RM-1 product selection
Nokia RM-1 is a WCDMA/GSM dual mode handportable phone, supporting WCDMA 2000 (UMTS) and EGSM 900/
1800/1900 bands.
According to GSM standard 05.05 it responds to class 4 (max. 2W) in EGSM 900, class 1 (1W) in DCS 1800 and
class 1 in PCS 1900. RM-1 supports EGPRS (EDGE) class B as well as Bluetooth 1.1 standard. The handset has a full
phase 2 Type Approval and it complies with the GSM Type Approval. RM-1 also has a full CE approval and FCC
approval.
RM-1 is an MMS (Multimedia Messaging Service) enabled phone with a large bright colour display and an
integrated 1.3 megapixel digital camera.
The MMS implementation follows the OMA MMS standard release 1.2.
WAP 2.0 compatible browser supports XHTML Mobile Profile (MP) and uses a TCP/IP stack to communicate with
a gateway in network.
RM-1 uses Symbian 8.0a operating system and supports also MIDP Java 2.0 & CLDC1.1, providing a good platform
for 3rd party applications.
RM-1 runs a 3G radio, Symbian operating system and Nokia Series 60 user interface.
Figure 1 View of RM-1
RM-1 transceiver features
Display and keypad features
• Active matrix colour display (176x208, 65k colors)
• Automatic brightness control for display (>200Cd/m2)
• Graphical user interface with selectable themes
• 5-way scroll, two softkeys, application-key, edit and clear key, send & end + key matrix
• Voice key for voice dialling and commands
Issue 1 Company Confidential Page 1–5
Copyright © 2004 Nokia. All Rights Reserved.
RM-1
Nokia Customer Care General Information
Hardware and software characteristics
• Monoblock, BB5.0
• 10 MB flash for user data + RS MMC card slot
• Quadband EGSM 900/1800+1900+WCDMA 2GHz, internal antenna
• Speech codecs: FR,EFR, AMR
• Integrated 1.3 megapixel camera
• Integrated Bluetooth & USB 2.0 full speed (12Mbps nominal)
• Integrated handsfree speaker, internal vibra
• SP-MIDI, XMF & true tones for ringtones and alerts
• Support for 3GPP video streaming and video capture (codec: h.263 baseline)
• GPRS, class B, multislot class 10, EGPRS cl. 6, WCDMA PS max speeds UL/DL 128/128 kbps, or 128/384kbps.
WCDMA CS 64kpbs
• XHTML browser with true Internet capability
• SWIM and DRM combined & separate delivery
• Real time clock + 20h backup battery
•
Pop-portTM connector
UI features
• Advanced camera modes: still, burst and video.
• Digital zoom up to 6X
• Image/video sending during phone call
• MMS text messages with images, sounds, video- or audio clips. (SMIL x.y)
• Multimedia player with streaming support (Real Player)
• New improved multimedia gallery
• Downloadable instrumental ringing tones (SP-MIDI, XMF), true tones (WB-AMR/MP3/AAC)
• Advanced S60 PIM (calendar, contacts, task list, etc.)
• Voice dialling and voice commands
• Off-line mode (phone use without SIM/network)
• Voice recording
• Muvee automatic video editing
• Manual video editing
• Start up wizard for easy configuration
• NVO hoover
Sales package
• RM-1 transceiver
• Charger ACP-12
• Battery BL-5C
• CD-ROM containing software and guides
• User guide
• Stereo headset HS-3
• RS -MMC 64MB memory card
• Adapter for MMC
• USB cable DKU-2
Page 1–6 Company Confidential Issue 1
Copyright © 2004 Nokia. All Rights Reserved.
RM-1
General Information Nokia Customer Care
Product and module list
Module name Type code Material code Notes
System/RF Module 1AX 202190 Main PWB with
components
UI Module 1AY 202191 Keyboard PWB with
components. Part of the
UI Frame Assy
Camera Module 4858047 Mirage-1.3X
Display Module 4850851 HALTI2
Chassis Assy 9467135 Mechanical Assembly
UI Frame Assy 9467138 Mechanical Assembly
SW Module N/A N/A
RM-1 mobile enhancements
Battery Type Product code
Battery 900mAh Li-ion BL-5C 0273558
Chargers Type Product code
Fast travel charger (multivoltage), Australia
Fast travel charger (multivoltage), Argentina
Fast travel charger (multivoltage), China
Fast travel charger (Euro plug),
100- 240 Vac
Fast travel charger (US plug), 100240 Vac
Travel charger (multi-voltage),
Brazil/Portugal
ACP-12A N/A
ACP-12AR N/A
ACP-12C N/A
ACP-12E 0273386
ACP-12US N/A
ACP-12UB N/A
Fast travel charger, Japan ACP-12J N/A
Fast travel charger (gradiente
CR1000), Brazil
Fast travel charger (UK plug),
multi-voltage
Retractable travel charger
(Europe)
Issue 1 Company Confidential Page 1–7
ACP-12G N/A
ACP-12X 0273387
AC-1E 0274390
Copyright © 2004 Nokia. All Rights Reserved.
