Nokia S230 User Manual
Nokia 5230 User Guide
Issue 5.1
2Contents
Contents
Safety 4
About your device 5
Network services 5
Find help 7
In-device help 7
Support 7
Software updates over the air 8
Update software using your PC 9
Access codes 9
Get started 9
Insert the SIM card 9
Insert the battery 11
Insert the memory card 12
Charge the battery 13
Keys and parts 15
Stylus 16
Switch the device on 17
Lock or unlock the keys and touch
screen 17
Home screen 18
Access the menu 19
Touch screen actions 19
Media key 21
Change the ringing tone 21
Nokia support 22
Your device 22
Contacts bar 22
Find an item with adaptive search 23
Antenna locations 23
Offline profile 23
Shortcuts 24
Sensor settings and display rotation 24
Headset 25
Attach a wrist strap 26
Remove the SIM card 26
Remove the memory card 27
Make calls 27
Touch screen during calls 27
Calls 27
Write text 28
Virtual keyboard 28
Handwriting 29
Enter text with the virtual keypad 30
Touch input settings 31
Messaging 32
Messaging main view 32
Write and send messages 32
Set up e-mail 34
E-mail service 34
Mail for Exchange 34
Music player 35
Play a song or a podcast 35
Playlists 37
Transfer music from a computer 37
Camera 38
Activate the camera 38
Image capture 38
Video recording 41
Gallery 42
View and organise files 42
View images and videos 43
Share online 43
About Share online 43
Subscribe to services 44
Manage your accounts 44
Create a post 44
Post files from Gallery 45
Nokia Video Centre 45
View and download video clips 45
Video feeds 47
My videos 47
Transfer videos from your PC 47
Video centre settings 48
Internet 48
About the web browser 48
Browse the web 48
Add a bookmark 49
Subscribe to a web feed 49
Unreadable characters while browsing
the web 50
Positioning (GPS) 50
About GPS 50
Assisted GPS (A-GPS) 51
Hold your device correctly 51
Maps overview 52
Connectivity 52
Protect the environment 53
Save energy 53
Recycle 53
Product and safety information 54
Index 68
Contents 3
4Safety
Safety
Read these simple guidelines. Not following them may be dangerous or illegal. Read
the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use is prohibited or when
it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect
performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in aircraft, near medical
equipment, fuel, chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do not connect incompatible
products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
Safety 5
About your device
The wireless device described in this guide is approved for use on the WCDMA 900/2100
and GSM/EDGE 850/900/1800/1900. Contact your service provider for more information
about networks.
Your device supports several connectivity methods and like computers may be exposed
to viruses and other harmful content. Exercise caution with messages, connectivity
requests, browsing, and downloads. Only install and use services and software from
trustworthy sources that offer adequate security and protection, such as applications
that are Symbian Signed or have passed the Java Verified™ testing. Consider installing
antivirus and other security software on your device and any connected computer.
Your device may have preinstalled bookmarks and links for third-party internet sites
and may allow you to access third-party sites. These are not affiliated with Nokia, and
Nokia does not endorse or assume liability for them. If you access such sites, take
precautions for security or content.
Warning:
To use any features in this device, other than the alarm clock, the device must be
switched on. Do not switch the device on when wireless device use may cause
interference or danger.
When using this device, obey all laws and respect local customs, privacy and legitimate
rights of others, including copyrights. Copyright protection may prevent some images,
music, and other content from being copied, modified, or transferred.
Make back-up copies or keep a written record of all important information stored in
your device.
When connecting to any other device, read its user guide for detailed safety instructions.
Do not connect incompatible products.
The images in this guide may differ from your device display.
Refer to the user guide for other important information about your device.
Network services
To use the device you must have service from a wireless service provider. Some features
are not available on all networks; other features may require that you make specific
arrangements with your service provider to use them. Network services involve
transmission of data. Check with your service provider for details about fees in your
home network and when roaming on other networks. Your service provider can explain
what charges will apply. Some networks may have limitations that affect how you can
use some features of this device requiring network support such as support for specific
6Safety
technologies like WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols and
language-dependent characters.
