NEXTBOOK Premium 7 SE User Manual [fr]

Page 1

Safety Precautions

 Do not subject the device to severe impact or drop it from heights.  Do not use the device in extreme hot or cold, dusty or damp conditions. Do not

expose it to direct sunlight.

 Avoid using the device near strong magnetic fields.  Normal functioning of the product may be disturbed by ESD. If so, simply reset

and restart the device following the instruction manual. During file transmission, please handle with care and operate in a static-free environment.

 Keep the device away from water and other liquids. In the event that water or

other liquids enter the device, power off the product immediately and clean the device.

 Do not use chemicals to clean the device in order to avoid corrosion. Clean it

with a dry cloth.

 Do not install this equipment in a confined space such as a book case or similar

unit. The ventilation should not be impeded by covering the ventilation openings with items such as newspaper, table-cloths, curtains etc.

 No naked flame sources, such as lighted candles, should be placed on the

apparatus.

 Attention should be drawn to environmental aspects of battery disposal.  Use the apparatus in moderate climates.  We are not responsible for damage or lost data caused by malfunction, misuse,

modification of the device or battery replacement.

 Do not attempt to disassemble, repair or modify the product. This will invalidate

the warranty.

 If the device will not be used for an extended period of time, please charge the

battery at least once per month to maintain battery life.

 Charge the battery if:

a) The battery level icon displays (An empty battery) b) The device powers off automatically when restarted. c) There is no response when pressing keys with keys unlocked and battery full.

 Do not interrupt the connection when the device is being formatted or

transferring files. Otherwise, data may be corrupted or lost.

 When the device is used as a portable HD, please use only per the instructions.

Otherwise, permanent data loss could occur.

 Please use and install data using the attachments/accessories provided and only

according to the manufacturer’s instruction.

 Please refer to the information on the bottom of the device for electrical and

safety information before installing data or operating the device.

 To reduce the risk of fire or electric shock, do not expose this device to rain or

moisture. The device should not be exposed to dripping or splashing. Never place objects filled with liquids, such as vases, on the device.

 There is danger of explosion if the battery is replaced incorrectly. Replace only

with the same or equivalent type.

Page 2

The battery (battery or batteries or battery pack) should not be exposed to



excessive heat such as sunlight, fire or the like.

 Please follow responsible procedures for battery disposal.  If the power adaptor disconnected from the device, the device will remain

operable as long as the battery has sufficient charge.

 The power adaptor is a CLASS II apparatus with double insulation, and no

external ground is provided.

 Safety symbol explanation:

- The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock.

- To reduce the risk of electric shock, do not remove the cover (or back) as there are no user-serviceable parts inside. Refer servicing to qualified personnel.

- The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance instructions in the literature accompanying the device.

- Correct Disposal of this product. This marking indicates that this product should not be disposed of with other household waste in the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To dispose of your used device, please use the return and collection systems available in your area or contact the retailer where the product was purchased. They can take this product for safe environmental recycling.

 This equipment should be installed and operated with minimum distance 20cm

between the radiator & your body.

 CE in which countries where the product may be used freely: Germany, UK, Italy,

Spain, Belgium, Netherlands, Portugal, Greece, Ireland, Denmark, Luxembourg, Austria, Finland, Sweden, Norway and Iceland. In France, except the channel 10 through 13, law prohibits the use of other channels.

Page 3

Listening Cautions

 This product respects the current regulations for limiting the output volume of

consumer audio devices to a safe level. By listening to your device with headphones or earbuds at high volumes, you run the risk of permanent damage to your ears. Even if you get used to listening at high volumes and it seems normal to you, you still risk the possibility of damaging your hearing. Reduce the volume of your device to a reasonable level to avoid permanent hearing damage. If you hear ringing in your ears, reduce the volume or shut off your device. This device has been tested with the supplied earphones. In order to preserve your hearing, it is advised that you use only the following headphone models: the earphones supplied with your device, or any other headphones that respect the current regulations. Other types of headphones may produce higher volume levels.（At full power ,the prolonged listening of the walkman can damage the ear of the use）

 Maximum output voltage<=150mv  Do not use while operating a motorized vehicle. It may create a traffic hazard

and is illegal in many areas.

 You should use extreme caution or temporarily discontinue use in potentially

hazardous situations created by obstructed hearing.

 Even if your headphones or earphones are the open-air type designed to let you

hear outside sounds, don’t turn up the volume so high that you can’t hear what’s around you.

 Sound can be deceiving. Over time your hearing “comfort level” adapts to higher

volumes of sound. What sounds “normal” can actually be loud and harmful to your hearing. Guard against this by setting the volume of your device at a safe level BEFORE your hearing adapts.

To establish a safe volume level:

a. Start your volume control at a low setting. b. Slowly increase the sound until you can hear it comfortably and clearly,

and without distortion. Once you have established a comfortable sound level, leave it there.

