Nordmende DW61SL, DW61WH User Manual [de]

Dishwasher
Instruction
Instruction Manual
InstructionInstruction
Geschirrspüler
Manual
Manual Manual
Gebrauchsanweisung
Gebrauchsanweisung
GebrauchsanweisungGebrauchsanweisung
DW61SL ––––
DW61WH
CONTENTS
Getting familiar with your machine ……………………………………………
Technical specifications ……………………………………………………..
Conformity with the standards and Test data ……………………………..
Safety information and Recommendations………………………………….. 5
Recycling .......……………………….........................................................
Safety information ……………………………………………………………
Recommendations …...………………………………………………………
Items not suitable for dishwashing …………………………………………
Installing the machine ………………………………………………………….. 7
Positioning the machine ……………………………………………………..
Water connections …………………...............................................................
Water inlet hose ….…………………………………………………………..
Water outlet hose …..………………..............................................................
Electrical connection…………………………………………………………
Fitting the machine undercounter ………………………………………….
Prior to using the machine ………………………………………………….
Preparing the machine for use ………………………………………………… 11
The importance of water decalcification …………………………………..
Filling with salt ………………………………………………………………..
Testing strip……………………………………………………………………
Adjusting salt consumption………………………………………………….
Detergent usage ……………………........................................................
Filling the detergent compartment………………………………………….
Combined detergent….………………………………………………………
Filling with rinse aid and making the setting……………………………….
4
5
5
5
5
6
7
7
7
8
8
8
9
11
11
11
12
13
14
14
14
15
1
Loading your dishwasher .……………………………………………………. 16
Dish rack…………………………………………………………………......
Alternative basket loads …………………………………………………...
Standard loading and Test data …………………………………………..
Programme descriptions .……………………………………………………..
Programme items …………………………………………………………..
Switching on the machine and selecting a programme……………........ 21
Switching on the machine………………………………………………….
Programme follow-up ………………………………………………………
Changing a programme ……………………………………………………
Changing a programme with resetting …………………………………...
Switching the machine off ….……………………………………………...
Maintenance and Cleaning ........................................................................ 23
Filters ..………………………………………………………………………
Spray arms ………………………………………………………………….
Hose filter ……………………………………………………………………
Failure codes and what to do in case of failure …………………………
Practical and useful information……......................................................... 27
17
18
19
20
20
21
21
21
22
22
23
24
24
25
2
2
5
8
10
11
12
3
1.
Worktop
2.
Upper basket with racks
3.
Upper spray arm
4.
Lower basket
5.
Lower spray arm
6.
Filters
7.
8.
9.
10.
11.
12.
Rating plate Control Panel Detergent and rinse-aid dispenser Cutlery basket Salt dispenser Upper basket track latch
GETTING FAMILIAR WIT
H YOUR MACHINE
4
1.) Power On/Off Button When the Power On/Off button is pressed, the lamp on the Start/Pause button starts lighting.
2.) Door Handle
The door handle is used to open/close the door of your machine.
3.) Start/Pause Button
Once you press the Start/Pause button, the programme you selected with the programme selector button will start running and the status indicator lamp “wash/dry” will light up.
In the stop condition while wash led is On, Start/Pause led will blink.
4.) Programme selector knob With the programme selector knob, you can select a suitable programme for your dishes.
5.) Wash Dry / End-of-cycle indicator
You can monitor the programme status with the help of ‘wash/dry’ and ‘end’ indicators.
Wash/Dry
End
Technical specifications
Capacity Height …………………………… ………
Height (without worktop) ………...........
Width ………… Depth ……………………………. ……..
Net Weight ……………………..............
Electricity input ……………...................
Total Po Heating Power …………………………. Pump Power ……………………………
Drain Pump Power …………….............
Water supply pressure............... ……...
Current
Producer company has its right to amend design and technical specifications reserved.
The machine's service life is 10 years (the duration required to keep spare parts for the machine
to fulfil its usage functions).
