Nilfisk R 571, R 571 C, 571 C, R 586, 571 User Manual

Manual Steering ModelsManual Steering Models

Manual Steering Models

Manual Steering ModelsManual Steering Models

SCRUBTEC R 571SCRUBTEC R 571

SCRUBTEC R 571

Operator's

Manual

U.S. Patent No. 6,105,192; No. RE39,581; No. 6,557,207; No. 7,185,397; and Patents Pending

READ THIS BOOK

CAUTION: Read the Operator's Manual before using the appliance.

This book has important information for the use and safe operation of this machine. Failure to read this
book prior to operating or attempting any service or maintenance procedure to your ALTO machine could
result in injury to you or to other personnel; damage to the machine or to other property could occur as
well. You must have training in the operation of this machine before using it. If operator(s) cannot read
this manual, have it explained fully before attempting to operate this machine.

All directions given in this book are as seen from the operator’s position at the rear of the machine.

For new books write to: ALTO, 2100 Highway 265, Springdale, Arkansas 72764.

SCRUBTEC R 571SCRUBTEC R 571

SCRUBTEC R 571 CSCRUBTEC R 571 C

SCRUBTEC R 571 C

SCRUBTEC R 571 CSCRUBTEC R 571 C

SCRUBTEC R 586SCRUBTEC R 586

SCRUBTEC R 586

SCRUBTEC R 586SCRUBTEC R 586

SCRUBTEC RSCRUBTEC R

SCRUBTEC R

SCRUBTEC RSCRUBTEC R

Form No. 71274A 3/08 CLARKE TECHNOLOGY Printed in the U.S.A.

Table of Contents

Operator Safety Instructions .................................................................................................................................................. 3

Introduction & Machine Specifications .................................................................................................................................... 5

Symbols Used on Scrubtec .................................................................................................................................................... 6

Display Screens for Scrubtec ................................................................................................................................................ 7

Machine Control Panel ............................................................................................................................................................. 8

Machine Controls and Features .............................................................................................................................................. 9

How to Prepare the Machine for Operation ........................................................................................................................... 10

How to Operate the Machine .................................................................................................................................................. 16

Maintenance ............................................................................................................................................................................ 24

How to Correct Problems in the Machine ............................................................................................................................... 27

Common Error Codes .............................................................................................................................................................. 28

Accesories and Options ......................................................................................................................................................... 29

SECTION II Parts and Service Manual

Final Assembly Drawing ......................................................................................................................................................... 32

Main Frame Assembly Drawing (Rotary) ............................................................................................................................... 34

Main Frame Assembly Drawing (Cylindrical) ......................................................................................................................... 36

Main Frame Assembly Drawing (BOOST) .............................................................................................................................. 38

Optional Side Squeegee Lift (28 & 34 Rotary Models) ........................................................................................................... 40

Front Wheel Assembly Drawing and Parts List ..................................................................................................................... 42

Squeegee Lift Assembly Drawing and Parts List .................................................................................................................. 43

Recovery Tank Assembly Drawing ........................................................................................................................................ 44

Solution Tank Assembly Drawing (View 1) ........................................................................................................................... 46

Solution Tank Assembly Drawing (View 2) ........................................................................................................................... 48

Steering Column Assembly Drawing ...................................................................................................................................... 50

28” Rotary Brush Head Assembly Drawing and Parts List ................................................................................................... 52

34” Rotary Brush Head Assembly Drawing and Parts List ................................................................................................... 53

28” Cylindrical Head Assembly Drawing ................................................................................................................................ 54

32” Boost Head Assembly Drawing ....................................................................................................................................... 56

Squeegee Assembly Drawing ................................................................................................................................................ 58

Front Squeegee Assembly Drawing and Parts List ............................................................................................................... 60

Front Squeegee Arm Assembly Drawing and Parts List ....................................................................................................... 61

Electrical Panel Assembly Drawing and Parts List ................................................................................................................. 62

Electrical Connection Diagram ................................................................................................................................................. 63

Electrical Schematic ................................................................................................................................................................ 67

How to Handle the Packed Machine ....................................................................................................................... 10

How to Unpack the Machine ................................................................................................................................... 10

How to Install the Batteries ..................................................................................................................................... 10

Battery Maintenance ............................................................................................................................................... 11

How to Charge the Batteries .................................................................................................................................. 12

Recharging the Batteries ........................................................................................................................................ 12

Level Indicators for the Charge on the Batteries ................................................................................................... 13

How to Install the Squeegee ................................................................................................................................... 13

How to Adjust the Squeegee ................................................................................................................................. 13

How to Change or Rotate Brushes on Cylindrical Brush Head ............................................................................. 14

How to Install and Remove the Brush or Pad on the Boost Head ......................................................................... 15

How to Return One Touch to Factory Default Settings ......................................................................................... 16

How to Move Machine ............................................................................................................................................ 16

Seat Adjustment ...................................................................................................................................................... 16

How to Read the Battery Meter .............................................................................................................................. 17

How to Change Display Screens on the LCD Module ........................................................................................... 17

How to Read the Solution Empty Indicator ............................................................................................................. 17

How to Read the Recovery Full Indicator ............................................................................................................... 17

How to Operate the Squeegee and the Vacuum Motor ........................................................................................ 18

How to Operate the Solution Flow ...............................................................................................

How to Operate Brush Pressure ........................................................................................................................... 18

How to Operate the Forward / Reverse Switch ................................................................................................... 18

How to Fill the Solution Tank ................................................................................................................................... 19

Operating the Machine ............................................................................................................................................ 19

Do These Procedures When You Begin Your Work Period .................................................................................. 20

How to Clean a Floor .............................................................................................................................................. 21

How to Clean a Very Dirty Floor ............................................................................................................................. 22

Do These Procedures When You End Your Work Period ..................................................................................... 22

Maintenance to Be Done Every Week .................................................................................................................... 24

Battery Inspection and Cleaning ............................................................................................................................. 24

Cleaning the Recovery Tank and Filter ................................................................................................................... 24

Cleaning the Solution Tank and Filter ...................................................................................................................... 25

Manually Draining the Solution Tank ....................................................................................................................... 25

Vac Assisted Solution Tank Draining ..................................................................................................................... 25

Squeegee Maintenance .......................................................................................................................................... 25

Front Squeegee Blade Replacement ...................................................................................................................... 25

Rear Squeegee Blade Replacement ....................................................................................................................... 26

Squeegee Maintenance .......................................................................................................................................... 26

Cleaning the Vac Hose ........................................................................................................................................... 26

Parts List ................................................................................................................................................................. 33

Parts List ................................................................................................................................................................. 35

Parts List ................................................................................................................................................................. 37

Parts List ................................................................................................................................................................. 39

Parts List ................................................................................................................................................................. 41

Parts List ................................................................................................................................................................. 45

Parts List (View 1) .................................................................................................................................................. 47

Parts List (View 2) .................................................................................................................................................. 49

Parts List ................................................................................................................................................................. 51

Parts List ................................................................................................................................................................. 55

Parts List ................................................................................................................................................................. 57

Parts List ................................................................................................................................................................. 59

.......................... 18

Page -2- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

OPERATOR SAFETY INSTRUCTIONS

DANGER: Failure to read and observe all DANGER statements could result in severe

bodily injury or death. Read and observe all DANGER statements found in
your Owner's Manual and on your machine.

WARNING: Failure to read and observe all WARNING statements could result in injury

to you or to other personnel; property damage could occur as well. Read
and observe all WARNING statements found in your Owner's Manual and
on your machine.

CAUTION: Failure to read and observe all CAUTION statements could result in

damage to the machine or to other property. Read and observe all
CAUTION statements found in our Owner's Manual and on your machine.

DANGER: Failure to read the Operator’s Manual prior to operating or attempting any service or

DANGER: Operating a machine that is not completely or fully assembled could result in injury or

DANGER: Machines can cause an explosion when operated near flammable materials and

DANGER: Lead acid batteries generate gases which can cause an explosion. Keep sparks and

DANGER: Working with batteries can be dangerous! Always wear eye protection and protective

DANGER: Using the charger with a damaged power cord could result in an electrocution. Do not

maintenance procedure to your ALTO machine could result in injury to you or to other
personnel; damage to the machine or to other property could occur as well. You must
have training in the operation of this machine before using it. If your operator(s) cannot
read English, have this manual explained fully before attempting to operate this
machine.

property damage. Do not operate this machine unless it is completely assembled.
Inspect the machine carefully before operation. Operate only when lids, doors and
access panels are securely closed.

vapors. Do not use this machine with or near fuels, grain dust, solvents, thinners, or
other flammable materials. This machine is not suitable for picking up hazardous dust
or flammable materials. Use only commercially available floor cleaning waxes intended
for machine operation. DO NOT put gasoline, combustible or flammable materials in
the solution or recovery tank.

flames away from batteries. Do not smoke around the machine. Charge the batteries
only in an area with good ventilation.

clothing when working near batteries. Remove all jewelry. Do not put tools or other
metal objects across the battery terminals, or the tops of the batteries.

use the charger if the power cord is damaged.

WARNING: Do not turn the machine on a ramp. Do not use on surfaces having a gradient exceeding that

marked on the appliance.

WARNING: Machines can topple over and cause injury or damage if guided over the edges of stairs or

loading docks. Stop and leave this machine only on a level surface. When you stop the
machine, put all switches into their "OFF" position. Turn the key switch "OFF" and remove the
key.

WARNING: Skidding may occur when traveling at high speeds and attempting sharp turns, especially on

wet surfaces.

WARNING: Do not move machine with forklift. Damage could occur to machine.

WARNING: Maintenance and repairs performed by unauthorized personnel could result in damage or

injury. Maintenance and repairs must be performed by authorized ALTO personnel only.

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -3-

WARNING: Any alterations or modifications of this machine could result in damage to the machine or

injury to the operator or other bystanders. Alterations or modifications not authorized by the
manufacturer voids any and all warranties and liabilities.

WARNING: Electrical components of this machine can "short-out" if exposed to water or moisture. Keep

the electrical components of the machine dry. Wipe the machine down after each use. This
appliance is for dry use only and is not to be used or stored outdoors in wet conditions. For
storage, keep the machine in a building.

WARNING: Operating a machine without observing all labels and instructional information could result in

injury or damage. Read all machine labels before attempting to operate. Make sure all of the
labels and instructional information are attached or fastened to the machine. Do not cover
them for any reason. If labels or decals are missing or become damaged, get replacement
labels and decals from your ALTO distributor immediately.

WARNING: Wet floor surfaces can be slippery. Water solutions or cleaning materials used with this type of

machine can leave wet areas on the floor surface. These areas can cause a dangerous
condition for the operator or other persons. Always put "Caution" signs around/near the area
you are cleaning.

WARNING: Improper discharge of waste water may damage the environment and be illegal.

The United States Environmental Protection Agency has established certain regulations
regarding discharge of waste water. City, state and national regulations regarding this
discharge may also be in effect in your area. Understand and follow the regulations in your
area. Be aware of the environment hazards of chemicals that you dispose.

WARNING: Only use the brushes provided with the appliance or those specified in the Operator's Manual.

The use of other brushes may impair safety.

CAUTION: Use of this machine to move other objects or to climb on could result in injury or damage. Do

not use this machine as a step or furniture.

CAUTION: Your machine warranty will be voided if anything other than genuine ALTO parts are used on

your machine. Always use ALTO parts for replacement.

CAUTION: This machine contains lead acid batteries. The batteries must be disposed of in an environ-

mentally acceptable manner.

WARNING: GENERAL SAFETY RULES

The rules below have to be followed carefully in order to avoid injury to the operator and damage to the
machine:

• During the operation of this machine, pay attention to other people around you, especially children.

• Use care when reversing machine in confined areas.

• Do not mix different kinds of detergents. Avoid harmful odors.

• Do not place any liquid containers on to the machine.

• The recommended operating temperature should be between 32° F and 104° F.

• The humidity for operating this machine should be between 30 and 95%.

• Do not use acid solutions that could damage the machine.

• In order to prevent floor damage, do not leave brushes running when machine is standing still.

• In case of fire, use a powder extinguisher. Do not use water.

• Do not strike shelving or scaffoldings, where there is danger of falling objects.

• Adapt the utilization speed to the adhesion conditions.

• Do not exceed the declared hill climbing capacity, otherwise the machine could become unstable.

• For any maintenance operation take off the power supply from the machine.

• Do not disassemble any parts which require the use of a tool to be removed.

• Do not wash the machine with direct water jets or with high water pressure nor with corrosive material.

• After every 200 working hours have machine checked by an authorized service person.

Page -4- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

English

Correct Disposal of This Product (Waste Electrical & Electronic Equipment)

(Applicable in the European Union and other European countries with separate
collection systems)

This marking shown on the product or its literature, indicates that it should not be disposed with
other household wastes at the end of its working life. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, please separate this from other
types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their
local government office, for details of where and how they can take this item for environmentally
safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase
contract. This product should not be mixed with other commercial wastes for disposal.

Introduction

Introduction & Machine Specifications

This is a floor cleaning machine which, using the mechanic abrasive action of brushes or pads and the chemical
action of a water-detergent solution, is able to clean any type of floor. During its forward movement, it picks up
the removed dirt and the detergent solution which has not been absorbed by the floor.

