CCS Techni cal Documenation
NHM-1 Series Transceivers
Nokia 6650 P arts
Issue 1 11/03 CopyrightNokia. All rights reserved
NHM-1 Company confidential
Nokia 6650 Parts CCS Technical Documentation
Table of Contents
Page No
NHM-1 Exploded Diagram............................................................................................ 3
List of mechanical parts ...............................................................................................4
Parts List, Engine module NB8 ...................................................................................6
Pwb NB8_15a, 0201714 ...................................................................................... 6
Parts list, User Interface module NB1 .......................................................................24
Page 2 Copyright Nokia. All rights reserved Issue 1 11/03
Company confidential NHM-1
CCS Technical Documentation Nokia 6650 Parts
NHM-1 Exploded Diagram
Figure 1: Nokia 6650 exploded diagram
Issue 1 11/03 CopyrightNokia. All rights reserved Page 3
NHM-1 Company confidential
Nokia 6650 Parts CCS Technical Documentation
List of mechanical parts
ITEM PART NO PART NAME
I001 9490522 A-COVER
I002 9794091 KEYPAD
4850301 DISPLAY MODULE ASSY (I003-I004)
I003 - DISPLAY
I004 5140247 EARPIECE
I005 6150071 SCREWS
9498000 UI-PWB ASSY (I006-I008)
I006 9460457 LIGHT GUIDE
I007 - DOME SHEET
I008 - UI-PWB
9517190 ENGINE SHIELD ASSY (I009-I01 1)
I009 - INSULATING SHEET
I010 - ENGINE SHIELD
I011 - ENGINE SHIELD GASKET
I012 - ENGINE PWB
9481208 ANTENNA ASSY (I013-I016)
I013 - IHF-TAPE / GASKET
I014 - IHF-SPEAKER
I015 - IHF-ACOUSTIC CH AM BER
I016 - ANTENNA
I017 4858013 CAMERA MODULE
I018 9790655 SIDE KEYMAT
I019 9790654 POWER KEYMAT
I020 0660243 WCDMA ANTENNA
I021 6800055 VIBRA
I022 5140265 MICROPHONE
I023 5400243 DC-JACK
I024 9452407 IR WINDOW
9491327 B-COVER ASSY (I025-I0 31)
I025 - CAMERA SHIELD
Page 4 Copyright Nokia. All rights reserved Issue 1 11/03
Company confidential NHM-1
CCS Technical Documentation Nokia 6650 Parts
ITEM PART NO PART NAME
I026 - CAMERA DE T ECTOR
I027 - CAMERA W I NDOW
I028 - B-COVER
I029 9470163 BATTERY LOCK
I030 9470162 BATTEY COVER LATCH
I031 9517112 SIM-CARD HO LDER
I032 9510921 JACKET SPRING
I033 9458438 CAMERA JACKET
I034 9430418 NOKIA LOGO
I035 6290093 SCREWS
I036 9370933 TYPE LABEL
I037 9452413 BATTERY COVER
Issue 1 11/03 CopyrightNokia. All rights reserved Page 5
NHM-1 Company confidential
Nokia 6650 Parts CCS Technical Documentation
Parts List, Engine module NB8
Pwb NB8_15A, 0201714
Part Code XY Name. type, size
A501 9510 960 Top F 8 RF CAN 1 ~ ~ DMC03968
A502 9510 959 Top E 3 RF CAN 2 ~ ~ DMC03969
A503 9510961 Top J 3 RF CAN 3 ~ ~ DMC03970
A504 9510962 Top K 8 RF CAN 4 ~ ~ DMC03971
B200 4510303 Top S 8 CRYSTAL 32.768kHz ~
B253 4700135 Top N 7 CELL CAP 3.3V ~ II02N
C100 2320744 Bot V 8 Chipcap 1n0 50V 0402C
C101 2320544 Bot V 7 Chipcap 22p 50V 0402C
C102 2320481 Top T 5 Chipcap 1u0 6.3V 0603C
C103 2320778 Top S 5 Chipcap 10n 16V 0402C
C104 2320481 Top T 6 Chipcap 1u0 6.3V 0603C
C105 2320783 Top S 7 Chipcap 33n 10V 0402C
C106 2320783 Top S 7 Chipcap 33n 10V 0402C
C107 2320805 Top T 6 Chipcap 100n 10V 0402C
C108 2320756 Bot X 6 Chipcap 3n3 50V 0402C
C109 2320756 Bot X 6 Chipcap 3n3 50V 0402C
C110 2320544 Top P 2 Chipcap 22p 50V 0402C
C111 2320744 Top S 6 Chipcap 1n0 50V 0402C
C112 2320744 Top S 8 Chipcap 1n0 50V 0402C
C113 2320744 Top S 8 Chipcap 1n0 50V 0402C
C114 2320544 Bot W 5 Chipcap 22p 50V 0402C
C115 2320544 Bot W 5 Chipcap 22p 50V 0402C
C116 2320756 Bot W 5 Chipcap 3n3 50V 0402C
C117 2320756 Bot X 5 Chipcap 3n3 50V 0402C
C118 2320633 Top T 8 Chipcap 220p 25V 0402C
C145 2320546 Bot E 7 Chipcap 27p 50V 0402C
C146 2320546 Bot E 7 Chipcap 27p 50V 0402C
C147 2320805 Bot V 8 Chipcap 100n 10V 0402C
C148 2320783 Top S 7 Chipcap 33n 10V 0402C
C149 2320783 Top S 7 Chipcap 33n 10V 0402C
Page 6 Copyright Nokia. All rights reserved Issue 1 11/03
Company confidential NHM-1
CCS Technical Documentation Nokia 6650 Parts
Part Code XY Name. type, size
C150 2320744 Bot V 9 Chipcap 1n0 50V 0402C