Conformity with the standards and Test data / EC Declaration of Conformity
All stages related to the machine are executed in accordance with the safety rules provided in all relevant directives of the European Community.
108/EC, 2006/95/EC, IEC 436/DIN 44990, EN 50242
2004/
…………………………............
………………….. …….
wer …………………….. ………
…………………………………..
12 place settings 845 mm 815 mm 596 mm 598 mm 46 kg 220-240 V, 50 Hz 2200 W 2000 W 100 W 30 W
0.03 MPa (0,3 bar) - 1 MPa (10 bar) 10 A
SAFETY INFORMATION AND RECOMMENDATIONS
Recycl
ing
Certain components and the packaging of your machine have been produced from recyclable materials.
Plastic parts are marked with international abbreviations:
(>PE< , >PS< , >POM<, >PP<, ….)
Cardboard parts have been produced from recycled paper and they should be disposed of into waste paper collection containers for recycling.
Such materials are not suitable for being disposed of into garbage bins. They should be delivered to recycling centres instead.
Contact relevant centres in order to obtain information on methods and points of disposal.
Safety Information
When you take delivery of your machine
Check for any damage to your machine or to its packaging. Never start a machine damaged in any way, make sure to contact an authorised service.
Unwrap the packaging materials as indicated and dispose of them in accordance with the rules.
The points to pay attention during machine installation
Choose a suitable, safe and level place to install your machine.
Carry out the installation and connection of your machine by following the instructions.
This machine should be installed and repaired by an authorised service only.
Only original spare parts should be used with the machine.
Before installing, be sure that the machine is unplugged.
5
Check whether the indoor electrical fuse system is connected according to the regulations.
All electrical connections must match the values indicated on the rating plate.
Pay special attention and be sure that the machine does not stand on the electricity supply cable.
Never use an extension cord or a multiple socket for making a connection. The plug should be
comfortably accessible after the machine has been installed.
Please assemble the dishwasher, which is inserted under or in the kitchen platform, according to the instruction. Be sure that the product is fixed properly
After installing the machine to a suitable place , run it unloaded for the first time.
In daily use
This machine is for household use, do not use it for any other purpose.
dishwasher will void the guarantee.
Do not get up, sit or place a load on the open door of the dishwasher, it may fall over.
Never put into the detergent and rinse aid dispensers of your machine anything other than those
detergents and rinse aids which are produced specifically for dishwashers. Our company will not be responsible for any damage that might occur in your machine otherwise.
The water in the machine's washing section is no drinking water, do not drink it.
Due to danger of explosion, do not put into the machine’s washing section any chemical
dissolving agents such as solvents.
Check whether plastic items are heat-resistant before washing them in the machine.
Do not put into your machine those items which are not suitable for dishwashing. Also, do not fill
any basket above its capacity. Our company will not be responsible for any scratch or rust to form on the inner frame of your machine due to basket movements otherwise.
Especially because hot water may flow out, the machine door should not be opened under any circumstances while the machine is in operation. In any case, a safety devices ensures that the machine stops if the door is opened.
Do not leave your dishwasher’s door open. Failure to do so may lead to accidents.
Place knives and other sharp-ended objects in the cutlery basket in blade-down position.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their
safety
For your children’s safety
After removing the machine’s packaging, make sure that the packaging material is out of reach of
Do not allow children to play with or start the machine.
Keep your children away from detergents and rinse aids.
Keep children away from the machine while it is open because there may still be residues of
Be sure that your old machine does not pose any threat to your children. Children are known to
In case of malfunctioning
Any malfunction in the machine should be repaired definitely by qualified persons. Any repair
Prior to any repair work on the machine, be sure that the machine is cut off from the mains.
Recommendations
For energy and water saving, remove coarse residues on your dishes before placing the dishes
Use the pre-wash programme only whenever necessary.
