when it runs.

Communications  IP Address: Specify the IP address where the Remote

Loader listens for connections from the Metadirectory server.

 Connection Port - Metadirectory Server: Specify the

TCP port on which the Remote Loader listens for connections from the Metadirectory server.

The default TCP/IP port for this connection is 8090. With each new instance you create, the default port number automatically increases by one.

 Command Port - Local host communication only:

Specify the TCP port number where a Remote Loader listens for commands such as Stop and Change Trace Level.

Each instance of the Remote Loader that runs on a particular computer must have a different command port number. The default command port is 8000. With each new instance you create, the default port number automatically increases by one.

novdocx (en) 17 September 2009

NOTE: By specifying different connection ports and command ports, you can run multiple instances of the Remote Loader on the same server, hosting different driver instances.

Remote Loader Password Specify the Remote Loader password. This password is used to

control access to a Remote Loader instance for a driver. It must be the same case-sensitive password specified in the Enter the Remote Loader Password field on the Identity Manager driver configuration page. It is important that this password be difficult to guess and be different from the driver object password.

Driver Object Password Specify the Driver Object password. The Remote Loader uses

this password to authenticate to the Metadirectory server. It must be the same case-sensitive password specified in the Driver Object Password field on the Identity Manager driver configuration page. It is important that this password be difficult to guess and be different from the Remote Loader password.

Secure Socket Layer (SSL)

 Use an SSL Connection: You should always select this

option. It is used to encrypt the transfer of data between the Remote Loader and the Metadirectory server.

 Trusted Root File: This is the exported self-signed

certificate from the eDirectory Certificate Authority. For more information, see

Section 3.5, “Creating a Secure Connection,” on page 35.

tree’s Organization

16 Identity Manager 3.6.1 Remote Loader Guide

Headings Description

Trace File  Trace Level: Specify a trace level greater than zero to

display a trace window that contains informational messages from both the Remote Loader and the driver.

The most common setting is trace level 3. If the trace level is set to 0, the trace window is not displayed.

 Trace File: Specify a trace filename where trace

messages are written.

Each Remote Loader instance running on a particular machine must use a different trace file. Trace messages are written to the trace file only if the trace level is greater than zero.

 Maximum Disk Space Allowed for all Trace Logs

(Mb): Specify the approximate maximum size that the trace file for this instance can occupy on disk.

NOTE: Use the tracing options only for troubleshooting issues. Having the tracing enabled reduces the performance of the Remote Loader. Do not leave the tracing enabled in production.

novdocx (en) 17 September 2009

Establish a Remote Loader service for this driver instance

Select this option if you want the Remote Loader established as a service. When this option is enabled, the operating system automatically starts the Remote Loader when the computer starts.

4 Specify the advanced configuration parameters. To do so:

4a Click Advanced to display the Advanced Configuration dialog box.

4b Modify the following settings as desired.

Parameter Description

Classpath Additional paths for the JVM to search for

package (.jar) and class (.class) files. Using this parameter is the same as using the java classpath command. When entering multiple class paths, separate them with a semicolon (;) for a Windows JVM and a colon (:) for a UNIX/Linux JVM.

JVM Options The options used when starting the JVM

instance of the driver.

Heap size The initial and maximum heap size for the

JVM instance.

4c Click OK, to save the advanced configuration information.

5 Click OK to save the configuration file.

If you need to change any of the parameters:

1 In the Remote Loader Console, select the Remote Loader instance from the Description

column.

Configuring the Remote Loader 17

2 Click Stop, type the Remote Loader password, then click OK.

3 Click Edit, then modify the configuration information. See Step 3 on page 15 and Step 4 on

page 17 for a description of each parameter.

4 Click OK to save the changes.

3.2 Configuring the Remote Loader for Linux/ UNIX by Creating a Configuration File

novdocx (en) 17 September 2009

For the Remote Loader to run, it requires a configuration file (for example,

LDAPShim.txt

). Windows is the only platform that provides a GUI interface to create this file. You can also create or edit a configuration file by using command line options. The following steps provide information on basic parameters for the configuration file. For information on additional parameters, see

Appendix A, “Options for Configuring a Remote Loader,” on page 45.

1 To create a configuration file, open a text editor. You should enter each parameter on a separate

line in the configuration file.

2 (Optional) Specify a description by using the

Option

-description -desc short

Secondary Name

Parameter Description

description

-description

Specify a short description string (for example, SAP) to be used for the trace window title and for

Novell

Example:

-description SAP

-desc SAP

The Remote Loader Console places long forms in the configuration files. You can use either a long form (for example, -description) or a short form (for example, -desc).

Audit logging.

option.

3 Specify a TCP/IP port that the Remote Loader instance will use by using the -commandport

option.

18 Identity Manager 3.6.1 Remote Loader Guide

novdocx (en) 17 September 2009

Option

-commandport -cp port number Specifies the TCP/IP port that the Remote Loader

Secondary Name

Parameter Description

instance uses for control purposes. If the Remote Loader instance is hosting an application shim, the command port is the port on which another Remote Loader instance communicates with the instance that is hosting the shim. If the Remote Loader instance is sending a command to an instance that is hosting an application shim, the command port is the port on which the hosting instance is listening. If a port is not specified, the default command port is 8000. Multiple instances of the Remote Loader can run on the same server, hosting different driver instances by specifying different connection ports and command ports.

Example:

-commandport 8001

-cp 8001

4 Specify the parameters for the connection to the Metadirectory server running the Identity

Manager remote interface shim by using the -connection option.

Use the format

-connection “parameter [parameter] [parameter]”

For example, type one of the following:

-connection "port=8091 rootfile=server1.pem"

-conn "port=8091 rootfile=server1.pem"

All the parameters must be included within quotation marks. Parameters include the following:

Option

-connection -conn connection

Secondary Name

Parameter Description

configuration string

Specifies the connection parameters for the connection to the Metadirectory server running the Identity Manager remote interface shim. The default connection method for the Remote Loader is TCP/IP using SSL. The default TCP/ IP port for this connection is 8090. Multiple instances of the Remote Loader can run on the same server. Each instance of the Remote Loader hosts a separate Identity Manager application shim instance. Differentiate multiple instances of the Remote Loader by specifying different connection ports and command ports for each Remote Loader instance.

