Nokia N97 Mini User Manual

Nokia N97 mini User Guide
Issue 1

Contents

Safety 7
About your device 7 Office applications 8 Network services 8 Shared memory 8 ActiveSync 8 Magnets and magnetic fields 8
Find help 9
Support 9 In-device help 9 Do more with your device 9 Update device software 10 Settings 11 Access codes 11 Remote lock 11 Prolong battery life 12 Free memory 12
Get started 14
Keys and parts (front) 14 Keys and parts (back) 14 Keys and parts (sides) 15 Keys and parts (top) 15 Insert the SIM card and battery 15 Memory card 16 Antenna locations 17 Switch the device on and off 18
Charge the battery 18 Headset 19 Attach wrist strap 20 Touch screen actions 20 Write text 21 Lock the keys and touch screen 25 Nokia Switch 25 Profiles 26
Your device 28
Home screen 28 Display indicators 29 Shortcuts 30 Search 31 Volume and loudspeaker control 32 Offline profile 32 Fast downloading 33 Ovi (network service) 33
Make calls 36
Proximity sensor 36 Voice calls 36 During a call 36 Voice and video mailboxes 37 Answer or reject a call 37 Make a conference call 37 Speed dial a phone number 38 Call waiting 38 Voice dialling 38 Make a video call 39
© 2009 Nokia. All rights reserved.2
During a video call 39 Answer or reject a video call 40 Internet calls 40 Video sharing 41 Log 43
Contacts (phonebook) 46
Save and edit names and numbers 46 Contacts toolbar 46 Manage names and numbers 46 Default numbers and addresses 46 Contact cards 47 Set contacts as favourites 47 Ringing tones, images, and call text for contacts 47 Copy contacts 48 SIM services 48 Contact groups 49
Ovi Contacts 50
About Ovi Contacts 50 Start using Ovi Contacts 50 Connect to the service 50 Create and edit your profile 51 Find and add friends 52 Chat with your friends 52 Ovi Sync 53 Share your location 53 Ovi Contacts settings 54 Nokia account settings 54 Presence settings 54
Personalisation settings 55 Connection settings 55
Messaging 56
Messaging main view 56 Write and send messages 56 Messaging inbox 57 Mailbox 58 View messages on a SIM card 60 Cell broadcast messages 60 Service commands 60 Messaging settings 60 Mail for Exchange 64 Nokia Messaging 65
Connectivity 66
Data connections and access points 66 Network settings 66 Wireless LAN 67 Access points 69 Active data connections 71 Synchronisation 71 Bluetooth connectivity 72 USB 75 PC connections 75 Administrative settings 76
Internet 77
Browse the web 77 Browser toolbar 77 Navigate pages 78
© 2009 Nokia. All rights reserved. 3
Web feeds and blogs 78 Content search 78 Bookmarks 79 Empty the cache 79 End the connection 79 Connection security 79 Web settings 80
Positioning (GPS) 82
About GPS 82 Assisted GPS (A-GPS) 82 Hold your device correctly 83 Tips on creating a GPS connection 83 Position requests 84 Landmarks 84 GPS data 84 Positioning settings 85
Maps 87
About Maps 87 About GPS 87 Move on a map 88 Display indicators 88 Find locations 88 Plan routes 89 Save and send locations 89 View your saved items 89 Synchronise your favourite locations with Ovi Maps 90 Your search history 90 About licences 90
Walk to your destination 91 Drive to your destination 92 Traffic and safety 92 Location details 93 Use Maps with the compass 93 Calibrate compass 94 Maps settings 94 Internet settings 94 Navigation settings 94 Route settings 95 Map settings 95 Synchronisation settings 96 Update maps 96 Update the Maps application 96 Nokia Map Loader 97
Camera 98
Image capture 98 Video recording 102 Camera settings 103
Photos 104
About Photos 104 View images and videos 104 View and edit file details 105 Organise images and videos 105 Photos toolbar 105 Albums 106 Tags 106 Slide show 106
© 2009 Nokia. All rights reserved.4
TV-out mode 107 Edit images 108 Edit videos 108 Image print 109 Share online 109
Clock 123 RealPlayer 124 Recorder 125 Notes 125 Office 126
Music 110
Play a song or a podcast 110 Playlists 111 Podcasts 111 Transfer music from a computer 112 Nokia Music Store 112 Nokia Podcasting 112 FM radio 115
Videos 117
Download and view video clips 117 Video feeds 117 My videos 118 Transfer videos from your PC 118 Video settings 118
Personalise your device 120
Change the look of your device 120 Profiles 120 3-D tones 120 Modify the home screen 121 Modify the main menu 121
Applications 122
Calendar 122
© 2009 Nokia. All rights reserved. 5
Settings 130
Phone settings 130 Application manager 136 Calling settings 138
Troubleshooting 141
Green tips 144
Save energy 144 Recycle 144 Save paper 144 Learn more 144
Accessories 145
Battery 145
Battery and charger information 145 Nokia battery authentication guidelines 145
Taking care of your device 146
Recycle 146
Additional safety information 147
Small children 147 Operating environment 147
Medical devices 147 Vehicles 147 Potentially explosive environments 147 Emergency calls 148 Certification information (SAR) 148
Index 149
© 2009 Nokia. All rights reserved.6

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

SWITCH OFF IN RESTRICTED AREAS

Follow any restrictions. Switch the device off in aircraft, near medical equipment, fuel, chemicals, or blasting areas.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ACCESSORIES AND BATTERIES

Use only approved accessories and batteries. Do not connect incompatible products.

WATER-RESISTANCE

Your device is not water-resistant. Keep it dry.

About your device

The wireless device described in this guide is approved for use on the (E)GSM 850, 900, 1800,1900, and UMTS 900, 1900, 2100 networks. Contact your service provider for more information about networks.
Your device supports several connectivity methods and like computers may be exposed to viruses and other harmful content. Exercise caution with messages, connectivity requests, browsing, and downloads. Only install and use services and software from trustworthy sources that offer adequate security and protection, such as applications that are Symbian Signed or have passed the Java Verified™ testing. Consider installing antivirus and other security software on your device and any connected computer.
Your device may have preinstalled bookmarks and links for third-party internet sites and may allow you to access third­party sites. These are not affiliated with Nokia, and Nokia does not endorse or assume liability for them. If you access such sites, take precautions for security or content.
© 2009 Nokia. All rights reserved. 7
Warning:
To use any features in this device, other than the alarm clock, the device must be switched on. Do not switch the device on when wireless device use may cause interference or danger.
When using this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights. Copyright protection may prevent some images, music, and other content from being copied, modified, or transferred.
Make back-up copies or keep a written record of all important information stored in your device.
When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.
The images in this guide may differ from your device display.
Refer to the user guide for other important information about your device.

Office applications

The office applications support common features of Microsoft Word, PowerPoint, and Excel (Microsoft Office 2000, XP, and
2003). Not all file formats are supported.

Network services

To use the device you must have service from a wireless service provider. Some features are not available on all networks; other features may require that you make specific
arrangements with your service provider to use them. Network services involve transmission of data. Check with your service provider for details about fees in your home network and when roaming on other networks. Your service provider can explain what charges will apply. Some networks may have limitations that affect how you can use some features of this device requiring network support such as support for specific technologies like WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols and language­dependent characters.
Your service provider may have requested that certain features be disabled or not activated in your device. If so, these features will not appear on your device menu. Your device may also have customized items such as menu names, menu order, and icons.

Shared memory

The following features in this device may share memory: multimedia messaging (MMS), e-mail application, instant messaging. Use of one or more of these features may reduce the memory available for the remaining features. If your device displays a message that the memory is full, delete some of the information stored in the shared memory.

ActiveSync

Use of the Mail for Exchange is limited to over-the-air synchronisation of PIM information between the Nokia device and the authorised Microsoft Exchange server.

Magnets and magnetic fields

Keep your device away from magnets or magnetic fields.
© 2009 Nokia. All rights reserved.8

Find help

Support

When you want to learn more about how to use your product or you are unsure how your device should function, see the support pages at www.nokia.com/support or your local Nokia website, www.nokia.mobi/support (with a mobile device), the Help application in the device, or the user guide.
If this does not resolve your issue, do one of the following:
Restart the device: switch off the device, and remove the battery. After about a minute, replace the battery, and switch on the device.
Restore the original factory settings as explained in the user guide. Your documents and files will be deleted in the reset, so back up your data first.
Update your device software regularly for optimum performance and possible new features, as explained in the user guide.
If your issue remains unsolved, contact Nokia for repair options. See www.nokia.com/repair. Before sending your device for repair, always back up the data in your device.

In-device help

Your device contains instructions to help to use the applications in your device.
To open help texts from the main menu, select Menu >
Applications > Help and the application for which you want
to read instructions.
When an application is open, to access the help text for the current view, select Options > Help.
When you are reading the instructions, to change the size of the help text, select Options > Decrease font size or
Increase font size.
You may find links to related topics at the end of the help text. If you select an underlined word, a short explanation is
displayed.
Help texts use the following indicators:
Link to a related help topic. Link to the application being discussed.
When you are reading the instructions, to switch between help texts and the application that is open in the background, select Options > Show open apps. and the desired application.

Do more with your device

There are various applications provided by Nokia and third party software developers, that help you do more with your device. To find and download applications, visit the Ovi Store at store.ovi.com. These applications are explained in the
© 2009 Nokia. All rights reserved. 9
guides that are available on the product support pages at www.nokia.com/support or your local Nokia website.
Update device software Software updates over the air
Select Menu > Applications > SW update.
With Software update (network service), you can check if there are updates available for your device software or applications, and download them to your device.
Downloading software updates may involve the transmission of large amounts of data (network service).
Make sure that the device battery has enough power, or connect the charger before starting the update.
Warning:
If you install a software update, you cannot use the device, even to make emergency calls, until the installation is completed and the device is restarted. Be sure to back up data before accepting installation of an update.
After updating your device software or applications using Software update, the instructions related to the updated applications in the user guide or the helps may no longer be up to date.
To download the available updates, select
. To unmark specific updates that you do not want to download, select the updates from the list.
To view information on an update, select the update and
.
To view the status of previous updates, select
.
Select Options and from the following:
Update via PC — Update your device using a PC. This option replaces the Start update option when updates are only available using the Nokia Software Updater PC application.
View update history — View the status of previous updates. Settings — Change the settings, such as the default access
point used for downloading updates.
Disclaimer — View the Nokia licence agreement.

Software updates using your PC

Nokia Software Updater is a PC application that enables you to update your device software. To update your device software, you need a compatible PC, broadband internet access, and a compatible USB data cable to connect your device to the PC.
To get more information, to check the release notes for the latest software versions, and to download the Nokia Software Updater application, see www.nokia.com/softwareupdate or your local Nokia website.
To update the device software, do the following:
1 Download and install the Nokia Software Updater
application to your PC.
© 2009 Nokia. All rights reserved.10
2 Connect your device to the PC using a USB data cable, and
select PC Suite mode.
3 Open the Nokia Software Updater application. The Nokia
Software Updater application guides you to back up your files, update the software, and restore your files.

Settings

Your device normally has MMS, GPRS, streaming, and mobile internet settings automatically configured, based on your network service provider information. You may have settings from your service providers already installed in your device, or you may receive or request the settings from the network service providers as a special message.
You can change the general settings in your device, such as language, standby mode, display, and keypad lock settings.

Access codes

If you forget any of the access codes, contact your service provider.
Personal identification number (PIN) code — This code protects your SIM card against unauthorised use. The PIN code (4 to 8 digits) is usually supplied with the SIM card. After three consecutive incorrect PIN code entries, the code is blocked, and you need the PUK code to unblock it.
UPIN code — This code may be supplied with the USIM card. The USIM card is an enhanced version of the SIM card and is supported by UMTS mobile phones.
PIN2 code — This code (4 to 8 digits) is supplied with some SIM cards, and is required to access some functions in your device.
Lock code (also known as security code) — The lock code helps you to protect your device against unauthorised use. The preset code is 12345. You can create and change the code, and set the device to request the code. Keep the new code secret and in a safe place separate from your device. If you forget the code and your device is locked, your device will require service. Additional charges may apply, and all the personal data in your device may be deleted. For more information, contact a Nokia Care point or your device dealer.
Personal Unblocking Key (PUK) code and PUK2 code — These codes (8 digits) are required to change a blocked PIN code or PIN2 code, respectively. If the codes are not supplied with the SIM card, contact the operator whose SIM card is in your device.
UPUK code — This code (8 digits) is required to change a blocked UPIN code. If the code is not supplied with the USIM card, contact the operator whose USIM card is in your device.

Remote lock

To prevent unauthorised use of your device, you can lock your device and memory card remotely using a text message. You must define the text message, and to lock your device, send the text message to your device. To unlock your device, you need the lock code.
To enable remote locking, and to define the text message, select Menu > Settings and Phone > Phone mgmt. >
Security settings > Phone and SIM card > Remote phone locking > Enabled. Tap the text input field to enter the text
© 2009 Nokia. All rights reserved. 11
message content (5-20 characters), select , and verify the message. Enter the lock code.

Prolong battery life

Many feat ures i n you r device incr ease the dema nd on b atte ry power and reduce the battery lifetime. To save battery power, note the following:
Features that use Bluetooth technology, or allowing such
features to run in the background while using other features, increase the demand on battery power. Deactivate Bluetooth technology when you do not need it.
Features that use wireless LAN (WLAN), or allowing such
features to run in the background while using other features, increase the demand on battery power. WLAN on your Nokia device deactivates when you are not trying to connect, not connected to an access point, or not scanning for available networks. To further reduce battery consumption, you can specify that your device does not scan, or scans less often, for available networks in the background.
If you have set Packet data connection to When
available in connection settings, and there is no packet
data coverage (GPRS), the device periodically tries to establish a packet data connection. To prolong the operating time of your device, select Packet data
connection > When needed.
The Maps application downloads new map information
when you scroll to new areas on the map, which increases the demand on battery power. You can prevent the automatic download of new maps.
If the signal strength of the cellular network varies much in your area, your device must scan for the available network repeatedly. This increases the demand on battery power.
If the network mode is set to dual mode in the network settings, the device searches for the 3G network. You can set the device to use only the GSM network. To use only the GSM network, select Menu > Settings and
Connectivity > Network > Network mode > GSM.
The backlight of the display increases the demand on battery power. In the display settings, you can change the length of the time-out period after which the backlight is switched off. Select Menu > Settings and
Phone > Display > Light time-out. To adjust the light
sensor that observes lighting conditions and adjusts the display brightness, in the display settings, select Light
sensor.
Leaving applications running in the background increases the demand on battery power. To close the applications you are not using, if they are not responding, select Options > Show open apps., and go to the application using the menu key. Press and hold the menu key to open the application, and select Options > Exit.

Free memory

To view how much space is available for different data types, select Menu > Applications > Office > File mgr..
© 2009 Nokia. All rights reserved.12
Many features of the device use memory to store data. The device notifies you if the memory in different memory locations is low.
To free memory, transfer data to a compatible memory card (if available) or to a compatible computer.
To remove data you no longer need, use File manager or open the respective application. You can remove the following:
Messages in the folders in Messaging and retrieved e-mail messages in the mailbox
Saved web pages
Contact information
Calendar notes
Applications shown in Application manager that you do
not need
Installation files (.sis or .sisx) of applications you have installed. Transfer the installation files to a compatible computer.
Images and video clips in Photos. Back up the files to a compatible computer.
© 2009 Nokia. All rights reserved. 13

Get started

Note: The surface of this device does not contain nickel in
the platings. The surface of this device contains stainless steel.

Keys and parts (front)

Do not cover the area above the touch screen, for example, with protective film or tape.

Keys and parts (back)

1 Proximity sensor 2 Earpiece 3 Touch screen 4 Menu key 5 Call key 6 Secondary camera lens 7 Light sensor 8 End key
1 Camera flash 2 Camera lens
© 2009 Nokia. All rights reserved.14

Keys and parts (sides)

1 Stereo speaker 2 Charging indicator light 3 Micro USB connector 4 Lock switch 5 Volume up/Zoom in key 6 Volume down/Zoom out key 7 Capture key

Keys and parts (top)

1 Power key 2 Nokia AV connector (3.5 mm)

Insert the SIM card and battery

Follow the instructions carefully, to avoid damaging the back cover.
Safe removal. Always switch the device off and disconnect the charger before removing the battery.
1 Remove the back cover by lifting it from the bottom end
of the device.
2 If the battery is inserted, lift the battery in the direction
of the arrow to remove it.
© 2009 Nokia. All rights reserved. 15
3 Pull out the SIM card holder, and insert the SIM card.
Ensure that the gold-coloured contact area on the card is facing down and that the bevelled corner on the card is facing the bevelled corner on the holder. Push the SIM card holder back in.
4 Align the contacts of the battery with the corresponding
connectors on the battery compartment, and insert the battery in the direction of the arrow.
5 To replace the back cover, direct the top locking catches
toward their slots, and press down until the cover locks into place.

Memory card

Use only compatible microSD cards approved by Nokia for use with this device. Nokia uses approved industry standards for memory cards, but some brands may not be fully compatible with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.

Insert the memory card

A memory card may be already inserted in the device. If not, do the following:
1 Remove the back cover of the device.
© 2009 Nokia. All rights reserved.16
2 Insert a compatible memory card in the slot. Ensure that
the contact area on the card is facing down and towards the slot.
3 Push the card in. You can hear a click when the card locks
into place.
4 Replace the back cover. Keep the device facing down
when replacing the cover. Ensure that the cover is properly closed.
Remove the memory card Important: Do not remove the memory card during an
operation when the card is being accessed. Doing so may damage the memory card and the device, and corrupt data stored on the card.
1 Before you remove the card, press the power key, and
select Remove memory card. All applications are closed.
2When Removing memory card will close all open
applications. Remove anyway? is displayed, select Yes.
3When Remove memory card and press 'OK' is
displayed, remove the back cover of the device.
4 Press the memory card to release it from the slot.
5 Pull out the memory card. If the device is switched on,
select OK.
6 Replace the back cover. Ensure that the cover is properly
closed.