Place such hollow items as bowls, glasses and pots into the machine in such a way that they will
.
children.
cleaning substances inside the machine.
have gotten themselves locked in old machines. To forestall such a situation, break your machine's door lock and tear off the electrical cables.
work performed by anyone other than the authorised service personnel will cause your machine to be left outside the scope of warranty.
Switch off the fuse or unplug the machine. Do not pull by the cable when unplugging. Make sure to turn off the water tap.
into the machine. Start your machine after having fully loaded it
face down.
6
.
Commercial usage of the
You are recommended not to load into your machine any dishes different or more than indicated.
INSTALLING THE MACHINE
Items
not suitable for dishwashing:
Cigarette ashes, candle leftovers, polish, paint, chemical substances, iron-alloy materials;
Forks, spoons and knives with wooden or bone, or ivory or nacre-coated handles; glued items,
items soiled with abrasive, acidic or base chemicals
Plastic items that are not heat-resistant, copper or tin-coated containers;
Aluminium and silver objects (they may discolour, become dull)
Certain delicate glass types, porcelains with ornamental printed patterns as they fade even after
the first wash; certain crystal items as they lose their transparency over time, adhered cutlery that is not heat-resistant, lead crystal glasses, cutting boards, items manufactured with synthetic fibre;
Absorbent items as sponges or kitchen rags are not suitable for dishwashing.
Warning: Take care to buy dishwasher-proof sets in your future purchases.
Positioning the machine
When determining the place to put your machine on, take care to choose a place where you can easily load and unload your dishes.
Do not put your machine in any location where there is the probability for the room temperature to fall below 0°C.
Before positioning, take the machine out of its packaging by following the warnings located on the package.
Position the machine close to a water tap or drain. You need to site your machine, taking into consideration that its connections will not be altered once they are made.
Do not grip the machine by its door or panel in order to move it.
Take care to leave a certain clearance from all sides of the machine so that you can comfortably move it back and forth during cleaning.
Make sure that the water inlet and outlet hoses do not get squeezed while positioning the machine. Also, make sure that the machine does not stand on the electrical cable.
Adjust the machine’s adjustable feet so that it can stand level and balanced. Proper positioning of the machine ensures problem-free opening and closing of its door.
If the door of your machine does not close properly, check if the machine is stable on the floor it stands; if not, adjust the adjustable feet and ensure its stable position.
Water connection Be sure that the indoor plumbing is suitable for installing a dishwasher. Also, we recommend that you fit a filter at the entrance of your place or apartment so as to avoid any damage to your machine because of any contamination (sand, clay, rust etc.) that might be occasionally carried in through the mains water supply or the indoor plumbing, and to forestall such complaints as yellowing and formation of deposits after washing.
7
Water inlet hose
Do not
use the water inlet hose of your old machine, if any. Use the new water inlet hose supplied with your machine instead. If you are going to connect a new or long-unused water inlet hose to your machine, run water through it for a while before making the connection. Connect the water inlet hose directly to the water inlet tap. The pressure supplied by the tap should be at a minimum of 0.03 Mpa and and at a maximum of 1 Mpa. If the water pressure is above 1 Mpa, a pressure-relief valve should be fitted inbetween. After the connections are made, the tap should be turned on fully and checked for water tightness. For the safety of your machine, make sure to always turn off the water inlet tap after each wash programme is finished.
NOTE: Aquastop water spout is used in some models. In case of using Aquastop, a dangerous tension exists. Do not cut Aquastop water spout. Do not let it get folded or twisted.
Water ou
The water drain hose can be connected either directly to the water drain hole or to the sink outlet spigot. Using a special bent pipe (if available), the water can be drained directly into the sink via hooking the bent pipe over the edge of the sink. This connection should be at a minimum of 50 cm and and at a maximum of 110 cm from the floor plane. Warning: When a drain hose longer than 4 m is used, the dishes might remain dirty. In that case, our company will not accept responsibility.
tlet hose
Electrical connection
The earthed plug of your machine should be connected to an earthed outlet supplied by suitable voltage and current. If there is no earthing installation, have a competent electrician carry out an earthing installation. In case of usage without earthing installed, our company will not be responsible for any loss of usage that might occur.
