Nokia N95-4 User Manual

Get started

Nokia N95-4

9207276 , Iss ue 1 EN

Keys and parts (front)

Model number: Nokia N95-4.
Hereinafter referred to as Nokia N95 8GB.

1 Power key
2 Selection keys to select commands and access Options
3 Menu key to access the main menu
4 Call key
5 Edit key to open a list of commands when you

edit text

6 Scroll key to move around the menus and to

select items

7 Numeric keypad
8 Clear key
9 End key
10 Multimedia key to access the multimedia menu and

open the music player

11 Light sensor
12 Secondary camera with lower resolution

2

Keys and parts (landscape)

1 Media keys under the 2-way slide

• Next key

• Play/pause key

• Stop key

• Previous key

2 Zoom/volume key

3 Review key to view the last stored image or

video clip

4 2-stage capture key for auto-focus, still image

capture, and video recording

When you open the media keys under the 2-way slide,
the media mode is activated and the display is shown in
landscape orientation.

Use the media keys to control music and video players.

To activate the main camera, press and hold the capture
key. To lock the focus on an object, press the capture key
halfway down. To take a picture, press the capture key down.

To activate the video mode, select in the active
toolbar. To shoot video, press the capture key down.

3

Keys and parts (back)

1 Charger connector

2 Mini-USB connector to connect to a compatible PC

3 Stereo speakers with 3D sound effect

4 Main camera for high resolution image capture and

video recording (up to 5 megapixel)

5 Camera flash

6 Nokia AV Connector (3.5 mm) for compatible headsets,

headphones, and TV-out cables, for example, the Nokia
Video Connectivity Cable

7 Infrared (IR) window

4

Insert the (U)SIM card and battery

A USIM card is an enhanced version of the SIM card and is
supported by UMTS mobile phones.

Always switch the device off and disconnect the charger before
removing the battery.

For availability and information on using SIM card services, contact
your SIM card vendor. This may be the service provider or other vendor.

1 With the back of the

device facing you, press
and hold the release
button, slide the cover,
and lift it up.

2 To release the (U)SIM

card holder, lift the
holder up from the handle.

3 Insert the (U)SIM card. Make sure that the contact area

on the card is facing the connectors on the device and
the bevelled corner on the card is facing the base of
the device.

4 Close the holder, and lock it into place.

5 Insert the battery. To secure the battery into place,

press it gently.

6 Replace the cover so that the locking catches are

directed towards their slots, and slide the cover
into place.

5
