Nokia CK-100 User Manual

Nokia Car Kit CK-100
User and Installation Guide

9209908

Issue 2

DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION, declares that this HF-22 product is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC. The product is
in conformity with the limits defined in Directive 2004/104/EC (amending Directive 72/245/
EEC), Annex I, paragraph 6.5, 6.6, 6.8 and 6.9. A copy of the Declaration of Conformity can be
found at http://www.nokia.com/phones/declaration_of_conformity/.

0434

© 2008-2009 Nokia. All rights reserved.

Nokia, Nokia Connecting People, Navi and the Nokia Original Accessories logo are
trademarks or registered trademarks of Nokia Corporation. Other product and company
names mentioned herein may be trademarks or tradenames of their respective owners.

Bluetooth is a registered trademark of Bluetooth SIG, Inc.

Reproduction, transfer, distribution, or storage of part or all of the contents of this document
in any form without the prior written permission of Nokia is prohibited.

Nokia operates a policy of ongoing development. Nokia reserves the right to make changes
and improvements to any of the products described in this document without prior notice.

To the maximum extent permitted by applicable law, under no circumstances shall Nokia be
responsible for any loss of data or income or any special, incidental, consequential or indirect
damages howsoever caused.

The contents of this document are provided “as is”. Except as required by applicable law, no
warranties of any kind, either express or implied, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose, are made in relation to the
accuracy, reliability or contents of this document. Nokia reserves the right to revise this
document or withdraw it at any time without prior notice.

The availability of particular products may vary by region. Please check with your Nokia
dealer for details.

Export controls
This device may contain commodities, technology or software subject to export laws and
regulations from the US and other countries. Diversion contrary to law is prohibited.

9209908/Issue 2 EN

Contents

For your safety......................... 4

1. Introduction ......................... 5

Bluetooth wireless technology .......... 5

2. Getting started..................... 6

Parts .......................................................... 6

Input device ............................................ 7

Switch the car kit on or off ................ 7

Switch on ............................................. 7

Switch off............................................. 7

Pair and connect with

another device........................................ 8

Pair and connect the car kit ........... 8

Connect the car kit

automatically ...................................... 9

Connect the car kit manually

to a phone............................................ 9

Connect two A2DP devices

at the same time .............................. 10

Disconnect the car kit..................... 10

Clear the list of paired devices..... 10

3. Operation............................ 11

Make a call............................................ 11

Answer a call ........................................ 11

End a call ............................................... 11

Manage two calls at

the same time....................................... 12

Adjust volume....................................... 12

Listen to music..................................... 12

Car radio mute ..................................... 12

Voice prompts....................................... 12

Reset ....................................................... 13

4. Troubleshooting.................. 14

Connection issues................................ 14

Audio issues .......................................... 14

Other issues........................................... 16

5. Installation.......................... 17

Safety information.............................. 17

Integration with a car radio

system..................................................... 18

Use the ISO cable CA-135

or CA-152........................................... 19

Use the power cable PCU-4

or CA-153P ........................................ 22

Install the car kit in a vehicle .......... 24

Hands-free unit HF-22................... 25

Input device CU-11 ......................... 26

Microphone MP-2............................ 26

Charging cable CA-134.................. 27

ISO cables CA-135 and

CA-152................................................ 27

Optional accessories........................... 28

Mobile holder.................................... 28

External antenna.............................. 28

Check the operation of the car kit . 28

Care and maintenance ........... 29

Additional safety

information............................. 30

3

For your safety

For your safety

Read these simple guidelines. Not following them may be dangerous or illegal.
Read the complete user and installation guide for further information.

SWITCH ON SAFELY

Do not switch the device on when wireless phone use is prohibited or
when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the
vehicle while driving. Your first consideration while driving should be
road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could
affect performance.

SWITCH OFF IN RESTRICTED AREAS

Follow any restrictions. Switch the device off near fuel, chemicals, or
blasting areas.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ACCESSORIES

Use only approved accessories. Do not connect incompatible
products.

4

Introduction

1. Introduction

With the Nokia Car Kit CK-100, you can conveniently make and answer
calls hands-free and listen to music from your compatible device. You
can operate the car kit using the supplied input device. The car kit also
includes voice prompts that guide you in its use.

The car kit can be connected to a compatible mobile phone or music
device using Bluetooth wireless technology.

Read this guide carefully before having the car kit professionally
installed and using it. Also, read the user guide for the device that you
connect to the car kit. It provides important safety and maintenance
information.

Check www.nokia.com/support or your local Nokia website for the latest
version of the user and installation guide, additional information, and
downloads related to your Nokia product.

This product may contain small parts. Keep them out of the reach of
small children.

The car kit should only be installed by a qualified service technician
using the original Nokia parts supplied in the sales package.

■ Bluetooth wireless technology

Bluetooth wireless technology allows you to connect compatible
devices without cables. The car kit and the other device do not need to
be in line of sight, but they should be within 10 metres (33 feet) of each
other. Connections may be subject to interference from obstructions,
such as walls, or other electronic devices.

