Instruction for use
DJ68-00316B(NILFISK)-EN 4/15/05 8:57 PM Page 1
1
SAFETY INSTRUCTIONS
• Do not use the machine without- filters properly fitted.
• This machine is not intended for the suction of hazardous materi-als or gas, doing so may
expose people to serious health risks.
• The machine must not be used for the suction of water or other liquids.
• Do not pick up sharp objects such as needles or pieces of glass.
• Do not pick up anything that is burning or smoking such as ciga-rettes, matches or hot
ashes.
• Use and store this machine indoors and in a dry environment, 0 °C to 60 °C.
• Do not use the machine outdoors.
• Do not handle the machine with wet hands.
• Turn off the machine before un-plugging.
• To unplug, grasp the plug, not by pulling on the cord. Do not carry or pull the machine by
the cord.
• The machine must not be used if the cord shows any sign of dam-age. Regularly inspect
the cord for damage, in particular if it has been crushed, shut in a door or run over.
• Do not use the machine if it ap-pears faulty.Have the machine inspected by an authorized
service center if the machine has been dropped, damaged, left outdoors or has been
exposed to water.
• No changes or modifications to the mechanical or electrical safety devices should be
made.
• All repairs must be carried out by an authorized service center.
• Use only original dust bags, original filters and original accessories from your local dealer.
Use of unauthorized dust bags and filters will void the warranty.
• Tur n off the machine and unplug before starting dust bag or filter change, grasp the plug,
not by pull-ing on the cord.
• Do not use the machine as a toy. Do not leave children with the machine without supervision.
• This appliance is not intended for use by young persons or infirm persons without supervision unless they have been adequately super-vised by a responsible person to ensure
that they can use the appli-ance safely.Young children should be supervised to ensure
that they do not play with the appliance.
• If the supply cord is damaged, it must be replaced by the manufac-turer or its service
agent or similary qualified person in order to avoid a hazard.
DJ68-00316B(NILFISK)-EN 4/15/05 8:57 PM Page 1
2
1
ASSEMBLING THE CLEANER
Features may vary according to model.
▼
For storage, park the floor nozzle.
OPTION
DJ68-00316B(NILFISK)-EN 4/15/05 8:57 PM Page 2
3
2
OPERATING THE CLEANER
2-1 POWER CORD
2-2 POWER-CONTROL (INFRARED-CONTROL)
HANDLE CONTROL BODY CONTROL
NOTE
1.When using the control button for suction power, make sure that the transmitter of the
remote controller not be blocked by your body.
2.When operating the cleaner in a room with a high ceiling or under intensive light, the suc-
tion power controlling button may not work properly.So, use the "Power Control" button on
the main body.
3.When the battery is run down, it does not work with the button pressed on the handle
control part. In this case, replace the battery.(How to change: Refer to User Manual No.6)
NOTE
When removing the
plug from the
electrical outlet, grasp the
plug, not the cord.
SENDER
Press Power Control on the main
body to turn on the power (MAX).
And, press it again to turn it off (STOP).
DJ68-00316B(NILFISK)-EN 4/15/05 8:57 PM Page 3
4
CREVICE
DUSTING
UPHOLSTERY
2-3 USING FLOOR TOOLS
Carpets
Bare floors
OPTION
Pet Brush
Detach transparent
drum cover for
easy cleaning.
DJ68-00316B(NILFISK)-EN 4/15/05 8:57 PM Page 4
NEGATIVE IONS FUNCTION (OPTIONAL)
5
1. Do not put it near the TV with its power on.
2. Do not put an iron skewer into the negative ion discharge port.
3.Do not pour liquid, etc into the negative ion discharge port.
4.Do not put any object into ionizer opening.
3
WARNING
1 2
3
4 5 6
7
8
NOTE
The Cyclone Filter must
be used at all times to
retain optimum efficiency.
4-1 CLEANING THE CYCLONE FILTER (OPTIONAL)
4
INDICATOR LIGHTS
When the indicator light comes on, please empty
and clean the Cyclone Filter (4-1) and the Basket
filter (4-2) as shown in the following illustrations.
NOTE
Do not over fill Cyclonic
Filter.It must be emptied
when the dustreaches
Dust Full Level.
- Model with the negative ion function
When power is applied to the unit, the “GREEN”
LED turns on and negative ions come out.
GREEN
- Model without the negative ion function
When power is applied to the unit, the
”RED”LED turns on.