Model SCRUBTEC R 571 SCRUBTEC R 586 SCRUBTEC R 571 C SCRUBTEC BOOST® R

Part Number

Cleaning Swath 28” (71.1 cm) 34” (86.4 cm) 28” (71.1 cm) 32” (81.3 cm)

Power Supply 36 volt system using (6) 6 volt 250, 330, or 370 AH deep cycle batteries

Battery Charger On-Board fully automatic smart charger, 115V 60 Hz or 230V 50 Hz

Brush Motors (1) 2 hp (1.5 kW) driving (1) 2.5 hp (1.9 kW) driving (2) .75 hp (.56 kW) (1) .75 hp (.56 kW)

two right angle gearboxes two right angle gearboxes

Brush Size / Speed (2) 14” (36 cm) 300 RPM (2) 17” (43 cm) 300 RPM (2) 6 x 28” (15.2 x 71.1 (1) 14 x 32” (35.6 x 81.3

cm) 300 RPM cm) 2250 RPM

Brush Pressure 12 -225 lbs. (57-102 kg) 90-130 lbs. (41-59 kg) 115-155 lbs. (52-70 kg)

(max)

Traverse Speed

4.1 mph (6.6 kph)

Traverse 1.5 hp (1.1 kW) transaxle powering of two 10” (25.4 cm) diameter rear wheels

Max. Cleaning Grade 6 degree

Vacuum Motor 1 hp (.75 kW) 3 stage tangential discharge

Noise Level 70 dBA

Solution Tank 30 gallon (113 liter)

Recovery Tank 30 gallon (113 liter)

Length 65” (165 cm)

Width 33” (84 cm) 35.5” (90 cm) 30” (130 cm) 33” (84 cm)

Height 56” (142cm)

Machine Weight

w/330 AH batteries 1478 lbs. (670 kg) 1498 lbs. (679 kg) 1498 lbs. (679 kg) 1488 lbs. (675 kg)

& full of solution

TM

Warranty 8 years Polydur

tanks, 3 years parts, 1 year labor, 18 months pro-rated batteries

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -5-

Symbols Used On Scrubtec R

Brush Up/Down

Squeegee
Up/Down

Forward /
Reverse

Horn

Solution Flow
Switch

Battery Meter

LCD Display
Button

On/Off Switch

Recovery /
Solution LED

WARNING

READ OPERATOR'S
MANUAL BEFORE OPERATING
THIS MACHINE

RISK OF FIRE

• Use only commercially available
floor cleaners and waxes intended
for machine operation.

• Do not use flammable materials.

One Touch
Button

Page -6- CLARKE TECHNOLOGY

RISK OF INJURY OR DAMAGE TO
MACHINE

• Do not turn, stop or leave machine
on a ramp or dock.

Operator's Manual -

71018A

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Display Screens For Scrubtec R

Traverse speed indicator

1 = low 0-3 KPH
2 = med 0-5 KPH
3 = high 0-6.4 KPH

SCREEN 1

Screens
Available
to Operator

SCREEN 2

“Battery” blinks when
low voltage occurs.

Position arrow indicating current position
of squeegee (up or down)

Indicators are on,
showing current
settings.

Water “droplets” off when solution is off and
they are flashing when solution is on.

Arrows indicating vacuum status.
They are flashing when vac is on
and off when vac is off.

Example

The Diagnostic only. It will not show unless a fault with
the machine occurs. When the fault happens the icon
and error code will be displayed.

CLARKE TECHNOLOGY Operator's Manual -

SCREEN 3 (Diagnostic)

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -7-

Machine Control Panel

On/Off Key Switch (See figure 1, Item D)

The key switch turns “ON” the power to the control
panel. “O” is the “OFF” and “I” is the “ON”.

Brush Up/Down Switch (See figure 1, Item A)

To lower brush head, push the brush switch in the
down (+) position. To lower the brush head to maxi­mum brush pressure, continue to hold the switch in
the down (+) position until the travel stops. The brush
motors will start and solution will flow (provided the
solution is turned “ON”) when the machine begins to
traverse. To raise the brush head, push the brush
switch in the up (-) position until the brush head travel
stops or desired position is reached.

Squeegee Up/Down Switch (See figure 1, Item B)

The squeegee switch is used to raise and lower the
squeegee and to turn on and off the vacuum motor.
The vacuum motor is turned on when the switch is
placed in the middle or lower position. NOTE: When

the squeegee switch is placed in the lower
position, the vacuum motor will turn on.

To raise the squeegee, place the switch in either the
middle or up position. The middle position is used for
one touch control. The vacuum motor will stop, after a
short delay, when the switch is placed in the up
position.

E

B

A

E, F

D

C

Figure 1

Hour Meter (See figure 1, Item E)

The hour meter is located on the front display. You
must toggle screens using LCD display button. The
hour meter indicates the number of hours the machine
has operated. It displays brush motor, vacuum motor,
traverse motor and total key on times.

Battery Meter (See figure 1, Item F)

The battery meter indicates the relative charge on the
battery pack. The battery meter is located on screen
1 on the front display. See page 7.

Solution Flow Control (See figure 1, Item C)

The solution flow switch regulates the flow of chemical
solution to the floor. To increase the flow, toggle (+).
To decrease the flow, toggle (-). To shut off the
solution, toggle - until no indicators are visible on
display. NOTE: DO NOT run dry!

NOTE: No solution will flow when the machine
does not traverse.

Circuit Breakers

The circuit breaker reset buttons are located on the
back side of the front cover below front display. The
breakers are as follows:
Item A - Main (5 amp)
Item B - Key Switch (5 amp)

Page -8- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Machine Controls and Features

Recovery Tank Float

The Scrubtec R is equipped with a float that shuts the
vacuum off when the recovery tank is full. The squeegee
will no longer pick up water. If this should happen, raise
the squeegee and empty the recovery tank.

The Traverse

The Scrubtec R is equipped with an electronically
controlled traverse system with variable speeds in
forward and reverse.

1. To traverse the machine, the power to the machine
must be turned on with the key switch and the
operator must be properly seated.

2. The traverse speed can be adjusted by varying the
pressure on the foot pedal.

NOTE: During reverse motion, the squeegee raises and
the solution flow stops automatically. Reverse also
reduces maximum traverse speed.

Brakes

The machine is equipped with an electronic braking
system. The electronic braking is activated automatically.
NOTE: During training, you should allow machine to
come to a full stop until you become familiar with
stopping distances required.

Parking Brake

The parking brake is activated automatically when the
machine comes to a stop. It disengages automatically
when you begin to traverse. The transaxle is equipped
with a manual brake release. NOTE: Machine will not
function when manual brake release is engaged. See
figure 2.

Reverse Alarm

The reverse alarm will sound intermittently and
automatically when the machine is in reverse.

Figure 2

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -9-

How To Prepare the Machine For Operation

How To Handle the Packed Machine

The machine is packed in a specific package provided on
a pallet so that it can be moved with a forklift.

WARNING: The packages cannot be placed on

top of each other.

How to Unpack the Machine

1. Remove the outer package.

2. The machine is fixed on the pallet with banding
straps and wooden blocks to prevent movement
during shipment. Remove the bands and blocks.

3. Remove tie down brackets.

4. Lower the ramp. The machine can be lowered off
the pallet if the operator is thoroughly familiar with
its operation. Avoid violent blows to the base unit.

5. Keep the pallet for future transport necessities.

How to Install the Batteries

BATTERY CONNECTIONS

Front of
machine

370 AH, 6 Volt

(Battery No. 40704A Wet)

(Battery No. 40602A Dry)

WARNING: The batteries are heavy. Lifting

batteries without help could result in
an injury. Get help to lift the
batteries.

WARNING: Working with batteries can be

dangerous. Always wear eye
protection and protective clothing
when working near batteries. NO
SMOKING!

WARNING: Hydrogen gas is formed during the

charging operation and is explosive.
Only charge batteries in a well
ventilated area with the seat base
lifted.

The batteries are fitted in the battery compartment under
the seat and recovery tank (figure 4). The machine uses
six - 6 volt batteries. They must be handled by using
appropriate lifting equipment suitable for the weight and
for the coupler system. For maintenance and daily
recharge of the batteries, it is necessary to follow all
instructions given by the manufacturer.

For Battery Installation follow these steps (See figure 4):

1. Make sure that the key switch is in the “OFF”
position.

2. Lift and rotate the base support of the seat forward.

3. Lean the seat on it’s restraint cable.

4. Lift the front of the recovery tank and rotate it towards
the rear until it rests on it’s restraint cable.

5. Put the batteries into position and connect the
battery cables as shown in figure 3.

Front of
machine

330 AH, 6 Volt

(Battery No. 891384 Wet)

(Battery No. 891385 Dry)

Front of
machine

250 AH, 6 Volt

(Battery No. 881317 Wet)

(Battery No. 881318 Dry)

Three (3) 70222A Spacers

6. Rotate the recovery tank and then carefully rotate it
forward to the normal operating position.

7. Lower the base support of the seat.

NOTE: Charge the batteries before using.

Page -10- CLARKE TECHNOLOGY

Operator's Manual -

Figure 3

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

How To Prepare the Machine For Operation

Battery Maintenance

The electrical power to operate the machine comes from the
storage batteries. Storage batteries need preventative
maintenance.

WARNING: Working with batteries can be

dangerous. Always wear eye
protection and protective clothing
when working near batteries. NO
SMOKING!

To maintain the batteries in good condition, follow these
instructions:

Correct Fill

1. Keep the electrolyte at the correct level. The correct

level is between 1/4” (1/2 cm) below the bottom of the
tube in each cell and above the tops of the plates.
Check the level of the electrolyte each time you charge
the batteries (see figure 4).

NOTE: Check the level of electrolyte prior to charging the
batteries. Be sure the plates in each cell are covered with
electrolyte before charging. Do not top off the cells prior to
charging the battery. Electrolyte expands during charging.
As a result, the electrolyte could overflow from the cells.
Always top off the cells with distilled water after charging.

CAUTION: Irreversible damage will occur to

the batteries if electrolyte does not
cover the plates. Keep the
electrolyte at the correct level.

CAUTION: Machine damage and discharge

across the tops of the batteries can
occur if the batteries are over filled.
Do not fill the batteries up to the
bottom of the tube in each cell.
Wipe any acid from the machine or
the tops of the batteries. Never
add acid to a battery after
installation.

Figure 4

CAUTION: Batteries must be refilled with

distilled water only. Do not use tap
water as it may contain
contaminants that will damage
batteries.

2. Keep the tops of the batteries clean and dry. Keep the

terminals and connectors clean. To clean the top of
the batteries, use a damp cloth with a weak solution of
ammonia or bicarbonate of soda solution. To clean
the terminals and connectors, use a terminal and
connector cleaning tool. Do not allow ammonia or
bicarbonate of soda to get into the batteries.

3. Keep the batteries charged.

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -11-

How To Prepare the Machine For Operation

How to Charge the Batteries

WARNING: Charging the batteries in an area

without adequate ventilation could
result in an explosion. To prevent an
explosion, charge the batteries only in
an area with good ventilation.

WARNING: Lead acid batteries generate gases

which could explode. Keep sparks and
flames away from batteries. NO
SMOKING!

CAUTION: See Charger Owner’s Manual. All

onboard battery chargers are
programmed for a specific type battery.
The charger may need reprogramming
to properly charge replacement
batteries different than the originally
equipped Clarke battery.

NOTE: Only replace batteries with the identical Clarke

battery pack as originally equipped. The correct Clarke
battery part number can be found on the Clarke battery
label affixed to the top of each battery.

If the replacement battery is a different Clarke battery,
please contact Clarke Technical Service, 1-800-356-7274,
for instructions.

If the replacement battery is not a Clarke battery, please
contact the charger manufacturer for instructions.

To charge the batteries, follow this procedure:

1. Make sure the key switch is in the “OFF” position.

2. Raise the seat base support.

(Shown with Optional

Chemical Mixing Sytem)

Figure 5

A

B

Figure 6

C

3. Connect the battery charger AC cord to a properly
grounded wall receptacle matching plug configuration
(50/60 Hz).

4. Observe indicator light to ensure the charging process
has started (see figure 5, A - Red, B - Yellow, C - Green
). For color indications see figure 6.

Recharging the Batteries

The Scrubtec R comes with an on board charger.

1. Plug into any wall socket and charging is automatic.

2. Observe indicator light to ensure the charging process
has started (see figure 5, A - Red, B - Yellow, C - Green
). For color indications see figure 6.

NOTE: Make sure you plug into a circuit that is not loaded by
other equipment. Wall breakers may be tripped and no
charge will occur.

WARNING: Never charge a GEL battery with an

NOTE: To prevent permanent damage to the batteries, avoid

their complete discharge. Never leave the batteries
completely discharged, even if the machine is not being used.
When recharging the batteries, keep the base support of the
seat lifted. After every 20 recharging operations, check the
level of the electrolyte and if necessary top off with distilled
water.

unsuitable battery charger. Carefully
follow the instructions given by the
manufacturer of the batteries and
battery charger.

Page -12- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

How To Prepare the Machine For
Operation

Level Indicators for the Charge of the Batteries

The battery meter ( see figure 7) on the control panel has a
digital read out with 10 fixed positions (A) and also a
blinking indicator (B). The bars that appear on the display
show the approximate charge level with icon (blinking)
discharged battery.

NOTE: A few seconds after the voltage reads 32V it will start
blinking. The brush motors will then automatically switch
off.

How To Install the Squeegee

To install the squeegee onto the machine, follow this
procedure:

1. The squeegee assembly has a break away feature
that is also used for mounting the squeegee. Loosen
the knobs on the squeegee (figure 8). Slide the stud
into the slotted hole in the support frame on the
machine.

2. Attach the vacuum hose cuff to the squeegee hose
fitting (see figure 9).

3. Tighten knobs. NOTE: Do not overtighten or break

away feature is lost and damage may occur.

NOTE: To prevent damage to the squeegee or machine, the

squeegee was designed to break away from the machine.
If the squeegee is impacted and it breaks away from the
machine, simply reinstall it by following step 1-3.

A

B

Figure 7

How to Adjust the Squeegee

During operation, the rear squeegee blade should have a
constant 3/16” minimum flare along the entire squeegee
blade (see figure 10).

1. The squeegee body can be tilted to adjust the
squeegee blade flare in the middle to match the flare
on the ends. To adjust the tilt, loosen the adjusting
bolt located on the left and right side of the squeegee
(see figure 9).

2. Press down on the squeegee until both sets of guide
wheels contact floor.

3. After making adjustments, retighten the screw(s).

NOTE: It is important that the right and left wheels are
contacting the floor in order for the squeegee to work.

NOTE: As the rear squeegee blade wears, it can be rotated
and/or flipped to obtain four good edges before having to
change blades.

