Page 1
Nokia Customer Care
6275/6275i (RM-154)
Mobile Terminals
Parts Lists and Exploded View
Issue 1 - September 2006 Company Confidential
Page 2
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Contents Page
Exploded View ................................................................................................................................................. 3
Spare Parts........................................................................................................................................................ 4
Assembly Parts List .....................................................................................................................................5
6275i Parts List — Version 010 — Engine Code 0202939................................................................... 7
6275 Parts List — Version 007 — Engine Code 0203038................................................................. 28
Page 2 Company Confidential Issue 1 - September 2006
Page 3
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Exploded View
Figure 1: Exploded View
Issue 1 - September 2006 Company Confidential Page 3
Page 4
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Spare Parts
Figure 2: Spare Parts
Page 4 Company Confidential Issue 1 - September 2006
Page 5
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Assembly Parts List
Item/
Circuit Ref.
I001 1 A-cover Available separately
I002 1 Keymat Available separately
I003 6 Screws (M1.6x7.2 T5) Available separately
Qty Description Item Availability
A1 UI Module Assembly
I004 1 Domesheet Available separately
I005 1 UI module Available as an assembly
A2 C-Cover Assembly
I006 1 Rubber pad Available as an assembly
I008 1 C-cover Available as an assembly
I009 3 Grounding clip Available as an assembly
I010 2 UIB C-cover clip Available as an assembly
1 Adhesive Available separately
A3 Light Swap Package
I011 1 Baseband shield lid Available separately
I012 1 Engine module Available as an assembly
I013 1 Bluetooth shield lid Available separately
I014 1 SIM door Available as an assembly
I016 1 Rx shield lid Available separately
I017 1 Tx shield lid Available separately
I018 1 GPS shield lid Available separately
I019 1 Duplexer shield lid Available separately
A4 MicroSD Card Reader Assembly
I015 1 MicroSD door Available as an assembly
A5 D-Cover Assembly
I022 1 D-cover Available as an assembly
I023 1 Camera boot Available as an assembly
I024 1 Flash module Available separately
I025 1 Volume key Available separately
I026 1 Camera key Available separately
Issue 1 - September 2006 Company Confidential Page 5
Page 6
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Item/
Circuit Ref.
I027 1 Battery cover latch Available as an assembly
I028 1 Microphone module Available separately
I029 1 Bluetooth antenna Available as an assembly
I030 1 DC jack Available separately
I031 1 Battery floor Available separately
I032 1 IR window Available as an assembly
I033 1 UHJ jack sliding cover Available as an assembly
I039 1 Water ingress label Available separately
Qty Description Item Availability
IHF Assembly
I034 1 Earpiece Available separately
I035 1 GPS antenna Available as an assembly
I036 1 IHF speaker Available as an assembly
I037 1 IHF chamber Available as an assembly
I007 1 LCD module Available separately
I020 1 Type label Available separately
I021 1 Camera Available separately
I038 1 Antenna cover (internal antenna) Available separately
I040 1 Battery cover Available separately
Page 6 Company Confidential Issue 1 - September 2006
Page 7
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
6275i Parts List — Version 010 — Engine Code 0202939
Item Side X Y Description
A0001 Top Q 5 BB SHIELD ASSEMBLY
A0002 Bottom K 4 RX SHIELD ASSEMBLY
A0003 Bottom K 7 TX SHIELD ASSEMBLY
A0004 Bottom D 7 DUPLEXOR SHIELD ASSEMBLY
A0005 Bottom D 3 GPS SHIELD ASSEMBLY
A0006 Bottom F 7 DC DC SHIELD COVER
A0007 Bottom R 6 BT SHIELD ASSEMBLY
B2200 Top P 7 CRYSTAL 32.768KHZ +/-30PPM 12.5PF
C2001 Bottom I 6 CHIPCAP X7R 10N K 50V 0603
C2002 Bottom H 8 CHIPCAP NP0 47P J 50V 0402
C2004 Top U 3 CHIPCAP X7R 1N0 J 50V 0402
C2005 Top U 3 CHIPCAP NP0 22P J 50V 0402
C2006 Top T 3 CHIPCAP X5R 100N K 16V 0402
C2007 Top U 3 CHIPCAP X5R 1U K 6V3 0402
C2008 Top Q 5 CHIPCAP X5R 1U K 6V3 0402
C2009 Top R 5 CHIPCAP X7R 10N J 16V 0402
C2016 Top T 7 CHIPCAP NP0 33P J 50V 0402
C2017 Top T 7 CHIPCAP NP0 33P J 50V 0402
C2018 Top T 7 CHIPCAP NP0 33P J 50V 0402
C2019 Top T 7 CHIPCAP NP0 33P J 50V 0402
C2020 Top T 6 CHIPCAP X7R 3N3 J 50V 0402
C2021 Top S 6 CHIPCAP X7R 3N3 J 50V 0402
C2022 Top T 7 CHIPCAP X7R 3N3 J 50V 0402
C2023 Top T 7 CHIPCAP X7R 3N3 J 50V 0402
C2024 Top U 7 CHIPCAP X7R 3N3 J 50V 0402
C2025 Top U 7 CHIPCAP X7R 3N3 J 50V 0402
C2100 Top S 6 CHIPCAP X5R 100N K 16V 0402
C2101 Top S 6 CHIPCAP X5R 100N K 16V 0402
C2102 Top Q 7 CHIPCAP X5R 100N K 16V 0402
C2103 Top Q 7 CHIPCAP X5R 100N K 16V 0402
C2104 Top S 6 CHIPCAP X5R 100N K 16V 0402
Issue 1 - September 2006 Company Confidential Page 7
Page 8
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Item Side X Y Description
C2105 Top S 6 CHIPCAP X5R 100N K 16V 0402
C2106 Top R 6 CHIPCAP X5R 10UF 6V3 0603
C2107 Bottom A 3 CHIPCAP NP0 47P J 50V 0402
C2108 Top Q 6 CHIPCAP X5R 10UF 6V3 0603
C2109 Top Q 6 CHIPCAP X5R 10UF 6V3 0603
C2110 Top B 3 CHIPCAP NP0 47P J 50V 0402
C2111 Top B 2 CHIPCAP X7R 3N3 J 50V 0402
C2112 Bottom C 2 CHIPCAP NP0 47P J 50V 0402
C2113 Bottom C 2 CHIPCAP X7R 3N3 J 50V 0402
C2114 Top B 2 CHIPCAP X5R 100N K 16V 0402
C2115 Top B 2 CHIPCAP X7R 390P J 50V 0402
C2116 Top Q 6 CHIPCAP X5R 100N K 16V 0402
C2117 Top R 5 CHIPCAP X7R 10N J 16V 0402
C2118 Bottom S 4 CHIPCAP X5R 100N K 16V 0402
C2119 Bottom S 4 CHIPCAP X5R 100N K 16V 0402
C2120 Bottom S 4 CHIPCAP X5R 100N K 16V 0402
C2121 Bottom C 6 CHIPCAP NP0 100P J 50V 0402
C2122 Bottom C 5 CHIPCAP NP0 100P J 50V 0402
C2123 Bottom C 5 CHIPCAP X5R 1U5 K 4V 0402
C2124 Bottom C 5 CHIPCAP X5R 1U K 6V3 0603
C2126 Bottom C 3 CHIPCAP X5R 100N K 16V 0402
C2127 Bottom C 3 CHIPCAP X5R 100N K 16V 0402
C2128 Bottom C 3 CHIPCAP X7R 10N J 16V 0402
C2129 Bottom C 3 CHIPCAP X7R 10N J 16V 0402
C2130 Bottom A 3 CHIPCAP X7R 3N3 J 50V 0402
C2200 Top N 7 CHIPCAP X5R 1U K 6V3 0603
C2201 Top N 7 CHIPCAP X7R 10N J 16V 0402
C2202 Top P 6 CHIPCAP X7R 10N J 16V 0402
C2203 Top P 5 CHIPCAP X5R 1U5 K 4V 0402
C2204 Top M 6 CHIPCAP X5R 100N K 16V 0402
C2205 Top O 7 CHIPCAP X5R 1U5 K 4V 0402
C2206 Top O 7 CHIPCAP X5R 1U5 K 4V 0402
Page 8 Company Confidential Issue 1 - September 2006
Page 9
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Item Side X Y Description
C2207 Top O 7 CHIPCAP X5R 1U5 K 4V 0402
C2208 Top P 5 CHIPCAP X5R 1U5 K 4V 0402
C2209 Top P 6 CHIPCAP X5R 1U5 K 4V 0402
C2210 Top Q 7 CHIPCAP NP0 10P J 50V 0402
C2211 Top P 8 CHIPCAP NP0 10P J 50V 0402
C2212 Top P 5 CHIPCAP X5R 1U5 K 4V 0402
C2213 Top O 7 CHIPCAP X5R 1U5 K 4V 0402
C2214 Top O 7 CHIPCAP X5R 1U5 K 4V 0402
C2215 Top Q 6 CHIPCAP X5R 1U5 K 4V 0402
C2216 Top Q 6 CHIPCAP X5R 1U5 K 4V 0402
C2217 Top P 5 CHIPCAP X5R 100N K 16V 0402
C2218 Top O 4 CHIPCAP X5R 100N K 16V 0402
C2220 Top P 5 CHIPCAP X5R 1U5 K 4V 0402
C2221 Top N 5 CHIPCAP X5R 100N K 16V 0402
C2222 Top N 5 CHIPCAP X5R 100N K 16V 0402
C2223 Top N 7 CHIPCAP X5R 1U K 6V3 0603
C2224 Top N 7 CHIPCAP X5R 220N K 6.3V 0402
C2225 Top M 5 CHIPCAP X5R 1U5 K 4V 0402
C2226 Top M 6 CHIPCAP X5R 1U5 K 4V 0402
C2227 Top N 6 CHIPCAP X5R 1U5 K 4V 0402
C2228 Top N 6 CHIPCAP X5R 1U5 K 4V 0402
C2230 Top P 5 CHIPCAP X7R 10N J 16V 0402
C2231 Top P 7 CHIPCAP X7R 10N J 16V 0402
C2232 Top M 8 CHIPCAP X5R 4U7 K 6.3V 0603
C2233 Top M 6 CHIPCAP X5R 1U5 K 4V 0402
C2234 Top N 6 CHIPCAP X5R 1U5 K 4V 0402
C2235 Top N 6 CHIPCAP X5R 1U5 K 4V 0402
C2236 Top M 6 CHIPCAP X5R 1U5 K 4V 0402
C2237 Top M 6 CHIPCAP X5R 1U5 K 4V 0402
C2238 Top N 6 CHIPCAP X5R 1U5 K 4V 0402
C2239 Top M 7 CHIPCAP X5R 1U K 6V3 0603
C2240 Top M 7 CHIPCAP X5R 1U K 6V3 0603
Issue 1 - September 2006 Company Confidential Page 9
Page 10
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Item Side X Y Description
C2241 Top N 5 CHIPCAP X5R 1U5 K 4V 0402
C2300 Top R 2 CHIPCAP X5R 10UF 6V3 0603