Example:

-connection “port=8091 rootfile=server1.pem”

-conn “port=8091 rootfile=server1.pem”

Configuring the Remote Loader 19

novdocx (en) 17 September 2009

Option

port decimal port

Secondary Name

Parameter Description

A required parameter. It specifies the TCP/IP

number

port on which the Remote Loader listens for connections from the remote interface shim.

Example:

port=8090

address IP address An optional parameter. Specifies that the

Remote Loader listens on a particular local IP address. This is useful if the server hosting the Remote Loader has multiple IP addresses and the Remote Loader must listen on only one of the addresses.

You have three options:

address=address number address=’localhost’ Don’t use this parameter

If you don’t use the address, the Remote Loader listens on all local IP addresses.

Example:

address=137.65.134.83

fromaddress None IP address The Remote Loader only accepts connections

from the specified IP address. Any other connections are not allowed.

Example:

--conn "port=8092 fromaddress=10.0.0.2"

-connect "port=8094 fromaddress=metaserver1.company.com ”

handshaketimeout None number of

milliseconds

Increases the time out period of the handshake between the Remote Loader and the Metadirectory engine.

Example:

-connection “port=8091 handshaketimeout=1000”

The value can be some integer greater than or equal to zero. Zero means never time out. The non-zero number is the number of milliseconds for the time out to occur. The default value is 1000 milliseconds.

20 Identity Manager 3.6.1 Remote Loader Guide

novdocx (en) 17 September 2009

Option

rootfile A conditional parameter. If you are running SSL

Secondary Name

Parameter Description

and need the Remote Loader to communicate with a native driver, use

rootfile=’trusted certname’

keystore Conditional parameter. Used only for the Identity

Manager application shims contained in files.

Specifies the filename of the Java keystore that contains the trusted root certificate of the issuer of the certificate used by the remote interface shim. This is typically the Certificate Authority of the eDirectory tree that is hosting the remote interface shim.

If you are running SSL and need the Remote Loader to communicate with a Java driver, use a key-value pair:

.jar

keystore=’keystorename’ storepass=’password’

storepass storepass Used only for the Identity Manager application

shims contained in password for the Java keystore specified by the keystore parameter.

.jar

files. Specifies the

Example:

storepass=mypassword

This option applies only to the Java Remote Loader.

5 (Optional) Specify a trace parameter by using the -trace option.

Option

-trace -t integer Specifies the trace level. This is only used when

Secondary Name

Parameter Description

hosting an application shim. Trace levels correspond to those used on the Metadirectory server.

Example:

-trace 3

-t 3

6 (Optional) Specify a trace file by using the -tracefile option.

Configuring the Remote Loader 21

novdocx (en) 17 September 2009

Option

Secondary Name

Parameter Description

-tracefile -tf filename Specify a file to write trace messages to. Trace messages are written to the file if the trace level is greater than zero. Trace messages are written to the file even if the trace window is not open.

Example:

-tracefile c:\temp\trace.txt

-tf c:\temp\trace.txt

7 (Optional) Limit the size of the trace file by using the -tracefilemax option.

Option

-tracefilemax -tfm size Specifies the approximate maximum size that trace

Secondary Name

Parameter Description

file data can occupy on disk. If you specify this option, there will be a trace file with the name specified using the tracefile option and up to 9 additional “roll-over” files. The roll-over files are named using the base of the main trace filename plus _n, where n is 1 through 9.

The size parameter is the number of bytes. Specify the size by using the suffixes K, M, or G for kilobytes, megabytes, or gigabytes.

If the trace file data is larger than the specified maximum when the Remote Loader is started, the trace file data remains larger than the specified maximum until roll-over is completed through all 10 files

Example:

-tracefilemax 1000M

-tfm 1000M

In this example, the trace file can be only 1 GB.

22 Identity Manager 3.6.1 Remote Loader Guide

8 (Optional) Specify a Java parameter by using the -javaparam option.

novdocx (en) 17 September 2009

Option

-javaparam -jp java

Secondary Name

Parameter Description

Specify that the specified Java environment environment parameter

parameters are set to the specified values. The

supported parameters are

DHOST_JVM_ADD_CLASSPATH (for additional jar

files to be loaded alongwith the ones in standard

IDM classpath), DHOST_JVM_INITIAL_HEAP,

DHOST_JVM_MAX_HEAP, and

DHOST_JVM_OPTIONS.

Example:

-javaparam DHOST_JVM_MAX_HEAP=512M

-jp DHOST_JVM_MAX_HEAP=512M

9 Specify the class by using the -class option, or specify the module by using the -module option.

Configuring the Remote Loader 23

novdocx (en) 17 September 2009

Option

-class -cl Java class

Secondary Name

Parameter Description

Specifies the Java class name of the Identity

name

Manager application shim that is to be hosted.

For example, for a Java driver, use one of the following:

-class com.novell.nds.dirxml.driver.ldap.LDA PDriverShim

-cl com.novell.nds.dirxml.driver.ldap.LDA PDriverShim

Java uses a keystore to read certificates. The class option and the -module option are mutually exclusive.

To see a list of the Java class names see Table 3-3

on page 33.

-module -m modulename Specifies the module containing the Identity Manager application shim that is to be hosted.

For example, for a native driver, type one of the following:

-module "c:\Novell\RemoteLoader\ADDriver.dll"

-m "c:\Novell\RemoteLoader\ADDriver.dll"

-module "usr/lib/dirxml/ NISDriverShim.so"

-m "usr/lib/dirxml/NISDriverShim.so"

The

-module

mutually exclusive.

option uses a rootfile certificate. The

option and the

-class

option are

10 Name and save the file.

You can change some settings while the Remote Loader is running. See Tab l e 3 - 1 for a list of some of these settings. For a complete list of these settings, see Appendix A, “Options for Configuring a

Remote Loader,” on page 45.

Table 3-1 Selected Remote Loader Parameters

Parameter Description

-commandport Specifies an instance of the Remote Loader.

-config Specifies a configuration file.

24 Identity Manager 3.6.1 Remote Loader Guide

Parameter Description

-javadebugport Specifies that the Remote Loader instance is to enable Java debugging on the specified port.

-password Specifies the password for authentication.

-service Installs an instance as a service. Windows only.

-tracechange Changes the trace level.

-tracefilechange Changes the name of the trace file being written to.

-unload Unloads the Remote Loader instance.