Figure 8

Figure 9

Figure 10

3

/16” minimum

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -13-

How To Prepare the Machine For
Operation

How To Change or Rotate Brushes on Cylindrical Brush
Head

To install or rotate brushes on the cylindrical brush head:

1. Raise the brush deck and turn the key switch “OFF”.

2. Raise the brush skirt and pull out to remove. See
figure 11.

3. Remove thumb screw from brush door. See figure 12.

4. Lower door approximately 12 mm and slide door and
hub assembly from brush. See figure 13.

5. Slide brush off hub at opposite end. See figure 14.

6. Rotate brush or replace.

7. Slide brush on drive hub and insert door and hub
assembly into brush core.

8. Raise door and install thumb screw.

9. Place side skirt on retainer pins and lower in place.

10. Brushes should be rotated after every 20 hours of use.

Figure 11

Figure 12

Page -14- CLARKE TECHNOLOGY

Operator's Manual -

Figure 13

Figure 14

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

How To Prepare the Machine For Operation

How To Install The Brush Or Pad on the BOOST
machine

To install the brush or pad on the BOOST machine, follow
this procedure:

1. Turn the key switch "ON".

2. Put the brush switch in the "UP" position.

3. Turn the key switch "OFF".

4. Go to the side of the machine.

5. Press on a brush or pad under the flex plates. See
figure 15.

NOTE: When using a black pad, position pad on
head. Lower head and operate momentarily to affix
pad to pad driver (if you have difficulty, position pad
on floor and lower head then operate.)

Figure 15

How To Remove The Brush Or Pad on the BOOST
machine

To remove the brush or pad from the machine, follow this
procedure:

1. Turn the key switch "ON".

2. Put the brush switch in the "UP" position.

3. Turn the key switch "OFF".

4. Go to the side of the machine.

5. Pull downward on the brush or pad until it releases
from the flex plates. See figure 16.

Figure 16

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -15-

How To Operate The Machine

How to Return One Touch to Factory Default Settings

To restore the factory settings, follow the procedures below:

1. Press and hold the green one touch button (figure 17) until
you hear a

required for this will be approximately 15 seconds.

double beep

from the machine. NOTE: The time

2. The settings should be returned to 2 bars of solution and 1
bar of brush pressure. NOTE: The squeegee vac switch

must be in the middle position for default settings to work.

How to Move the Machine Without Power (see figure 18)

1. Engage manual override on brake (see page 9, “Parking
Brake”).

2. Remove foot plate and 4 screws and locate steering motor.

3. Using the knob on steering motor, turn shaft on motor in
direction you wish to turn machine.

4. Slowly push machine to desired location. NOTE: If you

attempt to push machine too fast it will limit top speed. If
this happens, stop and restart.

5. After moving machine, disengage manual brake override.

NOTE: Machine will not function if override is engaged.

Seat Adjustment (Standard)

The standard seat is not adjustable forward or backward.

Seat Adjustment (Deluxe)

The optional deluxe seat is adjustable in three ways:

Figure 17

Figure 18

1. The seat can be adjusted to the forward/backward position
by using the lever on the lower right side of the seat . Moving
the lever will allow the seat to slide into the preferred position.
See figure 19.

2. To adjust the angle of the back support portion of the seat,
turn the lever located in the middle right position of the seat.
Turning this clockwise will make the seat more vertical.
Turning the knob counterclockwise will tilt the seat back.
See figure 20 A.

3. To adjust the suspension of the seat for operator comfort,
use the lever on the side of the back support section of the
seat. This has three positions. The upper position is for light
weight operators. The middle position is for medium weight
operators. The bottom position is for heavy weight operators.
See figure 20, B. NOTE: The lever must be pressed firmly

to change positions.

Page -16- CLARKE TECHNOLOGY

Operator's Manual -

Figure 19

Figure 20

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

How To Operate the Machine

How to Read the Battery Meter (see figure 21, A)

The battery meter is an indicator on the LCD display. This
indicator is on the LCD display on the front of the machine.
It has 10 bars with 10 bars visible indicating a full charge.
As you run the machine the bars will begin to lower. The
“Battery Icon” (B) will begin to flash to indicate you are
reaching the end of charge.

NOTE: If you continue to run the brushes they will shut
down to protect the batteries from over discharging.

NOTE: Run times will vary depending on machine
variables, battery size, brush pressure and floor type,
etc.

How to Change Displays Screens on the LCD Module

The LCD display has three screens. Two of them can be
accessed at any time the key is on. The first screen
shows the machine status and the second screen shows
the four hour meters (figure 21).

SCREEN 1

A

B

SCREEN 2

The two screens that can be viewed by the operator can be
accessed via the display button (figure 22) on the control
panel to the left of the key switch. Pressing this button
toggles the display between the available screens.

The third screen is for diagnostics only. This screen
displays any errors that might occur or if the system
diagnostics finds something wrong. When the diagnostic
screen comes up, refer to the trouble shooting guide for
suitable action to resolve the error code.

How to Read the Solution Empty Indicator (see figure
23, A)

The solution empty indicator is located on the front of the
machine below the LCD display. When the solution
reaches nearly empty, the indicator will begin to flash,
warning the operator of the need to refill.

NOTE: Solution run times will vary depending on
solution flow setting.

How to Read the Recovery Full Indicator (see figure
23, B)

The recovery full indicator is located on the front of the
machine below the LCD display. When the recover tank is
near full the indicator will begin to flash, warning the
operator of the need to empty the recovery tank. The
vacuum motors will shut down a few moments later.

NOTE: Recovery times will vary depending on solution
flow setting and floor type.

B

Figure 21

Figure 22

A

Figure 23

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -17-

How To Operate the Machine

How to Operate the Squeegee and the Vacuum
Motor

The squeegee wipes the floor while the vacuum motor
removes the dirty solution from the floor. To operate the
squeegee, follow this procedure:

1. To lower the squeegee and start the vacuum motor,
press the squeegee up/down switch to the down
position (figure 24). NOTE: The vacuum motor

will start immediately when the down position
of the switch is pressed, and the squeegee will
lower.

2. To raise the squeegee, press the squeegee up/
down switch to the up position (figure 24). The
squeegee will then raise and the vacuum motor will
shut off after short delay NOTE: The center

position of the squeegee up/down switch is for
use with one touch control.

NOTE: The squeegee will rise automatically when

traversing in reverse during scrubbing operations.

How to Operate the Solution Flow

The solution is used to loosen and remove dirt from the floor.
The amount of solution applied can be adjusted to five
different levels to accommodate many different floor
conditions. These different levels are shown on the LCD
display on the front of the machine. To adjust the amount
of solution applied, use the Solution Flow Switch (figure 25).

NOTE: There are five different settings on the display.
See figure 26, A.

Figure 24

To increase solution flow:

1. Press the “ + ” side of the switch (figure 25).

2. Press and hold the “ + ” switch to achieve the desired

level of solution flow.

To decrease solution flow:
.

1. Press the “ - “ side of the switch (figure 25).

2. Press and hold the “ - “ side of the switch to achieve the

desired level of solution flow.

How to Operate the Brush Pressure

The brushes are used to supply agitation for the solution,
which improves the cleaning process. The amount of brush
pressure applied can be adjusted to five different levels to
accommodate many different floor conditions. These
different levels are shown on the LCD display on the front of
the machine (figure 26, B). To adjust the amount of brush
pressure, use the brush up/down switch (figure 27).

To increase brush pressure:

1. Press the “ + ” side of the switch (figure 27).

2. Press and hold the “ + ” switch to achieve maximum

level of pressure.

To decrease brush pressure:
.

1. Press the “ - “ side of the switch (figure 27).

Figure 25

B

A

Figure 26

2. Press and hold the “ - “ side of the switch to achieve

minimum or no brush presssure.

Page -18- CLARKE TECHNOLOGY

Operator's Manual -

Figure 27

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

How To Operate the Machine

How to Operate the Forward / Reverse Switch

(see figure 28).

1. To go forward, push the up arrow side of the switch.

2. To go in reverse, push the down arrow side of the

switch.

How to Fill the Solution Tank

The solution tank fill port is located at the left side of the
machine (see figure 29). To fill the solution tank, follow this
procedure:

1. Turn the key switch to the “OFF” position.

2. Remove lid.

3. Add a cleaning chemical to the solution tank. For the

correct amount of chemical, follow the directions shown
on the container. NOTE: Excess foam in the recovery

tank could damage the vacuum motor, so use only
the minimum amount of detergent necessary.

WARNING: Always use low foam detergent. To

avoid the production of foam, before
starting to clean, put a minimum
quantity of antifoam liquid into the
recovery tank. NEVER USE PURE
ACID.

4. Fill the solution tank with clean water (see figure 29).

5. After filling the solution tank, replace the solution tank

lid.

WARNING: Water solutions or cleaning materials

used with this type of machine can
leave wet areas on the floor surface.
These areas can cause a dangerous
condition for the operator or other
persons. Always put CAUTION signs
near the area you are cleaning.

WARNING: Machines can ignite flammable

materials and vapors. Do not use
with or near flammables such as
gasoline, grain dust, solvents and
thinners. Only use a cleaning
concentration recommended by the
chemical manufacturer.

Figure 28

Figure 29

WARNING: ALTO recommends a maximum

water temperature of 120°F (49°C).

Operating the Machine
NOTE: Before scrubbing with the machine, become familiar

with the operations and handling of the machine. Run the
machine at the lowest traverse speed. Use the machine in
an area that has no furniture or objects until you can do the
following:

1. Traverse the machine in a straight direction, forward

and backward.

2. Stop the machine safely.

3. Turn the machine both left and right and return to a

straight direction.

4. Turn a 180o turn where one rear wheel just pivots.

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -19-

How To Operate the Machine (cont.)

To traverse the machine follow this procedure:

1. Sit on the driver seat.

traverse if the operator is not properly seated.

NOTE: The machine will not

2. Turn the key switch to the “ON” position.

3. Raise the brush to the highest position (if
necessary).

4. Raise the squeegee (if necessary).

5. Gently press the foot pedal and the machine will
begin to move.

6. To stop, release pressure on the foot pedal.

7. To travel in reverse, select reverse with the forward/
reverse switch.

8. To stop, release pressure on the foot pedal.

9. When you stop the machine, turn the key switch
“OFF” and remove the key.

Do These Procedures When You Begin Your Work
Period

1. Make sure the key switch is in the “OFF” position.

Figure 30

2. Disconnect AC power from battery charger (follow
charger instructions).

3. Make sure the filter screen (1) to the vacuum motor
is clean and installed properly in the recovery tank
(see figure 30).

4. Make sure the recovery tank lid is in place and has
been tightened (see figure 31).

5. Close and secure the lower cleaning port cover (if
so equipped) on the recovery tank.

6. Make sure that the plug in the recovery drain hose
is in place and has been tightened (see figure 32).

7. Make sure that the brushes/pads are in position
and installed correctly.

8. Make sure the brush housings are in position on
the brush head.

9. Check the installation of the squeegee and
squeegee hose.

Figure 31

Figure 32

Page -20- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

How To Operate the Machine

How to Clean a Floor

WARNING: Water solutions or cleaning materials

For one touch automatic cleaning follow this procedure:

1. Turn the key switch to the “OFF” position.

2. Put the water and a cleaning chemical in the solution tank.

3. Sit on the driver seat. NOTE: The machine will not

traverse if the operator is not properly seated.

4. Turn the key switch “ON”. NOTE: The key switch turns on
the battery and LED screen displays, which shows the
machines condition.

5. The machine has a one touch button on the control panel
(see figure 33) that is preset for brush pressure and
solution flow. Momentarily depress the one touch button if
you wish to use these settings. NOTE: If this is not the

settings that you desire see page 16 or one touch
operation.

For manual control of cleaning process, follow these
procedures:

1. Turn the key switch to the “OFF” position.

2. Put the water and a cleaning chemical in the solution tank.

3. Sit on the driver seat. NOTE: The machine will not

traverse if the operator is not properly seated.

4. Turn the key switch “ON”. NOTE: The key switch turns on
the battery and LED screen displays, which shows the
machines condition.

5. Lower the squeegee. NOTE: The vacuum motor will turn
on when the squeegee up/down switch is placed in the
lower position.

6. Lower the brush head until it reaches the full stroke down.

NOTE: The brushes will start rotating only when the
machine begins to traverse.

7. Reset the solution flow valve by using the + / - solution
switch. NOTE: The solution will flow only if the machine

is moving forward.

8. After a few feet of scrubbing, check to see that the amount
of solution being applied is correct and that the squeegee
is picking up water and drying the floor. Make adjustments
as required.

9. Once the machine is set properly continue to scrub until the
solution low indicator comes on or until you run out of
solution.

used with this type of machine can leave
wet areas on the floor surface. These
areas can cause a dangerous condition
for the operator or other persons.
Always put CAUTION signs near the area
you are cleaning.

Figure 33

NOTE: When making multiple passes across the floor, overlap

the brush cleaning path approximately 2 inches (5 cm) of the
area already cleaned by the brush.

NOTE: During most cleaning procedures, apply and remove the
solution in one operation.

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -21-

How To Operate the Machine

How to Clean a Very Dirty Floor

To clean a very dirty floor, follow this procedure:

1. Apply solution to the floor.

2. Do not lower the squeegee. This will keep the vacuum
motor off.

3. Lower the brush or pad and scrub the floor.

4. Scrub the floor again with additional solution and
lower the squeegee.

5. Pick up all the solution with the squeegee.

Do These Procedures When You End Your Work Period

Having finished the job and before any type of maintenance
is done, follow these procedures:

For one touch cleaning shut down process, press and
release the one touch button.

For manual shut down follow these procedures:

1. Turn the solution flow off by decreasing the flow to its
minimum position.

2. Press the brush up/down switch to the up position
until the brush head has reached its up most position.

3. Place the squeegee up/down switch in the up position
to raise the squeegee and allow the vacuum motor to
continue to run. The vacuum motor will run for another
20 seconds and then place the squeegee up/down
switch to the up position. This will shut the vacuum
motor off.