The indoor fuse current value should be 10-16 A.
8
Your machine is set according to 220-240 V. If the mains voltage in your location is 110 V, connect a transformer of 110/220 V and 3000 W inbetween. The machine should not be plugged in during positioning. Always use the coated plug supplied with your machine.
Running in low voltage will cause a decline in washing quality.
The machine’s electrical cable should be replaced by an authorised service or an authorised electrician only. Failure to do so may lead to accidents.
For safety purposes, always make sure to disconnect the plug when a wash programme is finished.
In order not to cause an electric shock, do not unplug when your hands are wet.
When disconnecting your machine from the mains supply, always pull from the plug. Never pull the cord itself.
Fitting the machine undercounter
If you wish to fit your machine undercounter, check whether you have sufficient space under your
countertop and whether the wiring-plumbing is suitable to do so.1 If you decide that the space under
the countertop is suitable for fitting your machine, remove the worktop as shown in the illustration. 2
Warning:The stand part which we will settle our machine under it by removing its worktop has to be stable in such a way not to allow balance disorder.
To remove the worktop, remove the screws that hold the worktop which are located at the rear of the machine; then push the front panel 1 cm from the front side towards the rear and lift it.
9
Adjust the machine feet according to the slope of the floor.3 Fit yo undercounter without letting the hoses get crushed or bent.4
Warning: dimensions are shown at fig.
After removal of worktop, the machine should be placed in such a closed place of which
10
ur machine by pushing it
PREPARING THE MACHINE FOR USE
Prior to using the machine for the first time
Check whether the electricity and supply water specifications match the values indicated by the installation instructions for the machine.
Remove all packaging materials inside the machine.
Set the water softener.
Add 2 kg salt into the salt compartment and fill with water up to a level at which it will almost
overflow.
Fill the rinse aid compartment.
The importance of water decalcification
For a good washing function, the dishwasher needs soft, i.e. less calcareous water. Otherwise, white lime residues will remain on the dishes and the interior equipment. This will negatively affect your machine’s washing, drying and shining performance. When water flows through the softener system, the ions forming the hardness are removed from the water and the water reaches the softness required to obtain the best washing result. Depending on the level of hardness of the inflowing water, these ions that harden the water accumulate rapidly inside the softener system. Therefore, the softener system has to be refreshed so that it operates with the same performance also during the next wash. For this purpose, dishwasher salt is used.
Filling with salt
Use softener salt specifically produced for use in dishwashers. To put softener salt, first remove
This way, overflowing salt gets immediately cleaned up through the wash operation. If you are not going to wash any dishes immediately after putting salt, then run a short washing program with an empty machine in order to avoid any damage ( to prevent corrosion ) to your machine due to the salt overflow while filling in the salt container.
the lower basket and then open the salt compartment cap by
turning it counter clockwise.1 2 At first fill the compartment with 2kg
salt and water3 at overflowing
level If available,using the funnel4 provided will make filling easier.; refit the cap and close it. After every 20th-30th wash, add salt into your machine until it fills up (approx. 1.5 kg)
Fill the salt compartment with water at first use only.
We recommend that you use small-grained or powder softener salt. Do not put table salt into your machine. Otherwise, the function of the softener compartment may decrease over time. When you start your dishwasher, the salt compartment gets filled with water. Therefore, put the softener salt prior to starting your machine.
SALT
11
In order to understand whether or not the amount of softener salt in your machine is sufficient, check the transparent section on the salt compartment cap. There is sufficient salt if the transparent section is green. Salt has to be added if the transparent section is not green.
Testing strip
The washing effectiveness of your machine depends on the softness of the tap water. For this reason, your machine is equipped with a system that reduces the hardness in mains water supply. The washing effectiveness will increase when the system is correctly set. To find out the water hardness level of water in your area, contact your local water board or determine water hardness level by using the test strip(if available).
Open the testing strip.
