NOKIA N97 User Guide
Nokia N97 User Guide
Issue 1
© 2009 Nokia. All rights reserved.
DECLARATION OF CONFORMITY
Nokia, Nokia Connecting People, Nseries, N97, Nokia Original Accessories logo, and Ovi are trademarks or registered trademarks of Nokia Corporation. Nokia
tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.
Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is
prohibited. Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described
Hereby, NOKIA CORPORATION declares that this RM-507 product is in compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity can be found at http://www.nokia.com/
phones/declaration_of_conformity/.
in this document without prior notice.
This product includes software licensed from Symbian Software Ltd ©1998-2009. Symbian and Symbian OS are trademarks of Symbian Ltd.
Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.
Portions of the Nokia Maps software are © 1996-2009 The FreeType Project. All rights reserved.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has
been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection
with MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that
related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See http://www.mpegla.com.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF
DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.
The third-party appl ications provided with your device may have been created and may be owned by persons or entities not affiliated with or related to Nokia.
Nokia does not own the copyrights or intellectual property rights to the third-party applications. As such, Nokia does not take any responsibility for end-user
support, functionality of the applications, or the information in the applications or these materials. Nokia does not provide any warranty for the third-party
applications.
BY USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE APPLICATIONS ARE PROVIDED AS IS WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, TO THE
MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW. YOU FURTHER ACKNOWLEDGE THAT NEITHER NOKIA NOR ITS AFFILIATES MAKE ANY REPRESENTATIONS OR
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO WARRANTIES OF TITLE, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR THAT
THE APPLICATIONS WILL NOT INFRINGE ANY THIRD-PARTY PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY,
RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.
Reverse engineering of software in the device is prohibited to the extent permitted by applicable law. Insofar as this user guide contains any limitations on
Nokia's representations, warranties, damages and liabilities, such limitations shall likewise limit any representations, warranties, damages and liabilities of
Nokia's licensors.
The availability of particular products and applications and services for these products may vary by region. Please check with your Nokia dealer for details and
availability of language options. This device may contain commodities, technology or software subject to export laws and regulations from the US and other
countries. Diversion contrary to law is prohibited.
The availability of some features may vary by region. Please contact your operator for more details.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada
can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device
complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved
by Nokia could void the user's authority to operate this equipment.
Issue 1 EN-US
Contents
Safety................................................................8
Contents
About your device.................................................................8
Network services...................................................................9
Shared memory...................................................................10
ActiveSync............................................................................10
Find help.........................................................11
Support................................................................................11
In-device help......................................................................11
Accessibility solutions........................................................12
Do more with your device.................................................12
Update device software.....................................................12
Settings................................................................................13
Access codes........................................................................13
Remote lock.........................................................................14
Prolong battery life............................................................14
Free memory.......................................................................15
Get started......................................................17
Keys and parts (top)...........................................................17
Keys and parts (front).........................................................17
Keys and parts (back).........................................................17
Keys and parts (sides)........................................................18
Insert the SIM card and battery.........................................18
Memory card........................................................................19
Antenna locations...............................................................20
Switch the device on and off.............................................21
Charge the battery..............................................................21
Headset................................................................................22
Attach wrist strap...............................................................22
Touch screen actions..........................................................22
Write text.............................................................................24
Lock the keys and touch screen........................................27
Nokia Switch.......................................................................27
Profiles.................................................................................29
Your device.....................................................30
Home screen........................................................................30
Display indicators...............................................................32
Shortcuts..............................................................................33
Search..................................................................................33
Volume and loudspeaker control......................................34
Offline profile......................................................................34
Fast downloading...............................................................35
Ovi (network service).........................................................35
Make calls.......................................................38
Proximity sensor.................................................................38
Voice calls ...........................................................................38
During a call........................................................................38
Voice and video mailboxes ...............................................39
Answer or reject a call........................................................39
Make a conference call.......................................................40
1-touch dial a phone number ...........................................40
Call waiting..........................................................................40
Voice dialing........................................................................41
Make a video call.................................................................41
During a video call..............................................................42
Answer or reject a video call.............................................42
Internet calls.......................................................................43
Video sharing......................................................................44
Log........................................................................................46
Contacts (phonebook)....................................48
Save and edit names and numbers..................................48
Contacts toolbar..................................................................48
Manage names and numbers............................................48
Default numbers and addresses........................................49
Contact cards.......................................................................49
Set contacts as favorites....................................................49
Ringing tones, images, and call text for contacts...........50
Copy contacts......................................................................50
SIM services.........................................................................50
Contact groups....................................................................51
Ovi Contacts.........................................................................52
Messaging.......................................................58
Messaging main view.........................................................58
Write and send messages..................................................58
Messaging inbox.................................................................59
Mailbox................................................................................60
View messages on a SIM card............................................62
Cell broadcast messages....................................................62
Service commands..............................................................62
Messaging settings.............................................................62
Mail for Exchange................................................................67
Nokia Messaging.................................................................68
Synchronization..................................................................75
Bluetooth connectivity.......................................................76
USB.......................................................................................79