4. Take the machine to a water drain.

5. Turn the key switch “OFF”.

6. Remove the drain hose from the holding hook.

Figure 34

7. Put the end of the hose over a drain or bucket.

8. Turn the valve housing to the left (see figure 34).

9. To open the valve completely, turn the housing fully to
the left. Pull the housing off of the valve.

10. Empty the recovery tank. NOTE: When hose is

lowered below water level, water will flow.

WARNING: Use gloves to protect your hands

from contact with dangerous
solutions when preforming the steps
listed above.

Page -22- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

How To Operate the Machine

11. Rinse the tank. Put clean water in the tank through
the opening at the top. Be careful not to allow
water into the vacuum intake tube (with screen).

12. If the tank or recovery hose has an obstruction, use
water pressure to flush them. Put the water hose
into the recovery hose (figure 35, A). NOTE: Do

not place water hose in vacuum intake tube
(see figure 35, B), damage will occur.

The recovery hose (figure 35, A) is located to the
right of the vacuum intake tube (see figure 35, B).
The recovery hose is flexible, which will allow you
to move it toward the opening for easy access to
the water hose for flushing the line.

13. Leave the tank and drain plug removed to air dry.

14. Check the squeegee blade. Use a cloth to clean
the squeegee blade. If the squeegee blade is
damaged or worn, turn or replace the blade.

NOTE: To avoid damage to the squeegee, the
squeegee must be lifted when the machine is not in
operation.

A

B

Figure 35

15. Take off the brushes and clean them with a jet
stream of water.

16. Use a clean cloth and wipe the surface of the
machine.

17. Check the batteries and add distilled water as
needed. The correct level is between ¼” (½ cm)
below the bottom of the tube in each cell and above
the tops of the plates. See the instructions in the
section of this book called “Battery Maintenance”.

CAUTION: Tap water may contain

contaminants that will damage
batteries. Batteries must be
refilled with distilled water only.

WARNING: Lead acid batteries generate

gases which can cause an
explosion. NO SMOKING.
Always wear eye protection and
protection clothing when
working near batteries.

18. Charge the batteries. See the instructions in the
section of this book called “How to Charge the
Batteries”.

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -23-

Maintenance

Maintenance To Be Done Every Week

WARNING: Maintenance and repairs must

be done by authorized
personnel only. Always empty
the solution tank and the
recovery tank before doing any
maintenance. Keep all
fasteners tight.

WARNING: Always wear eye protection and

protective clothing when
working near batteries. NO
SMOKING! Do not put tools or
other metal objects across the
battery terminals or the tops of
the batteries.

CAUTION: To prevent damage to the

machine, and discharge across
the tops of the batteries, do not
fill the batteries above the
bottom of the tube in each cell.
Wipe any acid from the machine
or the tops of the batteries. Do
not add acid to batteries after
installation.

Battery Inspection and Cleaning

1. Turn the key switch to the “OFF” position.

2. To inspect batteries, rotate seat support forward.
Lift and rotate recovery tank. Be sure the recovery
tank is empty before lifting.

Figure 36

Figure 37

3. Disconnect the batteries. Use a cloth and a
solution of ammonia or bicarbonate of soda to wipe
the top of the batteries. Clean the battery
terminals. Reconnect the batteries. See the
instructions in the section of this book called
“Battery Maintenance”.

4. When battery inspection is completed, close the
recovery tank. Rotate the seat support back to the
operating position.

Cleaning the Recovery Tank and Filter

1. Turn the key switch to the “OFF” position.

2. Empty the recovery tank using the flexible drain
hose by unscrewing the knob and taking off the
plug (see figure 36).

3. If the machine is equipped with the optional clean­out port, open the lower cleaning port cover by
unscrewing the four knobs (see figure 37). NOTE:

Make sure that the tank is empty first.

4. Rinse the tank and clean the drain plug.

Page -24- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Maintenance

5. Clean the hose fitting in the recovery tank and

spray water down the squeegee hose to clean
out debris.

6. Reattach the squeegee hose.

Cleaning the Solution Tank and Filter

1. Move the machine so that the solution tank filter

assembly is located directly over a floor drain.

2. Turn the key switch to the “OFF” position.

3. Clean inside the solution tank with a jet stream

of water.

7. Close the solution flow valve.

8. Clean the filter inside the housing and reinstall on

machine.

Manually Draining the Solution Tank

1. Remove sight gauge hose from top connector

(see figure 38).

2. Rotate lower fitting to allow drain hose to rest

over drain.

3. Drain solution tank (see figure 39).

Vac Assisted Solution Tank Drain

1. Remove vacuum hose from squeegee plate.

2. Turn vac on.

3. Remove and place solution hose into vac hose

until washer rest against hose cuff.

NOTE: Using vac assist will help to rinse recovery
tank. This will help to reduce cleanup and
maintenance times.

Figure 38

Figure 39

Squeegee Maintenance

Clean the squeegee with a jet stream of water and a
damp cloth. Inspect the front and rear squeegee
blades for wear. Readjust or replace if necessary.

Front Squeegee Blade Replacement

To replace the front squeegee blade, follow this
procedure:

1. Remove the squeegee assembly from the

machine.

2. Remove clamp and front squeegee blade.

3. Install new front squeegee blade and reinstall

clamp.

4. Replace squeegee on machine.

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -25-

Maintenance

Rear Squeegee Blade Replacement

If the rear squeegee blade is worn and does not dry the
floor well, follow this procedure:

1. Remove the squeegee assembly from the
machine.

2. Remove the squeegee blade and inspect it.

3. Rotate the squeegee blade to obtain a new
cleaning edge. Replace if necessary.

4. Reinstall the squeegee blade.

5. Reinstall the squeegee assembly on the
machine.

6. Readjust the settings on the squeegee as
required (see “How to Adjust Squeegee”).

Squeegee Maintenance

The squeegee blade may be rotated for longer life.
Keep sharp corner on floor for best cleaning
results. See figure 40. To rotate follow this
procedure:

Figure 40

A

B

1. Remove Clamp.

2. Remove blade and rotate to new edge.

3. Replace squeegee.

4. Replace clamp.

Cleaning the Vacuum Hoses

Make sure the squeegee is over a suitable drain.

1. Use a water hose to flush through the recovery
hoses.

2. Side Squeegee - Position water hose to the
squeegee side of the hose and flush thoroughly.

3. Recovery Hose - Position water hose
inside recovery tank. Recovery hose is located
behind threaded lip (see figure 40, A). NOTE: Do

not place hose in vacuum intake tube (see
figure 41, B), damage will occur.

Figure 41

Page -26- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

HOW TO CORRECT PROBLEMS IN THE MACHINE

PROBLEM CAUSE ACTION

Insufficient water onto the brushes

The machine does not clean
satisfactorily

The squeegee does not dry the floor

The solution flow is not set

There is no water in the solution tank.

The solution filter is dirty.

A circuit breaker has tripped.

Insufficient flow.

The brushes are worn.

Need to use a different kind of brush/pad

The squeegee is dirty.

Recovery drain hose is not closed.

The suction hoses need to be cleaned.

The squeegee blades are worn.

Make sure the solution flow is set.

Fill the solution tank.

Clean the solution filter.

Reset the circuit breaker.

Increase flow with solution switch.

Check the brushes and replace if necessary.
(the brushes have to be replaced when the
bristles reach approximately .59 inches (15mm
height.)
Use a different kind of brush. For cleaning
operations on floors where the dirt proves to be
particularly resistant, we recommend using spe­cial brushes. See Accessories page.

Clean the squeegee.

Close the drain plug.

Clean the vacuum hoses. See “Routine Main­tenance” section.

Replace/ or rotate the squeegee blades. See
“Routine Maintenance” section.

The vacuum motor does not function

The machine does not start

The brush motors do not work
WARNING: To avoid damage to the
floor, the motor starts only when the
machine is traversing.

The recovery tank is full.

The squeegee up/down switch in not in the
low or middle position.

The operator is not properly seated.

The key is not in the “ON position”.

The charger is still connected.

The batteries are not charged or not con­nected properly.

The circuit breaker has tripped.

The brush head unit is not down.

The batteries are not charged or not con­nected properly.

Poor electrical connection at the brush head
unit.

Drain recovery tank.

Put the squeegee in the low or middle position
or reprogram “one touch”.

The operator must be properly seated in the
driving position.

Turn the key to the “ON” position.

Remove the A/C cord from the wall.

Check to make sure the batteries are con­nected properly and charge if necessary.

Reset the circuit breaker.

Put the brush head unit down.

Check to make sure the batteries are con­nected properly and charge if necessary.

Connect the electrical connection at the brush
head unit.

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -27-

Scrubtec R

Common Error Codes

ERROR

CODE

1500
1501
1507

1600

3100
3101
3102
3103
3104
3105

7600

7602

7603

CAUSE

Check brake and wiring for
short circuit.

High battery voltage.

Probable short circuit of
output device.

Open circuit on brush motors
or brush motor wiring.

Brush motor overload.

Possible short circuit on
brush motors or wiring.

ACTION

Make sure manual override is not
engaged.

Poor or corroded connection to the
battery.

Check the traction, brush and vac motor
connections on the trio and check wiring
from these connectors down to the
traction, brush and vac motors.

Check the brush motor connection on
the trio and check the wiring from this
connector down to the brush motor.

Scrub in lower pressure setting.

Check the brush motor connection on
the trio and check the wiring from this
connector down to the brush motor.

7700

7800

7802

9000

2F01

Open circuit on vacuum motor

Open circuit on traction motor.

Traction motor current has
exceeded current limit for the
fold back time.

Brushes not fitted.

Drive system activated prior
to turning key switch "ON".

Check connector to trio and vacuum
motor

Check the traction motor connection on
trio and wiring down to motor.

Excessive driving up an incline, or
machine driven up against an obstacle
or step.

Place brushes or pads onto machine.

Release traverse switch and reactivate.

Page -28- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Accessories and Options

BRUSHES AND PAD DRIVERS

SCRUBTEC R 571 Disc Model

PART NO. DESCRIPTION

17521C Pad Driver Assembly (2 req.)
10383A Lite Grit Disc Brush (2 req.)
11431B Clean Grit Abrasive (2 req.)
11426B Supergrit (2 req.)
11427B Polypropylene (2 req.)

10874A Nylon (2 req.)

PART NO. DESCRIPTION

17520C Pad Driver Assembly (2 req.)
10384A Lite Grit Disc Brush (2 req.)
11430B Clean Grit Abrasive (2 req.)
11425B Supergrit (2 req.)
11424B Polypropylene (2 req.)
10875A Nylon (2 req.)

PART NO. DESCRIPTION

30614A Polypropylene (2 req.)
30615A Nylon (2 req.)
30616A Clean Grit Abrasive (2 req.)
30617A Supergrit (2 req.)
30619A Lite Grit (2 req.)

PART NO. DESCRIPTION

997004 Pads, Red 14 x 32 (5 Pack)
997003 Pads, Black 14 x 32 (5 Pack)
997005 Pads, White 14 x 32 (5 Pack)
997007 Pads, Blue 14 x 32 (5 Pack)

SCRUBTEC R 586 Disc Model

SCRUBTEC R 571 C Cylindrical Model

SCRUBTEC R BOOST Model

SQUEEGEE BLADES

SCRUBTEC R 571 Disc Model

PART NO. DESCRIPTION

30556A Rear Squeegee, Back Gum Rubber Blade
30067L Rear Squeegee, Back Linatex Blade
30066A Rear Squeegee, Front Ribbed Urethane Blade
30540A Side Squeegee, Back Gum Rubber Blade
30540L Side Squeegee, Back Linatex Blade
30541A Side Squeegee, Front Ribbed Urethane Blade

SCRUBTEC R 586 Disc & 571 C Cylindrical Model

PART NO. DESCRIPTION

30557A Rear Squeegee, Back Gum Rubber Blade
30069L Rear Squeegee, Back Linatex Blade
30091A Rear Squeegee, Front Ribbed Urethane Blade
30540A Side Squeegee, Back Gum Rubber Blade
30540L Side Squeegee, Back Linatex Blade
30541A Side Squeegee, Front Ribbed Urethane Blade

PART NO. DESCRIPTION

30773L2 Inner Blade, Linatex 3/16
38727A Inner Blade, Urethane Ribbed
30774A Outer Blade, Gum Rubber

30774L Outer Blade, Linatex 3/16

SCRUBTEC R BOOST Model

FIELD INSTALLED OPTION KITS

PART NO. DESCRIPTION

10880A ESP - Extra Scrub Productivity, Recycling
10881A Off Aisle Spray Tool and Vac Wand (includes pump)
10876A Solution and Recovery Tank Level Indicator Lights
10877A Caution Strobe Light (Amber)
10878A Deluxe Seat
10879A Head Light
53390A CBMS - Clarke Battery Maintenance System

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -29-

NOTES

Page -30- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Manual Steering ModelsManual Steering Models

Manual Steering Models

Manual Steering ModelsManual Steering Models

SCRUBTEC R 571SCRUBTEC R 571

SCRUBTEC R 571

SCRUBTEC R 571SCRUBTEC R 571

SCRUBTEC R 571 CSCRUBTEC R 571 C

SCRUBTEC R 571 C

SCRUBTEC R 571 CSCRUBTEC R 571 C

SCRUBTEC R 586SCRUBTEC R 586

SCRUBTEC R 586

SCRUBTEC R 586SCRUBTEC R 586

SCRUBTEC RSCRUBTEC R

SCRUBTEC R

SCRUBTEC RSCRUBTEC R

Section II

Parts and Service Manual

(71274A)

U.S. Patent No. 6,105,192; No. RE39,581; No. 6,557,207; No. 7,185,397; and Patents Pending

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -31-

CLARKE TECHNOLOGY

®®

®

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

®®

R R

R

R R

Final Assembly Drawing 10/06

13

3

1

12

14

11

10

2

4

5

15

6

9

8

7

8B

Page -32- CLARKE TECHNOLOGY

Operator's Manual -

8A

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

CLARKE TECHNOLOGY

®®

®

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

®®

R R

R

R R

Final Assembly Parts List 10/06

Qty Qty Qty.

