Nilfi sk-ALTO C 100.3
Nilfi sk-ALTO C 110.1
Nilfi sk-ALTO C 110.1 X-TRA
User Manual .................................................... 3 - 15
EN
15-03-2006
3
EN
Index
1 Safety precautions and warnings .............................................3
2 Description ...............................................................................5
3 Before you start using your pressure washer ...........................6
4 Operating your pressure washer ..............................................8
5 After using your pressure washer ........................................... 10
6 Maintenance ...........................................................................11
7 Trouble shooting .....................................................................13
8 Further information .................................................................14
9 Technical data ........................................................................15
10 Declaration .............................................................................15
1 Safety Precautions and Warnings
Before starting
up your highpressure washer
for the fi rst time,
this instruction
manual must be
read through carefully. Save the
instructions for later use.
Safety instructions
marked with this
symbol must be
observed to pre-
vent danger to persons.
This symbol is
used to mark safety
instructions that
must be ob-
served to prevent
damage to the ma-
chine and its performance.
This symbol indicates tips and
instructions to
simplify work and to ensure a
safe operation.
Do not let people who have not
been trained in the use of a
high pressure washer nor read
the instruction manual ope rate
the machine.
This appliance is not intended
for use by children or other
persons without assistance or
supervision if their physical,
sensory or mental capabilities prevent them from using it
safely. Children should be supervised to ensure that they do
not play with the appliance.
Before starting up your machine please check it carefully
for any defects. If you fi nd any,
do not start up your machine
and contact your Nilfi sk-ALTO
distributor.
Especially check:
The insulation of the electric
cable should be faultless
and without any cracks. If the
electric cable is damaged,
an authorized Nilfi sk-ALTO
di stributor should replace it.
WARNING!
High pressure jets can be
dangerous. Never direct the
water jet at persons, pets,
live electrical equipment or
the machine itself.
Never try to clean clothes or
footwear on yourself or other
persons.
Hold the spray lance fi rmly
with both hands. The spray
lance is affected by a thrust
of up to 26.5 Nm during ope–
ration.
The operator and anyone in
the immediate vicinity of the
site of cleaning should take
action to protect themselves
from being struck by debris
dislodged during operation.
Wear goggles and protection
clothes during operation.
This appliance has been de-
signed for use with cleaning
agents supplied or recommended by the manufacturer.
The use of other cleaning
agents or chemicals may
adversely affect the safety of
the appliance.
Symbols used to mark instructions
4
EN
Disconnect from electrical
power supply before carrying
out user maintenance.
To ensure the appliance
safety only use original spare
parts from the manufacturer
or approved by the manufacturer.
High pressure hoses, fi ttings
and couplings are important
for the safety of the appliance. Only use hoses, fi ttings
and couplings recommended
by the manufacturer.
Do not use the appliance
if a supply cord or important parts of appliance are
damaged, e.g. safety device ,
high pressure hose and trigger gun.
The appliance is intended to
clean cars and garden etc..
Appropriate ear protection
has to be used.
Never use the machine in
an environment where there
could be a danger of explosion. If any doubt arises,
please contact the local
authorities.
It is not allowed to clean as-
bestos- containing surfaces
with high pressure.
This high pressure washer
must not be used at temperatures below 0°C.
WARNING!
Inadequate extension cables
can be dangerous. Cables on
drums should always be com-
pletely unwinded to prevent the
cable from overheating.
If an extension cable is used,
the plug and the socket must be
waterproof and comply with the
below-mentioned requirements
for length and cable dimensions.
1.0 mm² max. 12.5 m
1.5 mm² max. 20 m
2.5 mm² max. 30 m
If the electric cable is
damaged, it must be replaced by the manufacturer
or his service agent or similarly qualifi ed person in order
to avoid a hazard.
Mains power connection
The following should be observed when connecting the
high pressure washer to the
electric installation:
The electric installation shall
be made by a certifi ed electrician and comply with IEC
364.
It is recommended that the
electric supply to this appliance should include either a
residual current device that
will interrupt the supply if the
leakage current to earth exceeds 30 mA for 30 ms.
Water connection
Connection to the public
mains according to regulations.
Inlet hose can be connected
to the water mains with a
max. inlet pressure of 10
bars.