Run water through your tap for 1 min.
Keep the testing strip in water for 1 sec.
Shake the testing strip after taking it out of water.
Wait for 1 min.
Make your machine’s water hardness setting according to the result obtained through the testing strip.
Adjusting salt consumption Table of Water Hardness Level Settings
If the hardness of the water you use is above 90 dF (French hardness) or if you are using well water; you are recommended to use filter and water refinement devices. NOTE: Hardness level is adjusted to level 3 as a factory setting.
12
Adjust the water softener according to how hard your tap water is.
Move the programme selector knob to the 0 (Reset) position while your machine is not
in operation.1
After resetting your machine, press the Start/Pause button and keep it pressed
down.2
Meanwhile, energise the machine by pressing the Power On/Off button. 4
Keep Start/Pause keys press until program monitor lights are on and off. 2
After the lamps “Wash Dry/End” have flashed 3 , release the Start/Pause button.
2
Your machine displays the latest entered water hardness setting.
You can adjust the levels by pressing the Start/Pause button 2 according to
Table of Water Hardness Level Settings.
After adjusting the water hardness level , press on/off button to save the settings
in memory.4
13
Detergent usage
Use a d
etergent specifically designed for use in domestic dishwashers.
You can find powder,gel,and tablet detergents in the market that have been designed for household dishwashers.Detergent should be put into the compartment prior to starting the
machine. Keep your detergents in cool, dry places out of reach of your children. Do not fill detergent into the detergent compartment more than required; otherwise it may cause scratches on your glasses as well as lead to a poorly dissolved detergent. Should you need more information concerning the detergent you will use, contact detergent manufacturers directly.
Filling the detergent compartment
Push the latch to open the detergent container as shown in the image. 1 Deterg
ent pod has level lines inside. It is possible to measure the right detergent amount using these lines. Detergent pod can take totally 40 cm3 detergent. Open the dishwasher detergent and pour into the larger compartment b 25 cm3 i cm3 if they are less soiled.2 If yo
f your dishes are heavily soiled or 15
ur dishes have been kept dirty for a very long time, if there are dried food wastes on them, and if you have overly
loaded the dishwasher, pour a 5 cm3 de
tergent into the pre-wash compartment and start your machine. You may have to add more detergent into your machine, depending on the degree of soil and on the water hardness level in your area.
Combined detergent
Detergent manufacturers also produce combined detergents called “2 in 1”, “3 in 1” or “5 in 1” etc.
“2 in 1” detergents contain detergent + salt or rinse aid. When using “2 in 1” detergents make sure to check the specifications of the tablet.
Other tablet detergents contain detergent + rinse aid + salt + varlous extra functions.
Generally, combined detergents produce sufficient results under certain usage conditions only. Such detergents contain rinse aid and/or salt in preset amounts
Points to consider when using this type of products:
Always make sure to check the specifications of the product you will use or whether or not
it is a combined product.
Check if the detergent used is appropriate for the hardness of mains water that machine is
appertaining to.
Observe the instructions on packagings when using such products.
If such detergents are in the form of tablets, never put them into the interior section or the
cutlery basket of the dishwasher. Always put the tablets into the detergent compartment in the detergent dispenser.
They produce good results for certain types of usage only. If you are using this type of
detergents, you need to contact the manufacturers and find out about the suitable conditions of use.
14
When the conditions of use of such products and the machine settings are appropriate,
they e
nsure savings in salt and/or rinse aid consumption.
Contact the detergent manufacturers if you are not obtaining good wash results (if your
dishes stay calcareous and wet) after having used 2 in 1 or 3 in 1 detergents. The scope of warranty for your machine does not cover any complaints caused by the use of these types of detergents.
Recommended usage: If you want to obtain better results while using combined detergents, add salt and rinse aid into your machine and adjust the water hardness setting and the rinse aid setting to the (1) lowest position.
Solubility of the tablet detergents produced by different companies can vary depending on the temperature and time. Therefore, it is not recommended to use such detergents in short programs. It is more suitable to use powder detergents in such programs.
