Norgren V52 Datasheet
®
®
igh flow in-line valves
4
513
2
14
1
H
Compact and robust design
Low power energy efficient solenoids
Very high cycle life
Flexible in-line and fixed length manifold
mounting options
Technical data
Connections:
1/8", 1/4", 3/8", and 1/2" NPT and ISO G
V50 ... V53 Series
/2, 5/2 and 5/3 Spool valves
3
Solenoid actuated and air pilot operated
/8 ... 1/2
1
Medium:
Compressed air, filtered to 40 µm,
lubricated or non-lubricated
Operation:
Softseal spool valve, solenoid and air pilot actuated
Mounting:
In-line or fixed length manifold
Operating pressure:
116 psi (8 bar)
Flow Characteristics:
Size Function l/min Cv
1/8 3/2 & 5/2 480 0.48
1/8 5/3 270 0.27
1/4 3/2 & 5/2 1020 1.02
1/4 5/3 755 0.75
3/8 3/2 & 5/2 1705 1.70
3/8 5/3 1190 1.19
1/2 3/2 & 5/2 2480 2.48
1/2 5/3 1910 1.91
Ambient & medium temperature:
23°F to 140°F (-5°C to 60°C) pilot models
23°F to 122°F (-5°C to 50°C) solenoid models
(consult our Technical Service for use below 36°F (2°C)
Materials
Body/sub-base: die-cast aluminum alloy or aluminum alloy
Softseal spool: NBR/aluminum alloy
Mounting sheets/screws: steel
Springs: stainless steel
Ordering information
See page 3 (solenoid actuated valves) and
4 (pneumatic actuated valves)
3/2 5/2
5/3 APB
5/3 COE
5/3 COP
10/09
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document.
N/US 5.3.541.01
®
®
50 ... V53 Series
2
1
3
12
10
24
1
5
3
14
12
2
1
3
12
1
0
24
1
5
3
14
12
2
1
3
1
2
10
24
1
5
3
1
4
12
4 2
1
5
3
14
12
4 2
1
5
3
14 12
1 2
1
5
3
14 12
V
Solenoid actuated valves
ModelSymbol Function Actuation Pilot supply Operating
V50P413AA2* 3/2 NC Solenoid Internal 29 to 116 0.48 Push & turn 0.26 1
V51R417AA2* 3/2 NC Solenoid/spring Internal 29 to 116 1.02 Push & turn 0.45 2
V52S417AA2* 3/2 NC Solenoid/spring Internal 29 to 116 1.70 Push & turn 0.77 2
53T417AA2* 3/2 NC Solenoid/spring Internal 29 to 116 2.48 Push & turn 0.79 2
V
50P411AA2* 3/2 Solenoid/solenoid Internal 29 to 116 0.48 Push & turn 0.38 3
V
V51R411AA2* 3/2 Solenoid/solenoid Internal 29 to 116 1.02 Push & turn 0.65 4
52S411AA2* 3/2 Solenoid/solenoid Internal 29 to 116 1.70 Push & turn 0.97 4
V
53T411AA2* 3/2 Solenoid/solenoid Internal 29 to 116 2.48 Push & turn 0.96 4
V
V50P513AA2* 5/2 Solenoid/air Internal 29 to 116 0.48 Push & turn 0.27 5
V51R517AA2* 5/2 Solenoid/spring Internal 29 to 116 1.02 Push & turn 0.41 6.