PC connections....................................................................80
Administrative settings......................................................80
Internet..........................................................82
Browse the web..................................................................82
Browser toolbar..................................................................83
Navigate pages...................................................................83
Web feeds and blogs..........................................................83
Content search....................................................................84
Bookmarks...........................................................................84
Empty the cache..................................................................84
End the connection.............................................................84
Connection security............................................................85
Web settings.......................................................................85
Positioning (GPS)............................................87
About GPS............................................................................87
Assisted GPS (A-GPS)...........................................................87
Hold your device correctly.................................................88
Tips on creating a GPS connection....................................88
Position requests................................................................89
Landmarks...........................................................................89
GPS data...............................................................................89
Positioning settings...........................................................91
Contents
Connectivity....................................................69
Data connections and access points.................................69
Network settings................................................................69
Wi-Fi/WLAN connection ....................................................70
Access points.......................................................................72
Active data connections.....................................................75
Nokia Maps.....................................................92
About Maps..........................................................................92
Network positioning..........................................................92
Use Maps with the compass..............................................93
Display indicators...............................................................93
Move on a map....................................................................93
Navigate to the destination..............................................94
Find locations......................................................................94
Plan routes..........................................................................94
Save and send locations.....................................................95
View your saved items.......................................................95
Contents
Walk to your destination...................................................96
Drive to your destination...................................................96
Traffic and safety................................................................97
Maps settings......................................................................98
Internet settings.................................................................98
Navigation settings............................................................98
Route settings.....................................................................99
Map settings........................................................................99
Update maps.....................................................................100
Nokia Map Loader.............................................................100
Camera..........................................................101
Activate the camera.........................................................101
Image capture...................................................................101
Video recording................................................................105
Camera settings................................................................106
Photos..........................................................108
About Photos....................................................................108
View images and videos..................................................108
View and edit file details.................................................109
Organize images and videos...........................................109
Photos toolbar..................................................................109
Albums...............................................................................110
Tags....................................................................................110
Slide show.........................................................................110
TV-out mode.....................................................................111
Edit images........................................................................112
Edit videos.........................................................................112
Image print.......................................................................113
Share online......................................................................113
Music.............................................................114
Play a song or a podcast..................................................114
Playlists..............................................................................115
Podcasts.............................................................................115
Transfer music from a computer....................................115
Nokia Music Store.............................................................116
FM transmitter..................................................................116
Nokia Podcasting..............................................................117
FM radio.............................................................................121
Videos...........................................................122
Download and view video clips......................................122
Video feeds........................................................................123
My videos...........................................................................123
Transfer videos from your PC..........................................124
Video settings...................................................................124
Personalize your device...............................125
Change the look of your device.......................................125
Profiles...............................................................................125
3-D tones...........................................................................126
Modify the home screen..................................................126
Modify the main menu.....................................................126
Applications..................................................127
Calendar.............................................................................127
Clock ..................................................................................128
RealPlayer .........................................................................129
Recorder............................................................................130
Notes..................................................................................130
Office..................................................................................131
Settings........................................................136
Phone settings..................................................................136
Application manager........................................................143
Calling settings.................................................................145
Troubleshooting...........................................148
Green tips.....................................................151
Save energy.......................................................................151
Recycle...............................................................................151
Save paper.........................................................................151
Learn more........................................................................151
Accessories...................................................152
Battery and charger information.................153
Battery and charger information....................................153
Nokia battery authentication guidelines.......................154
Taking care of your device...........................155
Recycle...............................................................................155
Additional safety information.....................157
Small children...................................................................157
Operating environment...................................................157
Medical devices.................................................................157
Hearing aids......................................................................158
Vehicles..............................................................................159
Potentially explosive environments...............................159
Emergency calls................................................................159
Certification information (SAR).......................................160
Index............................................................162
Contents
Safety
Safety
Read these simple guidelines. Not following them may
be dangerous or illegal. Read the complete user guide
for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless
phone use is prohibited or when it may cause
interference or danger.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in
aircraft, near medical equipment, fuel,
chemicals, or blasting areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free
to operate the vehicle while driving. Your first
consideration while driving should be road
safety.
QUALIFIED SERVICE
Only qualified personnel may install or repair
this product.