-window Turns the trace window on or off in a Remote Loader instance. Windows only.

IMPORTANT: For the Remote Loader to automatically start when your computer starts, place the configuration file in the following location:

/etc/opt/novell/dirxml/rdxml

novdocx (en) 17 September 2009

3.2.1 Setting Environment Variables on Solaris, Linux, or AIX

After installing the Remote Loader, you can set the environment variable changes the current directory for rdxml. This directory is then taken as the base path for files that are subsequently created. To set the value of the

RDXML_PATH

variable, specify the following

commands:



set RDXML_PATH=path



export RDXML_PATH

Refer to TID 7001255 (http://www.novell.com/support/php/

search.do?cmd=displayKC&docType=kc&externalId=7001255&sliceId=2&docTypeID=DT_TID_ 1_1&dialogID=102067736&stateId=0%200%20102071280) for configuring the Remote Loader on

UNIX platforms.

RDXML_PATH

, which

3.3 Configuring the Java Remote Loader

The options in the following table enable you to configure the Java Remote Loader on Linux, Solaris, and AIX.

Configuring the Remote Loader 25

Table 3-2 Remote Loader Options

novdocx (en) 17 September 2009

Option

address IP address An optional parameter. Specifies that the Remote

-class -cl Java class

Secondary Name

Parameter Description

Loader listens on a particular local IP address. This is useful if the server hosting the Remote Loader has multiple IP addresses and the Remote Loader must listen on only one of the addresses.

You have three options: address=address number address=‘localhost’ Don't use this parameter.

If you don't use the address, the Remote Loader listens on all local IP addresses.

Example:

Specifies the Java class name of the Identity

name

Manager application shim that is to be hosted.

For example, for a Java driver, use one of the following:

address=137.65.134.83

-class com.novell.nds.dirxml.driver.ldap.LDA PDriverShim

-cl com.novell.nds.dirxml.driver.ldap.LDA PDriverShim

Java uses a keystore to read certificates. The class option and the -module option are mutually exclusive.

To see a list of the Java class names see Table 3-3

on page 33.

26 Identity Manager 3.6.1 Remote Loader Guide

novdocx (en) 17 September 2009

Option

-commandport -cp port number Specifies the TCP/IP port that the Remote Loader

Secondary Name

Parameter Description

instance uses for control purposes. If the Remote Loader instance is hosting an application shim, the command port is the port on which another Remote Loader instance communicates with the instance that is hosting the shim. If the Remote Loader instance is sending a command to an instance that is hosting an application shim, the command port is the port on which the hosting instance is listening. If it is not specified, the default command port is 8000. Multiple instances of the Remote Loader can run on the same server hosting different driver instances by specifying different connection ports and command ports.

Example:

-commandport 8001

-cp 8001

-config None filename Specifies a configuration file. The configuration file

can contain any command line options except the config option. Options specified on the command line override options specified in the configuration file.

-connection -conn connection

configuration string

Example:

-config config.txt

Specifies the connection parameters for the connection to the Metadirectory server running the Identity Manager remote interface shim. The default connection method for the Remote Loader is TCP/IP using SSL. The default TCP/IP port for this connection is 8090. Multiple instances of the Remote Loader can run on the same server. Each instance of the Remote Loader hosts a separate Identity Manager application shim instance. Differentiate multiple instances of the Remote Loader by specifying different connection ports and command ports for each Remote Loader instance.

Example:

-connection "port=8091 rootfile=server1.pem"

-conn "port=8091 rootfile=server1.pem"

Configuring the Remote Loader 27

novdocx (en) 17 September 2009

Option

-description -desc short

Secondary Name

Parameter Description

Specify a short description string (for example,

description

SAP) to be used for the trace window title and for Novell® Audit logging.

Example:

-description SAP

-desc SAP

The Remote Loader Console places long forms in the configuration files. You can use either a long form (for example, -description) or a short form (for example, -desc).

fromaddress None IP address The Remote Loader only accepts connections

from the specified IP address. Any other connections are not allowed.

Example:

--conn "port=8092 fromaddress=10.0.0.2"

-connection "port=8094 fromaddress=metaserver1.company.com"

handshaketimeout None number of

milliseconds

Increases the time out period of the handshake between the Remote Loader and the Metadirectory engine.

Example:

-connection "port= 8093 handshaketimeout=1000"

-help -? None Displays help.

Example:

-help

-java -j None Specifies that the passwords are to be set for a

Java shim instance. This option is only useful in conjunction with the setpasswords option. If -class is specified with -setpasswords, this option isn't necessary.

28 Identity Manager 3.6.1 Remote Loader Guide

novdocx (en) 17 September 2009

Option

-javadebugport -jdp Port number Specifies that the Remote Loader instance is to

keystore Conditional parameters. Used only for Identity

Secondary Name

Parameter Description

enable Java debugging on the specified port. This is useful for developers of the Identity Manager application shims.

Example:

-javadebugport 8080

-jdp 8080

Manager application shims contained in files.

If you are running SSL and need the Remote Loader to communicate with a Java driver, use a key-value pair:

.jar

keystore=‘keystorename’

storepass=‘password’

-module -m modulename Specifies the module containing the Identity

Manager application shim that is to be hosted.

For example, for a native driver, use one of the following:

-module "c:\Novell\RemoteLoader\Exchange5Shim .dll"

-m "c:\Novell\RemoteLoader\Exchange5Shim .dll"

-module "usr/lib/dirxml/ NISDriverShim.so"

-m "usr/lib/dirxml/NISDriverShim.so"

The -module option uses a rootfile certificate. The

-module option and the -class option are mutually exclusive.

Configuring the Remote Loader 29

novdocx (en) 17 September 2009

Option

-password -p password Specifies the password for command

Secondary Name

Parameter Description

authentication. This password must be the same as the first password specified with the setpasswords option for the Remote Loader instance being commanded. If a command option (for example, unload or tracechange) is specified and the password option isn't specified, the user is prompted to enter the password for the loader that is the target of the command.

Example:

-password novell4

-p novell4

port decimal port

number

rootfile A conditional parameter. If you are running SSL

A required parameter. It specifies the TCP/IP port on which the Remote Loader listens for connections from the remote interface shim.

