SPECIFICATIONS SHEET
NUMERIC
INTELLIPAD®CI KEYPAD
Numeric™ Accessory Keypad
• Includes white, bone, and almond Decora®snap-in color inserts
• Compatible with Niles ZR4630 and ZR8630AV multizone receivers
MULTIZONE PRODUCTS
1 2
3
4
5
6
7
8 9
0
– +
RANDOM
GROUP
DISC
F
AV
P
E
S
TOP
PAUSE
M
C
*
P
LAY
REW
F
F
+
_
T
UNER DAT
CO DSS
C
O2 DSS2
V
CR SAT
OFF
MUTE
V
OLUME
Back View: Numeric
(b) Input: RJ-45 connector for
connection to additional
Accessory Keypad Modules.
(c) Output: RJ-45 connector for
connection to Master Keypad
Modules.
Front View: Numeric
(a) Function Keys for individual
component control.
Solo Master Keypad and
Numeric Accessory Keypad
Select Master Keypad, Transport
and Numeric Accessory Keypad
a
b
c
IntelliPad®Ci Keypad
FEATURES
■ Must be used with Solo®, Solo®IR, Select®or Select®IR Master Keypads
■ Numeric keys provide direct access to discs, tracks, stations, and/or DSS/TV channels
■ Random, Group, Disc, and Favorite keys provide advanced system control
■ Available in three designer colors - almond, bone, and white (inserts included with keypad)
SPECIFICATIONS:
■ Dimensions: 1-3/4" wide x 4" high x 1-5/8" deep
Warranty: Two-year limited
Numeric
™
Stock Number
FG00809
Product Detail
NILES AUDIO CORPORATION 12331 S.W. 130 Street, Miami, FL 33186 Tel: 800.289.4434 – www.nilesaudio.com NANUMERICPDF
©2004 Niles Audio Corporation. All Rights Reserved. Niles and the Niles logo are registered trademarks of Niles Audio Corporation.