RM-1
Nokia Customer Care General Information
Chargers Type Product code
Retractable travel charger (UK) AC-1X 0274387
Car accessories Type Product code
Mobile charger (EA, APAC, Americas) LCH-12 0274039
Wireless car kit (sales pack) CK-7W 0080948
Pop Port ™ accessories Type Product code
Boom mono headset HDB-4 0273504
Fashion stereo headset HDS-3 0273505
Mono headset HS-5 0274086
Stereo headset HS-3 0274576
Retractable headset HS-10 0274162
USB data cable DKU-2 0273643
Loopset LPS-4 0273270
FM radio headset HS-2R 0273951
Imaging accessories Type Product code
Nokia image viewer SU-5 0274284
Nokia image album PD-1 0080855
Camera flash PD-2 N/A
Nokia video call stand PT-8 0277825
Bluetooth accessories Type Product code
Bluetooth car kit (sales pack)
(EURO 1)
Bluetooth image viewer SU-5 0274284
Bluetooth QWERTY keypad
(Scandinavian EURO 1)
CK-7W 0080948
SU-8W 0277890
Nokia digital pen (Eur/US) SU-1B 0274231
Wireless headset HDW-3 0274141
HS-3W 0274424
HS-4W 0274702
HS-11W N/A
FM radio headset HS-2R 0274111
Inductive loopset LPS-4 0273270
Page 1–8 Company Confidential Issue 1
Copyright © 2004 Nokia. All Rights Reserved.
RM-1
General Information Nokia Customer Care
Bluetooth accessories Type Product code
Wireless GPS module LD-1W N/A
Other accessories Type Product code
Xpress-on colour covers Green CC-215D N/A
Red CC-215D N/A
Blue CC-215D N/A
Beige CC-215D N/A
RS multimedia card 64 MB MU-1 0278205
Carrying case N/A N/A
Neck strap N/A N/A
Technical specifications
RM-1 transceiver general specifications
Unit Dimensions (L x W x T) Weight (g) Volume (cm3)
Transceiver with BL-5C
900mAh li-ion battery
back
110 x 60 x 20.6 127 109cc
Main RF characteristics for triple-band (GSM900/1800/1900) and WCDMA phones
Parameter Unit
Cellular system EGSM900, GSM1800/1900 and WCDMA
Rx frequency band EGSM900: 925 - 960 MHz
GSM1800: 1805 - 1880 MHz
GSM1900: 1930 - 1990 MHz
WCDMA: 2110 - 2170 MHz
Tx frequency band EGSM900: 880 - 915 MHz
GSM1800: 1710 - 1785 MHz
GSM1900: 1850 - 1910 MHz
WCDMA: 1920 - 1980 MHz
Output power GSM900: +5 … +33dBm/3.2mW … 2W
GSM1800: +0 … +30dBm/1.0mW … 1W
GSM1900: +0 … +30dBm/1.0mW … 1W
WCDMA -50 … 21 dBm
Issue 1 Company Confidential Page 1–9
Copyright © 2004 Nokia. All Rights Reserved.
RM-1
Nokia Customer Care General Information
Parameter Unit
Number of RF channels GSM900: 125
GSM1800: 375
GSM1900: 300
Channel spacing 200 kHz
Number of Tx power levels GSM900: 15
GSM1800: 16
GSM1900: 16
Battery endurance
Battery Capacity (mAh) Talk time Stand-by
BL-5C 900 up to 2.2-3.2 hrs
(WCDMA) and 3-6 hrs
(GSM)
Charging times
ACP-12 LCH-12
1 h 15 min 1 h 15 min
Environmental conditions
Environmental condition Ambient temperature Notes
Normal operation
Reduced performance
Intermittent operation
No operation or storage
-15oC...+55oC
-25oC...-15oC
+55oC...+70oC
-40oC...-15oC
+70oC...+85 oC
<-40oC...>+85oC
Specifications fulfilled
Operational for shorts periods
only
Operation not guaranteed but an
attempt to operate does not
damage the phone.
No storage or operation: an
attempt may damage the phone.
up to 6 - 11 days
Charging allowed
Long term storage conditions
Page 1–10 Company Confidential Issue 1
-25oC...+50oC
0oC...+85oC