8
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do
not connect incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
About your device
The wireless device described in this guide is approved for
use on the (E)GSM 850, 900, 1800, 1900, and UMTS 850,
1900, 2100 networks. Contact your service provider for
more information about your network.
When using the features in this device, obey all laws and
respect local customs, privacy and legitimate rights of
others, including copyrights.
Copyright protection may prevent some images, music,
and other content from being copied, modified, or
transferred.
Your device supports several connectivity methods. Like
computers, your device may be exposed to viruses and
other harmful content. Exercise caution with messages,
connectivity requests, browsing, and downloads. Only
install and use services and other software from
trustworthy sources that offer adequate security and
protection against harmful software, such as applications
that are Symbian Signed or have passed the Java Verified™
testing. Consider installing antivirus and other security
software on your device and any connected computer.
Important: Your device can only support one
antivirus application. Having more than one application
with antivirus functionality could affect performance and
operation or cause the device to stop functioning.
Your device may have preinstalled bookmarks and links to
third-party internet sites. You may also access other thirdparty sites through your device. Third-party sites are not
affiliated with Nokia, and Nokia does not endorse or
assume liability for them. If you choose to access such
sites, you should take precautions for security or content.
Warning: To use any features in this device, other
than the alarm clock, the device must be switched on. Do
not switch the device on when wireless device use may
cause interference or danger.
The office applications support common features of
Microsoft Word, PowerPoint, and Excel (Microsoft Office
2000, XP, and 2003). Not all file formats can be viewed or
modified.
Remember to make back-up copies or keep a written
record of all important information stored in your device.
When connecting to any other device, read its user guide
for detailed safety instructions. Do not connect
incompatible products.
The images in this guide may differ from your device
display.
Network services
To use the device you must have service from a wireless
service provider. Some features are not available on all
networks; other features may require that you make
specific arrangements with your service provider to use
them. Network services involve transmission of data.
Check with your service provider for details about fees in
your home network and when roaming on other
networks. Your service provider can explain what charges
will apply. Some networks may have limitations that affect
how you can use some features of this device requiring
network support such as support for specific technologies
like WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP
protocols and language-dependent characters.
Your service provider may have requested that certain
features be disabled or not activated in your device. If so,
these features will not appear on your device menu. Your
device may also have customized items such as menu
names, menu order, and icons.
Safety
9
Shared memory
The following features in this device may share memory:
Safety
multimedia messaging (MMS), e-mail application, instant
messaging. Use of one or more of these features may
reduce the memory available for the remaining features
sharing memory. Your device may display a message that
the memory is full when you try to use a shared memory
feature. In this case, delete some of the information or
entries stored in the shared memory features before
continuing.
During extended operation such as an active video call and
high speed data connection, the device may feel warm. In
most cases, this condition is normal. If you suspect the
device is not working properly, take it to the nearest
authorized service facility.
ActiveSync
Use of the Mail for Exchange is limited to over-the-air
synchronization of PIM information between the Nokia
device and the authorized Microsoft Exchange server.
10
Find help
For local services and warranty information, please
refer to the separate booklet.
Support
When you want to learn more about how to use your
product or you are unsure how your device should
function, see the support pages at www.nokia.com/
support or your local Nokia website, www.nokia.mobi/
support (with a mobile device), the Help application in
the device, or the user guide.
If this does not resolve your issue, do one of the
following:
● Restart the device: switch off the device, and remove
the battery. After about a minute, replace the
battery, and switch on the device.
● Restore the original factory settings as explained in
the user guide. Your documents and files will be
deleted in the reset, so back up your data first.
● Update your device software regularly for optimum
performance and possible new features, as
explained in the user guide.
If your issue remains unsolved, contact Nokia for repair
options. See www.nokia.com/repair, or in Latin
America, www.nokia-latinoamerica.com/
centrosdeservicio. Before sending your device for
repair, always back up the data in your device.
In-device help
Your device contains instructions to help to use the
applications in your device.
To open help texts from the main menu, select Menu >
Applications > Help and the application for which
you want to read instructions.
When an application is open, to access the help text for
the current view, select Options > Help.
When you are reading the instructions, to change the
size of the help text, select Options > Decrease font
size or Increase font size.
You may find links to related topics at the end of the
help text. If you select an underlined word, a short
explanation is displayed. Help texts use the following
indicators:
the application being discussed.
When you are reading the instructions, to switch
between help texts and the application that is open in
the background, select Options > Show open apps.
and the desired application.
Link to a related help topic. Link to
Find help
11
Accessibility solutions
Nokia is committed to making mobile phones easy to
use for all individuals, including those with disabilities.
For more information, visit the Nokia website at
Find help
www.nokiaaccessibility.com.