This manual may not reflect your actual device’s operation. All information is subject to change

without prior notification. Please follow your actual device’s operational procedures.

Page 4

Table of Content

Safety Precautions ................................................................................................... 1

Listening Cautions .................................................................................................... 3

Feature Summary .................................................................................................... 5

Accessories ............................................................................................................. 5

Buttons & Ports ........................................................................................................ 5

Charging Battery ...................................................................................................... 6

Transferring Files from Computer ............................................................................. 6

Turning On the Unit .................................................................................................. 6

Home Screen ........................................................................................................... 7

Unlocking the Screen ............................................................................................... 8

Tips on touching screen ........................................................................................... 8

Accessing Internet .................................................................................................... 9

Reading E-Books ................................................................................................... 10

Playing Music ......................................................................................................... 13

Playing Video ......................................................................................................... 14

Viewing Photos ...................................................................................................... 15

Using the Camcorder/Camera ................................................................................ 16

Exploring Files ....................................................................................................... 16

Sending/Receiving E-mails ..................................................................................... 19

HDMI Output .................................................................................................... 21

Managing 3rd Party Applications ............................................................................. 21

Close Recent Applications ...................................................................................... 22

Managing Tasks ..................................................................................................... 22

Troubleshooting ..................................................................................................... 23

Specifications ......................................................................................................... 23

FCC Statement ...................................................................................................... 24

Page 5

g. Camera lens

it freezes.

Feature Summary

Wi-Fi Connectivity

With the latest Wi-Fi technology, this device can connect you to the Internet wherever you are.

7.0” Touch Screen

Touch or slide your finger on the screen, the screen responds instantly.

Third-party Application Support

With the built-in Android applications in this device.

Built-in Camera Lens

Equipped with the built-in camera lens, this unit can function as a webcam or video recorder.

Built-in G-sensor

The screen changes to landscape or portrait automatically when the device rotates.

Entertainment

You can enjoy music, movies, pictures and e-books with the device.

OS, you can install a large number of third-party

Accessories

 Main Unit ● USB cable ● AC Adaptor  User Manual ● Warranty Card ● Pouch

Buttons & Ports

a. VOL- - turn down the volume b. VOL+ - turn up the volume c. Power button – press and hold to

power on or off the unit; briefly press to turn on or off the screen.

d. Earphone Port – connect to stereo

earphones.

e. Built-in speakers f. Touch screen

h. Micro USB Port – connect to

computer, USB disk, keyboard or mouse through USB cable.

i. HDMI interface j. POWER-IN port - connect to

power supply through DC adaptor k. Micro SD card slot l. Reset pin hole/Built-in

microphone – reset your device if

Page 6

Charging Battery

The device has a built-in rechargeable battery. No extra battery installation is required. Just charge the device when it indicates low battery. To charge the battery, connect the device to any standard wall outlet via the DC-IN port using the power adaptor. It takes about 3 hours to fully charge the battery. When the battery is fully charged, the charge indicator should light up in orange. During charging, the indicator lights up in red.

Note: a. You are strongly recommended to charge the battery immediately when the device indicates the

battery is lower than 15%!

b. You can operate the device even when it is being charged. But for extended battery life, it is suggested

NOT to use the device when it is charging. c. It is recommended to charge the battery before you use the device for the first time. d. For maximum performance, lithium-ion batteries need to be used often. If you don’t use the device

often, be sure to recharge the battery at least once per month.

e. The Micro USB slot cannot be used to charge the unit from the PC.

f. Be sure to use only the dedicated power adaptor provided with the unit for charging.

Transferring Files from Computer

Before reading or playing files, you need to transfer media files from a computer to the device. (1) Connect the device to a computer with the supplied USB cable. (2) Tap “Turn on USB storage” to connect the device to computer. (3) Once connected, two removable disk drives will show on your computer. One

represents the internal memory of the device, and the other represents the

memory card inserted into the device. Now you can copy files from or to these disk

drives just as you would on your hard drive. (4) As you complete file transfer, choose “Turn off USB storage” to disconnect the

device. (5) Remove the device from the computer safely.

The pre-installed applications and Android OS occupy a considerable part of capacity – nearly more than

1GB, it is normal that you see huge difference between available memory space and total capacity.

Turning On the Unit

To turn on the device, press and hold the Power button on the unit until you see the boot-up screen. It may take a few minutes to start up the system, please wait before you proceed.

To turn off the device, press and hold the Power button until you see the option “Power Off”, tap on “Power Off” and then tap on “OK”.

Tip: For the sake of power saving, this device may sleep with the screen display off when there is no touch action for a while (depending on the actual setting of Screen Timeout). Yo u can briefly press the Power button to wake it up.