IMPORTANT! Only use water without any impurities. If
there is a risk of running sands
in the inlet water (i.e. from your
own well), an additional fi lter
should be mounted.
Safety devices
The unloader valve can re-
duce pressure if it exceeds
pre-set values.
Locking device on spray gun
(7a) (see foldout at the end of
this manual):
The spray gun features a locking device. When the pawl is
activated, the spray gun cannot
be ope rated.
Thermal sensor:
A thermal sensor protects the
motor against overloading. The
machine will restart after a few
minutes when the thermal sensor has cooled.
5
EN
2 Description
This high-pressure washer has
been developed for domestic
use within:
- Car, motorbike, boat, caravan, trailer, patio/drive/fl agstones, woodwork, brickwork,
barbecue, garden furniture,
lawn mower
Only use the high-pressure
washer for purposes described
in this manual.
The safety precautions must be
observed to prevent damage
to the machine, the surface to
be cleaned or severe personal
injuries.
2.2 Operation elements
and model survey
See foldout at the end of this
manual.
1 Start/stop switch
2 Water inlet with fi lter (2a)
3 High pressure connection
4 High pressure hose
5 Electric cable
6 Spray lance
7 Spray gun with lock (7a)
8 Multispeed
®
nozzle
9 Powerspeed
®
nozzle
10 Foam sprayer
11 Nozzle cleaning tool
12 Lance and nozzle holder
13 Model tag
14 Holder for electric cable (not
standard on all models)
Specifi cations: See model tag
(13) of machine.
We reserve the right to alter the
specifi cations.
2.1 Application
6
EN
3 Before you start using your
pressure washer
3.2 Mounting of holder for
electric cable
1. Press the holder for electric
cable (14) on to the machine.
The holder is not standard on
all models.
3.1 Mounting of lance and
nozzle holder
3.3 Mounting of wheels (only
models including wheels)
1. Mount the wheel bracket
by pressing it into the guide
at the bottom of the machine and mounting the two
screws.
2. Mount the wheels by pressing them into the bracket.
1. Press the lance and nozzle
holder (12) on to the machine.
7
EN
3.6 Mounting of high pressure hose on spray gun
1. Screw the high pressure (4)
hose on to the spray gun (7).
3.4 Mounting of trolley
handle (models with trolley handle)
1. Place the trolley handle on
the machine.
2. Secure the handle by mounting the 2 screws.
3.5 Mounting of quick
coupling
1. Screw the quick coupling
tight on to the water inlet (2).
Note: The inlet fi lter (2a) must
always be fi tted in the water
inlet pipe to fi lter out sand, limestone and other impurities as
these will damage the pump
valves.
Caution: Failure
to fi t the fi lter will
invalidate the
guarantee.
8
EN
4 Operating your pressure washer
4.1 Connection of high pressure hose
1. Mount the high pressure
hose on the outlet (3).
4.2 Mounting of spray lance,
nozzles and foam
sprayer
1. Push the spray lance (6) into
the spray gun (7) and screw
it on.
2. Attach the nozzle.
4.3 Water connection An ordinary 1/2" garden hose of
min. 5 m and max. 25 m will be
suitable.
NOTE: Connection to the public
mains according to regulations.
IMPORTANT! Only use water without any impurities. If
there is a risk of running sands
in the inlet water (i.e. from
your own well), an additional
fi lter (106411231) should be
mounted.
1. Let the water run through the
water hose before connecting
it to the machine to prevent
sand and dirt from penetrating the machine.
Note: Check that the fi lter is
fi tted in the water inlet pipe
and that it is not clogged up.
2. Connect the water hose to
the water supply by means
of the quick connector (inlet
water, max. pressure: 10 bar,
max. temperature: 40°C).
3. Turn on the water.
9
EN
4.4 Start and stop of the
machine
Do not cover the machine
during operation or use it in a
room without adequate ventilation !
Note: If the machine is left or not
used for 5 minutes, it must be switched off on
the start/stop switch "O" (1):
1. Press the start/stop switch
"O".
2. Disconnect the electrical plug
from the socket.
3. Shut off the water supply and
activate the trigger to relieve
the machine of pressure.
4. Lock the spray gun (7a).
When releasing the trigger of
the spray gun, the machine
automatically stops. The machine will start again when you
re- activate the spray gun.