Do more with your device
There are various applications provided by Nokia and
third party software developers, that help you do more
with your device. To find and download applications,
visit the Ovi Store at store.ovi.com. These applications
are explained in the guides that are available on the
product support pages at www.nokia.com/support or
your local Nokia website.
Update device software
Software updates over the air
Select Menu > Applications > SW update.
With Software update (network service), you can check
if there are updates available for your device software
or applications, and download them to your device.
Downloading software updates may involve the
transmission of large amounts of data (network
service).
12
Make sure that the device battery has enough power,
or connect the charger before starting the update.
Warning: If you install a software update, you
cannot use the device, even to make emergency calls,
until the installation is completed and the device is
restarted. Be sure to back up data before accepting
installation of an update.
After updating your device software or applications
using Software update, the instructions related to the
updated applications in the user guide or the helps
may no longer be up to date.
To download the available updates, select
unmark specific updates that you do not want to
download, select the updates from the list.
To view information on an update, select the update
and
.
To view the status of previous updates, select
Select Options and from the following:
● Update via PC — Update your device using a PC.
This option replaces the Start update option when
updates are only available using the Nokia Software
Updater PC application.
● View update history — View the status of previous
updates.
● Settings — Change the settings, such as the default
access point used for downloading updates.
● Disclaimer — View the Nokia licence agreement.
. To
.
Software updates using your PC
Nokia Software Updater is a PC application that enables
you to update your device software. To update your
device software, you need a compatible PC, broadband
internet access, and a compatible USB data cable to
connect your device to the PC.
To get more information, to check the release notes for
the latest software versions, and to download the
Nokia Software Updater application, see
www.nokia.com/softwareupdate, or in Latin America,
www.nokia-latinoamerica.com/nsu.
To update the device software, do the following:
1. Download and install the Nokia Software Updater
application to your PC.
2. Connect your device to the PC using a USB data
cable, and select PC Suite mode.
3. Open the Nokia Software Updater application. The
Nokia Software Updater application guides you to
back up your files, update the software, and restore
your files.
Settings
Your device normally has MMS, GPRS, streaming, and
mobile internet settings automatically configured,
based on your network service provider information.
You may have settings from your service providers
already installed in your device, or you may receive or
request the settings from the network service
providers as a special message.
You can change the general settings in your device,
such as language, standby mode, display, and keypad
lock settings.
Access codes
If you forget any of the access codes, contact your
service provider.
● Personal identification number (PIN) code — This
code protects your SIM card against unauthorized
use. The PIN code (4 to 8 digits) is usually supplied
with the SIM card. After three consecutive incorrect
PIN code entries, the code is blocked, and you need
the PUK code to unblock it.
● UPIN code — This code may be supplied with the
USIM card. The USIM card is an enhanced version of
the SIM card and is supported by UMTS mobile
phones.
● PIN2 code — This code (4 to 8 digits) is supplied
with some SIM cards and is required to access some
functions in your device.
● Lock code (also known as security code) — The
security code helps to protect your phone against
unauthorized use. The preset code is 12345. You can
create and change the code, and set the device to
request the code. Keep the code secret and in a safe
place separate from your phone. If you forget the
Find help
13
code and your device is locked, your device will
require service and additional charges may apply.
Additional charges may apply, and all the personal
data in your device may be deleted. For more
information, contact a Nokia Care point or your
Find help
device dealer.
● Personal Unblocking Key (PUK) code and PUK2
code — These codes (8 digits) are required to
change a blocked PIN code or PIN2 code,
respectively. If the codes are not supplied with the
SIM card, contact the operator whose SIM card is in
your device.
● UPUK code — This code (8 digits) is required to
change a blocked UPIN code. If the code is not
supplied with the USIM card, contact the operator
whose USIM card is in your device.
Remote lock
To prevent unauthorised use of your device, you can
lock your device and memory card remotely using a
text message. You must define the message text, and
to lock your device, send that text message to your
device. To unlock your device, you need the lock code.
To enable remote locking, and to define the text
message, select Menu > Settings and Phone >
Phone mgmt. > Security settings > Phone and
SIM card > Remote phone locking > Enabled. Tap
14
the text input field to enter the text message content
(5-20 characters), select , and verify the message.
Enter the lock code.
Prolong battery life
Many features in your device increase the demand on
battery power and reduce the battery life time. To save
battery power, observe the following:
● Features that use Bluetooth technology, or allowing
such features to run in the background while using
other features, increase the demand on battery
power. Switch off Bluetooth when you do not need
it.
● Features that use wireless LAN (WLAN), or allowing
such features to run in the background while using
other features, increase the demand on battery
power. The WLAN on your Nokia device switches off
when you are not trying to connect, not connected
to another access point, or not scanning for
available networks. To further reduce battery
consumption, you can specify that your device not
scan, or scans less often, for available networks in
the background.
