2010 ROGUE Quick Reference Guide
|
|
|
|
01 |
|
|
02 |
03 |
04 |
|
|
05 |
|
06 |
|
|
|
|
|
|
|
|
|
14 |
|
|
07 |
|
08 |
|
|
|
|
15 |
09 |
10 |
11 |
|
12 |
|
|
|
|
|
|
|
|
|
16 |
|
13 |
|
|
|
|
|
|
|
17 |
01 |
TRIP COMPUTER |
02 |
LOW TIRE PRESSURE WARNING LIGHT |
03 |
INSTRUMENT BRIGHTNESS CONTROL* |
04 |
TRIP CHANGE BUTTON |
05 |
HEADLIGHT AND TURN SIGNAL CONTROL |
06 WINDSHIELD WIPER/WASHER SWITCH
07STEERING WHEEL SWITCHES FOR AUDIO CONTROL/BLUETOOTH®
08 |
CRUISE CONTROL |
09 |
HEADLIGHT AIMING CONTROL |
10AWD LOCK SWITCH
11VEHICLE DYNAMIC CONTROL (VDC) OFF SWITCH
12STEERING WHEEL TILT ADJUSTMENT*
13HOOD RELEASE*
14 |
AUDIO SYSTEM |
15 |
AUXILIARY INPUT JACK* |
16 |
MANUAL CLIMATE CONTROL |
17FRONT PASSENGER AIR BAG STATUS LIGHT
*See your Owner’s Manual for more information.
TABLE OF CONTENTS
Remote Keyless Entry System (if so equipped) . . . . . . . . . . . . 2 NISSAN Intelligent Key™ (if so equipped) . . . . . . . . . . . . . . 2 Automatic Door Locks . . . . . . . . . . . . . . . . . . . . . . . 3 Windshield Wiper/Washer Switch . . . . . . . . . . . . . . . . . . 4
Headlight and Turn Signal Control . . . . . . . . . . . . . . . . . |
. 4 |
Headlight Aiming Control Switch (if so equipped) . . . . . . . . . . . |
5 |
Steering Wheel Switches for Audio Control/Bluetooth® |
|
(if so equipped) . . . . . . . . . . . . . . . . . . . . . . . . . |
5 |
Cruise Control . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Manual Climate Control . . . . . . . . . . . . . . . . . . . . . . 6
FM/AM/XM®* Radio with CD Changer (if so equipped) . . |
. |
. |
. |
. . . . 7 |
|||
Vehicle Information Display . . . . . . . . . . . . . . . . . . . . . 9 |
|||||||
Clock Set/Adjustment . . . . . . . . . . . . . . . . |
. |
. |
. |
. |
. |
. |
. 9 |
Trip Computer (if so equipped) . . . . . . . . . . . . |
. |
. |
. |
. |
. |
. |
. 9 |
Continuously Variable Transmission (CVT) . . . . . . . . |
. |
. . . . . 10 |
|||||
AWD Lock Switch (if so equipped) . . . . . . . . . . . |
. |
. . . . . 10 |
|||||
Vehicle Dynamic Control (VDC) OFF Switch . . . . . . . |
. |
. . . . . 10 |
|||||
Front Passenger Air Bag Status Light . . . . . . . . . . |
. |
. . . . . 11 |
|||||
Tire Pressure Monitoring System (TPMS) . . . . . . . . |
. |
. |
. . . . 11 |
||||
Seat Belt Warning Light and Chime . . . . . . . . . . |
. |
. |
. . . . 11 |
||||
Child Safety Rear Door Locks . . . . . . . . . . . . . |
. |
. . . . . 12 |
|||||
Moonroof Controls (if so equipped) . . . . . . . . . . . |
. . . . . . 12 |
||||||
Front Seat Adjustments . . . . . . . . . . . . . . . . . . . . . 12 |
|||||||
Folding the Front-Passenger’s Seat Down (if so equipped) . |
. |
. . . . . 13 |
|||||
Folding the Rear Seatbacks Down . . . . . . . . . . . |
. |
. . . . . 13 |
|||||
Bluetooth® Hands-free Phone System (if so equipped) . . . |
. |
. |
. |
. |
. |
|
. 14 |
This easy-to-use Quick Reference Guide is intended to help you more fully appreciate some of the unique features and functions of your new vehicle. However, it is not intended to replace your Owner’s Manual. The Owner’s Manual contains more detailed information to help you better understand the important safety warnings, features, operation and maintenance of your vehicle. All information, specifications, photographs and illustrations in this publication are those in effect at the time of printing. NISSAN reserves the right to change specifications or design without notice and without obligation.
REMOTE KEYLESS ENTRY SYSTEM (if so equipped)
LOCK DOORS
Press the button to lock all doors.