The car kit complies with the Bluetooth Specification 2.0 that supports
the Hands-Free Profile (HFP) 1.5 and Advanced Audio Distribution
Profile (A2DP) 1.0. Check with the manufacturers of other devices to
determine their compatibility with this device.

5

Getting started

2. Getting started

■ Parts

The car kit contains the following parts:

2

3

1

8

6

4

1. Hands-free unit HF-22

2. Power cable PCU-4 or CA-153P (not included in all sales packages)

3. ISO cable CA-135 or CA-152 (not included in all sales packages)

4. Loudspeaker SP-3 (not included in all sales packages)

5. Input device CU-11 with Navi

6. Charging cable CA-134 with a Nokia 2.0-mm (0.08 inch) plug

7. Microphone MP-2

8. CD that contains this user and installation guide

TM

wheel

5

7

6

Getting started

■ Input device

You can operate the car kit using the
input device. The device is provided with
the Navi wheel that you can turn or
press.

Turn the wheel to adjust the volume
when you are using the mobile phone or
music device connected to the car kit.

Press the wheel for other tasks, for example, to handle calls.

■ Switch the car kit on or off

If you are not certain whether the ignition sense wire is connected or
not, consult with the technician who installed the car kit.

Switch on

If the ignition sense wire is connected, turn on the car ignition. When
the car kit is switched on, the indicator light of the input device turns
on.

If the ignition sense wire is not connected, press and hold the Navi
wheel for about 2 seconds. Alternatively, turn on the ignition, start
driving, and wait until the built-in motion sensor switches the car kit on
automatically.

After the car kit is switched on, it tries to make a Bluetooth connection
to the mobile phone that was last used with it.

Switch off

If the ignition sense wire is connected, turn off the car ignition. If you
have a call in progress on your mobile phone connected to the car kit,
the car kit switches off after you end the call.

If the ignition sense wire is not connected and you are not using your
phone connected to the car kit for calling, do one of the following:

7

Getting started

• Disconnect your phone and music device (if any) from the car kit. See
“Disconnect the car kit,” p. 10. The car kit automatically switches off
after 2 minutes.

• Turn the Navi wheel to the left until the car kit plays a short beep and
the blue indicator light starts to flash. Within 5 seconds, turn the
Navi wheel 6 steps to the left.

When the car kit switches off, the indicator light turns off.

After you turn off the car ignition, do not leave the mobile phone or
music device connected to the car kit to prevent accidental draining of
the car battery. If the mobile phone or music device is left connected to
the car kit, the car kit automatically switches off after 12 hours.

■ Pair and connect with another device

Before using the car kit, you must associate (pair) and connect it with a
compatible mobile phone or music device that supports Bluetooth
wireless technology. For information on Bluetooth connections and the
supported Bluetooth profiles, see “Bluetooth wireless technology,” p. 5.

When your device is connected to the car kit using Bluetooth wireless
technology, you can keep the device, for example, in a bag, while using
the car kit. To charge the battery in your compatible Nokia device while
using the car kit, connect the device to the car kit using the supplied
charging cable.

You can pair the car kit with up to eight devices but connect it to only
one device supporting the HFP Bluetooth profile and another device
supporting the A2DP Bluetooth profile at a time.

Pair and connect the car kit

If your phone supports the HFP and A2DP Bluetooth profiles and has a
music player feature, you can use the car kit to handle calls and play
music.

If your phone does not support the A2DP Bluetooth profile, you can pair
the car kit with a music device that supports this profile.

1. Switch on the car kit and your mobile phone or music device.

8

Getting started

If you want to pair and connect a music device that supports the
A2DP Bluetooth profile, disconnect the car kit from your phone if the
phone supports this profile.

2. Activate the Bluetooth feature on your device, and set the device to
search for Bluetooth devices. See the user guide of your device for
instructions.

3. Select the car kit (Nokia CK-100) from the list of found devices, or
follow the related instructions in the user guide for your device.

4. Enter the Bluetooth passcode 0000 to pair and connect the car kit
with your device. In some devices you may need to make the
connection separately after pairing. See the user guide of your device
for details.

If your music device does not have a keypad, it may use the
Bluetooth passcode 0000 by default. If this is not the case, see the
user guide of your device to change the default Bluetooth passcode
to 0000.

You only need to pair the car kit with your device once.

If the pairing is successful and your device is connected to the car kit,
the blue indicator light is displayed, and the car kit plays a voice prompt
or a short beep. The car kit also appears in the menu of your phone or
music device where you can view the currently paired Bluetooth devices.
If the pairing fails, the car kit plays a voice prompt or a low beep.

Connect the car kit automatically

You may be able to set your mobile phone or music device so that the
car kit connects to it automatically. To activate this feature in a Nokia
device, change the paired device settings in the Bluetooth menu.

Connect the car kit manually to a phone

When you switch on the car kit, it tries to connect to the last used
mobile phone. If the connection does not succeed within 2 minutes, you
can manually search for paired phones.

9