● If you have set Packet data connection to When
available in connection settings, and there is no
pa cket d ata cov erage (GP RS), the device periodically
tries to establish a GPRS connection. To prolong the
operating time of your device, select Packet data
connection > When needed.
● The Maps application downloads new map
information when you scroll to new areas on the
map, which increases the demand on battery power.
You can prevent the automatic download of new
maps.
● If the signal strength of the cellular network varies
much in your area, your device must scan for the
available network repeatedly. This increases the
demand on battery power.
If the network mode is set to dual mode in the
network settings, the device searches for the 3G
network. You can set the device to use only the GSM
network. To use only the GSM network, select
Menu > Settings and Connectivity > Network >
Network mode > GSM.
● The backlight of the display increases the demand
on battery power. In the display settings, you can
change the length of the time-out period after
which the backlight is switched off. Select Menu >
Settings and Phone > Display > Light timeout. To adjust the light sensor that observes lighting
conditions and adjusts the display brightness, in the
display settings, select Light sensor.
● Leaving applications running in the background
increases the demand on battery power. To close
the applications you are not using, if they are not
responding, select Options > Show open apps.,
and go to the application using the menu key. Press
and hold the menu key to open the application, and
select Options > Exit.
Free memory
To view how much space is available for different data
types, select Menu > Applications > Office > File
mgr..
Many features of the device use memory to store data.
The device notifies you if the memory in different
memory locations is low.
To free memory, transfer data to a compatible memory
card (if available) or to a compatible computer.
To remove data you no longer need, use File manager
or open the respective application. You can remove the
following:
● Messages in the folders in Messaging and retrieved
e-mail messages in the mailbox
● Saved web pages
● Contact information
● Calendar notes
● Applications shown in Application manager that you
do not need
● Installation files (.sis or .sisx) of applications you
have installed. Transfer the installation files to a
compatible computer.
Find help
15
● Images and video clips in Photos. Back up the files
to a compatible computer.
Find help
16
Get started
Keys and parts (top)
1 — Power key
2 — Nokia AV connector (3.5 mm) for compatible
headsets, headphones, and TV-out connectors
Keys and parts (front)
1 — Proximity sensor
2 — Earpiece
3 — Touch screen
4 — Menu key
5 — Call key
6 — Secondary camera lens
7 — Light sensor
8 — End key
Do not cover the area above the
touch screen with, for example,
protective film or tape.
Keys and parts (back)
1 — Camera flash
2 — Camera lens
3 — Lens cover
Get started
17
Keys and parts (sides)
Get started
Insert the SIM card and battery
Follow the instructions carefully, to avoid damaging
the back cover.
Always switch the device off and disconnect the
charger before removing the battery.
1. Remove the back cover by lifting it from the bottom
end of the device.
1 — Stereo speaker
2 — Micro USB connector
3 — Charging indicator light
4 — Lock switch
5 — Volume up/Zoom in key
6 — Volume down/Zoom out key
7 — Capture key
Note: The surface of this device does not
contain nickel in the platings. The surface of this device
contains stainless steel.
18
2. If the battery is inserted, lift the battery in the
direction of the arrow to remove it.
3. Pull out the SIM card holder and insert the SIM card.
Ensure that the gold-colored contact area on the
card faces downwards and that the bevelled corner
on the card faces the bevelled corner of the holder.
Push the SIM card holder back in place.
4. Align the battery contacts to the corresponding
connectors of the battery compartment, and insert
the battery in the direction of the arrow.
5. To replace the back cover, direct the top locking
hooks toward their slots first and then press down
until the cover locks into place.
Get started
Memory card
Use only compatible microSD cards
approved by Nokia for use with this device.
Nokia uses approved industry standards for
memory cards, but some brands may not be fully
compatible with this device. Incompatible cards may
damage the card and the device and corrupt data
stored on the card.
Insert the memory card
A memory card may already be in the device. If not, do
the following:
1. Remove the back cover of the device.
19
2. Insert a compatible
memory card in the slot.
Ensure that the contact
area on the card is facing
down and towards the
slot.
Get started
3. Push the card in. You can
hear a click when the card
locks into place.
4. Replace the back cover. Keep
the device facing down when
replacing the cover. Ensure
that the cover is properly
closed.
Remove the memory card
Important: Do not remove the memory card
during an operation when the card is being accessed.
Doing so may damage the memory card and the device,
and corrupt data stored on the card.
1. Before you remove the card, press the power key,
and select Remove memory card. All applications
are closed.
2. When Removing memory card will close all open
applications. Remove anyway? is displayed,
20
select Yes.