Ref Part No. Description Rotary Cyl. Boost

1 pg 44-45 Tank, Recovery (Assembly) 1 - -

pg 44-45 Tank, Recovery (Assembly) - 1 1

2 pg 46-49 Tank, Solution (Assembly) - - 1

pg 46-49 Tank, Solution (Assembly) 1 1 -

3 pg 62 Plate, Electrical (28”) 1 - -

pg 62 Plate, Electrical (34”) 1 - -

pg 62 Plate, Electrical (Cyl.) - 1 -

pg 62 Plate, Electrical (Boost) - - 1

4 pg 34-35 Mainframe, Main Asm. (Rotary) 1 - -

pg 38-39 Mainframe, Main Asm. (Boost) - - 1

pg 36-37 Mainframe, Main Asm. (Cyl.) - 1 -

5 pg 42 Wheel, Front Steering 1 1 1

6 pg 61 Arm, Sec. Squeegee Lift 1 - -

7 pg 60 Squeegee, Secondary 1 - -

8 pg 52 Assembly, 28” Rotary Brush Head 1 - -

8 pg 53 Assembly, 34” Rotary Brush Head 1 - -

8A pg 54-55 Assembly, 28” Cyl. Brush Head - 1 -

8B pg 56-57 Assembly, 32” Boost Head - - 1

9 10129L Assembly, Squeegee 32” 1 - -

9 10068L Assembly, Squeegee 41” 1 1 1

10 pg 43 Arm, Rear Squeegee Lift 1 1 1

11 40704A Pack, Battery 370 A.H. 1 1 1

12 53767A Pedal, Accelerator 1 1 1

13 pg 50-51 Column, Steering Asm. 1 1 1

14 70079A Plate, Warning 1 - 1

15 818381 Spring Extension 1 - -

NI 40895A Positive Cable 1 1 1

NI 40896A Negative Cable 1 1 1

NI 40882A Cable Fuse 1 1 1

NI 41217A Cable, Series 4 4 4

NI= Not illustrated

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -33-

CLARKE TECHNOLOGY

SCRUBTEC R 571, 586SCRUBTEC R 571, 586

SCRUBTEC R 571, 586

SCRUBTEC R 571, 586SCRUBTEC R 571, 586

Main Frame Assembly Drawing (Rotary) 9/06

Drawing #11098A

2

1

3

4

22

20

17

16

25

24

7

21

18

27

26

6

23

19

1A, 1B

5

6

7

8

9

10

6

7

38

41

41

42

15

14

42

A

7

41

6

40

5

39

See Detail A

13

38

37

12

36

35

35

34

11

33

32

28

29

30

31

22

22

32

Page -34- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

CLARKE TECHNOLOGY

SCRUBTEC R 571, 586SCRUBTEC R 571, 586

SCRUBTEC R 571, 586

SCRUBTEC R 571, 586SCRUBTEC R 571, 586

Main Frame Assembly Parts List (Rotary) 5/07

Drawing #11098A

Ref Part No. Description Qty

1 53386B Actuator, Head Lift 1

1A 40910A Potentiometer & Circuit Borad 1

1B 40866A Housing Potentiometer 1

2 766780 Pin, Hair 1

3 82501A Pin, Clevis 1

4 40889A Horn 1

5 962288 Bolt, 3/8-16 x 1 Hex Hd 8

6 170883 Washer, Lock 3/8” 22

7 980645 Washer, 3/8” S.A.E. Flat 22

8 53760A Steering Asm. , Manual 1

9 61473A Linkage, Rod 4

10 920204 Nut, 3/8-24 Hex Jam 8

11 53493A Pin, Quick Release Act. Btm. 1

12 61482A Weldment, Head Carriage 1

13 818381 Spring, Idler Tension 1

14 61475A Clamp, Transaxle 2

15 51609A Bumper, Rear 2

16 962929 Screw, 10-32 x 3/8” 2

17 81221A Nut, 1/2-20 Lug 8

18 61382A Wheel, Anti-Skid 2

19 40868A Transaxle 1

20 61572A Mount, Front Squeegee 1

21 962086 Screw, 1/4-20 x 3/4 Hex Hd. 2

22 980657 Washer, Lock 1/4 6

23 962244 Bolt, 3/8-16 x .75 Hex 6

24 85813A Screw, 5/16-18 x 1 Hex Hd. 2

25 980652 Washer, 5/16 Lock 2

26 61491A Bracket, Squeegee Stop 1

27 61481A Weldment, Mainframe 1

28 30453A Hose, Clear Vinyl 1

29 61596A Stop, Brush Head 1

30 30558A Pad, Brush Carriage Stop 1

31 87026A Washer, 1/4 Flat SS 2

32 85737A Screw, 1/4-20 x 1/2 HHCS 6

33 50248A Clamp, Hose 1

34 59614A Valve, Battery Drain 1

35 722030 Clamp, Hose 2

36 30445A Hose, Solution (Flex) 1

37 48703A Valve, Electric 1

38 81104A Nut, 1/4” Nylock 3

39 69639A Strap, Static 1

40 85700A Screw, 1/4-20 x 1 HHCS 1

41 980614 Washer, 1/4” Starlock Ext. 3

42 980205 Washer, .31 I.D. x 1.06 O.D. 2

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -35-

CLARKE TECHNOLOGY

SCRUBTEC R 571CSCRUBTEC R 571C

SCRUBTEC R 571C

SCRUBTEC R 571CSCRUBTEC R 571C

Main Frame Assembly Drawing 9/06

Drawing #10949S

12

11

16

20

23

22

21

19

18

26

24

25

17

16

11

12

1

2

3

3A, 3B

4

5

6

7

8
9

10

11

12

13

14

15

36

34

31

33

34

33

32

34

35

See Detail A

A

Page -36- CLARKE TECHNOLOGY

30

31

Operator's Manual -

9

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

27

28

29

CLARKE TECHNOLOGY

SCRUBTEC R 571CSCRUBTEC R 571C

SCRUBTEC R 571C

SCRUBTEC R 571CSCRUBTEC R 571C

Main Frame Assembly Parts List 9/06

Drawing #10949S

Ref Part No. Description Qty

1 766780 Pin, Hair 1
2 82501A Pin, Clevis 1

3 40771A Actuator, Head Lift 1
3A 40910A Potentiometer & Circuit Borad 1
3B 40866A Housing Potentiometer 1

4 40889A Horn 1

5 962288 Bolt, 3/8-16 x 1 Hex Hd. 3

6 53760A Steering Asm, Manual 1

7 61736A Bracket, Head Stop (Cyl.) 1

8 980657 Washer, Lock 1/4 2

9 85737A Screw, 1/4-20 x 1.2 HHCS 4
10 920204 Nut, 3/8-24 Hex Jam 4
11 170883 Washer, Lock 3/8” 17
12 980645 Washer, 3/8” SAE Flat 17
13 61473A Linkage, Rod 4
14 53493A Pin, Quick Release Actuator Btm. 1
15 61718A Carriage, Weldment 1
16 962244 Bolt, 3/8-16 x .75 Hex 10
17 61475A Clamp, Transaxle 2
18 51609A Bumper, Rear 2
19 962929 Screw, 10-32 x 3/8” 2
20 81221A Nut, 1/2-20 Lug 8
21 61382A Wheel, Anti-Skid 2
22 40868A Transaxle 1
23 85813A Screw, 5/16-18 x 1 Hex Hd. 2
24 980652 Washer, 5/16 Lock 2
25 61836A Bracket, Squeegee Stop 1
26 61719A Frame, Main Weldment 1
27 30453A Hose, Clear Vinyl 1
28 50248A Clamp, Hose 1
29 59614A Valve, Battery Drain 1
30 48703A Valve, Electric 1
31 81104A Nut, 1/4” Nylock 3
32 69639A Strap, Static 1
33 980205 Washer, .31 I.D. X 1.06 O.D. 2
34 980614 Washer, 1/4” Starlock, Ext. 3
35 85700A Screw, 1/4-20 x 1 HHCS 1
36 413754 Grip, Solution Tank Clamp 1

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -37-

CLARKE TECHNOLOGY

®®

®

SCRUBTEC BOOSTSCRUBTEC BOOST

SCRUBTEC BOOST

SCRUBTEC BOOSTSCRUBTEC BOOST

®®

R R

R

R R

Main Frame Assembly Drawing 3/08

Drawing #11107A

17

16

15

14

7

6

13

12
12A,12B

11

1

2

3

2A, 2B

4

5

6

7

10

8

9

7

5

6

29

28

27

26

25

Page -38- CLARKE TECHNOLOGY

24

23

20

22

Operator's Manual -

21

18

19

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

CLARKE TECHNOLOGY

®®

®

SCRUBTEC BOOSTSCRUBTEC BOOST

SCRUBTEC BOOST

SCRUBTEC BOOSTSCRUBTEC BOOST

®®

R R

R

R R

Main Frame Assembly Parts List 3/08

Drawing #11107A

Ref Part No. Description Qty

1 766780 Pin, Hair 1

2 53874A Actuator, Head Lift 1
2A 40910A Potentiometer & Circuit Borad 1
2B 40866A Housing Potentiometer 1

3 82501A Pin, Clevis 1

4 40889A Horn 1

5 962288 Bolt, 3/8-16 x 1 Hex Hd. 7

6 170883 Washer, Lock 3/8” 14

7 980645 Washer, 3/8” S.A.E. Flat 14

8 53760A Steering Asm., Manual 1

9 61475A Clamp, Transaxle 2
10 81221A Nut, 1/2-20 Lug 8
11 61382A Wheel, Anti-Skid 2
12 40837A Transaxle 1
12A 40798A Brake 1
12B 41020A Motor 1
13 962244 Bolt, 3/8-16 x .75 Hex 7
14 85813A Screw, 5/16-18 x 1 Hex Hd. 2
15 980652 Washer, 5/16 Lock 2
16 61836A Bracket, Squeegee Stop 1
17 61719A Frame, Main Weldment 1
18 30453A Hose, Clear Vinyl 1
19 50248A Clamp, Hose 1
20 59614A Valve, Battery Drain 1
21 722030 Clamp, Hose 2
22 85737A Screw, 1/4-20 x 1/2 HHCS 2
23 30680A Hose, Solution (Flex) 1
24 48703A Valve, Electric 1
25 81104A Nut, 1/4” Nylock 3
26 69639A Strap, Static 1
27 980614 Washer, 1/4” Starlock Ext. 3
28 980205 Washer, .31 I.D. x 1.06 O.D. 2
29 85700A Screw, 1/4-20 x 1 HHCS 1

NOTE:  indicates a change has been made since the last
publication of this manual.

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -39-

CLARKE TECHNOLOGY

SCRUBTEC R 571, 586SCRUBTEC R 571, 586

SCRUBTEC R 571, 586

SCRUBTEC R 571, 586SCRUBTEC R 571, 586

Optional Side Squeegee Lift Assembly Drawing 5/05

8

9

10

7

11

12

13

6

6

5

14

4

12

3

2

1

16

17

Page -40- CLARKE TECHNOLOGY

Operator's Manual -

15

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

CLARKE TECHNOLOGY

SCRUBTEC R 571, 586SCRUBTEC R 571, 586

SCRUBTEC R 571, 586

SCRUBTEC R 571, 586SCRUBTEC R 571, 586

Optional Side Squeegee Lift Assembly Parts List 5/05

Ref Part No. Description Qty

1 87624A Washer, Nylon 1 1/2 x 1/4 x 1/8 2

2 86004A Screw, 1/4-20 x 1.50 HHCS 1

3 920296 Nut, 10-24 Elastic Stop 1

4 61699A Bracket, Sq. Lift Cable 1

5 962798 Screw, 10-24 x 1/2 PH 1

6 836711 Pin, Hair 2

7 80152A Washer, Flat 5/8 1

8 920110 Nut, 5/16-18 Hex Lock 1

9 980651 Washer, 5/16 Flat 1

10 80286A Spring, Actuator 1

11 80287A Screw, 5/16-18 x 7 Hex Head 1

12 80273A Pin, Clevis 2

13 61698A Bracket, Actuator Rear Mount 1

14 40751A Actuator, 3” Stroke 1

15 81104A Nut, 1/4” Nylock 1

16 61695A Cable, Squeegee Lift 1

17 57275A Pulley, Cable 1

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -41-

CLARKE TECHNOLOGY

®®

®

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

®®

R R

R

R R

Front Wheel Assembly Drawing and Parts List 6/07

Drawing #10779A

15

13

12

11

1

2

14

3

4

5

6

10

9

Ref Part No. Description Qty

1 80267A Bolt, 3/4 - 16 Hex Head 1
2 61472A Yoke Weldment, Steering 1
3 980645 Washer, 3/8 Flat 4
4 170883 Washer, Lock 3/8 4
5 85822A Screw, 3/8 -16 x 7/8 Hex Hd. 4
6 80268A Nut, .750 ESNA 1
7 * Spacer, Center (included w/#10) 1
8 81221A Nut, 1/2 -20 Lug 4

9 61382A Wheel, Anti-Skid 1
10 61691A* Hub Assembly, Front Wheel 1
11 * Bearing (included w/#10) 2
12 * Spacer (included w/#10) 2
13 85838A Bolt, 1/2 -20 Hex 4
14 61877A Stop, LH Steering 1
15 61878A Stop, RH Steering 1

*Front Wheel Hub Assembly (61691A) includes reference
#’s 7, 11 and 12.