C151 2320546 Bot X 8 Chipcap 27p 50V 0402C
C152 2320546 Bot V 9 Chipcap 27p 50V 0402C
C166 2320544 Bot B 6 Chipcap 22p 50V 0402C
C167 2320125 Top P 2 Chipcap 1u0 16V 0603C
C168 2320481 Bot I 1 Chipcap 1u0 6.3V 0603C
C169 2320125 Top P 3 Chipcap 1u0 16V 0603C
C174 2320481 Top N 2 Chipcap 1u0 6.3V 0603C
C175 2320556 Top O 3 Chipcap 68p 50V 0402C
C200 2320778 Top P 9 Chipcap 10n 16V 0402C
C201 2320481 Top O 9 Chipcap 1u0 6.3V 0603C
C202 2320744 Top P 9 Chipcap 1n0 50V 0402C
C203 2320481 Top P 7 Chipcap 1u0 6.3V 0603C
C204 2320481 Top Q 8 Chipcap 1u0 6.3V 0603C
C205 2320481 Top Q 9 Chipcap 1u0 6.3V 0603C
C206 2320481 Top R 5 Chipcap 1u0 6.3V 0603C
C207 2320481 Top R 8 Chipcap 1u0 6.3V 0603C
C208 2320481 Top R 8 Chipcap 1u0 6.3V 0603C
C210 2320481 Top P 8 Chipcap 1u0 6.3V 0603C
C211 2320536 Top S 8 Chipcap 10p 50V 0402C
C212 2320536 Top S 7 Chipcap 10p 50V 0402C
C213 2320481 Top R 8 Chipcap 1u0 6.3V 0603C
C214 2320481 Top R 8 Chipcap 1u0 6.3V 0603C
C215 2320481 Top R 8 Chipcap 1u0 6.3V 0603C
C216 2320481 Top S 7 Chipcap 1u0 6.3V 0603C
C218 2320481 Top S 7 Chipcap 1u0 6.3V 0603C
C219 2320481 Top S 6 Chipcap 1u0 6.3V 0603C
C220 2320481 Top S 6 Chipcap 1u0 6.3V 0603C
C221 2320805 Top Q 5 Chipcap 100n 10V 0402C
C222 2320805 Top Q 5 Chipcap 100n 10V 0402C
C223 2320805 Top P 6 Chipcap 100n 10V 0402C
C225 2320491 Top P 8 Chipcap 220n 10V 0603C
Issue 1 11/03 CopyrightNokia. All rights reserved Page 7
NHM-1 Company confidential
Nokia 6650 Parts CCS Technical Documentation
Part Code XY Name. type, size
C227 2320481 Top P 9 Chipcap 1u0 6.3V 0603C
C228 2320481 Top P 7 Chipcap 1u0 6.3V 0603C
C229 2320481 Top O 6 Chipcap 1u0 6.3V 0603C
C230 2320481 Top O 6 Chipcap 1u0 6.3V 0603C
C231 2320481 Top O 7 Chipcap 1u0 6.3V 0603C
C232 2320481 Top P 6 Chipcap 1u0 6.3V 0603C
C233 2320744 Top Q 5 Chipcap 1n0 50V 0402C
C234 2320744 Top S 6 Chipcap 1n0 50V 0402C
C235 2320744 Top S 6 Chipcap 1n0 50V 0402C
C236 2320744 Top S 6 Chipcap 1n0 50V 0402C
C237 2320481 Top P 9 Chipcap 1u0 6.3V 0603C
C238 2320481 Top O 7 Chipcap 1u0 6.3V 0603C
C239 2320481 Top O 7 Chipcap 1u0 6.3V 0603C
C240 2320481 Top O 7 Chipcap 1u0 6.3V 0603C
C241 2320481 Top O 8 Chipcap 1u0 6.3V 0603C
C242 2320481 Top O 8 Chipcap 1u0 6.3V 0603C
C243 2320481 Top P 8 Chipcap 1u0 6.3V 0603C
C244 2320481 Top P 8 Chipcap 1u0 6.3V 0603C
C246 2320481 Top P 7 Chipcap 1u0 6.3V 0603C
C248 2320481 Top P 8 Chipcap 1u0 6.3V 0603C
C249 2320481 Top P 7 Chipcap 1u0 6.3V 0603C
C251 2320481 Top O 6 Chipcap 1u0 6.3V 0603C
C254 2320560 Top O 5 Chipcap 100p 50V 0402C
C255 2320560 Top P 6 Chipcap 100p 50V 0402C
C256 2320546 Top M 8 Chipcap 27p 50V 0402C
C257 2320756 Top O 8 Chipcap 3n3 50V 0402C
C258 2320744 Top Q 5 Chipcap 1n0 50V 0402C
C300 2320481 Top W 4 Chipcap 1u0 6.3V 0603C
C301 2613009 Top Y 7 ChipTcap 100u_10V 10V
C302 2310793 Top W 5 Chipcap 2u2 10V 0805C
C303 2320805 Bot J 3 Chipcap 100n 10V 0402C
C304 2611801 Bot I 1 ChipTcap 150u_6.3V6V3
Page 8 Copyright Nokia. All rights reserved Issue 1 11/03
Company confidential NHM-1
CCS Technical Documentation Nokia 6650 Parts
Part Code XY Name. type, size
C306 2320805 Bot J 2 Chipcap 100n 10V 0402C
C307 2320778 Top W 4 Chipcap 10n 16V 0402C
C308 2320546 Bot I 4 Chipcap 27p 50V 0402C
C309 2320546 Bot I 4 Chipcap 27p 50V 0402C
C310 2310793 Top Y 4 Chipcap 2u2 10V 0805C
C311 2310793 Top W 3 Chipcap 2u2 10V 0805C
C312 2310793 Top Y 4 Chipcap 2u2 10V 0805C
C313 2320481 Top X 3 Chipcap 1u0 6.3V 0603C
C314 2320137 Top V 7 Chipcap 470n 10V 0603C
C315 2320137 Top V 7 Chipcap 470n 10V 0603C
C316 2320546 Top X 5 Chipcap 27p 50V 0402C
C317 2320546 Top Y 5 Chipcap 27p 50V 0402C
C318 2611689 Bot V 7 Chipcap 470u_10V 10V TANT_TPSE_L
C320 2320778 Top Y 5 Chipcap 10n 16V 0402C
C321 2320560 Top X 5 Chipcap 100p 50V 0402C
C323 2320481 Top W 4 Chipcap 1u0 6.3V 0603C
C324 2320481 Top Y 5 Chipcap 1u0 6.3V 0603C
C325 2320481 Top W 4 Chipcap 1u0 6.3V 0603C
C326 2320481 Top X 5 Chipcap 1u0 6.3V 0603C
C327 2320481 Top W 5 Chipcap 1u0 6.3V 0603C
C328 2320481 Top W 5 Chipcap 1u0 6.3V 0603C
C329 2320481 Top X 5 Chipcap 1u0 6.3V 0603C