Your service provider may have requested that certain features be disabled or not
activated in your device. If so, these features will not appear on your device menu. Your
device may also have customized items such as menu names, menu order, and icons.
Find help 7
Find help
In-device help
Your device contains instructions to help to use the applications in your device.
To open help texts from the main menu, select Menu > Help and the application for
which you want to read instructions.
When an application is open, to access the help text for the current view, select
Options > User guide.
When you are reading the instructions, to change the size of the help text, select
Options > Decrease font size or Increase font size.
You may find links to related topics at the end of the help text.
If you select an underlined word, a short explanation is displayed.
Help texts use the following indicators:
Link to a related help topic.
Link to the application being discussed.
When you are reading the instructions, to switch between help texts and the application
that is open in the background, select Options > Show open applications and the
desired application.
Support
When you want to learn more about how to use your product or you are unsure how
your device should function, see the support pages at www.nokia.com/support or your
local Nokia website, www.nokia.mobi/support (with a mobile device), the Help
application in the device, or the user guide.
If this does not resolve your issue, do one of the following:
• Restart the device: switch off the device, and remove the battery. After about a
minute, replace the battery, and switch on the device.
• Restore the original factory settings as explained in the user guide. Your documents
and files will be deleted in the reset, so back up your data first.
• Update your device software regularly for optimum performance and possible new
features, as explained in the user guide.
8Find help
If your issue remains unsolved, contact Nokia for repair options. See
www.nokia.com.hk/repair. Before sending your device for repair, always back up the
data in your device.
Software updates over the air
Select Menu > Applications > SW update.
With Software update (network service), you can check if there are updates available
for your device software or applications, and download them to your device.
Downloading software updates may involve the transmission of large amounts of data
(network service).
Make sure that the device battery has enough power, or connect the charger before
starting the update.
Warning:
If you install a software update, you cannot use the device, even to make emergency
calls, until the installation is completed and the device is restarted.
After updating your device software or applications using Software update, the
instructions related to the updated applications in the user guide or the helps may no
longer be up to date.
To download the available updates, select
not want to download, select the updates from the list.
To view information on an update, select the update and
To view the status of previous updates, select
Select Options and from the following:
Update via PC — Update your device using a PC. This option replaces the Start update
option when updates are only available using the Nokia Software Updater PC
application.
View update history — View the status of previous updates.
Settings — Modify the settings, such as the default access point used for downloading
updates.
Disclaimer — View the Nokia licence agreement.
. To unmark specific updates that you do
.
.
Get started 9
Update software using your PC
Nokia Software Updater is a PC application that enables you to update your device
software. To update your device software, you need a compatible PC, broadband
internet access, and a compatible USB data cable to connect your device to the PC.
To get more information and to download the Nokia Software Updater application, go
to www.nokia.com.hk/softwareupdate.
Access codes
If you forget any of the access codes, contact your service provider.
Personal identification number (PIN) code — This code protects your SIM card against
unauthorised use. The PIN code (4 - 8 digits) is usually supplied with the SIM card. After
three consecutive incorrect PIN code entries, the code is blocked, and you need the PUK
code to unblock it.
UPIN code — This code may be supplied with the USIM card. The USIM card is an enhanced
version of the SIM card and is supported by 3G mobile phones.
PIN2 code — This code (4 - 8 digits) is supplied with some SIM cards, and is required to
access some functions in your device.
Lock code (also known as security code) — The lock code helps you to protect your device
against unauthorised use. The preset code is 12345. You can create and change the
code, and set the device to request the code. Keep the new code secret and in a safe
place separate from your device. If you forget the code and your device is locked, your
device will require service. Additional charges may apply, and all the personal data in
your device may be deleted. For more information, contact a Nokia Care point or your
device dealer.
Personal Unblocking Key (PUK) code and PUK2 code — These codes (8 digits) are required
to change a blocked PIN code or PIN2 code, respectively. If the codes are not supplied
with the SIM card, contact the network service provider whose SIM card is in your device.