3. When Remove memory card and press 'OK' is
displayed, remove the back cover of the device.
4. Press the memory card to release it from the slot.
5. Pull out the memory card. If the device is switched
on, select OK.
6. Replace the back cover. Ensure that the cover is
properly closed.
Antenna locations
Your device may have internal and external antennas.
Avoid touching the antenna area unnecessarily while
the antenna is transmitting or receiving. Contact with
antennas affects the communication quality and may
cause a higher power level during operation and may
reduce the battery life.
Switch the device on and off
To switch on the device:
1. Press and hold the power key.
2. If the device asks for a PIN code
or lock code, enter it, and select
OK. The preset lock code is
12345. If you forget the code and
your device is locked, your device
will require service and
additional charges may apply.
For more information, contact a
Nokia Care point or your device
dealer.
To switch off the device, press the power key briefly,
and select Switch off!.
Charge the battery
Your battery has been partially charged at the factory.
There is no ne ed to ch arge t he d evice in adva nce. I f the
device indicates a low charge, do the following:
Regular charging
1. Connect the
charger to a wall
outlet.
2. Connect the
charger to the
device. The
charging indicator
light next to the USB connector is lit when the
battery is being charged.
3. When the battery is fully charged, disconnect the
charger from the device, then from the wall outlet.
You do not need to charge the battery for a specific
length of time, and you can use the device while it is
charging. If the battery is completely discharged, it
may take several minutes before the charging
indicator appears on the display or before any calls can
be made.
Tip: Disconnect the charger from the wall outlet
when the charger is not in use. A charger that is
connected to the outlet consumes power even
when it is not connected to the device.
USB charging
You can use USB charging when a wall outlet is not
available. With USB charging, you can also transfer data
while charging the device.
1. Connect a compatible USB device to your device
using a compatible USB cable.
Get started
21
Depending on the type of device that is used for
charging, it may take a while for charging to start.
2. If your device is switched on, you can select from
the available USB mode options on the display of
the device.
Get started
Note: During extended operation or charging,
the device or the charger may feel warm. In most cases,
this condition is normal. If you suspect that the device
or the charger are not working properly, take them to
the nearest authorized service facility.
Headset
You can connect a compatible headset or compatible
headphones to your device. You may need to select the
cable mode.
Warning: When you use the
headset, your ability to hear outside
sounds may be affected. Do not use
the headset where it can endanger
your safety.
Do not connect products that create
an output signal as this may cause
damage to the device. Do not
connect any voltage source to the
Nokia AV Connector.
22
When connecting any external device or any headset,
other than those approved by Nokia for use with this
device, to the Nokia AV Connector, pay special attention
to volume levels.
Attach wrist strap
1. Open the back cover.
2. Thread a wrist strap, and
tighten it.
3. Close the back cover.
Touch screen actions
Use the touch screen with your finger or with a stylus
(if available).
Important: Use only a st ylus app rove d by Nokia
for use with this device. Using any other stylus may
invalidate any warranty applying to the device and
may damage the touch screen. Avoid scratching the
touch screen. Never use an actual pen or pencil or other
sharp objects to write on the touch screen.
Tap and double-tap
To open an application or other element on the touch
screen, you normally tap it with your finger. However,
to open the following items, you must tap them twice.
● List items in an application, such as the Drafts folder
in the Messaging application.
● Files in a file list, for example, an image in the
Captured folder in the Photos application.
Tip: When you open a list view, the first item
is already highlighted. To open the
highlighted item, tap it once.
If you tap a file or similar item once, it is not opened,
but becomes highlighted. To see the options
available for the item, select Options or, if available,
select an icon from a toolbar.
Select .
In this user documentation, to open applications or
items by tapping them once or twice, you "select"
them.
Example: To select Options > Help, tap
Options, and then tap Help.
Drag
To drag, place your finger on the screen, and slide it
across the screen.
Example: To scroll
up or down on a
web page, drag the
page with your
finger.
Swipe
To swipe, slide your
finger quickly left or right on the screen.
Example: When
viewing an image,
to view the next or
previous image,
swipe left or right,
respectively.
Flick
To flick, place your finger on the screen, slide it quickly
across the screen, then quickly lift your finger. The
content of the screen will continue scrolling with the
speed and direction it had at the moment of release.
To select an item from a scrolling list and to stop the
Get started
23
movement, tap the item. In your device, flicking is
available in Music player.
Scroll
To scroll up or down in
lists that have a scroll
Get started
bar, drag the slider of the
scroll bar.
In some list views, you
can scroll your finger on
a list item and drag up or down.
Example: To scroll through contacts, place your
finger on a contact, and drag up or down.