C330 2320481 Top X 5 Chipcap 1u0 6.3V 0603C
C331 2320481 Top X 3 Chipcap 1u0 6.3V 0603C
C332 2320481 Top Y 3 Chipcap 1u0 6.3V 0603C
C333 2320481 Top X 3 Chipcap 1u0 6.3V 0603C
C334 2320546 Bot I 5 Chipcap 27p 50V 0402C
C336 2320540 Top N 2 Chipcap 15p 50V 0402C
C337 2320744 Top W 4 Chipcap 1n0 50V 0402C
C385 2320805 Bot V 3 Chipcap 100n 10V 0402C
C400 2320778 Top P 3 Chipcap 10n 16V 0402C
C401 2320805 Top T 3 Chipcap 100n 10V 0402C
Issue 1 11/03 CopyrightNokia. All rights reserved Page 9
NHM-1 Company confidential
Nokia 6650 Parts CCS Technical Documentation
Part Code XY Name. type, size
C402 2320805 Top T 3 Chipcap 100n 10V 0402C
C403 2320805 Top S 4 Chipcap 100n 10V 0402C
C404 2320805 Top P 3 Chipcap 100n 10V 0402C
C405 2320805 Top P 2 Chipcap 100n 10V 0402C
C406 2320805 Top R 1 Chipcap 100n 10V 0402C
C407 2320805 Top R 1 Chipcap 100n 10V 0402C
C408 2320560 Top K 2 Chipcap 100p 50V 0402C
C409 2320805 Top R 5 Chipcap 100n 10V 0402C
C410 2320805 Top T 2 Chipcap 100n 10V 0402C
C411 2320778 Top S 3 Chipcap 10n 16V 0402C
C412 2320805 Top S 4 Chipcap 100n 10V 0402C
C413 2320778 Top P 2 Chipcap 10n 16V 0402C
C414 2320805 Top S 2 Chipcap 100n 10V 0402C
C415 2320744 Top S 4 Chipcap 1n0 50V 0402C
C430 2320805 Bot B 6 Chipcap 100n 10V 0402C
C431 2312243 Bot C 7 Chipcap 4u7 6V3 0805C
C432 2320544 Bot D 8 Chipcap 22p 50V 0402C
C433 2320137 Bot D 7 Chipcap 470n 10V 0603C
C450 2320779 Top V 7 Chipcap 100n 16V 0603_BLM
C451 2320778 Top V 7 Chipcap 10n 16V 0402C
C452 2320805 Top V 7 Chipcap 100n 10V 0402C
C453 2320778 Top V 6 Chipcap 10n 16V 0402C
C454 2320805 Top V 6 Chipcap 100n 10V 0402C
C455 2320805 Top V 3 Chipcap 100n 10V 0402C
C456 2320805 Top V 3 Chipcap 100n 10V 0402C
C457 2320805 Top V 3 Chipcap 100n 10V 0402C
C458 2320805 Top V 3 Chipcap 100n 10V 0402C
C459 2320779 Top V 4 Chipcap 100n 16V 0603_BLM
C460 2320778 Top V 6 Chipcap 10n 16V 0402C
C461 2320805 Top V 6 Chipcap 100n 10V 0402C
C462 2320778 Top V 5 Chipcap 10n 16V 0402C
C463 2320805 Top V 5 Chipcap 100n 10V 0402C
Page 10 Copyright Nokia. All rights reserved Issue 1 11/03
Company confidential NHM-1
CCS Technical Documentation Nokia 6650 Parts
Part Code XY Name. type, size
C471 2310793 Top P 5 Chipcap 2u2 10V 0805C
C474 2320778 Top P 5 Chipcap 10n 16V 0402C
C481 2310793 Top P 4 Chipcap 2u2 10V 0805C
C483 2320481 Top O 5 Chipcap 1u0 6.3V 0603C
C484 2320560 Top O 4 Chipcap 100p 50V 0402C
C485 2320481 Top O 5 Chipcap 1u0 6.3V 0603C
C486 2320560 Top O 5 Chipcap 100p 50V 0402C
C551 2320560 Top G 1 Chipcap 100p 50V 0402C
C552 2320560 Top F 1 Chipcap 100p 50V 0402C
C554 2320554 Top G 4 Chipcap 56p 50V 0402C
C555 2320524 Top G 3 Chipcap 3p3 50V 0402C
C556 2312243 Top G 3 Chipcap 4u7 6V3 0805C
C557 2320778 Top C 3 Chipcap 10n 16V 0402C
C559 2320524 Top F 1 Chipcap 3p3 50V 0402C
C560 2320778 Top C 1 Chipcap 10n 16V 0402C
C561 2320540 Top E 1 Chipcap 15p 50V 0402C
C562 2320554 Top G 4 Chipcap 56p 50V 0402C
C563 2320560 Top C 4 Chipcap 100p 50V 0402C
C564 2310045 Top E 2 Chipcap 68n 10V 0402C
C565 2310045 Top E 3 Chipcap 68n 10V 0402C
C566 2320554 Top F 1 Chipcap 56p 50V 0402C
C567 2320756 Top G 1 Chipcap 3n3 50V 0402C
C568 2320556 Top F 2 Chipcap 68p 50V 0402C
C569 2320540 Top F 2 Chipcap 15p 50V 0402C
C570 2320536 Top F 3 Chipcap 10p 50V 0402C
C571 2320536 Top F 3 Chipcap 10p 50V 0402C
C572 2320536 Top I 4 Chipcap 10p 50V 0402C
C573 2320536 Top I 3 Chipcap 10p 50V 0402C
C574 2320546 Top E 3 Chipcap 27p 50V 0402C
C575 2320546 Top F 3 Chipcap 27p 50V 0402C
C600 2320546 Top J 2 Chipcap 27p 50V 0402C
C601 2320554 Top I 4 Chipcap 56p 50V 0402C
Issue 1 11/03 CopyrightNokia. All rights reserved Page 11
NHM-1 Company confidential
Nokia 6650 Parts CCS Technical Documentation
Part Code XY Name. type, size
C602 2320566 Top J 2 Chipcap 180p 50V 0402C
C603 2320805 Top K 2 Chipcap 100n 10V 0402C
C604 2320778 Top K 2 Chipcap 10n 16V 0402C
C605 2320805 Top J 4 Chipcap 100n 10V 0402C
C606 2320778 Top K 5 Chipcap 10n 16V 0402C
C608 2320805 Top L 2 Chipcap 100n 10V 0402C
C613 2320805 Top J 4 Chipcap 100n 10V 0402C
C615 2320558 Top I 4 Chipcap 82p 50V 0402C