The spray lance is affected
by a thrust during operation
- therefore always hold it fi rmly
with both hands. IMPORTANT:
Point the nozzle at the
ground.
1. Check that the machine is in
horizontal position.
NOTE: Do not place the ma-
chine in high grass!
2. Release the trigger lock (7a).
3. Activate the trigger of the
spray gun and let the water
run until all air has escaped
from the water hose.
4. Press the Start/stop switch
"I" (1).
5. Activate the trigger of the
spray gun.
Always adjust the distance and
thus the pressure of the nozzle
to the surface, which is to be
cleaned.
4.5 Regulation of spray
picture of Multispeed
®
nozzle
The spray picture can be
regulated on the Multispeed
®
nozzle.
10
EN
5.2 Winding up of electric
cable and high pressure
hose
5 After using your pressure washer
To avoid accidents, the electric
cable and the high pressure
hose should always be winded
carefully up around the handle.
C 110.1 X-TRA: Wind up the
cable on the appropriate hook.
5.1 Storing the washer The machine should be sto-
red in a frost-free room!
Pump, hose and accessories
should always be emptied of
water prior to storing as follows:
1. Stop the machine (press the
start/stop switch “O” (1) and
detach water hose and accessory.
2. Restart the machine and
activate the trigger. Let the
machine run until no more
water runs through the spray
gun.
3. Stop the machine, unplug
and wind up hose and cable.
4. Place spray handle, nozzles
and other accessories in the
holders of the machine.
Should the machine by mistake
be frozen, it will be necessary
to check it for damage.
NEVER START-UP A FROZEN
MACHINE.
Frost damages are not
covered by the guarantee!
5.3 Storage of accessories The lance and the nozzles
can be stored on the pressure
washer.
11
EN
6 Maintenance
WARNING! Always discon-
nect the electrical plug from the
socket prior to maintenance or
cleaning.
To ensure a long and problem
free working life, please take
the following advice:
Wash out water hose, high
pressure hose, spray lance
and accessories before
mounting.
Clean the connectors of dust
and sand.
Rinse the detergent spraying
attachment after use.
Clean the nozzles.
Any repair should always be
made in an authorized workshop
with original spare parts.
6.1 Cleaning of water inlet
fi lter
Clean the water inlet fi lter
regularly once a month or more
frequently according to use.
Carefully loosen the fi lter with a
screwdriver and clean it. Check
that it is intact before re-mounting it.
The inlet fi lter must always be
fi tted inside the water inlet pipe
to fi lter out sand, limestone and
other impurities, as they will
damage the pump valves.
CAUTION: Failure to fi t the fi lter
will invalidate the guarantee.
6.2 Cleaning of nozzle A clogging up in the nozzle
causes a pump pressure which
is too high. This is why cleaning
is required immediately.
1. Stop the machine and dis-
connect the nozzle.
2. Clean the nozzle. IMPOR-
TANT: The cleaning tool (11)
should only be used when
the nozzle is detached!
3. Flush the nozzle backwards
with water.
12
EN
6.3 Cleaning of machine
vents
The machine should be kept
clean so as to let cooling air
pass freely through the machine vents.
To ensure an easy connection and that o-rings do not dry
up, the couplings should be
greased regularly.
6.4 Greasing of couplings
13
EN
7 Trouble-shooting
To avoid unnecessary disappointments, you should check the following before contacting the Nilfi skALTO service organization:
Symptom Cause Recommended action
Machine refuses to start Machine not plugged in Plug in machine.
Defective socket Try another socket.
Fuse has blown Replace fuse. Switch off other machines.
Defective extension cable Try without the extension cable.
Fluctuating pressure Pump sucking air Check that hoses and connections are air-
tight.
Valves dirty, worn out Clean and replace or refer to local Nilfi sk
or stuck ALTO distributor
Pump seals worn out Clean and replace or refer to local Nilfi sk-
ALTO distributor.
Machine stops Fuse has blown Replace fuse. Switch off other machines.
Incorrect mains voltage Check that the mains voltage corresponds
to specifi cation on the model tag.
Thermal sensor activated Leave the washer for 5 minutes to cool
down.
Nozzle partially blocked Clean the nozzle (see section 6.2)
Fuse blows Fuse too small Change to an installation higher than the
amp. consumption of the machine.