Page 7

Go to Google Search page

Go to application page

Return

Go to Home

Recently used down

WiFi is on

Tap the circled area to display

Home Screen

Time

screen

applications

Battery level

settings

The extended Home Screen

Slide your finger horizontally on the screen to go to the left or right panel of the extended Home Screen.

Customizing Home Screen Items

 To add a Home Screen item (shortcuts, widgets, folders etc.), you can tap the application

icon to display all applications and then hold your tap on an item until it is placed on home page.

 To move a Home Screen item, hold your finger onto it until it is highlighted, then drag it to

the desired location, and release it.

 To remove a Home Screen item, hold your finger onto it until it is highlighted, drag it to the

recycle bin “Remove” and then release your finger.

Hold

Page 8

Changing the wallpaper

Hold your tap on the Home screen until a menu appear. Tap on “Wallpaper” and then choose a picture as the desktop wallpaper.

Preset Applications

The device has many useful applications pre-installed. You can tap the Application Tab to display them.

Unlocking the Screen

The screen will be locked after the device is idle for a few seconds. You need to unlock the screen by

dragging the lock icon rightwards before you continue to use the device.

Tips on touching screen

 Click: Briefly click on an item can open an application or page.  Drag: When watching a video or listening to music, you can tap on the progress

bar to playback any designated section of the

file. You can drag the cursor of the progress bar

to any other elapsed time point of the file.  Slide finger: In different browsers (File, Music,

Video, Photo, etc.), you can hold your finger on the

screen and then drag up and down to scroll the file

list up and down.

Page 9

 Hold finger: In some browsers (File, Music, Video,

Photo, Web etc.), you may hold your finger on an

item to display options.

 Pinch finger: You can zoom the page by pinching

your finger.

Accessing Internet

This device features built-in Wi-Fi technology so that you can access the internet over Wi-Fi network.

Make WI-FI Connection

To use WiFi, first of all, you need to configure a Wi-Fi network. For such purpose, you need to stay in a Wi-Fi service zone. Whenever it is within the coverage of a WiFi network you have configured, the device will attempt to make a connection.

Before launching an Internet application such as the web browser, you first need to activate the Wi-Fi and configure a Wi-Fi network.

(1)

Tap “ ” in the Home screen.

(2) Slide the WIFI toggle switch to “ON” to turn on WIFI.

(3) Your Tablet will scan automatically for available WiFi networks and display them in

the right panel. The list of available networks shows all the wireless networks in

range of your device. Choose a network from the list and then tap “Connect” to

connect. Some network may be secured with password, enter the password

before connecting. If the connection is successful, the message Connected

to…(WiFi Network Name) will appear under the WIFI Setting.

Note:

a) The available network list is constantly refreshed automatically. b) When the Wi-Fi is enabled, the device will connect automatically to your configured networks

when they are in range. c) If the device detects a network that has never been configured, it will display a notification icon.

Page 10

Launching the Web browser

To launch the Web browser, you tap the Browser icon in the Applications screen.

To display menus, tap .

To enter a new address, tap the address bar and then type in address.

Note: Not all wireless networks offer access to the Internet. Some Wi-Fi networks only link several

computers together, without any Internet connection.

Using the Web Browser

 You can scroll the screen up and down by tapping on the page and dragging it up

or down (be careful not to tap a link until you are ready!).

 To open a link, simply tap it.  To go back to the previous page that you browsed, tap the Back icon .

 To display the available menu items, tap the Menu icon .  To go back directly to the Home screen, tap the Home icon .

Reading E-Books

Read E-books offline

You can read e-books stored in the device. Before reading, you need to transfer or download e-books to the device.

1. Connect the device to computer by USB cable, and then copy e-books from your

computer’s local drive to the device (see “Transferring files” section mentioned

before).

Note: Make sure your e-books are in format of EPUB, TXT, FB2, RTF or PDB.

2. In the Application page, tap “Ebook” to enter the e-book reader mode.

Page 11

3. Slide your finger left and right on the book shelf to browse e-books and then tap an

e-book to start reading immediately.

4. When you are reading a page, you can tap to display a menu and then

choose “ ” to go to the local e-book library.

5. Tap “File tree” to choose e-books stored in the device. Choose “Device” and then

“sdcard” to enter the device’s internal memory (To search for e-books in an

external SD card, select “Memory Card” and then “external_sdcard”). Tap the

e-book that you want to open it.

6. When you are reading the e-book, you can:

 Slide your finger on the screen left and right to page up or down.

(turn over pages)

Page 12

 Tap to display e-book setting menu.

 Tap “ ” to display the table of content.

 Tap “ ” and then “New bookmark” to insert a bookmark on the current page.

To delete a bookmark, hold your finger on the bookmark list until a menu pops up, and then select “delete bookmark” from the menu.

 Tap “ ” to search for e-books in the online library.

Read E-books online

1. Tap “ ” to search for e-books in the online library (make sure the WiFi is turned

on).

