Ver.1.0.20110718
User Manual
Contents
1. For your Safety ............................ 5
2. Mobile Phone Profile .................. 8
3. Preparation before Use ............. 10
Install SIM Card ...................................... 10
Install Memory card ............................... 11
Install Battery ......................................... 13
Charge Battery ....................................... 14
Notices on using the battery ................... 15
PIN code ................................................. 16
4. General Instructions .................. 18
Dial key ................................................... 18
Switch-on/off key /End key ..................... 18
Standard keypad .................................... 18
FM function key ...................................... 19
Keypad lock ............................................ 19
Icons in Standby State ............................ 20
Language and Input Mode ..................... 25
Services ................................................... 26
Callers’ group ......................................... 26
5. Basic operation ......................... 27
Switch on ................................................ 27
Switch off ................................................ 28
Dial a Call ............................................... 28
2
User Manual
Adjust Receiver Volume .......................... 29
Answer a Call .......................................... 29
Send DTMF Signal ................................... 30
Dial Hold ................................................. 30
Fast Read SMS ........................................ 31
Missed Calls ............................................ 31
Connect to Voice mail ............................. 31
6. Use of Menu Functions ................ 32
Multimedia ............................................. 32
Phonebook .............................................. 40
Call Center .............................................. 43
Social networks ....................................... 49
Organiser ................................................ 49
Email....................................................... 52
Messaging .............................................. 53
Chatting .................................................. 64
Connectivity ............................................ 66
Settings ................................................... 71
Applications ............................................ 78
Servizi ..................................................... 88
7. Coffer Function ......................... 91
8. Editor Operation ....................... 95
Basic letter input .................................. 106
Number input ....................................... 106
Symbol input ......................................... 107
9. Use of USB .............................. 107
3
User Manual
10. Maintenance & Safety .............. 108
After sales service ................................. 108
Charger and Adapter Safety ................. 108
Battery Information and Care ............... 108
General Notice ...................................... 109
Troubleshooting ................................... 110
11. Abbreviations ........................... 114
12. Certifications ............................ 116
4
User Manual
1. For your Safety
For your safety and proper use of the
mobile phone, please read the following
guidelines carefully: Do not switch the mobile
phone on when close to chemical factory, gas
station or other explosive objects.
During driving, please use headset for safety
purpose; unless otherwise in emergency,
always stop the car on roadside to have a call
conversation.
Because the use of the mobile phone can
cause interference in the aircraft, never use
the mobile phone in aircraft. The use of the
mobile phone is dangerous and illegal; do
switch off the mobile phone before boarding.
Pay special attention to the use of the mobile
phone near heart pacemaker, deaf-aid and
some other medical equipments, because
the mobile phone can cause interference
with them.
None-original factory’s accessories and parts
will lose guarantee.
5
User Manual
Do not dismantle the mobile phone without
permission. In case of failure, please contract
the supplier as soon as possible.
Do not plug the charger into the mobile
phone and charge without battery. Always
power off the mobile phone when taking out
the battery; otherwise the memory of the
phone may be damaged.
When charging the mobile phone, always
keep it in the place with good ventilation,
heat sink and away from flammable and
explosive objects.
In order to avoid demagnetization, always
keep the mobile phone away from magnetic
objects such as CD, credit card etc.
Ensure the mobile phone not to contact any
liquid; once such case occurs, remove the
battery and contact the supplier
immediately.
Do not use the mobile phone in the
environment at too high or too low
temperature, never expose the mobile
phone under strong sunshine or too wet
environment. The suitable temperature for
the phone and accessories is 0℃-40℃. The
height to use the phone shall be less than
6
User Manual
2,000m.
Do not use liquid or wet cloth with strong
cleanser to clean the mobile phone.
This mobile phone has shooting, videoing
and audio recording functions, which shall be
used as per the related laws and regulations.
Always keep the mobile phone out of
children’s reach. Do not throw or vibrate the
mobile phone because violent treatment to
the mobile phone may damage the inner
circuits and precise structures.
Please do not discard the waste battery into
general household garbage. Please deal with
the waste battery according to provisions
where they are definitely made.
Tip: This user manual is based on simplified
Chinese operation mode; so it may vary in English
operation mode.
Warning: We will not be bear any responsibility
for any incompliance with the above guidelines
or improper use of the mobile phone. Our
company keeps the right to make modifications
to any of the content here in this user guide
without public announcement in advance. The
content of this manual may vary from the actual
content displayed in the mobile phone. In such
7
1
2
3
4
5
6
7
8
9
10
User Manual
case, the latter shall govern.
2. Mobile Phone Profile
The mobile phone has the keypad, including
single screen ， one vibration motor, one
charger/ data common transmission port.
(Below is the front of the mobile phone).
8
1.
Receiver
7.
QWERTY keypad
2.
LCD 8.
Phonebook
3.
Trace ball
9.
Key to Message
4.
SEND1key(SIM-1)
10.
End key
5.
Main menu key
11.
Speaker
6.
SEND 2 key(SIM-2)
12.
Camera
11
12
User Manual
9
User Manual
3. Preparation before Use
Install SIM Card
When registering mobile phone number, you
can apply for two different phone numbers, two
different mobile phone network service providers
and thus obtain two SIM (Subscriber
Identification Module) cards.
With these two SIM cards, you can use all
functions of your mobile phone. The SIM cards
save the parameters needed for communications
and personal data, including PIN (Personal
Identification Number) code, phonebook, short
message and other extra system services.
Warning: Do not distort or scratch the SIM card
nor let it contact static, dust or moisture. If it is
lost, please contact immediately your network
operator for help.
Before SIM card installation, please switch off
the mobile phone. The SIM card is installed on
the back of the mobile phone.
Follow the following diagram to install the
SIM card. Please insert the host SIM card into the
10
User Manual
SIM 2
SIM 1
SIM1 slot and the slave SIM card into the SIM2
slot.
Note: If SIM card is inserted only into the SIM1
slot, then only the host works; likely, If SIM card is
inserted only into the SIM2 slot, then only the
slave works. When two SIM cards are inserted
into the SIM1 slot and SIM2 slot respectively, you
can choose work mode freely as you wish.
Note: As the SIM card is small object, keep it out
of children’s touch or prevent children gulping it!
Install Memory card
As the mobile phone does not have enough
11
User Manual
Memory card
storage space, to use some functions, you need
to install a memory card (This mobile phone use
T-FLASH card.)
Install T-FLASH card: Open the back cover to
take out the battery, release the T-Flash card lock,
insert the T-Flash card into its slot, and restore
the lock and the battery before restarting the
mobile phone.
Note: As the T-FLASH card is small object, keep it
out of children’s touch or prevent children
gulping it!
12
User Manual
Battery
Battery
Install Battery
The mobile phone is suitable for original
battery and accessories. When the battery is idle,
it is recommended to put it into the protection
box.
Follow the following diagram to install the
battery.
Note: Do install the battery as per the diagram so
as prevent the battery contact patch being
damaged.
13
User Manual
Earphone
Charger Port /USB
Charge Battery
The new battery cannot reach the optimal
efficiency unless it has undergone several
continuous complete charges and discharges.
When the battery is used up, charge it in
time. Over-discharge can damage the battery.
After the battery is charged full, cut off the
connection of charger with the AC power supply
and the connection with the mobile phone.
Follow the following diagram to connect the
charger.
During charging, the battery capacity icon
on the screen flickers from the right to the left.
After the battery is charged full, the icon is full of
bars. Slight heat during charging is normal.
Warning: When a travel charger and its
accessories are used to charge the battery,
please firstly check if they are original or
14
User Manual
recognized by the original manufacturer. The use
of other accessories may damage your mobile
phone and cause risks! Always use them indoor
and dry places.
Notices on using the battery
The performance of the battery is affected
by many factors, including radio barrier network
settings, signal strength, signal strength, work
temperature, chosen and used functions or
settings as well as phone accessories, tone, data
or other applications.
For optimal performances, please follow the
rules below:
New battery or the battery having been idle
for long need charging for long. The standard
voltage scope for the battery is 3.6V-4.2V.
During charging, keep the battery at room
temperature or similar temperature.
With time passing by, the battery will
gradually be worn and thus need longer time
to charge. This is normal. However, after
normal charging, if call duration decreases
but charging time increases, you need to buy
another battery from the original
15
User Manual
Warning
Charging the mobile phone by
improper means can cause to explosion.