Antenna locations

Your device may have internal and external antennas. Avoid touching the antenna area unnecessarily while the antenna is transmitting or receiving. Contact with antennas affects the communication quality and may cause a higher power level during operation and may reduce the battery life.
© 2009 Nokia. All rights reserved. 17

Switch the device on and off

To switch on the device:
1 Press and hold the power key.
2 If the device asks for a PIN code or lock code, enter it, and
select OK. The preset lock code is 12345. If you forget the code and your device is locked, your device will require service and additional charges may apply. For more information, contact a Nokia Care point or your device dealer.
To switch off the device, press the power key briefly, and select Switch off!.

Charge the battery

Your battery has been partially charged at the factory. There may not be a need to charge the battery in advance. If the device indicates a low charge, do the following:
Regular charging
1 Connect the charger to a wall outlet. 2 Connect the charger to the device. The charging indicator
light next to the USB connector is lit when the battery is being charged.
3 When the device indicates a full charge, disconnect the
charger from the device, then from the wall outlet.
You do not need to charge the battery for a specific length of time, and you can use the device while it is charging. If the battery is completely discharged, it may take several minutes before the charging indicator appears on the display or before any calls can be made.
Tip: Disconnect the charger from the wall outlet when the charger is not in use. A charger that is connected to the outlet consumes power even when it is not connected to the device.
© 2009 Nokia. All rights reserved.18
USB charging
You can use USB charging when a wall outlet is not available. With USB charging, you can also transfer data while charging the device.
1 Connect a compatible USB device to your device using a
compatible USB cable. The efficiency of USB charging varies significantly. In
some cases, it may take a very long time for charging to start and the device to start functioning.
2 If your device is switched on, you can select from the
available USB mode options on the display of the device.

Headset

You can connect a compatible headset or compatible headphones to your device. You may need to select the cable mode.
Some headsets come in two parts, a remote control unit and headphones. A remote control unit has a microphone and keys to answer or end a phone call, adjust the volume, and play music or video files. To use the headphones with a remote control unit, connect the unit to the Nokia AV Connector in the device, then connect the headphones to the unit.
Warning:
When you use the headset, your ability to hear outside sounds may be affected. Do not use the headset where it can endanger your safety.
Do not connect products that create an output signal as this may cause damage to the device. Do not connect any voltage source to the Nokia AV Connector.
© 2009 Nokia. All rights reserved. 19
When connecting any external device or any headset, other than those approved by Nokia for use with this device, to the Nokia AV Connector, pay special attention to volume levels.

Attach wrist strap

Thread the wrist strap, and tighten it.

Touch screen actions

Use the touch screen with your finger or with a stylus (if available).
Important: Use only a stylus approved by Nokia for use with this device. Using any other stylus may invalidate any warranty applying to the device and may damage the touch screen. Avoid scratching the touch screen. Never use an actual pen or pencil or other sharp objects to write on the touch screen.
Tap and double-tap
To open an application or other element on the touch screen, you normally tap it with your finger. However, to open the following items, you must tap them twice.
List items in an application, such as the Drafts folder in the Messaging application.
Files in a file list, for example, an image in the Captured folder in the Photos application.
Tip: When you open a list view, the first item is already highlighted. To open the highlighted item, tap it once.
If you tap a file or similar item once, it is not opened, it becomes highlighted. To see the options available for the item, select Options or, if available, select an icon from a toolbar.
Select
In this user documentation, to open applications or items by tapping them once or twice, you "select" them. If you need to select several items in a sequence, the display texts to select are separated by arrows.
Example: To select Options > Help, tap Options, and then tap Help.
© 2009 Nokia. All rights reserved.20
Drag
To drag, place your finger on the screen, and slide it across the screen.
Example: To scroll up or down on a web page, drag the page with your finger.
Swipe
To swipe, slide your finger quickly left or right on the screen.
Flick
To flick, place your finger on the screen, slide it quickly across the screen, then quickly lift your finger. The content of the screen will continue scrolling with the speed and direction it had at the moment of release. To select an item from a scrolling list and to stop the movement, tap the item. In your device, flicking is available in Music player.
Scroll
To scroll up or down in lists that have a scroll bar, drag the slider of the scroll bar.
In some list views, you can place yo ur f in ge r on a l is t i tem an d drag up or down.
Tip: To view a brief description of an icon, place your finger on the icon. Descriptions are not available for all icons.
Touch screen backlight
To turn the screen backlight on, unlock the screen and keys, if necessary, and press the menu key.

Write text

You can enter text in different modes. The full keyboard works as a traditional keyboard, and the on-screen alphanumeric keypad mode allow you to tap characters. The
© 2009 Nokia. All rights reserved. 21
handwriting recognition modes allow you to write characters directly on the screen.
To activate text input mode, tap any text input field.
In the text input view, to switch between the available text input modes, tap
, and select the desired input mode.
The input methods and languages supported by the handwriting recognition vary by region.
Keyboard input Keyboard
Your device has a full keyboard. To open the keyboard, push the touch screen up. In all applications, the screen rotates
automatically from portrait to landscape when you open the keyboard.
1Sym key. To insert special characters not shown on the
keyboard, press the sym key once, and select the desired character from the table.
2 Function key. To insert special characters printed at the
top of keys, press the function key, and then press the corresponding alphabet key, or press and hold the alphabet key only. To enter several special characters in a row, press the function key twice quickly, and then press the desired alphabet keys. To return to normal mode, press the function key once.
3Shift key. To change between uppercase and lowercase
modes, press the shift key twice. To enter a single uppercase letter in lowercase mode, or a single lowercase letter in uppercase mode, press the shift key once, and then the desired alphabet key.
4Space key 5 Arrow keys. To move up, down, left, or right, use the
arrow keys.
© 2009 Nokia. All rights reserved.22
6Enter key 7 Backspace key. To erase a character, press the
backspace key. To erase several characters, press and hold the backspace key.
Insert letters not shown on the keyboard
It is possible to insert variations of letters, for example, letters with accents. To insert á, press and hold the sym key, and simultaneously press the A key repeatedly, until the desired character is displayed. The order and availability of letters
To write special characters, write them as you would normally. You can also tap
in the right pane of the input
area, and select a desired character from the pop-up table.
depends on the selected writing language.
To delete characters or move the cursor back, swipe
Touch input Handwriting
backwards (see Figure 1).
To insert a space, swipe forwards (see Figure 2).
To activate handwriting mode, tap and Handwriting.
Write legible, upright characters on the text input area, and leave a space between each character.
To teach the device your handwriting style, tap and
Handwriting training.
To enter letters and numbers (default mode), write words as you would normally. To select number mode, tap
in the right pane of the input area. To enter non-Latin characters, tap the corresponding icon, if available.
© 2009 Nokia. All rights reserved. 23
Touch input settings
Select Menu > Settings and Phone > Touch input.
To configure text input settings for the touch screen, select from the following:
Handwriting training — Open the handwriting training application. Train the device to recognise your handwriting better. This option is not available in all languages.
Writing language — Define which language-specific characters in your handwriting are recognised and how your on-screen keyboard is laid out.
Writing speed — Adjust the speed at which handwriting is recognised.
Guiding line — Show or h ide the guiding line in the writing area. The guiding line helps you write in a straight line, and it also helps the device recognise your writing.
Pen trail width — Change the thickness of the text written with the stylus.
Writing colour — Change the colour of the text written with the stylus.
Icons and functions
Use the on-screen keypad (Alphanumeric keypad) to enter characters like you would with a traditional phone keypad with numbers on the keys. For an explanation of each icon and its function, see the following figure.
1 Close - Closes on-screen keypad (Alphanumeric
keypad).
2 Input menu - Opens the touch input menu, which
includes commands such as Activate predictive text and Writing language.
3 Text input indicator - Opens a pop-up window, in which
you can turn predictive text input modes on or off, change the character case, and switc h between letter and number mode.
4 Input mode - Opens a pop-up window, in which you can
select from the available input modes. When you tap an item, the current input method view closes, and the selected one opens.
© 2009 Nokia. All rights reserved.24
5 Arrow keys - Moves the cursor left or right. 6 Backspace - Deletes the previously entered character. 7 Number keys - Enters the desired numbers or characters
according to the current case and input mode.
8 Star - Opens a special characters table. 9 Shift - Changes the character case, turns predictive text
input modes on or off, and switches between the alphabet and number modes.

Lock the keys and touch screen

When the device or keypad is locked, calls may be possible to the official emergency number programmed into your device.
To lock or unlock the touch screen and the keys, slide the lock switch on the side of the device.
When the touch screen and keys are locked, the touch screen is turned off and the keys are inactive.
To modify settings for automatic screen and key locking, select Menu > Settings and Phone > Phone mgmt. >
Auto. keyguard.
Nokia Switch Transfer content
You can use the Switch application to copy content such as phone numbers, addresses, calendar items, and images from your previous Nokia device to your device.
The type of content that can be transferred depends on the model of the device from which you want to transfer content. If that device supports synchronisation, you can also synchronise data between the devices. Your device notifies you if the other device is not compatible.
If the other device cannot be switched on without a SIM card, you can insert your SIM card in it. When your device is switched on without a SIM card, the Offline profile is automatically activated, and transfer can be done.
Transfer content for the first time
1 To retrieve data from the other device for the first time,
on your device, select Menu > Settings >
Connectivity > Data transfer > Phone switch.
2 Select the connection type you want to use to transfer
the data. Both devices must support the selected connection type.
3 If you select Bluetooth connectivity as the connection
type, connect the two devices. To have your device search for devices with Bluetooth connectivity, select
Continue. Select the device from which you want to
transfer content. You are asked to enter a code on your device. Enter a code (1-16 digits), and select OK. Enter the same code on the other device, and select OK. The devices are now paired.
Some earlier Nokia devices may not have the Switch application. In this case, the Switch application is sent to the other device as a message. To install the Switch application on the other device, open the message, and follow the instructions on the display.
© 2009 Nokia. All rights reserved. 25
4 On your device, select the content you want to transfer
from the other device. When the transfer has started, you can cancel it and
continue later.
Content is transferred from the memory of the other device to the corresponding location in your device. The transfer time depends on the amount of data to be transferred.

Synchronise, retrieve, or send content

Select Menu > Settings > Connectivity > Data transfer >
Phone switch.
After the first transfer, select from the following to start a new transfer, depending on the model:
to synchronise content between your device and the other device, if the other device supports synchronisation. The synchronisation is two-way. If an item is deleted in one device, it is deleted in both. You cannot restore deleted items with synchronisation. to retrieve content from the other device to your device. With retrieval, content is transferred from the other device to your device. You may be asked to keep or delete the original content in the other device, depending on the device model. to send content from your device to your other device
If you cannot send an item, depending on the type of the other device, you can add the item to the Nokia folder, to C: \Nokia or E:\Nokia in your device. When you select the folder
to transfer, the items are synchronised in the corresponding folder in the other device, and vice versa.
Use shortcuts to repeat a transfer
After a data transfer, you can save a shortcut with the transfer settings to the main view to repeat the same transfer later.
To edit the shortcut, select Options > Shortcut settings. For example, you can create or change the name of the shortcut.
A transfer log is shown after every transfer. To view the log of the last transfer, select a shortcut in the main view and
Options > View log.
Handle transfer conflicts
If an item to be transferred has been edited in both devices, the device attempts to merge the changes automatically. If this is not possible, there is a transfer conflict. Select Check
one by one, Priority to this phone, or Priority to other phone to solve the conflict.

Profiles

Select Menu > Settings and Profiles.
You can use profiles to set and customise the ringing tones, message alert tones, and other tones for different events, environments, or caller groups. The name of the selected profile is displayed at the top of the home screen.
© 2009 Nokia. All rights reserved.26
To change a profile, scroll to the profile, and select
Options > Activate.
To personalise a profile, scroll to the profile, and select
Options > Personalise. Select the setting you want to
change.
To set the profile to be active until a certain time within the next 24 hours, scroll to the profile, select Options > Timed, and set the time. When the time expires, the profile changes back to the previously active non-timed profile. When the
profile is timed,
is displayed in the home screen. The
Offline profile cannot be timed.
To create a new profile, select Options > Create new.
© 2009 Nokia. All rights reserved. 27

Your device

Home screen About the home screen
In the home screen, you can quickly access your most frequently used applications, control applications, such as the music player, view your favourite contacts, and view at a glance if you have missed calls or new messages.
Interactive home screen elements
To open the clock application, tap the clock (1).
To open calendar or change profiles in the home screen, tap the date or the profile name (2).
To make a phone call, select (4).
To open the main menu, press the menu key (5).
To hide and show content, swipe the home screen with your finger.
Add items to the home screen
To add an item to the home screen, select Options > Edit
content > Options > Add content, and select the item from
the list.
Using widgets may involve the transmission of large amounts of data (network service).
To move an item, select Options > Edit content, select the desired item, and drag and drop it to a new location.
Remove an item from the home screen
Select Options > Edit content and the item to be removed.
Select Options > Remove > Done.
To view or change connectivity settings ( ), to see the available wireless LANs if WLAN scanning is enabled, or to view the missed events, tap the top right corner (3).
E-mail notifications About e-mail notifications
E-mail notifications in the home screen help you keep track of e-mail messages in your mailbox. You can set the device
© 2009 Nokia. All rights reserved.28
to show a preview of e-mail headers or just the number of unread e-mail.
Work with e-mail in the home screen
To add e-mail to the home screen, in the home screen, select
Options > Edit content > Options > Add content > E- mail widget.
contacts' web feeds, or access the contact information and settings.
1 To add your favourite contacts to the home screen, select
Options > Edit content > Options > Add content > Favourite contacts.
A row of
2 Select any of the icons (
icons is displayed in the home screen.
) and a contact from Contacts.
To set up your e-mail account, in the home screen, select Set
up e-mail, and follow the instructions. When the setup is

Add your favourite Share online feed to your home screen

complete, the e-mail icon appears in the home screen. To open your e-mail mailbox, tap the icon.
By adding the Share online widget to your home screen, you can quickly access your favourite Share online feed.

Music player in the home screen

You can use the music player from the home screen. To activate the music player controls, select Options > Edit
content > Options > Add content > Music player.
Go to Music appears in the home screen.
To open the music player, tap Go to Music, and select the items you want to listen to.
The music player control keys, and, if available, the title of the song, artist, and album art are displayed when a song is played.
1 In the home screen, select Options > Edit content >
Options > Add content > Share online.
2 Select the feed you want to add. You may need to register
to a service of your service provider before you are able to add a feed.
The widget displays thumbnail images from a selected feed of any of your Share online accounts. The latest images are displayed first.

Display indicators

The device is being used in a GSM network (network

Favourite contacts in the home screen

You can add several contacts directly to the home screen, and quickly make calls or send messages to the contacts, view the
© 2009 Nokia. All rights reserved. 29
service). The device is being used in a UMTS network (network service).
You have one or more unread messages in the Inbox folder in Messaging. You have received new e-mail in the remo te mailbox. There are messages waiting to be sent in the Outbox folder. You have missed calls.
The ringing type is set to Silent, and the message and e-mail alert tones are turned off. A timed profile is active.
The touch screen and keys are locked. A clock alarm is active. The second phone line is being used (network
service). All calls to the device are diverted to another number (network service). If you have two phone lines, a number indicates the active line. Your device is connected to a network via wireless LAN or UMTS (network service) and ready for an internet call. A compatible headset is connected to the device.
A compatible TV out cable is connected to the device. A compatible text phone is connected to the device. A data call is active (network service). A GPRS packet data connection is active (network service). and
indicates that the connection is on hold
that a connection is available. A packet data connection is active in a part of the network that supports EGPRS (network service).
indicates that the connection is on hold and that a connection is available. The icons indicate that
EGPRS is available in the network, but your device is not necessarily using an EGPRS connection to transfer data. A UMTS packet data connection is active (network
service). suspended and
indicates that the connection is
that a connection is being established. High-speed downlink packet access (HSDPA) is supported and active (network service).
that the connection is suspended and
indicates
that a connection is being established. You have set the device to scan for wireless LANs, and a wireless LAN is available (network service). A wireless LAN connection is active in a network that uses encryption. A wireless LAN connection is active in a network that does not use encryption. Bluetooth connectivity is activated.
Data is being transmitted using Bluetooth connectivity. When the indicator is blinking, your device is trying to connect with another device. A USB connection is active.
Synchronisation is in progress. GPS is active.

Shortcuts

To switch between open applications, press and hold the menu key.
© 2009 Nokia. All rights reserved.30
Leaving applications running in the background increases the demand on battery power and reduces the battery life.
To open the browser application, in the dialler, tap and hold
0.
To change the profile, press the power key, and select a profile.
To call your voice mailbox (network service), in the dialler, tap and hold 1.
To open a list of last dialled numbers, in the home screen, press the call key.
To use voice commands, in the home screen, press and hold the call key.
When writing, to change the writing language, press and the sym key.
To search the contents of your mobile device, enter search terms in the search field, or browse the content categories. While you enter the search terms, the results are organised into categories. The most recently accessed results appear at the top of the result list, if they match your search terms.
To search for web pages on the internet, select Search the
Internet and a search provider, and enter your search terms
in the search field. The search provider you selected is set as your default internet search provider.
If a default search provider is already set, select it to start a search, or select More search services to use another search provider.
To change the default search provider, select Options >
Settings > Search services.
To change the country or region setting to find more search providers, select Options > Settings > Country or region.
Search About Search
Select Menu > Applications > Search.
Search enables you to use various internet-based search services to find, for example, websites, and images. The content and availability of the services may vary.