You may try without the extension cable.
Machine pulsating Air in inlet hose/pump Allow machine to run with open trigger until
regular working pressure resumes.
Inadequate supply of Check that the water supply corresponds to
mains water specifi cations required (see model tag)
NB! Avoid using long, thin hoses (min. 1/2")
Nozzle partially blocked Clean the nozzle (see section 6.2)
Water fi lter blocked Clean the fi lter (see section 6.1)
Hose kinked Straighten out hose.
Machine often starts Pump/spray gun is Contact your nearest Nilfi sk-ALTO Service
and stops by itself leaking Centre.
Machine starts, but Pump/hoses or accessory Wait for pump/hoses or accessory to thaw.
no water comes out frozen
No water supply Connect inlet water.
Water fi lter blocked Clean the fi lter (see section 6.1)
Nozzle blocked Clean the nozzle (see section 6.2)
In case problems other than the above occur, please contact your local Nilfi sk-ALTO distributor.
14
EN
8 Further information
8.1 Recycling the washer Make the old cleaner unusable
immediately.
1. Unplug the cleaner and cut
the electric cable.
Do not discard electrical appliances with household waste.
As specifi ed in European Directive 2002/96/EC on old electrical and electronic appliances,
used electrical goods must
be collected separately and
recycled ecologically.
Contact your local authorities or
your nearest dealer for further
information.
8.2 Warranty conditions Nilfi sk-ALTO guarantees high
pressure washers for domestic
use for 2 years. If your high
pressure washer or ac ces so ries
are handed in for repair, a copy
of the receipt must be enclosed.
Guarantee repairs are being
made on the following con dit ions:
that defects are attributable
to fl aws or defects in materials or workmanship. (wear
and tear as well as misuse
are not covered by the
gu a ran tee).
that the directions of this
instruction manual have been
thoroughly observed.
that repair has not been
carried out or attempted
by other than Nilfi sk-ALTOtrained service staff.
that only original accessories
have been applied.
that the product has not been
exposed to abuse such as
knocks, bumps or frost.
that only water without any
impurities has been used.
that the high pressure
washer has not been used
for rental nor used com mer cial ly in any other way.
Repairs under this guarantee
include replacement of defective parts, exclusive of packing
and postage/carriage. Besides,
we refer to your national law of
sale.
The machine should be forwarded to one of the service
centres of the Nilfi sk-ALTO
organisation with description/
spe ci fi ca ti on of the fault.
Repairs not covered by the
guarantee conditions will be
invoiced. (I.e. malfunctions due
to Causes men ti o ned in section
Troubleshooting Chart of the
instruction manual).
In order that Nilfi sk-ALTO
can render you optimum
service, you should register
your product on our web site
www.nilfi sk-alto.com under
“PRODUCT REGISTRATION”.
15
EN
Declaration
Manufacturer's name and address or his
authorized representative in the Community
Nilfi sk-Advance AG
Nilfi sk-ALTO Business Unit
Guido-Oberdorfer-Str. 10
89287 Bellenberg
GERMANY
Name of the person responsible for the
technical documentation
Wolfgang Nieuwkamp
Description of the equipment:
Equipment name
Model
Dimension
Rated output voltage
Rated frequency
Rated input power
Other
High pressure washer
Nilfi sk-ALTO
C 100.3-5 / C 110.1-5 / C 110.1-5 X-TRA
255 x 240 x 630 mm
AC 230-240 V
50 Hz
1.3 - 1.4 kW
Measured sound pressure level
90 dB(A)
Guaranteed sound power level
92 dB(A)
Related directive
Directive 2000/14EC relating to the noise emission in the
environment by equipment for outdoor use
Declaration
The equipment refer in this document fulfi ls all the requirements of the Directive 2000/14EC
Place and date of the declaration
Bellenberg, November 10, 2005
Signature
9 Main Technical Data
Type C 100.3 C 110.1 C 110.1 X-TRA
Rated pressure bar/MPa 65/6.5 70/7.0 70/7.0
Permissible pressure bar/MPa max. 100/10.0 max. 110/11.0 max. 110/11.0
Rated flow l/min 5.3 5.0 5.2
Rated input kW 1.3 1.4 1.4
Rated voltage V 230-240 230-240 230-240
Max. water temperature °C 40 40 40
Inlet pressure bar max. 10 max. 10 max. 10
Sound pressure level dB(A) 78 78 78
Guaranteed sound power level dB(A) 92 92 92
Vibration according to ISO 5349 m/s
2
max. 2.5 max. 2.5 max. 2.5
10 Declaration
126528900
http://www.nilfi sk-alto.com
FRANCE
Nilfi sk-ALTO
ALTO France SAS
Aéroparc 1
19 rue Icare
67960 Entzheim
Tel.: +33 3 88 28 84 00
Fax: +33 3 88 30 05 00
E-mail: info@nilfi sk-alto.fr
www.nilfi sk-alto.com
GERMANY
Nilfi sk-ALTO
Division of Nilfi sk-Advance AG
Guido-Oberdorfer-Strasse 10
89287 Bellenberg
Tel.: +49 0180 5 37 37 37
Fax: +49 0180 5 37 37 38
E-mail: info@nilfi sk-alto.de
www.nilfi sk-alto.de
GREECE
Nilfi sk-Advance SA
8, Thoukididou str.
