Nokia N97 MINI User Guide
Nokia N97 mini User Guide
Issue 4
Contents
Safety 6
About your device 6
Office applications 7
Network services 7
Shared memory 7
Mail for Exchange 7
Magnets and magnetic fields 7
Find help 8
Support 8
In-device help 8
Do more with your device 8
Update device software 8
Settings 9
Access codes 9
Remote lock 10
Prolong battery life 10
Free memory 11
Get started 12
Keys and parts (front) 12
Keys and parts (back) 13
Keys and parts (sides) 13
Keys and parts (top) 13
Insert the SIM card and battery 14
Memory card 15
Antenna locations 16
Switch the device on and off 16
Charge the battery 17
Headset 17
Attach wrist strap 18
Touch screen actions 18
Write text 20
Lock the keys and touch screen 23
Nokia Switch 24
Profiles 25
Your device 26
Home screen 26
Display indicators 27
Shortcuts 29
Search 29
Volume and loudspeaker control 30
Offline profile 30
Fast downloading 31
Ovi (network service) 31
Make calls 34
Touch screen during calls 34
Make a voice call 34
During a call 34
Voice and video mailboxes 35
Answer or reject a call 35
Make a conference call 36
Speed dial a phone number 36
Call waiting 36
Voice dialling 36
Make a video call 37
© 2009 Nokia. All rights reserved.2
During a video call 38
Answer or reject a video call 38
Internet calls 38
Video sharing 39
Log 42
Contacts (phonebook) 43
Save and edit names and numbers 43
Contacts toolbar 43
Manage names and numbers 44
Default numbers and addresses 44
Contact cards 44
Set contacts as favourites 45
Ringing tones, images, and call text for contacts 45
Copy contacts 45
SIM services 46
Contact groups 46
Ovi Contacts 47
About Ovi Contacts 47
Start using Ovi Contacts 47
Connect to the service 48
Create and edit your profile 48
Find and add friends 49
Chat with your friends 50
Ovi Sync 50
Share your location 51
Ovi Contacts settings 51
Nokia account settings 51
Presence settings 52
Personalisation settings 52
Connection settings 53
Messaging 53
Messaging main view 53
Write and send messages 54
Messaging inbox 55
Mailbox 55
View messages on a SIM card 57
Cell broadcast messages 57
Service commands 58
Messaging settings 58
Mail for Exchange 62
Connectivity 63
Data connections and access points 63
Network settings 63
Wireless LAN 64
Access points 66
Active data connections 68
Synchronisation 68
Bluetooth connectivity 69
USB 72
PC connections 72
Administrative settings 73
Internet 74
Browse the web 74
Browser toolbar 74
Navigate pages 75
Web feeds and blogs 75
© 2009 Nokia. All rights reserved. 3
Content search 75
Bookmarks 76
Empty the cache 76
End the connection 76
Connection security 76
Web settings 77
Synchronise your Favourites 88
Share location 89
Get voice guidance 89
Walk to your destination 90
Drive to your destination 90
Get traffic and safety information 91
Positioning (GPS) 78
About GPS 78
Assisted GPS (A-GPS) 79
Hold your device correctly 79
Tips on creating a GPS connection 79
Position requests 80
Landmarks 80
GPS data 81
Positioning settings 82
Ovi Maps 83
Maps overview 83
About positioning methods 83
Use the compass 84
View your location and the map 84
Map view 85
Change the look of the map 85
Find a location 85
View location details 86
Plan a route 86
Save places and routes 87
View and organise places or routes 88
Send places to your friends 88
Camera 92
Image capture 92
Video recording 96
Camera settings 97
Photos 98
About Photos 98
View images and videos 98
View and edit file details 99
Organise images and video clips 100
Photos toolbar 100
Albums 100
Tags 100
Slide show 101
TV-out mode 101
Edit images 102
Edit video clips 103
Image print 103
Share online 103
Music 104
Play a song or a podcast 104
Playlists 105
Podcasts 106
© 2009 Nokia. All rights reserved.4
Transfer music from a computer 106
Ovi Music 106
Nokia Podcasting 107
FM radio 110
Videos 111
Download and view video clips 111
Video feeds 112
My videos 112
Copy a video from your PC 113
Video settings 113
Personalise your device 114
Change the look of your device 114
Profiles 114
3-D tones 114
Modify the home screen 115
Modify the main menu 115
Applications 115
Calendar 115
Clock 116
RealPlayer 117
Recorder 118
Notes 119
Office 119
Settings 123
Phone settings 123
Application manager 129
Calling settings 131
Troubleshooting 133
Green tips 136
Save energy 136
Recycle 136
Product and safety information 136
Index 142
© 2009 Nokia. All rights reserved. 5
Safety
Read these simple guidelines
dangerous or illegal. Read the
information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone
use is prohibited or when
or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always
operate the vehicle while driving. Your first
consideration while driving
INTERFERENCE
All wireless devices may be susceptible to
interference, which coul
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in
aircraft, near medical eq
or blasting areas.
