Nokia SU-4 User Manual

Nokia Image Frame SU-4

User Guide

9362611
Issue 1

DECLARATION OF CONFORMITY
We, NOKIA CORPORATION, declare under our sole responsibility that the
product SU-4 is in conformity with the provisions of the following Council
Directive: 1999/5/EC.
A copy of the Declaration of Conformity can be found at
http://www.nokia.com/phones/declaration_of_conformity/.

Copyright © 2004 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents

in this document in any form without the prior written permission of Nokia
is prohibited.

Nokia and Nokia Connecting People are trademarks or registered trademarks
of Nokia Corporation. Other product and company names mentioned herein
may be trademarks or tradenames of their respective owners.

The information contained in this user guide was written for the Nokia
Image Frame. Nokia operates a policy of ongoing development. Nokia
reserves the right to make changes to any of the products described in
this document without prior notice.

UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS
OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, AND CONSEQUENTIAL
OR INDIRECT DAMAGES HOWSOEVER CAUSED. THE CONTENTS OF THIS
DOCUMENT ARE PROVIDED “AS IS.” EXCEPT AS REQUIRED BY APPLICABLE
LAW, NO WARRANTIES OF ANY KIND EITHER EXPRESS O R IMPLIED, INCLUDING,
BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE
ACCURACY AND RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA
RESE RV ES TH E RIGHT TO REVISE THI S DOCUME NT OR WITHDRAW IT AT A NY
TIME WITHOUT PRIOR NOTICE.

The availability of particular products may vary by region. Please check with
the Nokia dealer nearest to you.

FCC/INDUSTRY CANADA NOTICE

This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.

9362611/Issue 1

Contents

FOR YOUR SAFETY . . . . . . . . . . . . . . . . . . . . 1

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . 2

Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Image format. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2 Getting started . . . . . . . . . . . . . . . . . . . . . . . 6

Setting up the Nokia Image Frame . . . . . . . . . . . . . . . 6

Switching the power on and off . . . . . . . . . . . . . . . . . 6

3 Using the Nokia Image Frame . . . . . . . . . . . . 7

Viewing the images. . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Editing the images . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Switching the screensaver on and off . . . . . . . . . . . . . 8

Modifying the display brightness. . . . . . . . . . . . . . . . . 8

Sending an image from the Nokia Image Frame . . . . 9

Receiving images with the Nokia Image Frame . . . . . 9

Care and maintenance. . . . . . . . . . . . . . . . . 12

iii

NOTES

iv

FOR YOUR SAFETY

Read these simple guidelines. Breaking the rules may be dangerous or
illegal. Further detailed information is given in this manual.

QUALIFIED SERVICE

Only qualified personnel may repair the Nokia Image
Frame equipment.

CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user's guide for
detailed safety instructions. Do not connect incompatible
products.

BACKUP COPIES

Remember to make backup copies of all important data.

WATER-RESISTANCE

Your Nokia Image Frame is not water-resistant. Keep it dry.

Important:

power to the device with a charger when the device or charger
or their parts are damp or wet. If the device has been exposed
to salt water, wipe it immediately with a cloth dampened with
fresh water to avoid corrosion. The device must then be
carefully wiped dry.

Do not point the IR (infrared) beam at anyone's eye or allow it to
interfere with other IR devices. This device is a Class 1 Laser product.

Only use chargers in dry conditions. Never supply

1

Introduction

The Nokia Image Frame SU-4 is an enhancement product, which enables
you to view the digital images taken or received by your IrDA-enabled
Nokia phone or other compatible devices. The Nokia Image Frame can
communicate with other compatible devices via infrared (IR). You can
place the Nokia Image Frame on a table and view the images either one­by-one or as a slide show. The Nokia Image Frame comes supplied with
three pre-loaded images, and you can conveniently add new images
from a compatible device and delete old images.

Read this user’s guide carefully before using the Nokia Image Frame.

• POWER SUPPLY

Check the model number of any charger used to supply power before use
with this device. The Nokia Image Frame is intended for use with the
ACP-12 charger.

Warning:

use with this particular enhancement. The use of any other
types will invalidate any approval or warranty applying to the
enhancement, and may be dangerous.

For availability of approved chargers, please check with your dealer.

When you disconnect the power cord of any enhancement, grasp and
pull the plug, not the cord.

Use only chargers approved by the manufacturer for

2

• TECHNICAL DATA

• Weight: 15 oz (425g)

• Width (max) / height (max) / depth (max):

6.7 in / 5.1 in / 4.8 in
(170 mm / 129 mm / 123.0 mm)

• Display: 5.1" transmissive backlit STN color LCD 320 x 240
horizontal orientation, 4096 colors. The image resolution in
these materials may appear different.

o

• Operating temperature: 32

• Compatibility: The Nokia Image Frame SU-4 is compatible with
phones and other devices that support image sending over infrared
(IrDA). Note that if image sending cannot be activated from the
phone (IrDA Send feature), the Nokia Image Frame can pull the
images from the compatible Nokia phone when the phone’s IR
connection has been activated.

• IrDA standards: IrOBEX 1.3 receive/send, IrTranP receive

• Supported image format: JPEG and GIF (not animated GIF)

• Supported image size: max 1024 * 768, up to 200 kB. Due to
different techniques of image processing, possibly up to 1 MB.

F to 104 oF (0 oC to 40 oC)

• IMAGE FORMAT

The Nokia Image Frame converts all the received images to JPEG format
with the 320x240 pixel resolution. If the resolution of the received
image differs from this resolution, the Nokia Image Frame scales the
image so that it fits optimally on the display.

When you send images from the Nokia Image Frame, they are sent with
the JPEG format, since the Nokia Image Frame does not store the original
formats of the received images. You should therefore remember to make
backup copies of your original images.

3

1Overview

The Nokia Image Frame has the following main parts:

Display

1

Infrared (IR) port

2

Control keys

3

Table support

4

You can use the Nokia Image Frame through the control keys on top of
the device. The control keys are:

Power on/off key

1

Show/Brightness key

2

Rotation key

3

Three-position switch:

4

• Slide show mode

• Image view mode

• Edit mode

Up key

5

Down key

6

Mark key

7

IrDA key

8

There are three ways to press the
keys. These are as follows:

•

Press briefly

less than one second

•

Press

one second

•

Press and hold

hold down the key for at least
three seconds

4

- press a key for

- press a key for at least

- press and