164 52 Argiroupolis
Tel.: +30 210 96 33443
Fax: +30 210 96 52187
E-mail: nilfi sk-advance@clean.gr
HOLLAND
Nilfi sk-ALTO
Division of Nilfi sk-Advance BV
Camerastraat 9
3322 BB Almere
Tel.: +31 36 546 07 60
Fax: +31 36 546 07 61
E-mail: info@nilfi sk-alto.nl
www.nilfi sk-alto.nl
HONG KONG
Nilfi sk-Advance Ltd.
2001 HK Worsted Mills Ind’l Bldg.
31-39 Wo Tong Tsui St.
Kwai Chung
Tel.: +852 2427 5951
Fax: +852 2487 5828
HUNGARY
Nilfi sk-Advance Kereskedelmi Kft.
II. Rákóczi Ferenc út 10
2310 Szigetszentmiklos-Lakihegy
Tel: +36 2447 5550
Fax: +36 2447 5551
E-mail: info@nilfi sk-advance.hu
www.nilfi sk-advance.hu
ITALY
Nilfi sk-ALTO
Divisione di Nilfi sk-Advance A/S
Località Novella Terza
26862 Guardamiglio (LO)
E-mail: d.puglia@nilfi sk-advance.it
JAPAN
Nilfi sk-Advance Inc.
247 Nippa-cho, Kouhoku-ku
Yokohama, 223-0057
Tel.: +8145 548 2571
Fax: +8145 548 2541
MALAYSIA
Nillfi sk-Advance Sdn Bhd
Sd 14, Jalan KIP 11
Taman Perindustrian KIP
Sri Damansara
52200 Kuala Lumpur
Tel.: +60 3 603 6275 3120
Fax: +60 3 603 6274 6318
NORWAY
Nilfi sk-Advance AS
Bjørnerudveien 24
1266 Oslo
Tel.: +47 22 75 17 70
Fax: +47 22 75 17 71
E-mail: info@nilfi sk-alto.no
www.nilfi sk-alto.no
POLAND
Nilfi sk-Advance Sp. Z.O.O.
05-800 Pruszków
ul. 3-go MAJA 8
Tel.: +48 22 738 37 50
Fax: +48 22 738 37 51
E-mail: info@nilfi sk-alto.pl
www.nilfi sk-alto.pl
PORTUGAL
Nilfi sk-ALTO
Division of Nilfi sk-Advance Lda.
Sintra Business Park
Zona Industrial Da Abrunheira
Edifi cio 1, 1° A
P2710-089 Sintra
Tel.: +35 808 200 537
Fax: +35 121 911 2679
E-mail: mkt@nilfi sk-advance.es
RUSSIA
Nilfi sk-Advance LLC
Vyatskaya str. 27, bld. 7
127015 Moskow
Tel.: +7 495 783 96 02
Fax: +7 495 783 96 03
E-mail: info@nilfi sk-advance.ru
SINGAPORE
Nilfi sk-Advance Pte. Ltd.
Nilfi sk-ALTO Division
40 Loyang Drive
Singapore 508961
Tel.: +65 6 759 9100
Fax: +65 6 759 9133
E-mail: sales@nilfi sk-advance.com.sg
SPAIN
Nilfi sk-ALTO
Division of Nilfi sk-Advance S.A.