8

7

Page -42- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

CLARKE TECHNOLOGY

®®

®

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

®®

R R

R

R R

Squeegee Lift Assembly Drawing and Parts List 4/06

Drawing #10787A

5

3

4

67

8

9

2

1

10

16

29

28

27

26

25

24

23

22

Ref Part No. Description Qty

1 66531A Pin, Swing Arm 1
2 962798 Screw, 10-24 x 1/2 PH 1
3 80273A Pin, Clevis 4
4 30542A Spacer 2
5 61549A Cable, Rear Squeegee 1
6 53387A Actuator, Squeegee 1
7 53446A Lever, Pivot, Squeegee 2
8 836711 Pin, Hair 5

9 87026A Washer, 1/4 Flat SS 6
10 61552A Lever, Spring 1
11 920110 Nut, 5/16-18 Hex Lock 1
12 920296 Nut, 10-24 Elastic Stop 1
13 81104A Nut, 1/4 Nylock 5
14 170915 Screw, 1/4 - 20 x 3/4 Hex HD 2
15 962620 Screw, 5/16 - 24 x 3/4 Hex HD 2

21

11

12

13

30

14

15

16

17

18

20

Ref Part No. Description Qty

16 980652 Washer, 5/16 Lock 4
17 980651 Washer, 5/16 Flat 2
18 61267A Tube, Bracket Squeegee 1
19 85730A Screw, 3/8 - 16 x 1 1/4 Hex HD 1
20 87031A Washer, 3/8 Flat SS 1
21 60678C Bracket, Squeegee Mount 11
22 81105A Nut, 3/8 - 16 SS ESNA 1
23 61551A Arm, Rear Weldment 1
24 962269 Screw, 1/4 - 20 x 2 1/2 Hex HD 2
25 53423a Spring, Extension 5,19” 2
26 80015A Screw, 3/8 -16 x 2 2
27 61550A Mount, Front Arm 1
28 61491A

28 61736A

29 85813A Screw, 5/16 - 18 x 1 Hex HD 2
30 30568A Hose, Recovery 1

19

Bracket, Squeegee Mount (Rotary)
Bracket, Squeegee Mount (Cylindrical)

1
1

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -43-

44

43

42

1

23

CLARKE TECHNOLOGY

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

Recovery Tank Assembly Drawing 6/07

Drawing #10783A & 10990A

4

5

7

6

8

9

®®

®

®®

R R

R

R R

10

11

41

40

37

36

35

34
26

39

38

33

12

13

14

15

16

17

20

18, 18A

22

23

19

21

6

24

25

30

26

29

28

27

31

32

Page -44- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

CLARKE TECHNOLOGY

®®

®

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

®®

R R

R

R R

Recovery Tank Assembly Parts List 6/07

Drawing # 10783A & 10990A

Ref Part No. Description Qty

1 52206A Chain, Drain Asm. 1
2 962957 Screw, 10 -16 x 1/2 Self Tab 2
3 30227A Housing, Drain 1
4 40002A Switch, Float Electrical 1
5 30622A Hose, Vac Exhaust 1
6 752020 Clamp, Hose 1
7 58069A Screen, Vac Filter 1
8 30581A Lid, Recovery Tank 1

9 30582A Gasket, Rec. Tank Lid 1
10 39339B Tube, Stand 90
11 837304 O-Ring, Retainer 2
12 82100A Locknut, 1/02 1
13 30709A Tank, Recovery (571 model) 1

13 30710A Tank, Recovery (586 model) 1
13 30711A Tank, Recovery (571 C model) 1

14 920797 Nut, Drain Valve 1
15 30623A Tube, Stand Straight 1
16 643418 Gasket, Vac Unit 1
17 58533A Spacer, Vac Motor 3
18 45019A Motor, Vac` 1
18A 40830A Carbon Brush 2
19 41809A Contact, Housing Connector 2
20 43401A Housing, Connector 2
21 85728A Screw, 1/4 - 20 x 4 Hex HD 3
22 61565A Panel, Recovery Vac Motor 1
23* 962212 Screw, 6-32 x 7/8 PH 2
24* 40874A Light, Strobe 1
25* 61579A Bracket, Strobe Light 1
26 85395A Screw, 1/4 - 20 x 1/2 PH 8
27* 84237A Screw, 10-32 x .50 PH 4
28 920056 Nut, 6-32 ESNA Nylock 2
29 77093A Label 1
30* 920722 Nut, 10-32 ESNA 4
31 61478A Retainer, Lower Hose 1
32 30561A Coupler, Hose (Rotary Machine) 1

682408 Connector, Hose (Cyl. & BOOST) 1
33 61573A Cable, Recovery Tank 1
34 61498A Retainer, Mid Hose 1
35 61477A Retainer, Upper Hose 1
36* 30559A Gasket, Clean Out 1
37* 61566A Clean-Out, Drain 1
38* 52477A Knob, 1/4 - 20 Clamp 4
39 30443A Hose, Recovery 1
40 832002 Clamp, Hose 2
41 30225A Body, Drain Valve 1
42* 40876A Sensor, Water Level 1
43 52560A O-Ring, .103 x 7.99 ID 1
44 30226A Plug, Drain 1
NI 30568A Hose, Squeegee 1
NI 30567A Hose, Vac 1

o

1

NOTE: * Optional accessories

NI = Not illustrated

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -45-

CLARKE TECHNOLOGY

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

Solution Tank Assembly Drawing (View 1 of 2) 11/06

Drawing # 11099A

®®

®

®®

R R

R

R R

1

26

24

23

10

2

2

3

4

5

6

7

2

8

20

22

21

19

18

17

16

15

14

13

12

5

9

10

3

11

Page -46- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

CLARKE TECHNOLOGY

®®

®

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

®®

R R

R

R R

Solution Tank Assembly Parts List (View 1 of 2) 5/07

Drawing # 11099A

Ref Part No. Description Qty

1 193944 Grommet 1
2 85811A Screw, 5/16 - 18 x 3/4 Hex Head 12
3 980651 Washer, 5/16 Flat 13
4 61492B Plate, Seat Assembly 1
5 85395A Screw, 1/4-20 x 1/2 PH 9
6 81112A Nut, 5/16 - 18 Thin ESNA 1
7 61490A Mount, Seat Assembly 1
8 61489A Plate, Cover 1

9 70883A Label, Battery Charger 1
10 980652 Washer, 5/16 Lock 8
11 30566A Hose, 5/8” ID x 7/8” OD x 4.00 1
12 50358A Adapter, 5/8 Barb Swivel 1
13 838517 Screen, Hose Washer 1
14 54088A Valve, Shut-Off 3/4 GHT x 3/4 GHT 1
15 830214 Adapter, 3/4 Barb & GHT Male 1
16 30445A Hose, Solution (Flex) 1
17 53571A Clamp, Hose 4
18 53498A Fitting, 90d ELL Pipe 1
19 61561A Pivot, Recovery Tank 1
20 85704A Screw, 3/8-16 x 2 1/4” Hex 2
21 170883 Washer, Lock 3/8” 2
22 980645 Washer, 3/8” SAE Flat 2
23 61562A Stop, Seat 2
24 70841A Label, Battery Installation 1
26 30534B Seat, Ergo/Adjustable 1
NI 61573B Cable, Seat/Rec. Tank 1
NI 50248A Clamp, Hose 1

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -47-

CLARKE TECHNOLOGY

®®

®

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

®®

R R

R

R R

Solution Tank Assembly Drawing (View 2 of 2) 9/06

Drawing # 11099A

1

2

3

4

5

19

18

17

6

7

8

9

10

11

12

13

14
15

16

Page -48- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

CLARKE TECHNOLOGY

®®

®

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

®®

R R

R

R R

Solution Tank Assembly Parts List (View 2 of 2) 9/06

Drawing # 11099A

Ref Part No. Description Qty

1 30530A Tank, Solution 1
2 962957 Screw, 10-16 x 1/2 Self Tap 8
3 87036A Washer, #10 Flat 2
4 30539B Lid, Solution 1
5 30578A Gasket, Solution Tank Fill 1
6 61574A Bracket, Tank Fill Gasket 1
7 61563A Washer, Sight Tube 1
8 40876A Sensor, Water Level (Option) 1

9 30564A Hose, Solution Sight 1
10 980645 Washer, 3/8” S.A.E. Flat 2
11 170883 Washer, Lock 3/8” 2
12 85704A Screw, 3/8-16 x 2 1/4” Hex 2
13 55189A Hosebarb, .50 x 90 degree 2
14 31242A Bushing 2
15 61561A Pivot, Recovery Tank 2
16 30597A Pad, Solution Tank Step (Left) 1
17 30596A Pad, Solution Tank Step (Right) 1
18 61843A Plate, Deck 1
19 85398A Screw, 1/4-20 x 1/2” P.H. 4

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -49-

CLARKE TECHNOLOGY

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

Steering Column Assembly Drawing 5/07

Drawing # 11087B

®®

®

®®

R R

R

R R

49

48

47

46

45

44

43

42

41

40

39

37

38

50

56

53

54

55

51

52

1 2

3

4

5

6

7

8

9

10

11
12

13

14

15

16

17

36

35

34

33

32

31

18
19

20

21

22

23

24

25

26

27

28

29

30

Page -50- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

CLARKE TECHNOLOGY

®®

®

®®

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

R R

R

R R

Steering Column Assembly Parts List 5/07

Drawing # 11087B

Ref Part No. Description Qty

1 980648 Washer, 17/32 x 1 1/16 Plain 1
2 80349A Nut, 1/2-13 Hex Nyloc 1
3 56497543 Cap, Steering Wheel 1
4 80328A Washer, Flat 1
5 56497306 Wheel, Steering 1
6 56497560 Adapter, Wheel 1
7 56497308 Cup 1
8 56314148 Bearing, Nyliner 1

9 61848A Column, Upper Steering 1
10 55400A Key, 3/16 x 5/32 4
11 56320595 Bushing, .32 x .50 x .28 2
12 56413211 Spacer, Nylon 2
13 56900041 Plug, Cap 1
14 81104A Nut, 1/4” Nylock 3
15 962495 Screw, 1/4-20 x 1 P.H. 1
16 85742A Screw, 1/4-20 2
17 56413658 Plate, Column Tilt 1
18 56454081 Universal Joint 1
19 56001958 Screw, 3/8-16 x .25 Set 2
20 61838A Shaft, Lower (Man. Steer) 1
21 56413661 Handle, Pivot Weldment 1
22 85812A Screw, M10-1.5 x 30MM 2
23 56305072 Spring 1
24 61839A Column, Lower Steering 1
25 53759A Coupling, Sleeve (Man.) 1
26 56250414 Bearing, Flange 2
27 85737A Screw, 1/4-20 x 1/2 HHCS 8
28 980657 Washer, Lock 1/4 8
29 61837A Plate, Column Adapter 1
30 980645 Washer, 3/8” SAE Flat 4
31 80088A Screw, M10-1.5 x 30MM 4
32 30734A Cover, Front (Lower) 1
33 56003268 Retainer, 1/4” Shaft 1
34 56413664 Handle, Adjustment 1
35 56440817 Knob, Tilt Lock 1
36 30733A Cover, Front (Upper) 1
37 920722 Nut, 10-32 ESNA 2
38 85387A Screw, 1/4-16 x 3/4 8
39 41423B Breaker, 5A Circuit, Cntrl/Act 2
40 40786S Spacer, Key Switch 1
41 61835A Panel, Control 1
42 40941A Horn Button 1
43 71165A Label, Control Panel 1
44 84237A Screw, 10-32 x .50 P.H. 2
45 40786A Switch, CE Key 1
46 40880A Panel, LCD Control (TRIO) 1
47 40890A Switch, Maintained Rocker 1
48 40885A Switch, Momentary Rocker 2
49 40940A Switch, Maintained Rocker 1
50 56420059 Shaft, Upper Steering 1
51 81112A Nut, 5/16-18 Thin ESNA 2
52 980651 Washer, 5/16 Flat 2
53 962957 Screw, 10-16 x 1/2 Self Tap 4
54 40748A Switch, Push Button 1
55 40706A Switch, Momentary Push 1
56 40879A Module, Solution Level (Option0 1

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -51-

CLARKE TECHNOLOGY

SCRUBTEC R 571SCRUBTEC R 571

SCRUBTEC R 571

SCRUBTEC R 571SCRUBTEC R 571

571 Rotary Brush Head Assembly Drawing and Parts List 3/08

Drawing #10697A

2

5

3

27

26

25

24

29

23

28

22

1, 1A, 1B, 1C

4

6

7

8

9

10

11

12

13

30

16

2

21

20

Ref Part No. Description Qty

1 40904B Motor, Dual Gear Box 1

1A 915102 Key 2
1B 40968A Carbon Brush/Spring Set
1C 41048A Gearbox Asm. 2

2 962244 Bolt, 3/8 - 16 x 3/4 Hex 12
3 170883 Washer, Lock 3/8 2
4 980645 Washer, 3/8 Flat 2
5 61722A Plate, Auto Side Squeegee 1

61497A Plate, Manual Side Squeegee 1
6 85613A Screw, 8 - 32 x 7/8 PH SS 4
7 55451A Keeper, Latch 2
8 61570A Spacer, Keeper 2
9 962803 Screw, 5/16-18 x 1 1/2 FH 1

10 53838A Wheel, Guide 4” 1
11 920108 Nut, 8 - 32 ESNA SS 4
12 55721A Latch, Brush Housing 2
13 30535A Housing, 28” Brush Right Main 1
14 962030 Screw, 8 - 32 x 3/8” FHCS 4

(4 of ea.)

1

17

14

18

19

.

Ref Part No. Description Qty

16 980638 Washer, 3/8 Lock 10
17 59856A Washer, Rubber 2
18 61658A Collar, Brush Driver 2
19 962714 Screw, Gimbal Mount 2
20 34400B Gimbal, Motor 2
21 962989 Screw, 1/4 - 20 x 1 1/2 PH 2
22 34705A Hose, Solution 2
23 170915 Screw, 1/4 - 20 x 3/4 Hex HD 2
24 782002 Clamp, Manifold 2
25 38014A Splitter, Solution 1
26 61546A Frame, 28” Brush Motor 1
27 30536A Housing, 28” Brush Left Main 1
28 81104A Nut, 1/4 Nylock 4
29 77091A Label, Moving Parts 1
30 81109A Nut, 8-32 ESNA SS 4
NI 30536A Housing, 28” Left Brush 1
NI 30535A Housing, 28” Right Brush 1

NI = Not illustrated
NOTE:  indicates a change has been made since the
last publication of this manual.