RED
DJ68-00316B(NILFISK)-EN 4/15/05 8:57 PM Page 5
6
NOTE
You can rinse the basket filter with water.
Do not immerse the whole cleaner in water.
Ensure completely dry before replacing.
12
34
56
4-2 CLEANING THE BASKET FILTER
4-2-1 EMPTYING THE BASKET FILTER
- CLEANING THE INNER PART OF CYCLONE FILTER
DJ68-00316B(NILFISK)-EN 4/15/05 8:57 PM Page 6
7
1 2
4 5 6
4-2-2 CLEANING THE CASE FILTER
NOTE :
Please do not throw away the filter. It must be retained to maintain cleaning efficiency.
1 2
5-1 CLEANING THE INLET FILTER
3
5
CLEANING THE FILTER
3
1 2 3
5-2 CLEANING THE OUTLET FILTER
7
DJ68-00316B(NILFISK)-EN 4/15/05 8:57 PM Page 7
PROBLEM CAUSE REMEDY 0
- IF YOU HAVE A PROBLEM
Motor does not start.
No power supply.
Thermal cut-out.
Check cable, plug and socket.
Leave to cool.
Suction force is gradually
decreasing.
Nozzle, suction hose or tube
is blocked.
Check for blockage and
remove.
Cord does not rewind fully. Check that the cord is not
twisted or wound unevenly.
Pull the cord out 2-3m and
push down the cord rewind
button.
Vacuum cleaner does not
pick up dirt.
Crack or hole in hose.
Check hose and replace if
required.
Low or decreasing suction
Filter is full with dust.
Please check filter and, if
required, clean as illustrated
in the instructions.
6
CHANGE THE BATTERY
WARNING
1. Never disassemble or recharge the batteries.
2. Never heat up the batteries or throw them into fire.
3. Do not reverse (+),(-) terminals.
4. Dispose the batteries properly.
NOTE
When the vacuum cleaner does not operate, replace the batteries.
If the problem persists, please contact our authorized dealer.
BA TTER Y TYPE : AA Size
8
DJ68-00316B(NILFISK)-EN 4/15/05 8:57 PM Page 8
9
GUARANTEE AND SERVICE
This Nilfisk Smart Series vacuum cleaner is covered by a two (2) year guarantee on the
machine, which covers the motor, cable rewinder, switch and casing.The nozzles, filters,
hoses, tubes and other accessories are covered twelve months due to manufacturing fault
only and excludes wear and tear.
The guarantee includes spare parts and labour costs, and covers manu-facturing and
material defects that may occur during normal domestic use.
Service under the guarantee will only be performed if it can be proven that the defect
occurred within the product’s guarantee period (a correctly completed guarantee
certificate or printed/stamped cash register receipt with date and product type) and on
the condition that the vacuum cleaner was bought as a new product in Great
Britain/Ireland/Australia/New Zealand and distributed by Nilfisk-Advance.
In the event of the repair of defects, the customer must contact Nilfisk-Advance to be
directed to a service agent at the customers own expense.
Upon completion of any repairs necessary, the vacuum cleaner will be returned to the
customer at the risk and expense of Nilfisk-Advance.
The guarantee does not cover:
• Normal wear and tear of accesso-ries and filters.
• Defects or damage occurring as a direct or indirect result of incorrect use - such as the
vacuuming of rubble, hot ashes or carpet deodorant powder.
• Abuse, loss or lack of maintenance as described in Instructions for use.
• If the machine has been used for home renovations.
• If the machine has been used for suction of water,plaster dust or sawdust.
Nor will it cover incorrect or poor configuration, i.e. setting up or connection, nor fire
-damage, fire, lightning strike or unusual voltage fluctuations or any other electrical
disturbances such as defective fuses or defective electrical installations on the supply grid,
and defects or damage in general that Nilfisk- Advance consider to be the result of causes
other than manufacturing and material defects.
THE GUARANTEE BECOMES VOID:
• If a defect is caused by the use of filters.
• If the identity number is removed from the vacuum cleaner.
• If the vacuum cleaner has been repaired by a non-Nilfisk authorized dealer.
• If the machine is used in a com-mercial environment, i.e.building contractors, cleaning
contractors, professional trades or any other non-domestic usage.
The guarantee is valid in:
Australia and New Zealand
Customer Care Helpline Telephone:
Australia:1300 733 171
New Zealand: 0800 40 80 80
DJ68-00316B(NILFISK)-EN 4/15/05 8:57 PM Page 9