UPUK code — This code (8 digits) is required to change a blocked UPIN code. If the code
is not supplied with the USIM card, contact the network service provider whose USIM
card is in your device.
International Mobile Equipment Identity (IMEI) number — This number (15 or 17 digits)
is used to identify valid devices on the GSM network.
Get started
Insert the SIM card
Important: To prevent damage to the SIM card, always remove the battery before
you insert or remove the card.
10 Get started
Important: Do not use a mini-UICC SIM card, also known as a micro-SIM card, a
micro-SIM card with an adapter, or a SIM card that has a mini-UICC cutout (see figure)
in this device. A micro SIM card is smaller than the standard SIM card. This device does
not support the use of micro-SIM cards and use of incompatible SIM cards may damage
the card or the device, and may corrupt data stored on the card.
A SIM card may be already inserted in the device. If not, do the following:
1 Open the cover of the SIM card slot.
2 Insert a SIM card in the SIM card slot. Make sure the contact area on the card is facing
up. Push the card in.
Get started 11
3 Close the cover of the SIM card slot. Make sure the cover is properly closed.
If the SIM card is not properly in place, the device can only be used in the offline profile.
Insert the battery
Safe removal. Always switch the device off and disconnect the charger before removing
the battery.
1 Remove the back cover.
2 Insert the battery.
12 Get started
3 To replace the cover, direct the top locking catches toward their slots, and press
down until the cover locks into place.
Insert the memory card
Use only compatible microSD and microSDHC cards approved by Nokia for use with this
device. Nokia uses approved industry standards for memory cards, but some brands
may not be fully compatible with this device. Incompatible cards may damage the card
and the device and corrupt data stored on the card.
1 Open the cover of the memory card slot.
Get started 13
2 Insert a compatible memory card in the memory card slot. Make sure the contact
area on the card is facing up. Push the card in. You can hear a click when the card
locks into place.
3 Close the cover of the memory card slot. Make sure the cover is properly closed.
Charge the battery
Your battery has been partially charged at the factory. If the device indicates a low
charge, do the following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
14 Get started
3 When the device indicates a full charge, disconnect the charger from the device,
then from the wall outlet.
You do not need to charge the battery for a specific length of time, and you can use the
device while it is charging. If the battery is completely discharged, it may take several
minutes before the charging indicator appears on the display or before any calls can be
made.
Tip: Disconnect the charger from the wall outlet when the charger is not in use. A
charger that is connected to the outlet consumes power even when it is not connected
to the device.
Keys and parts
1 Micro USB connector
2 Nokia AV connector (3.5 mm)
3 Charger connector
4 Power key
5 Earpiece
6 Touch screen
7 Proximity sensor
8 Volume/Zoom key
9 Media key
10 Lock switch
11 Capture key
12 End key
13 Menu key
14 Call key
Get started 15
16 Get started
15 Camera lens
16 Loudspeaker
17 SIM card slot
18 Memory card slot
19 Wrist strap hole
20 Microphone
21 Stylus
Your device also comes with a plectrum stylus that can be attached to the device with
the wrist strap.
Do not cover the area above the touch screen, for example, with protective film or tape.
Stylus
Some functions, such as handwriting recognition, are designed to be used with a stylus.
The pen stylus is located in the back cover of the device.
Get started 17
Important: Use only a stylus approved by Nokia for use with this device. Using
any other stylus may invalidate any warranty applying to the device and may damage
the touch screen. Avoid scratching the touch screen. Never use an actual pen or pencil
or other sharp objects to write on the touch screen.
Switch the device on
1 Press and hold the power key.
2 If the device asks for a PIN code or lock code, enter it, and select OK. To delete a
number, select
. The factory setting for the lock code is 12345.
3 Select your location. If you accidentally select the wrong location, select Back.
4 Enter the date and time. When using the 12-hour time format, to switch between
a.m. and p.m., select any number.
Lock or unlock the keys and touch screen
You can lock the device to avoid accidental key presses, for example, when the device
is in your pocket or bag.