Search settings

Select Menu > Applications > Search.
To change the Search application settings, select Options >
Settings and from the following:
Country or region — Select the country or region you want
to search from.
Connection — Select the access point, and allow or deny

Start a search

network connections.
Select Menu > Applications > Search.
© 2009 Nokia. All rights reserved. 31
Search services — Select whether service providers and
search categories are shown. General — Enable or disable tooltips, and clear the search
history.

Volume and loudspeaker control

To adjust the volume level when you have an active call or are listening to a sound clip, use the volume key.
The built-in loudspeaker allows you to speak and listen from a short distance without having to hold the device to your ear.
To use the loudspeaker during a call, select Activate
loudsp..
To turn off the loudspeaker, select Activate handset.
The offline profile lets you use the device without connecting to the wireless cellular network. When you activate the offline profile, the connection to the cellular network is
turned off, as indicated by
in the signal strength indicator area. All radio frequency (RF) signals to and from the device to the cellular network are prevented. If you try to send messages using the cellular network, they are placed in the Outbox folder to be sent later.
When the offline profile is active, you can use your device without a SIM card.
If th e SIM car d is n ot pro perl y in plac e, th e device star ts in the offline profile.
Important: In the Offline profile you cannot make or receive any calls, or use other features that require cellular network coverage. Calls may still be possible to the official emergency number programmed into your device. To make calls, you must first activate the phone function by changing profiles. If the device has been locked, enter the lock code.
When you have activated the offline profile, you can still use the wireless LAN, for example, to read your e-mail or browse on the internet. You can also use Bluetooth connectivity while in the offline profile. Remember to comply with any applicable safety requirements when establishing and using a wireless LAN or Bluetooth connections.

Offline profile

To activate the offline profile, press the power key briefly, and select Offline.
To switch to another profile, press the power key briefly, and select another profile. The device re-enables wireless transmissions (providing there is sufficient signal strength).
© 2009 Nokia. All rights reserved.32

Fast downloading

High-speed downlink packet access (HSDPA, also called 3.5G, indicated by
) is a network service in UMTS networks and provides high-speed data downloads. When HSDPA support in the device is activated and the device is connected to a UMTS network that supports HSDPA, downloading data such as messages, e-mail, and browser pages through the cellular network may be faster. An active HSDPA connection is indicated by
.
You can activate or deactivate support for HSDPA in packet data settings.
For availability and subscription to data connection services, contact your service provider.
HSDPA only affects the download speed; sending data to the network, such as messages and e-mail, is not affected.
Ovi (network service) Open Ovi with Nokia N97 mini
Ovi is your door to different Nokia services.
For a tour and more information, browse to www.ovi.com with your computer.
Ovi store About Ovi Store
In Ovi Store, you can download mobile games, applications, videos, images, and ringing tones to your device. Some of the items are free of charge; others you need to purchase using your credit card or through your phone bill. Ovi Store offers
you content that is compatible with your mobile device and relevant to your tastes and location.
The content in Ovi Store is sorted into the following categories:
Recommended
Games
Personalisation
Applications
Audio & video
Create a Nokia account
When you create a Nokia Account, you can access Ovi and all its services with a single user name and password.
1 Select Create a Nokia account. 2 Enter a user name. 3 Select your country from the list. 4 Enter your date of birth. 5 Enter your e-mail address or phone number. 6 Enter a password, and confirm it. 7 Enter the characters displayed in the box on the right. 8 Select Submit.
© 2009 Nokia. All rights reserved. 33
Sign in to Ovi Store
Sign in
Select Sign in, and enter your Nokia account user name and password.
Retrieve forgotten user name or password Select Options > Retrieve.
Search Ovi Store
Items in Ovi Store are organised into categories. You can browse the categories, or search with a keyword.
You can also select the type of items you want to see: free or most popular items, or items recommended for you.
View details of an item
Select an item to see detailed information and other users' reviews. If you have signed in to Ovi Store, you can also write your own reviews.
Read more reviews from others Select More reviews.
Write a review
Select the link to write a review, enter your review, and assign a rating to from 1 to 3 stars.
View information about the publisher
Select the publisher profile link.
Find related items Select More related.
Purchase content
1 Select the item you want to purchase. 2 Select Buy. 3 Enter your Nokia account user name and password. If you
do not have an account, select Create a Nokia account, and enter the required information.
4 Select to pay using your credit card or through your
phone bill. If you already have your credit card information stored in your Nokia account, and you want to use another credit card, select Edit payment settings, and enter the required information. To save your credit card information to your Nokia account, select the Save this card to my Nokia account check box.
5 Select the e-mail address to which you want to receive a
receipt of your purchase.
6 Select Purchase.
Share favourites with friends
Ovi Store enables you to send a text message containing a link to items in Ovi Store.
1 Select the item you want to share. 2 Select Send to friend. 3 Enter a phone number in the international format. 4 Select Send.
© 2009 Nokia. All rights reserved.34
Report inappropriate content
Contact Nokia if you find inappropriate content in Ovi Store.
1 Select the item with inappropriate content. 2 Select Report issue. 3 Select the reason from the list, and enter additional
details, if needed.
4 Select Submit.
Edit the Ovi Store settings
In the Ovi Store settings, you can change your account information, grant your friends permission to see your activities in Ovi Store, and change your password and security question.
To change the Ovi Store settings, select Options > Settings and from the following:
Ovi sharing — Allow your Ovi contacts to see your activities in Ovi Store.
Account information — Change the details of your Nokia account.
Change password — Change your Nokia account password. Change security question — Change the security question
with which you can retrieve your user name and password. Installation preferences — Select how you want to install
content in your device.
© 2009 Nokia. All rights reserved. 35

Make calls

Proximity sensor

Your device has a proximity sensor. To prevent accidental selections, the touch screen is disabled automatically during calls when you place the device next to your ear.
2 Scroll to the desired name. Or, tap the search field to enter
the first letters or characters of the name, and scroll to the name.
3 To call the contact, press the call key. If you have saved
several numbers for a contact, select the desired number from the list, and press the call key.

During a call

Do not cover the proximity sensor, for example, with protective film or tape.

Voice calls

1 In the home screen, select
dialler, and enter the phone number, including the area code. To remove a number, select C.
For international calls, select * twice for the + character (which replaces the international access code), and enter the country code, area code (omit the leading zero if
necessary), and phone number. 2 To make the call, press the call key. 3 To end the call (or to cancel the call attempt), press the
end key.
Pressing the end key always ends a call, even if another
application is active.
1 To make a call from the contacts list, select Menu >
Contacts.
or Dialler to open the
To mute or unmute the microphone, select
To put the call on hold or unhold it, select or .
To activate the loudspeaker, select . If you have attached a compatible headset with Bluetooth connectivity, to route the sound to the headset, select Options > Activate BT
handsfree.
To switch back to the handset, select .
To end the call, select .
To switch between the active and the held call, select .
Tip: When you have only one active voice call, to put the call on hold, press the call key. To activate the call, press the call key again.
To send DTMF tone strings (for example, a password), select
Options > Send DTMF.
Enter the DTMF string or search for it in the contacts list.
© 2009 Nokia. All rights reserved.36
or .
To enter a wait character (w) or a pause character (p), press * repeatedly.
To send the tone, select OK. You can add DTMF tones to the phone number or DTMF field in contact details.
To end an active call and replace it by answering the waiting call, select Options > Replace.
To end all your calls, select .
Many of the options that you can use during a voice call are network services.
You can send a text message without rejecting the call, informing the caller that you cannot answer the call. To send the reply message, select Send msg., edit the message text, and press the call key.
If you do not want to answer a call, press the end key. If you activate the Call divert > Voice calls > If busy function in phone settings to divert calls, rejecting an incoming call also diverts the call.
To activate the text message option and write a standard reply message, select Menu > Settings and Calling >
Call > Reject call with message, and Message text.

Voice and video mailboxes

To call your voice or video mailbox (network services, video mailbox available only in UMTS networks), in the home
screen, select
to open the dialler, tap and hold 1, and
select Voice mailbox or Video mailbox.

Make a conference call

Your device supports conference calls between a maximum of six participants, including yourself.
1 Make a call to the first participant. 2 To make a call to another participant, select Options >
New call. The first call is put on hold.
1 To change the phone number of your voice or video
mailbox, select Menu > Settings and Calling > Call
mailbox, a mailbox, and Options > Change number.
2 Enter the number (obtained from your network service
provider), and select OK.

Answer or reject a call

To answer a call, press the call key, or open the slide.
© 2009 Nokia. All rights reserved. 37
3 When the new call is answered, to join the first
participant in the conference call, select
.
To add a new person to the call, make a call to another participant, and add the new call to the conference call.
To have a private conversation with one of the participants, select
Go to the participant, and select
.
. The conference call is put on hold on your device. The other participants can still continue the conference call.
To return to the conference call, select . To drop a particip ant, select
select
.
, go to the participant, and
4 To end the active conference call, press the end key.

Speed dial a phone number

To activate the feature, select Menu > Settings and
Calling > Call > Speed dialling.
1 To assign a phone number to one of the number keys,
select Menu > Settings and Calling > Speed dialling.
2 Scroll to the key to which you want to assign the phone
number, and select Options > Assign. 1 and 2 are reserved for the voice and video mailboxes.
To call in the home screen, select
to open the dialler, select
the assigned key number, and press the call key.
To call in the home screen when speed dialling is active, select
to open the dialler, and tap and hold the assigned key
number.

Call waiting

You can answer a call when you have another call in progress.
To activate call waiting (network service), select Menu >
Settings and Calling > Call > Call waiting.
1 To answer the waiting call, press the call key. The first call
is put on hold.
2 To switch between the two calls, select Options >
Swap.
3 To connect a call on hold with an active call, and to
disconnect yourself from the calls, select Options >
Transfer.
4 To end the active call, press the end key. 5 To end both calls, select Options > End all calls.

Voice dialling

Your device automatically creates a voice tag for the contacts. To listen to the synthesised voice tag, select a contact and
Options > Voice tag details. Scroll to a contact detail, and
select Options > Play voice tag.
Make a call with a voice tag Note: Using voice tags may be difficult in a noisy
environment or during an emergency, so you should not rely solely upon voice dialling in all circumstances.
When you use voice dialling, the loudspeaker is in use. Hold the device at a short distance away when you say the voice tag.
1 To start voice dialling, in the home screen, press and hold
the call key. If a compatible headset with the headset key is attached, press and hold the headset key to start voice dialling.
© 2009 Nokia. All rights reserved.38
2 A short tone sounds, and Speak now is displayed. Say
clearly the name that is saved for the contact.
3 The device plays a synthesised voice tag for the
recognised contact in the selected device language, and displays the name and number. To cancel the voice dialling, select Quit.
If several numbers are saved for a name, you can say also the name and the number type, such as mobile or telephone.

Make a video call

When you make a video call (network service), you can see a real-time, two-way video between you and the recipient of the call. The live video image, or video image captured by the camera in your device is shown to the video call recipient.
To be able to make a video call, you must have a USIM card and be in the coverage of a UMTS network. For availability, pricing and subscription to video call services, contact your network service provider.
A video call can only be made between two parties. The video call can be made to a compatible mobile device or an ISDN client. Video calls cannot be made while another voice, video, or data call is active.
Icons
You are not receiving video (the recipient is not sending video or the network is not transmitting it). You have denied video sending from your device. To send a still image instead, select Menu > Settings and Calling > Call > Image in video call.
Even if you denied video sending during a video call, the call is still charged as a video call. Check the pricing with your service provider.
1 In the home screen, select
to open the dialler, and
enter the phone number.
2 Select Options > Call > Video call.
The secondary camera on the front is used by default for video calls. Starting a video call may take a while. If the call is not successful (for example, video calls are not supported by the network, or the receiving device is not compatible), you are asked if you want to try a normal call or send a message instead.
The video call is active when you see two video images, and hear the sound through the loudspeaker. The call
recipient may deny video sending (indicated by
), and you only hear the voice of the caller and may see a still image or a grey screen.
3 To end the video call, press the end key.

During a video call

To change between showing video or hearing the voice of the caller only, select
or .
To mute or unmute the microphone, select or .
To activate the loudspeaker, select . If you have attached a compatible headset with Bluetooth connectivity, to route
© 2009 Nokia. All rights reserved. 39
the sound to the headset, select Options > Activate BT
handsfree.
To switch back to the handset, select .
To use the camera in the back of your device to send video, select Options > Use secondary camera.
To switch back to the camera in the front of your device, select
Options > Use main camera.
To take a snapshot of the video you are sending, select
Options > Send snapshot. Video sending is paused and the
snapshot is shown to the recipient. The snapshot is not saved.
To zoom your image in or out, select Options > Zoom.
To change the video quality, select Options > Adjust >
Video preference > Normal quality, Clearer detail or Smoother motion.

Answer or reject a video call

When a video call arrives,
is displayed.
1 To answer the video call, press the call key. 2 To start sending live video image, select Yes.
If you do not activate the video sending, you only hear the voice of the caller. A grey screen replaces your own video image. To enable the video sending, select Options >
Enable > Sending video.
To replace the grey screen with a still image captured by the camera in your device, select Menu > Settings and
Calling > Call > Image in video call.
If you do not want to answer a video call, press the end key.
Internet calls About internet calls
With the internet call network service, you can make and receive calls over the internet. Internet call services may support calls between computers, between mobile phones, and between a VoIP device and a traditional telephone. For availability and costs, contact your internet call service provider.
To make or receive an internet call, you must be in the service area of a wireless LAN (WLAN) or have a packet data (GPRS) connection in a UMTS network, and be connected to an internet call service.
Your device may offer you an installation widget, to install internet call services.

Log into an internet call service

When an internet call service has been installed, a tab for the service is displayed in the contacts list.
To log into a service, select Menu > Contacts, the service, and Options > Log in.
© 2009 Nokia. All rights reserved.40
To add contacts as service contacts to the friends list manually or from the contacts list, select Options > New contact.

Make internet calls

To call a contact when you are logged into a service, tap the contact in the friends list, and select
.
To make an internet call in the home screen, select , enter the number, and select Options > Call > Internet call.
To make an internet call to an internet call address, in the home screen, select Enter the address, and select
and Options > Open keyboard.
.

Internet communication settings

Select Menu > Settings and Connectivity > Admin.
settings > Net settings.
To view and edit the settings for a service, select [09] sett..
To remove a service from your service list, select Options >
Delete service.

Internet call service settings

Select Menu > Contacts, open a service tab, and select
Options > Settings.
To set an internet call service as the default service, select
Default service. When you press the call key to call a number,
your device makes an internet call using the default service if the service is connected. You can set only one service at a time as the default service.
To edit the service destination, select Service connectivity.

Video sharing

Use video sharing (network service) to send live video or a video clip from your mobile device to another compatible mobile device during a voice call.
The loudspeaker is active when you activate video sharing. If you do not want to use the loudspeaker for the voice call while you share video, you can also use a compatible heads et.
Warning:
Continuous exposure to high volume may damage your hearing. Listen to music at a moderate level, and do not hold the device near your ear when the loudspeaker is in use.

Video sharing requirements

Video sharing requires a UMTS connection. Your ability to use video sharing depends on the availability of the UMTS network. For more information on the service, UMTS network availability, and fees associated with using this service, contact your service provider.
To use video sharing, ensure the following:
© 2009 Nokia. All rights reserved. 41
Your device is set up for person-to-person connections.
You have an active UMTS connection and are within UMTS
network coverage. If you move outside the UMTS network during a video sharing session, the sharing stops while your voice call continues.
Both the sender and recipient are registered to the UMTS network. If you invite someone to a sharing session and the recipient’s device is not within UMTS network coverage or does not have video sharing installed or person-to-person connections set up, the recipient does not receive invitations. You receive an error message that indicates that the recipient cannot accept the invitation.

Settings

To set up video sharing, you need person-to-person and UMTS connection settings.
Person-to-person connection settings
A person-to-person connection is also known as a Session Initiation Protocol (SIP) connection. The SIP profile settings must be configured in your device before you can use video sharing. Ask your service provider for the SIP profile settings, and save them to your device. Your service provider may send you the settings or give you a list of the needed parameters.
To add a SIP address to a contact:
1 Select Menu > Contacts. 2 Open the contact or create a new contact. 3 Select Options > Edit. 4 Select Options > Add detail > Share video.
5 Enter the SIP address in the format
username@domainname (you can use an IP address instead of a domain name).
If you do not know the SIP address for the contact, you can use the phone number of the recipient, including the country code, to share video (if supported by the network service provider).
UMTS connection settings
To set up your UMTS connection:
Contact your service provider to establish an agreement for you to use the UMTS network.
Ensure that the UMTS access point connection settings for your device are configured properly. For more information about the settings, contact your service provider.

Share live video or video clips

During an active voice call, select Options > Share video.
1 To share live video during the call, select Live video.
To share a video clip, select Video clip. A list of video clips saved in the device memory, the mass memory, or a memory card (if available) opens. Select the clip you want to share.
You may need to convert the video clip into a suitable format to be able to share it. If your device notifies you that the video clip must be converted, select OK. Your device must have a video editor for the conversion to work.
© 2009 Nokia. All rights reserved.42
2 If the recipient has several SIP addresses or phone
numbers including the country code saved in Contacts, select the desired address or number. If the SIP address or phone number of the recipient is not available, enter the address or number of the recipient including the country code, and select OK to send the invitation. Your device sends the invitation to the SIP address.
Sharing begins automatically when the recipient accepts the invitation.
Options during video sharing
to mute or unmute the microphone
to switch the loudspeaker on and off
to pause and resume video sharing
to switch to full screen mode (available for receiver only)
3 To end the sharing session, select Stop. To end the voice
call, press the end key. When you end the call, video sharing also ends.
To save the live video you shared, select Yes when prompted. The device notifies you of the location of the saved video.
If you access other applications while you are sharing a video clip, the sharing is paused. To return to the video sharing view and to continue sharing, in the home screen, select
Options > Resume video sharing.