V52S517AA2* 5/2 Solenoid/spring Internal 29 to 116 170 Push & turn 0.65 6
53T517AA2* 5/2 Solenoid/spring Internal 29 to 116 2.48 Push & turn 0.67 6
V
V50P511AA2* 5/2 Solenoid/solenoid Internal 29 to 116 0.48 Push & turn 0.39 7
V51R511AA2* 5/2 Solenoid/solenoid Internal 29 to 116 1.02 Push & turn 0.64 8
52S511AA2* 5/2 Solenoid/solenoid Internal 29 to 116 1.70 Push & turn 1.0 8
V
53T511AA2* 5/2 Solenoid/solenoid Internal 29 to 116 2.48 Push & turn 0.42 8
V
V50P611AA2* 5/3 APB Solenoid/solenoid Internal 44 to 116 0.27 Push & turn 0.75 9
V51R611AA2* 5/3 APB Solenoid/solenoid Internal 44 to 116 0.75 Push & turn 0.85 10
52S611AA2* 5/3 APB Solenoid/solenoid Internal 44 to 116 1.19 Push & turn 1.25 11
V
V53T611AA2* 5/3 APB Solenoid/solenoid Internal 44 to 116 1.91 Push & turn 1.40 11
V50P711AA2* 5/3 COE Solenoid/solenoid Internal 44 to 116 0.27 Push & turn 0.75 9
51R711AA2* 5/3 COE Solenoid/solenoid Internal 44 to 116 0.75 Push & turn 0.85 10
V
52S711AA2* 5/3 COE Solenoid/solenoid Internal 44 to 116 1.19 Push & turn 1.25 11
V
V53T711AA2* 5/3 COE Solenoid/solenoid Internal 44 to 116 1.91 Push & turn 1.40 11
V50P811AA2* 5/3 COP Solenoid/solenoid Internal 44 to 116 0.27 Push & turn 0.75 9
V51R811AA2* 5/3 COP Solenoid/solenoid Internal 44 to 116 0.75 Push & turn 0.85 10
V52S811AA2* 5/3 COP Solenoid/solenoid Internal 44 to 116 1.19 Push & turn 1.25 11
V53T811AA2* 5/3 COP Solenoid/solenoid Internal 44 to 116 1.91 Push & turn 1.40 11
* Insert coil code from below tables
APB = All Ports Blocked, COE = Center Open Exhaust, COP = Center Open Pressure.
pressure
(psi)
Flow
(Cv)
Manual
override
Weight
(lb)
Drawing
No.
V50 series only V51 ... V53 series
Voltage codes and spare solenoid kits
Power Solenoid Kit
Voltage Code Inrush /hold Model
12 V d.c. 12A 2.5 W V12958-A12
24 V d.c. 13A 2.5 W V12958-A13
110/120 V a.c. 50/60 Hz 18A 3.7/ 3.1 VA V12958-A18
Electrical details for V50
solenoid operators
Voltage tolerances +/- 10%
Rating 100 % Continuous duty
Inlet orifice 0.8 mm
Materials PPS (body, FKM and NBR (seal)
Insulation class F class
Connector type DIN 43650 Table “C”
Protection class IP65 (with sealed plugs)
Voltage codes and spare solenoid kits
Voltage Code Inrush / hold Model
12 V d.c. 12J 2.0 W 54469-01
24 V d.c. 13J 2.0 W 54469-02
110/120 V a.c. 50/60 Hz 18J 4.0/2.5 VA 54469-03
Electrical details for V51 to V53
solenoid operators
Voltage tolerances +/- 10%
Rating 100 % Continuous duty
Inlet orifice 0.8 mm
Materials PPS (body), FKM and NBR (seal)
Insulation class F class
Connector type 22 mm industrial standard
Protection class IP65 (with sealed plugs)
Power Solenoid Kit
N/US 5.3.541.02
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document.
10/09
®
®
50 ... V53 Series
V
Solenoid Valve Options selector
V5 ˙ ˙˙ 1 ˙A A2 ˙ ˙˙ ˙
hread size Substitute
T
1/8" 0
/4" 1
1
/8" 2
3
1/2" 3
Thread type Substitute
/8 NPT P
1
/4 NPT R
1
3/8 NPT S
/2 NPT T
1
1/8 A
G
G 1/4 B
G 3/8 C
1/2 D
G
Ordering example
To order a 5/2 solenoid valve, 1/4 NPT ports,
spring return, 24 V d.c., with DIN connector.
quote: V51R517AA213JB
Connectors, 15 mm, DIN 43650, Form ‘C’ Substitute
o connector A
N
to 240 V a.c./d.c. w/ cable grip B
0
to 240 V a.c./d.c. w/ 6 ft.molded cable C
0
12 to 24 Vac/Vdc w/indicator light and cable grip H
20 Vac/Vdc w/indicator light and cable grip J
1
Connectors, 22 mm industrial standard Substitute
o connector A
N
to 240 V a.c./d.c. B
0
0 to 240 V a.c./d.c., 6 ft. [1m] molded cable C
12 to 24 Vac/Vdc w/indicator light and cable grip H
20 Vac/Vdc w/indicator light and cable grip J
1
oltage (V50 valve series) Substitute
V
12 V d.c 2.5 W 12A
24 V d.c 2.5 W 13A
10/120 V a.c (50/60 Hz) 3.7/3.2 VA 18A
1
Voltage (V51 ... V53 valve series) Substitute
12 V d.c 2.0 W 12J
4 V d.c 2.0 W 13J
2
10/120 V a.c (50/60 Hz) 4.0/2.5 VA 18J
1
Actuation Substitute
olenoid/Air spring* 3
S
Solenoid/Spring 7
Solenoid/Solenoid 1
* V50 Series only
Function Substitute
3/2 Normally closed 4
5/2 5
5/3 All ports blocked 6
5/3 Center open exhaust 7
5/3 Center open pressure 8
N/US 5.3.541.03
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document.