Slide the lock switch.
When the keys and screen are locked, the screen switches off and the keys are inactive.
The keys and screen may be locked automatically after a period of inactivity.
Change the settings for automatic key and screen locking
Select Menu > Settings and Phone > Phone mgmt. > Auto. keyguard and the
desired option.
18 Get started
Home screen
The home screen is your starting point where you can collect all your important contacts
or application shortcuts.
Interactive display elements
To open the clock application, select the clock (1).
To open the calendar, or to change the profile, select the date or the profile name (2).
To view or modify connectivity settings (
), or to view missed events, select the top
right corner (3).
To make a phone call, select Telephone or
To open the contacts list, select Contacts or
(4).
(5).
To open the main menu, press the menu key (6).
Start using the contacts bar
To start using the contacts bar, and to add your contacts to the home screen, select
Options > New contact, and follow the instructions.
>
Get started 19
Change the home screen theme or shortcuts
Select Menu > Settings and Personal > Home screen.
Music keys
When music or the radio is playing in the background, music keys (play/pause, skip
backward, and skip forward) are displayed in the home screen.
Access the menu
To access the menu, press the menu key.
To open an application or folder in the menu, select the item.
Touch screen actions
Tap and double-tap
To open an application or other element on the touch screen, you normally tap it with
your finger or the stylus. However, to open the following items, you must tap them
twice.
Important: Use only a stylus approved by Nokia for use with this device. Using
any other stylus may invalidate any warranty applying to the device and may damage
the touch screen. Avoid scratching the touch screen. Never use an actual pen or pencil
or other sharp objects to write on the touch screen.
• List items in an application, such as the Drafts folder in the folder list in Messaging
Tip: When you open a list view, the first item is already highlighted. To open the
highlighted item, tap it once.
• Applications and folders in the menu when using the list view type
• Files in a file list, for example, an image in the images and videos view in Gallery.
If you tap a file or similar item once, it is not opened, it becomes highlighted. To
see the options available for the item, select Options or, if available, select an icon
from a toolbar.
Select
In this user documentation, opening applications or items by tapping them once or
twice is called "selecting". If you need to select several items in a sequence, the menu
items to select are separated by arrows.
20 Get started
To select Options > User guide, tap Options, and then tap User guide.
Drag
To drag, place your finger or the stylus on the screen, and slide it across the screen.
To scroll up or down on a web page, drag the page with your finger or stylus.
Swipe
To swipe, slide your finger or the stylus quickly left or right on the screen.
When viewing an image, to view the next or previous image, swipe the image left or
right, respectively.
Swipe to unlock the touch screen
To unlock the touch screen, press the power key or the menu key, and swipe from right
to left.
Swipe to unlock the touch screen and mute a call
To unlock the touch screen without answering a call, swipe from right to left. The ringing
tone is muted automatically. To answer the call, press the call key, or to reject the call,
press the end key.
Swipe to answer a call
To answer an incoming call, swipe from left to right.
Swipe to stop an alarm
To stop a sounding alarm, swipe from left to right. To snooze the alarm, swipe from
right to left.
Scroll
To scroll up or down in lists that have a scroll bar, drag the slider of the scroll bar.
Get started 21
In some list views, you can scroll by placing your finger or stylus on a list item and
dragging up or down.
To scroll through contacts, place your finger or stylus on a contact, and drag up or down.
Tip: To view a brief description of an icon, place your finger or stylus on the icon.
Descriptions are not available for all icons.
Touch screen backlight
The touch screen backlight is turned off after a period of inactivity.
To turn the screen backlight on, tap the screen.
If the touch screen and keys are locked, tapping the screen does not turn the screen
backlight on. To unlock the screen and keys, slide the lock switch.
Media key
To open applications such as the music player or browser, select the media key ( ) to
open the media bar, and select the application.
Change the ringing tone
Select Menu > Settings and Personal > Profiles.
You can use profiles to set and customise the ringing tones, message alert tones, and
other tones for different events, environments, or caller groups.
Loading...
