Ninja CF080A, CF080W, CF080Z, CF081 Owner's Manual
CF081 series
®
OWNER’S GUIDE
COFFEE BAR
®
ninjakitchen.com
1-877-646-5288
IMPORTANT SAFEGUARDS
For Household Use Only
READ ALL INSTRUCTIONS BEFORE USING
YOUR NINJA COFFEE BAR®.
Safety Signal Words
This manual and the safety labels attached to this
appliance utilize signal words that signify safety
hazards with different levels of severity.
Below are the words used and the definitions for
these words:
• WARNING indicates a hazardous situation
which, if not avoided, could result in death or
serious injury.
• CAUTION indicates a hazardous situation
which, if not avoided, could result in minor or
moderate injury.
• NOTICE is used to address practices not
related to physical injury.
The words “WARNING” and “CAUTION” are
preceded by a triangle signifying that these are
safety related.
The terms “IMPORTANT” and “NOTE” are also
used to describe good ideas for better and more
efficient equipment use.
THIS BOOK COVERS MODEL NUMBERS:
CF081 CF080A
CF080Z CF080Q
CF080W
TECHNICAL SPECIFICATIONS
Voltage: 120V~, 60Hz.
Power: 1450 Watts
Water Reservoir
Capacity: 43 Ounces
WARNING:
To reduce the risk of fire, electric shock, serious
injury, death or damage when using this
appliance, follow these basic safety precautions.
General Precautions
1 Do not allow the appliance to be used by
children. Close supervision is necessary
when used near children. This is not a toy.
2 To reduce the risk of electric shock, this
appliance has a polarized plug (one blade is
wider than the other). As a safety feature,
this plug will fit into a polarized outlet only
one way. If the plug does not fit fully into the
outlet, reverse the plug. If it still does not fit,
contact a qualified electrician. Do not force
into outlet or try to modify to fit.
3 To protect against electrical shock, do not
submerge the appliance or allow the power
cord to come into contact with water or any
other liquid.
4 Allow the appliance to cool before taking off
parts and before cleaning.
5 Do not abuse the power cord. Never carry
the appliance by the power cord or yank it
to disconnect from electrical outlet; instead
grasp the plug and pull to disconnect.
6 Do not operate any appliance with a
damaged cord or plug, or after the appliance
malfunctions, has been dropped or damaged
in any manner.
7 Do not let the power cord hang over the edge
of table or counter or touch hot surfaces
such as the stove.
8 Do not remove the brew basket or carafe
while the appliance is brewing. Scalding
may occur if any of these parts are
removed during brewing cycles.
1
1-877-646-5288
9 The use of an accessory not recommended
by the manufacturer may result in fire,
electric shock, create an overflow condition
and scalding hazard or personal injury.
10 Do not operate your appliance in an
appliance garage or under a wall cabinet.
When storing in an appliance garage always
unplug the unit from the electrical outlet. Not
doing so could create a risk of fire, especially
if the appliance touches the walls of the
garage or the door touches the unit as it
closes.
Operating Notice
11 Clogging and backing up of water and/or
coffee in the filter basket can occur under
any or a combination of any of the following
conditions: The use of too finely ground
coffee, using two or more paper filters, using
the permanent filter in conjunction with a
paper filter, not cleaning coffee grounds
from the permanent filter, or allowing coffee
grounds to spill over the filter.
12 Always use appliance on a dry, level surface.
13 Do not use this appliance for anything other
than its intended use. Do not use outdoors.
14 Do not touch hot surfaces. Use handles
orknobs.
15 Do not touch warming plate while the brewer
is in use.
Glass Carafe
16 The carafe is designed for use with this
appliance. It must never be used on a range
top.
17 Do not set a hot carafe on a wet or cold
surface.
18 Do not use a cracked or scratched carafe or
a carafe having a loose or weakened handle.
19 Do not clean carafe with abrasive cleansers,
steel wools pads, or other abrasive material.
20 Do not place carafe in microwave.
21 Do not expose carafe to extreme temperature
changes.
22 Do not place on or near a hot gas or electric
burner or in a heated oven.