Page -52- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

28

29

CLARKE TECHNOLOGY

SCRUBTEC R 586SCRUBTEC R 586

SCRUBTEC R 586

SCRUBTEC R 586SCRUBTEC R 586

586 Rotary Head Assembly Drawing and Parts List 3/08

Drawing #10698A

5

1, 1A, 1B, 1C

23

4

6
7

8

9

10

27

26

25

24

4

23

22

21

20

Ref Part No. Description Qty

1 40905B Motor, Dual Gear Box 1

1A 915102 Key 2
1B 40968A Carbon Brush/Spring Set
1C 41048A Gearbox Asm. 2

2 980645 Washer, 3/8 Flat 2
3 170883 Washer, 3/8 Lock 2
4 962244 Bolt, 3/8 - 16 x 3/4 Hex 11
5 61723A Plate, Auto Side Squeegee 1

61497A Plate, Manual Side Squeegee 1
6 85613A Screw, 8 - 32 x 7/8 PH SS 4
7 55451A Keeper, Latch 2
8 61570A Spacer, Keeper 2
9 962803 Screw, 5/16-18 x 1 1/2 FH 1

10 53838A Wheel, Guide 4” 1
11 920108 Nut, 8 - 32 4
12 55721A Latch, Brush Housing 2
13 30537A Housing, 34” Brush Right Main 1
14 962030 Screw, 8 - 32 x 3/8” FHCS 4

19

18

17

(4 of ea.)

16

11

12

13

30

14

Ref Part No. Description Qty

16 782002 Clamp, Manifold 2
17 170915 Screw, 1/4 - 20 x 3/4 Hex HD 2

1

18 30210A Tubing, Vinyl 1
19 962989 Screw, 1/4 - 20 x 1 1/2 PH 2
20 962714 Screw, Gimbal Mount 2
21 34400B Gimbal, Motor 2
22 61658A Collar, Brush Driver 2
23 59856A Washer, Rubber 2
24 38014A Splitter, Solution 1
25 980638 Washer, 3/8 Lock 10
26 61547B Frame, 34” Brush Motor 1
27 30538A Housing, 34” Brush Left Main 1
28 81104A Nut, 1/4 Nylock 4
29 77091A Label, Moving Parts 1
30 81109A Nut, 8-32 ESNA SS 4
NI 30538A Housing, 34” Left Brush 1
NI 30537A Housing, 34” Right Brush 1

NI = Not illustrated
NOTE:  indicates a change has been made since the
last publication of this manual.

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -53-

CLARKE TECHNOLOGY

SCRUBTEC R 571 CSCRUBTEC R 571 C

SCRUBTEC R 571 C

SCRUBTEC R 571 CSCRUBTEC R 571 C

571 Cylindrical Head Assembly Drawing 5/05

Drawing #10962A

20

19

17

18

16

21

22

15

12

11

8

7

4

3

6

5

10

9

14

13

14

28

7

23

24

25

26

27

29

30

31

2

1

4

49

10

47

20

46

45

50

42

17

22

26

38

39

40

41

23

48

44

43

37

1

2

30

36

32

33

34

35

Assembled View

Page -54- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

CLARKE TECHNOLOGY

SCRUBTEC R 571 CSCRUBTEC R 571 C

SCRUBTEC R 571 C

SCRUBTEC R 571 CSCRUBTEC R 571 C

571 Cylindrical Head Assembly Parts List 3/05

Drawing #10962A

Ref Part No. Description Qty

1 980638 Washer, 3/8 Lock 4
2 962244 Bolt, 3/8-16 x .75 Hex 4
3 30649A Hose, Solution 1
4 50248A Clamp, Hose 2
5 40772A Motor, Brush 2
6 980646 Washer, 1/4” Flat 6
7 980657 Washer, Lock 1/4 9
8 85806A Screw, 1.4-20 x 3/4 Hex 6

9 61738A Mainframe, Weldment 1
10 52477A Knob, 1.4-20 Clamp 2
11 80248A Key, 3/16 Sq x .50 Lg 2
12 80247A Key, 1/8 Sq x .75 Lg 2
13 61308A Bearing Carrier 2
14 51226A Bearing, Sealed 4
15 61318A Pulley, Motor 2
16 30618A Tray, 28” Cyl. Debris 1
17 61743A Cover, Cyl Head Belt 2
18 84237A Screw, 10-32 x .50 P.H. 6
19 61752A Plate, Skirt L.H. 1
20 80240A Screw, 10-32 x 3/8 F.H. 14
21 30312A Skirt, Side 2
22 61336A Spacer, Binding 4
23 962094 Screw, 10-32 x 3/8 R.H. 3
24 53661A Belt, Drive 2
25 61319A Pulley, Brush Drive 2
26 467308 Ring, Retainer 4
27 962098 Screw, 1/4-20 x 3/4 F.H. 6
28 61309A Shaft, Drive 2
29 80270A Screw, 1/4-20 Shoulder 2
30 81104A Nut, 1/4” Nylock 8
31 30049B Wheel, Squeegee 2” 6
32 80257A Washer, Neoprene 4
33 61293A Hub, Driver 2
34 980648 Washer, 17/32 x 1 1/16 Plain 2
35 980626 Washer, 1/2 Lock 2
36 170857 Nut, 1/2-13 Hex 2
37 60254A Bolt, 5/16 x 2.25 Shoulder 2
38 61299A Hub, Driven 2
39 51225A Bearing, Sealed 2
40 167312 Ring, Retainer Internal 2
41 61310A Shaft, Driven 2
42 962973 Screw, 3/8-16 x 3/4 Flat Hd. 2
43 61335A Retainer, Skirt 2
44 61751A Plate, Skirt R.H. 1
45 61742A Door, Brush 1
46 962285 Screw, 1/4-20 x 1.00 F.H. 4
47 61322A Plate, Brush Door 2
48 53182A Cap, Plug 2
49 30648A Tube, Solution Assembly 1
50 77091A Label, Moving Parts 1

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -55-

CLARKE TECHNOLOGY

SCRUBTEC BOOSTSCRUBTEC BOOST

SCRUBTEC BOOST

SCRUBTEC BOOSTSCRUBTEC BOOST

BOOST® Head Assembly Drawing 10/06

Drawing #11103A

®®

®

®®

R R

R

R R

34

33

32
31

30

29

28

27

26

35

36

37

1

2

3

4

5

6

7

8

25

24

23

20

21

22

19

18

14

9

10

11

12

13

15

16

17

Page -56- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

CLARKE TECHNOLOGY

®®

®

SCRUBTEC BOOSTSCRUBTEC BOOST

SCRUBTEC BOOST

SCRUBTEC BOOSTSCRUBTEC BOOST

®®

R R

R

R R

BOOST® Head Assembly Drawing 6/07

Drawing #11103A

Ref Part No. Description Qty

1 53493A Pin, Quick Release Actuator 1
2 40790B Motor, 24V DC 1
3 30735A Spacer, Lift Arm 8
4 11173A Spring, Rubber 1
5 81220A Nut, Serrated Flange 12
6 920365 Nut, ½-13 Nylock 4
7 71192A Label, No Step 2
8 61730B Plate, Upper 32 1

9 80330A Screw, ½-13 x 2¼ Gr. 5 4
10 962098 Screw, ¼-20 x 3/4 FH 4
11 61753A Eccentric 1
12 61775A Retainer, Bearing 1
13 50736A Bearing 1
14 85737A Screw, ¼-20 x ½ HHCS 1
15 11172A Isolator, Deck 1
16 980614 Washer, ¼” Starlock Ext. 8
17 30664A Plate, Flex Asm. 32” 2
18 84236A Screw, #10-32 x .50 FH 4
19 30663A Plate, Driver 1
20 925589 Pin, Roll 1
21 980657 Washer, Lock ¼ 1
22 61724A Retainer, Eccentric 1
23 84237A Screw, 10-32 x .50 PH 3
24 782002 Clamp, Manifold 3
25 11002A Tube, Assmebly Drip 32” 1
26 81217A Nut, ¼-20 Hex ESNA 5
27 85395A Screw, ¼-20 x ½” PH 3
28 30048A Wheel, Guide 4
29 61782A Sleeve, Guide Wheel 4
30 980022 Washer, Wave 4
31 980646 Washer, ¼” Flat 4
32 85301A Screw, ¼-20 x 1¼ CRPH 4
33 962288 Bolt, 3/8 - 16 x 1 Hex Hd. 2
34 81105A Nut, 3/8-16 SS ESNA 2
35 87618A Washer, Flat .39 ID x .75 x 0.62 2
36 61816A Bracket. Lift 2
37 61818A Arm, Lift Weldment 1

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -57-

CLARKE TECHNOLOGY

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

Squeegee Assembly Drawing 3/08

Drawing # 10802A

6

®®

®

®®

R R

R

R R

1

2

21

24

23

21

18

17

19

3

4

20

7

8

9

4

5

22

16

Page -58- CLARKE TECHNOLOGY

12

15

Operator's Manual -

10

11

13

14

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

CLARKE TECHNOLOGY

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

Squeegee Assembly Drawing 3/08

Drawing # 10802A, 10803A

®®

®

®®

R R

R

R R

99cm 81cm

10068A

10129A

104cm

Ref. # Part No. Description Qty Qty Qty

1 962720 Screw, ¼-20 x ½ Hex SS - 4 -

80253A Screw, ¼-20 x 1½ Hex SS 4 - 4
2 980657 Washer, ¼ Lock 4 4 4
3 60243A Bracket, Squeegee Wheel 2 2 2
4 30049B Wheel, Squeegee 4 4 4
5 81104A Nut, ¼-20 2 2 2
6 60254A Bolt, Shoulder

5

/16x 2¼ 2 2 2
7 53185A Ring, 3/8 ID Snap 2 2 2
8 30048A Wheel, Guide, 4 Inch Diameter 2 2 2
9 60272B Channel, Squeegee Weldment 39” 1 - -

60234B Channel, Squeegee Weldment 32” - 1 -

61886A Channel, Squeegee Weldment 41” - - 1
10 50835A Latch, Squeegee Clamp 1 1 1
11 930086 Rivet, 3/16 x .450 Aluminum 2 2 2
12 60252A S trap, Clamp , Squeegee Retainer 39” 1 - -

60232A Strap, Clamp, Squeegee Retainer 32 - 1 -

61885A Strap , Clam p, Squeegee Retainer 41” - - 1
13 30557A Blade, Rear, Gum Rubber, 39” 1 - -

30717L1 Blade, Rear, Linatex Notched, 39” 1 - -

30557L Blade, Rear, Linatex 1 - -

30556A Blade, Rear, Gum Rubber, 32” - 1 -

30556L Blade, Rear, Linatex - 1 -

30774L Blade, Outer, Linatex, BOOST 41” - - 1
14 30058A Spacer, Squeegee 39” 1 - -

30047A Spacer, Squeegee 32 - 1 -

14 38726A Spacer, Squeegee 41” - - 2

15 30091A Blade, Front Ribbed 39” 1 - -

30066A Blade, Front Ribbed 32” - 1 -

30764L1 Blade, Front Linatex Notched 32” - 1 -

30773L2 Blade, Inner Linatex Notched ,

BOOST

41” - - 1
16 80011A Screw, 3/8-16 x 3 2 2 2
17 81301A Nut, 3/8-16 Jam SS 2 2 2
18 34260B Gasket 1 1 1
19 25201B Knob 2 2 2
20 60358A Shim, Squeegee Wheel 2 2 2
21 61370A Weight * * *
22 80280A Nut, Squeegee Backup 2 2 ­23 37016A Pad, Squeegee Grip - - 1
24 62712A Duct, Squeegee Inlet - - 1

11041L

* Optional - Not supplied with machine.

NOTE:  indicates a change has been made since the last publication of this manual.

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -59-

CLARKE TECHNOLOGY

SCRUBTEC R 571, 586SCRUBTEC R 571, 586

SCRUBTEC R 571, 586

SCRUBTEC R 571, 586SCRUBTEC R 571, 586

Front Squeegee Assembly Drawing and Parts List 8/05

(Rotary Machines Only)

Drawing # 10694A

13

12

14

15

2

3

1

4

5

6

7

8

11

Ref Part No. Description Qty

1 80275A Screw, 1/4 - 14 x 3/4 3
2 53185A Ring, Retainer 1
3 30048A Wheel, Guide 1
4 61496A Weldment, Fr. Squeegee Base 1
5 81104A Nut, 1/4 Nylock 1
6 59932A Wheel, Squeegee 1 5/8 1
7 30540A Blade, Outer Gum Rubber 1
8 50835A Latch, Squeegee Clamp 1

9 930086 Rivet, 3/16 x .450 Pan HD 2
10 61495A Strap, Squeegee Weldment 1
11 53444A Wedge, Secondary Squeegee 1
12 53443A Spacer, Secondary Squeegee 1
13 30541A Blade, Squeegee 1
14 80270A Screw, 1/4 - 20 Shoulder 1
15 30569A Hose, Sec. Squeegee 1

10

9

Page -60- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

CLARKE TECHNOLOGY

SCRUBTEC R 571, 586SCRUBTEC R 571, 586

SCRUBTEC R 571, 586

SCRUBTEC R 571, 586SCRUBTEC R 571, 586

Front Squeegee Arm Assembly Drawing and Parts List 5/05

(Rotary Machine Only)

Drawing # 10694A

1

2

3

4

7

Ref Part No. Description Qty

1 61548A Arm, Weldment Squeegee 1
2 81112A Nut, 5/16-18 Thin ESNA 2
3 67867A Spacer, Squeegee Swivel 1
4 60256A Arm, Squeegee Pivot 1
5 980651 Washer, 5/16 Flat 3
6 85811A Screw, 5/16-18 x 3/4 Hex Head 2
7 53491A Pin, Quick Release 1

NI 61370A Weight *

* Optional - Not supplied with machine.

