N79 RM-348 / RM-349 / RM-350
Service Manual Level 1&2
SERVICE MANUAL
Level 1&2
RM-348 RM-349 RM-350
Transceiver characteristics
Band
RM-348
RM-349
RM-350:
Display
Camera
Operating System
Connections
Talk time Standby Note
GSM
WCDMA
GSM
WCDMA
:
GPRS/ EGPRS 850/900/1800/1900 MHz
GPRS/ EGPRS 850/900/1800/1900 MHz
: Dual mode WCDMA 900/2100 + WLAN + GSM/
: GSM/ GPRS/ EGPRS 850/900/1800/1900 MHz
Dual mode WCDMA 850/1900 + WLAN + GSM/
2.4’’ QVGA (240 x 320 pixels) Active Matrix colour
display, 16 million colours
5 Mpix with 20x digital zoom
S60 3rd edition Feature Pack 2
Transceiver with BL-6F battery pack
3.4 h
:
:
:
:
x Bluetooth 2.0 + EDR
x WLAN – IEEE 802.11 g/b with UPnP support
x Nokia 3.5 mm AV connector
x Micro USB connector (USB 2.0 (High Speed))
x MicroSD card slot
x Assisted GPS receiver
x FM RDS radio
x FM transmitter
: Up to 5.5 h
: Up to
: Up to 390
hours
406 hours
: Up to
Depends on
network
parameters and
phone settings
1
Confidential
Copyright @ 2008 NOKIA. All rights reserved
ISSUE 1
N79 RM-348 / RM-349 / RM-350
Service Manual Level 1&2
1.
Change history ................................................................................................................................3
2. Copyright ........................................................................................................................................ 4
3. Warnings and cautions.................................................................................................................... 5
3.1 Warnings .................................................................................................................................. 5
3.2 Cautions ................................................................................................................................... 5
4. ESD protection................................................................................................................................. 6
5. Care and maintenance..................................................................................................................... 7
6. Battery information......................................................................................................................... 8
7. Exploded view................................................................................................................................. 9
8. Service devices .............................................................................................................................. 10
9. SW update..................................................................................................................................... 11
10. Disassembly instruction .......................................................................................................... 12
11. Assembly hints........................................................................................................................ 20
12. Solder components ................................................................................................................. 21
2
Confidential
Copyright @ 2008 NOKIA. All rights reserved
ISSUE 1
N79 RM-348 / RM-349 / RM-350
Service Manual Level 1&2
1. CHANGE HISTORY
Status Version No. Date Comments
CMO Operation & Logistics
Training and Vendor Development
Multimedia Creation & Support
mailto:Servic
e.Manuals@nokia.com
Draft 0.2 10.09.2008 Draft
Approved 1 10.09.2008 First approved version
The purpose of this document is to help NOKIA service levels 1 and 2 workshop technicians to
carry out service to NOKIA products. This Service Manual is to be used only by authorized NOKIA
service suppliers, and the content of it is confidential. Please note that NOKIA provides also
other guidance documents (e.g. Service Bulletins) for service suppliers, follow these regularly
and comply with the given instructions.
While every endeavor has been made to ensure the accuracy of this document, some errors
may exist. If you find any errors or if you have further suggestions, please notify NOKIA using
the address below:
Please keep in mind also that this documentation is continuously being updated and modified,
so watch always out for the newest version.
3
Confidential
Copyright @ 2008 NOKIA. All rights reserved
ISSUE 1