Torre D’Ara
Paseo del Rengle, 5 Pl. 10
08302 Mataró
Tel.: +34 902 200 201
Fax: +34 93 757 8020
E-mail: mkt@nilfi sk-advance.es
SWEDEN
ALTO Sverige AB
Member of Nilfi sk-Advance Group
Aminogatan 18, Box 4029
431 04 Mölndal
Tel.: +46 31 706 73 00
Fax: +46 31 706 @nilfi sk-alto.se
www.nilfi sk-alto.se
TAIWAN
Nilfi sk-Advance Taiwan Branch
No. 5, Wan Fang Road
Taipei
Tel.: +886 227 002 268
Fax: +886 227 840 843
THAILAND
Nilfi sk-Advance Co. Ltd.
89 Soi Chokechai-Ruammitr
Viphavadee-Rangsit Road
Layao, Jatuchak, Bangkok 10900
Tel.: +66 2 275 5630
Fax: +66 2 691 4079
UNITED KINGDOM
Nilfi sk-ALTO
Division of Nilfi sk-Advance Ltd.
Bowerbank Way
Gilwilly Industrial Estate, Penrith
Cumbria CA11 9BQ
Tel.: +44 1 768 86 89 95
Fax: +44 1 768 86 47 13
E-mail: sales@nilfi sk-alto.co.uk
www.nilfi sk-alto.co.uk
USA
ALTO Cleaning Systems Inc.
Part of the Nilfi sk-Advance Group
12249 Nations Ford Rd.
Pineville, North Carolina 28134
Tel.: +1 704 971 1240
Fax: +1 704 971 1241
E-mail: info@nilfi sk-advance.us
VIETNAM
Nilfi sk-Advance Representative Offi ce
No. 46 Doc Ngu Str.
Ba Dinh Dist.
Hanoi
Tel.: +84 4 761 5642
Fax: +84 4 761 5643
E-mail: nilfi sk@vnn.vn
HEAD QUARTER
DENMARK
Nilfi sk-Advance Group
Sognevej 25
DK-2605 Brøndby
Tel.: +45 4323 8100
Fax: +45 4343 7700
E-mail: mail@nilfi sk-advance.dk
SALES COMPANIES
AUSTRALIA
Nilfi sk-ALTO
48 Egerton St.
P.O. Box 6046
Silverwater, N.S.W. 2128
Tel.: +61 2 8748 5966
Fax: +61 2 8748 5960
AUSTRIA
Nilfi sk-Advance GmbH
Nilfi sk-ALTO
Metzgerstrasse 68
5101 Bergheim/Salzburg
Tel.: +43 662 456 400-0
Fax: +43 662 456 400-34
E-mail: info@nilfi sk-alto.at
www.nilfi sk-alto.at
CANADA
Clarke Canada
Part of the Nilfi sk-Advance Group
4080 B Sladeview Crescent, Unit 1
Mississauga, Ontario L5L 5Y5
Tel.: +1 905 569 0266
Fax: +1 905 569 8586
CHINA
Nilfi sk-Advance (Shenzhen) Ltd.
Blok 3, Unit 130 1001 Honghua Road
Int. Commercial & Trade Ce nter
Fuitian Free Trade Zone
518038 Shenzhen
Tel.: +86 755 8359 7937
Fax: +86 755 8359 1063
CZECH REPUBLIC
ALTO Ceská Republika s.r.o.
Zateckých 9
14000 Praha 4
Tel.: +420 24 14 08 419
Fax: +420 24 14 08 439
E-mail: wap_p@mbox.vol.cz
DENMARK
Nilfi sk-ALTO
Division of Nilfi sk-Advance A/S
Industrivej 1
9560 Hadsund
Tel.: +45 7218 2100
Fax: +45 7218 2105
E-mail: salg@nilfi sk-alto.dk
E-mail: service@nilfi sk-alto.dk
www.nilfi sk-alto.dk
Nilfi sk-ALTO Food division
Division of Nilfi sk-Advance A/S
Blytækkervej 2
9000 Aalborg
Tel.: +45 7218 2100
Fax: +45 7218 2099
E-mail: scanio.technology@nilfi sk-alto.dk
Loading...