Accept an invitation

When someone sends you a video sharing invitation, the invitation message displays the sender’s name or SIP address.
If someone sends you a sharing invitation and you are not within 3G network coverage, you will not know that you received an invitation.
When you receive an invitation, select from the following:
Yes — Accept the invitation, and activate the sharing session. No — Reject the invitation. The sender receives a message
that you rejected the invitation. You can also press the end key to reject the invitation and end the voice call.
To end the sharing session, select Stop. To end the voice call, press the end key. When you end the call, video sharing also ends.
Log
The log stores information about the communication history of the device. The device registers missed and received calls only if the network supports these functions, the device is switched on, and within the network service area.

Recent calls

You can view information about your recent calls.
Select Menu > Applications > Log and Recent calls.
© 2009 Nokia. All rights reserved. 43
View missed, received, and dialled calls
Select Missed calls, Received calls, or Dialled numbers.
Tip: To open the dialled numbers list in the home screen, press the call key.
Select Options and from the following: Save to Contacts — Save a phone number from a recent calls
list to your contacts.
Clear list — Clear the selected recent calls list. Delete — Clear an event in the selected list. Settings — S elect Log duration and the length of time that
the communication information is saved in the log. If you select No log, no information is saved in the log.

Call duration

Select Menu > Applications > Log.
To view the approximate duration of your last call, dialled and received calls, select Call duration.
Note: The actual invoice for calls and services from your service provider may vary, depending on network features, rounding off for billing, taxes, and so forth.

Packet data

Select Menu > Applications > Log.
To check the amount of data sent or received during packet data connections, select Packet data > All sent dataor All
received data.
To clear both sent and received information, select
Options > Clear counters. You need the lock code to clear
the information.

Monitor all communication events

Select Menu > Applications > Log.
To open the general log where you can monitor all voice calls, text messages, or data and wireless LAN connections
registered by the device, select the general log tab Subevents, such as a text message sent in more than one part
and packet data connections, are logged as one communication event. Connections to your mailbox, multimedia messaging centre, or web pages are shown as packet data connections.
To view how much data was transferred and how long a certain packet data connection lasted, scroll to an incoming or outgoing event indicated by GPRS, and select Options >
View.
To copy a phone number from the log to the clipboard, and paste it into a text message, for example, select Options >
Use number > Copy.
To filter the log, select Options > Filter and a filter.
.
© 2009 Nokia. All rights reserved.44
To set the log duration, select Options > Settings > Log
duration. If you select No log, all the log contents, recent
calls register, and messaging delivery reports are permanently deleted.
© 2009 Nokia. All rights reserved. 45

Contacts (phonebook)

To open Contacts, select Menu > Contacts.
You can save and update contact information, such as phone numbers, home addresses, or e-mail addresses of your contacts. You can add a personal ringing tone or a thumbnail image to a contact. You can also create contact groups, which allow you to send text messages or e-mail to many recipients at the same time.

Save and edit names and numbers

1 To add a new contact to the contacts list, tap 2 Tap a field to enter the information in the field. To close
the text input, select and select Done.
To edit contacts, select a contact and Options > Edit.
. Fill in the fields that you want,
.
To delete several contacts at the same time, select
Options > Mark/Unmark to mark the desired contacts, and
to delete, select Options > Delete.
To listen to the voice tag assigned to a contact, select the contact and Options > Voice tag details > Options > Play
voice tag.
Before using voice tags, note the following:
Voice tags are not language-dependent. They are dependent on the speaker's voice.
You must say the name exactly as you said it when you recorded it.
Voice tags are sensitive to background noise. Record voice tags and use them in a quiet environment.
Very short names are not accepted. Use long names, and avoid similar names for different numbers.

Contacts toolbar

On the contacts list toolbar, select from the following:
Call — Call the desired contact.
Create message — Send a message to the desired
contact.
New contact — Create a new contact.

Manage names and numbers

To copy or delete a contact, or to send a contact as a business card to another device, tap and hold a contact, and select Add
to favourites, Edit, or Send business card.
Note: Using voice tags may be difficult in a noisy
environment or during an emergency, so you should not rely solely upon voice dialling in all circumstances.

Default numbers and addresses

You can assign default numbers or addresses to a contact. If a contact has several numbers or addresses, you can easily call or send a message to a certain number or address. The default number is also used in voice dialling.
1 In the contacts list, select a contact. 2 Select Options > Defaults.
© 2009 Nokia. All rights reserved.46
3 Select a default to which you want to add a number or
an address, and select Assign.
4 Select a number or an address you want to set as a
default.
5 To exit the Defaults view and save the changes, tap
outside the view.

Contact cards

Select Menu > Contacts and a contact. All available communication methods for the selected contact are displayed in the contact cards view.
Select a contact from the list, the desired communication method, Options, and from the following:
Edit — Edit, add, or delete the contact card fields. Defaults — Define the numbers and addresses to use by
default when you communicate with the contact, if a contact has more than one number or address defined.
Voice tag details — View the voice tag details, or listen to the voice tag for the contact.
The available options and communication methods may vary.

Set contacts as favourites

Select Menu > Contacts.
Favourites are the contacts you have set as your favourite contacts. These contacts appear at the top of the contacts list.
To set a contact as a favourite, select a contact and
Options > Add to favourites. Favourites are marked with a
star icon.
To remove a contact from favourites, select a contact and
Options > Remove from favourites. The removed contact
is moved back to the standard contacts list.

Ringing tones, images, and call text for contacts

You can define a ringing tone for a contact or group, and an image and a call text for a contact. When the contact calls you, the device plays the selected ringing tone and shows the call text or image (if the caller’s phone number is sent with the call and your device recognises it).
To define a ringing tone for a contact or a contact group, select the contact or contact group and Options > Edit >
Ringing tone, and a ringing tone.
To add more fields to a contact details view, select the contact and Options > Edit > Options > Add detail.
To define a call text for a contact, select the contact and
Options > Edit > Options > Add detail > Call alert text.
Tap the text field to enter the call text, and select
.
To add an image for a contact saved in the device memory, select the contact, Options > Edit > Add image, and an image from Photos.
To remove the ringing tone, select Default tone from the list of ringing tones.
© 2009 Nokia. All rights reserved. 47
To view, change or remove the image from a contact, select the contact, Options > Image, and the desired option.

Copy contacts

When you open the contacts list for the first time, the device asks if you want to copy names and numbers from the SIM card to your device.
The numbers you save in the contacts list may not be automatically saved to your SIM card. To save numbers to the SIM card, select a contact and Options > Copy > SIM
memory.
To select whether the new contacts you enter are saved to your device or your SIM card, select Options > Settings >
Default saving memory > Phone memory or SIM memory.
To start copying, select OK.
If you do not want to copy the contacts from the SIM card to your device, select Cancel. Th e d e vi ce as ks i f y ou w an t t o v ie w the SIM card contacts in the contacts directory. To view the contacts, select OK. The contacts list opens, and the names
stored on your SIM card are indicated with
.

SIM services

For availability and information on using SIM card services, contact your SIM card vendor. This may be the service provider or other vendor.

SIM contacts

To set the names and numbers stored on the SIM card to be shown on the contacts list, select Options > Settings >
Contacts to display > SIM memory. You can add and edit
SIM contacts, or call them.

Fixed dialling

Select Menu > Contacts and Options > SIM numbers >
Fixed dial contacts.
With the fixed dialling service, you can restrict calls from your device to certain phone numbers. Not all SIM cards support the fixed dialling service. For more information, contact your service provider.
When security features that restrict calls are in use (such as call barring, closed user group, and fixed dialling), calls may be possible to the official emergency number programmed into your device. Call barring and call diverting cannot be active at the same time.
You need your PIN2 code to activate and deactivate fixed dialling or edit your fixed dialling contacts. Contact your service provider for your PIN2 code.
Select Options and from the following:
Activate fixed dialling — Activate the fixed dialing. Deactivate fixed dialling — Deactivate the fixed dialing.
© 2009 Nokia. All rights reserved.48
New SIM contact — Enter the contact name and phone
number to which calls are allowed. Add from Contacts — Copy a contact from the list of contacts
to the fixed dialling list.
To send text messages to the SIM contacts while the fixed dialling service is active, you need to add the text message centre number to the fixed dialling list.

Contact groups

To open the group list, open the contacts list, and tap
.

Create contact groups

1 To create a new group, in the group list, select
Options > New group. Use the default name or enter a
new name. Select OK.
2 To add members to the group, select the group and
Options > Add members.
3 Mark each contact you want to add, and select OK.

Manage contact groups

To send a message to all group members, to set a ringing tone for a group, or to rename or delete a group, tap and hold the group, and select Create message, Ringing tone,
Rename, or Delete.
To add a contact to a group, select the group and Options >
Add members.
To check which other groups a contact belongs to, select the group, scroll to the contact, and select Options > Belongs
to groups.
To remove a contact from a group, select the group, scroll to the contact, and select Options > Remove from group.
© 2009 Nokia. All rights reserved. 49

Ovi Contacts

About Ovi Contacts

With Ovi Contacts, you can stay connected to the people who matter most. Search for contacts, and discover friends in the Ovi community. Keep in touch with your friends - chat, share your location and presence, and easily follow what your friends are up to and where they are. You can even chat with friends who use Google Talk™.
You can also sync your contacts, calendar, and other content between your Nokia device and Ovi.com. Your important information is stored and kept up-to-date both in your device and on the web. With Ovi Contacts, you can make your contacts list dynamic and be confident that your contacts are stored on Ovi.com.
You must have a Nokia Account to use the service. Create an account on your mobile device, or visit www.ovi.com on your PC.
Using Ovi Contacts may involve the transmission of large amounts of data through your service provider's network. Contact your network service provider for information about data transmission charges.

Start using Ovi Contacts

Select Contacts, and open the Ovi tab.
The Ovi Contacts service is part of Ovi, and uses the same account information.
If you are new to Ovi and its services, to start using the Ovi Contacts application, you must register to Ovi by creating a Nokia account.
Create a Nokia account
1 Select Ovi Chat, and when prompted, connect to the
internet.
2 Enter the required information. 3 In the My profile view, enter your profile information.
Your first and last name are mandatory details.
4 Select Done.
If you have already registered to Ovi using your PC or mobile device, you can start using Ovi Contacts with the same account details.
Sign in to Ovi Contacts and activate the service
Select Ovi Chat, and enter your user name and password. If you have not yet provided your profile information for Ovi
Contacts, do so, and select Done. Your first and last name are mandatory details.

Connect to the service

Connect to Ovi Contacts
Select Go online and the connection method. Use a wireless LAN (WLAN) connection where available.
Cancel the connection
Select Options > Cancel connecting.
© 2009 Nokia. All rights reserved.50
A packet data connection may generate additional data transmission charges. For pricing details, contact your network service provider.
Select Go online > Options and from the following:
Select — Select the item. Go online — Connect to the service if you are offline. My profile — Edit your profile information. Recommend to friend — Invite a contact to join Ovi
Contacts. The invitation is sent as a text message. Settings — Modify the Ovi Contacts settings.
The available options may vary.

Create and edit your profile

Edit your profile information
Select My profile.
View the profiles of your Ovi Contacts friends
Select a friend and Options > Profile.
Your profile information is visible to your Ovi Contacts friends. Only the following profile details are displayed to other Ovi Contacts users, for example during a search: first name and last name. To change your privacy settings, access Ovi on your PC, and sign in to your Nokia account.
Change your profile image
Select the profile image, Select existing image, and the new image. You can also edit or remove the current profile image or capture a new one.
Change your availability
By default, your availability is set to Available. To change your availability, select the icon.
Tell your friends what you are doing at the moment
Select What are you doing?, and enter text in the field.
Show your friends what music you are currently listening to
Select Now playing. To do this, you must allow your now playing information to be shared in the presence settings.
Edit your contact information
Select a field, and enter text.
In the My profile view, select Options and from the following:
Edit text — Cut, copy, or paste text. Change — Change your status (when the status field is
selected). Activate — Start broadcasting your location or your now
playing information to your friends (when either field is selected).
Undo changes — Undo the changes you made in the profile view.
© 2009 Nokia. All rights reserved. 51
Edit shared locations — Select the landmarks you want to
broadcast to your friends (when the My location field is selected).
Stop sharing — Stop broadcasting your location to your friends (when the My location field is selected).
The available options may vary.

Find and add friends

Select Options > Invite friend.
Search for a friend
Enter the name of the friend in the Search friends field, and select the search icon. You cannot search for friends based on their mobile number or e-mail address.
Browse the search results
Select Next results or Previous results.
Start a new search
Select New search.
Select Options and from the following:
Select — Select an item. Open — Open an item. Invite as friend — Send an invitation to the contact. Show profile — View the profile of the contact. Renew invitation — Resend an invitation to join Ovi
Contacts to a pending friend. Search — Search for the contact whose name or other
related keyword you entered in the Search friends field. Edit text — Cut, copy, or paste text.
The available options may vary.

Chat with your friends

Start a chat with a friend
Select the friend.
Send a chat message
Enter the text in the message field, and select the send icon.
If the friends you searched for could not be found, they are not registered Ovi members, or they have chosen to be invisible in searches. When prompted, send a text message to your friends to invite them to join Ovi Contacts.
Send an invitation to join Ovi Contacts
Select Select service: and the service you know your friend uses. Enter your friend’s user name, and select the send icon.
In the chat view, select Options and from the following:
Send — Send the message. Add smiley — Insert a smiley. Send my location — Send your location details to your chat
partner (if supported by both devices).
Profile — View the details of a friend. My profile — Select your presence status or profile image,
personalise your message, or change your details.
© 2009 Nokia. All rights reserved.52
Edit text — Copy or paste text. End chat — End the active chat. Exit — End all active chats, and close the application.
The available options may vary.
To receive location information from your friend, you must have the Maps application. To send and receive location information, both the Maps and Positioning applications are needed.
View the location of your friend
Select Show on map.
Return to the Ovi Contacts main view without ending the chat
Select Back.
Add, call, or copy phone numbers from a chat
Go to a phone number in a chat, and select Options and the appropriate option.

Ovi Sync

To sync your device with Ovi, you must have a Nokia account and activate the Ovi Contacts service on your device.
Sync your device with Ovi
1 If you sync your device with Ovi for the first time, use the
Sync wizard to select what content you want to sync, and the sync interval.
2 Select Synchronise. If your device is in the Offline profile,
connect to the internet when prompted.
Select Options and from the following:
Start — Sync your device with Ovi. Cancel — Cancel an ongoing sync. Synchronisation settings — Modify your sync settings.
The available options may vary.

Share your location

Open the Contacts application and the Ovi tab.
To share your location, select Options > Settings >
Presence > Share my location and from the following:
Sharing allowed — Allow your friends to see your location. My shared landmarks — Select the landmarks from where
your location is broadcast to your friends. Refresh interval — Select how often you broadcast your
current location.
Add and select landmarks:
To add a location to the landmarks list, select Share my
location > My shared landmarks > Options > New landmark.
To add your current location as a landmark, select Current
position.
To browse for a location on a map, select Select from map.
© 2009 Nokia. All rights reserved. 53
To add a landmark manually, select Enter manually.
To select the locations you want to share with your friends, select Share my location > My shared landmarks, and select the landmarks from the list. Select Options to edit, mark, and unmark items on the list.
Whenever you are online with the Contacts on Ovi service, and in one of the selected locations, your friends can see your location.

Ovi Contacts settings

Select Options > Settings.
Select from the following: Account — Access your account details, and define your
visibility to others in a search. Presence — Show information about your location to your
friends, and allow them to see when you are making a phone call (call status).
Personalisation — Modify the settings related to the startup and tones of the Ovi Contacts application, and automatically accept friend invitations.
Connection — Select the network connection to use, and activate roaming warnings.
Using a packet data connection may involve the transmission of large amounts of data through your service provider's network. For information about data transmission charges, contact your network service provider.
Exit — End all active chats, and close the application.

Nokia account settings

Select Options > Settings > Account.
Edit your account details
Select My account.
Define your visibility in searches
Select My account > Visibility in search. You must be online to change your visibility.

Presence settings

Select Options > Settings > Presence.
Modify presence settings
Select from the following:
Share my location — Allow your friends to see your location. Share now playing — Allow your friends to see what music
you are currently listening to on your mobile device.
Share call status — Allow your friends to see your call status.
Share your location
Select Share my location and from the following: Sharing allowed — Allow your friends to see your location
in selected landmarks. My shared landmarks — Select the landmarks from where
your location is broadcast to your friends.
© 2009 Nokia. All rights reserved.54
Refresh interval — Select how often you broadcast your
current location.
Add a location to the landmarks list
Select Share my location > My shared landmarks >
Options > New landmark.
Add your current location as a landmark
Select Current position.
Browse for a location on a map
Select Select from map.
Add a landmark manually
Select Enter manually.
Select locations you want to share with your friends
1 Select Share my location > My shared landmarks. 2 Select the landmarks from the list. 3 Select Options to edit, mark, and unmark items on the
list. Depending on your settings, your friends can see your location when you are in one of the selected locations.

Personalisation settings

Select Options > Settings > Personalisation.
Select from the following: Login on start-up — Sign in automatically to Ovi Contacts
when you switch on your mobile device.
Auto-accept friend invit. — Accept friend requests automatically without notification.
Auto-accept voice msgs. — Allow voice message to be accepted automatically.
Message tone — Select a tone for new messages. Friend online tone — Select the tone that sounds when a
friend comes online. Icon on Home screen — Add the Ovi Contacts shortcut icon
to your device home screen.

