Nokia SLIDE 2220 User Manual

Nokia 2220 slide User Guide

Issue

41.

Contents

Safety 5

Support 7

Get started 8

Insert SIM card and battery 8

Charge the battery 9 Antenna 10 Headset 11 Magnets and magnetic

fields 11 Keys and parts 12 Access codes 14 Switch on and off 15 Standby mode 15 Keypad lock 16 Functions without a SIM

card 17 Applications running in

background 18

Calls 19

Make and answer a call 19

Loudspeaker 19 Dialling shortcuts 20

Write text 21

Text modes 21 Traditional text input 21 Predictive text input 22

Navigate the menus 24

Messaging 25

Text and multimedia messages 25

28

29 Instant messaging 30 Voice messages 31 Message settings 31

2Contents

Flash messages Nokia Xpress audio

messages E-mail

28

Contacts 33

Call log 35

Settings 36

Profiles 36 Tones 36 Display 37 Date and time 37 Shortcuts 37 Synchronisation and

backup 38 Connectivity 38 Call and phone 39 Accessories 40 Configuration 40 Restore factory

settings 41

Operator menu 43

Gallery 44

Media 45

Camera and video 45 FM radio 46 Voice recorder 48 Music player 48

Applications 51

Organiser 53

Alarm clock 53 Calendar and to-do

list 54

Web or Internet 55

Connect to a web service 56

SIM services 57

Nokia original accessories 58

Practical rules about accessories 59

Battery 59

Green tips 61

Contents 3

Save energy 61 Recycle 62 Learn more 62

General information 63

Battery 64

Battery and charger information 64

Taking care of your device 67

Recycle 68

Additional safety information 68

Small children 68 Operating

environment 68 Medical devices 69

Vehicles 70 Potentially explosive

environments 70 Emergency calls 71 Certification information

(SAR) 71 MANUFACTURER’S

LIMITED WARRANTY 72

Index 78

4Contents

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

Safety 5

SWITCH OFF IN RESTRICTED AREAS

Follow any restrictions. Switch the device off in aircraft, near medical equipment, fuel, chemicals, or blasting areas.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ACCESSORIES AND BATTERIES

Use only approved accessories and batteries. Do not connect incompatible products.

WATER-RESISTANCE

Your device is not water-resistant. Keep it dry.

6Safety

Support

When you want to learn more about how to use your product or you are unsure how your device should function, see the user guide or see the support pages at www.nokia.com/support or your local Nokia website, or with a mobile device, www.nokia.mobi/support.

If this does not resolve your issue, do the following:

• Restart the device: switch off the device, and remove the battery. After about a minute, replace the battery, and switch on the device.

• Restore the original factory settings as explained in the user guide.

If the issue remains unsolved, contact Nokia for repair options. See www.nokia-asia.com/repair. Before sending your device for repair, always back up the data in your device.

Support 7

Get started

Insert SIM card and battery

Safe removal. Always switch the device off and disconnect the charger before removing the battery.

The SIM card and its contacts can be easily damaged by scratches or bending, so be careful when handling, inserting, or removing the card.

1 Remove the back cover by lifting it from the top end of

the device (1).

2 Remove the battery (2). 3 Open the SIM card holder, and insert the SIM card (3).

Ensure that the contact surface on the card is facing

8Get started

down and that the bevelled corner on the card is facing toward the top of the device. Close the holder (4).

4 Insert the battery (5), and replace the back cover (6).

Charge the battery

Your battery has been partially charged at the factory. If the device indicates a low charge, do the following:

1 Connect the charger to a wall outlet. 2 Connect the charger to the device. 3 When the device indicates a full charge, disconnect the

charger from the device, then from the wall outlet.

You do not need to charge the battery for a specific length of time, and you can use the device while it is charging. If the battery is completely discharged, it may take several

Get started 9

minutes before the charging indicator appears on the display or before any calls can be made.

Antenna

Your device may have internal and external antennas. Avoid touching the antenna area unnecessarily while the antenna is transmitting or receiving. Contact with antennas affects the communication quality and may cause a higher power level during operation and may reduce the battery life.

The figure shows the antenna area marked in grey.

10 Get started

Headset

Warning:

When you use the headset, your ability to hear outside sounds may be affected. Do not use the headset where it can endanger your safety.

When connecting any external device or any headset, other than those approved by Nokia for use with this device, to the Nokia AV Connector, pay special attention to volume levels.

Do not connect products that create an output signal as this may cause damage to the device. Do not connect any voltage source to the Nokia AV Connector.

Magnets and magnetic fields

Keep your device away from magnets or magnetic fields.

Get started 11

Keys and parts

1 End/Power key 2 Navi™ key (scroll key) 3 Display 4 Earpiece 5 Selection keys

12 Get started

6 Call key 7 Keypad

Get started 13

8 Camera lens 9 Loudspeaker 10 Microphone 11 Charger connector 12 Headset connector/Nokia AV Connector (3.5 mm)

Note: Avoid touching this connector as it is intended for

use by authorised service personnel only.