C2302 Top R 2 CHIPCAP X5R 4U7 K 6.3V 0603
C2303 Top Q 2 CHIPCAP X5R 4U7 K 6.3V 0603
C2304 Top Q 2 CHIPCAP X5R 100N K 16V 0402
C2404 Top R 8 CHIPCAP X5R 100N K 16V 0402
C2405 Top Q 8 CHIPCAP X5R 4U7 K 6.3V 0603
C2406 Top R 8 CHIPCAP X5R 100N K 16V 0402
C2407 Top R 7 CHIPCAP X5R 1U0 K 25V T 1.0 1206
C2408 Top R 6 CHIPCAP X5R 1U0 K 25V T 1.0 1206
C2410 Bottom G 5 CHIPCAP NP0 10P J 50V 0402
C2600 Bottom F 2 CHIPCAP X5R 100N K 16V 0402
C2602 Bottom H 2 CHIPCAP X5R 4U7 K 6.3V 0603
C2700 Bottom R 2 CHIPCAP X5R 100N K 16V 0402
C2800 Top O 2 CHIPCAP X5R 1U5 K 4V 0402
C2801 Top P 2 CHIPCAP X7R 10N J 16V 0402
C2802 Top O 3 CHIPCAP X7R 10N J 16V 0402
C2803 Top Q 3 CHIPCAP X7R 10N J 16V 0402
C2804 Top P 4 CHIPCAP X7R 10N J 16V 0402
C2805 Top O 3 CHIPCAP X7R 10N J 16V 0402
C2806 Top P 4 CHIPCAP X7R 10N J 16V 0402
C2807 Top O 2 CHIPCAP X7R 10N J 16V 0402
C2808 Top Q 2 CHIPCAP X7R 10N J 16V 0402
C2809 Top Q 4 CHIPCAP X7R 10N J 16V 0402
C2810 Top P 2 CHIPCAP X7R 10N J 16V 0402
C2900 Bottom M 2 CHIPCAP X7R 10N J 16V 0402
C2901 Bottom M 2 CHIPCAP X7R 10N J 16V 0402
C2902 Top O 4 CHIPCAP X7R 10N J 16V 0402
C2903 Bottom M 6 CHIPCAP X7R 1N0 J 50V 0402
C2904 Bottom N 5 CHIPCAP X7R 33N K 10V 0402
C2905 Top O 4 CHIPCAP X7R 10N J 16V 0402
C2906 Bottom N 5 CHIPCAP X7R 1N0 J 50V 0402
Page 10 Company Confidential Issue 1 - September 2006
Page 11
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Item Side X Y Description
C2907 Bottom N 5 CHIPCAP X7R 33N K 10V 0402
C2908 Top O 3 CHIPCAP X7R 47N K 10V 0402
C2909 Top O 3 CHIPCAP X7R 4N7 J 25V 0402
C2910 Top O 4 CHIPCAP X7R 47N K 10V 0402
C3000 Top Q 4 CHIPCAP X7R 10N J 16V 0402
C3001 Top S 2 CHIPCAP X5R 100N K 10V 0402
C3002 Top Q 3 CHIPCAP X7R 10N J 16V 0402
C3003 Top T 4 CHIPCAP X5R 100N K 16V 0402
C3004 Top S 5 CHIPCAP X5R 100N K 16V 0402
C3200 Top P 8 CHIPCAP X5R 4U7 K 6.3V 0603
C3201 Top O 7 CHIPCAP X5R 100N K 16V 0402
C3202 Top P 7 CHIPCAP X5R 1U K 6V3 0603
C3204 Top O 8 CHIPCAP X5R 100N K 16V 0402
C3501 Top T 4 CHIPCAP NP0 47P J 50V 0402
C3609 Bottom C 4 CHIPCAP NP0 1P5 C 50V 0402
C3610 Bottom C 4 CHIPCAP NP0 1P5 C 50V 0402
C3611 Bottom C 6 CHIPCAP NP0 1P5 C 50V 0402
C3612 Bottom C 6 CHIPCAP NP0 3P3 C 50V 0402
C3650 Top N 3 CHIPCAP X5R 100N K 10V 0402
C3651 Top N 3 CHIPCAP X5R 100N K 10V 0402
C3656 Top N 5 CHIPCAP X7R 10N J 16V 0402
C3657 Top N 4 CHIPCAP X5R 1U5 K 4V 0402
C6031 Bottom S 5 CHIPCAP NP0 18P J 50V 0402
C6032 Bottom M 5 CHIPCAP NP0 18P J 50V 0402
C6033 Bottom Q 6 CHIPCAP X7R 10N J 16V 0402
C6034 Bottom R 6 CHIPCAP X7R 10N J 16V 0402
C6035 Bottom R 5 CHIPCAP X7R 10N J 16V 0402
C6036 Bottom Q 6 CHIPCAP X7R 10N J 16V 0402
C6037 Bottom Q 6 CHIPCAP X5R 1U5 K 4V 0402
C6038 Bottom R 5 CHIPCAP X7R 10N J 16V 0402
C6039 Bottom R 6 CHIPCAP NP0 18P J 50V 0402
C6040 Bottom S 2 CHIPCAP NP0 1P2 C 50V 0402
Issue 1 - September 2006 Company Confidential Page 11
Page 12
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Item Side X Y Description
C6051 Bottom R 6 CHIPCAP NP0 2P7 C 50V 0402
C6052 Bottom R 6 CHIPCAP NP0 2P7 C 50V 0402
C6055 Bottom S 5 CHIPCAP X5R 1U K 6V3 0402
C6101 Top R 7 CHIPCAP X5R 100N K 16V 0402
C6102 Top T 8 CHIPCAP NP0 100P J 50V 0402
C6103 Top S 7 CHIPCAP NP0 47P J 50V 0402
C6104 Top S 7 CHIPCAP NP0 27P J 50V 0402
C6105 Top S 7 CHIPCAP X7R 10N J 16V 0402
C6107 Top S 7 CHIPCAP X5R 100N K 16V 0402
C6108 Top S 7 CHIPCAP X7R 10N J 16V 0402
C6109 Top R 7 CHIPCAP X7R 33N K 10V 0402
C6110 Top S 8 CHIPCAP X5R 100N K 16V 0402
C6111 Top S 8 CHIPCAP X5R 100N K 16V 0402
C6112 Top S 8 CHIPCAP X7R 33N K 10V 0402
C6113 Top S 7 CHIPCAP X7R 33N K 10V 0402
C6114 Top R 8 CHIPCAP X7R 33N K 10V 0402
C6115 Top S 8 CHIPCAP X5R 100N K 16V 0402
C6200 Bottom D 4 CHIPCAP X5R 1U5 K 4V 0402
C6203 Bottom E 5 CHIPCAP X5R 100N K 16V 0402
C6205 Bottom E 4 CHIPCAP X5R 1U5 K 4V 0402
C6206 Bottom E 4 CHIPCAP X5R 1U K 6V3 0402
C6250 Bottom D 5 CHIPCAP X5R 100N K 10V 0402
C6251 Bottom E 5 CHIPCAP NP0 2P7 C 50V 0402
C6253 Bottom E 2 CHIPCAP NP0 47P J 50V 0402
C6255 Bottom E 3 CHIPCAP X7R 10N J 16V 0402
C6256 Bottom D 3 CHIPCAP NP0 22P J 50V 0402
C6257 Bottom D 3 CHIPCAP NP0 2P7 C 50V 0402
C6258 Bottom D 3 CHIPCAP NP0 15P J 50V 0402
C6259 Bottom E 3 CHIPCAP X7R 10N J 16V 0402
C6260 Bottom E 3 CHIPCAP NP0 22P J 50V 0402
C6261 Bottom E 3 CHIPCAP X7R 10N J 16V 0402
C6262 Bottom E 3 CHIPCAP NP0 22P J 50V 0402
Page 12 Company Confidential Issue 1 - September 2006
Page 13
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Item Side X Y Description
C6263 Bottom D 3 CHIPCAP NP0 22P J 50V 0402
C6264 Bottom D 3 CHIPCAP NP0 22P J 50V 0402
C6265 Bottom D 3 CHIPCAP X7R 10N J 16V 0402
C6266 Bottom D 3 CHIPCAP NP0 22P J 50V 0402
C6267 Bottom E 4 CHIPCAP NP0 22P J 50V 0402
C6268 Bottom E 4 CHIPCAP X5R 100N K 16V 0402
C6600 Bottom F 2 CHIPCAP X5R 220N K 6.3V 0402
C6601 Bottom F 3 CHIPCAP X5R 100N K 16V 0402
C6602 Bottom F 3 CHIPCAP NP0 27P J 50V 0402
C6603 Bottom G 5 CHIPCAP X5R 100N K 16V 0402
C6604 Bottom G 5 CHIPCAP NP0 27P J 50V 0402
C6607 Bottom H 4 CHIPCAP X7R 10N J 16V 0402
C6608 Bottom H 6 CHIPCAP X5R 100N K 16V 0402
C6612 Bottom G 2 CHIPCAP X5R 4U7 K 6.3V 0603
C6613 Bottom G 2 CHIPCAP X5R 10U M 6V3 0805
C6614 Bottom H 4 CHIPCAP X5R 4U7 K 6.3V 0603
C6615 Bottom G 6 CHIPCAP X5R 100N K 16V 0402
C6617 Bottom G 3 CHIPCAP X5R 4U7 K 6.3V 0603
C6618 Bottom F 2 CHIPCAP X7R 33N K 10V 0402
C6619 Bottom H 2 CHIPCAP X5R 4U7 K 6.3V 0603
C6621 Bottom G 3 CHIPCAP NP0 10P J 50V 0402
C7000 Bottom K 8 CHIPCAP X7R 10N J 16V 0402
C7001 Bottom K 7 CHIPCAP X7R 10N J 16V 0402
C7002 Bottom M 6 CHIPCAP X5R 100N K 10V 0402
C7003 Bottom L 8 CHIPCAP NP0 3P3 C 50V 0402
C7004 Bottom L 8 CHIPCAP NP0 220P J 25V 0402
C7005 Bottom M 8 CHIPCAP NP0 100P J 50V 0402
C7006 Bottom M 8 CHIPCAP NP0 2N2 J 16V 0603
C7007 Bottom L 8 CHIPCAP NP0 100P J 50V 0402
C7008 Bottom M 7 CHIPCAP NP0 4P7 C 50V 0402
C7009 Bottom M 7 CHIPCAP X5R 1U K 6V3 0402
C7010 Bottom M 7 CHIPCAP NP0 3P3 C 50V 0402
Issue 1 - September 2006 Company Confidential Page 13
Page 14
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Item Side X Y Description
C7011 Bottom L 8 CHIPCAP X7R 10N J 16V 0402
C7012 Bottom L 8 CHIPCAP NP0 18P J 50V 0402
C7013 Bottom L 6 CHIPCAP NP0 33P J 50V 0402
C7014 Bottom L 6 CHIPCAP NP0 18P J 50V 0402
C7015 Bottom L 6 CHIPCAP NP0 33P J 50V 0402
C7016 Bottom L 6 CHIPCAP X7R 10N J 16V 0402
C7017 Bottom L 6 CHIPCAP NP0 47P J 50V 0402
C7018 Bottom K 7 CHIPCAP NP0 10P J 50V 0402
C7019 Bottom M 7 CHIPCAP NP0 12P J 50V 0402
C7020 Bottom M 7 CHIPCAP NP0 18P J 50V 0402
C7021 Bottom M 7 CHIPCAP X7R 10N J 16V 0402
C7022 Bottom K 6 CHIPCAP NP0 3P3 C 50V 0402
C7023 Bottom K 6 CHIPCAP NP0 1P2 C 50V 0402
C7024 Bottom K 7 CHIPCAP NP0 1P2 C 50V 0402
C7026 Bottom K 7 CHIPCAP NP0 0P5 C 50V 0402
C7027 Bottom K 7 CHIPCAP NP0 0P5 C 50V 0402
C7029 Bottom K 7 CHIPCAP NP0 3P3 C 50V 0402
C7030 Bottom K 8 CHIPCAP NP0 3P3 C 50V 0402
C7031 Bottom M 7 CHIPCAP NP0 30P G 50V 0402
C7100 Bottom M 4 CHIPCAP X7R 10N J 16V 0402
C7101 Bottom M 4 CHIPCAP X5R 330N K 10V 0603
C7102 Bottom L 4 CHIPCAP X7R 33N K 10V 0402
C7103 Bottom L 4 CHIPCAP NP0 33P J 50V 0402
C7104 Bottom L 4 CHIPCAP X7R 1N0 J 50V 0402
C7105 Bottom M 2 CHIPCAP X7R 10N J 16V 0402
C7106 Bottom M 3 CHIPCAP X7R 10N J 16V 0402
C7107 Bottom M 2 CHIPCAP X7R 10N J 16V 0402
C7108 Bottom L 3 CHIPCAP X7R 10N J 16V 0402
C7109 Bottom L 3 CHIPCAP X7R 10N J 16V 0402
C7110 Bottom M 2 CHIPCAP X7R 10N J 16V 0402
C7111 Bottom M 3 CHIPCAP X7R 10N J 16V 0402
C7112 Bottom L 4 CHIPCAP X7R 10N J 16V 0402
Page 14 Company Confidential Issue 1 - September 2006
Page 15
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Item Side X Y Description
C7113 Bottom L 3 CHIPCAP X7R 10N J 16V 0402
C7162 Bottom I 2 CHIPCAP NP0 100P J 50V 0402
C7163 Bottom I 2 CHIPCAP NP0 100P J 50V 0402
C7164 Bottom J 2 CHIPCAP NP0 100P J 50V 0402
C7165 Bottom H 3 CHIPCAP NP0 56P J 50V 0402
C7166 Bottom H 4 CHIPCAP NP0 1P8 C 50V 0402
C7167 Bottom H 2 CHIPCAP NP0 12P J 50V 0402
C7168 Bottom H 2 CHIPCAP X5R 100N K 10V 0402
C7169 Bottom I 2 CHIPCAP NP0 1P5 C 50V 0402
C7170 Bottom J 4 CHIPCAP NP0 100P J 50V 0402
C7171 Bottom J 4 CHIPCAP NP0 5P6 C 50V 0402
C7172 Bottom I 4 CHIPCAP X7R 47N K 10V 0402