10/09
®
®
Pilot actuated valves
2
1
3
12
10
2
1
3
12
10
24
1
5
3
14
12
24
1
5
3
14
12
4
513
2
1
4
12
24
1
5
3
14
1
2
4 2
1
5
3
14
12
4 2
1
5
3
14
12
2
1
3
12
10
id
ModelSymbol Function Pilot
50P4D3AXP0900 3/2 Air Air spring 0 to 116 22 to 116 0.48 0.13 12
V
V51R4D3AXP0900 3/2 Air Spring 0 to 116 22 to 116 1.02 0.27 13
V52S4D7AXP0900 3/2 Air Spring 0 to 116 29 to 116 1.70 0.65 13
53T4D7AXP0900 3/2 Air Spring 0 to 116 29 to 116 2.48 0.66 13
V
50P4DDAXP0200 3/2 Air Air 0 to 116 22 to 116 0.48 0.16 14
V
V51R4DDAXP0200 3/2 Air Air 0 to 116 22 to 116 1.02 0.30 15
52S4DDAXP0200 3/2 Air Air 0 to 116 29 to 116 1.70 0.71 15
V
53T4DDAXP0200 3/2 Air Air 0 to 116 29 to 116 2.48 0.72 15
V
V50P5D3AXP0900 5/2 Air Air spring 0 to 116 22 to 116 0.48 0.16 16
51R5D7AXP0900 5/2 Air Spring 0 to 116 22 to 116 1.02 0.23 17
V
V52S5D7AXP0900 5/2 Air Spring 0 to 116 29 to 116 1.70 0.52 17
V53T5D7AXP0900 5/2 Air Spring 0 to 116 29 to 116 2.480 0.61 17
50P5DDAXP0200 5/2 Air Air 0 to 116 22 to 116 0.48 0.19 18
V
V51R5DDAXP0200 5/2 Air Air 0 to 116 22 to 116 1.02 0.30 19
V52S5DDAXP0200 5/2 Air Air 0 to 116 29 to 116 1.70 0.52 19
53T5DDAXP0200 5/2 Air Air 0 to 116 29 to 116 2.48 1.65 19
V
50P6DDAXP0200 5/3 Air APB Air 0 to 116 22 to 116 0.27 ??? 20
V
V51R6DDAXP0200 5/3 Air APB Air 0 to 116 22 to 116 0.75 0.39 21
V52S6DDAXP0200 5/3 Air APB Air 0 to 116 29 to 116 1.19 0.66 22
V53T6DDAXP0200 5/3 Air APB Air 0 to 116 29 to 116 1.91 0.75 22
50P7DDAXP0200 5/3 Air COE Air 0 to 116 22 to 116 0.27 ??? 20
V
51R7DDAXP0200 5/3 Air COE Air 0 to 116 22 to 116 0.75 0.39 21
V
V52S7DDAXP0200 5/3 Air COE Air 0 to 116 29 to 116 1.19 0.66 22
V53T7DDAXP0200 5/3 Air COE Air 0 to 116 29 to 116 1.91 0.75 22
V50P8DDAXP0200 5/3 Air COP Air 0 to 116 22 to 116 0.27 ??? 20
V51R8DDAXP0200 5/3 Air COP Air 0 to 116 22 to 116 0.75 0.39 21
V52S8DDAXP0200 5/3 Air COP Air 0 to 116 29 to 116 1.19 0.66 22
V53T8DDAXP0200 5/3 Air COP Air 0 to 116 29 to 116 1.91 0.75 22
APB = All Ports Blocked, COE = Center Open Exhaust, COP = Center Open Pressure.
M
osition
p
Return Operating
pressure
(psi)
Pilot
pressure
(psi)
Flow
(Cv)
V50 ... V53 Series
Weight
(lb)
Drawing
No.
Air Pilot Valve Options selector
Thread size Substitute
1/8" 0
1/4" 1
3/8" 2
1/2" 3
Thread type Substitute
1/8 NPT P
1/4 NPT R
3/8 NPT S
1/2 NPT T
G 1/8 A
G 1/4 B
G 3/8 C
G 1/2 D
Ordering example
To order a 5/2 valve, 3/8 NPT ports, air pilot,
spring return
quote: V52S5D7A-XA0900
V5 ˙ ˙˙ D ˙A X˙ 0 ˙0 0
Return Substitute
Double air pilot 0200
Single air pilot 0900
Pilot port thread Substitute
1/8 NPT P
G 1/8 A
Pilot Substitute
Solenoid/Air spring* 3
Single air 7
Double air D
Function Substitute
3/2 Normally closed 4
5/2 5
5/3 All ports blocked 6
5/3 Center open exhaust 7
5/3 Center open pressure 8
* V50 Series only
10/09
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document.
