Nokia N77 User Manual
User guide
Nokia N77-1
DECLARATION OF CONFORMITY
04340434
provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity can be
found at http://www.nokia.com/phones/declaration_of_conformity/
© 2007 Nokia. All rights reserved.
Nokia, Nokia Connecting People, Navi, Nseries, N77, and Visual Radio are
trademarks or registered trademarks of Nokia Corporation. Nokia tune is a sound
mark of Nokia Corporation. Other product and company names mentioned herein
may be trademarks or tradenames of their respective owners
Reproduction, transfer, distribution, or storage of part or all of the contents in this
document in any form without the prior written permission of Nokia is prohibited.
Java and all Java-based marks are trademarks or registered
trademarks of Sun Microsystems, Inc.
US Patent No 5818437 and other pending patents. T9 text input software
Copyright (C) 1997-2007. Tegic Communications, Inc. All rights reserved.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for
personal and noncommercial use in connection with information which has been
encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged
in a personal and noncommercial activity and (ii) for use in connection with
MPEG-4 video provided by a licensed video provider. No license is granted or shall
be implied for any other use. Additional information, including that related to
promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC.
See <http://www.mpegla.com>.
Nokia operates a policy of ongoing development. Nokia reserves the right to make
changes and improvements to any of the products described in this document
without prior notice.
Hereby, NOKIA CORPORATION declares that this
RM-194 product is in compliance with the
essential requirements and other relevant
This product includes software licensed from Symbian
Software Ltd (c) 1998-2007. Symbian and Symbian OS are
trademarks of Symbian Ltd.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO
CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR
ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL
OR INDIRECT DAMAGES HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED
BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN
RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT.
NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY
TIME WITHOUT PRIOR NOTICE.
The availability of particular products and applications and services for these
products may vary by region. Please check with your Nokia dealer for details, and
availability of language options.
Export controls
This device may contain commodities, technology or software subject to export
laws and regulations from the US and other countries. Diversion contrary to law is
prohibited.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a
telephone in close proximity to receiving equipment). The FCC or Industry Canada
can require you to stop using your telephone if such interference cannot be
eliminated. If you require assistance, contact your local service facility. This device
complies with part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause
undesired operation. Any changes or modifications not expressly approved by Nokia
could void the user's authority to operate this equipment.
The third-party applications provided with your device may have been created and
may be owned by persons or entities not affiliated with or related to Nokia. Nokia
does not own the copyrights or intellectual property rights to the third-party
applications. As such, Nokia does not take any responsibility for end-user support,
functionality of the applications, or the information in the applications or these
materials. Nokia does not provide any warranty for the third-party applications.
BY USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE APPLICATIONS ARE
PROVIDED AS IS WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, TO THE
MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW. YOU FURTHER
ACKNOWLEDGE THAT NEITHER NOKIA NOR ITS AFFILIATES MAKE ANY
REPRESENTATIONS OR WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT
LIMITED TO WARRANTIES OF TITLE, MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, OR THAT THE APPLICATIONS WILL NOT INFRINGE ANY
THIRD-PARTY PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.
Issue 1 EN, 9200089
Contents
For your safety...........................................7
Support .....................................................10
Nokia support and contact information....................... 10
Software updates................................................................10
Help.........................................................................................10
Tutorial................................................................................... 11
Get started............................................................................11
Additional applications ..................................................... 11
Your Nokia N77.......................................12
Settings.................................................................................. 12
Transfer content from another device .......................... 12
Essential indicators............................................................. 13
Volume and loudspeaker control....................................14
Mobile TV .............................................................................. 14
Active standby mode.......................................................... 15
Multimedia key....................................................................15
Memory card tool ............................................................... 15
File manager.........................................................................16
Personalize your device..................................................... 17
Mobile search....................................................................... 17
Games.....................................................................................18
Mobile TV .................................................19
First start-up ........................................................................19
View programs .....................................................................20
Services..................................................................................20
Program guide...................................................................... 21
Search.....................................................................................21
Subscribe to channels and programs............................21
Settings..................................................................................22
Indicators...............................................................................22
Camera......................................................24
Take pictures ........................................................................24
Active toolbar....................................................................... 27
Scenes ....................................................................................28
Record videos ....................................................................... 28
Camera settings................................................................... 30
Gallery.......................................................33
View and browse media files...........................................33
Images and video clips ...................................................... 34
Free memory.........................................................................36
Edit images ...........................................................................36
Edit video clips..................................................................... 37
Print images..........................................................................39
Share images and videos online......................................41
Video calls .............................................................................71
Log...........................................................................................73
Media applications ................................. 44
Music player..........................................................................44
Visual Radio ..........................................................................52
RealPlayer ..............................................................................54
Flash Player ...........................................................................56
Internet.................................................... 57
Services...................................................................................57
Web .........................................................................................60
Download! .............................................................................62