C616 2320556 Top J 2 Chipcap 68p 50V 0402C
C617 2320556 Top K 2 Chipcap 68p 50V 0402C
C624 2314001 Top J 4 Chipcap 470p 6V3 0402C
C625 2314001 Top J 4 Chipcap 470p 6V3 0402C
C626 2314001 Top J 4 Chipcap 470p 6V3 0402C
C627 2314001 Top J 4 Chipcap 470p 6V3 0402C
C641 2320518 Top H 3 Chipcap 1p8 50V 0402C
C642 2322015 Top H 4 Chipcap 2n2 16V 0603C
C650 2320524 Top K 3 Chipcap 3p3 50V 0402C
C652 2320524 Top K 4 Chipcap 3p3 50V 0402C
C653 2322015 Top K 2 Chipcap 2n2 16V 0603C
C654 2320564 Top L 2 Chipcap 150p 50V 0402C
C655 2320481 Top K 4 Chipcap 1u0 6.3V 0603C
C656 2320554 Top K 4 Chipcap 56p 50V 0402C
C657 2320564 Top L 2 Chipcap 150p 50V 0402C
C660 2320560 Top K 5 Chipcap 100p 50V 0402C
C662 2320560 Top K 5 Chipcap 100p 50V 0402C
C685 2320554 Top J 1 Chipcap 56p 50V 0402C
C686 2320744 Top I 1 Chipcap 1n0 50V 0402C
C687 2320604 Top I 2 Chipcap 18p 50V 0402C
C688 2320907 Top J 2 Chipcap 0p7 16V 0402C_AVX
C691 2320548 Top I 2 Chipcap 33p 50V 0402C
C692 2320548 Top I 2 Chipcap 33p 50V 0402C
C693 2320540 Top I 3 Chipcap 15p 50V 0402C
Page 12 Copyright Nokia. All rights reserved Issue 1 11/03
Company confidential NHM-1
CCS Technical Documentation Nokia 6650 Parts
Part Code XY Name. type, size
C694 2320540 Top I 2 Chipcap 15p 50V 0402C
C800 2320546 Top B 5 Chipcap 27p 50V 0402C
C801 2320568 Top E 5 Chipcap 220p 50V 0402C
C802 2320778 Top C 5 Chipcap 10n 16V 0402C
C803 2320546 Top C 6 Chipcap 27p 50V 0402C
C804 2320546 Top B 5 Chipcap 27p 50V 0402C
C805 2320546 Top C 5 Chipcap 27p 50V 0402C
C810 2320508 Top A 6 Chipcap 1p0 50V 0402C
C811 2320508 Top A 6 Chipcap 1p0 50V 0402C
C812 2320481 Top B 2 Chipcap 1u0 6.3V 0603C
C813 2320508 Top B 3 Chipcap 1p0 50V 0402C
C814 2320602 Top B 3 Chipcap 4p7 50V 0402C
C816 2320544 Top B 3 Chipcap 22p 50V 0402C
C818 2320485 Top B 3 Chipcap 470p 50V 0603C
C820 2320536 Top A 3 Chipcap 10p 50V 0402C
C822 2320131 Top D 6 Chipcap 33n 16V 0603C
C823 2320131 Top D 6 Chipcap 33n 16V 0603C
C824 2320131 Top D 5 Chipcap 33n 16V 0603C
C825 2320131 Top E 5 Chipcap 33n 16V 0603C
C826 2320131 Top D 5 Chipcap 33n 16V 0603C
C827 2320131 Top D 5 Chipcap 33n 16V 0603C
C830 2320744 Top E 6 Chipcap 1n0 50V 0402C
C831 2320744 Top E 6 Chipcap 1n0 50V 0402C
C832 2320744 Top D 5 Chipcap 1n0 50V 0402C
C833 2320744 Top D 5 Chipcap 1n0 50V 0402C
C842 2320546 Top B 5 Chipcap 27p 50V 0402C
C844 2320546 Top B 5 Chipcap 27p 50V 0402C
C846 2320536 Top B 6 Chipcap 10p 50V 0402C
C848 2320524 Top B 5 Chipcap 3p3 50V 0402C
C850 2320805 Top C 5 Chipcap 100n 10V 0402C
C852 2320566 Top D 6 Chipcap 180p 50V 0402C
C853 2320566 Top D 5 Chipcap 180p 50V 0402C
Issue 1 11/03 CopyrightNokia. All rights reserved Page 13
NHM-1 Company confidential
Nokia 6650 Parts CCS Technical Documentation
Part Code XY Name. type, size
C854 2320566 Top D 6 Chipcap 180p 50V 0402C
C855 2320566 Top D 5 Chipcap 180p 50V 0402C
C860 2320491 Top J 5 Chipcap 220n 10V 0603C
C861 2320744 Top K 5 Chipcap 1n0 50V 0402C
C866 2320805 Top D 6 Chipcap 100n 10V 0402C
C870 2320481 Top L 6 Chipcap 1u0 6.3V 0603C
C872 2320560 Top D 5 Chipcap 100p 50V 0402C
C890 2320544 Top B 6 Chipcap 22p 50V 0402C
C892 2320544 Top B 6 Chipcap 22p 50V 0402C
C901 2320805 Top I 7 Chipcap 100n 10V 0402C
C902 2320540 Top K 7 Chipcap 15p 50V 0402C
C903 2320744 Top I 7 Chipcap 1n0 50V 0402C
C904 2320540 Top K 7 Chipcap 15p 50V 0402C
C905 2320744 Top K 8 Chipcap 1n0 50V 0402C
C906 2320805 Top J 9 Chipcap 100n 10V 0402C
C907 2320536 Top L 8 Chipcap 10p 50V 0402C
C908 2320805 Top J 8 Chipcap 100n 10V 0402C
C909 2320540 Top J 8 Chipcap 15p 50V 0402C
C910 2320540 Top I 8 Chipcap 15p 50V 0402C
C911 2320778 Top I 6 Chipcap 10n 16V 0402C
C912 2320604 Top J 7 Chipcap 18p 50V 0402C
C914 2320604 Top I 8 Chipcap 18p 50V 0402C
C916 2320481 Top J 9 Chipcap 1u0 6.3V 0603C
C918 2320778 Top J 7 Chipcap 10n 16V 0402C
C920 2320560 Top J 7 Chipcap 100p 50V 0402C
C921 2320560 Top J 7 Chipcap 100p 50V 0402C
C924 2320558 Top L 7 Chipcap 82p 50V 0402C
C926 2322033 Top K 7 Chipcap 1n2 16V 0603C
C934 2320481 Top L 8 Chipcap 1u0 6.3V 0603C
C936 2320524 Top I 7 Chipcap 3p3 50V 0402C