23 Do not use for carbonated beverages.
24 Do not drink directly from the carafe! Liquid
from the carafe may be very hot!
25 Do not use the carafe to store any other type
of food when not in use.
26 Ensure that the carafe is completely empty
before starting a cleaning or brewing cycle.
Starting a cycle with water or coffee in the
carafe will cause an overflow.
Maintenance
27 Remove the power cord from the electrical
outlet, allow to cool before removing brew
basket, water reservoir, or filters and before
surface cleaning.
28 Clean the glass carafe with a soft brush or
sponge. Do not use a wire brush.
29 To prevent illness from bacterial growth in
the appliance, follow all cleaning instructions
in the “Care & Maintenance” section of this
owner’s guide.
30 If the product is not operating properly
contact SharkNinja Operating LLC at
1-877-646-5288 or ninjakitchen.com for
examination, repair or adjustment.
31 Clean the system on a weekly basis.
Cord Statement
32 A short power-supply cord is provided to
reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
33 Do not use extension cord with this product.
SAVE THESE
INSTRUCTIONS
ninjakitchen.com
2
3
1-877-646-5288
Contents
Thank you for
purchasing the
Ninja Coffee
Bar®.
Getting To Know Your Ninja Coffee Bar® .......................................................................................5
Control Panel .............................................................................................................................6
Features Of The Ninja Coffee Bar .................................................................................................7
Before First Use . .......................................................................................................................8
Setting The Clock And Delay Brew ...............................................................................................9
Assembly ................................................................................................................................10
Preparing For Use ....................................................................................................................12
Filling The Water Reservoir ....................................................................................12
How Much Coffee Do You Get In Your Cup...............................................................12
Would You Like A Hotter Coffee ..............................................................................13
Filling The Brew Basket With Coffee .......................................................................13
Drip Stop ..............................................................................................................14
Intelligent Warming Plate .......................................................................................14
Stay Warm Button .................................................................................................14
Brewing Coffee .....................................................................................................15
Classic And Rich Brew .......................................................................................15
Over Ice Brew ...................................................................................................16
Specialty Brew ..................................................................................................16
Care & Maintenance ................................................................................................................17
Cleaning After A Brew ...........................................................................................17
Cleaning Your Carafe ............................................................................................ 17
Cleaning Your Water Reservoir ..............................................................................17
Cleaning & Descaling Your Brewing System ............................................................ 18
Troubleshooting Guide ..............................................................................................................19
Replacement Parts ...................................................................................................................21
Warranty & Registration ............................................................................................................22
ninjakitchen.com
4
Getting To Know Your Ninja Coffee Bar
®
e
a
b
f
g
l
h
c
i
AM
H
PM
M
DELAY
BREW
STA
Y WARM
TRAVEL HALF
CUP
FULL
OFF
j
k
CLASSIC BREW
RICH BREW
OVER ICE BREW
SPECIALTY BREW
(CONCENTR
CLEAN
A
TED
COFFEE
)
DRIP
STOP
d
m
a Flip Top Water Reservoir Lid
b Removable Water Reservoir
c Brewer
d Control Panel
e Permanent Filter
f Removable Brew Basket
g Drip Stop Toggle
5
1-877-646-5288
h Brew-Through Carafe Lid
i Glass Carafe
j Multi-Serve Cup Platform
k Intelligent Warming Plate
l Double Sided Scoop: Carafe Side and Single Serve Side
m Power Cord & Wrap (not shown)
Control Panel
LH
AM
1
PM
DELAY BREW
3
5b
TRAVE
5a
CUP
6a
OFF
CLASSIC BREW
STAY WARM
ALF
FULL
1 Programmable Digital Clock
H
2
M
4
5c
5d
2 Clock Hour and Minute Buttons
3 Delay Brew Button
4 Stay Warm Button
5 Multi-Serve Dial
a Cup
b Travel Mug
c Half Carafe
d Full Carafe
e Off - Turns off all functions except the clock
6 Brew Types
a Classic Brew Button
b Rich Brew Button
c Over Ice Brew Button
d Specialty Brew Button
7 Intelligent Clean Cycle Indicator/Button
8 Drip Stop Indicator
6b
6c
6d
7
RICH BREW
OVER ICE BREW
SPECIALTY BREW
(CONCENTRATED COFFEE)
CLEAN DRIP STOP
8
ninjakitchen.com
6
Features of the Ninja Coffee Bar
®
• Thermal Flavor Extraction® Technology - Blends Precision Water Delivery with automated controls for Calibrated Temperature, Preinfusion, Coffee Saturation, and Flavor Richness. Ninja’s Thermal Flavor Extraction technology can truly unlock the full flavor potential of
your coffee.
