Nokia E600 User Manual

Nokia E6-00 User Guide
Issue 2.1
2Contents

Contents

Safety 5
Get started 7
Keys and parts 7 Insert the SIM card and battery 10 Insert or remove the memory card 12 Charging 14 Switch the phone on or off 15 Lock or unlock the keys and screen 16 Antenna locations 16 Change the volume of a call, song, or video 17 Attach the wrist strap 17 Headset 18 Use your phone for the first time 18 Copy contacts or photos from your old phone 19 Access codes 20 Use the user guide in your phone 20
Install Nokia Suite on your computer 21
Basic use 22
Touch screen actions 22 Use shortcuts 23 Switch between open applications 24 Write text 25 Keyboard shortcuts 25 General icons 27 Network icons 27 Bluetooth and USB icons 28 Set your phone to blink for missed calls or messages 28 Search your phone and the internet 28 Use your phone offline 29 Prolong battery life 29 If your phone stops responding 31
Personalise your phone 31
Profiles 31 Change your theme 32 Home screen 33 Organise your apps 35 Download a game, app, or other item 36
Calls 36
Call a phone number 36 Search for a contact 36 Call a contact 37 Mute a call 37 Make a video call 37 Make a conference call 38 Call the numbers you use the most 39 Use your voice to call a contact 40 Make calls over the internet 41 Call the last dialled number 41 Record a phone conversation 42 Turn to silence your phone 42 View your missed calls 42 Call your voice mailbox 43 Forward calls to your voice mailbox or another phone number 43 Prevent making or receiving calls 43 Allow calls only to certain numbers 44
Contacts 45
About Contacts 45 Save phone numbers and mail addresses 45 Save a number from a received call or message 45 Contact your most important people quickly 46 Add your important contacts to the home screen 46 Set a ringtone for a contact 46 Add a picture for a contact 47 Send your contact information using My Card 47 Create a contact group 47
Contents 3
Send a message to a group of people 48 Copy contacts from the SIM card to your phone 48 Back up your contacts to Nokia services 48
Messaging 48
About Messaging 48 Send a message 49 Send an audio message 50 Read a received message 50 View a conversation 51 Listen to a text message 51 Change the writing language 52
Mail 52
About Mail 52 Get a free mail account from Nokia 52 About Exchange ActiveSync 52 Add a mailbox 53 Read a received mail 53 Send a mail 54 Respond to a meeting request 55 Open mail from the home screen 55
Internet 55
About the web browser 55 Browse the web 56 Add a bookmark 57 Subscribe to a web feed 57 Allow a website to use your location info 57 Unreadable characters while browsing the web 58
Social networks 58
About Social 58 See your friends' status updates in one view 59 Post your status to social networking services 59
Link your online friends to your contacts list 59 See your friends' status updates on the home screen 59 Upload a photo or video to a service 60 Share your location in your status update 60 Contact a friend from a social networking service 61 Add an event to your phone calendar 61
Camera 61
About the camera 61 Take a photo 61 Save location info to your photos and videos 62 Take a photo in the dark 63 Photo and video tips 63 Record a video 64 Send a photo or video 64 Share a photo or video directly from the camera 65
Your photos and videos 65
About Gallery 65 View photos and videos 66 Edit a photo you have taken 67 Video editor 67 View photos and videos on a TV 68
Videos and TV 69
Videos 69 Watch Web TV 70
Music and audio 71
Music player 71 Protected content 73 Record sounds 73 FM radio 73
Maps 75
About Maps apps 75
4Contents
Navigate to your destination 76 Find and view locations 81 Save and share places 85 Report incorrect map information 86
Time management 87
Clock 87 Calendar 89
Office 92
Quickoffice 92 Read PDF documents 94 Calculator 94 Write notes 95 Translate words 95 Open or create zip files 95 Chat with your colleagues 96
Connectivity 96
Connectivity security 96 Select a network manually 97 Internet connections 97 Wireless LAN 98 Bluetooth 100 USB data cable 103 Close a network connection 104
Phone management 105
Keep your phone software and applications up to date 105 Manage files 106 Free up phone memory 108 Manage applications 108 Synchronise content 109 Copy contacts or pictures between phones 110 Protect your phone 110 Restore original settings 112 Prepare your phone for recycling 112
Nokia original accessories 113
Practical rules about accessories 113 Battery 114
Product and safety information 114
Index 132
Find more help 113
Support 113
Safety 5