C938 2320524 Top I 8 Chipcap 3p3 50V 0402C
C940 2320540 Top I 8 Chipcap 15p 50V 0402C
Page 14 Copyright Nokia. All rights reserved Issue 1 11/03
Company confidential NHM-1
CCS Technical Documentation Nokia 6650 Parts
Part Code XY Name. type, size
C946 2320778 Top H 8 Chipcap 10n 16V 0402C
C948 2320778 Top G 8 Chipcap 10n 16V 0402C
C951 2320568 Top J 6 Chipcap 220p 50V 0402C
C952 2320540 Top H 7 Chipcap 15p 50V 0402C
C953 2320524 Top K 8 Chipcap 3p3 50V 0402C
C954 2320540 Top H 9 Chipcap 15p 50V 0402C
C955 2310793 Top I 5 Chipcap 2u2 10V 0805C
C956 2320778 Top J 6 Chipcap 10n 16V 0402C
C958 2320481 Top I 6 Chipcap 1u0 6.3V 0603C
C959 2320481 Top J 5 Chipcap 1u0 6.3V 0603C
C960 2320744 Top E 9 Chipcap 1n0 50V 0402C
C962 2320540 Top E 9 Chipcap 15p 50V 0402C
C964 2320540 Top E 8 Chipcap 15p 50V 0402C
C966 2320540 Top D 8 Chipcap 15p 50V 0402C
C970 2320481 Top F 9 Chipcap 1u0 6.3V 0603C
C980 2320778 Top F 8 Chipcap 10n 16V 0402C
C988 2320633 Top H 6 Chipcap 220p 25V 0402C
C989 2320536 Top H 5 Chipcap 10p 50V 0402C
C995 2613023 Top H 6 ChipTcap 2u2_10V 10V TANT_TPSA
C999 2312243 Top H 5 Chipcap 4u7 6V3 0805C
D400 4370939 Top R 3 ASIC TIKU F751 876C
C035
D450 4341529 Top U 7 FLASH 4MX16 64Mbit ~ uBGA40_64
D451 4341497 Top U 5 FLASH 8MX16 128Mbit ~ uBGA40_128
D452 4341341 Top U 3 SDRAM 4Mx16 ~ uBGA52_H1.
~uBGA_289
MB_4
MB_3A
1
F100 51 190 19 Bot W 3 SM FUSE F 1.5A 32V ~ 0603_FUSE
G650 4350325 Top L 4 VCO E/GSM 3420-
3840MHz
G800 4350363 Top B 4 VCO W-CDMA 4220-
4340MHz
G820 4510371 Top K 5 VCTCXO W-CDMA 19.2MHz ~ VCTCXO_NK
~ VCO_FDK_IT
001
~ VCO_FDK_IT
_H1.7
G3126A
Issue 1 11/03 CopyrightNokia. All rights reserved Page 15
NHM-1 Company confidential
Nokia 6650 Parts CCS Technical Documentation
Part Code XY Name. type, size
G900 4350367 Top L 7 VCO W-CDMA 3840-
3960MHz
L100 3203705 Bot W 2 FERRITE BEAD 42R/
100MHZ
L101 3203801 Bot X 6 CHIP BEAD ARRAY 2x1000R/
100MHz
L102 3203801 Bot X 5 CHIP BEAD ARRAY 2x1000R/
100MHz
L146 3203725 Bot X 8 FERRITE BEAD 0R6 600R/
100M
L166 3640119 Top O 1 CHOKE 22uH ~ 984FB
L300 3640131 Top W 7 CHOKE 22uH ~ D62CB
L301 3203705 Top X 3 FERRITE BEAD 42R/
100MHZ
L302 3203741 Top O 8 FERRITE BEAD 0603 0R5 600R/
100MHZ
L303 3203705 Top M 7 FERRITE BEAD 42 R/
100MHZ
~ VCO_FDK_IT
_UCVA4
~ 0805
~ 0405
~ 0405
~0402
~ 0805
~ 0603_BLM
~ 0805
L304 3203705 Bot J 6 FERRITE BEAD 0R5 600R/
100MHZ
L305 3203741 Top I 5 FERRITE BEAD 0R5 600R/
100MHZ
L552 3203705 Top G 4 FERRITE BEAD 42R/
100MHZ
0805
L553 3203715 Top C 4 FERRITE BEAD 0R35
240R/
100M
0402
L554 3646059 Top C 3 CHIP COIL 5n6H ~ 0402L
L560 4551015 Top F 2 DIR.COUP 897.5/
1747.5/
1880MHZ
L601 3203725 Top J 5 FERRITE BEAD 0R6 600R/
100M
0402
L633 3646061 Top I 4 Chip coil 15nH ~ 0402L
~ 0805
~ 0603_BLM
~ 0805_
~_BK1005
~ LDC15D
~0402
L634 3646061 Top I 4 Chip coil 15nH ~ 0402L
L635 3646003 Top I 4 Chip coil 2n2H ~ 0402L
L636 3646003 Top I 3 Chip coil 2n2H ~ 0402L
Page 16 Copyright Nokia. All rights reserved Issue 1 11/03
Company confidential NHM-1
CCS Technical Documentation Nokia 6650 Parts
Part Code XY Name. type, size
L685 3646065 Top J 2 Chip coil 12nH ~ 0402L
L686 3646065 Top J 2 Chip coil 12nH ~ 0402L
L691 3646007 Top H 2 Chip coil 27nH ~ 0402L
L801 3646009 Top B 6 Chip coil 10nH ~ 0402L
L806 3646059 Top B 2 Chip coil 5n6H ~ 0402L
L810 3646003 Top B 6 Chip coil 2n2H ~ 0402L
L812 3646003 Top B 6 Chip coil 2n2H ~ 0402L
L899 3645345 Top L 5 Chip coil 4u7H ~ 1608
L900 3646005 Top I 8 Chip coil 2n7H ~ 0402L
L902 3646005 Top I 8 Chip coil 2n7H ~ 0402L
L906 3646067 Top H 7 Chip coil 18nH ~ 0402L
L940 3646063 Top K 7 Chip coil 22nH ~ 0402L
L958 3646003 Top H 9 Chip coil 2n2H ~ 0402L
L959 3646087 Top H 7 Chip coil 1n8H ~ 0402L
L960 3646003 Top H 8 Chip coil 2n2H ~ 0402L
L961 3646087 Top H 7 Chip coil 1n8H ~ 0402L
L970 4550227 Top E 7 DIR COUP. 1950+-
30MHZ
14DB
L999 3640139 Top F 5 CHOKE 10uH ~ ELL4LM100M
N100 4370961 Top S 5 ASIC NUT/
CP2137
N130 4341309 Top O 2 DC/DC CONV 350MA
TK11851
N200 4370825 Top Q 7 UEMK 4.4 W-DOG
ENA
N300 4370861 Top X 4 ASIC TO06C AEM REG-
ULATOR
~LDC10B
N
~BCC_16
~SOT23L_8
~uBGA168
~uBGA80_H1.
23
N301 4341165 Bot I 3 CURRENT SENSE LM3822M
MX-1
N471 4341485 Top O 4 REG USMD5 LP2985ITLX1.8V USMD5_1.44
N472 4341485 Top P 5 REG LP2985ITLX1.8V USMD5_1.44
~ SO8_MINI
2X1.087_H0.
675
2X1.087_H0.
675
Issue 1 11/03 CopyrightNokia. All rights reserved Page 17
NHM-1 Company confidential
Nokia 6650 Parts CCS Technical Documentation
Part Code XY Name. type, size
N550 4350385 Top D 3 PW AMP RF9302E1
0.1 900/
1800MHZ
3V5
N600 4370949 Top J 3 ASIC HELGO73A ~uBGA_108_P
N810 4370963 Top C 5 REX4.1 TFA1DHDT ~ TFBGA84
N900 4370897 Top J 7 TEX3.3 TFA2CHDT ~ TFBGA84
N902 4370929 Top G 8 HEX4.2 QFN20 ~ VFQFPN_20
N950 4341269 Top J 6 REG 2.8V 150MA LP3985IBL
X USMD5
N951 4341269 Top I 6 REG 2.8V 150 MA LP3985IBL
X USMD5
N960 4350389 Top F 7 PW AMP WCDMA1900 HS/
FMM5531
ZKT
N961 4341411 Top G 5 DC/DC CONV LM2614
USMD10
~RF_AMP_RF
9203_E5_H1
.7
0.5
2.8V USMD5_1.4X
1.1
2.8V USMD5_1.4X
1.1
~ RF9212E5_H
1.25
~ USMD10_2.5
34X2.28X0.6
75
R100 1430812 Top S 8 Resistor 220k ~ 0402R
R101 1430714 Bot X 5 Resistor 33R ~ 0402R
R102 1430762 Top S 8 Resistor 2k2 ~ 0402R
R103 412008 1 Bot X 5 ASIP EMIF02-
USB02
USB/ESD
R104 1430762 Top S 8 Resistor 2k2 ~ 0402R
R105 1 825133 Bot W 6 C hip varistor 14V/50V ~ 0402_VAR
R106 1 825133 Bot W 5 C hip varistor 14V/50V ~ 0402_VAR
R107 1430754 Top T 6 Resistor 1k0 ~ 0402R
R108 1430754 Top T 6 Resistor 1k0 ~ 0402R
R109 1430754 Top S 8 Resistor 1k0 ~ 0402R
R110 1825133 Bot X 5 Chip varistor 14V/50 V ~ 0402_VAR
R111 1825133 Bot X 5 Chip varistor 14V/50 V ~ 0402_VAR
R115 1430812 Bot W 5 Resistor 220k ~ 0402R
R116 1430718 Bot W 6 Resistor 47R ~ 0402R
~uBGA_10_1.
7X2.05
R117 1430718 Bot W 6 Resistor 47R ~ 0402R
R142 1 825133 Bot E 7 C hi p varistor 14V/50V ~ 0402_VAR
Page 18 Copyright Nokia. All rights reserved Issue 1 11/03
Company confidential NHM-1
CCS Technical Documentation Nokia 6650 Parts
Part Code XY Name. type, size
R145 1 825133 Bot E 7 C hi p varistor 14V/50V ~ 0402_VAR
R146 1430762 Bot V 8 Resistor 2k2 ~ 0402R
R147 1430762 Bot V 8 Resistor 2k2 ~ 0402R
R149 1430762 Bot V 8 Resistor 2k2 ~ 0402R
R165 1430778 Bot C 2 Resistor 10k ~ 0402R
R166 1430778 Bot C 2 Resistor 10k ~ 0402R
R167 1430754 Bot C 3 Resistor 1k0 ~ 0402R
R168 1430820 Top Q 1 Resistor 470k ~ 0402R
R169 1430754 Bot J 2 Resistor 1k0 ~ 0402R
R170 1430249 Top O 3 Resistor 33R ~ 0402R
R171 1 825133 Bot J 1 Chip v ari s t o r 14 V/ 50V ~ 0402_VAR
R172 1 825133 Bot J 2 Chip v ari s t o r 14 V/ 50V ~ 0402_VAR
R173 1 825133 Bot J 2 Chip v ari s t o r 14 V/ 50V ~ 0402_VAR
R174 1 825133 Bot J 1 Chip v ari s t o r 14 V/ 50V ~ 0402_VAR
R178 1430754 Bot J 1 Resistor 1k0 ~ 0402R
R179 1430770 Bot B 6 Resistor 4k7 ~ 0402R
R183 1430754 Bot J 1 Resistor 1k0 ~ 0402R
R184 1 825133 Bot J 6 Chip v ari s t o r 14 V/ 50V ~ 0402_VAR
R186 1430754 Bot J 2 Resistor 1k0 ~ 0402R
R187 1430754 Bot J 6 Resistor 1k0 ~ 0402R
R188 1430756 Bot C 3 Resistor 1k2 ~ 0402R
R200 1414605 Top Q 8 Resistor 0R22 ~ 0805R
R201 1430804 Top R 5 Resistor 100k ~ 0402R
R202 1430804 Top S 6 Resistor 100k ~ 0402R
R203 1430796 Top P 6 Resistor 47k ~ 0402R
R204 1430770 Top O 5 Resistor 4k7 ~ 0402R
R205 1430770 Top P 5 Resistor 4k7 ~ 0402R
R207 1430804 Top T 8 Resistor 100k ~ 0402R
R208 1430804 Top S 6 Resistor 100k ~ 0402R
R209 1430804 Top S 6 Resistor 100k ~ 0402R
R210 1430754 Top O 8 Resistor 1k0 ~ 0402R
R212 1430804 Top S 6 Resistor 100k ~ 0402R
Issue 1 11/03 CopyrightNokia. All rights reserved Page 19
NHM-1 Company confidential
Nokia 6650 Parts CCS Technical Documentation
Part Code XY Name. type, size
R213 1430770 Top Q 5 Resistor 4k7 ~ 0402R
R214 1430770 Top S 6 Resistor 4k7 ~ 0402R
R300 1430681 Bot V 8 Resistor 4R3 ~ 0402R
R301 1430681 Bot V 8 Resistor 4R3 ~ 0402R
R385 4120071 Bot V 6 SIM FILTER ASIP EMIF03-SIM01 uBGA8
R400 1430710 Top T 4 Resistor 22R ~ 0402R
R401 1430786 Top R 5 Resistor 18k ~ 0402R
R402 1430726 Top O 3 Resistor 100R ~ 0402R
R403 1430726 Top P 3 Resistor 100R ~ 0402R
R407 1430778 Top T 8 Resistor 10k ~ 0402R
R408 1430778 Top T 8 Resistor 10k ~ 0402R
R430 1413850 Bot B 6 Resistor 4R7 ~ 0805R
R431 1430804 Bot D 8 Resistor 100k ~ 0402R
R450 1430770 Top V 3 Resistor 4k7 ~ 0402R
R471 1430804 Top P 5 Resistor 100k ~ 0402R
R472 1430804 Top O 4 Resistor 100k ~ 0402R
R552 1430734 Top E 3 Resistor 220R ~ 0402R
R553 1430714 Top E 3 Resistor 33R ~ 0402R
R554 1430714 Top E 3 Resistor 33R ~ 0402R
R555 1430718 Top F 2 Resistor 47R ~ 0402R
R556 1430764 Top F 3 Resistor 3k3 ~ 0402R
R557 1430764 Top E 3 Resistor 3k3 ~ 0402R
R558 1620515 Top C 3 RES NETWORK 870R/5R77/870R 0404_RAC10
R559 1620515 Top C 3 RES NETWORK 870R/5R77/870R 0404_RAC10
R601 1430700 Top K 2 Resistor 10R ~ 0402R
R603 1430865 Top J 4 Resistor 5k6 ~ 0402R
R604 1430770 Top J 4 Resistor 4k7 ~ 0402R
R606 1430784 Top I 4 Resistor 15k ~ 0402R
R607 1620033 Top J 2 RES NETWORK 2x5k6 ~ 0404_R
R608 1620033 Top K 2 RES NETWORK 2x5k6 ~ 0404_R
R641 1430770 Top H 4 Resistor 4k7 ~ 0402R
R642 1430788 Top H 4 Resistor 22k ~ 0402R
Page 20 Copyright Nokia. All rights reserved Issue 1 11/03
Company confidential NHM-1
CCS Technical Documentation Nokia 6650 Parts
Part Code XY Name. type, size
R650 1430137 Top L 2 Resistor 1k0 ~ 0402R
R651 1430907 Top L 2 Resistor 11k ~ 0402R
R652 1430681 Top K 4 Resistor 4R3 ~ 0402R
R800 1430792 Top A 3 Resistor 33k ~ 0402R
R802 1430758 Top A 3 Resistor 1k5 ~ 0402R
R807 1430726 Top B 5 Resistor 100R ~ 0402R
R816 1430867 Top C 6 Resistor 13k ~ 0402R
R818 1430700 Top C 5 Resistor 10R ~ 0402R
R822 1430710 Top L 6 Resistor 22R ~ 0402R
R824 1430774 Top J 6 Resistor 6k8 ~ 0402R
R834 1430770 Top D 6 Resistor 4k7 ~ 0402R
R844 1430804 Top E 5 Resistor 100k ~ 0402R
R845 1430804 Top E 6 Resistor 100k ~ 0402R
R907 1430770 Top I 7 Resistor 4k7 ~ 0402R
R908 1430726 Top K 8 Resistor 100R ~ 0402R
R909 1430691 Top J 9 Resistor 2R2 ~ 0402R
R910 1430788 Top K 6 Resistor 22k ~ 0402R
R912 1430754 Top L 7 Resistor 1k0 ~ 0402R
R916 1430700 Top L 8 Resistor 10R ~ 0402R
R921 1430801 Top I 7 Resistor 2k1 ~ 0402R
R922 1430867 Top J 7 Resistor 13k ~ 0402R
R924 1430748 Top I 7 Resistor 680R ~ 0402R
R928 1430748 Top H 8 Resistor 680R ~ 0402R
R931 1430832 Top H 8 Resistor 2k7 ~ 0402R
R940 1430804 Top J 6 Resistor 100k ~ 0402R
R942 1430804 Top I 6 Resistor 100k ~ 0402R
R951 1430726 Top I 6 Resistor 100R ~ 0402R
R957 1430726 Top I 7 Resistor 100R ~ 0402R
R958 1430700 Top J 8 Resistor 10R ~ 0402R
R959 1430691 Top J 8 Resistor 2R2 ~ 0402R
R960 1430762 Top E 9 Resistor 2k2 ~ 0402R
R961 1430762 Top E 8 Resistor 2k2 ~ 0402R
Issue 1 11/03 CopyrightNokia. All rights reserved Page 21
NHM-1 Company confidential
Nokia 6650 Parts CCS Technical Documentation
Part Code XY Name. type, size
R962 1430718 Top E 8 Resistor 47R ~ 0402R
R964 1430740 Top D 8 Resistor 330R ~ 0402R
R966 1430740 Top D 8 Resistor 330R ~ 0402R
R968 1430752 Top D 8 Resistor 820R ~ 0402R
R971 1430792 Top H 5 Resistor 33k ~ 0402R
R976 1430796 Top H 6 Resistor 47k ~ 0402R
R996 1430804 Top G 5 Resistor 100k ~ 0402R
R998 1430187 Top G 5 Resistor 47k ~ 0402R
S165 5209001 Bot E 1 SIDE KEY SM SW
12V 50MA
S166 5209001 Bot F 1 SIDE KEY SM SW
12V 50MA
S167 5209001 Bot H 1 SIDE KEY SM SW
12V 50MA
S168 5200051 Bot I 6 SMD DOME SWITCH 12VDC
50MA
S170 5209001 Bot A 5 SIDE KEY 12V 50MA ~ BUTTON_EVQ
T650 3640423 Top L 3 BALUN TRANS 3.7GHZ+/
-300MHZ
0805
T651 4550223 Top H 3 TRANSF BALUN 1800+-
100mhz
2x1.25