Connection settings

Select Options > Settings > Connection.
Modify connection settings
Select Network connection and the desired connection. To use the default connection defined in your device connection settings, select Default connection.
Set the device to notify you when your home network is not available
To receive a warning when your device is trying to connect to another network, select Roaming warning > On.
© 2009 Nokia. All rights reserved. 55

Messaging

Messaging main view

Select Menu > Messaging (network service).
To create a new message, select New message.
Tip: To avoid rewriting messages that you send often, use texts in the Templates folder in My folders. You can also create and save your own templates.
Messaging contains the following folders:
Inbox — Received messages, except e-mail and cell
broadcast messages, are stored here.
My folders — Organise your messages into folders.
Mailbox — Connect to your remote mailbox to retrieve
your new e-mail messages, or view your previously retrieved e-mail messages offline.
Drafts — Draft messages that have not been sent are
stored here.
Sent — The last messages that have been sent, excluding
messages sent using Bluetooth connectivity, are stored here. You can change the number of messages to save in this folder.
Outbox — Messages waiting to be sent are temporarily
stored in the outbox, for example, when your device is outside network coverage.
Delivery reports — You can request the network to send
you a delivery report of the text messages and multimedia messages you have sent (network service).

Write and send messages

Select Menu > Messaging.
Important: Exercise caution when opening messages. Messages may contain malicious software or otherwise be harmful to your device or PC.
Before you can create a multimedia message or write an e­mail, you must have the correct connection settings defined.
The wireless network may limit the size of MMS messages. If the inserted picture exceeds this limit, the device may make it smaller so that it can be sent by MMS.
Only devices that have compatible features can receive and display multimedia messages. The appearance of a message may vary depending on the receiving device.
Check the size limit of e-mail messages with your service provider. If you attempt to send an e-mail message that exceeds the size limit of the e-mail server, the message is left in the Outbox folder, and the device attempts to resend it periodically. Sending an e-mail requires a data connection, and continuous attempts to resend the e-mail may incur charges from your service provider. In the Outbox folder, you can delete such a message or move it to the Drafts folder.
Messaging requires network services.
© 2009 Nokia. All rights reserved.56
1 To send a text or a multimedia message, select New
message.
To send an audio or e-mail message, select Options >
Create message, and the relevant option.
2 To select recipients or groups from the contacts list,
select
from the toolbar; Or to enter the number or e-
mail manually, tap the To field.
3 In the Subject field, enter the subject of the e-mail or
multimedia message. If the Subject field is not visible, select Options > Message header fields to change the fields that are visible.
4 To write the message, tap the message field. 5 To add an object to a message or e-mail, select
and
the relevant type of content. The message type may change to multimedia message
based on the inserted content.
6 To send the message or e-mail, select
, or press the
call key.
Your device supports text messages beyond the limit for a single message. Longer messages are sent as two or more messages. Your service provider may charge accordingly. Characters with accents, other marks, or some language options take more space, and limit the number of characters that can be sent in a single message.
Messaging inbox Receive messages
Select Menu > Messaging and Inbox.
In the Inbox folder,
indicates an unread text message,
an unread multimedia message, an unread audio
message, and
data received through Bluetooth
connectivity.
When you receive a message,
and 1 new message are
displayed in the home screen. To open the message, select
Show. To open a message in the Inbox folder, select the
message. To reply to a received message, select Options >
Reply.
Multimedia messages Important: Exercise caution when opening messages.
Messages may contain malicious software or otherwise be harmful to your device or PC.
You may receive a notification that a multimedia message is waiting in the multimedia message centre. To start a packet data connection to retrieve the message to your device, select
Options > Retrieve.
When you open a multimedia message ( image and a message.
is shown if sound is included, or
), you may see an
if video is included. To play the sound or the video, select
the indicator.
To see the media objects that have been included in the multimedia message, select Options > Objects.
© 2009 Nokia. All rights reserved. 57
If the message includes a multimedia presentation, is displayed. To play the presentation, select the indicator.

Data, settings, and web service messages

Your device can receive many kinds of messages that contain data, such as business cards, ringing tones, operator logos, calendar entries, and e-mail notifications. You may also receive settings from your service provider in a configuration message.
To save the data from the message, select Options and the corresponding option.
Web service messages are notifications (for example, news headlines) and may contain a text message or a link. For availability and subscription, contact your service provider.
Mailbox Define e-mail settings
Select Menu > Messaging and Mailbox.
To use e-mail, you must have defined a valid internet access point (IAP) in the device and have defined your e-mail settings correctly.
You must have a separate e-mail account. Follow the instructions given by your remote mailbox and internet service provider (ISP).
If you select Messaging > Mailbox and have not set up your e-mail account, you are prompted to do so. To start creating the e-mail settings with the mailbox guide, select Start.
When you create a new mailbox, the name you give to the mailbox replaces Mailbox in the Messaging main view. You can have up to six mailboxes.

Open the mailbox

Select Menu > Messaging and a mailbox.
When you open the mailbox, the device asks if you want to connect to the mailbox.
To connect to your mailbox and retrieve new e-mail headers or messages, select Yes. When you view messages online, you are continuously connected to a remote mailbox using a data connection.
To view previously retrieved e-mail messages offline, select
No.
To create a new e-mail message, select Options > Create
message > E-mail.
When you are online, to end the data connection to the remote mailbox, select Options > Disconnect

Retrieve e-mail messages

Select Menu > Messaging and a mailbox.
© 2009 Nokia. All rights reserved.58
If you are offline, select Options > Connect to open a connection to the remote mailbox.
Important: Exercise caution when opening messages. Messages may contain malicious software or otherwise be harmful to your device or PC.
1 When you have an open connection to a remote mailbox,
select Options > Retrieve e-mail > New to retrieve all new messages, Selected to retrieve only selected messages, or All to retrieve all messages from the mailbox.
To stop retrieving messages, select Cancel.
2 To close the connection and view the e-mail messages
offline, select Options > Disconnect.
3 To open an e-mail message, select the message. If the e-
mail message has not been retrieved and you are offline, you are asked if you want to retrieve this message from the mailbox.
To view e-mail attachments, open the message, and select the attachment field indicated by
. If the attachment has
not been retrieved to the device, select Options >
Retrieve.
To retrieve e-mail messages automatically, select Options >
E-mail settings > Automatic retrieval.
Setting the device to retrieve e-mail automatically may involve the transmission of large amounts of data through
your service provider's network. Contact your service provider for information about data transmission charges.

Delete e-mail messages

Select Menu > Messaging and a mailbox.
To delete the contents of an e-mail message from the device while still retaining it in the remote mailbox, select
Options > Delete > Phone only.
The device mirrors the e-mail headers in the remote mailbox. Although you delete the message content, the e-mail header stays in your device. If you want to remove the header as well, you must be connected to the server when deleting the message from your device and the remote mailbox. It there is no connection to the server, the header is deleted when you make a connection from your device to the remote mailbox again to update the status.
To delete an e-mail from the device and the remote mailbox, select Options > Delete > Phone and server.
To cancel deleting an e-mail that has been marked to be deleted from the device and server during the next
connection (
), select Options > Restore.

Disconnect from the mailbox

When you are online, to end the data connection to the remote mailbox, select Options > Disconnect.
© 2009 Nokia. All rights reserved. 59

View messages on a SIM card

Select Menu > Messaging and Options > SIM messages.
Before you can view SIM messages, you must copy them to a folder in your device.
1 Select Options > Mark/Unmark > Mark or Mark all to
mark messages.
2 Select Options > Copy. A list of folders opens. 3 To start copying, select a folder. To view the messages,
open the folder.

Cell broadcast messages

Select Menu > Messaging and Options > Operator msgs..
Cell broadcast (network service) allows you to receive messages on various topics, such as weather or traffic conditions, from your service provider. For available topics and relevant topic numbers, contact your service provider. This service may not be available for all regions.
Cell broadcast messages cannot be received in UMTS networks. A packet data connection may prevent cell broadcast reception.

Service commands

Select Menu > Messaging and Options > Service
commands.
With service commands (network service) you can enter and send service requests (also known as USSD commands), such
as activation commands for network services, to your service provider. This service may not be available for all regions.

Messaging settings

The settings may be preconfigured in your device, or you may receive them in a message. To enter settings manually, fill in all fields marked with Must be defined or an asterisk.
Some or all message centres or access points may be preset for your device by your service provider, and you may not be able to change, create, edit, or remove them.

Text message settings

Select Menu > Messaging and Options > Settings > Text
message.
Select from the following: Message centres — View a list of all text message centres
that have been defined. Message centre in use — Select which message centre to
use to deliver text messages. Character encoding — To use character conversion to
another encoding system when available, select Reduced
support.
Receive report — Select whether the network sends
delivery reports on your messages (network service). Message validity — Select how long the message centre
resends your message if the first attempt fails (network service). If the message cannot be sent within the validity period, the message is deleted from the message centre.
© 2009 Nokia. All rights reserved.60
Message sent as — To learn if your message centre is able
to convert text messages into these other formats, contact your service provider.
Preferred connection — Select the connection to use. Reply via same centre — Select whether you want the reply
message to be sent using the same text message centre number (network service).

Multimedia message settings

Select Menu > Messaging and Options > Settings >
Multimedia message.
Select from the following: Image size — Define the size of the image in a multimedia
message. MMS creation mode — If you select Guided, the device
informs you if you try to send a message that may not be supported by the recipient. If you select Restricted, the device prevents you from sending messages that may not be supported. To include content in your messages without notifications, select Free.
Access point in use — Select which access point is used as the preferred connection.
Multimedia retrieval — Select how you want to receive messages, if available. To receive messages automatically in your home network, select Auto in home netw.. Outside your home network, you receive a notification that there is a message to retrieve in the multimedia message centre. If you select Always automatic, your device automatically makes an active packet data connection to retrieve the message both in and outside your home network. Select Manual to
retrieve multimedia messages from the message centre manually, or Off to prevent receipt of any multimedia messages. Automatic retrieval may not be supported in all regions.
Allow anonymous msgs. — Reject messages from anonymous senders.
Receive adverts — Receive multimedia message advertisements (network service).
Receive reports — Display the status of sent messages in the log (network service).
Deny report sending — Prevent your device from sending delivery reports of received messages.
Message validity — Select for how long the message centre resends your message if the first attempt fails (network service). If the message cannot be sent within this time period, the message is deleted from the message centre.
The device requires network support to indicate that a sent message has been received or read. Depending on the network and other circumstances, this information may not always be reliable.
E-mail settings Manage mailboxes
Select Menu > Messaging and Options > Settings > E-
mail.
To select which mailbox you want to use to send and receive e-mail, select Mailbox in use and a mailbox.
© 2009 Nokia. All rights reserved. 61
To remove a mailbox and its messages from your device, select Mailboxes, tap the mailbox to be removed if it is not already highlighted, and select Options > Delete.
To create a new mailbox, select Mailboxes > Options >
New mailbox. The name you give to the new mailbox
replaces Mailbox in the Messaging main view. You can have up to six mailboxes.
Select Mailboxes and a mailbox to change the connection settings, user settings, retrieval settings, and automatic retrieval settings.
Connection settings
Select Menu > Messaging and Options > Settings > E-
mail > Mailboxes, a mailbox, and Connection settings.
To edit the settings for the e-mail you receive, select
Incoming e-mail, and from the following:
User name — Enter your user name given to you by your
service provider. Password — Enter your password. If you leave this field
blank, you are prompted for the password when you try to connect to your remote mailbox.
Incoming mail server — Enter the IP address or host name of the mail server that receives your e-mail.
Access point in use — Select an internet access point (IAP). Mailbox name — Enter a name for the mailbox.
Mailbox type — Defines the e-mail protocol that your
remote mailbox service provider recommends. The options are POP3 and IMAP4. This setting cannot be changed.
Security — Select the security option used to secure the connection to the remote mailbox.
Port — Define a port for the connection. APOP secure login (for POP3 only) — Use with the POP3
protocol to encrypt the sending of passwords to the remote e-mail server while connecting to the mailbox.
To edit the settings for the e-mail you send, select Outgoing
e-mail and from the following:
My e-mail address — Enter the e-mail address given to you
by your service provider. Outgoing mail server — Enter the IP address or host name
of the mail server that sends your e-mail. You may only be able to use the outgoing server of your service provider. For more information, contact your service provider.
The settings for user name, password, access point, security, and port are similar to the ones in incoming e-mail.
User settings
Select Menu > Messaging and Options > Settings > E-
mail > Mailboxes, a mailbox, and User settings.
Select from the following: My name — Enter your own name. Your name replaces your
e-mail address in the recipient’s device if the recipient’s device supports this function.
© 2009 Nokia. All rights reserved.62
Send message — Define how e-mail is sent from your
device. Select Immediately for the device to connect to the mailbox when you select Send message. If you select During
next conn., e-mail is sent when the connection to the remote
mailbox is available. Send copy to self — Select whether you want to send a copy
of the e-mail to your own mailbox. Include signature — Select whether you want to attach a
signature to your e-mails. New e-mail alerts — Select whether you want to receive
the new e-mail indications (a tone, a note, and a mail indicator) when new e-mail is received.
E-mail deletion — Select whether you want to delete e­mails from phone only, from phone and server, or to be asked each time separately.
Reply-to address — Define an e-mail address to which replies to e-mails sent from the mailbox in question are delivered.
Retrieval settings
Select Menu > Messaging and Options > Settings > E-
mail > Mailboxes, a mailbox, and Retrieval settings.
Select from the following: E-mail retrieval — Define which parts of the e-mail are
retrieved: Headers only, Size limit (POP3), or Msgs. &
attachments (POP3).
Retrieval amount — Define how many new e-mail
messages are retrieved to the mailbox.
IMAP4 folder path (for IMAP4 only) — Define the folder path for folders to be subscribed.
Folder subscriptions (for IMAP4 only) — Subscribe to other folders in the remote mailbox, and retrieve content from those folders.
Automatic retrieval settings
Select Menu > Messaging and Options > Settings > E-
mail > Mailboxes, a mailbox, and Automatic retrieval.
Select from the following: E-mail notifications — To automatically retrieve the
headers to your device when you receive new e-mail in your remote mailbox, select Auto-update or Only in home netw.
E-mail retrieval — To automatically retrieve the headers of new e-mail from your remote mailbox at defined times, select
Enabled or Only in home netw. Define when and how often
the e-mails are retrieved.
E-mail notifications and E-mail retrieval cannot be active
at the same time.
Setting the device to retrieve e-mail automatically may involve the transmission of large amounts of data through your service provider's network. Contact your service provider for information about data transmission charges.

Web service message settings

Select Menu > Messaging and Options > Settings >
Service message.
© 2009 Nokia. All rights reserved. 63
Select whether you want to receive service messages. To set the device to automatically activate the browser and start a network connection to retrieve content when you receive a service message, select Download messages >
Automatically.

Cell broadcast settings

Select Menu > Messaging and Options > Settings >
Operator message.
Check the available topics and related topic numbers with your service provider.
Select from the following: Reception — Select whether you want to receive cell
broadcast messages. Language — Select the languages in which you want to
receive messages: All, Selected, or Other. Topic detection — Select whether the device automatically
searches for new topic numbers, and saves the new numbers without a name to the topic list.

Other settings

Select Menu > Messaging and Options > Settings >
Other.
Select from the following: Save sent messages — Select whether you want to save
copies of the text, multimedia, or e-mail messages that you send to the Sent folder.
Number of saved msgs. — Define how many sent messages are saved to the sent folder at a time. When the limit is reached, the oldest message is deleted.
Memory in use — Select the memory where you want to save your messages.
Show messages in groups — Define whether you want to group the messages in Inbox, Sent, Drafts and My folders.
Show e-mails in groups — Define whether you want to group your e-mail messages.

Mail for Exchange

With Mail for Exchange, you can receive your work e-mail to your device. You can read and reply to your e-mails, view and edit compatible attachments, view calendar information, receive and reply to meeting requests, schedule meetings, and view, add, and edit contact information.
ActiveSync
Use of the Mail for Exchange is limited to over-the-air synchronisation of PIM information between the Nokia device and the authorised Microsoft Exchange server.
Mail for Exchange can be set up only if your company has Microsoft Exchange Server. In addition, your company's IT administrator must have activated Mail for Exchange for your account.
Before starting to set up Mail for Exchange, ensure that you have the following:
A corporate e-mail ID
Your office network user name
© 2009 Nokia. All rights reserved.64
Your office network password
Your network domain name (contact your company's IT
department)
Your Mail for Exchange server name (contact your company's IT department)
Depending on your company's Mail for Exchange server configuration, you may need to enter other information in addition to those listed. If you do not know the correct information, contact your company's IT department.
With Mail for Exchange, the use of the lock code may be mandatory. The default lock code of your device is 12345, but your company's IT administrator may have set a different one for you to use.
You can access and modify the Mail for Exchange profile and settings in the Messaging settings.

Nokia Messaging

The Nokia Messaging service automatically transfers e-mail from your existing e-mail address to your Nokia N97 mini. You can read, respond to, and organise your e-mails on the go. The Nokia Messaging service works with a number of internet e-mail providers that are often used for personal e­mail, such as Google e-mail services.
The Nokia Messaging service may be chargeable. For information on possible costs, contact your service provider or the Nokia Messaging service.
The Nokia Messaging service must be supported by your network and may not be available in all regions.
Install the Nokia Messaging application
1 Select Menu > Applications > Email and New. 2 Read the information on the display, and select Start. 3 Select Connect to allow your device to access the
network.
4 Enter your e-mail address and password.
The Nokia Messaging service can run on your device even if you have installed other e-mail applications, such as Mail for Exchange.
© 2009 Nokia. All rights reserved. 65

Connectivity

Your device offers several options to connect to the internet or to another compatible device or PC. For more information on other connectivity methods, see the extended user guide on the product support pages of the Nokia website.

Data connections and access points

Your device supports packet data connections (network service), such as GPRS in the GSM network. When you use your device in GSM and UMTS networks, multiple data connections can be active at the same time, and access points can share a data connection. In the UMTS network, data connections remain active during voice calls.
You can also use a WLAN data connection. Only one connection in one wireless LAN can be active at a time, but several applications can use the same internet access point.
To establish a data connection, an access point is required. You can define different kinds of access points, such as the following:
MMS access point to send and receive multimedia messages
Internet access point (IAP) to send and receive e-mail and connect to the internet
Check the type of access point you need with your service provider for the service you want to access. For availability and subscription to packet data connection services, contact your service provider.