Example:

port=8090

and need the Remote Loader to communicate with a native driver, use

-service -serv None, or install/

uninstall

rootfile=‘trusted certname’

To install an instance as a service, use the install argument together with any other arguments necessary to host an application shim. For example, the arguments used must include module, but any argument can include connection, -commandport, and so forth.

This option installs the Win32 service but doesn't start the service.

To uninstall an instance running as a service, use the uninstall argument together with any other arguments necessary to host the application shim.

The no-argument version of this option is only used on the command line to an instance being run as a Win32* service. This is automatically set up when installing an instance as a service.

Example:

-service install

-serv uninstall

This option isn't available on rdxml or the Java Remote Loader.

30 Identity Manager 3.6.1 Remote Loader Guide

novdocx (en) 17 September 2009

Option

-setpasswords -sp password

storepass storepass Used only for Identity Manager application shims

Secondary Name

Parameter Description

Specifies the password for the Remote Loader

password

instance and the password of the Identity Manager Driver object of the remote interface shim that the Remote Loader communicates with. The first password in the argument is the password for the Remote Loader. The second password in the optional arguments is the password for the Identity Manager Driver object associated with the remote interface shim on the Metadirectory server. Either no password or both passwords must be specified. If no password is specified, the Remote Loader prompts for the passwords. This is a configuration option. Using this option configures the Remote Loader instance with the passwords specified but doesn't load a Identity Manager application shim or communicate with another loader instance.

Example:

-setpasswords novell4 staccato3

-sp novell4 staccato3

contained in .jar files. Specifies the password for the Java keystore specified by the keystore parameter.

Example:

storepass=mypassword

This option applies only to the Java Remote Loader.

-trace -t integer Specifies the trace level. This is only used when

hosting an application shim. Trace levels correspond to those used on the metadirectory server.

Example:

-trace 3

-t 3

-tracechange -tc integer Commands a Remote Loader instance that is

hosting an application shim to change its trace level. Trace levels correspond to those used on the metadirectory server.

Example:

-tracechange 1

-tc 1

Configuring the Remote Loader 31

novdocx (en) 17 September 2009

Option

-tracefile -tf filename Specify a file to write trace messages to. Trace

Secondary Name

Parameter Description

messages are written to the file if the trace level is greater than zero. Trace messages are written to the file even if the trace window is not open.

Example:

-tracefile c:\temp\trace.txt

-tf c:\temp\trace.txt

-tracefilechange -tfc None, or

filename

Commands a Remote Loader instance that is hosting an application shim to start using a trace file, or to close one already in use and use a new one. Using the no-argument version of this option causes the hosting instance to close any trace file being used.

Example:

-tracefilechange c:\temp\newtrace.txt

tfc c:\temp\newtrace.txt

-tracefilemax -tfm size Specifies the approximate maximum size that

trace file data can occupy on disk. If you specify this option, there is a trace file with the name specified using the tracefile option and up to 9 additional “roll-over” files. The roll-over files are named using the base of the main trace filename plus _n, where n is 1 through 9.

The size parameter is the number of bytes. Specify the size by using the suffixes K, M, or G for kilobytes, megabytes, or gigabytes.

Example:

-tracefilemax 1000M

-tfm 1000M

In this example, the trace file can be only 1 GB.

-unload -u None Unloads the Remote Loader instance. If the

Remote Loader is running as a Win32 Service, this command stops the service.

Example:

-unload

-u

32 Identity Manager 3.6.1 Remote Loader Guide

novdocx (en) 17 September 2009

Option

Secondary Name

Parameter Description

-window -w On/Off Turns the trace window on or off in a Remote

Loader instance.

Example:

-window on

-w off

This option is available only on Windows platforms. It isn't available on the Java Remote Loader.

-wizard -wiz None Launches the Configuration Wizard. Running

dirxml_remote.exe

with no command line parameters also launches the wizard. This option is useful if a configuration file is also specified. In this case, the wizard starts with values from the configuration file and the wizard can be used to change the configuration without editing the configuration file directly.

Example:

-wizard

-wiz

This option is available only on Windows platforms. It isn't available on the Java Remote Loader.

Table 3-3 Java Class Names

Java Class Name Driver

com.novell.nds.dirxml.driver.avaya.PBXDriverShim Avaya* PBX Driver

com.novell.nds.dirxml.driver.delimitedtext.DelimitedTextDriver Delimited Text Driver

be.opns.dirxml.driver.ars.arsremedydrivershim.ARSDriverShim Driver for Remedy* ARS

com.novell.nds.dirxml.driver.nds.DriverShimImpl eDirectory Driver

com.novell.nds.dirxml.driver.entitlement.EntitlementServiceDriver Entitlements Service Driver

com.novell.gw.dirxml.driver.gw.GWdriverShim GroupWise

Driver

com.novell.idm.drivers.idprovider.IDProviderShim ID Provider Driver

com.novell.nds.dirxml.driver.jdbc.JDBCDriverShim JDBC* Driver

com.novell.nds.dirxml.driver.jms.JMSDriverShim JMS Driver

com.novell.nds.dirxml.driver.ldap.LDAPDriverShim LDAP Driver

com.novell.nds.dirxml.driver.loopback.LoopbackDriverShim Loopback Driver

com.novell.nds.dirxml.driver.manualtask.driver.ManualTaskDriver Manual Task Driver

Configuring the Remote Loader 33

Java Class Name Driver

com.novell.nds.dirxml.driver.nisdriver.NISDriverShim NIS Driver

com.novell.nds.dirxml.driver.notes.NotesDriverShim Notes Driver

com.novell.nds.dirxml.driver.psoftshim.PSOFTDriverShim PeopleSoft* Driver

com.novell.nds.dirxml.driver.SAPShim.SAPDriverShim SAP HR Driver

com.novell.nds.dirxml.driver.sapusershim.SAPDriverShim SAP User Management Driver

com.novell.nds.dirxml.driver.soap.SOAPDriver SOAP Driver

com.novell.idm.driver.ComposerDriverShim User Application

com.novell.nds.dirxml.driver.workorder.WorkOrderDriverShim WorkOrder Driver

3.4 Configuring the Identity Manager Drivers for Use with the Remote Loader

You can configure a new driver or enable an existing driver to communicate with the Remote Loader. This section provides general information on configuring drivers so that they communicate with the Remote Loader. For driver-specific information, refer to the relevant driver implementation guide at the Identity Manager Driver Documentation Web page (http://www.novell.com/

documentation/idm36drivers/index.html).

novdocx (en) 17 September 2009

When you create a new Driver object in either Designer or iManager, there are additional fields to populate to enable the Remote Loader. You add information to these same fields if you modify an existing driver.

To configure the driver:

1 In the properties of the Driver object, fill in the following fields:

Driver Module: Select Connect to Remote Loader.

Driver Object Password: The driver object password is used by the Remote Loader to

authenticate itself to the Metadirectory server. This password must match the password for the driver object defined on the Remote Loader.

Remote Loader Connection Parameters: Specify the information required to connect to the Remote Loader. The parameter format is

kmo=certificatename port

is the port the Remote Loader is listening on (the default is 8090). The

, where

hostname

hostname=xxx.xxx.xxx.xxx port=xxxx

is the IP address of the Remote Loader server and

kmo

parameter is used only when an SSL connection exists between the Remote Loader and the Metadirectory engine; tt defines the Key Name of the Key Material Object containing the keys and certificate used for SSL.

Example:

hostname=10.0.0.1 port=8090 kmo=IDMCertificate

Remote Loader Password: Specify the password required for the Metadirectory engine (or Remote Loader shim) to authenticate to the Remote Loader.

2 Define a security-equivalent user, click Next, then click Finish.

34 Identity Manager 3.6.1 Remote Loader Guide

3.5 Creating a Secure Connection

If you plan to use the Remote Loader, the first step is to provide secure data transfer between the Remote Loader and the Metadirectory engine. This requires you to use the Secure Socket Layer (SSL) to setup a connection between the Remote Loader and the Metadirectory engine.

To accomplish this, complete the following tasks:

 Section 3.5.1, “Creating a Server Certificate,” on page 35

 Section 3.5.2, “Exporting a Self-Signed Certificate,” on page 35

 Section 3.5.3, “Creating a Keystore,” on page 36

3.5.1 Creating a Server Certificate

If you are unfamiliar with certificates, it is easy to create a new one.

1 In Novell iManager, click Novell Certificate Server > Create Server Certificate.

2 Select the server to own the certificate, and give the certificate a nickname (for example,

remotecert).

novdocx (en) 17 September 2009

IMPORTANT: We recommend that you don’t use spaces in the certificate nickname. For example, use remotecert instead of remote cert.

Also, make a note of the certificate nickname. This nickname is used for the KMO name in the driver’s remote connection parameters.

3 Leave the Creation method set to Standard, then click Next.

4 Review the Summary, click Finish, then click Close.

You have created a server certificate. Continue with Section 3.5.2, “Exporting a Self-Signed

Certificate,” on page 35.

3.5.2 Exporting a Self-Signed Certificate

You can export a newly created certificate. Or, if an SSL server certificate already exists and you have experience with SSL certificates, you can use the existing certificate instead of creating and using a new one.

When a server joins a tree, eDirectory creates the following default certificates:

 SSL CertificateIP

 SSL CertificateDNS

1 In iManager, click eDirectory Administration > Modify Object.

Configuring the Remote Loader 35

2 Browse to and select the Certificate Authority in the Security container, then click OK.

The Certificate Authority (CA) is named after the tree name (Treename-CA.Security).

3 Click the Certificates tab, select the Self-Signed Certificate, then click Export.

4 In the Export Certificate Wizard, deselect Export private key.

novdocx (en) 17 September 2009

You don’t want to export the private key with the certificate.

5 Set the export format to BASE64, then click Next.

IMPORTANT: When the Remote Loader is running on a Windows 2003 R2 SP1 32-bit server, the certificate must be in Base64 format. If you use the DER format, the Remote Loader fails to connect to the Identity Manager engine.

6 Click the link to Save the exported certificate, specify a location, then click Save.

7 Click Close.

3.5.3 Creating a Keystore

A keystore is a Java file that contains encryption keys and, optionally, certificates. If you want to use SSL between the Remote Loader and the Metadirectory engine, and you are using a Java shim, you need to create a keystore file.

 “Keystore on Windows” on page 37

 “Keystore on Solaris, Linux, or AIX” on page 37

 “Keystore on All Platforms” on page 37

36 Identity Manager 3.6.1 Remote Loader Guide

Keystore on Windows

novdocx (en) 17 September 2009

On Windows, run the Keytool utility, typically found in the

c:\novell\remoteloader\jre\bin

directory.

Keystore on Solaris, Linux, or AIX

On Solaris, Linux, or AIX environments, use the installed with rdxml. It is located in the

install_directory/dirxml/bin

create_keystore file is also included in the

dirxml\java_remoteloader

directory. The

create_keystore

dirxml_jremote.tar.gz

create_keystore

file.

file is a shell script that calls the

Create_keystore

directory. The

file, found in the

Keytool utility.

On UNIX, when the self-signed certificate is used to create the keystore, the certificate can be exported in Base64 or binary DER format.

Enter the following at the command line:

create_keystore self-signed_certificate_name keystorename

For example, type one of the following

create_keystore tree-root.b64 mystore create_keystore tree-root.der mystore

The

create_keystore

script specifies a hard-coded password of “dirxml” for the keystore password. This is not a security risk because only a public certificate and public key are stored in the keystore.

Keystore on All Platforms

To create a keystore on any platform, you can enter the following at the command line:

keytool -import -alias trustedroot -file self-signed_certificate_name keystore filename -storepass

The filename can be any name (for example,

rdev_keystore

Configuring the Remote Loader 37

novdocx (en) 17 September 2009

38 Identity Manager 3.6.1 Remote Loader Guide

Managing the Remote Loader

The Remote Loader is either a service or a daemon. At times the server or daemon must be restarted. The following procedures explain how to start and stop the Remote Loader.

 Section 4.1, “Starting the Remote Loader,” on page 39

 Section 4.2, “Stopping the Remote Loader,” on page 43

4.1 Starting the Remote Loader

Each platform has a different way to start the Remote Loader.

 Section 4.1.1, “Starting the Remote Loader on Windows,” on page 39

 Section 4.1.2, “Auto-Starting the Remote Loader,” on page 41

 Section 4.1.3, “Starting the Remote Loader on Solaris, Linux, or AIX,” on page 42

novdocx (en) 17 September 2009

4.1.1 Starting the Remote Loader on Windows

You can start the Remote Loader from the Remote Loader Console icon or from the command line.

 “Starting from the Remote Loader Console” on page 39

 “Starting from the Command Line in Windows” on page 40

Starting from the Remote Loader Console

1 Click the Remote Loader Console icon on the desktop.

Managing the Remote Loader

2 Select a driver instance, then click Start.

novdocx (en) 17 September 2009

Starting from the Command Line in Windows

The command line functionality is provided by

c:\novell\RemoteLoader\dirxml_remote.exe

dirxml_remote.exe

. By default, it is located in

1 At a command prompt, set the password for the Remote Loader. For password command

options, see Table 4-1 on page 41.

dirxml_remote -config path_to_config_file -sp password password

2 Start the Remote Loader.

dirxml_remote -config path_to_config_file

3 Use iManager to start the driver.

4 Confirm that the Remote Loader is working properly.

The Remote Loader loads the Identity Manager application shim only when the Remote Loader is in communication with the remote interface shim on the Metadirectory server. This means, for example, that the application shim shuts down if the Remote Loader loses communication with the Metadirectory server.

40 Identity Manager 3.6.1 Remote Loader Guide

Table 4-1 Password Command Line Options

novdocx (en) 17 September 2009

Option

-password -p password Specifies the password for command

Secondary Name

Parameter Description

authentication. This password must be the same as the first password specified with setpasswords for the loader instance being commanded. If a command option (for example, unload or tracechange) is specified and the option isn’t specified, the user is prompted to enter the password for the loader that is the target of the command.

Example:

password

-password novell4

-p novell4

-setpasswords -sp password

password

Specifies the password for the Remote Loader instance and the password of the Identity Manager Driver object of the remote interface shim that the Remote Loader communicates with. The first password in the argument is the password for the Remote Loader. The second password in the optional arguments is the password for the Identity Manager Driver object associated with the remote interface shim on the Metadirectory server. Either no password or both passwords must be specified. If no password is specified, the Remote Loader prompts for the passwords. This is a configuration option. Using this option configures the Remote Loader instance with the passwords specified but doesn’t load an Identity Manager application shim or communicate with another loader instance.

Example:

-setpasswords novell4 staccato3

-sp novell4 staccato3

4.1.2 Auto-Starting the Remote Loader

To auto-start the Remote Loader on a Windows platform, see Step 9 in Section 3.1, “Configuring the

Remote Loader on Windows,” on page 15.

Select Establish a Remote Loader service for this driver instance if you want the Remote Loader as a service.

When this option is enabled, the operating system automatically starts the Remote Loader when the computer starts.

Managing the Remote Loader 41

novdocx (en) 17 September 2009

To auto-start the Remote Loader on a Linux/Unix platform, place your configuration file in

opt/novell/dirxml/rdxml

. Your Remote Loader instance starts automatically when the computer

/etc/

starts.

4.1.3 Starting the Remote Loader on Solaris, Linux, or AIX

On Solaris, Linux, or AIX, the binary component rdxml provides the Remote Loader functionality. The default location of this component is in the

/usr/bin/

1 Set the password for the Remote Loader. For command password options, see Table 4-1 on

page 41.

Platform Command

Solaris LInux AIX

HP-UX* AS/400* OS/390* z/OS

rdxml

-config path_to_config_file -sp password password

dirxml_jremote

-config path_to_config_file -sp password password

A sample config file can be as follows:

commandport 8000

connection "port=8090 handshaketimeout=2000"

trace 4

tracefile /opt/novell/dirxml/bin/RemotePipeShim.log

tracefilemax 4096M

class com.novell.nds.dirxml.driver.delimitedtext.DelimitedTextDriver

2 The above command does not start the Remote Loader, but creates the encrypted password

files. See TID 7001255 (http://www.novell.com/support/php/

search.do?cmd=displayKC&docType=kc&externalId=7001255&sliceId=2&docTypeID=DT_ TID_1_1&dialogID=102067736&stateId=0%200%20102071280) for more information.

Now run the above command without the -sp option to start the Remote Loader.

directory.

Platform Command

Solaris LInux AIX

HP-UX AS/400 OS/390 z/OS

rdxml

-config path_to_config_file

dirxml_jremote

3 Use iManager to start the driver.

4 Confirm that the Remote Loader is operating properly.

42 Identity Manager 3.6.1 Remote Loader Guide

-config path_to_config_file

For Linux, Solaris, or AIX, use the

command or a trace file to find out whether the

command and connection ports are listening.

tail

For HP-UX and similar platforms, monitor the Java Remote Loader by using the command on the tracefile:

tail -f trace filename

If the last line of the log shows the following, the loader is successfully running and awaiting connection from the Identity Manager remote interface shim:

TRACE: Remote Loader: Entering listener accept()

4.2 Stopping the Remote Loader

Each platform has a different way to stop the Remote Loader. Table 4-2 contains the instructions for each platform.

novdocx (en) 17 September 2009

Table 4-2 How to Stop the Remote Loader

Platform Command

Windows Use the Remote Loader Console to stop a driver instance.

Solaris LInux AIX

HP-UX AS/400 OS/390 z/OS

If multiple instances of the Remote Loader are running on the computer, pass the

rdxml -config path_to_config_file -u

dirxml_jremote -config path_to_config_file -u

-cp

command port

option so that the Remote Loader can stop the appropriate instance.

When you stop the Remote Loader, you must have sufficient rights or specify the Remote Loader password. For example, the Remote Loader is running as a Windows service. You have sufficient rights to stop it. You enter a password, but realize that it is incorrect. The Remote Loader stops anyway, because the Remote Loader isn’t “accepting” the password. Instead, it is ignoring the password because the password is redundant in this case. If you run the Remote Loader as an application rather than as a service, the password is used.

NOTE: If the Lotus Notes driver is loaded on the Notes server, the Domino console might occasionally show the error message '

de.exe (2488/0x9B8) has terminated abnormally

Process C:\Novell\RemoteLoader\dirxml_remote_

'. You can ignore this cosmetic error message. To avoid receiving this error message, move the Notes driver to a server that runs the Notes client. For more information about installing Notes driver on the machine that runs the client, see Local Installation on a Notes Client Workstation (http://www.novell.com/documentation/

idm36drivers/notes/data/agin4qb.html).

Managing the Remote Loader 43

novdocx (en) 17 September 2009

44 Identity Manager 3.6.1 Remote Loader Guide

Options for Configuring a Remote

novdocx (en) 17 September 2009

Loader

The options in the following table enable you to configure a Remote Loader.

Table A-1 Remote Loader Options

Options

address IP address An optional parameter. Specifies that the Remote Loader

Secondary

Name

Parameter Description

listens on a particular local IP address. This is useful if the server hosting the Remote Loader has multiple IP addresses and the Remote Loader must listen on only one of the addresses.

You have three options:

address=address number

address=‘localhost’

Don't use this parameter.

If you don't use the address, the Remote Loader listens on all local IP addresses.

-class -cl Java class

name

Example:

Specifies the Java class name of the Identity Manager application shim that is to be hosted.

For example, for a Java driver, use one of the following:

-class com.novell.nds.dirxml.driver.ldap.LDA PDriverShim

-cl com.novell.nds.dirxml.driver.ldap.LDA PDriverShim

Java uses a keystore to read certificates. The - class option and the -module option are mutually exclusive.

To see a list of the Java class names see Table A-2 on

page 52.

address=137.65.134.83

Options for Configuring a Remote Loader

novdocx (en) 17 September 2009

Options

commandport

Secondary

Name

-cp port number Specifies the TCP/IP port that the Remote Loader

Parameter Description

instance uses for control purposes. If the Remote Loader instance is hosting an application shim, the command port is the port on which another Remote Loader instance communicates with the instance that is hosting the shim. If the Remote Loader instance is sending a command to an instance that is hosting an application shim, the command port is the port on which the hosting instance is listening. If it is not specified, the default command port is 8000. Multiple instances of the Remote Loader can run on the same server hosting different driver instances by specifying different connection ports and command ports.

Example:

-commandport 8001

-cp 8001

-config None filename Specifies a configuration file. The configuration file can

contain any command line options except the config option. Options specified on the command line override options specified in the configuration file.

-connection -conn connection

configuration string

Example:

-config config.txt

Specifies the connection parameters for the connection to the Metadirectory server running the Identity Manager remote interface shim. The default connection method for the Remote Loader is TCP/IP using SSL. The default TCP/IP port for this connection is 8090. Multiple instances of the Remote Loader can run on the same server. Each instance of the Remote Loader hosts a separate Identity Manager application shim instance. Differentiate multiple instances of the Remote Loader by specifying different connection ports and command ports for each Remote Loader instance.

Example:

-connection "port=8091 rootfile=server1.pem"

-conn "port=8091 rootfile=server1.pem"

46 Identity Manager 3.6.1 Remote Loader Guide

novdocx (en) 17 September 2009

Options

-description -desc short description Specify a short description string (for example, SAP) to

Secondary

Name

Parameter Description

be used for the trace window title and for Novell® Audit logging.

Example:

-description SAP

-desc SAP

The Remote Loader Console places long forms in the configuration files. You can use either a long form (for example, -description) or a short form (for example, desc).

fromaddress None IP address The Remote Loader only accepts connections from the

specified IP address. Any other connections are not allowed.

Example:

--conn "port=8092 fromaddress=10.0.0.2"

-connection "port=8094 fromaddress=metaserver1.company.com"

handshaketim eout

None number of

milliseconds

Increases the time out period of the handshake between the Remote Loader and the Metadirectory engine.

Example:

-connection "port= 8093 handshaketimeout=1000"

-help -? None Displays help.

Example:

-help

-java ? None Specifies that the passwords are to be set for a Java

shim instance. This option is only useful in conjunction with the setpasswords option. If -class is specified with setpasswords, this option isn't necessary

Options for Configuring a Remote Loader 47

novdocx (en) 17 September 2009

Options

javadebugport

Secondary

Name

-jdp Port number Specifies that the Remote Loader instance is to enable

Parameter Description

Java debugging on the specified port. This is useful for developers of the Identity Manager application shims.

Example:

-javadebugport 8080

-jdp 8080

keystore Conditional parameters. Used only for Identity Manager

application shims contained in .jar files.

If you are running SSL and need the Remote Loader to communicate with a Java driver, use a key-value pair:

keystore=‘keystorename’

storepass=‘password’

-module -m modulename Specifies the module containing the Identity Manager

application shim that is to be hosted.

For example, for a native driver, use one of the following:

-module "c:\Novell\RemoteLoader\Exchange5Shim .dll"

-m "c:\Novell\RemoteLoader\Exchange5Shim .dll"

-module "usr/lib/dirxml/ NISDriverShim.so"

-m "usr/lib/dirxml/NISDriverShim.so"

The -module option uses a rootfile certificate. The module option and the -class option are mutually exclusive.

48 Identity Manager 3.6.1 Remote Loader Guide

novdocx (en) 17 September 2009

Options

-password -p password Specifies the password for command authentication. This

Secondary

Name

Parameter Description

password must be the same as the first password specified with the setpasswords option for the Remote Loader instance being commanded. If a command option (for example, unload or tracechange) is specified and the password option isn't specified, the user is prompted to enter the password for the loader that is the target of the command.

Example:

-password novell4

-p novell4

port decimal port

number

A required parameter. It specifies the TCP/IP port on which the Remote Loader listens for connections from the remote interface shim.

Example:

port=8090

A conditional parameter. If you are running SSL and need the Remote Loader to communicate with a native driver, use

-service -serv None, or install/

uninstall

rootfile=‘trusted certname’

To install an instance as a service, use the install argument together with any other arguments necessary to host an application shim. For example, the arguments used must include - module, but any argument can include - connection, -commandport, and so forth.

This option installs the Win32 service but doesn't start the service.

To uninstall an instance running as a service, use the uninstall argument together with any other arguments necessary to host the application shim.

The no-argument version of this option is only used on the command line to an instance being run as a Win32* service. This is automatically set up when installing an instance as a service.

Example:

-service install

-serv uninstall

This option isn't available on rdxml or the Java Remote Loader.

Options for Configuring a Remote Loader 49

novdocx (en) 17 September 2009

Options

setpasswords

Secondary

Name

-sp password

Parameter Description

password

Specifies the password for the Remote Loader instance and the password of the Identity Manager Driver object of the remote interface shim that the Remote Loader communicates with. The first password in the argument is the password for the Remote Loader. The second password in the optional arguments is the password for the Identity Manager Driver object associated with the remote interface shim on the Metadirectory server. Either no password or both passwords must be specified. If no password is specified, the Remote Loader prompts for the passwords. This is a configuration option. Using this option configures the Remote Loader instance with the passwords specified but doesn't load a Identity Manager application shim or communicate with another loader instance.

Example:

-setpasswords novell4 staccato3

-sp novell4 staccato3

storepass storepass Used only for Identity Manager application shims

contained in .jar files. Specifies the password for the Java keystore specified by the keystore parameter.

Example:

storepass=mypassword

This option applies only to the Java Remote Loader.

-trace -t integer Specifies the trace level. This is only used when hosting

an application shim. Trace levels correspond to those used on the metadirectory server.

Example:

-trace 3

-t 3

-tracechange -tc integer Commands a Remote Loader instance that is hosting an

application shim to change its trace level. Trace levels correspond to those used on the metadirectory server.

Example:

-tracechange 1

-tc 1

50 Identity Manager 3.6.1 Remote Loader Guide

novdocx (en) 17 September 2009

Options

-tracefile -tf filename Specify a file to write trace messages to. Trace

Secondary

Name

Parameter Description

messages are written to the file if the trace level is greater than zero. Trace messages are written to the file even if the trace window is not open.

Example:

-tracefile c:\temp\trace.txt

-tf c:\temp\trace.txt

tracefilechang e

-tfc None, or filename

Commands a Remote Loader instance that is hosting an application shim to start using a trace file, or to close one already in use and use a new one. Using the noargument version of this option causes the hosting instance to close any trace file being used.

Example:

-tracefilechange c:\temp\newtrace.txt

tfc c:\temp\newtrace.txt

-tracefilemax -tfm size Specifies the approximate maximum size that trace file data can occupy on disk. If you specify this option, there is a trace file with the name specified using the tracefile option and up to 9 additional “roll-over” files. The roll-over files are named using the base of the main trace filename plus _n, where n is 1 through 9.

The size parameter is the number of bytes. Specify the size by using the suffixes K, M, or G for kilobytes, megabytes, or gigabytes.

Example:

-tracefilemax 1000M

-tfm 1000M

In this example, the trace file can be only 1 GB.

-unload -u None Unloads the Remote Loader instance. If the Remote Loader is running as a Win32 Service, this command stops the service.

Example:

-unload

-u

Options for Configuring a Remote Loader 51

novdocx (en) 17 September 2009

Options

Secondary

Name

Parameter Description

-window -w On/Off Turns the trace window on or off in a Remote Loader instance.

Example:

-window on

-w off

This option is available only on Windows platforms. It isn't available on the Java Remote Loader.

-wizard -wiz None Launches the Configuration Wizard. Running dirxml_remote.exe with no command line parameters also launches the wizard. This option is useful if a configuration file is also specified. In this case, the wizard starts with values from the configuration file and the wizard can be used to change the configuration without editing the configuration file directly.

Example:

-wizard

-wiz

This option is available only on Windows platforms. It isn't available on the Java Remote Loader.

Table A-2 Java Class Names

Java Class Name Driver

com.novell.nds.dirxml.driver.avaya.PBXDriverShim Avaya* PBX Driver

com.novell.nds.dirxml.driver.delimitedtext.DelimitedTextDriver Delimited Text Driver

be.opns.dirxml.driver.ars.arsremedydrivershim.ARSDriverShim Driver for Remedy* ARS

com.novell.nds.dirxml.driver.nds.DriverShimImpl eDirectory Driver

com.novell.nds.dirxml.driver.entitlement.EntitlementServiceDriver Entitlements Service Driver

com.novell.gw.dirxml.driver.gw.GWdriverShim GroupWise® Driver

com.novell.idm.driver.idprovider.IDProviderShim ID Provider Driver

com.novell.nds.dirxml.driver.jdbc.JDBCDriverShim JDBC* Driver

com.novell.idm.driver.jms.JMSDriverShim JMS Driver

com.novell.nds.dirxml.driver.ldap.LDAPDriverShim LDAP Driver

com.novell.nds.dirxml.driver.loopback.LoopbackDriverShim Loopback Driver

com.novell.nds.dirxml.driver.manualtask.driver.ManualTaskDriver Manual Task Driver

com.novell.nds.dirxml.driver.nisdriver.NISDriverShim NIS Driver

52 Identity Manager 3.6.1 Remote Loader Guide

Java Class Name Driver

com.novell.nds.dirxml.driver.notes.NotesDriverShim Notes Driver

com.novell.nds.dirxml.driver.psoftshim.PSOFTDriverShim PeopleSoft* Driver

com.novell.nds.dirxml.driver.SAPShim.SAPDriverShim SAP HR Driver

com.novell.nds.dirxml.driver.sapusershim.SAPDriverShim SAP User Management Driver

com.novell.nds.dirxml.driver.soap.SOAPDriver SOAP Driver

com.novell.idm.driver.ComposerDriverShim User Application

com.novell.nds.dirxml.driver.workorder.WorkOrderDriverShim WorkOrder Driver

novdocx (en) 17 September 2009

Options for Configuring a Remote Loader 53

novdocx (en) 17 September 2009

54 Identity Manager 3.6.1 Remote Loader Guide

Novell IDENTITY MANAGER Remote Loader Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Identity Manager 3.6.1 Remote Loader Guide

About This Guide

Remote Loader Overview

1.1 Java Remote Loader

Installing the Remote Loader

Configuring the Remote Loader

3.1 Configuring the Remote Loader on Windows

3.2 Configuring the Remote Loader for Linux/ UNIX by Creating a Configuration File

3.2.1 Setting Environment Variables on Solaris, Linux, or AIX

3.3 Configuring the Java Remote Loader

3.4 Configuring the Identity Manager Drivers for Use with the Remote Loader

3.5 Creating a Secure Connection

3.5.1 Creating a Server Certificate

3.5.2 Exporting a Self-Signed Certificate

3.5.3 Creating a Keystore

Managing the Remote Loader

4.1 Starting the Remote Loader

4.1.1 Starting the Remote Loader on Windows

4.1.2 Auto-Starting the Remote Loader

4.1.3 Starting the Remote Loader on Solaris, Linux, or AIX

4.2 Stopping the Remote Loader