C7173 Bottom I 2 CHIPCAP NP0 12P J 50V 0402
C7174 Bottom J 2 CHIPCAP X7R 3N3 J 50V 0402
C7175 Bottom J 2 CHIPCAP NP0 22P J 50V 0402
C7176 Bottom J 3 CHIPCAP X7R 1N0 J 50V 0402
C7177 Bottom J 3 CHIPCAP NP0 4P7 C 50V 0402
C7178 Bottom J 4 CHIPCAP NP0 3P9 C 50V 0402
C7179 Bottom K 4 CHIPCAP NP0 10P J 50V 0402
C7180 Bottom K 3 CHIPCAP NP0 6P8 C 50V 0402
C7181 Bottom K 3 CHIPCAP NP0 6P8 C 50V 0402
C7182 Bottom K 3 CHIPCAP X7R 3N3 J 50V 0402
C7183 Bottom J 2 CHIPCAP X5R 100N K 10V 0402
C7184 Bottom J 3 CHIPCAP NP0 2P2 C 50V 0402
C7185 Bottom J 3 CHIPCAP NP0 100P J 50V 0402
C7187 Bottom L 2 CHIPCAP NP0 12P J 50V 0402
C7188 Bottom L 2 CHIPCAP NP0 12P J 50V 0402
C7189 Bottom H 3 CHIPCAP NP0 0P5 C 50V 0402
C7200 Bottom L 4 CHIPCAP X5R 1U K 6V3 0402
C7201 Bottom L 5 CHIPCAP X7R 10N J 16V 0402
C7202 Bottom K 5 CHIPCAP X7R 1N0 J 50V 0402
C7203 Bottom L 5 CHIPCAP NP0 15P J 50V 0402
Issue 1 - September 2006 Company Confidential Page 15
Page 16
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Item Side X Y Description
C7205 Bottom L 5 CHIPCAP NP0 8P2 C 50V 0402
C7206 Bottom L 8 CHIPCAP NP0 27P J 50V 0402
C7207 Bottom M 2 CHIPCAP NP0 22P J 50V 0402
C7208 Bottom L 5 CHIPCAP NP0 18P J 50V 0402
C7209 Bottom L 4 CHIPCAP X7R 10N J 16V 0402
C7210 Bottom M 4 CHIPCAP X5R 100N K 10V 0402
C7211 Bottom L 5 CHIPCAP NP0 47P J 50V 0402
C7212 Bottom J 4 CHIPCAP NP0 1P8 C 50V 0402
C7213 Bottom L 5 CHIPCAP X7R 3N3 J 50V 0402
C7214 Bottom L 4 CHIPCAP X7R 33N K 10V 0402
C7215 Bottom L 4 CHIPCAP X7R 6N8 K 25V 0402
C7216 Bottom K 5 CHIPCAP X7R 1N0 J 50V 0402
C7217 Bottom K 5 CHIPCAP X7R 1N0 J 50V 0402
C7218 Bottom K 4 CHIPCAP X5R 1U K 6V3 0402
C7219 Bottom K 5 CHIPCAP X7R 10N J 16V 0402
C7220 Bottom J 5 CHIPCAP X5R 100N K 10V 0402
C7221 Bottom M 4 CHIPCAP X7R 10N J 16V 0402
C7222 Bottom M 4 CHIPCAP X5R 100N K 10V 0402
C7300 Bottom J 7 CHIPCAP X7R 1N0 J 50V 0402
C7301 Bottom J 7 CHIPCAP NP0 3P3 C 50V 0402
C7302 Bottom J 7 CHIPCAP X7R 10N J 16V 0402
C7303 Bottom J 7 CHIPCAP NP0 3P3 C 50V 0402
C7304 Bottom I 8 CHIPCAP NP0 15P J 50V 0402
C7305 Bottom J 8 CHIPCAP X7R 1N0 J 50V 0402
C7306 Bottom J 8 CHIPCAP NP0 10P J 50V 0402
C7311 Bottom B 8 CHIPCAP NP0 10P J 50V 0402
C7312 Bottom B 8 CHIPCAP NP0 47P J 50V 0402
C7313 Bottom D 6 CHIPCAP X7R 10N J 16V 0402
C7314 Bottom D 6 CHIPCAP NP0 10P J 50V 0402
C7315 Bottom D 6 CHIPCAP X7R 3N3 J 50V 0402
C7316 Bottom D 6 CHIPCAP X7R 3N3 J 50V 0402
C7317 Bottom I 7 CHIPCAP X5R 10U M 6V3 0805
Page 16 Company Confidential Issue 1 - September 2006
Page 17
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Item Side X Y Description
C7318 Bottom H 8 CHIPCAP X5R 10U M 6V3 0805
C7319 Bottom I 7 CHIPCAP NP0 270P J 50V 0402
C7320 Bottom J 6 CHIPCAP X7R 6N8 K 25V 0402
C7321 Bottom J 7 CHIPCAP X7R 1N0 J 50V 0402
C7322 Bottom I 6 CHIPCAP X7R 1N0 J 50V 0402
C7323 Bottom J 7 CHIPCAP X7R 1N0 J 50V 0402
C7324 Bottom J 7 CHIPCAP NP0 3P3 C 50V 0402
C7325 Bottom I 6 CHIPCAP NP0 7P5 C 50V 0402
C7326 Bottom I 7 CHIPCAP NP0 3P3 C 50V 0402
C7350 Bottom F 6 CHIPCAP NP0 47P J 50V 0402
C7351 Bottom F 6 CHIPCAP NP0 47P J 50V 0402
C7352 Bottom F 6 CHIPCAP NP0 10P J 50V 0402
C7353 Bottom G 7 CHIPCAP NP0 47P J 50V 0402
C7354 Bottom F 6 CHIPCAP X5R 4U7 K 6.3V 0603
C7355 Bottom F 6 CHIPCAP X5R 4U7 K 6.3V 0603
C7356 Bottom G 8 CHIPCAP X7R 10N J 16V 0402
C7357 Bottom G 6 CHIPCAP X5R 10U M 6V3 0805
C7358 Bottom G 7 CHIPCAP X5R 10U M 6V3 0805
D2200 Top O 6 UEMEK2v0 LF WDENA TFBGA244
D2800 Top P 3 TIKUEDGE v2.0 LF CO27 GZG289
D3000 Top R 3 COMBO 128MNOR+256MM3+128MSDRAM FBGA133
D6200 Bottom D 4 GPS5002ZRE GPS ASIC UBGA63
D6601 Bottom H 5 HW ACCELERATOR STV0984N
E2100 Bottom T 4 CONN SPACER PAD
E2101 Bottom T 3 CONN SPACER PAD
F2000 Top U 3 SM FUSE F 2.0A 32V 0603
G6250 Bottom E 5 TCXO 16.368MHZ +-1.5PPM 2.8V GPS
G7200 Bottom L 5 VCTCXO 19.2MHZ +-2PPM 2.78V 2.2MA
G7201 Bottom J 5 UHF VCO 986-1034MHz/2040-2140MHz
L2000 Top U 3 FERR.BEAD 220R/100M 2A 0R05 0603
L2001 Top T 4 FERRITE BEAD 0.6R 600R/100MZ 0402
L2002 Top T 4 FERRITE BEAD 0.6R 600R/100MZ 0402
Issue 1 - September 2006 Company Confidential Page 17
Page 18
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Item Side X Y Description
L2003 Top T 4 FERRITE BEAD 0.6R 600R/100MZ 0402
L2004 Top T 6 CHIP BEAD ARRAY 2X1000R 0R75 0405
L2005 Top T 7 CHIP BEAD ARRAY 2X1000R 0R75 0405
L2006 Top U 7 CHIP BEAD ARRAY 2X1000R 0R75 0405
L2100 Top B 2 FERRITE BEAD 0.6R 600R/100MZ 0402
L2101 Bottom A 3 FERRITE BEAD 0.6R 600R/100MZ 0402
L2102 Bottom C 2 FERRITE BEAD 0.6R 600R/100MZ 0402
L2103 Top B 1 CHIP BEAD ARRAY 2X1000R 0R75 0405
L2104 Bottom B 6 CHIP BEAD ARRAY 2X220R 0405
L2105 Top A 1 CHIP COIL 100N J Q16/300MHZ 0402
L2301 Top S 2 INDUCT WW 10UH 0A34 0R54 310 case size
L2302 Top Q 2 FERR.BEAD 220R/100M 2A 0R05 0603
L2400 Top R 8 FERR.BEAD 220R/100M 2A 0R05 0603
L2401 Top Q 7 CHOKE 3U3 M 0R1 1.2A 4.0X4.0X1.2
L3609 Bottom C 4 CHIP COIL 6N8 K Q29/800MHZ 0402
L3610 Bottom C 4 CHIP COIL 6N8 K Q29/800MHZ 0402
L3611 Bottom C 7 CHIP COIL 6N8 K Q29/800MHZ 0402
L3612 Bottom C 6 CHIP COIL 3N3 +-0N3 Q28/800M 0402
L6030 Bottom R 6 CHIP COIL 2N7 +-0N3 Q29/800M 0402
L6031 Bottom R 6 CHIP COIL 2N7 +-0N3 Q29/800M 0402
L6032 Bottom R 5 CHIP COIL 22N J Q28/800MHZ 0402
L6100 Top T 7 CHIP COIL 68N J Q17/300MHZ 0402
L6101 Top S 7 CHIP COIL 120NH J Q8/100MHZ 0402
L6102 Top S 7 CHIP COIL 47N +-3% Q25/200MHz 0402
L6251 Bottom D 3 CHIP COIL 8N2 J Q28/800MHZ 0402
L6254 Bottom E 3 CHIP COIL 3N9 +-0N3 Q28/800M 0402
L7000 Bottom M 7 CHIP COIL 27N J Q27/800MHZ 0402
L7001 Bottom K 6 CHIP COIL 27N J Q27/800MHZ 0402
L7002 Bottom K 6 CHIP COIL 33N J Q23/800MHZ 0402
L7003 Bottom K 6 CHIP COIL 27N J Q27/800MHZ 0402
L7004 Bottom K 7 CHIP COIL 6N8 J Q27/800MHZ 0402
L7005 Bottom K 7 CHIP COIL 12N J Q31/800MHZ 0402
Page 18 Company Confidential Issue 1 - September 2006
Page 19
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Item Side X Y Description
L7006 Bottom K 7 CHIP COIL 6N8 J Q27/800MHZ 0402
L7101 Bottom L 4 CHIP COIL 33NH J Q12/100MHZ 0603
L7160 Bottom H 3 CHIP COIL 7N5 Q25/100MHZ 0402
L7161 Bottom H 3 CHIP COIL 19N J Q24/250MHZ 0402
L7162 Bottom I 2 CHIP COIL 12N J Q31/800MHZ 0402
L7163 Bottom J 3 CHIP COIL 3N3 +-0N3 Q28/800M 0402
L7164 Bottom J 4 CHIP COIL 82N +-0N3 Q17/300M 0402
L7165 Bottom H 4 CHIP COIL 12N J Q31/800MHZ 0402
L7166 Bottom I 2 CHIP COIL 3N3 +-0N3 Q28/800M 0402
L7167 Bottom I 4 CHIP COIL 220N J Q8/50MHZ 0603
L7168 Bottom I 2 CHIP COIL 18N J Q29/800MHZ 0402
L7169 Bottom I 4 CHIP COIL 15N J Q30/800MHZ 0402
L7170 Bottom J 3 CHIP COIL 82N +-0N3 Q17/300M 0402
L7171 Bottom J 4 CHIP COIL 180N J Q13/100MHZ 0603
L7172 Bottom K 4 CHIP COIL 120N J Q16/100MHZ 0603
L7173 Bottom K 4 CHIP COIL 120N J Q16/100MHZ 0603
L7174 Bottom K 3 CHIP COIL 220N J Q8/50MHZ 0603
L7175 Bottom K 3 CHIP COIL 220N J Q8/50MHZ 0603
L7176 Bottom J 3 CHIP COIL 120N J Q16/100MHZ 0603
L7177 Bottom L 2 CHIP COIL 100N J Q12/100MHZ 0603
L7178 Bottom L 2 CHIP COIL 120N J Q16/100MHZ 0603
L7179 Bottom L 2 CHIP COIL 120N J Q16/100MHZ 0603
L7201 Bottom J 4 CHIP COIL 3N3 +-0N3 Q28/800M 0402
L7301 Bottom I 7 CHIP COIL 3N9 +-0N3 Q28/800M 0402
L7302 Bottom D 8 DIR.COUPLER 1850-1910MHZ 1.6X0.8
L7303 Bottom B 7 CHIP COIL 33N J Q23/800MHZ 0402
L7304 Bottom D 7 CHIP COIL 10N J Q30/800MHZ 0402
L7305 Bottom D 7 DIR.COUPLER 824-849MHZ 1.6X0.8MM
L7306 Bottom I 7 CHIP COIL 22N J Q28/800MHZ 0402
L7350 Bottom G 7 FERRITE BEAD 0.015R 42R/100M 0805
L7351 Bottom F 7 INDUCT WW 1.5UH 0.096 OHM 1.1A
L7397 Bottom B 7 CHIP COIL 10N J Q30/800MHZ 0402
Issue 1 - September 2006 Company Confidential Page 19
Page 20
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Item Side X Y Description
M2400 Bottom T 5 SMD-VIBRA MOTOR 1.3V 80mA 9000RPM
N2001 Top Q 5 NUT/CP2137 ASIC HBCC16++
N2100 Bottom C 5 AF AMP 1W LM4990 NOPB 2.8V uSMD9
N2300 Top R 2 DC/DC CONV LM3661-1.35V/1.05V
N2401 Top R 7 STEP-UP DC/DC CONV TK11891F-G SON3024-8
N2600 Bottom G 1 IRDA 1.15Mbps 2V4
N3200 Top O 8 VREG & LEVELSHIFT(LP3928)USMD16
N3650 Top N 4 VREG LP3985ITLX-2.8 NOPB USMD5
N6030 Bottom R 6 BC4-ROM1.0RDL
N6100 Top S 7 FM RECEIVER TEA5761UK N4B (Ti) CSP
N6200 Bottom E 4 LI VREG TK63128B-G 2.8V WLCSP4
N6250 Bottom D 2 TR BGA622 LNA 3V NF 1.1DB SOT343