Network settings

Select Menu > Settings and Connectivity > Network.
Your device can automatically switch between GSM and UMTS networks. GSM networks are indicated with networks are indicated with
An active high-speed downlink packet access (HSDPA) connection (network service) is indicated with
Select from the following:
Network mode — S ele ct w hic h netw ork to u se. If you sel ect
Dual mode, the device uses the GSM or UMTS network
automatically, according to the network parameters and the roaming agreements between the wireless service providers. For details and roaming costs, contact your network service provider. This option is shown only if supported by the wireless service provider.
A roaming agreement is an agreement between two or more service providers to enable the users of one service provider to use the services of other service providers.
Operator selection — Select Automatic to set the device to search for and select one of the available networks, or
Manual to manually select the network from a list. If the
connection to the manually selected network is lost, the device sounds an error tone and asks you to reselect a network. The selected network must have a roaming agreement with your home network.
.
. UMTS
.
© 2009 Nokia. All rights reserved.66
Cell info display — Set the device to indicate when it is used
in a cellular network based on microcellular network (MCN) technology and to activate cell info reception.

Wireless LAN

Your device can detect and connect to wireless local area networks (WLAN). Using a WLAN, you can connect your device to the internet and compatible devices that have WLAN support.

About WLAN

To use a wireless LAN (WLAN) connection, it must be available in the location, and your device must be connected to the WLAN. Some WLANs are protected, and you need an access key from the service provider to connect to them.
Note: In France, you are only allowed to use WLAN indoors.
Features that use WLAN, or that are allowed to run in the background while using other features, increase the demand on battery power and reduce the battery life.
Important: Always enable one of the available encryption methods to increase the security of your wireless LAN connection. Using encryption reduces the risk of unauthorised access to your data.

WLAN connections

To use a wireless LAN (WLAN) connection, you must create an internet access point (IAP) for WLAN. Use the access point for applications that need to connect to the internet.
A WLAN connection is established when you create a data connection using a WLAN internet access point. The active WLAN connection ends when you end the data connection.
You can use WLAN during a voice call or when packet data is active. You can only be connected to one WLAN access point device at a time, but several applications can use the same internet access point.
When the device is in the offline profile, you can still use WLAN (if available). Remember to comply with any applicable safety requirements when establishing and using a WLAN connection.
Tip: To check the unique media access control (MAC) address that identifies your device, open the dialler and enter
*#62209526#.

WLAN wizard

Select Menu > Settings and Connectivity > Wireless LAN.
The WLAN wizard helps you to connect to a wireless LAN (WLAN) and manage your WLAN connections.
If the search finds WLANs, to create an internet access point (IAP) for a connection and start the web browser using this IAP, select the connection and Start web browsing.
If you select a secured WLAN, you are asked to enter the relevant password. To connect to a hidden network, you must enter the correct network name (service set identifier, SSID).
© 2009 Nokia. All rights reserved. 67
If you already have the web browser running using the currently active WLAN connection, to return to the web browser, select Continue web browsing.
To end the active connection, select the connection and
Disconnect WLAN.

WLAN internet access points

Select Menu > Settings and Connectivity > Wireless
LAN > Options.
Select from the following:
Filter WLAN networks — Filter out wireless LANs (WLANs) from the list of found networks. The selected networks are not displayed the next time the application searches for WLANs.
Details — View the details of a network shown in the list. If you select an active connection, the connection details are displayed.

Operating modes

There are two operating modes in WLAN: infrastructure and ad hoc.
The infrastructure operating mode allows two kinds of communication: wireless devices are connected to each other through a WLAN access point device, or wireless devices are connected to a wired LAN through a WLAN access point device.
In the ad hoc operating mode, devices can send and receive data directly with each other.

Wireless LAN settings

Select Menu > Settings and Connectivity > Wireless
LAN > Options > Settings.
Select from the following:
Show WLAN availability — Select whether
is displayed
when a wireless LAN (WLAN) is available.
Tip: To access the WLAN Wizard application and view the available options, select the WLAN icon, and in the pop-up window, select the highlighted text next to the WLAN icon.
Scan for networks — If you set Show WLAN availability to Yes, you can select how often the device searches for available WLANs and updates the indicator.
Internet connectivity test — Select whether you want the device to test the internet capability of the selected WLAN automatically, to ask for permission every time, or to never perform the connectivity test. If you select Run
automatically or allow the test to be performed when the
device asks for it, and the connectivity test is performed successfully, the access point is saved to the internet destinations.
To view advanced settings, select Options > Advanced
settings. Changing the advanced settings for the WLAN is not
recommended.
© 2009 Nokia. All rights reserved.68
Access points Create a new access point
Select Menu > Settings and Connectivity > Destinations.
You may receive access point settings in a message from a service provider. Some or all access points may be preset for your device by your service provider, and you may not be ab le to change, create, edit, or remove them.
When you open one of the access point groups (
, , ,
), you can see the access point types:
indicates a protected access point indicates a packet data access point indicates a wireless LAN (WLAN) access point
Tip: You can create internet access points in a WLAN with the WLAN wizard.
To create a new access point, select
Access point.
The device asks to check for available connections. After the search, connections that are already available are shown and can be shared by a new access point.
If you skip this step, you are asked to select a connection method and to define the settings needed.
Data bearer — Select the data connection type.
Depending on the data connection you select, only certain setting fields are available. Fill in all fields marked with Must
be defined or with a red *. Other fields can be left empty,
unless your service provider has instructed otherwise.
To use a data connection, your service provider must support this feature, and if necessary, activate it for your SIM card.

Create access point groups

Select Menu > Settings and Connectivity > Destinations.
Some applications allow you to use access point groups for network connections.
To avoid selecting a single access point every time the device makes a network connection, you can create a group that contains various access points to connect to that network and define the order in which the access points are used.
For example, you can add wireless LAN (WLAN) and packet data access points to an internet access point group, and use the group for browsing the web. If you give WLAN the highest priority, the device connects to the internet through WLAN, if available, and through a packet data connection if not.
To edit the settings of an access point, open one of the access point groups, and select an access point. Follow the
To create a new access point group, select Options >
Manage > New destination.
instructions from your service provider.
Connection name — Enter a name for the connection.
© 2009 Nokia. All rights reserved. 69
To add access points to an access point group, select the group and Options > New access point. To copy an existing access point from another group, select the group, tap the relevant access point if it is not already highlighted, and select Options > Organise > Copy to other dest..
To change the priority of an access point within the group, select Options > Organise > Change priority.

Packet data access points

Select Menu > Settings and Connectivity >
Destinations > Access point, and follow the instructions on
the screen.
To edit a packet data access point, open one of the access point groups, and select an access point marked with
Follow the instructions from your service provider.
Select from the following: Access point name — You obtain the access point name
from your service provider. User name — The user name may be needed to make a data
connection, and is usually provided by your service provider. Prompt password — If you must enter the password every
time you log in to a server, or if you do not want to save your password in the device, select Yes.
Password — A password may be needed to make a data connection and is usually provided by your service provider.
Authentication — Select Secure to always send your password encrypted or Normal to send your password encrypted when possible.
Homepage — Depending on the access point you are setting up, enter the web address or the address of the multimedia message centre.
Use access point — Select After confirmation if you want the device to ask for confirmation before the connection using this access point is created, or Automatically if you want the device to connect to the destination using this access point automatically.
Select Options > Advanced settings and from the following:
Network type — Select the internet protocol type to transfer data to and from your device. The other settings depend on
.
the selected network type. Phone IP address (for IPv4 only) — Enter the IP address of
your device. DNS addresses — Enter the IP addresses of the primary and
secondary DNS servers, if required by your service provider. To obtain these addresses, contact your internet service provider.
Proxy server address — Enter the address of the proxy server.
Proxy port number — Enter the port number of the proxy server.

WLAN internet access points

Select Menu > Settings and Connectivity >
Destinations > Access point, and follow the instructions.
© 2009 Nokia. All rights reserved.70
To edit a wireless LAN (WLAN) access point, open one of the access point groups, and select an access point marked with
.
Follow the instructions from your WLAN service provider.
Select from the following:
WLAN network name — Select Enter manually or Search
for networks. If you select an existing network, WLAN
network mode and WLAN security mode are determined by the settings of its access point device.
Network status — Define whether the network name is displayed.
WLAN network mode — Select Ad-hoc to create an ad hoc network and to allow devices to send and receive data directly; a WLAN access point device is not needed. In an ad hoc network, all devices must use the same WLAN network name.
WLAN security mode — Select the encryption used: WEP,
802.1x, orWPA/WPA2 (802.1x and WPA/WPA2 are not
available for ad hoc networks). If you select Open network, no encryption is used. The WEP, 802.1x and WPA functions can be used only if the network supports them.
Homepage — Enter the web address of the starting page. Use access point — Set the device to create a connection
using this access point automatically or after confirmation.
The available options may vary.

Active data connections

Select Menu > Settings and Connectivity > Connection
mgr..
In the active data connections view, you can see the open data connections:
data calls packet data connections wireless LAN (WLAN) connections
Note: The actual invoice for calls and services from your service provider may vary, depending on network features, rounding off for billing, taxes, and so forth.
To end a connection, select Options > Disconnect.
To end all open connections, select Options > Disconnect
all.
To view the details of a connection, select Options >
Details.

Synchronisation

Select Menu > Settings and Connectivity > Data
transfer > Sync.
The Synchronisation application enables you to synchronise your notes, calendar entries, text and multimedia messages, browser bookmarks, or contacts with various compatible applications on a compatible computer or on the internet.
© 2009 Nokia. All rights reserved. 71
You may receive synchronisation settings in a special message from your service provider.
A synchronisation profile contains the necessary settings for synchronisation.
When you open the application, the default or previously used synchronisation profile is displayed. To modify the profile, tap a synchronisation item to include it in the profile or to leave it out.
To manage synchronisation profiles, select Options and the desired option.
To synchronise data, select Options > Synchronise.
To cancel synchronisation before it finishes, select Cancel.
Bluetooth connectivity About Bluetooth connectivity
With Bluetooth connectivity, you can make a wireless connection to other compatible devices, such as mobile phones, computers, headsets, and car kits.
You can use the connection to send images, video clips, music and sound clips, and notes, transfer files from your compatible PC, and print images with a compatible printer.
Since devices with Bluetooth wireless technology communicate using radio waves, they do not need to be in direct line-of-sight. However, they must be within 10 metres
(33 feet) of each other, although the connection may be subject to interference from obstructions such as walls or from other electronic devices.
This device is compliant with Bluetooth Specification 2.0 + EDR supporting the following profiles: Dial-Up Networking (DUN), Object Push Profile (OPP), File Transfer Profile (FTP), Hands Free Profile (HFP), Headset Profile (HSP), Basic Imaging Profile (BIP), Remote SIM Access Profile (SimAP), Device Identification Profile (DI), Phonebook Access Profile (PBAP), Generic Audio/Video Distribution Profile (GAVDP), Audio/ Video Remote Control Profile (AVRCP), Advanced Audio Distribution Profile (A2DP). To ensure interoperability between other devices supporting Bluetooth technology, use Nokia approved accessories for this model. Check with the manufacturers of other devices to determine their compatibility with this device.
Features using Bluetooth technology increase the demand on battery power and reduce the battery life.
When the device is locked, only connections to authorised devices are possible.

Settings

Select Menu > Settings and Connectivity > Bluetooth.
When you open the application for the first time, you are asked to define a name for your device. You can change the name later.
Select from the following:
Bluetooth — Turn Bluetooth connectivity on or off.
© 2009 Nokia. All rights reserved.72
My phone's visibility — To allow your device to be found
by other devices with Bluetooth wireless technology, select
Shown to all. To set a time period after which the visibility
is set from shown to hidden, select Set visibility period. To hide your device from other devices, select Hidden.
My phone's name — Edit the name shown to other devices with Bluetooth wireless technology.
Remote SIM mode — Enable or disable another device, such as a compatible car kit accessory, to use the SIM card in your device to connect to the network.

Security tips

Select Menu > Settings and Connectivity > Bluetooth.
When you are not using Bluetooth connectivity, to control who can find your device and connect to it, select
Bluetooth > Off or My phone's visibility > Hidden.
Deactivating Bluetooth connectivity does not affect other functions of the device.
Do not pair with or accept connection requests from an unknown device. This helps to protect your device from harmful content.

Send data using Bluetooth connectivity

Several Bluetooth connections can be active at a time. For example, if you are connected to a compatible headset, you can also transfer files to another compatible device at the same time.
1 Open the application where the item you want to send is
stored.
2 Tap an item, and select Options > Send > Via
Bluetooth.
Devices with Bluetooth wireless technology that are within range are displayed. Device icons are as follows:
computer phone audio or video device other device
To interrupt the search, select Stop.
3 Select the device with which you want to connect. 4 If the other device requires pairing before data can be
transmitted, a tone sounds, and you are asked to enter a passcode. The same passcode must be entered in both devices.
When the connection is established, Sending data is displayed.
Tip: When searching for devices, some devices may show only the unique address (device address). To find the unique address of your device, enter *#2820#.

Pair devices

Select Menu > Settings and Connectivity > Bluetooth.
To pair with compatible devices and view your paired devices, open the Paired devices tab.
© 2009 Nokia. All rights reserved. 73
Before pairing, create your own pa ss co de (1 to 16 dig it s) , and agree with the owner of the other device to use the same code. Devices that do not have a user interface have a factory­set passcode. The passcode is used only once.
1To pair with a device, select Options > New paired
device. Devices that are within range are displayed.
2 Select the device, and enter the passcode. The same
passcode must be entered on the other device, as well.
3 Some audio accessories connect automatically to your
device after pairing. Otherwise, to connect to an accessory, select Options > Connect to audio device.
Paired devices are indicated by
in the device search.
To set a device as authorised or unauthorised, select from the following:
Set as authorised — Connections between your device and the authorised device can be made without your knowledge. You will not be asked for authorisation or acceptance separately. Use this status only for your own devices, such as your compatible headset or PC, or devices that belong to
someone you trust.
indicates authorised devices in the
paired devices view. Set as unauthorised — Connection requests from this
device must be accepted separately every time.
To cancel a pairing with a device, select Options > Delete.
To cancel all pairings, select Options > Delete all.

Receive data using Bluetooth connectivity

When you receive data through Bluetooth connectivity, a tone sounds, and you are asked if you want to accept the
message. If you accept,
is displayed, and the item is placed in the Inbox folder in Messaging. Messages received through Bluetooth connectivity are indicated by
.

Block devices

Select Menu > Settings and Connectivity > Bluetooth.
To block a device from establishing a Bluetooth connection to your device, open the Paired devices tab.
Tap a device you want to bloc k, if it is not already highlighted, and select Options > Block.
To unblock a device, open the Blocked devices tab, tap a device, if it is not already highlighted, and select Options >
Delete.
To unblock all blocked devices, select Options > Delete all.
If you reject a pairing request from another device, you are asked if you want to block all future connection requests from this device. If you accept the query, the remote device is added to the list of blocked devices.

Remote SIM mode

Select Menu > Settings and Connectivity > Bluetooth.
© 2009 Nokia. All rights reserved.74
Before the remote SIM mode can be activated, the two devices must be paired and the pairing initiated from the other device. When pairing, use a 16-digit passcode, and set the other device as authorised.
To use the remote SIM mode with a compatible car kit accessory, activate Bluetooth connectivity, and enable the use of the remote SIM mode with your device.
Activate the remote SIM mode from the other device.
When the remote SIM mode is on in your device, Remote SIM
mode is displayed in the home screen. The connection to the
wireless network is turned off, as indicated by
in the signal strength indicator area, and you cannot use SIM card services or features requiring cellular network coverage.
When the wireless device is in the remote SIM mode, you can only use a compatible connected accessory, such as a car kit, to make or receive calls. Your wireless device will not make any calls while in this mode, except to the emergency numbers programmed into your device. To make calls from your device, you must leave the remote SIM mode. If the device is locked, enter the lock code to unlock it.
To leave the remote SIM mode, press the power key, and select Exit remote SIM mode.
USB
Select Menu > Settings and Connectivity > USB.
To have the device ask the purpose of the connection each time a compatible data cable is connected, select Ask on
connection > Yes.
If the Ask on connection option is turned off or you want to change the mode during an active connection, select USB
connection mode and from the following:
PC Suite — Use Nokia PC applications such as Nokia Ovi Suite,
and Nokia Software Updater. Mass storage — Transfer data between your device and a
compatible PC.
Image transfer — Print images with a compatible printer. Media transfer — Synchronise music with Nokia Music or
Windows Media Player.

PC connections

You can use your mobile device with a variety of compatible PC connectivity and data communications applications. With Nokia Ovi Suite you can, for example, transfer files and images between your device and a compatible computer.
© 2009 Nokia. All rights reserved. 75
To use Ovi Suite with USB connection mode, select PC Suite
mode.
For more information about Ovi Suite, see the support area at www.ovi.com.

Administrative settings

Select Menu > Settings and Connectivity > Admin.
settings.
To set the online time for the data call connection, select Data
call. The data call settings affect all access points that use a
GSM data call.

Packet data settings

Select Menu > Settings and Connectivity > Admin.
settings > Packet data.
The packet data settings affect all access points using a packet data connection.
Select from the following:
Packet data connection — If you select When available and you are in a network that supports packet data, the device registers to the packet data network. Starting an active packet data connection (for example, to send and receive e-mail) is quicker than if the device establishes a packet data connection when needed. If there is no packet data coverage, the device periodically tries to establish a packet data connection. If you select When needed, the device uses a packet data connection only if you start an application or action that needs it.
Access point — The access point name is needed to use your device as a packet data modem to a compatible computer.
High speed packet access — Enable or disable the use of HSDPA (network service) in UMTS networks.

SIP settings

Select Menu > Settings and Connectivity > Admin.
settings > SIP settings.
Session Initiation Protocol (SIP) settings are needed for certain network services using SIP. You may receive the settings in a special text message from your service provider. You can view, delete, or create these setting profiles in SIP settings.

Access point name control

Select Menu > Settings and Connectivity > Admin.
settings > APN control.
With the access point name control service, you can restrict packet data connections and allow your device to use only certain packet data access points.
This setting is only available if your SIM card supports the access point control service.
To tur n th e cont rol ser vic e on or off , or to c han ge the all owe d access points, select Options and the corresponding option. To change the options, you need your PIN2 code. Contact your service provider for the code.
© 2009 Nokia. All rights reserved.76

Internet

With the Web browser, you can view hypertext markup language (HTML) web pages on the internet as originally designed. You can also browse web pages that are designed specifically for mobile devices, and use extensible hypertext markup language (XHTML), or the wireless markup language (WML).
To browse the web, you need to have an internet access point configured in your device. Using the web browser requires network support.

Browse the web

Select Menu > Web.
To browse the web, select toolbar, and enter a web address.
By default, the browser is in full screen mode. To exit full screen mode, select the arrow icon in the bottom right corner.
Some web pages may contain material, such as graphics or video clips, that requires a large amount of memory to view. If your device runs out of memory while loading such a web page, insert a memory card. Otherwise, the video clips are not displayed.
To browse web pages with graphics disabled, to save memory and increase the page loading speed, select
Options > Settings > Page > Load content > Text only.
Go to web address from the
To refresh the content of the web page, select Options >
Web page options > Reload.
To save the current web page as a bookmark, select
Options > Web page options > Save as bookmark.
To view snapshots of the web pages you have visited during the current browsing session, select Back (available if
History list is activated in the browser settings and the
current web page is not the first web page you visit).
To prevent or allow the automatic opening of multiple windows, select Options > Web page options > Block
pop-ups or Allow pop-ups.
To zoom in on a web page, double-tap the display.
Tip: To send the browser to the background without exiting the application or connection, press the end key once.

Browser toolbar

The browser toolbar helps you select frequently used functions of the browser.
To open the toolbar when browsing, select the arrow in the bottom right corner.
From the toolbar, select from the following:
Expand toolbar — Expand the toolbar to access more
toolbar functions.
Go to web address — Enter a web address.
© 2009 Nokia. All rights reserved. 77
Show zoom — Zoom in or out on the web page.
To use the expanded toolbar, select
Expand toolbar and
from the following:
Go to feeds — View your current feed subscriptions.
Send URL — Send the web address of the current page
to another device.
Switch win. — Switch between open browser windows.
Subsc. feeds — View a list of available web feeds on the
current web page, and subscribe to a web feed.
Settings — Edit the settings.
Save bkmrk. — Save the current web page as a
bookmark.
Reload — Refresh the web page.
Overview — View an overview of the current web page.
Homepage — Go to the homepage (if defined in
settings).
Bookmarks — Open the bookmarks view.
Find keywd. — Search on the current web page.

Navigate pages

When you are browsing a web page that contains a large amount of information, you can use Page overview to view what kind of information the web page contains.
To see an overview of the current web page, open the toolbar, and select
> .

Web feeds and blogs

Select Menu > Web.
Web feeds are XML files on web pages that are used to share, fo r exa mple , the late st ne ws he adli nes o r blo gs. I t is c ommo n to find web feeds on web, blog, and wiki pages.
The browser application automatically detects if a web page contains web feeds.
If web feeds are available, to subscribe to a web feed, select
Options > Subscribe to web feeds.
To update a web feed, in the Web feeds view, select a feed and Options > Web feed options > Refresh.
To define whether the web feeds are updated automatically, in the Web feeds view, select Options > Edit > Edit. This option is not available if one or more feeds are marked.

Content search

Select Menu > Web.
To search for text within the current web page, select
Options > Find keyword.
© 2009 Nokia. All rights reserved.78
To go to the next match, from the toolbar, select Find
next.
To go to the previous match, from the toolbar, select Find
previous.

Bookmarks

Select Menu > Web.
Select Options > Go to > Bookmarks. You can select web addresses from a list or from a collection of bookmarks in the Recently visited pages folder.
The toolbar helps you select frequently used functions of the browser.
From the toolbar, select from the following:
Add bookmark — Add a new bookmark.
Go to web address — Enter a new web address.
Delete — Delete a bookmark.
To go to a new web page, select Options > Go to > New
web page.
To send and add bookmarks, or to set a bookmark as the homepage, select Options > Bookmark options.
To edit, move, or delete bookmarks, select Options >
Bookmark manager.

Empty the cache

The information or services you have accessed are stored in the cache memory of the device.
A cache is a memory location that is used to store data temporarily. If you have tried to access or have accessed confidential information requiring passwords, empty the cache after each use.
To empty the cache, select Options > Clear privacy data >
Cache.

End the connection

To end the connection and close the browser, select
Options > Exit.
To delete the information the network server collects about your visits to various web pages, select Options > Clear
privacy data > Cookies.

Connection security

If the security indicator (
) is displayed during a connection, the data transmission between the device and the internet gateway or server is encrypted.
The security icon does not indicate that the data transmission between the gateway and the content server (where the data is stored) is secure. The service provider secures the data transmission between the gateway and the content server.
© 2009 Nokia. All rights reserved. 79
Security certificates may be required for some services, such as banking services. You are notified if the identity of the server is not authentic or if you do not have the correct security certificate in your device. For more information, contact your service provider.
Important: Even if the use of certificates makes the risks involved in remote connections and software installation considerably smaller, they must be used correctly in order to benefit from increased security. The existence of a certificate does not offer any protection by itself; the certificate manager must contain correct, authentic, or trusted certificates for increased security to be available. Certificates have a restricted lifetime. If "Expired certificate" or "Certificate not valid yet" is shown, even if the certificate should be valid, check that the current date and time in your device are correct.
Before changing any certificate settings, you must make sure that you really trust the owner of the certificate and that the certificate really belongs to the listed owner.

Web settings

Select Menu > Web and Options > Settings and from the following:
General settings Access point — Change the default access point. Some or all
access points may be preset for your device by your service provider. You may not be able to change, create, edit, or remove them.
Homepage — Define the homepage.
History list — If you select On, while browsing, to see a list
of the pages you have visited during the current session, select Back.
Web address suffix — Enter a web address suffix that the device uses by default when you enter a web address in the Go to field (for example, .com or .org).
Security warnings — Hide or show security notifications. Java/ECMA script — Enable or disable the use of scripts. Java/ECMA script errors — Select whether you want to
receive script notifications. Open while downloading — Select whether you want to
be able to open a file while it is being downloaded.
Page settings Load content — Select whether you want to load images
and other objects while browsing. If you select Text only, to load images or objects later during browsing, select
Options > Display options > Load images.
Default encoding — If text characters are not shown
correctly, you can select another encoding according to the language for the current page.
Block pop-ups — Allow or block automatic opening of different pop-ups while browsing.
Automatic reload — Select whether you want the web pages to be refreshed automatically while browsing.
Font size — Define the font size that is used for web pages.
Privacy settings Recently visited pages — Enable or disable automatic
bookmark collecting. If you want to continue saving the
© 2009 Nokia. All rights reserved.80
addresses of the visited web pages into the Recently visited
pages folder, but hide the folder from the bookmarks view,
select Hide folder. Form data saving — Select whether you want the password
data or data you enter on different forms on a web page to be saved and used the next time you open the page.
Cookies — Enable or disable the receiving and sending of cookies.
Web feed settings Acc. point for auto-update — Select the desired access
point for updating. This option is only available when
Automatic updates is active.
Update when roaming — Select whether you want the web
feeds to be updated automatically when roaming.
© 2009 Nokia. All rights reserved. 81

Positioning (GPS)

You can use applications such as GPS data to calculate your location or measure distances. These applications require a GPS connection.

About GPS

The coordinates in the GPS are expressed using the international WGS-84 coordinate system. The availability of the coordinates may vary by region.
The Global Positioning System (GPS) is operated by the government of the United States, which is solely responsible for its accuracy and maintenance. The accuracy of location data can be affected by adjustments to GPS satellites made by the United States government and is subject to change with the United States Department of Defense civil GPS policy and the Federal Radionavigation Plan. Accuracy can also be affected by poor satellite geometry. Availability and quality of GPS signals may be affected by your location, buildings, natural obstacles, and weather conditions. GPS signals may not be available inside buildings or underground and may be impaired by materials such as concrete and metal.
GPS should not be used for precise location measurement, and you should never rely solely on location data from the GPS receiver and cellular radio networks for positioning or navigation.
The trip meter has limited accuracy, and rounding errors may occur. Accuracy can also be affected by availability and quality of GPS signals.
Different positioning methods can be enabled or disabled in positioning settings.

Assisted GPS (A-GPS)

Your device also supports Assisted GPS (A-GPS).
A-GPS is a network service.
Assisted GPS (A-GPS) is used to retrieve assistance data over a packet data connection, which assists in calculating the coordinates of your current location when your device is receiving signals from satellites.
When you activate A-GPS, your device receives useful satellite information from an assistance data server over the cellular network. With the help of assisted data, your device can obtain the GPS position faster.
Your device is preconfigured to use the Nokia A-GPS service, if no service provider-specific A-GPS settings are available. The assistance data is retrieved from the Nokia A-GPS service server only when needed.
You must have an internet access point defined in the device to retrieve assistance data from the Nokia A-GPS service over a packet data connection. To define an access point for A-GPS, select Menu > Applications > Location and Positioning >
Positioning server > Access point. A wireless LAN (WLAN)
access point cannot be used for this service. Only a packet data internet access point can be used. Your device asks for the internet access point when GPS is used for the first time.
© 2009 Nokia. All rights reserved.82

Hold your device correctly

When using the GPS receiver, ensure you do not cover the antenna with your hand.
Establishing a GPS connection may take from a couple of seconds to several minutes. Establishing a GPS connection in a vehicle may take longer.
The GPS receiver draws its power from the device battery. Using the GPS receiver may drain the battery faster.
Tips on creating a GPS connection Check satellite signal status
To check how many satellites your device has found, and whether your device is receiving satellite signals, select
Menu > Applications > Location and GPS data > Options > Satellite status.
If your device has found satellites, a bar for each satellite is shown in the satellite info view. The longer the bar, the stronger the satellite signal. When your device has received enough data from the satellite signal to calculate your location, the bar colour changes.
To view the positions of found satellites, select Chg. view.
Initially your device must receive signals from at least four satellites to be able to calculate your location. When the initial calculation has been made, it may be possible to continue calculating your location with three satellites. However, the accuracy is generally better when more satellites are found.
If no satellite signal can be found, consider the following:
If you are indoors, go outdoors to receive a better signal.
If you are outdoors, move to a more open space.
Ensure that your hand does not cover the GPS antenna of
your device.
If the weather conditions are bad, the signal strength
may be affected.
Some vehicles have tinted (athermic) windows, which
may block the satellite signals.
© 2009 Nokia. All rights reserved. 83

Position requests

You may receive a request from a network service to receive your position information. Service providers may offer information about local topics, such as weather or traffic conditions, based on the location of your device.
When you receive a position request, the service that is making the request is displayed. Select Accept to allow your position information to be sent or Reject to deny the request.

Landmarks

Select Menu > Applications > Location and Landmarks.
With Landmarks, you can save the position information of specific locations in your device. You can sort the saved locations into different categories, such as business, and add other information to them, such as addresses. You can use your saved landmarks in compatible applications, such as GPS data.
GPS coordinates are expressed using the international WGS-84 coordinate system.
Select Options and from the following:
New landmark — Create a new landmark. To make a positioning request for your current location, select Current
position. To enter the position information manually, select Enter manually.
Edit — Edit or add information to a saved landmark (for
example, a street address).
Add to category — Add a landmark to a category in Landmarks. Select each category to which you want to add the landmark.
Send — Send one or several landmarks to a compatible device. Your received landmarks are placed in the Inbox folder in Messaging.
You can sort your landmarks into preset categories, and create new categories. To edit and create new landmark categories, open the categories tab, and select Options >
Edit categories.

GPS data

Select Menu > Applications > Location and GPS data.
GPS data is designed to provide route guidance information to a selected destination, position information about your current location, and travelling information, such as the approximate distance to the destination and the approximate duration of travel.
The coordinates in the GPS are expressed using the international WGS-84 coordinate system.
To use GPS data, the GPS receiver of your device must initially receive position information from at least four satellites to calculate your location. When the initial calculation has been made, it may be possible to continue calculating your location with three satellites. However, the accuracy is generally better when more satellites are found.
© 2009 Nokia. All rights reserved.84

Route guidance

Select Menu > Applications > Location and GPS data >
Navigation.
Start the route guidance outdoors. If started indoors, the GPS receiver may not receive the necessary information from the satellites.
Route guidance is designed to show the straightest route and the shortest distance to the destination, measured in a straight line. Any obstacles on the route, such as buildings and natural obstacles, are ignored. Differences in altitude are not taken into account when calculating the distance. Route guidance is active only when you move.
To set your trip destination, select Options > Set
destination and a landmark as the destination, or enter the
latitude and longitude coordinates.
To clear the destination set for your trip, select Stop
navigation.

Retrieve position information

Select Menu > Applications > Location and GPS data >
Position.
In the position view, you can view the position information of your current location. An estimate of the accuracy of the location is displayed.
To save your current location as a landmark, select
Options > Save position. Landmarks are saved locations
with more information, and they can be used in other
compatible applications and transferred between compatible devices.

Trip meter

Select Menu > Applications > Location and GPS data >
Trip distance.
The trip meter has limited accuracy, and rounding errors may occur. Accuracy can also be affected by availability and quality of GPS signals.
To turn trip distance calculation on or off, select Options >
Start or Stop. The calculated values remain on the display.
Use this feature outdoors to receive a better GPS signal.
To set the trip distance and time and average and maximum speeds to zero, and to start a new calculation, select
Options > Reset. To set the odometer and total time to zero,
select Restart.

Positioning settings

Select Menu > Applications > Location and Positioning.
Positioning methods
Select from the following: Integrated GPS — Use the integrated GPS receiver of your
device. Assisted GPS — Use Assisted GPS (A-GPS) to receive
assistance data from an assistance data server.
© 2009 Nokia. All rights reserved. 85
Bluetooth GPS — Use a compatible external GPS receiver
with Bluetooth connectivity. Network based — Use information from the cellular
network (network service).
Positioning server
To define an access point and positioning server for network­assisted positioning methods, such as assisted GPS or network-based positioning, select Positioning server.
The positioning server may be preset by your service provider, and you may not be able to edit the settings.
Notation settings
To select which measurement system you want to use for speeds and distances, select Measurement system >
Metric or Imperial.
To define in which format the coordinate information is displayed in your device, select Coordinate format and the desired format.
© 2009 Nokia. All rights reserved.86

Maps

About Maps

Select Menu > Maps.
With Maps, you can see your current location on the map, browse maps of different cities and countries, search for places, plan routes from one location to another, save locations, and send them to compatible devices. You can also purchase traffic information and navigation services, if available for your country or region.
When you use Maps for the first time, you may need to select an internet access point for downloading maps.
When you have an active data connection and browse the map on the display, a new map is automatically downloaded, if you browse to an area not covered by the maps that have already been downloaded. You can also use the Nokia Map Loader PC software to download maps. To install Nokia Map Loader to a compatible PC, visit www.nokia.com/maps (in English).
Tip: To avoid data transfer costs, you can also use Maps without an internet connection, and browse the maps that are saved in your device or memory card, if available in your device.
Note: Downloading content such as maps, satellite images, voice files, guides or traffic information may involve transmission of large amounts of data (network service).
Almost all digital cartography is inaccurate and incomplete to some extent. Never rely solely on the cartography that you download for use in this device.

About GPS

The Global Positioning System (GPS) is operated by the government of the United States, which is solely responsible for its accuracy and maintenance. The accuracy of location data can be affected by adjustments to GPS satellites made by the United States government and is subject to change with the United States Department of Defense civil GPS policy and the Federal Radionavigation Plan. Accuracy can also be affected by poor satellite geometry. Availability and quality of GPS signals may be affected by your location, buildings, natural obstacles, and weather conditions. GPS signals may not be available inside buildings or underground and may be impaired by materials such as concrete and metal.
GPS should not be used for precise location measurement, and you should never rely solely on location data from the GPS receiver and cellular radio networks for positioning or navigation.
The trip meter has limited accuracy, and rounding errors may occur. Accuracy can also be affected by availability and quality of GPS signals.
Assisted GPS (A-GPS) is used to retrieve assistance data over a packet data connection, which assists in calculating your current location when your device is receiving signals from satellites.
A-GPS is a network service.
© 2009 Nokia. All rights reserved. 87

Move on a map

When the GPS connection is active,
shows your current
location on the map.
To view your current or last known location, select
Options > My position.
To move on the map, drag the map. The map is oriented towards north by default.
When you have an active data connection and browse the map on the display, a new map is automatically downloaded if you scroll to an area not covered by the maps that have already been downloaded. The maps are automatically saved in the device memory or on a compatible memory card, if inserted.
To zoom in and out on the map, tap + and -.
To change the map type, select Options > Map mode.

Display indicators

The GPS indicator
shows the availability of the satellite signals. One bar is one satellite. When the device tries to find satellite signals, the bar is yellow. When the device receives enough data from the satellites for GPS to calculate your location, the bar turns green. The more green bars, the more reliable the location calculation.
Initially, your device must receive signals from at least four satellites to calculate your location. After the initial calculation, signals from three satellites may be enough.
The data transfer indicator
shows the internet connection used, and the amount of data transferred since the application started.