Always refer to the related regulations for
the disposal of the battery.
manufacturer or authorized by the original
manufacturer. The battery of interior quality
can damage your mobile phone and cause
danger!
If the phone is overused at low battery when
charging, there might need a longer time for
the charge indicator to be shown on the
screen.
Note: Please dispose the battery according to the
local regulations. Try to recycle the battery as
possible. Do not treat the waste battery as
common waste.
Warning: Do not throw the battery into fire so as
to prevent fire. The broken battery may cause
explosion.
PIN code
PIN1 Code: It is the personal identification
number used to enter SIM and able to prevent
16
User Manual
others using SIM1 without permission. If the
mobile phone has activated the PIN1 code
protection, when the mobile phone is switched
on, the screen will display “Input PIN”. In the
process of inputting PIN1 code, the screen will
use “*” to represent the input content. While
obtaining SIM, you can obtain its PIN1 code.
PIN2 Code: It is the personal identification
number used for some special functions such as
paid call etc.
PUK Code and PUK2 Code(8-digit)
To change the locked PIN code, you need to
use PUK (Personal Unblocking Key) code. To
change the locked PIN2 code, you need to use
PUK2 code. If these two codes are not provided
together with the SIM cards, ask the local service
provider for them.
Warning: If the PIN code is input wrongly for
successively three times, the SIM card will be
locked. Please contact the network operator
immediately for help. Attempt to unlock the code
may make the SIM card ineffective forever!
17
User Manual
4. General Instructions
Dial key
It is used to dial a call (with phone number
entered or in phonebook state) or receive an
incoming call. In standby state, press this key to
display the latest call register (SIM1 and SIM2
support respectively 20 call entries, including
received calls, missed calls and dialed calls). In
dual-SIM standby mode, press this key to have an
option menu on which you can choose to operate
via SIM1 or via SIM2.
Switch-on/off key /End key
In call state, it is used to interrupt a call; in
call conversation state, it is used to end a call or
exit from the current menu and back to the
standby state. Hold this key for 4~5s to switch
on/off the mobile phone.
Standard keypad
On the keypad, you can see A-Z （ 0-9
number keys ）number keys, * key and # key,
totally 42 keys.
18
User Manual
Press these keys to input phone number,
password, English letters, symbols or choose
menus.
In different states or different functional
menus, “+” key and “-“key have different
functions:
In music player state, “+” and “-” are used to
adjust volume.
FM function key
OK key: In radio state, press the key to record
In search state, press the left/right key to
search channels forward and backward,
press the OK key until you find an effective
channel. For FM, you can have a tuning of
0.1MHz downward or backward.
1-9 number keys: If they are pressed shortly,
you can switch to the corresponding
channels saved in the channel list; if they are
pressed long, you can save the current
frequency to the corresponding channel.
+, - key: Adjust volume.
Keypad lock
When in standby interface, if the mobile
19
phone is idle for certain time, it will be locked
Icon
Status
Meaning
SIM1 / SIM2 No
signal
SIM1 / SIM2
Signal searching /
Signal Level
automatically. It can be locked an unlocked by
pressing the home key and “*”to release. After
the mobile phone is locked, the keypad cannot
be activated easily; in case of incoming call,
likewise, press the answer key to receive it; after
that, the keypad will be locked automatically.
Icons in Standby State
User Manual
20
No power
charging
disconnect
WIFI signal level
/ searching
BT powered on
User Manual
21
BT powered on
Call Active
Call Hold
Call Mute
Alarm on
Audio playing
Auto answer
machine
Auto answer
machine
recording
User Manual
22
Background
sound on
SIM1 / SIM2 CSD
connection
SIM1 / SIM2
EDGE connection
SIM1 / SIM2
EDGE connecting
SIM1 / SIM2
GPRS connection
SIM1 / SIM2
GPRS connecting
SIM1 / SIM2 Call
forward(Line 1 /
Line 2)
User Manual
23
SIM1 / SIM2
Missed Call
SIM1 / SIM2 new
messages
SMS sending
SIM1 / SIM2
roaming
SIM1 / SIM2
MMS busy
SIM1 / SIM2 new
MMS
SIM1 / SIM2 /
both new emails
Earphone
plugged in
User Manual
24
Profile ring mode
Profile silent
mode
Vibrate and ring
Vibrate then ring
Profile Vibrate
mode
Java program
minimizing
Language and Input Mode
mode. For different areas, there are different
languages and corresponding input modes.
Call hint
User Manual
The mobile phone has defaulted abc input
25
User Manual
The mobile phone is inbuilt with vibration
motor and buzzer and provides several incoming
call modes:
Ring
Vibration
Ring and vibration
Ring after vibration
Services
Services are provided with SIM kit. The
mobile phone support service function. The
detailed menu items depend on SIM card and the
network. When the network provides such
function and your SIM card supports such
function, the service menu will automatically be
posted in the services of the mobile phone.
Callers’ group
The callers’ group in the mobile phone
includes friends, family, VIP, colleagues and
others etc. You can set different call tone and
photo for different callers’ group.
26
User Manual
5. Basic operation
Switch on
Press the switch-on/off key to start the
mobile phone, then the screen will display
switch-on image. Then you can enter Settings
menu to set phone modes, including Dual SIM
Open, Only SIM1 Open, Only SIM2 Open and
Flight mode. The defaulted one is Dual SIM Open.
After insert SIM card, the mobile phone will
automatically check the SIM card availability, and
then it will be shown information as following on
the display by sequence:
1. “Input phone password”——If you have set
the password.
2. “Input PIN” —— If you set SIM card
password.
3. “No service”—Indicates fail to make register
and cannot make any calls.
4. “Emergency calls only”—indicates has
registered to other network and only can
make call to 112.
5. “Searching”—the mobile phone is searching
network until find appropriate network;
6. “Operator name”—Indicates network
successfully registered.
27
User Manual
Note: If you do not know PIN code, please
contact the network service provider.
The defaulted phone password is “1122”.
Switch off
To switch off the mobile phone, press the
end key. When the screen displays switch-off
cartoon, the host and the slave will be off at the
same time. Do not take out the battery to switch
off the mobile phone. If so, the SIM card can be
damaged easily and some data will be lost.
Dial a Call
With the number keypad, you can enter
phone numbers (if wrong characters are
input, press the clear key to delete them).
Press the dial key to dial the phone number.
In SIM1 and SIM2 On state, you can choose
to dial a call via SIM1 or SIM2. To end a call,
press the end key; or to cancel a dial, press
the Cancel key or the switch-on/off key. After
the call is connected, you can see the call
timer on the screen.
Dial a call via phonebook: Enter the
phonebook and search the desired
28
User Manual
name/phone number, and then press dial
key to dial call.
Redial latest dialed number: In standby state,
press dial key to view the list of the latest
dialed 20 phone number or names. Roll to
the desired phone number or name and
press dial key to dial call.
Adjust Receiver Volume
In call conversation, press the “+”and “-” to
adjust the volume of the receiver.
Answer a Call
When there is a call, as per the settings of
the mobile phone, you will be alerted with ring,
vibration, vibration and ring as well as ring after
vibration.
To receive a call, press Dial/Call Key.
To refuse a call, press Switch-on/off key or
the end key directly.
If the CLI (Call Line Identity) is opened, the
phone number of the caller will occur on the
screen. If this number has been saved in the
phonebook, the name corresponding to this
number will be displayed on the screen.
29
User Manual
Send DTMF Signal
When this function is set, in call
conversation, press the desired number key and *
key and # key to send DTMF signals to the other
party. If such function is inactive, then extension
call will become impossible.
Dial Hold
If you have applied for dial hold, in the call
conversation process, press “Options” to have
the following function menus:
Pause: Pause the current call but with the
line keeping connected.
End: End the current call conversation.
New Call: Enter the dial interface, dial
another call.
Phonebook: Enter the directory of the
phonebook.
SMS: Enter the directory of theSMS.
Record: While having call conversation, you
can record the call.
Activate/Inactivate Handfree: You can
activate/inactivate the speaker.
DTMF: You can set whether to send DTMF
signals.
Note: Some menu items need the support of the
30
local network or can occur in special cases, such
User Manual
as Conference and New Call. Consult the local
network operator for details.
Fast Read SMS
When the user receives unread SMS, the
screen will display an icon of unread SMS. Press
Read to enter and read the SMS. The SIM card 1
unread SMS icon is marked with “1” and SIM card
2 unread SMS icon is marked with “2”.