N6251 Bottom D 3 GPS RX TRF5101 PG2.1 PBGA-49
N6600 Bottom G 2 REG LP3981YDX-2.8/NOPB 0.3A LLP-6
N6601 Bottom H 3 LI VREG 1.2V/150mA (LP3990YD 1.2) LLP6
N6602 Bottom G 3 LI VREG TK63118B-G 1.8V WLCSP4
N7000 Bottom L 7 JUPITER D4 PMB3365G VQFN-40
N7100 Bottom L 3 BATMAN RF RX ASIC STB7102FTR
N7160 Bottom I 3 LNA/MIXER/DOWNCNTR ALFRED VQFN-24
N7200 Bottom M 5 1XPLL/SYNTH 2.5GHZ(LMX2310U)MLF20
N7300 Bottom J 7 PW AMP RF3448 CDMA1900
N7301 Bottom J 6 PW AMP RF3449 CDMA800 LFM
N7302 Bottom D 6 ASIP STPAC01F2 CDMA PWR DET BGA-8
N7350 Bottom F 6 RF4013 V-E2.2 DC-DC BUCK CONV QFN 16
R2001 Bottom G 7 CHIP VARISTOR VWM15V VC50V 0402
R2002 Top S 5 NTC RES 0W1 47K J B 4050+-3% 0402
R2003 Top T 3 CHIPRES 0W06 100K J 0402
R2004 Top U 3 CHIPRES 0W06 33R J 0402
R2005 Top U 3 CHIP VARISTOR VWM15V VC50V 0402
R2006 Top T 3 ASIP USB2 FILTER BGA10 PBFREE
R2007 Top U 3 CHIPRES 0W06 220K J 0402
Page 20 Company Confidential Issue 1 - September 2006
Page 21
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Item Side X Y Description
R2008 Top U 3 CHIPRES 0W06 220K J 0402
R2009 Top U 7 CHIP VARISTOR VWM15V VC50V 0402
R2010 Top T 7 CHIP VARISTOR VWM15V VC50V 0402
R2011 Top U 7 CHIP VARISTOR VWM15V VC50V 0402
R2012 Top U 7 CHIP VARISTOR VWM15V VC50V 0402
R2013 Bottom Q 7 ASIP 4XESD *** PB-FREE *** BGA5
R2017 Top T 5 CHIPRES 0W06 330R J 0402
R2018 Top T 7 CHIPRES 0W06 330R J 0402
R2019 Top S 6 CHIP VARISTOR VWM15V VC50V 0402
R2020 Top S 6 CHIP VARISTOR VWM15V VC50V 0402
R2100 Top R 6 CHIPRES 0W06 10K J 0402
R2101 Top S 6 CHIPRES 0W06 1K0 J 0402
R2102 Top Q 6 CHIPRES 0W06 10R J 0402
R2103 Top Q 6 CHIPRES 0W06 10R J 0402
R2106 Top N 2 CHIPRES 0W06 100K J 0402
R2107 Bottom C 1 CHIP VARISTOR VWM15V VC50V 0402
R2108 Top R 5 CHIPRES 0W06 1K0 J 0402
R2111 Top R 6 CHIPRES 0W06 47K J 0402
R2112 Bottom D 5 CHIPRES 0W06 100K J 0402
R2113 Bottom C 4 CHIPRES 0W06 22K J 0402
R2114 Bottom C 6 CHIPRES 0W06 100K J 0402
R2115 Bottom C 4 CHIPRES 0W06 22K J 0402
R2116 Bottom D 5 CHIPRES 0W06 100K J 0402
R2117 Bottom B 7 CHIP VARISTOR VWM15V VC50V 0402
R2118 Bottom B 6 CHIP VARISTOR VWM15V VC50V 0402
R2119 Top S 5 CHIPRES 0W06 100K J 0402
R2120 Top S 6 CHIPRES 0W06 100K J 0402
R2121 Bottom A 1 CHIPRES 0W06 4K7 J 0402
R2123 Bottom C 3 CHIPRES 0W06 2K2 J 0402
R2124 Bottom C 3 CHIPRES 0W06 2K2 J 0402
R2200 Top N 7 CHIPRES 0W25 0R22 J 0805
R2202 Top Q 5 CHIPRES 0W06 10K J 0402
Issue 1 - September 2006 Company Confidential Page 21
Page 22
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Item Side X Y Description
R2203 Top Q 5 CHIPRES 0W06 4K7 J 0402
R2204 Top Q 5 CHIPRES 0W06 4K7 J 0402
R2205 Top Q 5 CHIPRES 0W06 100K J 0402
R2206 Top Q 5 CHIPRES 0W06 100K J 0402
R2207 Top P 7 CHIPRES 0W06 100K J 0402
R2208 Top M 5 CHIPRES 0W06 27K J 0402
R2209 Top O 7 CHIPRES 0W06 100K J 0402
R2401 Bottom G 8 CHIP VARISTOR VWM15V VC50V 0402
R2403 Bottom C 8 CHIP VARISTOR VWM15V VC50V 0402
R2404 Bottom G 8 CHIP VARISTOR VWM15V VC50V 0402
R2406 Top R 6 CHIPRES 0W06 10K J 0402
R2407 Top R 6 CHIPRES 0W06 330K J 0402
R2408 Top T 4 CHIPRES 0W06 33R J 0402
R2409 Top T 3 CHIPRES 0W06 20R J 0402
R2410 Top T 3 CHIPRES 0W06 10K J 0402
R2411 Top T 3 CHIPRES 0W06 33R J 0402
R2412 Bottom R 4 CHIPRES 0W06 10K J 0402
R2413 Top S 5 CHIPRES 0W06 10K J 0402
R2414 Bottom R 4 CHIPRES 0W06 10K J 0402
R2415 Bottom S 5 CHIPRES 0W06 82R J 0402
R2416 Bottom R 5 CHIPRES 0W06 82R J 0402
R2417 Bottom P 5 CHIPRES 0W06 33R J 0402
R2418 Bottom Q 5 CHIPRES 0W06 33R J 0402
R2419 Bottom Q 5 CHIPRES 0W06 33R J 0402
R2420 Bottom C 7 CHIP VARISTOR VWM15V VC50V 0402
R2421 Bottom Q 8 CHIP VARISTOR VWM15V VC50V 0402
R2422 Bottom R 8 CHIP VARISTOR VWM15V VC50V 0402
R2423 Bottom P 5 CHIPRES 0W06 33R J 0402
R2424 Bottom P 5 CHIPRES 0W06 33R J 0402
R2425 Bottom P 5 CHIPRES 0W06 33R J 0402
R2426 Top T 4 CHIPRES 0W06 10K J 0402
R2427 Top Q 6 CHIPRES JUMPER 0R0 0402
Page 22 Company Confidential Issue 1 - September 2006
Page 23
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Item Side X Y Description
R2430 Top T 2 CHIPRES 0W06 68R J 0402
R2432 Top T 3 CHIPRES 0W06 20R J 0402
R2600 Bottom H 2 CHIPRES 0W125 4R7 J 0805
R2700 Bottom R 3 ASIP SIM INTERFACE **low cap** BGA8
R2800 Bottom I 5 CHIPRES 0W06 4K7 J 0402
R2801 Bottom I 5 CHIPRES 0W06 4K7 J 0402
R2803 Top Q 4 CHIPRES 0W06 100R J 0402
R2804 Top Q 4 CHIPRES 0W06 100R J 0402
R2809 Top Q 4 CHIPRES 0W06 10K J 0402
R2900 Bottom M 2 CHIPRES 0W06 4K7 J 0402
R2901 Top O 4 CHIPRES 0W06 1K0 J 0402
R2902 Bottom O 5 CHIPRES 0W06 4K7 J 0402
R2904 Top O 4 CHIPRES 0W06 1K0 J 0402
R2905 Bottom N 5 CHIPRES 0W06 4K7 J 0402
R2906 Top O 4 CHIPRES 0W06 1K0 J 0402
R2907 Top O 2 CHIPRES 0W06 1K0 J 0402
R2908 Top O 3 CHIPRES 0W06 4K7 J 0402
R3000 Top Q 3 CHIPRES 0W06 47R J 0402
R3001 Top S 5 CHIPRES 0W06 100K J 0402
R3002 Top S 5 CHIPRES 0W06 4K7 J 0402
R3207 Top N 7 CHIPRES 0W06 1K0 J 0402
R3208 Top P 2 CHIPRES 0W06 100K J 0402
R3209 Top P 2 CHIPRES 0W06 100K J 0402
R3502 Top U 4 CHIPRES 0W06 4K7 J 0402
R3503 Top U 4 CHIP VARISTOR VWM15V VC50V 0402
R3600 Bottom B 6 CHIP VARISTOR VWM15V VC50V 0402
R3611 Top N 4 ASIP 4XESD *** PB-FREE *** BGA5
R3614 Bottom B 6 CHIP VARISTOR VWM15V VC50V 0402
R3652 Top N 4 CHIPRES JUMPER 0R0 0402
R3654 Top N 5 CHIPRES 0W06 100K J 0402
R6030 Bottom Q 6 CHIPRES 0W06 10K J 0402
R6031 Bottom R 5 CHIPRES 0W06 10K J 0402
Issue 1 - September 2006 Company Confidential Page 23
Page 24
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Item Side X Y Description
R6032 Bottom Q 6 CHIPRES 0W06 2R2 J 0402
R6034 Bottom R 6 CHIPRES 0W06 10K J 0402
R6037 Bottom R 5 CHIPRES 0W06 100K J 0402
R6100 Top S 7 CHIPRES 0W06 10K J 0402
R6101 Top S 7 CHIPRES 0W06 100K J 0402
R6205 Bottom D 4 CHIPRES 0W06 10K J 0402
R6251 Bottom D 5 CHIPRES 0W06 10R J 0402
R6600 Bottom H 4 CHIPRES 0W06 4K7 J 0402
R6601 Bottom G 4 CHIPRES 0W06 4K7 J 0402
R6602 Bottom H 4 CHIPRES JUMPER 0R0 0402
R6604 Bottom G 3 CHIPRES 0W06 10K J 0402
R6608 Bottom I 5 CHIPRES JUMPER 0R0 0402
R6628 Bottom F 2 CHIPRES 0W06 100K J 0402
R7000 Bottom K 8 CHIPRES JUMPER 0R0 0402
R7001 Bottom M 8 CHIPRES 0W06 10K J 0402
R7002 Bottom M 8 CHIPRES 0W06 27K J 0402
R7007 Bottom M 6 CHIPRES 0W06 22K J 0402
R7008 Bottom M 7 CHIPRES 0W06 43K 1% 0402
R7009 Bottom L 6 CHIPRES 0W06 12K J 0402
R7010 Bottom K 7 CHIPRES JUMPER 0R0 0402
R7011 Bottom M 7 CHIPRES 0W06 150R J 0402
R7012 Bottom M 7 CHIPRES 0W06 180R J 0402
R7100 Bottom M 4 CHIPRES 0W06 1K0 J 0402
R7101 Bottom M 4 CHIPRES 0W06 470R J 0402
R7102 Bottom M 4 CHIPRES 0W06 4K7 J 0402
R7103 Bottom M 2 CHIPRES 0W06 8K2 J 0402
R7104 Bottom M 3 CHIPRES 0W06 27K J 0402
R7161 Bottom I 2 CHIPRES 0W06 47K J 0402
R7162 Bottom J 2 CHIPRES 0W06 47K J 0402
R7163 Bottom J 2 CHIPRES 0W06 47K J 0402
R7164 Bottom H 2 CHIPRES 0W06 4R3 J 0402
R7165 Bottom J 3 CHIPRES 0W06 82R J 0402
Page 24 Company Confidential Issue 1 - September 2006
Page 25
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Item Side X Y Description
R7166 Bottom I 2 CHIPRES 0W06 4R3 J 0402
R7200 Bottom L 4 CHIPRES 0W06 10R J 0402
R7201 Bottom K 4 CHIPRES 0W06 10K J 0402
R7206 Top O 3 CHIPRES JUMPER 0R0 0402
R7209 Bottom L 4 CHIPRES 0W06 10R J 0402
R7210 Bottom J 5 CHIPRES 0W06 150R J 0402
R7211 Bottom L 5 CHIPRES 0W06 3K9 J 0402
R7212 Bottom K 5 CHIPRES 0W06 10K J 0402
R7213 Bottom K 5 CHIPRES 0W06 10K J 0402
R7215 Bottom J 5 CHIPRES 0W06 2K2 J 0402
R7216 Bottom M 4 CHIPRES 0W06 10R J 0402
R7300 Bottom J 7 CHIPRES JUMPER 0R0 0402
R7301 Bottom D 8 CHIPRES 0W06 56R J 0402
R7306 Bottom J 6 CHIPRES JUMPER 0R0 0402
R7307 Bottom D 7 CHIPRES 0W06 56R J 0402
R7308 Bottom I 7 NTC RES 0W1 47K J B 4050+-3% 0402
R7310 Bottom B 7 CHIPRES JUMPER 0R0 0402
R7350 Bottom G 7 CHIPRES 0W06 100R J 0402
R7352 Bottom F 7 CHIPRES 0W06 1K8 J 0402
S2401 Bottom C 8 SM SW TACT SPST 12V SIDE KEY 2.2N
S2402 Bottom F 8 SM SW TACT SPST 12V SIDE KEY 2.2N
S2403 Bottom R 8 SM SW TACT SPST 12V SIDE KEY 2.2N
V2000 Top U 2 ASIP TVS BGA4
V2001 Top T 5 TRX2 N 40V 0A1 GENERAL PURPOSE SOT666
V2002 Top U 7 TRX2 N 40V 0A1 GENERAL PURPOSE SOT666
V2100 Top R 6 TR 2SC5658QRS N 50V 0A1 0W15 VMT3
V2101 Top R 6 TR 2SC5658QRS N 50V 0A1 0W15 VMT3
V2400 Top Q 6 DI SCH RB160M-30 1A <0.48 SOD123F