Find locations

To search for locations, tap the information area above the map, and select Explore. Start entering the location name in the search field. The device suggests matching nearby locations. Select the location from the list, or enter the location name in the search field, and select Search.
1 To find a specific address, select the search icon and
Address.
2 Start entering the required information. The fields
marked with an asterisk (*) are mandatory.
3 Select the address from the list of suggested matches.
To find an address saved in the contacts list, select the search icon and Address > Options > Select from Contacts.
To search for locations by their coordinates, select the search icon and Places.
To search for locations in specific categories, such as restaurants or shopping, tap the information area above the
© 2009 Nokia. All rights reserved.88
map, and select Explore. Select a category, and enter the search terms in the search field.
Save the route
Select Show route > Options > Save route.

Plan routes

You can create routes and view them on the map.
Select Menu > Maps.
Create a route
1 Tap your starting point on the map. To add the
destination and more locations to the route, select Add
new route point. If you want to use your current
position as the starting point, add the destination to the route.
2 Tap the information area above the map, and select Add
to route.
3 Select Add new route point, and add the destination
and more locations to the route.
Change the order of the locations in the route
Tap a location, and select Move. Tap the place where you want to move the location, and select Select.
Show the route on the map
Select Show route.
Navigate to the destination
Select Show route > Options > Start driving or Start
walking. To be able to navigate, you need to purchase a
licence.
© 2009 Nokia. All rights reserved. 89

Save and send locations

You can save your favourite locations to your device and send them to compatible devices.
Select Menu > Maps.
Save a location to your device
Tap the location, tap the information area above the map, and select Save.
View your saved locations
In the main view, select Options > Favourites.
Send a location to a compatible device
Tap the location, and select Send.

View your saved items

You can sort the locations and routes you have saved to your device, and view them on the map. You can also create collections of your favourite places, such as restaurants and museums.
Select Menu > Maps.
View the saved locations and routes
Select Options > Favourites.
Sort the saved locations
Select Places > Options > Sort.
View the location on the map
Tap the location, and select Show on map.
Add the location to a route
Tap the location, and select Add to route.
Create a collection
Select Options > New collection.

Synchronise your favourite locations with Ovi Maps

The Ovi website contains the internet services that Nokia provides. The Ovi Maps section contains services related to Maps. You can synchronise your saved locations, collections, and routes with Ovi Maps, if you have a Nokia account in Ovi. To create the account, visit www.ovi.com.
Select Menu > Maps.
Synchronise saved items with Ovi Maps
Select Options > Favourites > Synchronise with Ovi.
Set the device to synchronise items automatically
Select Options > Tools > Settings > Synchronisation >
Synchronise with Ovi > At start-up and shut-d.. The
device starts the synchronisation when you open and close the Maps application.
Synchronising may involve the transmission of large amounts of data through your service provider’s network. Contact your service provider for information about data transmission charges.

Your search history

In the history view, you can quickly return to the locations you have recently searched for.
Select Menu > Maps.
View your search history
Select Options > History.
View the selected location on the map
Tap the location, and select Show on map.
Send the location to a compatible device
Tap the location, and select Send.
Add the location to a route
Tap the location, and select Add to route.

About licences

There are additional services available for Maps. To use a service, you need to buy a licence. Most services are region­specific.
When you buy a licence, some landmarks are shown in 3D on the map.
Select Menu > Maps.
© 2009 Nokia. All rights reserved.90
Purchase a service for your current location
Select Options > Shop & licences > Shop.
When you purchase a service, you have two options:
Purchase a licence with a fixed end date.
Subscribe to a licence that is automatically renewed
every 30 days until you cancel it. To cancel the licence, select Options > Shop & licences > My licences, go to the licence, and select Options > Cancel subscription.
You can pay for the service through a credit card or in your phone bill, if supported by your service provider. During the purchase, you can select to save your credit card number and expiry date to your device. To remove the credit card information from your device, select Options > Clear
personal data.
Some devices may have a City Explorer licence preinstalled.
View your valid licences
Select Options > Shop & licences > My licences.
View the services available in other regions
Select Options > Shop & licences > Options > Shops for
other regions.

Walk to your destination

When you purchase a licence for pedestrian navigation, you can create routes that include pedestrian zones and parks, prioritise walkways and smaller roads, and omit motorways.
With the licence, you also get the enhanced search service to your device, if available for your country or region. The enhanced search service enables you to find local events and travelling-related information when you perform searches.
Select Menu > Maps.
Purchase a licence for pedestrian navigation
Select Options > Shop & licences > Options > Shops for
other regions > All regions > City Explorer. You can pay
for the licence through a credit card or in your phone bill, if supported by your service provider.
Start navigating
Tap a location, tap the information area above the map, and select Walk to.
The distance between the start and end points of a walking route is limited to a maximum of 50 kilometres (31 miles) and the travelling speed to a maximum of 30 kph (18 mph). If the speed limit is exceeded, navigation stops and is resumed once the speed is back within limits.
If the destination is on off-road terrain, the route is displayed as a straight line to indicate the walking direction.
There is no voice guidance available for pedestrian navigation, but the device guides you with a tone or vibration approximately 20 metres (22 yards) before you need to turn or make another manoeuvre. The guiding method depends on the settings of the profile currently active in your device.
© 2009 Nokia. All rights reserved. 91
See an overview of the route
Select Options > Route overview.
Stop navigating
Select Stop.

Drive to your destination

You can purchase a licence for navigating on foot or by car. The licence is region-specific and can be used only in the selected area.
To help navigating and driving, you also have lane assistance and speed limit warning services in your device, if available for your country or region.
Select Menu > Maps.
Purchase a licence
Select Options > Shop & licences > Shop > Drive %s.
Start navigating by car
Select a location, tap the information area above the map, and select Drive to.
When you use car navigation for the first time, you are asked to select the language of the voice guidance and download the related voice guidance files.
Note: Downloading content such as maps, satellite images, voice files, guides or traffic information may involve transmission of large amounts of data (network service).
To switch between different views during the navigation, tap the information area above the map, and select 2D view, 3D
view, Arrow view, or Route overview.
Find an alternative route
Select Options > Diff. route.
Repeat the voice guidance
Select Options > Repeat.
Adjust the volume of the voice guidance
Select Options > Volume.
View the trip distance and duration
Select Options > Dashboard.
Stop navigating
Select Stop.
Your first consideration while using Maps should be road safety. The service should not be used by the driver of a motor vehicle while driving.

Traffic and safety

The real-time traffic information service provides information about traffic events that may affect your travel. You can purchase and download the traffic information service to your device, if available in your country or region.
When you purchase the licence, the location of speed cameras is shown on your route during navigation and tracking, if this feature is enabled and available for your country or region.
© 2009 Nokia. All rights reserved.92
Some jurisdictions prohibit or regulate the use of speed camera location data. Nokia is not responsible for the accuracy, or the consequences of use of speed camera location data. You also get the notification service for speed cameras, if available for your country or region.
Note: Downloading content such as maps, satellite images, voice files, guides or traffic information may involve transmission of large amounts of data (network service).
Content such as satellite images, guides, weather and traffic information and related services are generated by third parties independent of Nokia. The content may be inaccurate and incomplete to some extent and is subject to availability. Never rely solely on the aforementioned content and related services.
Select Menu > Maps.
Purchase a licence for the traffic information service
Select Options > Shop & licences > Shop, and select the traffic information service for your region.
View information about traffic events
Select Options > Traffic info. The events are shown on the map as triangles and lines.
View the details and possible rerouting options
Select Options > Open.
Update the traffic information
Select Update traffic info.
Set your device to avoid traffic events
In the main view, select Options > Tools > Settings >
Navigation > Reroute due to traffic.

Location details

A location may include details, such as a 24-hour weather forecast.
Select Menu > Maps.
View the details of a location
Tap the location, tap the information area above the map, and select Show details.
See a more detailed weather forecast
Select Options > Full weather details. You need to have a valid navigation licence and the service must be available for the location.

Use Maps with the compass

Select Menu > Maps.
When the compass in your device is enabled, the circle around the compass is green, and the map view rotates automatically according to the direction to which the top of the device is pointing.
To enable the compass, select Options > Tools > Turn
compass on. When the compass is not in use, the circle
© 2009 Nokia. All rights reserved. 93
around the compass is white, and the map view does not rotate automatically.

Calibrate compass

The compass has limited accuracy. Electromagnetic fields, metal objects, or other external circumstances may also affect the accuracy of the compass. The compass should always be properly calibrated.
To calibrate the compass, do the following:
Internet — Define the internet settings. Navigation — Define the navigation settings. Route — Define the routing settings. Map — Define the map settings. Synchronisation — Define the settings for synchronising
saved items with the Ovi Maps web service.

Internet settings

Select Menu > Maps.
Select Options > Tools > Settings > Internet and from the following:
Go online at start-up — Set the device to open an internet connection when you open Maps.
Default access point or Network destination — Select the access point to be used when connecting to the internet.
Roaming warning — Set the device to notify you when registering to a network other than your home network.
Rotate the device around all axes in a continuous movement until the calibration indicator changes its colour to green
. If the indicator is yellow , the accuracy of the compass
is low. If the indicator is red
, the compass is not calibrated.

Maps settings

Select Menu > Maps.
Select Options > Tools > Settings and from the following:

Navigation settings

Select Menu > Maps.
Select Options > Tools > Settings > Navigation and from the following:
Voice guidance — Select the language of the voice guidance for car navigation. If you select a language with the text "with street names", also the street names are said aloud. You may need to download the voice files before you can select the language.
Backlight — Define the backlight setting.
© 2009 Nokia. All rights reserved.94
Automatic zoom — Use automatic zooming. Traffic info update — Update the information about traffic
events. Reroute due to traffic — Plan a new route to avoid traffic
events. Time indicator — Display the travel time or estimated time
of arrival. Speed limit warner — Set the device to notify you when
you exceed the speed limit, if speed limit information is available for your route.
Safety spot warner — Set the device to notify you when you approach a speed camera, if such information is available for your route.
Maps improvement — Let Nokia use information from your device to improve the Maps application. The information is collected periodically while you are travelling with typical car speeds, and it is anonymous and encrypted. The information contains your direction, speed, location, satellite time, and accuracy of the positioning. The information is sent only when you use Maps over a fixed or wireless local area network connection. The information is deleted from your device once sent.
The available options may vary.

Route settings

You can select the mode of transportation used when you create routes and what characteristics you want the route to prefer.
Select Menu > Maps.
Edit the route settings
Select Options > Tools > Settings > Route.
Select the mode of transportation
Select Transport mode > Walk or Drive. If you select
Walk, one-way streets are regarded as normal streets and
walkways can be used.
Use the fastest route
Select Route selection > Faster route. This option is available only if you have selected Drive as the mode of transportation.
Use the shortest route
Select Route selection > Shorter route.
To plan routes that combine the advantages of both the shortest and the fastest route, select Route selection >
Optimised.
You can also choose to allow or avoid using motorways, tunnels, ferries, and toll roads.

Map settings

Select Menu > Maps.
Select Options > Tools > Settings > Map and from the following:
Categories — Select what type of points of interest you want to see on the map.
© 2009 Nokia. All rights reserved. 95
Colours — Optimise the colour scheme for day or night
usage. Memory to be used — Select where the map files are saved
in your device. Maximum memory use — Select how much memory can
be used to store maps. When the memory limit is reached, the oldest maps are removed.
System of measurement — Select the metric or imperial system.

Synchronisation settings

Define how you want your device to synchronise with Ovi Maps. If you do not have an account in Ovi, create one at www.ovi.com.
Select Menu > Maps.
Define the synchronisation settings
Select Options > Tools > Settings > Synchronisation.
To set the device to synchronise your saved items with your Ovi account automatically when you open and close the Maps application, select Synchronise with Ovi > At start-up and
shut-d..
Synchronise your saved items with Ovi manually
Select Synchronise with Ovi > Manual. To synchronise the items, in the main view, select Options > Favourites >
Synchronise with Ovi.
Define your Ovi account details
Select Login information.

Update maps

To update the maps and voice guidance files in your compatible device, download Nokia Maps Updater to your computer from www.nokia.com/maps. Connect your device to the computer, open Nokia Maps Updater, and do the following:
1 Select your language from the list. 2 If more than one device is connected to the computer,
select your device from the list.
3 When Nokia Maps Updater has found updates, download
them to your device.
4 Accept the download in your device when prompted on
the device display.

Update the Maps application

If your device has an older version of Maps, use Nokia Maps Updater to install the latest version of Maps to your device. Nokia Maps Updater also updates the maps and other services in your device, if needed.Download Nokia Maps Updater to your compatible computer from www.nokia.com/maps. To use Nokia Maps Updater, you need to have Nokia PC Suite installed on your computer.
1 Connect your device to the computer. 2 Open Nokia Maps Updater. 3 Select your language from the list.
© 2009 Nokia. All rights reserved.96
4 If more than one device is connected to the computer,
select your device from the list.
5 When Nokia Maps Updater has found updates, download
them to your device.
6 Accept the download in your device when prompted on
the device display. If prompted, close the running applications.
When you upgrade an older version of Ma ps t o Map s 3.0 , you r licences for the services are automatically converted to new ones. The coverage of the car or pedestrian navigation licence may change, but it still covers the area of your old licence. The licence period remains unchanged. For further information on licence coverage, see www.nokia.com/ maps.

Nokia Map Loader

With the Nokia Map Loader application, you can download maps and voice guidance files from the internet to the device memory or a compatible memory card. You must use the Maps application and browse maps at least once before using Nokia Map Loader, as Nokia Map Loader uses the Maps information to check which version of the maps to download.
To install Nokia Map Loader to a compatible computer, go to www.nokia.com/maps (in English), and follow the instructions on the display.
© 2009 Nokia. All rights reserved. 97

Camera

Activate sequence mode (images only).
Your device supports an image capture resolution of 2592x1944 pixels (5 megapixels). The image resolution in this guide may appear different.
To ensure good quality photos, wipe the camera lens carefully with a cleaning cloth.
Image capture Capture and recording settings
To open the capture and recording settings view before capturing an image or recording a video clip, select Menu >
Applications > Camera and
The capture and recording settings view provides you with shortcuts to different items and settings before capturing an image or recording a video clip.
The capture and recording settings return to the default settings after you close the camera.
Select from the following:
Select the scene.
or Switch between video and image mode.
or Show or hide the viewfinder grid (images only).
Activate the self-timer (images only).
.
Open Photos.
Image settings:
Select a colour effect.
Adjust the white balance. Select the current lighting conditions. This allows the camera to reproduce colours more accurately.
Adjust the exposure compensation (images only). If you are shooting a dark subject against a very light background, such as snow, adjust the exposure to +1 or +2 to compensate for the background brightness. For light subjects against a dark background, use -1 or -2.
Adjust light sensitivity (images only). Increase the light sensitivity in low light conditions to avoid too dark images and blurry images. Increasing the light sensitivity may also increase the image noise.
Adjust contrast (images only). Adjust the difference
between the lightest and darkest parts of the image.
Adjust sharpness (images only).
The screen display changes to match the settings you define.
The capture settings are shooting-mode specific. Switching between the modes does not reset the defined settings.
© 2009 Nokia. All rights reserved.98
If you select a new scene, the capture settings are replaced by the selected scene. You can change the capture settings after selecting a scene if needed.
Saving the captured image may take longer if you change the zoom, lighting, or colour settings.

Capture images

When capturing an image, note the following:
Use both hands to keep the camera still.
The quality of a digitally zoomed image is lower than that
of a non-zoomed image.
The camera goes into battery saving mode if there are no actions for about a minute. To continue capturing images, select Continue.
Keep a safe distance when using the flash. Do not use the flash on people or animals at close range. Do not cover the flash while taking a picture.
To capture an image with the main camera, do the following:
1 To switch from video mode to image mode, if necessary,
select
> .
2 To capture an image, press the capture key. Do not move
the device before the image is saved and the final image displayed.
Capture images with secondary camera
To capture an image, select
. Do not move the device
before the image is saved and the final image displayed.
To zoom in or out when capturing an image, use the zoom slider.
To leave the camera open in the background and use other applications, press the menu key. To return to the camera, press and hold the capture key.

On-screen controls and indicators for still image capture

The still image viewfinder displays the following:
1 Capture mode indicator 2 Zoom slider. To turn the zoom slider on and off, tap the
screen.
3 Capture icon. Tap to capture an image. 4 Flash mode. Tap to change settings. 5 Capture settings. Tap to change settings. 6 Battery charge level indicator 7 Image resolution indicator
© 2009 Nokia. All rights reserved. 99
8 Image counter (the estimated number of images you can
capture using the current image quality setting and available memory)
9 Memory in use. Depending on the setup of your device,
there are the following options: device memory (
).
10 GPS signal indicator

Location information

You can automatically add capture location information to the file details of the captured material. For example, in the Photos application, you can then view the location where an image was captured.
Select Menu > Applications > Camera.
Add location information to all captured material
Select Options > Settings > Show GPS info > On. The location information is available only for images captured with the main camera.
It may take several minutes to obtain the coordinates of your location. The availability and quality of GPS signals may be affected by your location, buildings, natural obstacles, and weather conditions. If you share a file that includes location information, also the location information is shared, and your location may be visible to third parties viewing the file. The device requires network services to acquire location information.
Location information indicators:
— Location information unavailable. GPS stays active in
the background for several minutes. If a satellite connection is made and the indicator changes to
within that time, all the images captured and video clips recorded during that time are tagged based on the received GPS positioning information.
— Location information is available. Location information
is added to the file details.
Files with location information are indicated with
in the
Photos application.

After capturing an image

After you capture an image, select from the follo wing options (available only if you have selected Options > Settings >
Show captured image > Yes):
— Send the image in a multimedia or e-mail message, or through connection methods such as Bluetooth connectivity.
— Upload the image to a compatible online album.
Delete — Delete the image.
To use the image as wallpaper in the home screen, select
Options > Use image > Set as wallpaper.
© 2009 Nokia. All rights reserved.100
Loading...