Access codes

The security code helps to protect your phone against unauthorised use. The preset code is 12345. You can create and change the code, and set the phone to request the code. Keep the code secret and in a safe place separate from your phone. If you forget the code and your phone is

14 Get started

locked, your phone will require service and additional charges may apply. For more information, contact a Nokia Care point or your phone dealer.

The PIN code supplied with the SIM card protects the card against unauthorised use. The PIN2 code supplied with some SIM cards is required to access certain services. If you enter the PIN or PIN2 code incorrectly three times in succession, you are asked for the PUK or PUK2 code. If you do not have them, contact your service provider.

The module PIN is required to access the information in the security module of your SIM card. The signing PIN may be required for the digital signature. The barring password is required when using the call barring service.

To set how your phone uses the access codes and security settings, select Menu > Settings > Security.

Switch on and off

Press and hold the power key.

Standby mode

When the phone is ready for use, and you have not entered any characters, the phone is in the standby mode.

Get started 15

1 Network signal strength

2 Battery charge level

3 Network name or operator logo

4 Functions of selection keys

The left selection key, Go to, allows you to access the functions in your personal shortcut list. When viewing the list, select Options > Select options to view the available functions, or select Options > Organise to arrange the functions in your shortcut list.

Keypad lock

Lock the keypad

Close the slide, and select Lock within 5 seconds to lock the keypad.

16 Get started

Unlock the keypad

Select Unlock > OK, or open the slide. If the security keyguard is activated, enter the security code when requested.

Set automatic keypad lock

Select Menu > Settings > Phone > Automatic

keyguard > On, and set the length of time, after which

the keypad locks.

Answer a call when the keypad is locked

Press the call key. When you end or reject the call, the keypad locks automatically.

When the device or keypad is locked, calls may be possible to the official emergency number programmed into your device.

Functions without a SIM card

Some functions of your phone may be used without inserting a SIM card, such as Organiser functions and games. Some functions appear dimmed in the menus and cannot be used.

Get started 17

Applications running in background

Leaving applications running in the background increases the demand on battery power and reduces the battery life.

18 Get started

Calls

Make and answer a call

Make a call

Enter the phone number, including the country and area code if necessary, and press the call key.

Answer an incoming call

Press the call key.

Reject a call

Press the end key.

Adjust the volume

During a phone call, scroll up or down.

Loudspeaker

If available, you may select Loudsp. or Normal to use the loudspeaker or the earpiece of the phone during a call.

Calls 19

Warning:

Continuous exposure to high volume may damage your hearing. Listen to music at a moderate level, and do not hold the device near your ear when the loudspeaker is in use.

Dialling shortcuts

Assign a phone number to a number key

Select Menu > Contacts > Speed dials, scroll to a desired number (2-9), and select Assign. Enter the desired phone number, or select Search and a saved contact.

Activate speed dialling

Select Menu > Settings > Call > Speed dialling > On.

Make a call using speed dialling

In the standby mode, press and hold the desired number key.

20 Calls

Write text

Text modes

To enter text (for example, when writing messages) you can use traditional or predictive text input.

When you write text, press and hold Options to switch between traditional text input, indicated by

, and

predictive text input, indicated by

. Not all languages

are supported by predictive text input.

The character cases are indicated by

, , and .

To change the character case, press #. To change from the letter to number mode, indicated by

, press and hold

#, and select Number mode. To change from the number to the letter mode, press and hold #.

To set the writing language, select Options > Writing

language.

Traditional text input

Press a number key, 2-9, repeatedly until the desired character appears. The available characters depend on the selected writing language.

Write text 21

If the next letter you want is located on the same key as the present one, wait until the cursor appears, and enter the letter.

To access the most common punctuation marks and special characters, press 1 repeatedly. To access the list of special characters, press *.

Predictive text input

Predictive text input is based on a built-in dictionary to which you can also add new words.

1 Start writing a word, using the keys 2 to 9. Press each

key only once for one letter.

2 To confirm a word, scroll right or add a space.

• If the word is not correct, press * repeatedly, and

select the word from the list.

• If the ? character is displayed after the word, the

word you intended to write is not in the dictionary. To add the word to the dictionary, select Spell. Enter the word using traditional text input, and select Save.

22 Write text

• To write compound words, enter the first part of

the word, and scroll right to confirm it. Write the last part of the word, and confirm the word.

3 Start writing the next word.

Write text 23

Navigate the menus

The phone functions are grouped into menus. Not all menu functions or option items are described here.

In the standby mode, select Menu and the desired menu and submenu. Select Exit or Back to exit the current level of menu. Press the end key to return to the standby mode directly. To change the menu view, select Menu >

Options > Main menu view.

24 Navigate the menus

Messaging

You can read, write, send, and save text, multimedia, audio, and flash messages, and e-mail. The messaging services can only be used if your network or service provider supports them.

Text and multimedia messages

You can create a message and optionally attach, for example, a picture. Your phone automatically changes a text message to a multimedia message when a file is attached.

Text messages

Your device supports text messages beyond the limit for a single message. Longer messages are sent as two or more messages. Your service provider may charge accordingly. Characters with accents, other marks, or some language options take more space, and limit the number of characters that can be sent in a single message.

The total number of characters left and the number of messages needed for sending are displayed.

Messaging 25