QUALIFIED SERVICE
Only qualified personnel ma
product.
. Not following them may be
complete user guide for further
it may cause interference
keep your hands free to
should be road safety.
d affect performance.
uipment, fuel, chemicals,
y install or repair this
ACCESSORIES AND BATTERIES
Use only approved acce
ssories and batteries. Do
not connect incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
About your device
The wireless device described in
use on the (E)GSM 850, 900, 1800,1900
MHz
2100
1900,
more
information about networks.
w
orks. C
n
e
t
this guide is approved for
MHz
and
your s
o
n
tac
t
,
v
ice
p
e
r
U
rov
MTS
9
0
0
d
er
for
i
Your device supports several connectivity methods and like
computers may be exposed to viruses and other ha
content. Exercise caution
requests, browsing,
with messages, connectivity
and downloads. Only
install and use
services and software from trustworthy sources that offe
rmful
r
adequate security and protection, such as applications th
are Symbian Signed or have pass
Consider installing antivirus
ed the Java Verified™ testing.
and other security software on
your device and any connected computer.
Your device may have preins
third-party internet sites and may allow you to access
party sites. These are not affi
talled bookmarks and links for
third-
liated with Nokia, and Nokia
does not endorse or assume liability for them. If you access
such sites, take precautions for security or conten
t.
,
at
6
© 2009 Nokia. All rights reserved.
Warning:
To use any features in this device, other than the alarm clock,
the device must be switched on. Do not switch the device on
when wireless device use may cause interference or danger.
When using this device, obey all laws and respect local
customs, privacy and legitimate rights of others, including
copyrights. Copyright protection may prevent some images,
music, and other content from being copied, modified, or
transferred.
Make back-up copies or keep a written record of all important
information stored in your device.
When connecting to any other device, read its user guide for
detailed safety instructions. Do not connect incompatible
products.
The images in this guide may differ from your device display.
Refer to the user guide for other important information about
your device.
Office applications
The office applications support common features of Microsoft
Word, PowerPoint, and Excel (Microsoft Office 2000, XP, and
2003). Not all file formats are supported.
Network services
To use the device you must have service from a wireless
service provider. Some features are not available on all
networks; other features may require that you make specific
arrangements with your service provider to use them.
Network services involve transmission of data. Check with
your service provider for details about fees in your home
network and when roaming on other networks. Your service
provider can explain what charges will apply. Some networks
may have limitations that affect how you can use some
features of this device requiring network support such as
support for specific technologies like WAP 2.0 protocols (HTTP
and SSL) that run on TCP/IP protocols and languagedependent characters.
Your service provider may have requested that certain
features be disabled or not activated in your device. If so,
these features will not appear on your device menu. Your
device may also have customized items such as menu names,
menu order, and icons.
Shared memory
The following features in this device may share memory:
multimedia messaging (MMS), e-mail application, instant
messaging. Use of one or more of these features may reduce
the memory available for the remaining features. If your
device displays a message that the memory is full, delete
some of the information stored in the shared memory.
Mail for Exchange
Use of the Mail for Exchange is limited to over-the-air
synchronisation of PIM information between the Nokia
device and the authorised Microsoft Exchange server.
Magnets and magnetic fields
Keep your device away from magnets or magnetic fields.
© 2009 Nokia. All rights reserved. 7
Find help
Support
When you want to learn more about how to use your product
or you are unsure how your device should function, go to
www.nokia.com/support, or using a mobile device,
nokia.mobi/support. You can also select Menu >
Applications > Help in your device.
If this does not resolve your issue, do one of the following:
• Reboot your device. Switch off the device, and remove
the battery. After about a minute, replace the battery,
and switch on the device.
• Restore the original factory settings.
• Update your device software.
If your issue remains unsolved, contact Nokia for repair
options. Go to www.nokia.com/repair. Before sending your
device for repair, always back up the data in your device.
In-device help
Your device contains instructions to help to use the
applications in your device.
To open help texts from the main menu, select Menu >
Applications > Help and the application for which you want
to read instructions.
When an application is open, to access the help text for the
current view, select Options > Help.
When you are reading the instructions, to change the size of
the help text, select Options > Decrease font size or
Increase font size.
You may find links to related topics at the end of the help text.
If you select an underlined word, a short explanation is
displayed.
Help texts use the following indicators:
Link to a related help topic.
Link to the application being discussed.
When you are reading the instructions, to switch between
help texts and the application that is open in the background,
select Options > Show open apps. and the desired
application.