Tip: To view a brief description of icons and
buttons, place your finger on the icon or button.
Descriptions are not available for all icons and
buttons.
Touch screen backlight
The touch screen backlight is turned off after a period
of inactivity. To turn the screen back light on, unlock the
screen and keys, if necessary, and press the menu key.
Write text
You can enter text in different modes. The full keyboard
works as a traditional keyboard, and the on-screen
alphanumeric keypad mode allow you to tap
24
characters. The handwriting recognition modes allow
you to write characters directly on the screen.
To activate text input mode, tap any text input field.
In the text input view, to switch between the available
text input modes, tap
mode.
The input methods and languages supported by the
handwriting recognition vary by region.
, and select the desired input
Keyboard input
Keyboard
Your device has a full
keyboard. To open the
keyboard, lift the touch
screen up. In all applications,
the screen rotates
automatically from portrait to
landscape when you open the
keyboard.
1 — Shift key. To change between uppercase and
lowercase modes, press the shift key twice. To enter a
single uppercase letter in lowercase mode, or a single
lowercase letter in uppercase mode, press the shift key
once, and then the desired alphabet key.
2 — Space key
3 — Sym key. To insert special characters not shown
on the keyboard, press the sym key once, and select the
desired character from the table.
4 — Function key. To insert special characters printed
at the top of keys, press the function key once, and then
press the desired key. To enter several special
characters in a row, press the function key twice
quickly. To return to normal mode, press the function
key again.
5 — Backspace key. To erase a character, press the
backspace key. To erase several characters, press and
hold the backspace key.
Insert letters not shown on the keyboard
It is possible to insert variations of letters, for example,
letters with accents. To insert á, press and hold the sym
key, and simultaneously press the A key repeatedly,
until the desired character is displayed. The order and
availability of letters depends on the selected writing
language.
Touch input
Handwriting
The input methods and languages supported by the
handwriting recognition vary by region and may not
be available for all languages.
To activate handwriting mode, select
Handwriting.
Write legible, upright characters on the text input area,
and leave a space between each character.
To teach the device your handwriting style, select
Handwriting training.
To enter letters and numbers (default mode), write
words as you would normally. To select number mode,
select
corresponding icon, if available.
To enter special characters,
write them as you would
normally, or select
desired character.
To delete characters or move
the cursor back, swipe backwards (see Figure 1).
To insert a space, swipe forwards (see Figure 2).
. To enter non-Latin characters, select the
and the
>
>
Get started
25
Touch input settings
Select Menu > Settings and Phone > Touch input.
To configure text input settings for the touch screen,
select from the following:
● Handwriting training — Open the handwriting
Get started
training application. Train the device to recognize
your handwriting better. This option is not available
in all languages.
● Writing language — Define which language-
specific characters in your handwriting are
recognized and how your on-screen keyboard is laid
out.
● Writing speed — Adjust the speed at which
handwriting is recognised.
● Guiding line — Show or hide the guiding line in
the writing area. The guiding line helps you write in
a straight line, and it also helps the device recognize
your writing. This option may not be available in all
languages.
● Pen trail width — Change the thickness of the text.
● Writing color — Change the color of the text.
Icons and functions
Use the on-screen keypad (Alphanumeric keypad) to
enter characters like you would with a traditional
phone keypad with numbers on the keys. For an
explanation of each icon and its function, see the
following figure.
26
1 — Close - Closes on-screen keypad (Alphanumeric
keypad).
2 — Input menu - Opens the touch input menu, which
includes commands such as Activate predictive text
and Writing language.
3 — Text input indicator - Opens a pop-up window, in
which you can turn predictive text input modes on or
off, change the character case, and switch between
letter and number mode.
4 — Input mode - Opens a pop-up window, in which
you can select from the available input modes. When
you tap an item, the current input method view closes,
and the selected one opens.
5 — Arrow keys - Moves the cursor left or right.
6 — Backspace - Deletes the previously entered
character.
7 — Number keys - Enters the desired numbers or
characters according to the current case and input
mode.
8 — Star - Opens a special characters table.
9 — Shift - Changes the character case, turns predictive
text input modes on or off, and switches between the
alphabet and number modes.
Lock the keys and touch screen
To lock or unlock the touch screen and the keys, slide
the lock switch on the side of the device.
When the touch screen and keys are locked, the touch
screen is switched off and the keys are inactive.
The screen and keys may be locked automatically after
a period of inactivity. To change settings for automatic
screen and key locking, select Menu > Settings and
Phone > Phone mgmt. > Auto. keyguard.
Nokia Switch
Transfer content
You can use the Switch application to copy content
such as phone numbers, addresses, calendar items,
and images from your previous Nokia device to your
device.