V2402 Top S 5 DI SCH DUAL 0.4V 1MA SOT490
V2403 Top T 4 TRX2 BIPOLAR 2XPNP 40V 0A1 0W12 SOT666
V2404 Top T 3 TRX2 BIPOLAR 2XPNP 40V 0A1 0W12 SOT666
Issue 1 - September 2006 Company Confidential Page 25
Page 26
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Item Side X Y Description
V2405 Top U 2 TRX2 BIPOLAR 2XPNP 40V 0A1 0W12 SOT666
V2406 Top R 5 DI SCH DUAL 0.4V 1MA SOT490
V2407 Top T 2 TRX2 BIPOLAR 2XPNP 40V 0A1 0W12 SOT666
V2408 Bottom R 4 TR NPN RBE4K7/47K 50V 0A08 VMT3
V2409 Top S 5 TR NPN RBE4K7/47K 50V 0A08 VMT3
V2410 Bottom R 4 TR NPN RBE4K7/47K 50V 0A08 VMT3
V2900 Bottom O 5 TR 2SC5658QRS N 50V 0A1 0W15 VMT3
V2901 Bottom N 5 TR 2SC5658QRS N 50V 0A1 0W15 VMT3
V2902 Top O 4 TR 2SC5658QRS N 50V 0A1 0W15 VMT3
V7100 Bottom L 4 CAP.DI BBY57-02W 1/4 16/4P SOD523
X0001 Top M 7 MODULE ID COMPONENT 2.8X1.8X0.3
X2000 Bottom H 7 SM BATTERY CONN 3POL SPR 12V 2A
X2001 Bottom U 5 CONN SYST SM 14POL
X2002 Top U 5 SM CONN 16P SPR P1.3 50V PWB/PWB
X2101 Bottom B 2 HEADSET JACK 4-POLE
X2700 Bottom P 3 SM SIM CONN 2X3POL P2.54 50V 0.5A
X3200 Bottom O 7 CONN MICRO SD HINGE
X3650 Top M 3 SM CONN 2X12F P0.4 30V.3A PWB/PWB
X6200 Bottom D 2 CONN MULTI POGO PIN 2 5.8X3X2.5
X6250 Bottom F 2 CONN SM COAX +SW F 50R 250V 6GHZ
X6600 Bottom F 4 SMIA85 SOCKET
X6601 Bottom F 5 CONN 2POL SPR 6.6X6.8X2.5
X7300 Top A 7 CONN SM COAX +SW F 50R 250V 6GHZ
Z2101 Top S 6 ASIP AUDIO MIC ST ** RESERVED HELIOS ***
Z2102 Top P 7 ASIP AUDIO OUTPUT STAGE
Z2103 Bottom A 3 ASIP AUDIO MIC ST ** RESERVED HELIOS ***
Z2105 Bottom S 4 ASIP AUDIO MIC ST ** RESERVED HELIOS ***
Z2400 Top U 4 ASIP KEYBOARD INTERFACE *PB-FREE*
Z3200 Top N 8 ASIP MMC HIGH SPEED ESD/EMI FILT BGA16
Z3600 Top M 4 ASIP 10-CH ESD EMI FILTER BGA25
Z6030 Bottom S 6 LTCC FILT 2441.75+-41.75MHZ 2.5X2
Page 26 Company Confidential Issue 1 - September 2006
Page 27
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Item Side X Y Description
Z6250 Bottom F 2 CER FILT 1575.42+-40MHZ 3.6X3.6
Z6251 Bottom D 2 SAW FILT 1575.42MHZ 2X1.6X0.6
Z7000 Bottom K 6 SAW FILT 836.5+-12.5MHZ/2.5 2X1.6
Z7001 Bottom K 7 SAW FILT 1850-1910MHZ 2X1.6X0.68
Z7160 Bottom I 4 SAW FILT 881.52 MHz 2X1.6X0.8
Z7161 Bottom I 2 SAW FILT 1960+-30MHz/3.5dB 2x1.6
Z7162 Bottom J 4 XTAL FILT 128.1MHZ/4DB 3X3X1
Z7163 Bottom K 2 SAW FILT 128.1MHZ 7X5X1.48
Z7300 Bottom E 7 DUPL 1930-1990/1850-1910MHZ 5X5
Z7301 Bottom D 7 DIPL 1850-1990/824-894MHZ
Z7302 Bottom E 6 DUPL 824-849/869-894MHZ 3.8X3.8X1.5
Issue 1 - September 2006 Company Confidential Page 27
Page 28
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
6275 Parts List — Version 007 — Engine Code 0203038
Item Side X Y Description
A0001 Top Q 5 BB SHIELD ASSEMBLY
A0002 Bottom K 4 RX SHIELD ASSEMBLY
A0003 Bottom K 7 TX SHIELD ASSEMBLY
A0004 Bottom D 7 DUPLEXOR SHIELD ASSEMBLY
A0005 Bottom D 3 GPS SHIELD ASSEMBLY
A0006 Bottom F 7 DC DC SHIELD COVER
A0007 Bottom R 6 BT SHIELD ASSEMBLY
B2200 Top P 7 CRYSTAL 32.768KHZ +/-30PPM 12.5PF
C2001 Bottom I 6 CHIPCAP X7R 10N K 50V 0603
C2002 Bottom H 8 CHIPCAP NP0 47P J 50V 0402
C2004 Top U 3 CHIPCAP X7R 1N0 J 50V 0402
C2005 Top U 3 CHIPCAP NP0 22P J 50V 0402
C2006 Top T 3 CHIPCAP X5R 100N K 16V 0402
C2007 Top U 3 CHIPCAP X5R 1U K 6V3 0402
C2008 Top Q 5 CHIPCAP X5R 1U K 6V3 0402
C2009 Top R 5 CHIPCAP X7R 10N J 16V 0402
C2016 Top T 7 CHIPCAP NP0 33P J 50V 0402
C2017 Top T 7 CHIPCAP NP0 33P J 50V 0402
C2018 Top T 7 CHIPCAP NP0 33P J 50V 0402
C2019 Top T 7 CHIPCAP NP0 33P J 50V 0402
C2020 Top T 6 CHIPCAP X7R 3N3 J 50V 0402
C2021 Top S 6 CHIPCAP X7R 3N3 J 50V 0402
C2022 Top T 7 CHIPCAP X7R 3N3 J 50V 0402
C2023 Top T 7 CHIPCAP X7R 3N3 J 50V 0402
C2024 Top U 7 CHIPCAP X7R 3N3 J 50V 0402
C2025 Top U 7 CHIPCAP X7R 3N3 J 50V 0402
C2100 Top S 6 CHIPCAP X5R 100N K 16V 0402
C2101 Top S 6 CHIPCAP X5R 100N K 16V 0402
C2102 Top Q 7 CHIPCAP X5R 100N K 16V 0402
C2103 Top Q 7 CHIPCAP X5R 100N K 16V 0402
C2104 Top S 6 CHIPCAP X5R 100N K 16V 0402
Page 28 Company Confidential Issue 1 - September 2006
Page 29
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Item Side X Y Description
C2105 Top S 6 CHIPCAP X5R 100N K 16V 0402
C2106 Top R 6 CHIPCAP X5R 10UF 6V3 0603
C2107 Bottom A 3 CHIPCAP NP0 47P J 50V 0402
C2108 Top Q 6 CHIPCAP X5R 10UF 6V3 0603
C2109 Top Q 6 CHIPCAP X5R 10UF 6V3 0603
C2110 Top B 3 CHIPCAP NP0 47P J 50V 0402
C2111 Top B 2 CHIPCAP X7R 3N3 J 50V 0402
C2112 Bottom C 2 CHIPCAP NP0 47P J 50V 0402
C2113 Bottom C 2 CHIPCAP X7R 3N3 J 50V 0402
C2114 Top B 2 CHIPCAP X5R 100N K 16V 0402
C2115 Top B 2 CHIPCAP X7R 390P J 50V 0402
C2116 Top Q 6 CHIPCAP X5R 100N K 16V 0402
C2117 Top R 5 CHIPCAP X7R 10N J 16V 0402
C2118 Bottom S 4 CHIPCAP X5R 100N K 16V 0402
C2119 Bottom S 4 CHIPCAP X5R 100N K 16V 0402
C2120 Bottom S 4 CHIPCAP X5R 100N K 16V 0402
C2121 Bottom C 6 CHIPCAP NP0 100P J 50V 0402
C2122 Bottom C 5 CHIPCAP NP0 100P J 50V 0402
C2123 Bottom C 5 CHIPCAP X5R 1U5 K 4V 0402
C2124 Bottom C 5 CHIPCAP X5R 1U K 6V3 0603
C2126 Bottom C 3 CHIPCAP X5R 100N K 16V 0402
C2127 Bottom C 3 CHIPCAP X5R 100N K 16V 0402
C2128 Bottom C 3 CHIPCAP X7R 10N J 16V 0402
C2129 Bottom C 3 CHIPCAP X7R 10N J 16V 0402
C2130 Bottom A 3 CHIPCAP X7R 3N3 J 50V 0402
C2200 Top N 7 CHIPCAP X5R 1U K 6V3 0603
C2201 Top N 7 CHIPCAP X7R 10N J 16V 0402
C2202 Top P 6 CHIPCAP X7R 10N J 16V 0402
C2203 Top P 5 CHIPCAP X5R 1U5 K 4V 0402
C2204 Top M 6 CHIPCAP X5R 100N K 16V 0402
C2205 Top O 7 CHIPCAP X5R 1U5 K 4V 0402
C2206 Top O 7 CHIPCAP X5R 1U5 K 4V 0402
Issue 1 - September 2006 Company Confidential Page 29
Page 30
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Item Side X Y Description
C2207 Top O 7 CHIPCAP X5R 1U5 K 4V 0402
C2208 Top P 5 CHIPCAP X5R 1U5 K 4V 0402
C2209 Top P 6 CHIPCAP X5R 1U5 K 4V 0402
C2210 Top Q 7 CHIPCAP NP0 10P J 50V 0402
C2211 Top P 8 CHIPCAP NP0 10P J 50V 0402
C2212 Top P 5 CHIPCAP X5R 1U5 K 4V 0402
C2213 Top O 7 CHIPCAP X5R 1U5 K 4V 0402
C2214 Top O 7 CHIPCAP X5R 1U5 K 4V 0402
C2215 Top Q 6 CHIPCAP X5R 1U5 K 4V 0402
C2216 Top Q 6 CHIPCAP X5R 1U5 K 4V 0402
C2217 Top P 5 CHIPCAP X5R 100N K 16V 0402
C2218 Top O 4 CHIPCAP X5R 100N K 16V 0402
C2220 Top P 5 CHIPCAP X5R 1U5 K 4V 0402
C2221 Top N 5 CHIPCAP X5R 100N K 16V 0402
C2222 Top N 5 CHIPCAP X5R 100N K 16V 0402
C2223 Top N 7 CHIPCAP X5R 1U K 6V3 0603
C2224 Top N 7 CHIPCAP X5R 220N K 6.3V 0402
C2225 Top M 5 CHIPCAP X5R 1U5 K 4V 0402
C2226 Top M 6 CHIPCAP X5R 1U5 K 4V 0402
C2227 Top N 6 CHIPCAP X5R 1U5 K 4V 0402
C2228 Top N 6 CHIPCAP X5R 1U5 K 4V 0402
C2230 Top P 5 CHIPCAP X7R 10N J 16V 0402
C2231 Top P 7 CHIPCAP X7R 10N J 16V 0402
C2232 Top M 8 CHIPCAP X5R 4U7 K 6.3V 0603
C2233 Top M 6 CHIPCAP X5R 1U5 K 4V 0402
C2234 Top N 6 CHIPCAP X5R 1U5 K 4V 0402
C2235 Top N 6 CHIPCAP X5R 1U5 K 4V 0402
C2236 Top M 6 CHIPCAP X5R 1U5 K 4V 0402
C2237 Top M 6 CHIPCAP X5R 1U5 K 4V 0402
C2238 Top N 6 CHIPCAP X5R 1U5 K 4V 0402
C2239 Top M 7 CHIPCAP X5R 1U K 6V3 0603
C2240 Top M 7 CHIPCAP X5R 1U K 6V3 0603
Page 30 Company Confidential Issue 1 - September 2006
Page 31
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Item Side X Y Description
C2241 Top N 5 CHIPCAP X5R 1U5 K 4V 0402
C2300 Top R 2 CHIPCAP X5R 10UF 6V3 0603
C2302 Top R 2 CHIPCAP X5R 4U7 K 6.3V 0603
C2303 Top Q 2 CHIPCAP X5R 4U7 K 6.3V 0603
C2304 Top Q 2 CHIPCAP X5R 100N K 16V 0402
C2404 Top R 8 CHIPCAP X5R 100N K 16V 0402
C2405 Top Q 8 CHIPCAP X5R 4U7 K 6.3V 0603
C2406 Top R 8 CHIPCAP X5R 100N K 16V 0402
C2407 Top R 7 CHIPCAP X5R 1U0 K 25V T 1.0 1206
C2408 Top R 6 CHIPCAP X5R 1U0 K 25V T 1.0 1206
C2410 Bottom G 5 CHIPCAP NP0 10P J 50V 0402
C2600 Bottom F 2 CHIPCAP X5R 100N K 16V 0402
C2602 Bottom H 2 CHIPCAP X5R 4U7 K 6.3V 0603
C2700 Bottom R 2 CHIPCAP X5R 100N K 16V 0402
C2800 Top O 2 CHIPCAP X5R 1U5 K 4V 0402
C2801 Top P 2 CHIPCAP X7R 10N J 16V 0402
C2802 Top O 3 CHIPCAP X7R 10N J 16V 0402
C2803 Top Q 3 CHIPCAP X7R 10N J 16V 0402
C2804 Top P 4 CHIPCAP X7R 10N J 16V 0402
C2805 Top O 3 CHIPCAP X7R 10N J 16V 0402
C2806 Top P 4 CHIPCAP X7R 10N J 16V 0402
C2807 Top O 2 CHIPCAP X7R 10N J 16V 0402
C2808 Top Q 2 CHIPCAP X7R 10N J 16V 0402
C2809 Top Q 4 CHIPCAP X7R 10N J 16V 0402
C2810 Top P 2 CHIPCAP X7R 10N J 16V 0402
C2900 Bottom M 2 CHIPCAP X7R 10N J 16V 0402
C2901 Bottom M 2 CHIPCAP X7R 10N J 16V 0402