5

6

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -61-

CLARKE TECHNOLOGY

®®

®

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

®®

R R

R

R R

Electrical Panel Assembly Drawing and Parts List 3/08

Drawing # 11091A, 10782S, 10961S, 10989S

17

6

5

4

9

1

6

5

5

723

8

5

6

9

10

11

16

15

Ref Part No. Description Qty

1 980614 Washer, 1/4” Starlock Ext. 1
2 40932B Harness, Main Power 1

2 40965A Harness, Main Power (Cyl. only) 1

3 854849 Post, Isolation 1
4 83302A Stud, 1/4-20 1
5 87026A Washer, 1/4 Flat SS 8
6 980657 Washer, Lock 1/4 7
7 81104A Nut, 1/4” Nylock 1
8 41801A Contactor, Main 36V 1
9 962430 Screw, 1/4-20 x 1/2 HHCS 2

10 962113 Screw, 10-32 x 1.00 P.H. 1
11 53791A Main Controller, 28”

12 53792A Main Controller, 34” Rotary 1

53790A Main Controller, 32” BOOST 1

Rotary & Cyl.

1

12

13

13

14

Ref Part No. Description Qty

12 40892A Relay 1
13 962929 Screw, 10-32 x 3/8” 4
14 40853A Display, Battery Charger 1
15 40797A Charger, 36V Battery w/display 1
16 61558A Plate, Electrical Panel 1
17 962086 Screw, 1/4-20 x 3/4 Hex Head 4
NI 77092A Label, Gases and Chemical 1
NI 41217A Cable, Battery Series 1
NI 40896A Cable, 32” Neg. Battery 1
NI 40895A Cable, 24” Pos. Battery 1
NI 40882A Cable, 200 Amp Fus. Battery 1
NI 40934A Harness, Logic 1

NI = Not illustrated
NOTE:  indicates a change has been made since the
last publication of this manual.

Page -62- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

CLARKE TECHNOLOGY

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

Electrical Connection Diagram 9/06

(pages 63-66)

®®

®

®®

R R

R

R R

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -63-

CLARKE TECHNOLOGY

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

Electrical Connection Diagram 9/06

(pages 63-66)

®®

®

®®

R R

R

R R

Page -64- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

CLARKE TECHNOLOGY

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

Electrical Connection Diagram 9/06

(pages 63-66)

®®

®

®®

R R

R

R R

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -65-

CLARKE TECHNOLOGY

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

Electrical Connection Diagram 9/06

(pages 63-66)

®®

®

®®

R R

R

R R

Page -66- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

CLARKE TECHNOLOGY

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

Electrical Schematic 9/06

®®

®

®®

R R

R

R R

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -67-

CLARKE TECHNOLOGY

®®

®

®®

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOST

SCRUBTEC R 571, 586, 571 C, BOOSTSCRUBTEC R 571, 586, 571 C, BOOST

R R

R

R R

Rider Electrical Options and Ground Connections 9/06

Page -68- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

NOTES

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -69-

CORPO

HEADQUARTERS

DENMARK

Nilfisk-Advance Group
Sognevej 25
2605 Brøndby
Denmark
Tel: [phone]
Fax:[phone]
E-mail: [e-mail]

SALES COMPANIES

AUSTRALIA

Nilfisk-ALTO
48 Egerton St.
PO Box 6046
Silverwater NSW 2128
Australia
Tel: [phone]
Fax: [phone]

AUSTRIA

Nilfisk-Advance GmbH

Nilfisk ALTO

Metzgerstrasse 68
A-5101 Bergheim/Salzburg
Austria
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
www.nilfisk-alto.at

BELGIUM

Nilfisk-ALTO

Division of Nilfisk-Advance n.v-s.a.

Dornveld/Sphere Business Park
Industrie Asse 3, nr 11-bus 41
1731 Zellik-Asse
Belgium
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]

CANADA

Clarke Canada
Part of the Nilfisk-Advance Group
4080 Sladeview Crescent, Unit 1
Mississauga, Ontario L5L 5Y5
Canada
Tel: [phone]
Fax: [phone]

CZECH REPUBLIC

ALTO Ceskà republika s.r.o.
Zateckých 9
14000 Praha 4
Czech Republic
Tel. [phone]
Fax [phone]
E-mail: [e-mail]

DENMARK

Nilfisk-ALTO
Division of Nilfisk-Advance A/S

Industrivej 1
9560 Hadsund
Denmark
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
E-mail:[e-mail]
www.nilfisk-alto.dk

Nilfisk-ALTO Food Division

Division of Nilfisk-Advance A/S

Blytækkervej 2,
9000 Aalborg
Denmark
Tel: [phone]
Fax: [phone]
E-mail: scanio.technology@­nilfisk-alto.dk
www.nilfisk-alto.com

FRANCE

Nilfisk-ALTO
ALTO France SA
Aéroparc 1
19 rue Icare
67960 Entzheim
France
Tel: [phone]
Fax: [phone]
E-mail: info@nilfisk-alto-fr
www.nilfisk-alto.com

GERMANY

Nilfisk-ALTO
Division of Nilfisk-Advance AG
Guido-Oberdorfer-Str. 10
89287 Bellenberg
Germany
Tel: (+49) (0) 180 5 37 37 37
Fax: (+49) (0) 180 5 37 37 38
E-mail: [e-mail]
www.nilfisk-alto.de

GREECE

Nilfisk-Advance SA
8, Thoukididou str.
164 52 Argiroupolis
Greece
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]

HOLLAND

Nilfisk-ALTO
Division of Nilfisk-Advance BV
Camerastraat 9
NL-1322 BB Almere
Tel: [phone]
Fax: [phone]
E-mail: info @nilfisk-alto.nl
www.nilfisk-alto.nl

HONG KONG

Nilfisk-Advance Ltd.
2001 HK Worsted Mills Ind'l Bldg.,
31-39 Wo Tong Tsui St.
Kwai Chung, Hong Kong
Tel.: [phone]
Fax: [phone]

HUNGARY

Nilfisk-Advance Kereskedelmi Kft.
II. Rákóczi Ferenc út 10
2310 Szigetszentmiklos-Lakihegy
Hungary
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
Sales: [e-mail]
Service: [e-mail]
www:nilfisk-advance.hu

ITALY

Nilfisk-ALTO
Divisione di Nilfisk-Advance A/S
Localita Novella Terza
26862 Guardamiglio (LO)
Italy
E-mail: [e-mail]

JAPAN

Nilfisk-Advance, Inc.
1-6-6 Kita-shinyokohama, Kouhoku-ku,
Yokohama, 223-0059 Japan
Tel.: [phone]
Fax: [phone]

Page -70- CLARKE TECHNOLOGY

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

MALAYSIA

Nilfisk-Advance Sdn Bhd
Sd 14, Jalan KIP 11
Taman Perindustrian KIP
Sri Damansara
52200 Kuala Lumpur
Malaysia
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]

NORWAY

ALTO Norge AS
Bjørnerudveien 24
1266 Oslo
Norway
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
www.nilfisk-alto.no

PEOPLE'S REPUBLIC OF CHINA

Nilfisk-Advance (Shenzhen) Ltd
Blok 3, Unit 130, 1001 Honghua Road
Int. Commercial & Trade Center
Fuitan Free Trade Zone
518038 Shenzhen
P.R. China
Tel.: [phone]
Fax: [phone]

POLAND

Nilfisk-Advance Sp. Z.O.O.
05-800 Pruszków
ul. 3-go MAJA 8
Poland
Tel.: [phone]
Fax: [phone]
[e-mail]
www.nilfisk-alto.pl

PORTUGAL

Nilfisk-ALTO
Division of Nilfisk-Advance Lda.
Sintra Business Park
Zona Industrial Da Abrunheira
Edificio 1, 1

o

A
P-2710-089 Sintra
Tel.: [phone]
Fax: [phone]
E-mail: [e-mail]
www.nilfisk-alto.com

RUSSIA

Nilfisk-Advance LLC
127015 Moskow
Vyatskaya str. 27, bid. 7
Russia
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]

SINGAPORE

Nilfisk-Advance Pte. Ltd.
Nilfisk-ALTO Division
40 Loyang Drive
Singapore 508961
Tel: [phone]
Fax: [phone]
E-mail: sales@nilfisk­advance.com.sg

SPAIN

Nilfisk-ATLO
Division of Nilfisk-Advance S.A.
Torre D'Ara
Paseo del Rengle, 5 Pl. 10
E-08302 Mataró
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
www.-nilfisk-alto.com

SWEDEN

ALTO Sverige AB
Member of Nilfisk-Advance Group
Aminogatan 18, Box 4029
S-431 04 Mölndal
Sweden
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
www.nilfisk-alto.se

TAIWAN

Nilfisk-Advance Taiwan Branch
No. 5, Wan Fang Road
Taipei
Taiwan, R.O.C.
Tel.: [phone]
Fax: [phone]

THAILAND

Nilfisk-Advance Co. Ltd.
89 Soi Chokechai-Ruammitr
Viphavadee-Rangsit Road
Ladyao, Jatuchak, Bangkok 10900
Thailand
Tel: [phone]
Fax: [phone]

TURKEY

Nilfisk-Advance Professional
Temizlik
Ekipmanlari Tic. A.S.
Necla Cad. NI.: 48
Yenisahra / Kadiköy
Istanbul
Tu r k ey
Tel.: [phone] - 60
Fax: [phone] - 63
www.nilfisk-advance.com

UNITED KINGDOM

Nilfisk-ALTO
Division of Nilfisk-Advance Ltd.
Bowerbank Way
Gilwilly Industrrial Estate
Penrith Cumbria CA11 9BQ
Great Britian
Tel.: (+44) (0) 1768 868995
Fax: (+44) (0) 1768 864713
E-mail: [e-mail]
www.nilfisk-alto.co.uk

VIETNAM

Nilfisk-Advance
Representative Office
No. 46 Doc Ngu Str.
Ba Dinh Dist.
Hanoi
SR. Vietnam
Tel.: [phone]
Fax: [phone]
E-mail: [e-mail]

USA

Clarke
2100 Highway 265
Springdale
Arkansas 72764
USA
Tel: [phone]
Fax: [phone]
E-mail:
[e-mail]
www.ClarkeUS.com

Clarke American Sanders
2100 Highway 265
Springdale
Arkansas 72764
USA
Tel: [phone]
Fax: [phone]
E-mail: customerservice
@americansanders .com
www.AmericanSanders.com

CLARKE TECHNOLOGY Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

Page -71-

CLARKE TECHNOLOGY LIMITED U.S. WARRANTY

This Clarke Technology Industrial/Commercial Product is warranted to be free from defects in materials and workman­ship under normal use and service, when operated and maintained in accordance with Clarke Technology’'s Maintenance
and Operations instructions. The warranty period is subject to the conditions stated below.

3 YEARS FOR PARTS AND 1 YEAR FOR SERVICE LABOR (See exceptions below)

Motors must be inspected for carbon motor brush wear at six-month intervals by an authorized Clarke Technology repair
station. Failure to comply with the six-month inspection requirement or failure to replace worn motor brushes identified
during the inspection will void the warranty on the motors. Cost of the six-month inspection and replacement of carbon
motor brushes is the responsibility of the purchaser. In the event of a warranty claim on the motors, proof of inspection and
any required motor brush replacement must be provided. This warranty is extended only to the original purchaser for use
of the product. It does not cover normal wear parts such as electrical cable, rubber parts, hoses and motor brushes.

BATTERY WARRANTY

In addition to the items above, any original equipment Clarke Technology Battery which becomes unserviceable under
normal use within a period of ninety (90) days from date of sale to the original user will be repaired or replaced with one of
equal specification at our option, F.O.B. any authorized Clarke Technology Sales or Service Branch, with no charge to the
user, except transportation costs. After expiration of the above ninety (90) day period, any battery which fails under
normal use will be adjusted to the original user with a new battery of equal specification on an eighteen (18) months pro rate
basis from the date of purchase. Adjustment will be determined using the then current list price, plus transportation costs.

Warranty is rendered null and void if battery is not kept filled to the proper level with DISTILLED WATER.

CLARKE TECHNOLOGY: POLYDUR® AUTOMATIC SCRUBBER SOLUTION AND RECOVERY TANK EIGHT­YEAR U.S. GUARANTEE

Your new Clarke Technology machine has polydur Solution and Recovery Tanks. Polydur is a rotationally molded, low­density linear polyethylene that won't crack or dent, and withstands most corrosives and temperature extremes. Clarke
Technology backs up your Polydur tanks with an eight-year guarantee. If a tank breaks or leaks under normal use
within eight years of the date of purchase, it will be replaced free.

CLARKE TECHNOLOGY UNIBODY FRAME FIVE-YEAR U.S. WARRANTY

Clarke Technology warranties the frame for a period of five years against defects in materials and workmanship under
normal use and service.

STATED WARRANTIES ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED

Clarke Technology's liability under this warranty is limited to repair of the product and/or replacement of parts and is given
to purchaser in lieu of all other remedies, including INCIDENTAL AND CONSEQUENTIAL DAMAGES.

THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE SPECIFIED HEREIN. THERE ARE NO WARRANTIES WHICH
EXTEND BEYOND THE DESCRIPTION OF THE FACE HEREOF. NO WARRANTIES, INCLUDING BUT NOT LIMITED TO WAR­RANTY OF MERCHANTABILITY, SHALL BE IMPLIED. A warranty registration card is provided with your Clarke Technology
product. Return the card to assist Clarke Technology in providing the performance you expect from your new floor
machine.

If a difficulty develops with the product, you should: a) Contact the nearest authorized Clarke Technology repair location or
contact the Clarke Technology Service Operations Department, 2100 Highway 265, Springdale, Arkansas 72764, for the
nearest authorized Clarke Technology repair location. Only these locations are authorized to make repairs to the product
under this warranty. (b) Return the product to the nearest Clarke Technology repair location. Transportation charges to and
from the repair location must be prepaid by the purchaser. Clarke Technology will repair the product and/or replace any
defective parts with out charge within a reasonable time after receipt of the product.
ALTO, 2100 Highway 265, Springdale, Arkansas 72764.

ALTO reserves the right to make changes or improvements to its machine without notice.

Always use genuine ALTO Parts for repair.

2100 Highway 265

Page -72- CLARKE TECHNOLOGY

Springdale, Arkansas, 72764

Operator's Manual -

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering

SCRUBTEC R Manual Steering

SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering
