Nova-Tech 4605 User Manual

TRACEABLE®

SPECIFICATIONS
Range: –40° to 176°F / –40° to 80°C (probe)
14° to 176°F / –10° to 80°C (ambient)
Resolution: 0.5°

OPERATION

1. Remove the battery and re-insert it to set the clock on the unit. After
the segment test has been run, the minutes counter will flash. Set the
minutes by pressing the MIN/MAX button. Press and hold the MIN/MAX
button to increase the minute counter rapidly until the button is
released. Press the IN/DATE button to confirm the correct minute
setting.

2. The hour counter will begin flashing. Set the hour by pressing the
MIN/MAX button. Press and hold the MIN/MAX button to increase the
hour counter rapidly until the button is released. Press the IN/DATE
button to confirm the correct hour setting.

3. The month indicator will begin flashing. Set the month by pressing the
MIN/MAX button. Press and hold the MIN/MAX button to increase the
counter rapidly until the button is released. Press the IN/DATE button to
confirm the correct month setting. If no button is pressed for 15
seconds, the unit will be set and will begin recording temperature.

4. To select °F or °C, slide the switch located on the back of the unit to
the desired setting.

5. To switch the display between date and indoor temperature, press the
IN/DATE button. While in date mode, “DATE” will appear on the
display. While in indoor temperature mode, “IN” will appear on the
display.

6. To recall the stored memories, press the MIN/MAX button repeatedly
and the display will indicate the following:

Maximum outdoor temperature
Minimum outdoor temperature
Maximum indoor temperature

Minimum indoor temperature
The display will also show the corresponding date and time. Press the
MIN/MAX button again to display current temperature, date, and time.

7. To delete stored memories, press and hold the MIN/MAX button for

approximately 3 seconds.

BENCH STAND

The unit is supplied with a bench stand that is a part of the battery cover. To
use the bench stand, locate the small opening at the bottom of the unit.
Place your fingernail into the opening and flip the stand up. To close the
stand, simply snap it shut.

WALL MOUNTING THE UNIT

Set two screws into the wall at the desired location. Do not set the screw
flush to the wall, the heads of the screws will need to slip into the receptacles
on the back of the unit. Once the screws have been properly set, hang the
unit in place by sliding the receptacles on the back of the unit over the heads
of the screws.

THERMOMETER WITH TIME/DATE MAX/MIN MEMORY

ALL OPERATIONAL DIFFICULTIES

If this unit does not function properly for any reason, replace the battery with
a new high quality battery (see “Battery Replacement” section). Low battery
power can occasionally cause any number of “apparent” operational
difficulties. Replacing the battery with a new fresh battery will solve most
difficulties.

BATTERY REPLACEMENT

Erratic readings, faint readings, or no display are all indications that the
battery must be replaced. Remove the battery cover. Remove the
exhausted battery and replace with a new AAA alkaline battery. Replace
the battery cover making certain to run the probe cable through the slot on
the right or left bottom side of the battery cover. Upon initial installation of
the battery, the time and date will require setting. (See the “Operation”
section.)

INSTRUCTIONS

WARRANTY, SERVICE, OR RECALIBRATION

For warranty, service, or recalibration, contact:

CONTROL COMPANY

4455 Rex Road

Friendswood, Texas 77546 USA

Ph. 281-482-1714 Fax [phone]

E-mail [e-mail]

www.control3.com

Control Company is ISO 9001 Quality-

Certified by DNV and ISO 17025 accredited

as a Calibration Laboratory by A2LA.

Control Company Cat. No. 4105, 4305 & 4605

Traceable® is a registered trademark of Control Company ©2008 Control Company. 92-4105-00 Rev. 1 051908