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. For further information, read the complete user guide.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when mobile phone use is not allowed or when it may cause interference or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or blasting areas. Obey all instructions in restricted areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

BATTERIES, CHARGERS, AND OTHER ACCESSORIES

Use only batteries, chargers, and other accessories approved by Nokia for use with this device. Do not connect incompatible products.

KEEP YOUR DEVICE DRY

Your device is not water-resistant. Keep it dry.

GLASS PARTS

The device screen is made of glass. This glass can break if the device is dropped on a hard surface or receives a substantial impact. If the glass breaks, do not touch the glass parts of the device or attempt to remove the broken glass from the device. Stop using the device until the glass is replaced by qualified service personnel.
6Safety

PROTECT YOUR HEARING

Listen to a headset at a moderate level, and do not hold the device near your ear when the loudspeaker is in use.

Get started

Keys and parts Top
1 Memory card slot 2 Nokia AV connector (3.5 mm) 3 Power key

Front

1 Earpiece 2 Display 3 Navi™ key (scroll key). Also used to take pictures. 4 Home key 5 Call key 6 Calendar key 7 Keyboard 8 Microphone 9 Contacts key 10 End key 11 Mail key 12 Front camera lens 13 Ambient light/Proximity sensor
Get started 7
8Get started

Back

1 Loudspeaker 2 Camera flash 3 Camera lens 4 Back cover release latch 5 Wrist strap hole
If there is protective tape on the camera lens, remove the tape.

Sides

1 Micro-USB connector 2 Volume up/Zoom key 3 Mute key 4 Volume down/Zoom key 5 Key lock switch/Flashlight key
Get started 9

Bottom

1 Charger connector

Quick access with one-touch keys

With the one-touch keys, you can access applications and tasks quickly. Each key has been assigned an application and a task.
Modify one-touch keys
Select assigned applications to the keys, in which case you cannot modify them.
1 Home key. To open the main menu, press the home key. To return to the home
2 Mail key. To open your default mailbox, press the mail key. To start writing a mail,
3 Calendar key. To view your phone calendar, press the calendar key. To create a new
4 Contacts key. To open the contacts list, press the contacts key. To create a new
> Settings and Phone > One-touch keys. Your service provider may have
screen, press the home key again. To switch between the open applications, press and hold the home key.
press and hold the mail key.
meeting entry, press and hold the calendar key.
contact, press and hold the contacts key.

Touch screen

To control your phone, lightly touch the screen with your fingertips. The screen does not respond when you use your fingernails.
If your fingertips are cold, the screen may not respond to your touch.
Important: Avoid scratching the touch screen. Never use an actual pen, pencil, or
other sharp object on the touch screen.
10 Get started

Flashlight

The camera flash can be used as a flashlight. To switch the flashlight on or off, slide and hold the key lock switch for two seconds.
Do not shine the flashlight in anyone's eyes.

Noise cancellation

If you are calling from a noisy environment, your phone filters out background noise to make your voice sound clearer to the person at the other end of the line.
Noise cancellation is not available when using the loudspeaker or a headset.
For the best noise cancellation, hold the phone with the earpiece to your ear and the main microphone towards your mouth. Do not cover the secondary microphone on the back of the phone.

Insert the SIM card and battery

Important: This device is designed to be used with a standard SIM card (see figure)
only. Use of incompatible SIM cards may damage the card or the device, and may corrupt data stored on the card. Please consult your mobile operator for the use of a SIM card that has a mini-UICC cutout.
1 Switch the phone off. 2 Pull the back cover release latch towards the bottom of the phone, and remove the
cover.
Get started 11
3 Remove the battery, if inserted.
4 Use your fingernail to carefully pull out the SIM card holder. The holder cannot be
removed.
5 Make sure the contact area of the card is facing down, and insert the SIM card. Push
the holder carefully back into place.
6 Line up the battery contacts, and insert the battery.
12 Get started
7 Direct the top locking catches toward their slots, and press down until the cover
locks into place.
Remove the SIM card
1 Switch the phone off. 2 Remove the back cover. 3 Remove the battery, if inserted. 4 Use your fingernail to carefully pull out the SIM card holder. The holder cannot be
removed. Remove the SIM card.

Insert or remove the memory card

Memory cards are sold separately.
Do not attach any stickers to your memory card.
Get started 13
You can record high-definition videos. If recording to a memory card, for best performance, use a fast, high-quality microSD card from a wellknown manufacturer. The recommended microSD card class is 4 (32 Mbit/s (4 MB/s)) or higher.
Insert the memory card
1 Use your fingernail to open the cover of the memory card slot.
2 Make sure the contact area of the memory card is facing up. 3 Push the card in, until it locks into place.
Remove the memory card
1 If the phone is switched on, press the power key, and select Remove [memory
card name].
2 Use your fingernail to open the cover of the memory card slot. 3 Push the card in, until it is released. 4 Pull the card out.
14 Get started
Charging About the battery
Your phone has a removable, rechargeable battery. Use only Nokia approved chargers designated for this phone. You can also use a compatible USB data cable to charge your phone.
When the battery charge is low, power save mode is activated. To deactivate power save mode, press the power key
, and select Deactivate power saving. When power
save mode is activated, you may not be able to modify the settings of certain applications.

Charge the battery

Your battery has been partially charged at the factory, but you may need to recharge it before you can switch on your phone for the first time.
If the phone indicates a low charge, do the following:
1
2
You do not need to charge the battery for a specific length of time, and you can use the phone while it is charging.
If the battery is completely discharged, it may take several minutes before the charging indicator is displayed or before any calls can be made.
If the battery has not been used for a long time, to begin charging, you may need to connect the charger, then unplug and reconnect it.
Get started 15
Tip: You can also use a compatible USB charger to charge your battery.

Charge the battery over USB

Battery low, but you don't have a charger with you? You can use a compatible USB cable to connect your phone to a compatible device, such as a computer.
You can use USB charging when a wall outlet is not available. Data can be transferred while charging the device. The efficiency of USB charging power varies significantly, and it may take a long time for charging to start and the device to start functioning.
You can use your phone while it's charging.
To avoid breaking the charger connector, be careful when connecting or disconnecting the charger cable.

Switch the phone on or off

Switch on
Press and hold the power key
Switch off
Press and hold the power key
until the phone vibrates.
.
16 Get started

Lock or unlock the keys and screen

To avoid accidentally making a call when your phone is in your pocket or bag, lock the keys and screen of your phone.
Slide the key lock switch.
Tip: If the key lock switch is out of reach, to unlock the phone, press the scroll key, and select Unlock.
Set the keys and screen to lock automatically
1 Select
> Settings and Phone > Display > Screen/keylock time-out.
2 Define the length of time after which the keys and screen are locked automatically.

Antenna locations

Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the communication quality and may reduce battery life due to higher power level during operation.
Get started 17
The antenna area is highlighted.

Change the volume of a call, song, or video

Use the volume keys.
You can change the volume during a call or when an app is active.
The built-in loudspeaker lets you speak and listen from a short distance without having to hold the phone to your ear.
Switch the loudspeaker on or off during a call
Select
or .

Attach the wrist strap

Thread the wrist strap, and tighten it.
18 Get started

Headset

You can connect a compatible headset or compatible headphones to your phone.
Do not connect products that create an output signal, as this may damage the device. Do not connect any voltage source to the Nokia AV connector. If you connect an external device or headset, other than those approved by Nokia for use with this device, to the Nokia AV connector, pay special attention to volume levels.

Use your phone for the first time

Get started with your phone – copy contacts, messages, and other stuff from your old phone. Your phone guides you when you switch your phone on for the first time. You can also subscribe to the My Nokia service to receive helpful tips and tricks on how to make the most of your phone.
To start an action, select
. To skip an action, select .
To use Nokia services, create a Nokia account. You need an internet connection. For info about possible costs, contact your network service provider. If you can't connect to the internet, you can create an account later.
If you already have a Nokia account, type in your username and password, then select
.
Get started 19
Tip: Forgotten your password? You can request it to be sent to you in a mail or text
message.
Use the Phone switch app to copy your stuff, such as:
Contacts
Messages
Pictures
Videos
When you set up your mail account, you can set your inbox to be shown on your home screen, so you can easily check your mail.
If you need to make an emergency call when setting up your phone, press the call key.

Copy contacts or photos from your old phone

Want to copy important info from your previous Nokia phone and start using your new phone quickly? Use the Phone switch app to copy, for example, your contacts, calendar entries, and photos to your new phone, free of charge.
Your previous phone needs to support Bluetooth.
1 Select > Settings > Connectivity > Data transfer > Phone switch. 2 Select your old phone from the list, then pair the phones. Bluetooth needs to be on
in both phones.
3 If the other phone requires a passcode, type in the passcode in both phones.
The passcode is for the current connection only, and you can define it yourself. The passcode in some phones is fixed. For details, see the user guide of the other phone.
4 Select what you want to copy, then select OK.
Tip: You can also use the Phone switch app to copy content from other phones later.
20 Get started

Access codes

PIN or PIN2 code
(4-8 digits)
PUK or PUK2 code
(8 digits)
IMEI number
(15 digits)
Lock code (security code)
(min. 4 digits or characters)

Use the user guide in your phone

These protect your SIM against unauthorised use or are required to access some features.
You can set your phone to ask for the PIN code when you switch it on.
If not supplied with your card or you forget the codes, contact your service provider.
If you type in the code incorrectly three times in a row, you need to unblock the code with the PUK or PUK2 code.
These are required to unblock a PIN or PIN2 code.
If not supplied with your SIM, contact your service provider.
This is used to identify valid phones in the network. You may also need to give the number to Nokia Care services.
To view your IMEI number, dial *#06#.
This helps you protect your phone against unauthorised use.
You can set your phone to ask for the lock code that you define.
Keep the code secret and in a safe place, separate from your phone.
If you forget the code and your phone is locked, your phone will require service. Additional charges may apply, and all the personal data in your phone may be deleted.
For more information, contact Nokia Care or your phone dealer.
Your phone has a built-in user guide. It's always with you, available when needed.
Select
Open the user guide from an application
Select
> User guide.
> User guide. This is not available for every application.
Install Nokia Suite on your computer 21
Search the user guide
When the user guide is open, select search field.
Open an application from the user guide
Select the application link in a topic. To switch back to the user guide, press and hold the home key, swipe left or right, and
select the user guide.
Links to related topics may be at the end of instructions.
Tip: You also receive text messages and pop-up tips that give useful information about using your phone. To view the tips later, select
> Search, and enter a letter or a word in the
> My Nokia.

Install Nokia Suite on your computer

With the Nokia Suite PC app, you can manage content on your phone, and keep it in sync with your compatible computer. You can also update your phone with the latest software, and download maps.
A connection to the internet may be needed. For info about data costs, contact your network service provider.
Download the latest version of Nokia Suite from www.nokia.com/support to your computer.
Install Nokia Suite using your phone
1 Connect your phone to your computer with a compatible USB cable.
If you are using the Windows XP or Windows Vista operating system on your computer, set the USB mode of your phone to Mass storage. To set the USB mode on your phone, swipe down from the notification area, and select
storage.
Your phone mass memory and memory card are shown as removable disks on your PC.
2 If the installation window doesn't open automatically, in your computer file
manager, find and open your phone, and double-click the Nokia Suite installation
file. 3 Follow the instructions shown on your computer. 4 When the installation is complete, if you are using Windows XP or Windows Vista
on your computer, make sure the USB mode of your phone is Nokia Suite.
To learn more about Nokia Suite, and to check which operating systems Nokia Suite works with, go to www.nokia.com/support.
> Mass
22 Basic use

Basic use

Touch screen actions

To use your phone, tap or tap and hold the touch screen.
Important: Avoid scratching the touch screen. Never use an actual pen, pencil, or
other sharp object on the touch screen.
Open an app or item
Tap the app or item.
Tap and hold to see more options
Place your finger on an item until the menu opens.
Example: To send an image or delete an alarm, tap and hold the image or alarm, then select the option you want.
Drag an item
Tap and hold the item, and slide your finger across the screen.
Basic use 23
Example: You can drag items on the home screen, or when arranging the main menu.
Swipe
Place your finger on the screen, then slide it in the direction you want.
Example: To switch to another home screen, swipe left or right.
To quickly scroll through a long list or menu, slide your finger quickly up or down the screen, then lift your finger. To stop the scrolling, tap the screen.
Zoom in and out
Place two fingers on an item, such as a map, photo, or web page, and slide your fingers apart or together.
Tip: You can also tap the item twice.

Use shortcuts

You don't have to navigate long paths to, for example, open or close an internet connection, or to silence your phone. You can access these settings directly in the status menu, no matter what application or view you're in.
Swipe down from the notification area.
24 Basic use
In the status menu, you can do the following:
View notifications of missed calls or unread messages
Silence your phone
Modify the connectivity settings
View available WLAN connections, and connect to a WLAN
Manage Bluetooth connections
Tip: When listening to music, you can quickly access the music player from the status area.

Switch between open applications

You can see which applications and tasks are open in the background, and switch between them.
Press and hold the home key, swipe left or right, and select the desired application.
Basic use 25
Applications running in the background increase the demand on battery power and use memory. To close an application that you are not using, select
Tip: To close all open applications, select and hold the task switcher, and from the pop­up menu, select Close all.
Write text Write with the keyboard
Your phone has a full keyboard.
1 Function key. To insert special characters printed at the top of keys, press the
function key, and then press the corresponding key. To enter several special
characters in a row, press the function key twice. To return to normal mode, press
the function key.
Shift key. To switch between the upper and lower case modes, press the shift key
2
twice. To enter a single upper case letter in lower case mode, or a single lower case
letter in upper case mode, press the shift key, and then press the desired alphabet
key.
3
Sym key. To insert special characters not shown on the keyboard, press the sym
key, and select the desired character.
Backspace key. To delete a character, press the backspace key. To delete several
4
characters, press and hold the backspace key.
Enter key. To move the cursor to the next row or text input field, press the enter
5
key. Additional functions are based on the current context. For example, in the web
address field of the web browser, the enter key acts as the Go icon.
Ctrl key
6
Insert a variation of a letter
You can insert, for example, letters with accents. To insert á, press and hold the sym key, and then press A repeatedly, until the desired letter is displayed. The order and availability of letters depends on the selected writing language.
.

Keyboard shortcuts

Shortcuts can make the use of the applications more efficient.
26 Basic use
General shortcuts
Ctrl + C Copy text.
Ctrl + X Cut text.
Ctrl + V Paste text.
Shift + Sym Change the writing language.
Ctrl + A Select all.
Ctrl + B Use bold font.
Mail shortcuts
C Create a new message.
R Reply to a message.
A Reply to all.
F Forward a message.
D Delete a message.
H Open the in-device user guide.
I Collapse or expand the message list.
L Mark a message with a flag.
M Move a message to a different folder.
N Go to the next message.
P Go to the previous message.
S Search for a message.
U Mark a message as read or unread.
Z Synchronise the mail account.

General icons

The touch screen and keys are locked. Someone has tried to call you. You have unread messages. If the message icon is blinking, your Inbox folder may be full. You have a missed calendar event. An alarm is set. Messages are waiting to be sent in the Outbox folder. Incoming calls are forwarded to another number. Your phone is ready for an internet call. A data call is active.

Network icons

Basic use 27
Your phone is connected to a GSM network. Your phone is connected to a 3G network. A WLAN connection is open. A GPRS data connection is opening or closing. A GPRS data connection is open. A GPRS data connection is on hold. An EGPRS data connection is opening or closing. An EGPRS data connection is open.
28 Basic use
An EGPRS data connection is on hold. A 3G data connection is opening or closing. A 3G data connection is open. A 3G data connection is on hold. An HSPA connection is opening or closing. An HSPA data connection is open. An HSPA connection is on hold.

Bluetooth and USB icons

Bluetooth is on. If the icon is blinking, your phone is trying to connect to another device. Your phone is sending data over Bluetooth. A USB cable is connected to your phone. The phone is syncing. A compatible headset is connected to your phone. A compatible car kit is connected to your phone.

Set your phone to blink for missed calls or messages

When the phone notification light blinks, you have missed a call or a message has arrived.
Select
> Settings and Phone > Notification lights > Notification light.

Search your phone and the internet

Explore your phone and the internet. You can search for mail, contacts, photos,
music, or apps stored on your phone and on the internet.
Select
1 Start writing a search word, then select from the proposed matches.
> Search.
Basic use 29
2 To search on the internet, select the internet search link at the end of the search
results. You need an active internet connection.
Tip: You can add a search widget to the home screen. Tap and hold an empty area of the home screen, then select Add widget and the search widget from the list.

Use your phone offline

In places where you do not want to make or receive calls, you may still access your calendar, contacts list, and offline games if you activate the offline profile. Switch the phone off when mobile phone use is not allowed or when it may cause interference or danger.
Press the power key
When the offline profile is activated, your connection to the cellular network is closed. All radio frequency signals between the phone and the cellular network are prevented. If you try to send a message, it is placed in the Outbox folder, and is sent only when another profile is activated.
You can also use your phone without a SIM card. Switch the phone off, and remove the SIM card. When you switch back on, the offline profile is activated.
Important: In the offline profile you cannot make or receive any calls, or use other
features that require cellular network coverage. You may be able to call the official emergency number programmed into your device.To make calls, you must first change to another profile.
When the offline profile is activated, you can still connect to a WLAN to, for example, read your mail or browse the internet. You can also use Bluetooth.
Remember to comply with any applicable safety requirements.
, and select Offline.

Prolong battery life

If it seems you're always looking for a charger, there are steps you can take to reduce the power consumption of your phone.
Always charge the battery fully.
When power saving mode is activated, phone settings, such as Network mode and
the screen saver, are optimised.
Activate power saving mode
Press the power key saving mode, press the power key
, and select Activate power saving. To deactivate power
, and select Deactivate power saving.
30 Basic use
Close the applications you are not using
Press and hold the home key, swipe until the desired application is displayed, and select
.
Sounds, themes, and effects
Mute unnecessary tones, such as key tones.
Use wired headphones, rather than the loudspeaker.
Change the length of the time-out period after which the phone display switches
off.
Set the length of the time-out period
Select
Activate a dark theme and wallpaper
Select To change the wallpaper, on the home screen, select
Deactivate background animation effects
Select
Decrease the brightness of the display
Select
Deactivate the Big clock screen saver
Select
Network use
If you are listening to music or otherwise using your phone, but do not want to
Set your phone to check for new mail less frequently.
Use a WLAN connection to connect to the internet, rather than a mobile data (GPRS
If your phone is set to use both GSM and 3G networks (dual mode), the phone uses
Deactivate Bluetooth when not needed
Swipe down from the notification area, and select
> Settings and Phone > Display > Light time-out.
> Settings and Themes > General.
> Change wallpaper.
> Settings and Themes > General > > Theme effects > Off.
> Settings and Phone > Display > Brightness.
> Settings and Themes > Screen saver > None.
make or receive calls, activate the offline profile.
or 3G) connection.
more power when searching for the 3G network.
.
Loading...
+ 106 hidden pages
