USER MANUAL
1
SUMMARY
PREFACE ................................................................................................................................................................. 4
PRECAUTIONS ..................................................................................................................................................... 4
DESCRIPTION....................................................................................................................................................... 4
TECHNICAL SPECIFICATIONS ....................................................................................................................... 4
STRUCTURE .......................................................................................................................................................... 6
MINI UP Structure ............................................................................................................................................ 6
Status led ............................................................................................................................................................. 6
START UP ............................................................................................................................................................... 7
Charge ................................................................................................................................................................. 7
Inserting and removing the memory card ................................................................................................... 7
FUNCTION KEYS AND OPERATING MODES........................................................................................... 8
PARAMETERS SETTING ..................................................................................................................................... 8
VIDEO PARAMETERS SETTING ...................................................................................................................... 9
Video resolution ................................................................................................................................................ 9
Enter date ........................................................................................................................................................... 9
Loop video .......................................................................................................................................................... 9
PHOTO PARAMETER SETTINGS .................................................................................................................. 11
SETUP PARAMETER SETTINGS ..................................................................................................................... 13
VIEWING PHOTOS AND VIDEOS ............................................................................................................... 17
2
COMPUTER CONNECTION ......................................................................................................................... 18
PRECAUTIONS ................................................................................................................................................... 19
INCLUDED IN THE PACK .............................................................................................................................. 20
INSTRUCTIONS FOR THE ENVIRONMENT ............................................................................................ 21
3
PREFACE
Thank you for choosing MINI UP, the high-definition digital camera. Easy to use, compact and with an integrated design. With its high-definition and dynamic image capturing technology it can record your daily activities at anytime and anywhere. So you can remember your experiences and share them with your family and friends. This manual will clearly explain you how to use and install the video camera, providing detailed information as well as technical specifications. Please read this Manual carefully before the use and keep it for long-term reference.
PRECAUTIONS
Please observe the following points when using MINI UP:
• Do not drop, hit or shake the camera.
• Keep the device away from any electromagnetic source, such as magnets or electro
motors, or from any other object emitting strong radio waves, like antennas. Strong magnetic fields may cause failures to the camera or damages to image and audio.
• Do not expose the camera to high temperatures or directly to sunlight.
• Keep the memory card away from electromagnetic sources, such as TVs, speakers or
magnets. Do not put it in any place with potential static, as the data stored may be lost.
• If the device overheats, smokes or smells in charging, please disconnect the power supply immediately.
• Keep the camera out of the reach of children in charging, as the power cord may cause accidental suffocation or electric shock.
• Keep the camera in a cool, dry and dust-free place.
• Use a lens and screen guard to prevent scratching or permanent damages.
• Use a cloth and specific products to clean the lens and screen; do not use any organic
solvent.
DESCRIPTION
The MINI UP camera is able to perform the following functions:
l
High definition (HD) video recording and photos.
l
Real-time image display.
l
Recorded video recall function.
l
Photo files recall function.
l
2.0 USB High-Speed data transfer.
l
USB cable for battery charging.
l
All accessories are easy to use to facilitate shooting in any place and at any time.
Supplemented by its accessories, this product is the result of multiple patented technologies and can be used for recording anything, anytime, anywhere.
TECHNICAL SPECIFICATIONS
MINI UP camera has the following specifications:
4
• Image sensor: 5.0 mega-pixel CMOS
• Functions: Video recording, photos, preview
• Screen: LCD 1.5”
• Photo resolution: 5M (2592 x1944), 3M (2048 x1536)
• Video resolution: HD (1280x720 30fps), WGA (6400x480 30fps)
• External memory: TF card (Maximum 32GB)
• File format: JPEG, H.264
• USB Port: USB 2.0
• Battery: Internal 3.7V rechargeable lithium battery
• Menu: English, Italian, German, French, Spanish, Portuguese, Greek, Czech, Slovak, Hebrew
• Supported operating systems Windows XP/Vista/7/8, Mac 10.2
• Dimensions: 58x40x23 mm
• Weight (without case) 59 gr.
5
STRUCTURE
1) Switch: cam on and off;
lightly press to cyclically
switch the cam between
recording, display and
setup modes.
2) Charge LED: when lit,
the cam is charging.
MINI UP STRUCTURE
3) Status LED: lit during video recording.
4) Video recording start and stop key.
5) Scroll menu up key.
6) Scroll menu down key and photo shutter key.
STATUS LED
The status led (5) turns on:
• When the camera is on.
• When the camera is charging.
4) MicroSD card slot.
8) One-way USB interface to charge the cam and copy photos and videos from MINI UP to PC.
6
START UP
•
Installation
CHARGE
Turn on the video camera and check battery status; if low, charge it. Either a computer USB port of power adapter (not included) can be used to charge it. Generally, it takes 2-4 hours to complete the charge cycle.
INSERTING AND REMOVING THE MEMORY CARD
The MINI UP video camera supports TF memory cards with capacity up to 32 GB. Any type of Micro SD card can be used but we recommend high-speed cards to optimise performance.
1. Make sure the video camera is off.
2. Insert the card in its slot, being careful that it is inserted in the correct direction until a click is heard.
• Removal.
1. Turn off the video camera.
2. Press the centre of the back of the card and release it; then remove it.
7