Missed Calls
When there is a missed call incoming, the
screen will display a missed call icon. And press
Read to enter and read missed calls.
Connect to Voice mail
The mobile phone allows connecting the
incoming call into the voice mail and then you
can receive a notice about voice message. (The
voice mail number must be preset).
31
User Manual
Options
Description
Photos
To view the saved photos.
6. Use of Menu Functions
Multimedia
Camera
With this function, you can use the inbuilt
camera to take photos. The lens of the camera is
located on the back of the slide and the screen is
used as the viewing window. All photos taken are
in JPG form. After downloading the photos onto
PC, you need some software to view them.
If the storage space of the mobile phone is
insufficient to store the taken photos, it is
necessary to delete some old photos or other
files in “File Management” function list to release
more space.
Description of Mobile Phone Options:
32
User Manual
Camera Settings
Shutter Sound: sound 1, sound 2, sound 3 and
Off.
EV: EV-2 ——EV+2.
Contrast: High, Medium, Low.
Banding: 50Hz(default), 60Hz.
Delay Time: 5s, 10s, 15s or Off.
Cont.Shot: 1 Shot , 3 Shot , 5 Shot and Off.
Image Settings
Size: 320x240, 640x480, 800x600, 1600x1200,
2048x1536.
Quality: High, Normal, Low.
White Balance
Auto, Daylight, Tungsten, Fluorescent, Cloudy,
Incandescent
Scene Mode
Auto, Night.
Effect Settings
Normal, Grayscale, Sepia, Sepia green, Sepia
blue, Color invert.
Storage
Phone, Memory Card.
Restore
Default
You can restore the recorder to factory
settings.
Image viewer
All photos taken are saved in the album.
33
User Manual
Options
Description
View
You can view the selected photos.
Slide show
You can browser pictures as Slide show.
Edit
You can edit the pictures as the phone
guides.
Browse Style
There are two browse styles, i.e. list and
matrix.
Send
As multimedia message; as email; via
Bluetooth.
Use as
You can send photo to wallpaper ,Screen
saver, power on display, power off display,
call picture.
Rename
You can rename the selected photo.
Delete
You can delete the selected photo.
Delete All files
You can delete all photos in the album.
Sort by
For convenience of search, you can rank
them as per name, type, time and size or
choose “None”.
Storage
You can choose photos storage path (to
phone or memory card).
Video recorder
Press the OK key to start video recording.
The duration of recording depends on the time
limit set and file management capacity. Entering
34
User Manual
Options
Description
Camcorder
Settings
You can set White Balance, EV, Night
Mode and Banding for your recorder so as
to have high-quality videos.
Video Settings
You can set here the video quality.
Effect Setting
There are 6 options available.
Storage
You can choose videos storage path (to
phone or memory card).
Restore
Default
You can restore the recorder to factory
settings.
Options
Description
Play
It supports the videos in MP4 and 3GP and will
not be limited by file size. Click the play
interface to play.
Send
As multimedia message; as email; via
the options, you can have the following settings:
Video player
It supports the videos in MP4 and 3GP
format.
Options of the player
35
User Manual
Bluetooth.
Rename
You can rename the specified video.
Delete
You can delete the specified videos.
Delete All
files
You can delete all files.
Sort by
For convenience of search, you can rank them
as per name, type, time and size or cho ose
“None”.
URL
streaming
You can v iew streaming video clips f rom
YouTube (default) or some other URL.
Network
Profiles
You can select a profile from the list.
Storage
You can choose video storage path (to phone
or memory card).
Audio player
If the operation system is Windows 2000
above, no driver needs installing. To download
music, you must insert the T-Flash card into the
mobile phone, switch off the mobile phone,
connect the mobile phone and PC with USB cable,
then the PC will detect the new hardware and
create a new mobile HD. Download the chosen
MP3 file to under "My Music" of the mobile disk
36
rather than in such folders as Audio, Images and
Options
Description
Play
Play the current chosen music.
Details
View file name, track, SQ , file size, music
duration, music name, singer, music special a
music type etc.
Add to
Ringtones
Add the chosen music into the ring base.
Refresh
list
Enter the tracklist and update it (e.g. the
deleted music in the file management will not
disappear until update is conducted.
Settings
Play Settings: tracklist path, automatic tracklist,
repeat, shuffle ,background play.
User Manual
Photos; otherwise, the file cannot be played.
(Only the music in MP3, AMR and MIDI are
supportable).
Description of audio player options:
Sound recorder
After choosing “Sound Recorder” and press
“OK” to enter, you can the previous record files.
Press “Options” to have the following operations:
Record: You can record new files.
Play: You can play the selected file.
Append: You can have annex record for the
files of the superior level (only for the record
37
User Manual
files in AMR).
Rename: You can rename the chosen file.
Delete: You can delete the chosen file.
Delete All files: You can delete all files.
Settings: You can set the storage position for
record files, including phone and memory
card. Also you can set the format of the
record file, including AMR and WAV.
Use as: You can used as user profiles.
Send: You send the record file to Bluetooth,
email and multimedia message.
Photo editor
This Photo editor has the Photo artist and
Image tiles. You can set the photo as the phone
guides.
FM radio
Your mobile phone supports FM radio. To
use the mobile phone to listen to radio, insert the
headset connection cable into the headset port
on the mobile phone. The headset connection
cable functions as the antenna of the FM radio,
so it should hang freely. While listening to radio,
you can dial or receive a call normally. During call
conversation, the radio will turn mute
automatically. If some applications are using
38
GPRS or CSD to send or receive data, they may
User Manual
interfere with the radio.
When the FM radio is activated, the mobile
phone will display the number and name (if
having been saved) and frequency of the radio
channel. If you have saved some radio channels
(at most 9 channels) in the mobile phone, you
can roll to choose the desired channel or press
any of number keys 1-9 to choose the
corresponding channel.
Option menu
Channel list: You can edit and save 9
channels.
Manual input: You can edit the specified
radio frequency band. The frequency of the
radio is between 87.5mHz and 108.0mHz.
Preset Auto Search: You can have automatic
search and save the searched channels into
the list.
Settings: You can set background play, loud
speaker, record format, audio quality and
record storage.
Record: You can record new files.
Append: You can have annex record for the
files of the superior level (only for the record
files in AMR).
File list: the record files
39
User Manual
Schedule FM record
You can schedule to record certain FM Radio
channel at any time, so that you will not miss the
program.
Melody composer
With this function, you can play the melody that
you compose.
Enter to the interface; you can enter the melody
from 1-7 numbers key. After composing, you can
choose the play speed, instrument as the phone
guide.
Slide Show
You can browser pictures as Slide show. Select
the files or pictures to browse.
Phonebook
The mobile phone is provided with the
business card folder type phonebook. The
information of every contact saved on the mobile
phone include three phone numbers (mobile
phone, home phone and company phone),
40
User Manual
company name, e-mail, fax, birthday, big-head
sticker, tone, callers’ group (five types: family,
friends, VIPs, colleagues and others). Every
contact saved into SIM1 and SIM2 can only
include name and number. The mobile phone
supports 1,000 groups of numbers.
View
You can browse the details of the contract.
Send text message
Input the message, and you can sent to the
contract.
Send multimedia message
Input the multimedia message, and you can
sent to the contract.
Call
You can make a phone call of the contract by
pressing this option
Edit
You can edit the name and the number of the
contract.
41
User Manual
Delete
You can delete the current contact.
Copy
You can copy current contacts to phone, to
SIM1, to SIM2, to SIM2, to file.
Move
You can move the contacts to phone, or to
the contrary SIM card.
Send contact
You can send the contract as the phone
guides, as text message, as multimedia message,
as email and via Bluetooth.
Copy contacts: You can copy the contact
from SIM1 to phone, from phone to SIM1,
from SIM2 to phone, from phone to SIM2,
from SIM1 to SIM2, from SIM2 to SIM1.
Move contacts: You can move the contact
from SIM1 to phone, from phone to SIM1,
from SIM2 to phone, from phone to SIM2,
from SIM1 to SIM2, from SIM2 to SIM1.
42
User Manual
Caller Groups
You can set call tone, photo and members
for five callers’ groups. Callers’ group member
can only come from the number saved on phone.
Phonebook settings
Preferred Storage: You can choose the
storage path for the current number.
Speed dial: On or Off
My vCard: You can edit and send your
business card.
Vcard version: Including vcard 2.1 and vcard
3.0
Extra numbers: Have the related choice to
have the option.