Warning: Should any problem, which you have not encountered before, arise with the use of this type of detergents, contact the detergent manufacturers directly.
When you give up using combined detergents
Fill the salt and rinse aid compartments.
Adjust the water hardness setting to the highest position ( 6 ) and run an empty-wash.
Adjust the water hardness level.
Make the suitable rinse aid setting.
Filling with rinse aid and making the setting
Rinse aid is used to prevent the stay of white water drops, lime stains, white film strip-shaped stains that may form on the dishes, as well as to increase the drying performance. Contrary to the popular beliefs, it is used not only for obtaining shinier dishes but also for obtaining sufficiently dried dishes. For this reason, care should be taken that there is adequate amount of rinse aid in the rinse aid compartment and only polishing material produced for use at dishwashers should be used.
To put rinse aid, remove the rinse aid compartment cap by turning
it.1 Fill the rinse aid compartment with rinse aid until the ri
nse aid level indicator becomes dark;2 refit the cap and close it by turning it in a way that the nails will correspond to one another. By checking the rinse aid level indicator on the detergent dispenser, you can understand whether or not your machine needs rinse aid. A dark indicator b means that there is rinse aid in the compartment, while a light indicator a shows that you need to fill the compartment with rinse aid.
The rinse aid level adjuster can be set to a position between 1 and 6. Factory setting for rinse aid is the position 3. You need to increase the degree of the adjuster if water stains form on your dishes after a wash, whereas you need to decrease the degree if a blue stain is left when wiped by hand.3
Warning: Use only those rinse aid materials which are allowed for use in the machine. As rinse aid residues left as a result of overflowing will create extremely high amounts of foam and thus reduce the washing performance, remove the excess amount of rinse aid by wiping it with a rag.
15
LOADING YOUR DISHWASHER
If you
properly place your dishes into the machine, you will be using it in the best way in terms
of energy consumption, washing and drying performance. There are two separate baskets for you to load your dishes into your machine. You can load into the lower basket such round and deep items as pots with long handles, pot lids, plates, salad plates, cutlery sets. The upper basket has been designed for tea plates, dessert plates, salad bowls, cups and glasses. When placing long-stem glasses and goblets, lean them against the basket edge, rack or glass supporter wire and not against other items. Do not lean long glasses against one another or they cannot remain steady and may receive damage. It is more appropriate to locate the thin narrow parts into the middle sections of baskets. You can place spoons among the other cutlery sets in order to prevent them from sticking to one another. You are recommended to use the cutlery grid in order to obtain the best result. To avoid any possible injuries, always place such long-handle and sharp-pointed dishes as serving fork, bread knife etc. with their sharp points facing down or horizontally on the baskets.
Warning: Place your dishes into your machine in a way that they will not prevent the upper and lower spray arms from spinning.
Top basket
Dish rack There are dish racks on the upper basket of your machine. a b You ca
n use these dish racks in open or closed position. When they are in open position a you can place your cups on them; and when in closed position b you ca
n place long glasses on the basket. Also, you can use these racks by placing long forks, knives and spoons on them laterally.
Top basket height adjustment
Top basket of your machine is in upper position. When it is in this position, you can place big items such as pans, etc. on lower basket. When you take top basket to lower position, you can place and wash big sized plates on the top basket. Use wheels in order to change the basket height. Open the basket retaining parts at the end of top basket rails by turning them to the sides, and take the basket out. Change the position of the wheels; reinstall the basket to the rail, and close basket retainer parts. In this way, you take the top basket to lower position.
16
Lower Basket Folding
Racks
Folding racks consisting of four parts that are located on the lower basket of your machine are designed in order to let you place big items easier such as pots, pans, etc. If requested, each part can be folded separately, or all of them can be folded and larger spaces can be obtained. You can use folding racks by raising them upwards, or by folding.
1
b
a
d
c
2
17
Loading...
+ 42 hidden pages