Do more with your device
There are various applications provided by Nokia and third
party software developers, that help you do more with your
device. To find and download applications, visit the Ovi Store
at store.ovi.com. These applications are explained in the
guides that are available on the product support pages at
www.nokia.com/support or your local Nokia website.
Update device software
About device software and application updates
With device software updates and application updates, you
can get new features and enhanced functions for your device.
© 2009 Nokia. All rights reserved.8
Updating the software may also improve your device
performance.
It is recommended that you back up your personal data
before updating your device software.
Warning:
If you install a software update, you cannot use the device,
even to make emergency calls, until the installation is
completed and the device is restarted. Be sure to back up data
before accepting installation of an update.
Downloading software updates may involve the transmission
of large amounts of data (network service).
Make sure that the device battery has enough power, or
connect the charger before starting the update.
After you update your device software or applications, the
instructions in the user guide may no longer be up to date.
Update device software using your PC
You can use the Nokia Software Updater PC application to
update your device software. To update your device software,
you need a compatible PC, a high-speed internet connection,
and a compatible USB data cable to connect your device to
the PC.
To get more information and to download the Nokia
Software Updater application, go to www.nokia.com/
softwareupdate.
Settings
Your device normally has MMS, GPRS, streaming, and mobile
internet settings automatically configured, based on your
network service provider information. You may have settings
from your service providers already installed in your device,
or you may receive or request the settings from the network
service providers as a special message.
You can change the general settings in your device, such as
language, standby mode, display, and keypad lock settings.
Access codes
If you forget any of the access codes, contact your service
provider.
© 2009 Nokia. All rights reserved. 9
Personal identification number (PIN) code — This code
protects your SIM card against unauthorised use. The PIN
code (4 - 8 digits) is usually supplied with the SIM card. After
three consecutive incorrect PIN code entries, the code is
blocked, and you need the PUK code to unblock it.
UPIN code — This code may be supplied with the USIM card.
The USIM card is an enhanced version of the SIM card and is
supported by 3G mobile phones.
PIN2 code — This code (4 - 8 digits) is supplied with some
SIM cards, and is required to access some functions in your
device.
Lock code (also known as security code) — The lock code
helps you to protect your device against unauthorised use.
The preset code is 12345. You can create and change the code,
and set the device to request the code. Keep the new code
secret and in a safe place separate from your device. If you
forget the code and your device is locked, your device will
require service. Additional charges may apply, and all the
personal data in your device may be deleted. For more
information, contact a Nokia Care Point or your device dealer.
Personal Unblocking Key (PUK) code and PUK2 code — These
codes (8 digits) are required to change a blocked PIN code or
PIN2 code, respectively. If the codes are not supplied with the
SIM card, contact the network service provider whose SIM
card is in your device.
UPUK code — This code (8 digits) is required to change a
blocked UPIN code. If the code is not supplied with the USIM
card, contact the network service provider whose USIM card
is in your device.
International Mobile Equipment Identity (IMEI)
number — This number (15 or 17 digits) is used to identify
valid devices on the GSM network. Devices that are, for
example, stolen, can be blocked from accessing the network.
The IMEI number for your device can be found under the
battery.
Remote lock
To prevent unauthorised use of your device, you can lock your
device and memory card remotely using a text message. You
must define the text message, and to lock your device, send
the text message to your device. To unlock your device, you
need the lock code.
To enable remote locking, and to define the text message,
select Menu > Settings and Phone > Phone mgmt. >
Security settings > Phone and SIM card > Remote phone
locking > Enabled. Tap the text input field to enter the text
message content (5-20 characters), select
, and verify the
message. Enter the lock code.
Prolong battery life
Many features in your device increase the demand on battery
power and reduce the battery lifetime. To save battery
power, note the following:
• Features that use Bluetooth technology, or allowing such
features to run in the background while using other
features, increase the demand on battery power.
Deactivate Bluetooth technology when you do not need
it.
• Features that use wireless LAN (WLAN), or allowing such
features to run in the background while using other
features, increase the demand on battery power. WLAN
© 2009 Nokia. All rights reserved.10
on your Nokia device deactivates when you are not trying
to connect, not connected to an access point, or not
scanning for available networks. To further reduce
battery consumption, you can specify that your device
does not scan, or scans less often, for available networks
in the background.
• If you have set Packet data connection to When
available in connection settings, and there is no packet
data coverage (GPRS), the device periodically tries to
establish a packet data connection. To prolong the
operating time of your device, select Packet data
connection > When needed.
• The Maps application downloads new map information
when you scroll to new areas on the map, which
increases the demand on battery power. You can prevent
the automatic download of new maps.
• If the signal strength of the cellular network varies much
in your area, your device must scan for the available
network repeatedly. This increases the demand on
battery power.
If the network mode is set to dual mode in the network
settings, the device searches for the 3G network. You can
set the device to use only the GSM network. To use only
the GSM network, select Menu > Settings and
Connectivity > Network > Network mode > GSM.
• The backlight of the display increases the demand on
battery power. In the display settings, you can change
the length of the time-out period after which the
backlight is switched off. Select Menu > Settings and
Phone > Display > Light time-out. To adjust the light
sensor that observes lighting conditions and adjusts the
display brightness, in the display settings, select Light
sensor.
• Leaving applications running in the background
increases the demand on battery power. To close the
applications you are not using, if they are not responding,
select Options > Show open apps., and go to the
application using the menu key. Press and hold the menu
key to open the application, and select Options > Exit.
Free memory
To view how much space is available for different data types,
select Menu > Applications > Office > File mgr..
Many features of the device use memory to store data. The
device notifies you if the memory in different memory
locations is low.
To free memory, transfer data to a compatible memory card
(if available) or to a compatible computer.
To remove data you no longer need, use File manager or open
the respective application. You can remove the following:
• Messages in the folders in Messaging and retrieved e-mail
messages in the mailbox
• Saved web pages
• Contact information
• Calendar notes
© 2009 Nokia. All rights reserved. 11
• Applications shown in Application manager that you do
not need
• Installation files (.sis or .sisx) of applications you have
installed. Transfer the installation files to a compatible
computer.
• Images and video clips in Photos. Back up the files to a
compatible computer.
Get started
Note: The surface of this device does not contain nickel in
the platings. The surface of this device contains stainless
steel.
Keys and parts (front)
1 Proximity sensor
2 Earpiece
3 Touch screen
4 Menu key
5 Call key
6 Secondary camera lens
7 Light sensor
8 End key
© 2009 Nokia. All rights reserved.12
Do not cover the area above the touch screen, for example,
with protective film or tape.
Keys and parts (back)
1 Camera flash
2 Camera lens
Keys and parts (sides)
1 Stereo speaker
2 Charging indicator light
3 Micro USB connector
4 Lock switch
5 Volume up/Zoom in key
6 Volume down/Zoom out key
7 Capture key
Keys and parts (top)
© 2009 Nokia. All rights reserved. 13
1 Power key
2 Nokia AV connector (3.5 mm)
Insert the SIM card and battery
Follow the instructions carefully, to avoid damaging the back
cover.
Safe removal. Always switch the device off and disconnect the
charger before removing the battery.
1 Remove the back cover by lifting it from the bottom end
of the device.
2 If the battery is inserted, lift the battery in the direction
of the arrow to remove it.
3 Pull out the SIM card holder, and insert the SIM card.
Ensure that the gold-coloured contact area on the card is
facing down and that the bevelled corner on the card is
facing the bevelled corner on the holder. Push the SIM
card holder back in.
4 Align the contacts of the battery with the corresponding
connectors on the battery compartment, and insert the
battery in the direction of the arrow.
5 To replace the back cover, direct the top locking catches
toward their slots, and press down until the cover locks
into place.
© 2009 Nokia. All rights reserved.14
Memory card
Use only compatible microSD cards approved by Nokia for use
with this device. Nokia uses approved industry standards for
memory cards, but some brands may not be fully compatible
with this device. Incompatible cards may damage the card
and the device and corrupt data stored on the card.
Insert the memory card
A memory card may be already inserted in the device. If not,
do the following:
1 Remove the back cover of the device.
2 Insert a compatible memory card in the slot. Ensure that
the contact area on the card is facing down and towards
the slot.
3 Push the card in. You can hear a click when the card locks
into place.
4 Replace the back cover. Keep the device facing down
when replacing the cover. Ensure that the cover is
properly closed.
Remove the memory card
Important: Do not remove the memory card during an
operation when the card is being accessed. Doing so may
damage the memory card and the device, and corrupt data
stored on the card.
1 Before you remove the card, press the power key, and
select Remove memory card. All applications are closed.
2When Removing memory card will close all open
applications. Remove anyway? is displayed, select
Yes.
3When Remove memory card and press 'OK' is
displayed, remove the back cover of the device.
4 Press the memory card to release it from the slot.
© 2009 Nokia. All rights reserved. 15
5 Pull out the memory card. If the device is switched on,
select OK.
6 Replace the back cover. Ensure that the cover is properly
closed.
Antenna locations
Your device may have internal and external antennas. Avoid
touching the antenna area unnecessarily while the antenna
is transmitting or receiving. Contact with antennas affects the
communication quality and may cause a higher power level
during operation and may reduce the battery life.
Switch the device on and off
To switch on the device:
1 Press and hold the power key.
2 If the device asks for a PIN code or lock code, enter it, and
select OK. The preset lock code is 12345. If you forget the
code and your device is locked, your device will require
service and additional charges may apply. For more
information, contact a Nokia Care point or your device
dealer.
To switch off the device, press the power key briefly, and
select Switch off!.
© 2009 Nokia. All rights reserved.16
Charge the battery
Your battery has been partially charged at the factory. There
may not be a need to charge the battery in advance. If the
device indicates a low charge, do the following:
Regular charging
USB charging
You can use USB charging when a wall outlet is not available.
With USB charging, you can also transfer data while charging
the device.
1 Connect a compatible USB device to your device using a
compatible USB cable.
The efficiency of USB charging varies significantly. In
some cases, it may take a very long time for charging to
start and the device to start functioning.
2 If your device is switched on, you can select from the
available USB mode options on the display of the device.
1 Connect the charger to a wall outlet.
2 Connect the charger to the device. The charging indicator
light next to the USB connector is lit when the battery is
being charged.
Headset
You can connect a compatible headset or compatible
headphones to your device. You may need to select the cable
mode.
3 When the device indicates a full charge, disconnect the
charger from the device, then from the wall outlet.
You do not need to charge the battery for a specific length of
time, and you can use the device while it is charging. If the
battery is completely discharged, it may take several minutes
before the charging indicator appears on the display or
before any calls can be made.
Tip: Disconnect the charger from the wall outlet when the
charger is not in use. A charger that is connected to the outlet
consumes power even when it is not connected to the device.
© 2009 Nokia. All rights reserved. 17
Warning:
When you use the headset, your ability to hear outside
sounds may be affected. Do not use the headset where it can
endanger your safety.
Do not connect products that create an output signal as this
may cause damage to the device. Do not connect any voltage
source to the Nokia AV Connector.
When connecting any external device or any headset, other
than those approved by Nokia for use with this device, to the
Nokia AV Connector, pay special attention to volume levels.
Attach wrist strap
Thread the wrist strap, and tighten it.
Touch screen actions
Use the touch screen with your finger or with a stylus (if
available).
Important: Use only a stylus approved by Nokia for use with
this device. Using any other stylus may invalidate any
warranty applying to the device and may damage the touch
screen. Avoid scratching the touch screen. Never use an actual
pen or pencil or other sharp objects to write on the touch
screen.
© 2009 Nokia. All rights reserved.18
Tap and double-tap
Drag
To open an application or other element on the touch screen,
you normally tap it with your finger. However, to open the
following items, you must tap them twice.
• List items in an application, such as the Drafts folder in
To drag, place your finger on the screen, and slide it across
the screen.
Example: To scroll up or down on a web page, drag the page
with your finger.
the Messaging application.
• Files in a file list, for example, an image in the Captured
folder in the Photos application.
Tip: When you open a list view, the first item is already
Swipe
To swipe, slide your finger quickly left or right on the screen.
highlighted. To open the highlighted item, tap it once.
If you tap a file or similar item once, it is not opened, it
becomes highlighted. To see the options available for the
item, select Options or, if available, select an icon from
a toolbar.
Select
In this user documentation, to open applications or items by
tapping them once or twice, you "select" them. If you need
to select several items in a sequence, the display texts to
select are separated by arrows.
Example: To select Options > Help, tap Options, and then
tap Help.
Flick
To flick, place your finger on the screen, slide it quickly across
the screen, then quickly lift your finger. The content of the
screen will continue scrolling with the speed and direction it
had at the moment of release. To select an item from a
scrolling list and to stop the movement, tap the item. In your
device, flicking is available in Music player.
© 2009 Nokia. All rights reserved. 19
Scroll
To scroll up or down in lists that have a scroll bar, drag the
slider of the scroll bar.
In some list views, you can place your finger on a list item and
drag up or down.
Tip: To view a brief description of an icon, place your finger
on the icon. Descriptions are not available for all icons.
Touch screen backlight
To turn the screen backlight on, unlock the screen and keys,
if necessary, and press the menu key.
or use handwriting mode to write characters directly on the
screen.
To open the virtual keypad, select any text input field. To
switch between the virtual keypad and handwriting mode,
select
and the desired input mode.
The input methods and languages supported by the
handwriting recognition vary by region.
Keyboard input
Keyboard
Write text
You can enter text in several ways. When the slide is open,
the full keyboard works as a traditional keyboard. When the
slide is closed, you can use the virtual keypad to enter text,
Your device has a full keyboard. To open the keyboard, push
the touch screen up. In all applications, the screen rotates
© 2009 Nokia. All rights reserved.20
automatically from portrait to landscape when you open the
keyboard.