C2902 Top O 4 CHIPCAP X7R 10N J 16V 0402
C2903 Bottom M 6 CHIPCAP X7R 1N0 J 50V 0402
C2904 Bottom N 5 CHIPCAP X7R 33N K 10V 0402
C2905 Top O 4 CHIPCAP X7R 10N J 16V 0402
C2906 Bottom N 5 CHIPCAP X7R 1N0 J 50V 0402
Issue 1 - September 2006 Company Confidential Page 31
Page 32
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Item Side X Y Description
C2907 Bottom N 5 CHIPCAP X7R 33N K 10V 0402
C2908 Top O 3 CHIPCAP X7R 47N K 10V 0402
C2909 Top O 3 CHIPCAP X7R 4N7 J 25V 0402
C2910 Top O 4 CHIPCAP X7R 47N K 10V 0402
C3000 Top Q 4 CHIPCAP X7R 10N J 16V 0402
C3001 Top S 2 CHIPCAP X5R 100N K 10V 0402
C3002 Top Q 3 CHIPCAP X7R 10N J 16V 0402
C3003 Top T 4 CHIPCAP X5R 100N K 16V 0402
C3004 Top S 5 CHIPCAP X5R 100N K 16V 0402
C3200 Top P 8 CHIPCAP X5R 4U7 K 6.3V 0603
C3201 Top O 7 CHIPCAP X5R 100N K 16V 0402
C3202 Top P 7 CHIPCAP X5R 1U K 6V3 0603
C3204 Top O 8 CHIPCAP X5R 100N K 16V 0402
C3501 Top T 4 CHIPCAP NP0 47P J 50V 0402
C3609 Bottom C 4 CHIPCAP NP0 1P5 C 50V 0402
C3610 Bottom C 4 CHIPCAP NP0 1P5 C 50V 0402
C3611 Bottom C 6 CHIPCAP NP0 1P5 C 50V 0402
C3612 Bottom C 6 CHIPCAP NP0 3P3 C 50V 0402
C3650 Top N 3 CHIPCAP X5R 100N K 10V 0402
C3651 Top N 3 CHIPCAP X5R 100N K 10V 0402
C3656 Top N 5 CHIPCAP X7R 10N J 16V 0402
C3657 Top N 4 CHIPCAP X5R 1U5 K 4V 0402
C6031 Bottom S 5 CHIPCAP NP0 18P J 50V 0402
C6032 Bottom M 5 CHIPCAP NP0 18P J 50V 0402
C6033 Bottom Q 6 CHIPCAP X7R 10N J 16V 0402
C6034 Bottom R 6 CHIPCAP X7R 10N J 16V 0402
C6035 Bottom R 5 CHIPCAP X7R 10N J 16V 0402
C6036 Bottom Q 6 CHIPCAP X7R 10N J 16V 0402
C6037 Bottom Q 6 CHIPCAP X5R 1U5 K 4V 0402
C6038 Bottom R 5 CHIPCAP X7R 10N J 16V 0402
C6039 Bottom R 6 CHIPCAP NP0 18P J 50V 0402
C6040 Bottom S 2 CHIPCAP NP0 1P2 C 50V 0402
Page 32 Company Confidential Issue 1 - September 2006
Page 33
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Item Side X Y Description
C6051 Bottom R 6 CHIPCAP NP0 2P7 C 50V 0402
C6052 Bottom R 6 CHIPCAP NP0 2P7 C 50V 0402
C6055 Bottom S 5 CHIPCAP X5R 1U K 6V3 0402
C6101 Top R 7 CHIPCAP X5R 100N K 16V 0402
C6102 Top T 8 CHIPCAP NP0 100P J 50V 0402
C6103 Top S 7 CHIPCAP NP0 47P J 50V 0402
C6104 Top S 7 CHIPCAP NP0 27P J 50V 0402
C6105 Top S 7 CHIPCAP X7R 10N J 16V 0402
C6107 Top S 7 CHIPCAP X5R 100N K 16V 0402
C6108 Top S 7 CHIPCAP X7R 10N J 16V 0402
C6109 Top R 7 CHIPCAP X7R 33N K 10V 0402
C6110 Top S 8 CHIPCAP X5R 100N K 16V 0402
C6111 Top S 8 CHIPCAP X5R 100N K 16V 0402
C6112 Top S 8 CHIPCAP X7R 33N K 10V 0402
C6113 Top S 7 CHIPCAP X7R 33N K 10V 0402
C6114 Top R 8 CHIPCAP X7R 33N K 10V 0402
C6115 Top S 8 CHIPCAP X5R 100N K 16V 0402
C6600 Bottom F 2 CHIPCAP X5R 220N K 6.3V 0402
C6601 Bottom F 3 CHIPCAP X5R 100N K 16V 0402
C6602 Bottom F 3 CHIPCAP NP0 27P J 50V 0402
C6603 Bottom G 5 CHIPCAP X5R 100N K 16V 0402
C6604 Bottom G 5 CHIPCAP NP0 27P J 50V 0402
C6607 Bottom H 4 CHIPCAP X7R 10N J 16V 0402
C6608 Bottom H 6 CHIPCAP X5R 100N K 16V 0402
C6612 Bottom G 2 CHIPCAP X5R 4U7 K 6.3V 0603
C6613 Bottom G 2 CHIPCAP X5R 10U M 6V3 0805
C6614 Bottom H 4 CHIPCAP X5R 4U7 K 6.3V 0603
C6615 Bottom G 6 CHIPCAP X5R 100N K 16V 0402
C6617 Bottom G 3 CHIPCAP X5R 4U7 K 6.3V 0603
C6618 Bottom F 2 CHIPCAP X7R 33N K 10V 0402
C6619 Bottom H 2 CHIPCAP X5R 4U7 K 6.3V 0603
C6621 Bottom G 3 CHIPCAP NP0 10P J 50V 0402
Issue 1 - September 2006 Company Confidential Page 33
Page 34
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Item Side X Y Description
C7000 Bottom K 8 CHIPCAP X7R 10N J 16V 0402
C7001 Bottom K 7 CHIPCAP X7R 10N J 16V 0402
C7002 Bottom M 6 CHIPCAP X5R 100N K 10V 0402
C7003 Bottom L 8 CHIPCAP NP0 3P3 C 50V 0402
C7004 Bottom L 8 CHIPCAP NP0 220P J 25V 0402
C7005 Bottom M 8 CHIPCAP NP0 100P J 50V 0402
C7006 Bottom M 8 CHIPCAP NP0 2N2 J 16V 0603
C7007 Bottom L 8 CHIPCAP NP0 100P J 50V 0402
C7008 Bottom M 7 CHIPCAP NP0 4P7 C 50V 0402
C7009 Bottom M 7 CHIPCAP X5R 1U K 6V3 0402
C7010 Bottom M 7 CHIPCAP NP0 3P3 C 50V 0402
C7011 Bottom L 8 CHIPCAP X7R 10N J 16V 0402
C7012 Bottom L 8 CHIPCAP NP0 18P J 50V 0402
C7013 Bottom L 6 CHIPCAP NP0 33P J 50V 0402
C7014 Bottom L 6 CHIPCAP NP0 18P J 50V 0402
C7015 Bottom L 6 CHIPCAP NP0 33P J 50V 0402
C7016 Bottom L 6 CHIPCAP X7R 10N J 16V 0402
C7017 Bottom L 6 CHIPCAP NP0 47P J 50V 0402
C7018 Bottom K 7 CHIPCAP NP0 10P J 50V 0402
C7019 Bottom M 7 CHIPCAP NP0 12P J 50V 0402
C7020 Bottom M 7 CHIPCAP NP0 18P J 50V 0402
C7021 Bottom M 7 CHIPCAP X7R 10N J 16V 0402
C7022 Bottom K 6 CHIPCAP NP0 3P3 C 50V 0402
C7023 Bottom K 6 CHIPCAP NP0 1P2 C 50V 0402
C7024 Bottom K 7 CHIPCAP NP0 1P2 C 50V 0402
C7026 Bottom K 7 CHIPCAP NP0 0P5 C 50V 0402
C7027 Bottom K 7 CHIPCAP NP0 0P5 C 50V 0402
C7029 Bottom K 7 CHIPCAP NP0 3P3 C 50V 0402
C7030 Bottom K 8 CHIPCAP NP0 3P3 C 50V 0402
C7031 Bottom M 7 CHIPCAP NP0 30P G 50V 0402
C7100 Bottom M 4 CHIPCAP X7R 10N J 16V 0402
C7101 Bottom M 4 CHIPCAP X5R 330N K 10V 0603
Page 34 Company Confidential Issue 1 - September 2006
Page 35
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Item Side X Y Description
C7102 Bottom L 4 CHIPCAP X7R 33N K 10V 0402
C7103 Bottom L 4 CHIPCAP NP0 33P J 50V 0402
C7104 Bottom L 4 CHIPCAP X7R 1N0 J 50V 0402
C7105 Bottom M 2 CHIPCAP X7R 10N J 16V 0402
C7106 Bottom M 3 CHIPCAP X7R 10N J 16V 0402
C7107 Bottom M 2 CHIPCAP X7R 10N J 16V 0402
C7108 Bottom L 3 CHIPCAP X7R 10N J 16V 0402
C7109 Bottom L 3 CHIPCAP X7R 10N J 16V 0402
C7110 Bottom M 2 CHIPCAP X7R 10N J 16V 0402
C7111 Bottom M 3 CHIPCAP X7R 10N J 16V 0402
C7112 Bottom L 4 CHIPCAP X7R 10N J 16V 0402
C7113 Bottom L 3 CHIPCAP X7R 10N J 16V 0402
C7162 Bottom I 2 CHIPCAP NP0 100P J 50V 0402
C7163 Bottom I 2 CHIPCAP NP0 100P J 50V 0402
C7164 Bottom J 2 CHIPCAP NP0 100P J 50V 0402
C7165 Bottom H 3 CHIPCAP NP0 56P J 50V 0402
C7166 Bottom H 4 CHIPCAP NP0 1P8 C 50V 0402
C7167 Bottom H 2 CHIPCAP NP0 12P J 50V 0402
C7168 Bottom H 2 CHIPCAP X5R 100N K 10V 0402
C7169 Bottom I 2 CHIPCAP NP0 1P5 C 50V 0402
C7170 Bottom J 4 CHIPCAP NP0 100P J 50V 0402
C7171 Bottom J 4 CHIPCAP NP0 5P6 C 50V 0402
C7172 Bottom I 4 CHIPCAP X7R 47N K 10V 0402
C7173 Bottom I 2 CHIPCAP NP0 12P J 50V 0402
C7174 Bottom J 2 CHIPCAP X7R 3N3 J 50V 0402
C7175 Bottom J 2 CHIPCAP NP0 22P J 50V 0402
C7176 Bottom J 3 CHIPCAP X7R 1N0 J 50V 0402
C7177 Bottom J 3 CHIPCAP NP0 4P7 C 50V 0402
C7178 Bottom J 4 CHIPCAP NP0 3P9 C 50V 0402
C7179 Bottom K 4 CHIPCAP NP0 10P J 50V 0402
C7180 Bottom K 3 CHIPCAP NP0 6P8 C 50V 0402
C7181 Bottom K 3 CHIPCAP NP0 6P8 C 50V 0402
Issue 1 - September 2006 Company Confidential Page 35
Page 36
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Item Side X Y Description
C7182 Bottom K 3 CHIPCAP X7R 3N3 J 50V 0402
C7183 Bottom J 2 CHIPCAP X5R 100N K 10V 0402
C7184 Bottom J 3 CHIPCAP NP0 2P2 C 50V 0402
C7185 Bottom J 3 CHIPCAP NP0 100P J 50V 0402
C7187 Bottom L 2 CHIPCAP NP0 12P J 50V 0402
C7188 Bottom L 2 CHIPCAP NP0 12P J 50V 0402
C7189 Bottom H 3 CHIPCAP NP0 0P5 C 50V 0402
C7200 Bottom L 4 CHIPCAP X5R 1U K 6V3 0402
C7201 Bottom L 5 CHIPCAP X7R 10N J 16V 0402
C7202 Bottom K 5 CHIPCAP X7R 1N0 J 50V 0402
C7203 Bottom L 5 CHIPCAP NP0 15P J 50V 0402
C7206 Bottom L 8 CHIPCAP NP0 27P J 50V 0402
C7207 Bottom M 2 CHIPCAP NP0 22P J 50V 0402
C7208 Bottom L 5 CHIPCAP NP0 18P J 50V 0402
C7209 Bottom L 4 CHIPCAP X7R 10N J 16V 0402
C7210 Bottom M 4 CHIPCAP X5R 100N K 10V 0402
C7211 Bottom L 5 CHIPCAP NP0 47P J 50V 0402
C7212 Bottom J 4 CHIPCAP NP0 1P8 C 50V 0402
C7213 Bottom L 5 CHIPCAP X7R 3N3 J 50V 0402
C7214 Bottom L 4 CHIPCAP X7R 33N K 10V 0402
C7215 Bottom L 4 CHIPCAP X7R 6N8 K 25V 0402
C7216 Bottom K 5 CHIPCAP X7R 1N0 J 50V 0402
C7217 Bottom K 5 CHIPCAP X7R 1N0 J 50V 0402
C7218 Bottom K 4 CHIPCAP X5R 1U K 6V3 0402
C7219 Bottom K 5 CHIPCAP X7R 10N J 16V 0402
C7220 Bottom J 5 CHIPCAP X5R 100N K 10V 0402
C7221 Bottom M 4 CHIPCAP X7R 10N J 16V 0402
C7222 Bottom M 4 CHIPCAP X5R 100N K 10V 0402
C7300 Bottom J 7 CHIPCAP X7R 1N0 J 50V 0402
C7301 Bottom J 7 CHIPCAP NP0 3P3 C 50V 0402
C7302 Bottom J 7 CHIPCAP X7R 10N J 16V 0402
C7303 Bottom J 7 CHIPCAP NP0 3P3 C 50V 0402
Page 36 Company Confidential Issue 1 - September 2006
Page 37
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Item Side X Y Description
C7304 Bottom I 8 CHIPCAP NP0 15P J 50V 0402