The type of content that can be transferred depends on
the model of the device from which you want to
transfer content. If that device supports
synchronization, you can also synchronize data
between the devices. Your device notifies you if the
other device is not compatible.
If the other device cannot be switched on without a
SIM card, you can insert your SIM card in it. When your
device is switched on without a SIM card, the Offline
profile is automatically activated, and transfer can be
done.
Transfer content for the first time
1. To retrieve data from the other device for the first
time, on your device, select Menu > Settings >
Connectivity > Data transfer > Phone switch.
2. Select the connection type you want to use to
transfer the data. Both devices must support the
selected connection type.
3. If you select Bluetooth connectivity as the
connection type, connect the two devices. To have
your device search for devices with Bluetooth
connectivity, select Continue. Select the device
from which you want to transfer content. You are
asked to enter a code on your device. Enter a code
(1-16 digits), and select OK. Enter the same code on
Get started
27
the other device, and select OK. The devices are now
paired.
Some earlier Nokia devices may not have the Switch
application. In this case, the Switch application is
sent to th e oth er device a s a message. To install the
Switch application on the other device, open the
Get started
message, and follow the instructions on the display.
4. On your device, select the content you want to
transfer from the other device.
When the transfer has started, you can cancel it and
continue later.
Content is transferred from the memory of the other
device to the corresponding location in your device.
The transfer time depends on the amount of data to be
transferred.
Synchronize, retrieve, or send content
Select Menu > Settings > Connectivity > Data
transfer > Phone switch.
After the first transfer, select from the following to start
a new transfer, depending on the model:
to synchronize content between your device and
the other device, if the other device supports
synchronization. The synchronization is two-way. If an
item is deleted in one device, it is deleted in both. You
28
cannot restore deleted items with synchronization.
to retrieve content from the other device to your
device. With retrieval, content is transferred from the
other device to your device. You may be asked to keep
or delete the original content in the other device,
depending on the device model.
to send content from your device to your other
device
If you cannot send an item, depending on the type of
the other device, you can add the item to the Nokia
folder, to C:\Nokia or E:\Nokia in your device. When
you select the folder to transfer, the items are
synchronized in the corresponding folder in the other
device, and vice versa.
Use shortcuts to repeat a transfer
After a data transfer, you can save a shortcut with the
transfer settings to the main view to repeat the same
transfer later.
To edit the shortcut, select Options > Shortcut
settings. For example, you can create or change the
name of the shortcut.
A transfer log is shown after every transfer. To view the
log of the last transfer, select a shortcut in the main
view and Options > View log.
Handle transfer conflicts
If an item to be transferred has been edited in both
devices, the device attempts to merge the changes
automatically. If this is not possible, there is a transfer
conflict. Select Check one by one, Priority to this
phone, or Priority to other phone to solve the
conflict.
Profiles
Select Menu > Settings and Profiles.
You can use profiles to set and customize the ringing
tones, message alert tones, and other tones for
different events, environments, or caller groups. The
name of the selected profile is displayed at the top of
the home screen.
To change a profile, scroll to the profile, and select
Options > Activate.
To personalize a profile, scroll to the profile, and select
Options > Customize. Select the setting you want to
change.
To set the profile to be active until a certain time within
the next 24 hours, scroll to the profile, select Options >
Timed, and set the time. When the time expires, the
profile changes back to the previously active nontimed profile. When the profile is timed,
in the home screen. The Offline profile cannot be timed.
To create a new profile, select Options > Create
new.
is displayed
Get started
29
Your device
Home screen
Your device
About the home screen
In the home screen, you can quickly access your most
frequently used applications, control applications,
such as the music player, view your favorite contacts,
and view at a glance if you have missed calls or new
messages.
Interactive home screen elements
To open the clock application, tap the clock (1).
To open calendar or change profiles in the home
screen, tap the date or the profile name (2).
To view or change connectivity settings (
the available wireless LANs if WLAN scanning is
enabled, or to view missed events, tap the top right
30
corner (3).
), to see
To make a phone call, select (4).
To open the main menu, press the menu key (5).
To hide and show content, swipe the home screen with
your finger.
Add items to the home screen
To add an item to the home screen, select Options >
Edit content > Options > Add content, and select
the item from the list. Using widgets may involve the
transmission of large amounts of data (network
service).
To move an item, select Options > Edit content,
select the desired item, and drag and drop it to a new
location.
Remove an item from the home screen.
Select Options > Edit content and the item to be
removed. Select Options > Remove > Done.
E-mail notifications
About e-mail notifications
E-mail notifications in the home screen help you keep
track of e-mail messages in your mailbox. You can set
the device to show a preview of e-mail headers or just
the number of unread e-mails.
Loading...