6Enter key
7 Backspace key. To erase a character, press the
backspace key. To erase several characters, press and
hold the backspace key.
Insert letters not shown on the keyboard
It is possible to insert variations of letters, for example, letters
with accents. To insert á, press and hold the sym key, and
simultaneously press the A key repeatedly, until the desired
character is displayed. The order and availability of letters
depends on the selected writing language.
1Sym key. To insert special characters not shown on the
keyboard, press the sym key once, and select the desired
character from the table.
2 Function key. To insert special characters printed at the
top of keys, press the function key, and then press the
corresponding alphabet key, or press and hold the
alphabet key only. To enter several special characters in
a row, press the function key twice quickly, and then
press the desired alphabet keys. To return to normal
mode, press the function key once.
3Shift key. To change between uppercase and lowercase
modes, press the shift key twice. To enter a single
uppercase letter in lowercase mode, or a single
lowercase letter in uppercase mode, press the shift key
once, and then the desired alphabet key.
4Space key
5Arrow keys. To move up, down, left, or right, use the
Touch input
Handwriting
The input methods and languages supported by the
handwriting recognition vary by region and may not be
available for all languages.
To activate handwriting mode, select
> Handwriting.
Write legible, upright characters on the text input area, and
leave a space between each character.
To teach the device your handwriting style, select
>
Handwriting training.
To enter letters and numbers (default mode), write words as
you would normally. To select number mode, select
. To
arrow keys.
© 2009 Nokia. All rights reserved. 21
enter non-Latin characters, select the corresponding icon, if
available.
To enter special characters, write them as you would
normally, or select
and the desired character.
To delete characters or move the cursor back, swipe
backwards (see Figure 1).
To insert a space, swipe forwards (see Figure 2).
Touch input settings
Select Menu > Settings and Phone > Touch input.
To configure text input settings for the touch screen, select
from the following:
Handwriting training — Open the handwriting training
application. Train the device to recognise your handwriting
better. This option is not available in all languages.
Writing language — Define which language-specific
characters in your handwriting are recognised and how your
on-screen keyboard is laid out.
Writing speed — Adjust the speed at which handwriting is
recognised.
Guiding line — Show or hide the guiding line in the writing
area. The guiding line helps you write in a straight line, and
it also helps the device recognise your writing. This option
may not be available in all languages.
Pen trail width — Change the thickness of the text.
Writing colour — Change the colour of the text.
Virtual keypad
With the virtual keypad (Alphanumeric keypad), you can
enter characters like you would with a traditional physical
keypad with numbers on the keys.
© 2009 Nokia. All rights reserved.22
whether the automatic input mode (sensor settings) is
activated or not.
5 Arrow keys - Scroll left or right.
6 Backspace
7 Numbers
8 Star - Opens a special characters table.
9 Shift - Changes the character case, activates or
deactivates predictive text input modes, and switches
between letter and number modes.
Lock the keys and touch screen
When the device or keypad is locked, calls may be possible to
the official emergency number programmed into your
device.
To lock or unlock the touch screen and the keys, slide the lock
switch on the side of the device.
1 Close - Closes the virtual keypad (Alphanumeric
keypad).
2 Input menu - Opens the touch input menu, which
includes commands such as Activate predictive text
and Writing language.
3 Text input indicator - Opens a pop-up window, in which
you can activate or deactivate predictive text input
modes, change the character case, and switch between
letter and number modes.
4 Input mode - Opens a pop-up window, in which you can
select the input mode. When you tap an item, the current
When the touch screen and keys are locked, the touch screen
is turned off and the keys are inactive.
When you push the touch screen up, the keyboard unlocks.
The screen and keys may be locked automatically after a
period of inactivity.
To modify settings for automatic screen and key locking,
select Menu > Settings and Phone > Phone mgmt. >
Auto. keyguard.
input method view closes, and the selected one opens.
The availability of input modes may vary depending on
© 2009 Nokia. All rights reserved. 23
Nokia Switch
Transfer content
You can use the Switch application to copy content such as
phone numbers, addresses, calendar items, and images from
your previous Nokia device to your device.
The type of content that can be transferred depends on the
model of the device from which you want to transfer content.
If that device supports synchronisation, you can also
synchronise data between the devices. Your device notifies
you if the other device is not compatible.
If the other device cannot be switched on without a SIM card,
you can insert your SIM card in it. When your device is
switched on without a SIM card, the Offline profile is
automatically activated, and transfer can be done.
Transfer content for the first time
1 To retrieve data from the other device for the first time,
on your device, select Menu > Settings >
Connectivity > Data transfer > Phone switch.
2 Select the connection type you want to use to transfer
the data. Both devices must support the selected
connection type.