N/US 5.3.541.04
®
®
V50 ... V53 Series
Manifold system and blanking plates
Manifold for 3 port valves
or valve series NPT BSPP NPT BSPP
F
V50 V50P30* V50PA30* V500351 V50P50* V50PA50* V500551
51 V51R30* V51RB30* V510351 V51R50* V51RB50* V510551
V
52 V52S30* V52SC30* V520351 V52S50* V52SC50* V520551
V
V53 V53T30* V53TD30* V530351 V53T50* V53TD50* V530551
* Number of station 2 ... 9 for 2 ... 9 stations
umber of station 10 for 10 stations
N
Blanking plate for 3 port valves Manifold for 5 port valves Blanking plate for 5 port valves
Accessories
Connectors, 15 mm, DIN 43650, Form ‘C’
= V10027-D00 (0 to 240 V a.c./d.c.)
B
C = V10013-D03 (0 to 240 V a.c./d.c., 6 ft. molded cable)
H = V10012-D13 (12 to 24 Vac/Vdc w/indicator light)
= V10012-D18 (120 Vac/Vdc w/indicator light)
J
Accessories
Silencers plastic
Valve series NPT BSP NPT BSP
V50 (1/8") C/S1 M/S1 MS001A T40C1800
V51 (1/4") C/S2 M/S2 MS002A T40C2800
V52 (3/8") C/S3 M/S3 MS003A T40C3800
V53 (1/2") C/S4 M/S4 MS004A T40C4800
Silencers
sintered bronze
Accessories
Connectors, 22 mm industrial standard
= 54934-01 (0 to 240 V a.c./d.c.)
B
C = 54934-21 (0 to 240 V a.c./d.c., 6 ft. [1m] molded cable)
H = 54934-08 (12 to 24 Vac/Vdc w/indicator light)
= 54934-02 (120 Vac/Vdc w/indicator light)
J
Manifold series NPT BSP NPT BSP
V50 C/S2 M/S2 MS002A T40C2800
V51 C/S2 M/S2 MS002A T40C2800
V52 C/S3 M/S3 MS003A T40C3800
V53 C/S4 M/S4 MS004A T40C4800
10/09
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document.
N/US 5.3.541.05
®
®
50 ... V53 Series
NAD
R
A
PR
Q
C AB
D
P
M
B
V
A
S
T
U
W
H
G
X
F
E
2
3
1
J
LAC
N
AD
R
A
PR
Q
C
AB
D
P
J
M
L
AC
V
S
T
U
H I
G
F
E
A
1
2
3
B
W
V
Dimensions in Inches
Valve dimensions
/2 Single solenoid pilot valve,
3
1/8" port
Air Spring return
/2 Single solenoid pilot valve,
3
1/4"... 1/2" ports
Mechanical spring return
Manual override
1
(Push and Turn)
4-6 mm cable dia.
2
Solenoid rotates
3
2 x 180° (V50) 4 x 90° (V51...V53)
4
6-8 mm cable dia.
Series Drawing A AB AC AD BCDE F GHI J
V50 1 3.92 0.53 0.85 0.59 2.56 0.59 0.13 2.19 1.06 0.20 0.12 - 1/8“
V51 2 4.23 0.53 0.67 0.53 2.72 0.98 0.17 2.68 1.38 0.33 0.12 0.12 1/4“
V52 2 4.98 0.51 1.02 0.59 3.50 1.02 0.18 2.87 1.83 1.56 0.16 0.12 3/8“
V53 2 5.24 0.49 1.06 0.59 3.78 1.14 0.18 2.87 1.83 1.56 0.16 0.12 1/2“
Series Drawing LMNPQRSTUVWX
V50 1 0.57 4.25 0.91 1/8" 0.13 0.24 0.04 0.51 0.71 1.16 0.63 0.02
V51 2 0.71 4.72 0.98 1/4" 0.13 0.24 0.08 0.67 0.89 1.02 0.87 -
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document.
10/09
V52 2 1.02 5.49 1.61 3/8" 0.18 0.31 - 0.91 1.18 1.61 0.87 -
V53 2 1.14 5.75 1.89 1/2" 0.17 0.31 0.10 0.91 1.18 1.59 0.87 -
N/US 5.3.541.06
Loading...
