NILFISK BU800 20B User Manual

BU800™ 20B & 20BT

Battery Burnishers

Smart cleaning.

A Nilfisk-Advance Brand

BU800

™

20B & 20BT

Battery Burnishers

Ideal applications include:

• K-12 Schools

• Colleges and Universities

• Hospitals and Healthcare Facilities

• Supermarkets

• Retail Stores and Shopping Centers

• Government Buildings

Superior Shine. Easier to Use Design.

When the job calls for restoring your floor’s gloss, the Advance
BU800™ battery burnisher outshines even its updated look.

Operators of the BU800 will sense a whole new feel and
experience when burnishing. A more rigid frame and nine
vibration isolators have turned the operation of the BU800 into
the smoothest burnishing experience in the market.

With an updated, double-pivot pad-driver design, the BU800
burnishing pad stays in alignment and allows the pad to follow
the floor contours, leaving a more consistent gloss. Combining
the pad-driver design with the self-regulating pad pressure,
operators have an easy to use, battery walk-behind burnisher
that saves labor time and dollars.

Adding to the ease of operation is the self-lowering burnishing
deck. When the palm switches on the handle are activated, the
burnishing deck automatically lowers to the floor. When the
palm switches are released, the deck automatically returns to a
raised position. Simple controls also minimize training time
of operators.

Safety isn’t sacrificed for price and performance. An angle­activated safety switch keeps the machine from starting when
tipped back in the pad change position. Superior mobility
and line of site during operation add to its safety when
in operation.

The best passive dust control in the market is included on all
models, which contributes to improved indoor air quality
during operation. A felt seal contains all dust within a specially
designed shroud, directing it into a dual-port, disposable filter
bag. For facilities where indoor air quality is even more critical,
optional active dust control is available with the addition of an
Adgility™ hip-style vacuum on the front of the machine.

The Advance BU800 battery burnisher delivers the smooth
performance, consistent shine, and cleaner indoor air quality
that is demanded by today’s customers.

The BU800 has a 20 inch burnishing path, and comes with
either wet batteries for dependable long run time, or
maintenance-free AGM gel type batteries for an even longer
run time. The onboard battery charger allows for convenient
charging at any 120 Volt outlet so that operators don’t need to
return the machine to a storage or charging area.

Reverse button

Better site lines with shorter machine
body than traditional burnishers

Easy to access dust bag

Heavy-duty Industrial
caster wheels

Palm switches for easy
operation

BU800™ tips back for easy
pad changes

Traction drive model
is transaxle driven

Flexible shroud and felt dust
seal captures all dust

Designed for Safety, Comfort and the Environment.

Easy to operate control panel and
palm switches. Non-traction model shown.

Two port dust bag is easy to access for
bag changes.

Pad changes are easier with the tip back
design of the BU800™.

Traction drive model features speed control
and reverse button.

Optional vacuum available for active
dust control.

Choose between wet cell or service-free
AGM batteries. Onboard charger
is standard.

Technical Specifications

Model BU800™ 20B BU800™ 20BT

Burnishing Path / Pad Diameter 20 in (50.8 cm) 20 in (50.8 cm)
Power 36 V, (3) 12 V batt. 36 V, (3) 12 V batt.
Drive (Traction or Non-Traction) Non-Traction Traction
Transaxle Traction Motor – 0.5 hp (0.37l W)
Forward Speed – 0 - 240 ft/min

(73.2 m/min)

Reverse Speed – 0 - 170 ft/min

(51.8 m/min)
Low Battery Protection Yes - ALL MODELS
Onboard Charger 36 V, 25 A DC, 85-265 V / 45-65 Hz AC - ALL MODELS
Pad Motor 2.5 hp (1.9 kW) 2.5 hp (1.9 kW)
Pad RPM (on the floor) 2,000 rpm 2,000 rpm
Pad Pressure Self Regulating up to 30 lb (13 kg) - ALL MODELS
Sound Level 68 dB A 68 dB A
Drive Wheels 1.62 in x 8 in (4 cm x 20 cm) - ALL MODELS
Polishing Rate (Maximum) 24,000 ft2/hr (7,315 m2/hr) - ALL MODELS
Polishing Rate (Practical) 17,600 ft2/hr (5,365 m2/hr) - ALL MODELS
Length 50 in (127 cm) 50 in (127 cm)
Width 23 in (58 cm) 23 in (58 cm)
Height 41.25 in (105 cm) 41.25 in (105 cm)
Batteries
Weight with Batteries 551 lb / 596 lb

Shipping Weight 597 lb / 642 lb

Part Numbers

Passive Dust Control 56383510 / 56383512 56383509 / 56383511

Specifications are subject to change without notice.

200 Ah / 234 Ah AGM 200 Ah / 234 Ah AGM

565 lb / 609 lb

(250 kg) / (270 kg)

(271 kg) / (291 kg)

(256 kg) / (276 kg)

611 lb / 655 lb

(277 kg) / (297 kg)

Accessories and model options

• 20 inch burnishing path

• Wet cell or AGM batteries

• Onboard charger (standard)

• Non-traction or traction drive

• Passive dust control

• Passive vacuum paper bags

• Active vacuum paper bags

• Active vacuum cloth bag

• Aqua HS burnishing pads

• Natural blend tan HS
burnishing pads

• Natural blend white HS
burnishing pads

Smart cleaning.

Our products are designed using innovative

technologies that increase productivity and

drive down the cost to clean.

Maintain peak performance with

Nilfisk-Advance Parts.

©2015 Nilfisk-Advance, Inc. Form L3329A 3-9-15

• Automatic, continuous
pad alignment (standard)

SNAP

IT!

14600 21st Avenue North
Plymouth, MN 55447-3408
www.advance-us.com
Phone [phone]
Fax [phone]

240 Superior Boulevard
Mississauga, Ontario, Canada L5T 2L2
www.nilfisk-advance.ca
Phone [phone]
Fax [phone]

A Nilfisk-Advance Brand

A Nilfisk-Advance Brand

www.advance-us.com