3 If you select Bluetooth connectivity as the connection
type, connect the two devices. To have your device search
for devices with Bluetooth connectivity, select
Continue. Select the device from which you want to
transfer content. You are asked to enter a code on your
device. Enter a code (1-16 digits), and select OK. Enter the
same code on the other device, and select OK. The devices
are now paired.
Some earlier Nokia devices may not have the Switch
application. In this case, the Switch application is sent to
the other device as a message. To install the Switch
application on the other device, open the message, and
follow the instructions on the display.
4 On your device, select the content you want to transfer
from the other device.
When the transfer has started, you can cancel it and
continue later.
Content is transferred from the memory of the other device
to the corresponding location in your device. The transfer
time depends on the amount of data to be transferred.
Synchronise, retrieve, or send content
Select Menu > Settings > Connectivity > Data transfer >
Phone switch.
After the first transfer, select from the following to start a
new transfer, depending on the model:
to synchronise content between your device and the
other device, if the other device supports
synchronisation. The synchronisation is two-way. If
an item is deleted in one device, it is deleted in both.
You cannot restore deleted items with
synchronisation.
to retrieve content from the other device to your
device. With retrieval, content is transferred from the
other device to your device. You may be asked to
keep or delete the original content in the other
device, depending on the device model.
© 2009 Nokia. All rights reserved.24
to send content from your device to your other device
If you cannot send an item, depending on the type of the
other device, you can add the item to the Nokia folder, to C:
\Nokia or E:\Nokia in your device. When you select the folder
to transfer, the items are synchronised in the corresponding
folder in the other device, and vice versa.
Use shortcuts to repeat a transfer
After a data transfer, you can save a shortcut with the transfer
settings to the main view to repeat the same transfer later.
You can use profiles to set and customise the ringing tones,
message alert tones, and other tones for different events,
environments, or caller groups. The name of the selected
profile is displayed at the top of the home screen.
To change a profile, scroll to the profile, and select
Options > Activate.
To personalise a profile, scroll to the profile, and select
Options > Personalise. Select the setting you want to
change.
To edit the shortcut, select Options > Shortcut settings. For
example, you can create or change the name of the shortcut.
To set the profile to be active until a certain time within the
next 24 hours, scroll to the profile, select Options > Timed,
and set the time. When the time expires, the profile changes
A transfer log is shown after every transfer. To view the log
of the last transfer, select a shortcut in the main view and
Options > View log.
Handle transfer conflicts
back to the previously active non-timed profile. When the
profile is timed,
is displayed in the home screen. The
Offline profile cannot be timed.
To create a new profile, select Options > Create new.
If an item to be transferred has been edited in both devices,
the device attempts to merge the changes automatically. If
this is not possible, there is a transfer conflict. Select Check
one by one, Priority to this phone, or Priority to other
phone to solve the conflict.
Profiles
Select Menu > Settings and Profiles.
© 2009 Nokia. All rights reserved. 25
Your device
Home screen
About the home screen
In the home screen, you can quickly access your most
frequently used applications, control applications, such as
the music player, view your favourite contacts, and view at a
glance if you have missed calls or new messages.
To open the main menu, press the menu key (5).
To hide and show content, swipe the home screen with your
finger.
Add items to the home screen
To add an item to the home screen, select Options > Edit
content > Options > Add content, and select the item from
the list.
Using widgets may involve the transmission of large amounts
of data (network service).
To move an item, select Options > Edit content, select the
desired item, and drag and drop it to a new location.
Interactive home screen elements
To open the clock application, tap the clock (1).
To open calendar or change profiles in the home screen, tap
the date or the profile name (2).
To view or change connectivity settings (
available wireless LANs if WLAN scanning is enabled, or to
view the missed events, tap the top right corner (3).
To make a phone call, select
(4).
), to see the
Remove an item from the home screen
Select Options > Edit content and the item to be removed.
Select Options > Remove > Done.
E-mail notifications
About e-mail notifications
E-mail notifications in the home screen help you keep track
of e-mail messages in your mailbox. You can set the device
to show a preview of e-mail headers or just the number of
unread e-mail.
© 2009 Nokia. All rights reserved.26
Work with e-mail in the home screen
To add e-mail to the home screen, in the home screen, select
Options > Edit content > Options > Add content > E-
mail widget.
1 To add your favourite contacts to the home screen, select
Options > Edit content > Options > Add content >
Favourite contacts.
A row of
2 Select any of the icons (
icons is displayed in the home screen.
) and a contact from Contacts.
To set up your e-mail account, in the home screen, select Set
up e-mail, and follow the instructions. When the setup is
complete, the e-mail icon appears in the home screen. To
open your e-mail mailbox, tap the icon.
Add your favourite Share online feed to your home
screen
By adding the Share online widget to your home screen, you
can quickly access your favourite Share online feed.