• Multi Serve – Ability to brew directly into your favorite cup, travel mug, or carafe.
• Brew Types – Control the strength and style of your coffee:
a. Classic Brew for smooth, balanced hot coffee.
b. Rich Brew for a richer-than-classic and still smooth coffee with more room for milk and cream.
c. Over Ice Brew for smooth, rich, freshly brewed iced coffee that’s not watered down.
d. Specialty Brew for a strong extract for specialty milk based drinks or blended iced drinks.
• Multi Serve Cup Platform – Pull it down and place your favorite cup on it and brew directly into it.
• Removable Water Reservoir with Easy Access Flip Top Lid – For quick and easy filling.
• AUTO-iQ® – The Ninja Coffee Bar® knows how much water to use for each size and brew type.
• 43 oz Glass Carafe
• LED Control Panel with Programmable Digital Clock
• 24-HR Programmable Delay Brew Button – Set it to automatically brew the following morning.
• Drip Stop – Stops the flow of coffee from the brew basket allowing you to pour a cup mid-brew; switch toggle to the closed position to
prevent dripping once the brew cycle is finished.
• Clean Function – It illuminates when your Ninja Coffee Bar senses that there is hard water calcium build up in your brewer which can
affect the flavor of your coffee. When it illuminates, follow the cleaning instructions in the Care & Maintenance section or printed on the
back of your brewer.
• Stay Warm Button – Your warming plate will automatically turn on after brewing a carafe and turn off after 2 hours. The Stay Warm
button allows you to manually turn the warming plate off.
• Intelligent Warming Plate – Automatically adjusts the temperature of the warming plate to keep your coffee at the ideal drinking
temperature without burning it.
• Pre-Heat Mode – The Ninja Coffee Bar brewer will be in an idle mode keeping the internal water pre-heated for 72
hours.
• Sleep Mode – After 72 hours the Ninja Coffee Bar will enter sleep mode to conserve energy or turn the Multi-Serve dial
to “OFF” to manually turn off the pre-heat and all other functions.
• Audible Ready Signal – Alerts you that your coffee is ready.
• 2 hour shut off – Automatically turns off the warming plate two hours after you brew coffee.
• Permanent Filter - The permanent filter is a reusable filter that preserves the natural coffee oils and small coffee particles to provide
a robust flavor, similar to what you would experience when using a French press.
Brew into a cup, travel mug, or classic carafe or half carafe.
Multi Serve
Classic Carafe or Half CarafeTravel MugCup
AM
AM
H
PM
M
DELAY
BREW
STA
Y WARM
TRAVEL HALF
CUP
FULL
OFF
CLASSIC BREW
RICH BREW
OVER ICE BREW
SPECIALTY BREW
(CONCENTR
A
TE
D
COFFEE
)
CLEAN
DRIP
STOP
7
1-877-646-5288
AM
H
PM
M
DELAY
BREW
STA
Y WARM
TRAVEL
HALF
CUP
FULL
OFF
CLASSIC BREW
RICH BREW
OVER ICE BRE
W
SPECIALTY BREW
(CONCENTR
A
TE
D
COFFEE)
CLEAN
DRIP
STOP
PM
DELAY
BREW
TRAVEL HALF
CUP
OFF
CLASSIC BREW
OVE
SPECIALTY BREW
(CONCENTR
CLEAN
H
M
STA
Y WARM
FULL
RICH BREW
R ICE BREW
A
TE
D
COFFEE)
DRIP
STOP
Loading...
