Page 1
Specifications for a quotation
Date:
Project:
Customer:
Phone:
Specifications: Exterior dimensions:
Cooler: 2°C/35°F or ________
Freezer: (-18°C/0°F), (-23°C/-10°F)
Combo (see drawing), NSF Urethane: Regular, Fire rated
Thickness:
Walls:
Ceilings:
Floors:
Options: Doors:
Quotation required:
3’’ 4” 5”
Fax: Email address:
Finish:
White pre-painted
White pre-painted
18 g. galvanized
Location:
Contact:
Project required:
Width: ______, Length: ______, Height: _____
Width: ______, Length: ______, Height: _____
steel , Other _____________
steel , Other _____________
steel , Other _____________
Intelligence module PP-330 flush man door, PP-130 overlap man door,
Thermometer PL-1600 overlap pallet door, CL-1600 sliding pallet door
Pilot switch CP-130 sliding man door
Incandescent light Dimensions: 36” x 78”, Other: ____________
Fluorescent light Kick plates: Int., Ext., Height:: ______________
Enclosure panels Finish: S/s 18g. Gal. 18g. Other: ________
Glass doors: Brand:_____________, Dims:_________, No. of doors:______, Hinged, Sliding
Intelliref Other____________________
Refrigeration (Top mounted): STORAGE, KITCHEN
Conventional: air cooled, water cooled (Note: A clear space of 30’’ is require over the ceiling).
Penthouse: air cooled (Note: A clear space of 34’’ is required over the ceiling).
Warranty: 1 year parts/labour, OPTION: 5 years on compressor.
For a remote refrigeration system, see form: Specification And Scope Of Work For Remote Refrigeration
Systems.
DRAWING
Delivery: yes ___ no ___ Installation: yes ___ no ___
N:\a Ventes\Formulaires\Specifications for a quotation_R06.doc