C7305 Bottom J 8 CHIPCAP X7R 1N0 J 50V 0402
C7306 Bottom J 8 CHIPCAP NP0 10P J 50V 0402
C7311 Bottom B 8 CHIPCAP NP0 10P J 50V 0402
C7312 Bottom B 8 CHIPCAP NP0 47P J 50V 0402
C7313 Bottom D 6 CHIPCAP X7R 10N J 16V 0402
C7314 Bottom D 6 CHIPCAP NP0 10P J 50V 0402
C7315 Bottom D 6 CHIPCAP X7R 3N3 J 50V 0402
C7316 Bottom D 6 CHIPCAP X7R 3N3 J 50V 0402
C7317 Bottom I 7 CHIPCAP X5R 10U M 6V3 0805
C7318 Bottom H 8 CHIPCAP X5R 10U M 6V3 0805
C7319 Bottom I 7 CHIPCAP NP0 270P J 50V 0402
C7320 Bottom J 6 CHIPCAP X7R 6N8 K 25V 0402
C7321 Bottom J 7 CHIPCAP X7R 1N0 J 50V 0402
C7322 Bottom I 6 CHIPCAP X7R 1N0 J 50V 0402
C7323 Bottom J 7 CHIPCAP X7R 1N0 J 50V 0402
C7324 Bottom J 7 CHIPCAP NP0 3P3 C 50V 0402
C7325 Bottom I 6 CHIPCAP NP0 7P5 C 50V 0402
C7326 Bottom I 7 CHIPCAP NP0 3P3 C 50V 0402
C7350 Bottom F 6 CHIPCAP NP0 47P J 50V 0402
C7351 Bottom F 6 CHIPCAP NP0 47P J 50V 0402
C7352 Bottom F 6 CHIPCAP NP0 10P J 50V 0402
C7353 Bottom G 7 CHIPCAP NP0 47P J 50V 0402
C7354 Bottom F 6 CHIPCAP X5R 4U7 K 6.3V 0603
C7355 Bottom F 6 CHIPCAP X5R 4U7 K 6.3V 0603
C7356 Bottom G 8 CHIPCAP X7R 10N J 16V 0402
C7357 Bottom G 6 CHIPCAP X5R 10U M 6V3 0805
C7358 Bottom G 7 CHIPCAP X5R 10U M 6V3 0805
D2200 Top O 6 UEMEK2v0 LF WDENA TFBGA244
D2800 Top P 3 TIKUEDGE v2.0 LF CO27 GZG289
D3000 Top R 3 COMBO 128MNOR+256MM3+128MSDRAM FBGA133
D6601 Bottom H 5 HW ACCELERATOR STV0984N
Issue 1 - September 2006 Company Confidential Page 37
Page 38
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Item Side X Y Description
E2100 Bottom T 4 CONN SPACER PAD
E2101 Bottom T 3 CONN SPACER PAD
F2000 Top U 3 SM FUSE F 2.0A 32V 0603
G7200 Bottom L 5 VCTCXO 19.2MHZ +-2PPM 2.78V 2.2MA
G7201 Bottom J 5 UHF VCO 986-1034MHz/2040-2140MHz
L2000 Top U 3 FERR.BEAD 220R/100M 2A 0R05 0603
L2001 Top T 4 FERRITE BEAD 0.6R 600R/100MZ 0402
L2002 Top T 4 FERRITE BEAD 0.6R 600R/100MZ 0402
L2003 Top T 4 FERRITE BEAD 0.6R 600R/100MZ 0402
L2004 Top T 6 CHIP BEAD ARRAY 2X1000R 0R75 0405
L2005 Top T 7 CHIP BEAD ARRAY 2X1000R 0R75 0405
L2006 Top U 7 CHIP BEAD ARRAY 2X1000R 0R75 0405
L2100 Top B 2 FERRITE BEAD 0.6R 600R/100MZ 0402
L2101 Bottom A 3 FERRITE BEAD 0.6R 600R/100MZ 0402
L2102 Bottom C 2 FERRITE BEAD 0.6R 600R/100MZ 0402
L2103 Top B 1 CHIP BEAD ARRAY 2X1000R 0R75 0405
L2104 Bottom B 6 CHIP BEAD ARRAY 2X220R 0405
L2105 Top A 1 CHIP COIL 100N J Q16/300MHZ 0402
L2301 Top S 2 INDUCT WW 10UH 0A34 0R54 310 case size
L2302 Top Q 2 FERR.BEAD 220R/100M 2A 0R05 0603
L2400 Top R 8 FERR.BEAD 220R/100M 2A 0R05 0603
L2401 Top Q 7 CHOKE 3U3 M 0R1 1.2A 4.0X4.0X1.2
L3609 Bottom C 4 CHIP COIL 6N8 K Q29/800MHZ 0402
L3610 Bottom C 4 CHIP COIL 6N8 K Q29/800MHZ 0402
L3611 Bottom C 7 CHIP COIL 6N8 K Q29/800MHZ 0402
L3612 Bottom C 6 CHIP COIL 3N3 +-0N3 Q28/800M 0402
L6030 Bottom R 6 CHIP COIL 2N7 +-0N3 Q29/800M 0402
L6031 Bottom R 6 CHIP COIL 2N7 +-0N3 Q29/800M 0402
L6032 Bottom R 5 CHIP COIL 22N J Q28/800MHZ 0402
L6100 Top T 7 CHIP COIL 68N J Q17/300MHZ 0402
L6101 Top S 7 CHIP COIL 120NH J Q8/100MHZ 0402
L6102 Top S 7 CHIP COIL 47N +-3% Q25/200MHz 0402
Page 38 Company Confidential Issue 1 - September 2006
Page 39
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Item Side X Y Description
L7000 Bottom M 7 CHIP COIL 27N J Q27/800MHZ 0402
L7001 Bottom K 6 CHIP COIL 27N J Q27/800MHZ 0402
L7002 Bottom K 6 CHIP COIL 33N J Q23/800MHZ 0402
L7003 Bottom K 6 CHIP COIL 27N J Q27/800MHZ 0402
L7004 Bottom K 7 CHIP COIL 6N8 J Q27/800MHZ 0402
L7005 Bottom K 7 CHIP COIL 12N J Q31/800MHZ 0402
L7006 Bottom K 7 CHIP COIL 6N8 J Q27/800MHZ 0402
L7101 Bottom L 4 CHIP COIL 33NH J Q12/100MHZ 0603
L7160 Bottom H 3 CHIP COIL 7N5 Q25/100MHZ 0402
L7161 Bottom H 3 CHIP COIL 19N J Q24/250MHZ 0402
L7162 Bottom I 2 CHIP COIL 12N J Q31/800MHZ 0402
L7163 Bottom J 3 CHIP COIL 3N3 +-0N3 Q28/800M 0402
L7164 Bottom J 4 CHIP COIL 82N +-0N3 Q17/300M 0402
L7165 Bottom H 4 CHIP COIL 12N J Q31/800MHZ 0402
L7166 Bottom I 2 CHIP COIL 3N3 +-0N3 Q28/800M 0402
L7167 Bottom I 4 CHIP COIL 220N J Q8/50MHZ 0603
L7168 Bottom I 2 CHIP COIL 18N J Q29/800MHZ 0402
L7169 Bottom I 4 CHIP COIL 15N J Q30/800MHZ 0402
L7170 Bottom J 3 CHIP COIL 82N +-0N3 Q17/300M 0402
L7171 Bottom J 4 CHIP COIL 180N J Q13/100MHZ 0603
L7172 Bottom K 4 CHIP COIL 120N J Q16/100MHZ 0603
L7173 Bottom K 4 CHIP COIL 120N J Q16/100MHZ 0603
L7174 Bottom K 3 CHIP COIL 220N J Q8/50MHZ 0603
L7175 Bottom K 3 CHIP COIL 220N J Q8/50MHZ 0603
L7176 Bottom J 3 CHIP COIL 120N J Q16/100MHZ 0603
L7177 Bottom L 2 CHIP COIL 100N J Q12/100MHZ 0603
L7178 Bottom L 2 CHIP COIL 120N J Q16/100MHZ 0603
L7179 Bottom L 2 CHIP COIL 120N J Q16/100MHZ 0603
L7201 Bottom J 4 CHIP COIL 3N3 +-0N3 Q28/800M 0402
L7301 Bottom I 7 CHIP COIL 3N9 +-0N3 Q28/800M 0402
L7302 Bottom D 8 DIR.COUPLER 1850-1910MHZ 1.6X0.8
L7303 Bottom B 7 CHIP COIL 33N J Q23/800MHZ 0402
Issue 1 - September 2006 Company Confidential Page 39
Page 40
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Item Side X Y Description
L7304 Bottom D 7 CHIP COIL 10N J Q30/800MHZ 0402
L7305 Bottom D 7 DIR.COUPLER 824-849MHZ 1.6X0.8MM
L7306 Bottom I 7 CHIP COIL 22N J Q28/800MHZ 0402
L7350 Bottom G 7 FERRITE BEAD 0.015R 42R/100M 0805
L7351 Bottom F 7 INDUCT WW 1.5UH 0.096 OHM 1.1A
L7397 Bottom B 7 CHIP COIL 10N J Q30/800MHZ 0402
M2400 Bottom T 5 SMD-VIBRA MOTOR 1.3V 80mA 9000RPM
N2001 Top Q 5 NUT/CP2137 ASIC HBCC16++
N2100 Bottom C 5 AF AMP 1W LM4990 NOPB 2.8V uSMD9
N2300 Top R 2 DC/DC CONV LM3661-1.35V/1.05V
N2401 Top R 7 STEP-UP DC/DC CONV TK11891F-G SON3024-8
N2600 Bottom G 1 IRDA 1.15Mbps 2V4
N3200 Top O 8 VREG & LEVELSHIFT(LP3928)USMD16
N3650 Top N 4 VREG LP3985ITLX-2.8 NOPB USMD5
N6030 Bottom R 6 BC4-ROM1.0RDL
N6100 Top S 7 FM RECEIVER TEA5761UK N4B (Ti) CSP
N6600 Bottom G 2 REG LP3981YDX-2.8/NOPB 0.3A LLP-6
N6601 Bottom H 3 LI VREG 1.2V/150mA (LP3990YD 1.2) LLP6
N6602 Bottom G 3 LI VREG TK63118B-G 1.8V WLCSP4
N7000 Bottom L 7 JUPITER D4 PMB3365G VQFN-40
N7100 Bottom L 3 BATMAN RF RX ASIC STB7102FTR
N7160 Bottom I 3 LNA/MIXER/DOWNCNTR ALFRED VQFN-24
N7200 Bottom M 5 1XPLL/SYNTH 2.5GHZ(LMX2310U)MLF20
N7300 Bottom J 7 PW AMP RF3448 CDMA1900
N7301 Bottom J 6 PW AMP RF3449 CDMA800 LFM
N7302 Bottom D 6 ASIP STPAC01F2 CDMA PWR DET BGA-8
N7350 Bottom F 6 RF4013 V-E2.2 DC-DC BUCK CONV QFN 16
R2001 Bottom G 7 CHIP VARISTOR VWM15V VC50V 0402
R2002 Top S 5 NTC RES 0W1 47K J B 4050+-3% 0402
R2003 Top T 3 CHIPRES 0W06 100K J 0402
R2004 Top U 3 CHIPRES 0W06 33R J 0402
R2005 Top U 3 CHIP VARISTOR VWM15V VC50V 0402
Page 40 Company Confidential Issue 1 - September 2006
Page 41
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Item Side X Y Description
R2006 Top T 3 ASIP USB2 FILTER BGA10 PBFREE
R2007 Top U 3 CHIPRES 0W06 220K J 0402
R2008 Top U 3 CHIPRES 0W06 220K J 0402
R2009 Top U 7 CHIP VARISTOR VWM15V VC50V 0402
R2010 Top T 7 CHIP VARISTOR VWM15V VC50V 0402
R2011 Top U 7 CHIP VARISTOR VWM15V VC50V 0402
R2012 Top U 7 CHIP VARISTOR VWM15V VC50V 0402
R2013 Bottom Q 7 ASIP 4XESD *** PB-FREE *** BGA5
R2017 Top T 5 CHIPRES 0W06 330R J 0402
R2018 Top T 7 CHIPRES 0W06 330R J 0402
R2019 Top S 6 CHIP VARISTOR VWM15V VC50V 0402
R2020 Top S 6 CHIP VARISTOR VWM15V VC50V 0402
R2100 Top R 6 CHIPRES 0W06 10K J 0402
R2101 Top S 6 CHIPRES 0W06 1K0 J 0402
R2102 Top Q 6 CHIPRES 0W06 10R J 0402
R2103 Top Q 6 CHIPRES 0W06 10R J 0402
R2106 Top N 2 CHIPRES 0W06 100K J 0402
R2107 Bottom C 1 CHIP VARISTOR VWM15V VC50V 0402
R2108 Top R 5 CHIPRES 0W06 1K0 J 0402
R2111 Top R 6 CHIPRES 0W06 47K J 0402
R2112 Bottom D 5 CHIPRES 0W06 100K J 0402
R2113 Bottom C 4 CHIPRES 0W06 22K J 0402
R2114 Bottom C 6 CHIPRES 0W06 100K J 0402
R2115 Bottom C 4 CHIPRES 0W06 22K J 0402
R2116 Bottom D 5 CHIPRES 0W06 100K J 0402
R2117 Bottom B 7 CHIP VARISTOR VWM15V VC50V 0402
R2118 Bottom B 6 CHIP VARISTOR VWM15V VC50V 0402
R2119 Top S 5 CHIPRES 0W06 100K J 0402
R2120 Top S 6 CHIPRES 0W06 100K J 0402
R2121 Bottom A 1 CHIPRES 0W06 4K7 J 0402
R2123 Bottom C 3 CHIPRES 0W06 2K2 J 0402
R2124 Bottom C 3 CHIPRES 0W06 2K2 J 0402
Issue 1 - September 2006 Company Confidential Page 41
Page 42
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Item Side X Y Description
R2200 Top N 7 CHIPRES 0W25 0R22 J 0805
R2202 Top Q 5 CHIPRES 0W06 10K J 0402
R2203 Top Q 5 CHIPRES 0W06 4K7 J 0402
R2204 Top Q 5 CHIPRES 0W06 4K7 J 0402
R2205 Top Q 5 CHIPRES 0W06 100K J 0402
R2206 Top Q 5 CHIPRES 0W06 100K J 0402
R2207 Top P 7 CHIPRES 0W06 100K J 0402
R2208 Top M 5 CHIPRES 0W06 27K J 0402
R2209 Top O 7 CHIPRES 0W06 100K J 0402
R2401 Bottom G 8 CHIP VARISTOR VWM15V VC50V 0402
R2403 Bottom C 8 CHIP VARISTOR VWM15V VC50V 0402
R2404 Bottom G 8 CHIP VARISTOR VWM15V VC50V 0402
R2406 Top R 6 CHIPRES 0W06 10K J 0402
R2407 Top R 6 CHIPRES 0W06 330K J 0402
R2408 Top T 4 CHIPRES 0W06 33R J 0402
R2409 Top T 3 CHIPRES 0W06 20R J 0402
R2410 Top T 3 CHIPRES 0W06 10K J 0402
R2411 Top T 3 CHIPRES 0W06 33R J 0402
R2412 Bottom R 4 CHIPRES 0W06 10K J 0402
R2413 Top S 5 CHIPRES 0W06 10K J 0402
R2414 Bottom R 4 CHIPRES 0W06 10K J 0402
R2415 Bottom S 5 CHIPRES 0W06 82R J 0402
R2416 Bottom R 5 CHIPRES 0W06 82R J 0402
R2417 Bottom P 5 CHIPRES 0W06 33R J 0402
R2418 Bottom Q 5 CHIPRES 0W06 33R J 0402
R2419 Bottom Q 5 CHIPRES 0W06 33R J 0402
R2420 Bottom C 7 CHIP VARISTOR VWM15V VC50V 0402
R2421 Bottom Q 8 CHIP VARISTOR VWM15V VC50V 0402
R2422 Bottom R 8 CHIP VARISTOR VWM15V VC50V 0402
R2423 Bottom P 5 CHIPRES 0W06 33R J 0402
R2424 Bottom P 5 CHIPRES 0W06 33R J 0402
R2425 Bottom P 5 CHIPRES 0W06 33R J 0402
Page 42 Company Confidential Issue 1 - September 2006
Page 43
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Item Side X Y Description
R2426 Top T 4 CHIPRES 0W06 10K J 0402
R2427 Top Q 6 CHIPRES JUMPER 0R0 0402
R2430 Top T 2 CHIPRES 0W06 68R J 0402
R2432 Top T 3 CHIPRES 0W06 20R J 0402
R2600 Bottom H 2 CHIPRES 0W125 4R7 J 0805
R2700 Bottom R 3 ASIP SIM INTERFACE **low cap** BGA8
R2800 Bottom I 5 CHIPRES 0W06 4K7 J 0402
R2801 Bottom I 5 CHIPRES 0W06 4K7 J 0402
R2803 Top Q 4 CHIPRES 0W06 100R J 0402
R2804 Top Q 4 CHIPRES 0W06 100R J 0402
R2809 Top Q 4 CHIPRES 0W06 10K J 0402
R2900 Bottom M 2 CHIPRES 0W06 4K7 J 0402
R2901 Top O 4 CHIPRES 0W06 1K0 J 0402
R2902 Bottom O 5 CHIPRES 0W06 4K7 J 0402
R2904 Top O 4 CHIPRES 0W06 1K0 J 0402
R2905 Bottom N 5 CHIPRES 0W06 4K7 J 0402
R2906 Top O 4 CHIPRES 0W06 1K0 J 0402
R2907 Top O 2 CHIPRES 0W06 1K0 J 0402
R2908 Top O 3 CHIPRES 0W06 4K7 J 0402
R3000 Top Q 3 CHIPRES 0W06 47R J 0402
R3001 Top S 5 CHIPRES 0W06 100K J 0402
R3002 Top S 5 CHIPRES 0W06 4K7 J 0402
R3207 Top N 7 CHIPRES 0W06 1K0 J 0402
R3208 Top P 2 CHIPRES 0W06 100K J 0402
R3209 Top P 2 CHIPRES 0W06 100K J 0402
R3502 Top U 4 CHIPRES 0W06 4K7 J 0402
R3503 Top U 4 CHIP VARISTOR VWM15V VC50V 0402
R3600 Bottom B 6 CHIP VARISTOR VWM15V VC50V 0402
R3611 Top N 4 ASIP 4XESD *** PB-FREE *** BGA5
R3614 Bottom B 6 CHIP VARISTOR VWM15V VC50V 0402
R3652 Top N 4 CHIPRES JUMPER 0R0 0402
R3654 Top N 5 CHIPRES 0W06 100K J 0402
Issue 1 - September 2006 Company Confidential Page 43
Page 44
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Item Side X Y Description
R6030 Bottom Q 6 CHIPRES 0W06 10K J 0402
R6031 Bottom R 5 CHIPRES 0W06 10K J 0402
R6032 Bottom Q 6 CHIPRES 0W06 2R2 J 0402
R6034 Bottom R 6 CHIPRES 0W06 10K J 0402
R6037 Bottom R 5 CHIPRES 0W06 100K J 0402
R6100 Top S 7 CHIPRES 0W06 10K J 0402
R6101 Top S 7 CHIPRES 0W06 100K J 0402
R6203 Bottom D 5 CHIPRES 0W06 100K J 0402
R6252 Bottom E 1 CHIPRES 0W06 47R J 0402
R6600 Bottom H 4 CHIPRES 0W06 4K7 J 0402
R6601 Bottom G 4 CHIPRES 0W06 4K7 J 0402
R6602 Bottom H 4 CHIPRES JUMPER 0R0 0402
R6604 Bottom G 3 CHIPRES 0W06 10K J 0402
R6608 Bottom I 5 CHIPRES JUMPER 0R0 0402
R6628 Bottom F 2 CHIPRES 0W06 100K J 0402
R7000 Bottom K 8 CHIPRES JUMPER 0R0 0402
R7001 Bottom M 8 CHIPRES 0W06 10K J 0402
R7002 Bottom M 8 CHIPRES 0W06 27K J 0402
R7007 Bottom M 6 CHIPRES 0W06 22K J 0402
R7008 Bottom M 7 CHIPRES 0W06 43K 1% 0402
R7009 Bottom L 6 CHIPRES 0W06 12K J 0402
R7010 Bottom K 7 CHIPRES JUMPER 0R0 0402
R7011 Bottom M 7 CHIPRES 0W06 150R J 0402
R7012 Bottom M 7 CHIPRES 0W06 180R J 0402
R7100 Bottom M 4 CHIPRES 0W06 1K0 J 0402
R7101 Bottom M 4 CHIPRES 0W06 470R J 0402
R7102 Bottom M 4 CHIPRES 0W06 4K7 J 0402
R7103 Bottom M 2 CHIPRES 0W06 8K2 J 0402
R7104 Bottom M 3 CHIPRES 0W06 27K J 0402
R7161 Bottom I 2 CHIPRES 0W06 47K J 0402
R7162 Bottom J 2 CHIPRES 0W06 47K J 0402
R7163 Bottom J 2 CHIPRES 0W06 47K J 0402
Page 44 Company Confidential Issue 1 - September 2006
Page 45
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Item Side X Y Description
R7164 Bottom H 2 CHIPRES 0W06 4R3 J 0402
R7165 Bottom J 3 CHIPRES 0W06 82R J 0402
R7166 Bottom I 2 CHIPRES 0W06 4R3 J 0402
R7200 Bottom L 4 CHIPRES 0W06 10R J 0402
R7201 Bottom K 4 CHIPRES 0W06 10K J 0402
R7206 Top O 3 CHIPRES JUMPER 0R0 0402
R7209 Bottom L 4 CHIPRES 0W06 10R J 0402
R7210 Bottom J 5 CHIPRES 0W06 150R J 0402
R7211 Bottom L 5 CHIPRES 0W06 3K9 J 0402
R7212 Bottom K 5 CHIPRES 0W06 10K J 0402
R7213 Bottom K 5 CHIPRES 0W06 10K J 0402
R7215 Bottom J 5 CHIPRES 0W06 2K2 J 0402
R7216 Bottom M 4 CHIPRES 0W06 10R J 0402
R7300 Bottom J 7 CHIPRES JUMPER 0R0 0402
R7301 Bottom D 8 CHIPRES 0W06 56R J 0402
R7306 Bottom J 6 CHIPRES JUMPER 0R0 0402
R7307 Bottom D 7 CHIPRES 0W06 56R J 0402
R7308 Bottom I 7 NTC RES 0W1 47K J B 4050+-3% 0402
R7310 Bottom B 7 CHIPRES JUMPER 0R0 0402
R7350 Bottom G 7 CHIPRES 0W06 100R J 0402
R7352 Bottom F 7 CHIPRES 0W06 1K8 J 0402
S2401 Bottom C 8 SM SW TACT SPST 12V SIDE KEY 2.2N
S2402 Bottom F 8 SM SW TACT SPST 12V SIDE KEY 2.2N
S2403 Bottom R 8 SM SW TACT SPST 12V SIDE KEY 2.2N
V2000 Top U 2 ASIP TVS BGA4
V2001 Top T 5 TRX2 N 40V 0A1 GENERAL PURPOSE SOT666
V2002 Top U 7 TRX2 N 40V 0A1 GENERAL PURPOSE SOT666
V2100 Top R 6 TR 2SC5658QRS N 50V 0A1 0W15 VMT3
V2101 Top R 6 TR 2SC5658QRS N 50V 0A1 0W15 VMT3
V2400 Top Q 6 DI SCH RB160M-30 1A <0.48 SOD123F
V2402 Top S 5 DI SCH DUAL 0.4V 1MA SOT490
V2403 Top T 4 TRX2 BIPOLAR 2XPNP 40V 0A1 0W12 SOT666
Issue 1 - September 2006 Company Confidential Page 45
Page 46
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
Item Side X Y Description
V2404 Top T 3 TRX2 BIPOLAR 2XPNP 40V 0A1 0W12 SOT666
V2405 Top U 2 TRX2 BIPOLAR 2XPNP 40V 0A1 0W12 SOT666
V2406 Top R 5 DI SCH DUAL 0.4V 1MA SOT490
V2407 Top T 2 TRX2 BIPOLAR 2XPNP 40V 0A1 0W12 SOT666
V2408 Bottom R 4 TR NPN RBE4K7/47K 50V 0A08 VMT3
V2409 Top S 5 TR NPN RBE4K7/47K 50V 0A08 VMT3
V2410 Bottom R 4 TR NPN RBE4K7/47K 50V 0A08 VMT3
V2900 Bottom O 5 TR 2SC5658QRS N 50V 0A1 0W15 VMT3
V2901 Bottom N 5 TR 2SC5658QRS N 50V 0A1 0W15 VMT3
V2902 Top O 4 TR 2SC5658QRS N 50V 0A1 0W15 VMT3
V7100 Bottom L 4 CAP.DI BBY57-02W 1/4 16/4P SOD523
X0001 Top M 7 MODULE ID COMPONENT 2.8X1.8X0.3
X2000 Bottom H 7 SM BATTERY CONN 3POL SPR 12V 2A
X2001 Bottom U 5 CONN SYST SM 14POL
X2002 Top U 5 SM CONN 16P SPR P1.3 50V PWB/PWB
X2101 Bottom B 2 HEADSET JACK 4-POLE
X2700 Bottom P 3 SM SIM CONN 2X3POL P2.54 50V 0.5A
X3200 Bottom O 7 CONN MICRO SD HINGE
X3650 Top M 3 SM CONN 2X12F P0.4 30V.3A PWB/PWB
X6200 Bottom D 2 CONN MULTI POGO PIN 2 5.8X3X2.5
X6600 Bottom F 4 SMIA85 SOCKET
X6601 Bottom F 5 CONN 2POL SPR 6.6X6.8X2.5
X7300 Top A 7 CONN SM COAX +SW F 50R 250V 6GHZ
Z2101 Top S 6 ASIP AUDIO MIC ST ** RESERVED HELIOS ***
Z2102 Top P 7 ASIP AUDIO OUTPUT STAGE
Z2103 Bottom A 3 ASIP AUDIO MIC ST ** RESERVED HELIOS ***
Z2105 Bottom S 4 ASIP AUDIO MIC ST ** RESERVED HELIOS ***
Z2400 Top U 4 ASIP KEYBOARD INTERFACE *PB-FREE*
Z3200 Top N 8 ASIP MMC HIGH SPEED ESD/EMI FILT BGA16
Z3600 Top M 4 ASIP 10-CH ESD EMI FILTER BGA25
Z6030 Bottom S 6 LTCC FILT 2441.75+-41.75MHZ 2.5X2
Z7000 Bottom K 6 SAW FILT 836.5+-12.5MHZ/2.5 2X1.6
Page 46 Company Confidential Issue 1 - September 2006
Page 47
6275/6275i (RM-154)
Nokia Customer Care Parts Lists and Exploded View
Item Side X Y Description
Z7001 Bottom K 7 SAW FILT 1850-1910MHZ 2X1.6X0.68
Z7160 Bottom I 4 SAW FILT 881.52 MHz 2X1.6X0.8
Z7161 Bottom I 2 SAW FILT 1960+-30MHz/3.5dB 2x1.6
Z7162 Bottom J 4 XTAL FILT 128.1MHZ/4DB 3X3X1
Z7163 Bottom K 2 SAW FILT 128.1MHZ 7X5X1.48
Z7300 Bottom E 7 DUPL 1930-1990/1850-1910MHZ 5X5
Z7301 Bottom D 7 DIPL 1850-1990/824-894MHZ
Z7302 Bottom E 6 DUPL 824-849/869-894MHZ 3.8X3.8X1.5
Issue 1 - September 2006 Company Confidential Page 47
Page 48
6275/6275i (RM-154)
Parts Lists and Exploded View Nokia Customer Care
This page intentionally left blank.
Page 48 Company Confidential Issue 1 - September 2006
Loading...