1 In the home screen, select Options > Edit content >
Music player in the home screen
You can use the music player from the home screen. To
activate the music player controls, select Options > Edit
content > Options > Add content > Music player.
Go to Music appears in the home screen.
To open the music player, tap Go to Music, and select the
items you want to listen to.
The music player control keys, and, if available, the title of
the song, artist, and album art are displayed when a song is
Options > Add content > Share online.
2 Select the feed you want to add. You may need to register
to a service of your service provider before you are able
to add a feed.
The widget displays thumbnail images from a selected feed
of any of your Share online accounts. The latest images are
displayed first.
Display indicators
General indicators
played.
Favourite contacts in the home screen
You can add several contacts directly to the home screen, and
quickly make calls or send messages to the contacts, view the
contacts' web feeds, or access the contact information and
settings.
© 2009 Nokia. All rights reserved. 27
The touch screen and keys are locked.
The device alerts silently for incoming calls or
messages.
You have set a clock alarm.
You are using a timed profile.
Call indicators
Someone has tried to call you.
You are using your second phone line (network
service).
You have set your device to divert incoming calls
to another number (network service). If you
have two phone lines, a number indicates the
active line.
Your device is ready for an internet call.
You have an ongoing data call (n etwork service).
Messaging indicators
You have unread messages. If the indicator is
blinking, the SIM card memory for messages
may be full.
You have received new mail.
You have messages waiting to be sent in the
Outbox folder.
Network indicators
Your device is connected to a GSM network
(network service).
Your device is connected to a 3G network
(network service).
You have a GPRS packet data connection
(network service).
connection is on hold and
indicates that the
that a connection
is being established.
You have an EGPRS packet data connection
(network service).
connection is on hold and
indicates that the
that a connection
is being established.
You have a 3G packet data connection (network
service).
suspended and
indicates that the connection is
that a connection is being
established.
You have a high-speed downlink packet access
(HSDPA) connection (network service).
indicates that the connection is suspended and
that a connection is being established.
A WLAN connection is available (network
service).
encrypted and
indicates that the connection is
that the connection is not
encrypted.
© 2009 Nokia. All rights reserved.28
Connectivity indicators
Bluetooth is active. indicates that your
device is sending data. If the indicator is
blinking, your device is trying to connect to
another device.
You have connected a USB cable to your device.
GPS is active.
The device is synchronising.
You have connected a compatible headset to the
device.
You have connected a compatible TV-out cable
to the device.
You have connected a compatible text phone to
the device.
Shortcuts
To switch between open applications, press and hold the
menu key.
Leaving applications running in the background increases the
demand on battery power and reduces the battery life.
To open the browser application, in the dialler, tap and hold
0.
To change the profile, press the power key, and select a
profile.
To call your voice mailbox (network service), in the dialler,
tap and hold 1.
To open a list of last dialled numbers, in the home screen,
press the call key.
To use voice commands, in the home screen, press and hold
the call key.
When writing, to change the writing language, press
and
the sym key.
Search
About Search
Select Menu > Applications > Search.
Search (network service) enables you to use various internet-
based search services to find, for example, websites and
images. The content and availability of the services may vary.
Start a search
Select Menu > Applications > Search.
To search the contents of your mobile device, enter search
terms in the search field, or browse the content categories.
While you enter the search terms, the results are organised
© 2009 Nokia. All rights reserved. 29
into categories. The most recently accessed results appear at
the top of the result list, if they match your search terms.
To search for web pages on the internet, select Search the
Internet and a search provider, and enter your search terms
in the search field. The search provider you selected is set as
your default internet search provider.
If a default search provider is already set, select it to start a
search, or select Search more to use another search provider.
To change the default search provider, select Options >
Settings > Search services.
To change the country or region setting to find more search
providers, select Options > Settings > Country or region.
Volume and loudspeaker control
To adjust the volume level when you have an active call or
are listening to a sound clip, use the volume key.
The built-in loudspeaker allows you to speak and listen from
a short distance without having to hold the device to your
ear.
Search settings
Select Menu > Applications > Search.
To change the Search application settings, select Options >
Settings and from the following:
Country or region — Select the country or region you want
to search from.
Connection — Select the access point, and allow or deny
network connections.
Search services — Select whether service providers and
search categories are shown.
General — Enable or disable tooltips, and clear the search
history.
To use the loudspeaker during a call, select Loudspeaker.
To turn off the loudspeaker, select Activate handset.
Offline profile
The offline profile lets you use the device without connecting
to the wireless cellular network. When the offline profile is
active, you can use your device without a SIM card.
Activate the offline profile
Press the power key briefly, and select Offline.
© 2009 Nokia. All rights reserved.30
Loading...