Memory Status: You can view the current use
status of the phonebook, including SIM1,
SIM2 and phone memory. The display format
is “Used/Total”.
Delete all contacts: You can have four modes
regarding deletion: from SIM1, from SIM2,
from phone and one by one.
Call Center
Call Center includes Call History and Call
43
User Manual
Settings. In dual-SIM mode, you can separately
search the call register of SIM1 and SIM2 and set
separately some operations corresponding to
SIM1 and SIM2. In mono-SIM standby mode, you
can set the available SIM card and see its call
register.
Call history
Call history includes missed calls, dialed calls
and received calls.
In missed calls, received calls and dialed
calls function list, you can see the date and time
of the call, edit or delete the phone number in
the list, save the number to phonebook or send
SMS and MMS to the number, etc.
Note: SIM1 and SIM2 contain respectively
20 entries. Choose any entry from missed calls,
received calls and dialed calls, press the Send key
to dial the number directly.
Call timers
Last Call: with this function, you can view the
duration of the last call.
Dialed calls: with this function, you can view
the duration of all calls.
Received calls: with this function, you can
44
User Manual
view the duration of the received calls.
Reset all: with this function, you can reset all
the records of the calls.
Call cost
This needs the support of the network service
provider.
Last call cost: with this function, you can
view the cost of the last call.
Total cost: with this function, you can view
the cost of all calls.
Reset cost: with this function, you can reset
all the records concerning the cost of the
calls.
Max. cost: with this function, you can set a
limit to the cost in the specified currency.
This setting requires the input of PIN2 code.
Price per unit: this function requires the
support of the network service provider.
Please contact your service provider for
further details.
SIM text message Counter
With this function, you can see and preset
the number of sent messages and received
messages.
GPRS Counter
45
User Manual
Last Sent: You can view the sending traffic of
last link.
Last Received: You can view the reception
traffic of last link.
All Sent: You can view the sending traffic of
all links.
All Received: You can view the reception
traffic of all links.
Reset Counter: You can clear all link traffic.
Call settings
[SIM Card settings]
Caller ID: Including set by Network, hides ID and
send ID.
Set by Network: While having a call
conversation, you can send my caller
ID in the form preset by the system.
Hide ID: While having a call
conversation, you will not send my
caller ID. If the system does not
support such function, call may fail.
Send ID: While having a call
conversation, you can send my caller
ID to the system.
Note: This function needs network support.
46
Name
Description
Divert All
Voice Calls
The network will divert all
voice calls without
conditions.
Divert if
Unreachable
When the network cannot
find your mobile phone
(switched-off or out of the
service area), it will divert
the calls.
Divert if no
Answer
When the mobile phone
does not answer the call,
the network will
automatically divert it.
Divert if Busy
When you are on line, the
network will divert the
Call Waiting: You can set this function On or Off.
The call hold and multi-party call cannot be active
unless this function is activated. This needs
network support.
Call Divert: This is a kind of network function,
which cannot be used unless you apply to the
network operator for it. With this function, you
can divert calls meeting he conditions to another
number.
User Manual
47
call.
Divert All
Data Calls
Network support needed.
Cancel All
Diverts
Cancel all divert functions.
[Advance settings]
Call Firewall Setup: you can set here the Black list
and the White list, block unknown numbers and
block anonymous numbers separately SIM1 and
SIM2.
Auto Redial: you can set it as On or Off. After the
first automatic redial fails, you can have at most
ten times to connect a phone number.
Background sound: you can select one
background sound to use during conversations,
or record one yourself.
Call time Display: You can set whether to display
call duration during call conversation.
Call Time Reminder: You can set one alert tone
or periodic alert tone for several round minutes
during call conversation so that you can
understand call time. You can turn off the alert
tone.
User Manual
48
User Manual
Auto quick end: You can set call duration. After
the set time expires, the mobile phone will
automatically end the call.
Reject by SMS: You can have this function as
choose it On/Off.
Note: Some settings need network support. For
example, call barring can not be used unless the
local network and SIM card open it.
Social networks
Facebook
By pressing this menu, you will be connected to
Facebook. Then, you can enjoy accessing the well
known face book social networking.
Twitter
By pressing this menu, you will be connected to
Twitter. Then, you can enjoy accessing the well
known microblogging platform.
Organiser
Calendar
With this function, you can set the alarm
49
clock to remind you of your schedule and record
User Manual
your schedule. To view all memos of one day,
press OK to see the schedule. You can have the
following operations:
View: You can view the schedule of the date
where the cursor is on and set the time,
date, content and whether to activate alarm
on this schedule of todays. When editing the
schedule, you can choose alarm type with
the left and right direction keys. In addition,
you can have such operations as Delete,
Delete and Add on the schedule.
View all: You can view the entire schedule of
the date where the cursor is on and set the
time, date, content and whether to activate
alarm on this schedule.
Add event: you can select task type as
reminder, meeting, course.
Delete event: You can delete the task as the
phone guides.
Jump to Date: You can move to the calendar
of the specified date.
Go to weekly view: You can go to weekly and
monthly view.
50
User Manual
Tasks
You can have such operations as Create
Memo, Browse, Add, Edit, Delete, Delete All and
Send on memos.
If you have set alarm for the memo, when
the set time is reached, the mobile phone will
ring and display the memo content.
Alarm
The time format for the alarm clock is
identical to that of clock. When the mobile phone
is off, the alarm clock can still work provided the
battery is sufficient. The system has set 5 alarm
clock options and the defaulted is off. You can
activate one option or all options according to
the actual demand. Every alarm clock option can
set independent time and date. When the time is
reached, the mobile phone will give out alert
tone and flicker the current time and date on the
screen. Press Stop to stop alarm clock; press
Sleep, then the mobile phone will pause ringing
and continue after 4min.
If alarm time is reached but the mobile
phone is switched off, then the mobile phone will
be switch on automatically and ring. If Stop is
pressed, then the mobile phone will ask you
whether to switch on the mobile phone. Press
51
“No” to switch off the mobile phone and “Yes” to
register at the network and switch on the mobile
phone.
User Manual
World clock
Press the left and right direction keys to
view the current time of every country
corresponding to every time zone.
Email
Before sending or receiving emails, you need
to create and activate an email account.
Before use, you need to set the e-mail in the
“E-mail accounts” menu. Via this menu, you can
receive and send e-mail.
Send and Receive: You can send/receive
the e-mail from the specified mailbox.
Write Email: You can edit e-mails.
Inbox: You can see the received e-mails.
Outbox: You can see the sent e-mails.
Sent: You can send e-mails.
Drafts: You can see the drafts in the
specified mailbox.
Clear mailbox: You can clear the e-mails in
the specified mailbox, including inbox,
outbox, sent e-mail backup and drafts, or
52
User Manual
clear all e-mails.
Delete Marked emails: You can change the
status of all e-mails to deleting status,
Email accounts: You can set up you new
account.
Templates: you can pre-edit some common
phrases, which is convenient for quick
editing.
Messaging
SMS
SMS is a kind of network service that cannot
be used to send and receive short messages until
you apply to the network operator
Both SIM cards of the mobile phone can
send and receive SMS. The SMS is sent to the
SMS center of the network and then sent by the
network to the target user (GSM user). If the user
does not switch on the mobile phone or the
mobile phone cannot receive the SMS (the
memory is full), the network will save the SMS
temporarily. The duration of storage depends on
sender’s settings and network service provider.
With this function, the mobile phone can
send and receive chain text messages, which may
53
User Manual
affect the message fees. For more information,
please consult the service provider.
When the SMS capacity is full, there will be
an SMS icon flickering on the standby interface.
The full capacity can affect SMS reception. Delete
some SMS to solve the problem.
If the other party has received SMS, you will
hear the alert sound from the mobile phone (if
such alert function is set as ON)
Note: When sending SMS via the SMS network,
the mobile phone may display “Message sent”. It
indicates that the SMS has been sent to the SMS
center inbox set in the mobile phone but does
not mean the receiver has received the SMS. For
more information, please consult the service
provider.
Write Message
You can write message in this menu.
Every SMS can contain 160 word length
English characters. To write SMS, press “#” key to
switch input modes, “*” key to select Symbol;
press “Clear” key to clear one character before
the cursor, long press “Clear” key to delete all
characters; press the end key to back to the
standby interface, press the upper and down
direction key to choose characters.
54
User Manual
The mobile phone can send the chain SMS
more than 160 characters (limit for common text
messages). If the SMS contains more than 160
characters, then the SMS will be split into 2pcs or
more. Yo u can insert Picture, My picture,
Predefined animation, My animation, Melody,
My melody, Predefined sound into SMS. However,
the SMS will not be received and displayed unless
the network and the receiving mobile phone
support.
You can enter the phone number or choose
a number from the phonebook to send the SMS.
In dual-SIM standby mode, you can choose to
send the SMS via SIM1or SIM2.
Inbox
You can see the SMS in the SIM1/SIM2 inbox.
Reply: You can reply to the received SMS.
Delete: Delete the current SMS.
Forward: You can directly forward this SMS
to others.
Copy to phone: You can copy the entries in
SIM card onto the phone.
Move to phone: You can move the entries in
SIM card onto the phone.
Chat: You can chat with the sender after set
a chat room.
55
User Manual
Delete all: You can delete all SMS in inbox.
Copy all: You can have two options, i.e. copy
all entries on the SIM card in the inbox onto
the phone or vice versa.
Move all: You can have two options, i.e.
move all entries on the SIM card in the inbox
onto the phone or vice versa.
Use number: You can extract the number in
the SMS and save it or dial a call.
Use URL: You can link to the website
contained in the received SMS.
Outbox
While sending SMS, if choosing “Save and
send”, you can save the SMS into the Outbox. You
can directly save the edited SMS into the Outbox,
in such case; the Outbox will display “No
number”, i.e. no target number. If you fail to send
the SMS, it will be saved in the Outbox. Also, you
can have such operations as Send from
SIM1/SIM2, Edit, Delete, Copy to phone ,Move to
phone, Delete all, Copy all, Move all, Use number,
Use URL.
Templates
With it, you can pre-edit some common
phrases, which is convenient for quick SMS
editing.
56
User Manual
SMS settings
You can set some parameters of the SIM1
SMS or SIM2 SMS in the menu.
Profile settings: To send SMS, you must
input the SMS center number.
Note: The SMS center number is provided by the
network operator.
Common settings
Delivery report: The network will
inform you whether the other party
has received the SMS and what the
time is.
Reply path: You can send the reply
path to the network terminal. This
function needs the support from the
SMS center.
Memory status: You can view the
capacity of the SIM card or the phone
for SMS by number.
Preferred storage: You can set the
storage position (SIM or phone) for SMS.
MMS
MMS can contain words, sound and photos.
If the MMS is out of the limit, the mobile phone
will be unable to receive the MMS. If the SMS
57
User Manual
contains photos, the mobile phone will adjust
photos so as to display them on the screen
completely.
The display effect of MMS depends on
reception devices.
Note: You cannot use photo messages unless the
network operator or service provider supports to
do so. You cannot receive and display MMS
unless the mobile phone has the compatible
MMS or e-mail function.
Write message
To
Add Number-- Input the number of
the receiver.
Add E-mail-- Input the e-mail of the
receiver.
Cc
Add Number-- Input the number of
the receiver.
Add E-mail-- Input the e-mail of the
receiver.
Bcc
Add Number-- Input the number of
the receiver.
Add E-mail-- Input the e-mail of the
receiver.
58
User Manual
Subject: You can edit the subject of the
MMS.
Edit content
Press Edit key to have the following options:
Add text: You can write you want to
say.
Add picture: You can insert you
desired picture.
Add audio: You can insert your
desired audio.
Add attachment: You can insert you
desired attachment.
Add slide before: You can add a slide
before the current page.
Add slide after: You can add a slide
after the current page.
Preview: You can preview the
editing effect of the current MMS.
Slid timing: You can set the play
time of every slide.
After editing, you can press “Done” key to
finish the MMS, in this option you can send the
MSM as following methods: send only, save and
send, save to drafts or save as template, you can
also set functions including: Validity period,
Delivery report, Read report, Priority.
59
User Manual
Inbox
You can see the MMS in the inbox and have
the following operations:
View: You can view the MMS and save
photos, audio and annex.
Reply: Reply the sender with MMS Reply by
SMS: Reply the sender with SMS.
Reply all: If the MMS you received has been
sent to many receivers by the sender, with
such function, you can send a reply MMS to
the same receivers.
Forward: You can directly forward this MMS
to others.
Delete: Delete the current MMS.
Delete all: You can delete all MMS in inbox.
Save as template: You can save the MMS as
template.
Properties: View the detailed information of
the current message.
Use details: You can extract the number in
the MMS and save it or dial a call. You can
also use the URL in the MMS.
Outbox
You can view the MMS send and saved in the
Outbox and failed and have such operations as
View, Send, Delete and Delete all, Save as
60
User Manual
template, Properties and Use details.
Drafts
You can save the edited MMS into the drafts,
and also you can have such operations as View,
Send, Edit, Delete and Delete all, Save as
template, Properties and Use details on the MMS
in the drafts.
Template
There are 5pcs preset MMS in the mobile
phone and you can have such operations as View,
Write message and Properties from Template.
There will be the templates which user defined.
SMS timing send
From this menu you can set the time
and date when the message shall be sent out, or
set the sending delay.
Message settings: You can set some parameters
of the MMS in the menu.
Compose:
Creation mode-- "Free" and
“Restricted ".
Picture resizing-- You can reduce the
size of the inserted photo, including:
160x120, 320x240 and Off.
Best slide duration-- You can set On
or Off to activate such function.
61
User Manual
Auto Signature-- You can set On or
Off to activate such function.
Signature-- You can edit the content
of the automatic signature.
Send:
Validity period-- You can set the
time to save in the MMS service
center and send, including
Maximum,1 hour, 6 hours, 12 hours,
1 day, 1 week.
Delivery report--You can On or Off
to activate such function.
Read report-- You can On or Off to
activate such function.
Priority-- Including Medium, High,
Low.
Slide timing-- You can set the
interval of the receiver to see the
MMS, defaulted as 5s
Delivery time -- Immediate, 1 hour
later, 12 hours later and 24 hours
later.
Retrieve:
Home network—Immediate and
Rejected, Delayed.
Roaming -- The same as to the main
62
User Manual
network, including and As home,
Delayed and Rejected,.
Read report—On request, Send,
Never send
Delivery report—You can set On or
Off to activate such function.
Filter:
Anonymous -- Allow and Reject.
Advertisement-- Allow and Reject.
Server profile:
In dual-SIM mode, you can separately set
SIM1 and SIM2. After choosing Settings, you can
have the following settings:
Activate account.
View account: You will view the
Account name, MMSC address, Data
account, Connection type, User
name and Password of the account.
Memory Status:
You can see the utilization rate of the
mobile phone, including the used space and the
usable space. The sub menu should show SMS
capacity in Numbers.
Broadcast Message
63
User Manual
Broadcast is a kind of information service
such as weather report, traffic etc that the
network operator sends to the GSM users within
a certain area. In Dual-SIM mode, you can
separately set SIM1 and SIM2.
Receive Mode: You can select the on/off
tab for such a function.
Read Message: You cannot read the
received information until you open such a
function.
Languages: You can set the language for
the received information.
Channel Settings: You can choose, add and
edit and delete channel numbers.
Chatting
MSN
This mobile phone provides inbuilt MSN
application. To run this application is simply to
navigate into application and enter MSN ID and
password like to do it on your computer. You
should set the parameters required to run the
MSN application will access the network. You
need to set the parameters correctly based on
64
User Manual
the SIM card you are using. To set the parameters,
you are kindly refer to Menu > Services > Data
account > GPRS. Please consult to the operator to
have the correct setting and make sure the
mobile phone can connection with internet
access the WAP function.
Yahoo Messager
With this function, you can communicate
with others just input the user’s name and the
password. Make the settings as the phone
guides.
Google talk
With this function, you can have
communication with others, by inputting the
Users name and the password, enter the
interface as the phone directs.
Skype
With this function, you can have
communication with others, by inputting the
Users name and the password, enter the
interface as the phone directs.
65
User Manual
Ebuddy
This application is a web browser, that you
can possible open a Website through your phone.
Just put a web site address and press OK to visit
the web site. Refer to the phone to have the
related functions.
Connectivity
Bluetooth
The mobile phone supports the Bluetooth
function. You can use Bluetooth wireless
technology to set wireless connection with other
compatible devices, including mobile phone,
computer, headset, in-car accessories etc. With
Bluetooth function, you can send photo, video
segment, audio segment, personal business card
and memo. You can also establish wireless
connection with the compatible PC to transmit
files and connect to web by dialing number via
SIM.
As the device supporting Bluetooth wireless
technology performs communications via
wireless wave, you need no keeping the device
opposite to other devices but keep the distance
66
User Manual
between tem not more than 10m (about 33”).
However, Bluetooth connection can be affected
by wall or other electronic equipments etc. To
ensure mutual operation between this device
and other devices supporting Bluetooth wireless
technology, consult the manufacturer to confirm
whether the device by it is compatible with this
device. Do not use Bluetooth function in hospital
and aircraft etc.
Bluetooth Menu
Power: Before using Bluetooth function, you
need to activate this option. When Bluetooth
function or other functions are being used,
allowing this function to operate in the back desk
will consume more power. It is recommended to
close this function when it is idle.
Inquiry audio device: With this function,
you can inquiry audio device. For other devices,
enter My Devices to search.
My Device: After entering this option, you
will see the Bluetooth devices compatible with
the mobile phone. Entering options, you can have
necessary operations on the desired Bluetooth
device or search the incompatible Bluetooth
devices.
Active Devices: With this function, you can
67
User Manual
see all devices connected with the mobile phone
and their link service type. You can interrupt the
specified link service.
Settings: Before using Bluetooth function,
enter this menu to have corresponding settings.
If your mobile phone’s Bluetooth function is not
activated, you can have activation confirmation.
Visibility: After this option is activated,
other peripheral devices supporting
Bluetooth wireless technology can see
your device and its name via search. After
the step audio play service is activated, this
device will be unable to be searched.
Change Device Name: You can edit my
device name.
Authentication: After this option is
activated, matching is needed when
peripheral device accesses my device via
Bluetooth (for matched devices as well).
After closing the option, no matching is
needed for the matched devices.
Audio Path: You can leave the audio on my
device or send to other hand-free devices
via Bluetooth. If using Bluetooth to have a
call, set this path as hand-free devices.
FTP Settings: You can set the file directory
68
User Manual
shared by my device and the access right
to online Bluetooth devices.
About: Here, you can see the name of my
device, my device’s Bluetooth device address and
the Bluetooth services supported by my device.
Tip: When searching Bluetooth devices, make
sure that the peripheral Bluetooth devices are
within the signal cover range and can be
searched. To match the searched devices, you
need to discuss with the user of this device about
a pair of matching passwords. To match the
hand-free device, you must input its matching
password. After matching, this device will be
saved in my device view.
Data account
GSM Data—You can set the number, name DNS
etc.
GPRS—You can set the name, APN, user name,
password, Auth. type, DNS.
Note: For related charging standard and detailed
settings, please consult the local network
service operator. Different network service
providers provide different services.
Consult the local network operator.
69
User Manual
WLAN
A WLAN (wireless local area network) links
devices via a wireless distribution method (typically
spread- spectrum or OFDM radio), and usually
provides a connection through an access point to the
wider internet. This gives users the mobility to move
around within a local coverage area and still be
connected to the network
Enable WLAN / Disable WLAN
You can set the WLAN status of connectivity.
WLAN status
Here you can see the status of the connectivity. If
the WIFI is on, you can see the mac address, and
once connected to the network, you can check the
related information.
Search for networks
Search the networks, and connect to the network. If
the network is for free, you can surf the net free, if
not, you need to input the password.
Access point settings
Here you can add a new WLAN network address.
Input the related information and save them, and
70
User Manual
then you can be linked to the net automatically in
future.
After you set the WLAN, go to the service, choose
the Internet service, and the set the profiles and the
data accounts as the WLAN.
Settings
Dual SIM settings
You can in any place and at any time set the
dual-mode mobile phone as the following modes
according to your own demand:
Dual SIM open
Only SIM1 open
Only SIM2 open
Flight mode
Phone Settings
In such menu, you can set phone language,
standby wallpaper, time etc.
Time and Date: With this function, you can
set city, time and date format and the time
of specific place.
Set Home City: You can set
71
User Manual
different cities.
Note: This option must be used together with
auto update of time and date. Auto update of
time and data cannot be conducted unless the
network supports.
Set Time and Date: You can set
the current time and date.
Set Format: You can set the
display format for time and date.
Update with time zone: You can
set it On or Off
Note: If the battery is taken from the mobile
phone or the battery is used up for long time,
when switching on the mobile phone after
reinstalling the battery or charging the battery,
you need to reset the time and date.
Schedule Power on/off: You can set the
time for schedule Power on/off.
Special Note: In the area forbidding using mobile
phone (such as cabinet), you must confirm to
inactivate this function before entering this area
so as to prevent accident.
Language: You can choose the desired
language for phone display.
Display Settings: You can set standby menu
72
User Manual
display as wallpaper, screen saver, power
on display, power off display, whether to
display time and date and owner number
(if set in the phonebook)
Greeting text: You can set the greeting text
displayed on the main screen.
Shortcuts: You can choose here shortcut
functions for various menu options.
Trackball: You can have corresponding
settings on the Up and Down movements of
the trackball.
Auto update of date and time: To set the
mobile phone to automatically update
time and date according to the current
time zone, choose “Activate”. Auto update
of time and date will not affect the alarm
clock, calendar or alarm clock memo
setting time, which will be subject to the
time and date when created. However,
auto update of time and date may make
some set alarm clocks out of date.
Misc. Settings: You can adjust the brightness
and time of LCD backlight.
User Profiles
Your mobile phone is provided with multiple
73
User Manual
profiles so that you can customize some settings
in different cases for different events. Firstly, as
per your personal hobby, have individualized
settings on profile and then activate it. You can
have such profiles as General, Meeting, Outdoor,
Indoor, Headset, Headset and Bluetooth.
The content can be edited at every profiles mode
as following:
Tone Setup: Include Incoming Call, power-on,
power-off, Message Tone and Key Tone.
Volume: Set the volume of Ring and Key
Tone.
Alert type: You can choose any one from
Ring, Vibration, Vibration and Ring ，
Vibration then Ring as the current ring mode.
Ring Type: You can choose any one from
single, repeat and ascending as the current
ring type.
Extra Tone: You can have on/off settings on
Warning Tone, Error Tone, camp on Tone and
Call Connect Tone so as to have
corresponding tone tips.
Answer Mode: You can choose whether to
use any key to answer.
After individualized settings, choose “Activate” in
“Select” to start profiles.
74
User Manual
Note: After the headset is inserted into the
mobile phone, the mobile phone will
automatically change into headset profile.
Unplug the headset to return to the previous
profile.
In standby state, you can press $ key to switch to
vibration profile and again to the previous profile.
Network Settings
Network Selection: You can search the
network again. Select your favorite network and
choose to register the network automatically or
manually.
Preferences: You can set the preferred
registered network for SIM card.
Security Settings
SIM Security Settings
SIM Lock: You can set SIM lock (PIN
code) as on/off. When this option is
chosen, it is necessary to input PIN
code for every insert of the SIM
card.
Fixed Dial: This function needs the
75
User Manual
support of the SIM card and the
network operator. When it is
activated, you can only dial the
phone numbers saved in host fixed
dial list. To activate it, you need to
input host PIN2 code.
Change Password: You can change
the PIN and PIN2 codes for each
SIM.
Phone Lock: You can set it as On or Off. It is
a password of 4-8 digits and the defaulted
one is 1122. You can change it.
Auto Keypad Lock: You can set it as On or
Off. The mobile phone has keypad lock
function. When it lasts certain time, the
keypad will be locked, including such
options as Off, 5s, 30s, 60s and 5 min.
Change Password: You can change the
defaulted phone password “1122” into
4-8-digit number easy to remember. If the
phone lock is activated, when switched on,
the mobile phone will hint “Phone locked”.
To unlock it, you can input the phone lock
password and click OK.
Certificate manager: You can browse the
certificate as the phone guides.
76
User Manual
Privacy firewall: Input the password to
access this function (predefined: “1122”).
From here you can enable/disable the
block for the Phonebook, the Messages
and the Call history.
Connectivity
Conn. Management
It shows the status of the connectivity.
Data account
GSM Data—You can set the number, name DNS
etc.
GPRS—You can set the name, APN, user name,
password, Auth. type, DNS.
Note: For related charging standard and detailed
settings, please consult the local network
service operator. Different network service
providers provide different services.
Consult the local network operator.
Restore Factory Settings
You can restore the factory settings of the
mobile phone. The factory setting password is
1122.
77
User Manual
Sound effect
You can set the sound effect of the audio
effect and the bass enhancement.
Applications
Answering machine
1． Set Auto answer on (Only SIM1, only SIM2
or SIM1 and SIM2)
2． Choose the Storage to Phone or Memory
card.
3． Set the Pickup time as 3 / 5 / 10 / 30
seconds.
4． Set the Record duration as 1 minute / 3
minutes/ 5 minutes/ Unlimited.
5． Choose the Greeting file as Default or From
files.
6． Edit Remote access. This function is to hear
the unread leaving messages from the
other phone, either Telephone or Mobile
phone.
Set the Status On.
Hot key is #
Save all the settings.
Password 1234 (As the phone guides)
78
User Manual
Make sure there is a leaving message in the
mobile A. Dial to the mobile A, press # after
hearing the hints”….Please leave a message after
the DE tone. The message leaving duration is 1
minute.”, and input the password 1234 and # to
receive the leaving messages.
Note: The remote access only support the
function of hearing.
Calculator
The upper direction key for “+” and the
lower direction key for “－”, the left direction
key for "×" and the right direction key for "÷";
Press the clear key to clear the latest inputs
or results digit by digit; press the clear key
long to clear all content or result;
Press “OK” key to obtain the result.
Note: The precision of this calculator is limited
and can be used for simple calculation.
Ebook reader
In standby, choose [Menu/Extras/E-book
Reader]. After e-book is activated, the e-book list
will be displayed. If no e-book, click Options to
have such submenus as Clean Up Bookshelf and
Global Settings.
79
If there are e-books, you can choose one
User Manual
e-book and press Options to have such submenus
as Open E-book, Update, System Preset, Details,
Delete, Delete All, Ranking, Execute System
Preset and Help.
Open E-book: Activate the current e-book
and enter the reading menu.
Clean up bookshelf:
Global settings: You can set Font Style, Font
Size, Scroll By, Auto Scroll, Scroll Speed, Full
Screen, Encoding, alignment and Storage
Priority.
Book info: Display the detailed information
about the current e-book.
Delete: Delete the current e-book.
Delete All files: Delete all e-books.
Sort by: You can have such options as As per
Name, As per Type, As per Time, As per Size
or None to rank e-books.
Apply global settings: You can execute the
options for the preset system.
Help: You can have some operation
instructions. Use key 0 to go to book settings
screen; use key 1 for help; use key 2 to add a
bookmark; use key 3 to go to find screen; use
key 4 to go to jump to screen; use key 5 to go
80
User Manual
to bookmark; use key 6 to find next; use key
7 to toggle the auto scroll; use key 8 to
remove bookmark; use key 9 to toggle full
screen mode.
Currency converter
To save exchange rate, press “OK”, then
choose to set exchange rate. Choose one
exchange rate from the displayed options. After
that, press “OK” to confirm. Then the exchange
rate will be saved in the memory until you enter a
new one to replace it. To convert currency, enter
the sum to be converted, press “OK” and then
choose to local currency or foreign currency.
Stopwatch
Choose the function as the phone guide to
use the stopwatch.
You can choose Typical stopwatch and nway
stopwatch as the phone guides.
Fun & Games
Java
To access the feature, choose Menu > Fun and
games > Java, and a list of applications which
have been installed will be displayed. To run an
81
User Manual
application, simply select it and click OK.
You should set the parameters required to run
the application as most of Java application will
access the network. As such, you need to set the
parameters correctly based on the SIM card you
are using. To set the parameters, you are kindly
go to Menu > Services > Data account > GPRS.
Please consult to the operator to have the correct
setting.
Java settings
Java audio: you can select 1~7 and off.
Java backlight: on or off.
Java vibration: on or off.
Select SIM: SIM1 or SIM2.
Java SIM profile: select the profile you
want.
Heap size: default size is 2097152 bytes
Java default security
It contains third party, untrusted domain,
restore settings and domain options.
Games
This mobile phone provides the inbuilt game
Enigma. Please refer to the operation instructions
attached to the games.
82
User Manual
Game settings
BGM: On or off background audio.
Sound effect: On or off audio.
Vibration: On or off Vibration
Volume: Up and Low Volume
File manager
You can manage photos, MP3 and folders.
[Phone]-- The storage body is phone.
[Memory card]-- The storage body is memory
card.
[Open]: You can open Audio, Images, Photos, My
Music and Video folders.
Audio—Audio folder
Play: You can play the selected content.
Use as: You can send audio to Profiles.
Send: You can send the file as MMS, by
e-mail or via Bluetooth.
Details: You can see the date and size of the
file.
Rename: You can rename the folder.
Copy: You can copy the file into Audio,
Images, My Music, Photos, Video or specified
folders.
Move: You can move the file into Images, My
83
User Manual
Music, Photos, Video or specified folders.
Delete: You can delete the current record.
Delete All files: You can delete all records in
all current folders.
Mark several: You can select more files at the
same time.
Sort by: You can rank files as per name, type,
time and size or choose “None”.
Ebook - Ebook folder: see Ebook reader.
Images—Images Folder
View: You can see the current image.
Edit: You can enter photo artist and edit the
desired image.
Use as: You can use images as wallpaper,
screen saver, Switch-on Cartoon, Switch-off
Cartoon, Caller picture.
Send: You can send the file as MMS, by
e-mail or via Bluetooth.
Details: You can see the date and size of the
file.
Rename: You can rename the folder.
Copy: You can copy the file into Audio,
Images, My Music, Photos, Video or specified
folders.
84
User Manual
Move: You can move the file into Audio, My
Music, Images, Photos, Video or specified
folders.
Delete: You can delete the current record.
Delete All files: You can delete all records in
all current folders.
Mark several: You can select more files at the
same time.
Sort by: You can rank files as per name, type,
time and size or choose “None”.
My Music—MP3 Folder
Play: You can play the current MP3.
Use as: You can send music to Profiles.
Send: You can send the file as MMS, by
e-mail or via Bluetooth.
Details: You can see the date and size of the
file.
Rename: You can rename the folder.
Copy: You can copy the file into Audio,
Images, Photos, Video r specified folders.
Move: You can move the file into Audio,
Images, Photos, Video or specified folders.
Delete: You can delete the current record.
Delete All files: You can delete all records in
all current folders.
85
User Manual
Mark several: You can select more files at the
same time.
Sort by: You can rank files as per name, type,
time and size or choose “None”.
Photos—Photo Folder
View: You can see the current photo.
Edit: You can enter photo artist and edit the
desired photo.
Use as: You can use Photos as wallpaper,
screen saver, Switch-on Cartoon, Switch-off
Cartoon, Caller picture.
Send: You can send the file as MMS, by
e-mail or via Bluetooth.
Details: You can see the date and size of the
file.
Rename: You can rename the folder.
Copy: You can copy the file into Audio,
Images, My Music, Photos, Video or specified
folders.
Move: You can move the file into Audio, My
Music, Images, Video or specified folders.
Delete: You can delete the current record.
Delete All files: You can delete all records in
all current folders.
Mark several: You can select more files at the
86
User Manual
same time.
Sort by: You can rank files as per name, type,
time and size or choose “None”.
Video—Video Folder
Play: You can play the current video.
Send: You can send the file as MMS, by
e-mail or via Bluetooth.
Details: You can see the date and size of the
file.
Rename: You can rename the folder.
Copy: You can copy the file into Audio,
Images, My Music, Photos, Video or specified
folders.
Move: You can move the file into Audio,
Images, My Music, Photos or specified
folders.
Delete: You can delete the current record.
Delete All files: You can delete all records in
all current folders.
Mark several: You can select more files at the
same time.
Sort by: You can rank files as per name, type,
time and size or choose “None”.
Create Folder: Under the root directory, you can
87
create a new folder to save more detailed files.
Format: Formatting can clear all files in the
mobile phone and on the memory card. After
formatting, you need to restart the mobile phone
and the Audio folder and Images folder will
restore automatically and Photos folder will
automatically occur after the first photo is taken.
Details: You can check the free space available.
User Manual
Servizi
With this function, you can access multiple
services on the Internet. These services include
weather report, news and financial and economic
information etc. This function is provided by the
network supplier. According to the services the
SIM card provides, there will be new menu
options occurring. If the SIM card and network do
not support this function, it will be inactive. For
more details, please contact the network
provider.
Opera Mini
This application is a web browser, that you can
possible open a website through your phone. Just
88
User Manual
put a website address and press OK to visit the
website.
For further information, you can get it in
http://www.opera.com.
Internet service
Homepage-- Start the website chosen in the
connection settings file.
Bookmarks—Yahoo is the default bookmark.
Enter the options menu and have the following
operations on the bookmark:
Go to: Log into the chosen website.
Edit: Edit the chosen bookmark
name and website.
Send: Send the bookmark as text
message, multimedia message or
email.
Delete: Delete the chosen
bookmark.
Delete all: Delete all bookmarks.
Add bookmark: Add new
bookmarks.
Recent pages: Record the latest 10 web pages
browsed.
Offline pages: You can view these pages when
89
User Manual
you offline.
Input address: Input the website to be logged
in.
Service Inbox: The mobile phone can receive
the service information (“Recommended”
information) sent by the service provider. For
example, the service information can be the
notice of related news headlines, which can
include one piece of news or a service website.
Settings:
Select SIM: Always ask/SIM1/SIM2
Edit account: By this function you can edit
the account.
Browser options-- You set whether to
display images during waiting time and
when browsing WebPages.
Service message settings-- You can choose
ON or OFF to enable the push or not and
you can choose the disable or always in
the Trust settings. Set SL settings functions
as follow: Never, confirm, without confirm.
Add new trust list including: number, IP
address, Domain name.
Clear cache-- You can clear cache. When
the data of the cache are excessive,
network surfing speed can be affected.
90
User Manual
Clear cookies-- You can clear personal data.
Trusted certificates--Entrust.net WAP CA
©1999 Limited liability. See
www.entrust.net/wapcps; US VeriSign, Inc.
Class 3 Public, primary certification
authority.
Licence Manager
Licence list – You can view here the list of
the downloaded licences.
Status – You can check version and time of
each licence.
Advanced – You can check the available
space before downloading, and remove the
oldest licences.
7. Coffer Function
You can access the Coffer function only
aftyer entering the password from the standby
interface.
All call history, SMS etc produced by the
contacts saved in the coffer will be saved in the
coffer and no hint is left out of the coffer. When
91
the coffer receives SMS, there will be SMS
User Manual
envelope hint and message alert tone rather than
message alert menu occurring in the standby
menu
The characteristics of the phonebook, SMS
and MMS etc in the coffer not mentioned are the
same as those out of the coffer.
Enter the coffer:
In the standby interface, input “*”, coffer
password (initial value is 0000, able to be
modified) and then “#” to enter the coffer.
Coffer phonebook
The coffer phonebook supports 10 private
contacts.
Browse
You call see all contacts on the phonebook.
Press the left softkey to enter the option menu of
a contact and then you can have such operations
as Send, View, Edit, Delete, Delete All and Save
etc. Saving is to move the contact into the
phonebook out of the coffer.
Press the dial key to dial a call. If the contact
has false name or false phone number, then
screen will display false name or number and the
call history this time can be saved in the coffer.
Add Calls
In this interface, you can add name, number,
false name or false number.
92
Note: For outgoing calls, incoming calls or SMS
User Manual
reception, if one contact sets false name and
number, then the false name will be displayed; if
not, “Unknown contact” will be displayed.
Settings
View Capacity: You can view the use status in
the coffer phonebook. The display format is
“Used space/Total space”.
Delete All: You can clear the coffer phonebook.
Coffer SMS
Create SMS
You can create new SMS in this menu of
1,224 English characters.
Inbox
The inbox supports 20pcs SMS. You can see
the received SMS in the inbox.
Reply: You can have a text message reply
to the received SMS.
Edit: You can edit the current SMS and
send it after editing.
Delete: You can delete the current SMS.
Delete All: You can delete all SMS not
locked in the inbox.
Note: In the coffer, to choose the contacts for
SMS sending, you can see only the phonebook
contacts in the coffer.
Tip: When the inbox is full, the new messages will
93
automatically cover the earliest messages.
User Manual
Outbox
The outbox supports 10 SMS. If choosing
“Save and Send” to send SMS, you can SMS will
be saved into the coffer outbox. And you can
have such operations as Edit, Send, Delete,
Delete All on the SMS saved in the outbox.
Draftbox
The Coffer SMS Tone Mode lets you
enable/disable the tone for the Coffer SMS.
Coffer Call Log
It can record the missed calls, received calls
and dialed calls related to the contacts in the
coffer phonebook. Its capacity is 30 records. In
the register list, press the dial key to dial a call.
Tip: When the mobile phone displays the alert
message of the missed calls, press “Read” to
enter the missed call list directly. It is possible to
display false name or number. If false alert
message occurs, press “Read” to display a blank.
Change Coffer Lock
You can change the password, which can be
of 4-8 digits, into the coffer.
Note: You must remember the coffer password in
mind; otherwise, you will be unable to access the
coffer and all data cannot be restored.
94
T9 software has set the bar for mobile
usability, creating mobile user experiences
that help drive consumer demand for and use
of mobile communications devices and
services. The T9 portfolio now includes XT9
Smart Input: a first of its kind multi-modal
user interface solution for feature-rich
smartphones and advanced mobile devices.
This pioneering user interface is designed to
enable users to easily switch between input
modes, as well as alternate between
numbers, letters, symbols and languages,
Block Incoming Call
To enable/disable a block for all the calls coming
from the contacts in the Coffer.
Password Remind
You can save here your numbers for
personal accounts, passwords, ATM, etc..
Five storage positions are available.
User Manual
8. Editor Operation
Overview
95
User Manual
making it faster and easier to input text.
The following the main innovations introduced
into XT9 software:
- Form Factor Versatility:
XT9 software is a powerful text entry
solution that works on a wide variety of form
factors. This includes traditional 12-key
phone keypad, hard and soft QWERTY
keyboard, half-QWERTY keyboard and
handwriting.
- Mode transitions:
XT9 software makes it easy to switch
between input modes on devices that have
more than one way of entering text. For
example, XT9 will support a device with both
traditional 12-key input and a touchscreen.
Users have access to XT9 in all modes on the
device, making it faster and easier to input
text regardless of how they enter it.
Switching between numbers, letters and
symbols is also easy. And XT9 supports
auto-accenting of words, a plus for typing in
many European languages, like French,
Spanish and Italian.
- Regional error correction
Typing on the little QWERTY keyboard found
on most mobile devices, it's easy to hit a
96
wrong key. XT9 compensates for the
User Manual
challenge presented to big fingers by tiny
keys. For example, if you inadvertently type
in "m-o-o-b," XT9 presents "moon" because
the "b" is just one key away from the "n,"
and the word "moon" is a more likely choice.
- Extensive Language Support
An expert linguistics team, native language
speakers, and other researchers participate
in carefully constructing and testing T9
language databases. New language
databases are continually in development to
make T9 products available to as many
people as possible worldwide. XT9 Smart
Input is available in over 60 languages: in this
device we choose English, Italian, French,
Spain and German.
Settings
The write method settings allow the user
what aid to enable and can
configure XT9 in general directly from the
Options menu of the message end user is
writing. It will be possible to access to
the Preferences menu and suggested settings.
In the first, you can select one of the
the following options:
97
User Manual
The second one allows to determine the
level of automatic correction of the text and after
how
many keystrokes to enter the auto-complete func
tion of the word.
98
User Manual
Input text XT9
Writing language menu you
can select the languages you want the
support of the dictionary when entering text.
From the Preferences menu you
can choose different settings for text entry such
as:
- Shift automatic: automatically capitalize the fi
rst letter of a new sentence
- Automatic Punctuation:
Press the spacing twice at the end of
a word for a dot
- Automatic Reselection: Shows the list
again for selecting a word previously entered.
From the Setup menu suggestions, you can
choose the following options:
- Auto correction: automatically corrects typing
errors and spelling (High, Low and Off)
- Completion of the word sets the number of
times a button is pressed before displaying
the completion of words (can be
activated after entering
99
the key from one to 6 times)
User Manual
Text input
The XT9 IME for Android supports ambiguous
and explicit text entry. For all alphabetic
languages, both methods are available.
The keyboard layouts share common keys that
make it easy for the user to get to access
languages, numbers, symbols, input methods, etc.
The diagram below displays most of these keys:
When selected as the XT9 input method, a
horizontal bar appears on top of the keyboard
where the suggestions are displayed in the
sequence of key presses.
The visible selection list is a feature of the XT9
IME where words appear in a horizontal list
above the keyboard. As the user enters
characters, the XT9 IME examines available
databases for words that best match the input.
100
Loading...