T800 4550225 Top B 7 TRANSF BALUN 2140+-
100MHZ
0805
~BUTTON_EVQ
PUA02
~BUTTON_EVQ
PUA02
~BUTTON_EVQ
PUA02
~SWITCH_SKR
M
PUA02
~TRANS_LDB1
5
~TRANS_LDB1
5
~TRANS_LDB1
5
T802 4550229 Top C 5 TRANSF BALUN 4.5G HZ+-
300MHZ
0603
T902 3640423 Top K 7 TRANSF BALUN 3.7GHZ+/-
300MHZ
0805
V100 4113721 Bot V 2 TVS DI 1PMT16AT3 ~ CASE_457
V165 4110471 Top P 2 SCH DI RB520S-
30
V430 4860151 Bot D 9 IRDA CIM 93M4
9K6-
1M152
~TRANS_LDB1
0
~TRANS_LDB1
5
~EMD2
~ CIM_93M4_
T
Page 22 Copyright Nokia. All rights reserved Issue 1 11/03
Company confidential NHM-1
CCS Technical Documentation Nokia 6650 Parts
Part Code XY Name. type, size
V550 4110079 Top F 3 SCH DIX2 HSMS282
C 15V
V960 4115861 Top E 8 SCHDIX2 BAS70-
07W
X102 5460061 Bot Y 6 SM SYSTEM CONNEC-
TOR
X166 5400211 Top N 5 SM CONN 2X25F
X300 5409211 Bot J 4 SM BATT CONN 4POL SPR ~ CONN_MQ1
X385 5409231 Bot V 4 SM SIM CONN 2X3POL
X700 5420047 Bot D 4 SM COAX CONN+SW F 50R
X962 5420047 Bot D 6 SM COAX CONN+SW F 50R
14POL ~ SYSCON_MQ
P0.5 BTB
P2.54
250V
6GHZ
250V
6GHZ
~SOT323
~ SOT343_R
202_NK_14R
3
~ MOLEX_529
91_0500
95_NK_4R
~ SIM_CONN_
2X3POL
~COAX_MM8
430
~COAX_MM8
430
Z500 4550241 Top G 2 ANT.SW+2SAW 880-960/
1710-
1990 MHZ
Z650 4511337 Top I 2 SAW FILT 897.5MHz ~ DCC6D_H1.2
Z800 4511349 Top B 5 SAW FILT 2140MHz ~ FILTER_EFCH
Z900 4511345 Top G 7 SAW FILT 1950MHz ~ DCC6D
Z960 4512163 Top C 8 DUPL 1920-1980/2110-
2170MHz
Z962 4510375 Top D 8 ISOLATOR 1950+-30MHZ/13DB
4X4X1.7
~ANT_SW_LM
SP65GA
25
2140MTE2
DFYK61G95L
BJBA_X
SI_4AA
Issue 1 11/03 CopyrightNokia. All rights reserved Page 23
NHM-1 Company confidential
Nokia 6650 Parts CCS Technical Documentation
Parts list, User Interface module NB1
Version NB1_09
Item Code Side, X, Y Name Type
C100 2320481 Top Z 2 Chipcap 1u0 6.3V 0603C
C101 2320481 Top Y 2 Chipcap 1u0 6.3V 0603C
C103 2320778 Top Z 8 Chipcap 10n 16V 0402C
C106 2320778 Top C 2 Chipcap 10n 16V 0402C
C107 2320778 Top C 2 Chipcap 10n 16V 0402C
C109 2320481 Top Y 2 Chipcap 1u0 6.3V 0603C
C110 2320744 Top B 7 Chipcap 1n0 50V 0402C
C111 2320744 Top B 7 Chipcap 1n0 50V 0402C
G100 4510377 Top Y 8 TCXO 26MHz 2.4V 2MA
L102 3203801 Top B 6 Chip bead
array
N100 4341063 Top Y 2 REG LP3985 2.8V/
R101 1430700 Top Z 8 Resistor 10R ~ 0402R
R102 1825033 Top Y 2 Chip varistor 14V/46V ~ 0402_V
R103 1825033 Bot N 4 Chip varistor 14V/46V ~ 0402_V
R104 1825033 Bot N 5 Chip varistor 14V/46V ~ 0402_V
R105 1825033 Bot N 6 Chip varistor 14V/46V ~ 0402_V
R106 1825033 Bot N 6 Chip varistor 14V/46V ~ 0402_
R107 1825033 Bot N 3 Chip varistor 14V/46V ~ 0402_
R108 1825033 Bot N 4 Chip varistor 14V/46V ~ 0402_
R109 1825033 Bot N 4 Chip varistor 14V/46V ~ 0402_
R110 1825033 Bot N 4 Chip varistor 14V/46V ~ 0402_
R111 1825033 Bot N 4 Chip varistor 14V/46V ~ 0402_
R112 1825033 Bot N 4 Chip varistor 14V/46V ~ 0402
2x1000R/
100MHz
0405_2
SOT23
150MA
R113 1825033 Bot N 6 Chip varistor 14V/46V ~ 0402
R114 1825033 Bot N 6 Chip varistor 14V/46V ~ 0402_
R115 1430754 Top C 7 Resistor 1k0 ~ 0402R
R116 1825033 Top B 6 Chip varistor 14V/46V ~ 0402_V
R117 1825033 Top B 7 Chip varistor 14V/46V ~ 0402_V
Page 24 Copyright Nokia. All rights reserved Issue 1 11/03
Company confidential NHM-1
CCS Technical Documentation Nokia 6650 Parts
Item Code Side, X, Y Name Type
V100 4350289 Top Y 5 BLUETOOTH LRB-2 ~ BT102_
X
V101 4864525 Top W 6 LED CL270WBKE ~
V102 4864525 Top W 4 LED CL270WBKE ~
X100 5469179 Bot O 5 SM connector 2X25 M P0.5 PWB/PWB
X101 5469189 Top C 1 SM connector 2X9 F P0.5 50V 0.3A B2B
Issue 1 11/03 CopyrightNokia. All rights reserved Page 25
NHM-1 Company confidential
Nokia 6650 Parts CCS Technical Documentation
Page 26 Copyright Nokia. All rights reserved Issue 1 11/03
Loading...