Profiles—set tones .................................. 64
Offline profile .......................................................................64
Contacts (phonebook) ............................ 65
Save and edit names and numbers ................................65
Copy contacts.......................................................................66
Add ringing tones for contacts........................................67
Create contact groups........................................................67
Make calls ............................................... 68
Voice calls..............................................................................68
Voice dialing .........................................................................70
Voice mailbox .......................................................................71
Messaging.................................................75
Write text..............................................................................76
Write and send messages .................................................76
Inbox—receive messages...................................................78
Mailbox .................................................................................. 79
View messages on a SIM card.........................................81
Messaging settings.............................................................82
Time management ...................................87
Clock .......................................................................................87
Calendar.................................................................................87
Office........................................................89
Quickoffice............................................................................89
Notes.......................................................................................90
Recorder.................................................................................90
Adobe Reader .......................................................................90
Calculator..............................................................................91
Converter...............................................................................91
Connections..............................................92
Bluetooth connectivity......................................................92
Data cable .............................................................................95
PC connections ....................................................................96
Connection manager..........................................................96
Synchronization................................................................... 96
Device manager................................................................... 97
Tools..........................................................99
Themes ................................................................................... 99
3-D tones...............................................................................99
Voice commands ...............................................................100
Application manager........................................................100
Digital rights management ............................................103
Settings.................................................. 104
Phone....................................................................................104
Call ........................................................................................105
Connection..........................................................................106
Date and time ....................................................................109
Security................................................................................109
Call divert............................................................................112
Call barring ........................................................................112
Network ...............................................................................112
Enhancement .....................................................................113
Troubleshooting: Q&A ......................... 114
Battery information ............................. 118
Charging and discharging...............................................118
Nokia battery authentication guidelines ...................118
Care and maintenance ......................... 121
Additional safety information............. 123
Index ...................................................... 127
For your safety
Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for
further information.
SWITCH ON SAFELY Do not switch the device
on when wireless phone use is prohibited or
when it may cause interference or danger.
ROAD SAFETY COMES FIRST Obey all local
laws. Always keep your hands free to operate
the vehicle while driving. Your first
consideration while driving should be road
safety.
INTERFERENCE All wireless devices may be
susceptible to interference, which could affect
performance.
SWITCH OFF IN HOSPITALS Follow any
restrictions. Switch the device off near medical
equipment.
SWITCH OFF IN AIRCRAFT Follow any
restrictions. Wireless devices can cause
interference in aircraft.
SWITCH OFF WHEN REFUELING Do not use
the device at a refueling point. Do not use near
fuel or chemicals.
SWITCH OFF NEAR BLASTING Follow any
restrictions. Do not use the device where
blasting is in progress.
USE SENSIBLY Use only in the positions as
explained in the product documentation. Do
not touch the antenna areas unnecessarily.
QUALIFIED SERVICE Only qualified personnel
may install or repair this product.
ENHANCEMENTS AND BATTERIES Use only
approved enhancements and batteries. Do not
connect incompatible products.
WATER-RESISTANCE Your device is not
water-resistant. Keep it dry.
BACK-UP COPIES Remember to make backup copies or keep a written record of all
important information.
CONNECTING TO OTHER DEVICES When
connecting to any other device, read its user
7
guide for detailed safety instructions. Do not
connect incompatible products.
EMERGENCY CALLS Ensure the phone
function of the device is switched on and in
service. Press the end key as many times as
needed to clear the display and return to the
standby mode. Enter the emergency number,
then press the call key. Give your location. Do
not end the call until given permission to do
so.
About your device
The wireless device described in this guide is approved for
use on the EGSM 900/1800/1900 and UMTS 2100
networks. Contact your service provider for more
information about networks.
Your device supports internet connections and other
methods of connectivity. Like computers, your device may
be exposed to viruses, malicious messages and
applications, and other harmful content. Exercise caution
and open messages, accept connectivity requests,
download content, and accept installations only from
trustworthy sources. To increase the security of your
devices, consider installing, using, and regularly updating
antivirus software, firewall, and other related software on
your device and any connected computer.
When using the features in this device, obey all laws, and
respect local customs, privacy and legitimate rights of
others, including copyrights.
Copyright protections may prevent some images, music
(including ringing tones), and other content from being
copied, modified, transferred or forwarded.
Warning: To use any features in this device, other
than the alarm clock, the device must be switched on.
Do not switch the device on when wireless device use
may cause interference or danger.
The office applications support common features of
Microsoft Word, PowerPoint, and Excel (Microsoft Office
2000, XP, and 2003). Not all file formats can be viewed or
modified.
During extended operation such as an active video call and
high speed data connection, the device may feel warm. In
most cases, this condition is normal. If you suspect the
device is not working properly, take it to the nearest
authorized service facility.
Your device may have some bookmarks or links preinstalled
for or may allow access to sites provided by third parties
not affiliated with Nokia. Nokia does not endorse or
assume any liability for these sites. If you choose to access
them, you should take the same precautions, for security or
content, as you would with any internet site.
8
Network services
To use the phone you must have service from a wireless
service provider. Many of the features require special
network features. These features are not available on all
networks; other networks may require that you make
specific arrangements with your service provider before
you can use the network services. Your service provider can
give you instructions and explain what charges will apply.
Some networks may have limitations that affect how you
can use network services. For instance, some networks may
not support all language-dependent characters and
services.
Your service provider may have requested that certain
features be disabled or not activated in your device. If so,
these features will not appear on your device menu. Your
device may also have a special configuration such as
changes in menu names, menu order, and icons. Contact
your service provider for more information.
This device supports WAP 2.0 protocols (HTTP and SSL) that
run on TCP/IP protocols. Some features of this device, such
as MMS, browsing, e-mail, and content downloading using
the browser or over MMS, require network support for
these technologies.
For availability and information on using SIM card services,
contact your SIM card vendor. This may be the service
provider or other vendor.
Enhancements, batteries, and
chargers
Always switch the device off and disconnect the charger
before removing the battery.
Check the model number of any charger before use with
this device. This device is intended for use when supplied
with power from a AC-4 or DC-4 charger and from an
AC-1, ACP-7, ACP-8, ACP-9, ACP-12, LCH-9, or LCH-12
charger when used with a CA-44 charger adapter.
The battery intended for use with this device is BP-6M.
Warning: Use only batteries, chargers, and
enhancements approved by Nokia for use with this
particular model. The use of any other types may
invalidate any approval or warranty, and may be
dangerous.
For availability of approved enhancements, please check
with your dealer. When you disconnect the power cord of
any enhancement, grasp and pull the plug, not the cord.
9
Support
Support
10
Nokia support and contact information
Check www.nokia.com/support or your local Nokia
website for the latest version of this guide, additional
information, downloads, and services related to your
Nokia product.
On the website, you can get information on the use of
Nokia products and services. If you need to contact
customer service, check the list of local Nokia contact
centers at www.nokia.com/customerservice.
For maintenance services, check your nearest Nokia
service center at www.nokia.com/repair.
Software updates
Nokia may produce software updates that may offer new
features, enhanced functions, or improved performance.
You may be able to request these updates through the
Nokia Software Updater PC application. To update the
device software, you need the Nokia Software Updater
application and a compatible PC with Microsoft Windows
2000 or XP operating system, broadband internet access,
and a compatible data cable to connect your device to the
PC.
To get more information and to download the
Nokia Software Updater application, visit www.nokia.com/
softwareupdate or your local Nokia website.
If software updates over the air are supported by your
network, you may also be able to request updates through
the device. See ‘Device manager’, ‘Software updates’, p.
97.
Help
Your device has context-sensitive help. When an
application is open, select Options > Help to access help
for the current view.
When you are reading the instructions, to switch between
help and the application that is open in the background,
press and hold , and select the application or help.
To open help from the main menu, select Applications >
Help. Select the desired application to view its help topics.
Tutorial
The tutorial gives you information about some of the
features of your device. To access the tutorial, press ,
and select Applications > Tutorial and the section you
want to view.
Get started
See the Get started guide for keys and parts information
and instructions for setting up the device for use.
Additional applications
There are various applications provided by Nokia and
different third-party software developers to help you do
more with your Nokia N77. These applications are
explained in the guides which are available at the Nokia
N77 product support pages at www.nokia.com/support or
your local Nokia website.
Support
11
Your Nokia N77
Model number: Nokia N77-1.
Hereinafter referred to as Nokia N77.
The images in this guide may differ from your device
display.
Your Nokia N77
Settings
Your device normally has MMS, GPRS, streaming, and
mobile internet settings automatically configured in the
device, based upon your network service provider
information. You may have settings from your service
providers already installed in your device, or you may
receive the settings from the service providers as a special
text message.
To change the general settings in your device, such as
language, standby mode, and display settings, see
‘Settings’, ‘Phone’, p. 104.
Transfer content from another device
You can transfer content, such as contacts, from a
compatible Nokia device to your Nokia N77 using
12
Bluetooth connectivity. Your device notifies you if the
other device is not compatible. The type of content that
can be transferred depends on the model of the device
from which you want to transfer content. If the other
device supports synchronization, you can also synchronize
data between the other device and your Nokia N77.
If the other device cannot be powered on without a SIM
card, you can insert your SIM card in the other device.
When Nokia N77 is switched on without a SIM card, the
offline profile is automatically activated.
Transfer content
1 To use the application for the first time, press , and
select Tools > Transfer. If you have used the
application before and want to start a new transfer,
select Transfer data. Follow the instructions on the
display.
2 To have Nokia N77 search for devices with Bluetooth
connectivity, select Continue. Select the device from
which you want to transfer content from the list.
3 You are asked to enter a code on your Nokia N77. Enter
a code (1–16 digits), and select OK. Enter the same
code on the other device, and select OK. The devices are
now paired. See ‘Pair devices’, p. 94.
For some phone models, Transfer is sent to the other
device as a message. To install Transfer on the other
device, open the message, and follow the instructions
on the display.
4 From your Nokia N77, select the content you want to
transfer from the other device.
Content is transferred from the memory of the other device
to the corresponding location in your Nokia N77.
Transferring time depends on the amount of data to be
transferred. You can cancel transferring and continue
later.
If the other device supports synchronization, you can keep
the data up-to-date in both devices. To start a
synchronization with a compatible Nokia device, select
Phones, scroll to the device, and select Options >
Synchronise. Follow the instructions on the display.
To view the log of a previous transfer, select Transfer log.
Essential indicators
The device is being used in a GSM network.
The device is being used in a UMTS network (network
service).
You have one or more unread messages in the Inbox
folder in Messaging.
You have received new e-mail in the remote mailbox.
There are messages waiting to be sent in the outbox
folder.
You have missed calls.
Shown if Ringing type is set to Silent and Message
alert tone, IM alert tone, and E-mail alert tone are set
to Off.
The device keypad is locked.
A clock alarm is active.
The second phone line is being used (network service).
All calls to the device are diverted to another
number. If you have two phone lines (network service), the
indicator for the first line is and for the second
.
A compatible headset is connected to the device.
The connection to a compatible headset with
Bluetooth connectivity has been lost.
A compatible loopset is connected to the device.
A compatible text phone is connected to the device.
A data call is active.
A GPRS packet data connection is active. indicates
the connection is on hold and that a connection is
available.
Your Nokia N77
13
A packet data connection is active in a part of the
network that supports EDGE. indicates the connection
is on hold and that a connection is available. The icons
indicate that EDGE is available in the network, but your
device is not necessarily using EDGE in the data transfer.
A UMTS packet data connection is active. indicates
the connection is on hold and that a connection is
Your Nokia N77
available.
Bluetooth connectivity is on.
Data is being transmitted using Bluetooth
connectivity.
A USB connection is active.
Mobile TV is on.
Volume and loudspeaker control
To increase or decrease the
volume level when you have
an active call or are listening
to a sound, press the volume key on the side of the device.
The built-in loudspeaker allows you to speak and listen
from a short distance without having to hold the device
to your ear.
Warning: Do not hold the device near your ear when
the loudspeaker is in use, because the volume may be
extremely loud.
To use the loudspeaker during a call, select Options >
Activate loudsp..
To turn off the loudspeaker, select Options > Activate
handset.
Mobile TV
Your device has an integrated Digital Video Broadcast Handheld (DVB-H) receiver, which enables it to receive live
digital TV broadcasts. With the Mobile TV application you
can watch and listen to digital TV programs (network
service). You may have to subscribe to channels or
programs before you can watch them. Press and hold the
Mobile TV key to open the application.
14
Active standby mode
Use your standby display for
fast access to your most
frequently used applications.
By default, the active standby
mode is on.
Press , select Tools >
Settings > Phone > Standby mode > Active standby, and
press to switch the active
standby on or off.
The active standby display is
shown with default
applications across the top of the screen, and calendar,
to-do, print basket, and player events listed below.
Scroll to an application or event, and press .
The standard scroll key shortcuts available in the standby
mode cannot be used when the active standby mode is on.
To change the default applications’ shortcuts, press ,
select Tools > Settings > Phone > Standby mode >
Active standby apps., and press .
Some shortcuts may be fixed, and you are not able to
change them.
Multimedia key
With the multimedia key, you have a quick access to
multimedia content and predefined applications.
To open the shortcut assigned to the multimedia key, press
and hold . To open a list of multimedia applications,
press . To open the desired application, use the scroll
key. To exit the list without selecting an application, press
.
To change the shortcuts, press , and . To change the
applications that are shown when you press , select
Top, Left, Middle, and Right and the application.
Some shortcuts may be fixed, and you are not able to
change them.
Memory card tool
Use only compatible microSD cards approved by Nokia for
use with this device. Nokia uses approved industry
standards for memory cards, but some brands may not be
fully compatible with this device. Incompatible cards may
damage the card and the device and corrupt data stored
on the card.
Your Nokia N77
15
Press , and select Tools > Memory. Use a compatible
microSD card as extra storage space and for backing up
the information in the device memory.
To back up information from the device memory to a
compatible memory card, select Options > Backup phone
mem.
To restore information from the compatible memory card
Your Nokia N77
to the device memory, select Options > Restore from
card.
To eject the memory card, press , and select Remove
mem. card.
Important: Do not remove the memory card in the
middle of an operation when the card is being accessed.
Removing the card in the middle of an operation may
damage the memory card as well as the device, and data
stored on the card may be corrupted.
To set a password to protect your memory card, select
Options > Set password. Use up to 8 characters in the
password. You can change or remove the password later.
Format a memory card
When a memory card is reformatted, all data on the card
is permanently lost. Some memory cards are supplied
preformatted and others require formatting. Consult your
retailer to find out if you must format the memory card
before you can use it.
To format a memory card, select Options > Format mem.
card. Select Yes to confirm.
File manager
To browse files and folders in the device memory or on a
compatible memory card (if inserted), press , and select
Tools > File mgr.. The device memory view ( ) opens.
Press to open the memory card view ( ), if available.
To move or copy files to a folder, press and at the
same time to mark a file, and select Options > Move to
folder or Copy to folder.
To find a file, select Options > Find and the memory from
which to search, and enter a search text that matches the
file name.
To view what types of data you have in the device and how
much memory the different data types consume, select
Options > Memory details. The amount of available free
memory is shown in Free memory.
16
Memory low—free memory
Many features of the device use memory to store data. The
device notifies you if the device or the memory card
memory is low.
To free device memory, transfer data to a compatible
memory card, if you have one. Mark files to be moved, and
select Options > Move to folder > Memory card and a
folder.
To remove data to free memory, select File manager or the
respective application. For example, you can remove the
following:
• Messages from Inbox, Drafts, and Sent folders in
Messag.
• Retrieved e-mail messages from the device memory
• Saved web pages
• Saved images, videos, or sound files
• Contact information
•Calendar notes
• Downloaded applications. See also ‘Application
manager’, p. 100.
• Installation files (.sis) of applications you have installed
to a compatible microSD card; first back up the
installation files to a compatible PC using Nokia
Nseries PC Suite.
• Any other data that you no longer need
Personalize your device
• Use the standby display for fast access to your most
frequently used applications. See ‘Active standby
mode’, p. 15.
• To change the standby mode background image or
what is shown in the screen saver, see ‘Themes’, p. 99.
• To customize the ringing tones, see ‘Profiles—set
tones’, p. 64 and ‘Add ringing tones for contacts’, p. 67.
• To change the shortcuts assigned for the different
presses of the scroll key and left and right selection
keys in the standby mode, see ‘Standby mode’, p. 104.
• To change the clock shown in the standby mode, press
, and select Applications > Clock > Options >
Settings > Clock type > Analogue or Digital.
Mobile search
Use Mobile Search to get access to search engines, and
find and connect to local services, web sites, images, and
mobile content.
Press , and select Search. A list of categories is
displayed. Select a category (for example, images), and
enter your text into the search field. Select Search. The
search results are displayed on the screen.
Your Nokia N77
17
Games
Press , and select Games and a game. For
instructions on how to play the game, select Options >
Help.
Your Nokia N77
18
Mobile TV
Your Nokia N77 has an integrated Digital Video Broadcast
- Handheld (DVB-H) receiver, which enables it to receive
digital TV broadcasts. With Mobile TV, you can access
mobile television and radio services (network service) and
watch and listen to digital TV programs.
If you do not have access to a Mobile TV service, the
operators in your area may not support Mobile TV services.
Mobile TV services may only be available upon
subscription. Check the Mobile TV network coverage and
the availability of and instructions on accessing the
services and pricing with your service provider.
In some countries owners of a television receiver are
required to pay a television licence fee. Contact your local
authorities for more information.
You cannot watch live TV without a SIM card or when the
offline profile is activated.
If you need to change your device or your SIM card,
contact your service provider for the availability of the
service. You may have to resubscribe to the service.
The TV program content provider or the Mobile TV service
provider may prevent or limit the use of external devices
with Bluetooth wireless technology when Mobile TV is
used. For example, broadcast reception may be stopped if
you are using a headset with Bluetooth wireless
technology.
If you answer a call while watching live TV, broadcast
reception is interrupted, but resumes after you finish the
call.
First start-up
1 To open Mobile TV, press and hold the Mobile TV key
. The system shows the program guides
available in your location. In the first start-up, this may
take a few minutes.
2 To select a program guide, scroll to it, and press . The
system arranges the available channels. This may take
some time. You can change the program guide later in
the settings.
The last selected program guide and the last watched TV
channel are shown the next time you open Mobile TV.
If the device cannot find any program guides when you
open Mobile TV, select Options > Rescan to search for
and display the available program guides; select one of the
guides.
Mobile TV
19
Mobile TV uses a large amount of device memory to store
the program guide. The device attempts to update the
program guide periodically even if Mobile TV is not on. If
there is not enough memory for the update, the device
notifies you that device memory is low. Remove data to
Mobile TV
free memory. For information on how to free device
memory, see “Memory low—free memory”, p. 17.
View programs
You may have to subscribe to a channel before you can
view it. See ‘Subscribe to channels and programs’, page
21.
You may be able to preview a program that you have not
subscribed to. Select Options > Preview, if available.
To select a channel, scroll to it, and press , or press the
number keys. Press to enter two-digit channel
numbers.
To change the channel, scroll left or right.
To change the order of the channels, select Options >
Settings. See ‘Settings’, p. 22.
To switch between landscape and portrait views, select
Options > Display mode > Landscape or Portrait.
To switch to full screen, select Options > Full screen. To
return to normal screen, select Options > Normal screen.
Tip: Press to quickly switch between full and
normal screens.
To view the web page of your service provider, select
Options > Provider page. The menu command may vary.
Access to the provider web page may require a network
connection.
To adjust the volume, use the volume key. To mute and
unmute the sound, select Options > Mute or Unmute.
Warning: Do not hold the device near your ear when
the loudspeaker is in use, because the volume may be
extremely loud.
To replay the last 30 seconds, select Options > Replay, if
available.
Services
Channels may offer additional interactive services, such as
web links or possibilities to purchase or vote for something
or install and use Java
Important: Only install and use applications and
other software from trusted sources, such as applications
that are Symbian Signed or have passed the Java Verified
testing
TM
applications.
TM
20
To view the available services of the channel you are
currently viewing, select Options > Services. Services vary,
and many TV programs may not include services.
Additional charges may apply for using the network
required to access the services.
Program guide
To view the program guide, select Options > Programme
guide. To change the channel in the program guide, scroll
right or left. To view programs, scroll up or down. Programs
are arranged according to their starting time.
To watch the currently running program, select Options >
Watch programme.
To set a reminder for an upcoming program, select
Options > Remind. indicates a program with a
reminder. To define the time before the start of the
program that the reminder goes off, see ‘Settings’, p. 22.
Active reminders may not work if you change the program
guide or if a program is removed from the program guide.
The reminder does not sound if the device is turned off.
To remove a reminder in a program guide, select the
reminder and Options > Remove reminder.
To view details on a program, select a program from the
program guide, and Options > Programme details.
Search
To search a string of characters in the currently selected
program guide, do the following
1 Select Options > Search.
2 Enter the search term, or press to select from your
previous search terms. You can limit the search to a
specific channel, or specify a weekday or a genre for
the search.
3 Select Find to start the search.
4 Select a found program and Options to watch or listen
to the program, subscribe to it, view the details, or set
a reminder.
Subscribe to channels and
programs
Some TV channels and programs may require a
subscription. Unsubscribed items are indicated with . A
channel package is a set of channels that you can
subscribe to as one package.
To view a list of items you have subscribed, select
Options > Subscriptions > My subscriptions. To retrieve
subscribed items in case they have been lost from the
device, select Options > Retrieve subscriptions.
To subscribe to an item, do the following:
Mobile TV
21
1 Select Options > Subscriptions > New subscription.
2 Select from a list of unsubscribed items: Channel
pckgs., Channels, or Programmes.
3 Select Options > Subscribe.
4 Select the length of the subscription.
Mobile TV
5 To accept the subscription, select Verify.
A note is displayed when you can start watching the
channel or program.
You cannot subscribe without a SIM card or when the
offline profile is activated. If you change SIM cards, you
must re-subscribe to channels and programs.
End subscriptions
1 Select Options > Subscriptions > My subscriptions.
2 Select Channel pckgs., Channels, or Programmes.
3 To view the details of an item, select Options > Item
details.
To end your continuous subscription, select Options >
Unsubscribe.
Settings
To configure the Mobile TV settings, select Options >
Settings. Define the following:
System status—View the general status of the Mobile TV
and the signal strength. To update the signal strength
indicator, close this dialog and open it again.
Channel order—Change the default channel order. Select
Options > Mark to mark the items you want to move,
select Options > Move, scroll to the new location, and
select OK.
Parental control—Set an age limit on programs. The
required password is the same as the device lock code. You
must enter the lock code to view any TV program with a
higher age limit. For more information on lock code, see
“Security”, p. 109.
Reminder alarm—Define how early you want to be
reminded of a program start.
Programme guide—View the available program guides and
change the current program guide.
Indicators
—Channel package
—Channel
—Program
—Unsubscribed item
—Messaging service
22
—Phone service
—Web service
—Java service
—Age limit
Mobile TV
23
Camera
Camera
24
Your Nokia N77 has two cameras, a high resolution
camera on the back of the device (the main camera) and
a lower resolution camera on the front (the secondary
camera). You can use both cameras to take still pictures
and record videos. The secondary camera on the front is
used in portrait mode, and the main camera on the back
in landscape mode.
The Nokia N77 device supports an image capture
resolution of 1600x1200 pixels using the main camera.
The image resolution in these materials may appear
different.
The images and video
clips are automatically
saved in Images & video
in Gallery. The cameras
produce .jpeg images.
Video clips are recorded
in the .mp4 file format, or
in the 3GPP file format
with the .3gp file
extension (sharing
quality). See ‘Video settings’, p. 31.
You can send images and video clips in a multimedia
message, as an e-mail attachment, or by using Bluetooth
connectivity. You can also upload them to a compatible
online album. See ‘Share images and videos online’, p. 41.
Take pictures
When taking a picture, note the following:
• Use both hands to steady the camera.
• To zoom in or out, use the zoom key on the side of your
device. The quality of a digitally zoomed picture is
lower than that of a nonzoomed picture.
• To make lighting and color adjustments before taking a
picture, use the active toolbar. See ‘Setup settings—
adjust color and lighting’, p. 30. Saving the captured
image may take longer if you change the zoom,
lighting, or color settings.
• The camera goes into the battery saving mode if there
are no keypresses for a moment. To continue taking
pictures, press .
To take a picture, do the following:
1 To activate the main camera, press and hold the
capture key, or press , and select Applications >
Camera.
2 If the camera is in Video mode, select Switch to image
mode from the active toolbar.
3 To take a picture, in the main camera, press the capture
key. In the secondary camera, press . Do not move
the device before the image is saved.
To free memory before taking a picture, select Options >
Go to free memory (only available if you have backed up
images or video clips). See ‘Free memory’, p. 36.
To activate the front camera, select Options > Use
secondary camera.
To close the camera, select Exit.
Still image camera indicators
The still image camera viewfinder displays the following:
• The current capture mode indicator (1).
•The active
toolbar (2),
which you can
scroll through
before
capturing the
image to
select the
scene and
flash mode,
activate the
self-timer or sequence mode, or select the exposure
compensation, white balance, and color tone (the
active toolbar is not displayed during image capture).
See ‘Active toolbar’, p. 27.
• The image resolution indicator (3) indicates whether
the quality of the image is Print 2M - Large, Print 1M
- Medium, or MMS 0.3M - Small.
• The image counter (4) displays the estimated number
of images you can capture using the current image
quality setting and memory in use (the counter is not
displayed during image capture).
• The device memory ( ) and memory card ( )
indicators (5) show where images are saved.
To display all viewfinder indicators, select Options >
Show icons. To display only the camera status indicators,
select Hide icons.
After taking a picture
After you take the picture, in the active toolbar, select
from the following (toolbar available only if Show
captured image is set to On in still image camera
settings):
• If you do not want to keep the image, select Delete.
• To send the image using a multimedia message, e-mail,
Bluetooth connectivity, or upload it to a compatible
online album, press the call key, or select Send. For
more information, see ‘Messaging’, p. 75, ‘Bluetooth
connectivity’, p. 92, and ‘Share images and videos
Camera
25
online’, p. 41. This option is not available during an
active call.
• To send the image to a call recipient during an active
Camera
call, select Send to caller (only available during an
active call).
• To tag images to the print basket for later printing,
select Add to Print Basket.
• To print the picture, select Print. See ‘Image print’,
p. 39.
• To capture a new image, select New image.
To rename the image, select Options > Rename image.
To use the picture as wallpaper in the active standby,
select Options > Set as wallpaper.
Take pictures in sequence
The sequence mode is available only in the main camera.
To set the camera to take six pictures or the desired
number of pictures in sequence (if enough memory is
available), in the active toolbar, select Sequence mode.
To take six pictures, select Burst > OK. To capture the
pictures, press the capture key.
To take two or more pictures in a sequence, select the
desired time lapse, and OK. To capture pictures using the
selected time lapse, press the capture key. To stop taking
pictures, select Cancel. You can capture up to 100 images,
depending on the available memory.
After you take the pictures in the burst mode, they are
shown in a grid on the display. To view a picture, press
to open it. If you used a time lapse, only the last taken
picture is shown on the display. To view the other pictures,
select Options > Go to Gallery.
You can also use the sequence mode with the self-timer.
When using the self-timer, the maximum number of
pictures is six.
To return to the sequence mode viewfinder, press the
capture key.
You in the picture—self-timer
The self-timer is available only in the main camera.
Use the self-timer to delay the capture so that you can
include yourself in the picture. To set the self-timer delay,
in the active toolbar, select Self timer > 2 seconds, 10
seconds, or 20 seconds. To activate the self-timer, select
Activate. The device beeps when the timer is running. The
camera takes the picture after the selected delay elapses.
To switch off Self timer, in the active toolbar, select Self
timer > Off.
You can also use the self-timer in the sequence mode.
26
Tip! In the active toolbar, select Self timer > 2
seconds to keep your hand steady when taking a
picture.
Flash
The flash is available only in the main camera.
Keep a safe distance when using the flash. Do not use the
flash on people or animals at close range. Do not cover the
flash while taking a picture.
The camera has an LED flash for low light conditions. The
following flash modes are available for the still image
camera: Automatic (), On (), and Off ().
To change the flash mode, in the active toolbar, select the
desired flash mode.
Active toolbar
Use the active toolbar as a shortcut to select items and
adjust different settings before and after taking a picture
or recording a video. The available options may vary
depending on the capture mode and view you are in.
If you want the active toolbar to be visible on the display
before and after taking a picture or recording a video,
select Options > Show icons.
If you want the active toolbar to be visible only a while
when you need it, select Options > Hide icons. To activate
the active toolbar again, press .
Before taking a picture or recording a video, in the active
toolbar, select from the following:
to switch between
the video and image
modes
to select the scene
to select the flash
mode
to activate the selftimer (images only). See
‘You in the picture—selftimer’, p. 26.
to activate the sequence mode (images only). See
‘Take pictures in sequence’, p. 26.
to adjust the exposure compensation (images only)
to adjust white balance
to select a color effect
The icons change to reflect the current status of the
setting.
Camera
27
See also active toolbar options in ‘After taking a picture’,
p. 25, ‘After recording a video’, p. 29, and ‘Active toolbar’,
p. 35 in Gallery.
Camera
Scenes
A scene helps you to find the right color and lighting
settings for the current environment. The settings of each
scene have been set according to a certain style or
environment.
Scenes are only available in the main camera.
In the active toolbar, select Scene modes, and from the
following options:
Automatic ( ) (default), User defined (), Portrait
(), Landscape (), Night (), and Night portrait
() (images only).
To make your own scene suitable for a certain
environment, scroll to User defined, and select Options >
Change. In the user defined scene you can adjust different
lighting and color settings. To copy the settings of another
scene, select Based on scene mode and the desired scene.
Record videos
1 To activate the main camera, press and hold the
capture key, or press , and select Applications >
Camera.
2 If the camera is in the Image mode, select Switch to
video mode from the active toolbar.
3 To start recording, press the capture key. In the portrait
mode, press . The red record icon is shown and a
tone sounds, indicating that recording has started.
4 To pause recording at any time, select Pause. The pause
icon ( ) blinks on the display. Video recording
automatically stops if recording is set to pause and
there are no keypresses within a minute. To resume
recording, select Continue.
5 To stop recording, select Stop. The video clip is
automatically saved to Images & video in Gallery. See
‘Gallery’, p. 33. The maximum length of the video is 60
minutes (if enough memory is available).
To zoom in or out, use the zoom key on the side of the
device.
To make lighting and color adjustments before recording a
video, use the active toolbar. See ‘Setup settings—adjust
color and lighting’, p. 30 and ‘Scenes’, p. 28.
To free memory before recording a video, select Options >
Go to free memory (only available if you have backed up
images or video clips). See ‘Free memory’, p. 36.
28
To activate the front camera, select Options > Use
secondary camera.
Video capture indicators
The video viewfinder displays the following:
• The current capture mode indicator (1).
• The audio mute on indicator (2).
• The active toolbar (3), which you can scroll through
before recording to select the scene, white balance, and
color tone (the toolbar is not displayed during
recording).
• The video clip file type (4).
• The total
available
video
recording
time (5).
When you are
recording, the
current video
length
indicator also
shows the
elapsed time and time remaining.
• The device memory ( ) and memory card ( )
indicators (6) show where videos are saved.
To display all viewfinder indicators, select Options >
Show icons. Select Hide icons to display only the video
status indicators, and during the recording, the available
record time, zoom bar when zooming, and the selection
keys.
To activate the front camera, select Options > Use
secondary camera.
After recording a video
After you record a video clip, select the following from the
active toolbar (available only if Show captured video is
set to On in video settings):
• To immediately play the video clip you just recorded,
select Play.
• If you do not want to keep the video, select Delete.
• To send the video clip in a multimedia message, using
e-mail or Bluetooth connectivity, or upload it to a
compatible online album, press the call key, or select
Send. For more information, see ‘Messaging’, p. 75,
‘Bluetooth connectivity’, p. 92, and ‘Share images and
videos online’, p. 41. This option is not available during
an active call. You cannot send video clips saved in the
.mp4 file format in a multimedia message.
• To send the video clip to a call recipient during an
active call, select Send to caller (only available during
an active call).
• To record a new video clip, select New video.
Camera
29
To rename the video, select Options > Rename video.
Camera settings
Camera
There are two kinds of settings for the camera: setup
settings and main settings. To adjust image or video setup
settings, see ‘Setup settings—adjust color and lighting’,
p. 30. To change the main settings, see ‘Still image camera
settings’, p. 30, or ‘Video settings’, p. 31.
The setup settings return to the default settings after you
close the camera, but the main settings remain the same
until you change them again.
Setup settings—adjust color and lighting
To enable the camera to reproduce colors and lighting
more accurately, or to add effects to your pictures or
videos, use the scroll key to scroll through the active
toolbar, and select from the following options:
White balance—Select the current lighting condition
from the list. This allows the camera to reproduce colors
more accurately.
Exposure compensation (images only)—Adjust the
exposure time of the camera.
Colour tone—Select a color effect from the list.
The screen display changes to match any settings you
make, so that you see how the change affects the pictures
or videos.
The available settings vary depending on the selected
camera.
The setup settings affect both the cameras; if you change
the settings in the secondary camera, the settings in the
main camera change too. The setup settings return to the
default settings when you close the camera.
If you select a new scene, the color and lighting settings
are replaced by the selected scene. See ‘Scenes’, p. 28. You
can change the setup settings after selecting a scene if
needed.
Still image camera settings
To change the still image camera main settings, select
Options > Settings and from the following:
Image quality—Print 2M - Large (1600x1200 resolution),
Print 1M - Medium (1152x864 resolution), or MMS
0.3M - Small (640x480 resolution). The better the image
quality, the more memory the image consumes. If you
want to print the image, select Print 2M - Large or Print
1M - Medium. If you want to send it through e-mail,
select Print 1M - Medium. To send the image through
MMS, select MMS 0.3M - Small.
30
Loading...