UNLOCK DOORS
Press the button once to unlock the driver’s door only. Press the button again within 5 seconds to unlock all doors.
USING THE PANIC ALARM
Press and hold the button for longer than 0.5 seconds. The panic alarm will sound and the headlights will stay on for 25 seconds. The panic alarm stops when it has run for 25 seconds or when any button on the keyfob is pressed.
SILENCING THE HORN BEEP FEATURE
To deactivate: Press and hold the and buttons for at least 2 seconds. To activate: Press and hold the and buttons for at least 2 seconds.
NISSAN INTELLIGENT KEYTM (if so equipped)
The NISSAN Intelligent KeyTM allows you to lock or unlock your vehicle and start the engine.
NOTE: It is important to make sure the Intelligent Key is with you (that is, in your pocket or purse).
The operating range of the door lock/unlock function is approximately 31.50 in (80 cm).
Locking the vehicle - Push any door handle Request Switch 01 once.
Unlocking the vehicle - Push any door handle Request Switch 01 once. The corresponding door will unlock. Push the door handle Request Switch 01 again within 1 minute; all other
doors will unlock.
01
STARTING THE ENGINE
Push the ignition knob in.
Confirm the Intelligent Key system warning light is illuminated green.
Turn the ignition knob to the START position to start the engine.
2
TURNING THE ENGINE OFF
Shift the transmission into P (Park).
Turn the ignition knob to the LOCK position.
An audible warning chime will sound when exiting the vehicle if the ignition knob is not completely turned to the OFF position.
AUTOMATIC DOOR LOCKS
All doors lock automatically when the vehicle speed reaches 15 MPH (24 km/h).
All doors unlock automatically when the ignition is placed in the OFF position (Intelligent Key equipped vehicles) or when the key is removed from the ignition switch (mechanical key equipped vehicles).
The automatic lock and unlock functions can be deactivated or activated independently of each other. To deactivate or activate the automatic door lock or unlock system, perform the following procedure:
1.Close all doors.
2.Place the ignition switch in the ON position.
3.Do one of the following within 20 seconds of performing Step #2:
•To change AUTO UNLOCK settings: Push and hold the power door lock switch to the (UNLOCK) position for more than 5 seconds.
•To change AUTO LOCK settings: Push and hold the power door lock switch to the (LOCK) position for more than 5 seconds.
4.When activated, the hazard indicator will flash twice. When deactivated, the hazard indicator will flash once.
5.The ignition switch must be placed in the OFF and ON position again between each setting change.
WINDSHIELD WIPER/WASHER SWITCH
|
The ignition switch must be in the ON position to |
|
04 |
|||
|
|
|||||
|
activate the windshield wipers. |
|
|
|||
|
|
|
|
|||
|
Move the lever to the following positions to operate |
1B |
05 |
|||
|
||||||
|
the windshield wipers: |
|
||||
|
|
|
||||
|
|
|
|
|
||
|
|
1A |
Intermittent (INT) – Front wipers operate |
|
|
|
|
|
|
intermittently and can be further adjusted by |
|
|
|
|
|
|
twisting the time control ring |
1B . |
|
|
02Low Speed (LO) – Continuous low-speed operation of front wipers.
03High Speed (HI) – Continuous high-speed operation of front wipers.
1A
02
03
04 Mist (MIST) – Lift the lever up for one sweep of the front wipers.
05Rear Wiper (REAR) – Twist the end section to operate the first (INT) or second (ON) speed settings for the rear wipers.
The washer function activates the washer fluid and several sweeps of the wipers:
•For FRONT WASHER, pull lever toward you.
•For REAR WASHER, push lever away from you.
HEADLIGHT AND TURN SIGNAL CONTROL
HEADLIGHT CONTROL SWITCH
Turn the headlight control switch 01 to the |
position |
01 |
02 |
|
to turn on the front parking, tail, license plate and instrument |
||||
|
|
|||
panel lights. |
|
|
|
Turn the headlight control switch 01 to the position to turn on the headlights. All other lights remain on.
FOG LIGHT OPERATION
NOTE: The headlights must be on and the low beams selected for the fog lights to operate.
Turn the switch (inside collar) 02 to the position to turn on the fog lights.
Turn the switch (inside collar) 02 to the OFF position to turn off the fog lights.
HIGH BEAM
Push the headlight control switch forward A |
to select |
A |
||
the high beam function. The blue |
indicator light |
|||
|
||||
illuminates. Pull the headlight switch back to the original |
|
|||
position to select the low beam. The blue |
indicator |
|
||
light goes off. |
|
|
|
|
Pull and release the headlight control switch |
B to |
B |
||
flash the headlight high beams on and off. |
|
|||
|
|
4