2. Input the search criteria and then tap Enter on the keyboard to start searching.

When the result is listed, tap the e-book that you want, and then tap “download” to

download it. After downloading, tap “read local copy” to read it at once.

Page 13

Artist

Album

Songs

Playlists

Playing Music

Tap the Music icon in the application page to launch the music player.

Music Library

You should enter the music library once you start the music player. The Music Library shows your music files sorted by categories (Artist, Album, etc.) if your music files contain these song information tags. If some of your music files do not contain information tags, they will be classified as (Unknown) in the Music Library. When new music is copied to the device, the Music Library will be updated automatically.

 You can drag your finger up and down on the file list to scroll through it.  Tap a song to play.

List music files by artist.

List music files by album.

Now Playing

Shuffle songs

In the library, tap the Menu icon to display options – Play all, Party shuffle and Shuffle all.

Play all – play tracks in normal order.

Party shuffle – shuffle 7-8 songs as a group each time.

Shuffle all – shuffle all songs stored in the device.

Playback Screen

List all music files.

List your favorite songs.

Go to the Now Playing screen.

a. Now Playing List b. Shuffle songs /Not shuffle c. Repeat /Not repeat d. Display lyric e. Artist Name f. Album Name g. Title (holding your tap on the title can search for

information about the track from the Internet.) h. Previous song/Rewind i. Play/Pause j. Next song/Fast Forward k. Progress bar

Page 14

c d e f g h

Playback menu

During playback of a music file, tap on the MENU icon to bring up a context menu:

Library– return to music library menu. Party Shuffle – select Party Shuffle mode Add to playlist – add a song to the playlist. Delete – delete a song. Sound Effects – Set the sound effects for

the music playback.

Playlist

The playlist is a list of songs that you have added manually. To add the current track to a playlist, tap during playback, selelect “Add to playlist”

and then choose a playlist or tap “new” to create a new playlist. To play a playlist, (1) In the Music menu, tap the Playlist icon to display all the playlist. All songs

that you have added are listed.

(2) Tap a song to start playing.

Playing Video

Tap the Video icon in the application page to launch the video player.

Navigate through Video Files

You should see the video list when you enter the video player.  You can drag your finger up and down on the video list to scroll the video list up

and down.

 Tap a video to start playing.

Playback Screen

Note: Some video files may not be played correctly with the device. Refer to the Technical Specifications and make sure the video resolution, encoding format or file type is supported.

a. VOLb. Progress bar c. VOL+ d. Bookmark e. Brightness f. Previous Video/Fast Rewind g. Play/Pause h. Next video/Fast forward i. View Mode j. Exit k. Video settings

Page 15

Delete Bookmark

Delete the video bookmark.

Repeat All –

Help

Get instructions on playing video.

Video Playback Settings

Tap on the icon to display the video settings.

Delete Bookmark and Play from beginning

Delete bookmark and play from beginning.

Play Mode

Return Exit from the menu.

Single – plays the current video and then stops after playing. Repeat One – Repeat the current video.

Repeat all videos.

Viewing Photos

Tap the Gallery icon in the application page to launch the Photo Gallery.

Viewing Photos

(1) Photos should be listed in thumbnail. You can slide your finger on the screen left

or right to browse photos.

(2) Tap a photo thumbnail to view the photo in full screen.

(3) To display the previous/next picture, slide your finger on the screen horizontally.

(4) To zoom in or out the picture, pinch your finger on the picture.

Page 16

Display Menu

When you are viewing the picture, you can tap on the screen or the Menu icon to show a menu.

Using the Camcorder/Camera

Tap the Camera in the application page to launch the Camera.

Zoom

Viewfinder

 To start making video clips, tap on the Start/Stop button to start video

Start/Stop

Settings

VCR mode

Photography mode

recording.

 Tap on the Start/Stop button again to stop video recording or photographing.  The video clip / photo can be previewed in the Preview Window.  To play the video clip that you have made, enter the Video Player, and then tap the

video.

 To view the photo that you have taken, enter the Photo Viewer mode, and then tap

the photo.

Exploring Files

You can explore files and folders with the FileBrowser and Astro application. In the Home Screen, tap the Applications shortcut to display all applications and then tap the Explorer icon or ASTRO to enter the file explorer mode.

Using the FileBrowser

Navigate through Files and Folders

 You can drag your finger up and down to scroll

the file list up and down.

 To open a file or folder, tap the file/folder.  You can go back or forward one level in the

interface by tapping on the Back icon .

 Wherever you are in the interface, you can go back directly to the Home screen by

Page 17

Go to Root Select files

Copy/delete Sort files

Thumbnail/list

tapping .

 Tap the Home icon to go to the root directory.

The Toolbar

Sending/Receiving E-mails

This device has an E-mail application pre-installed. You can send or receive e-mails from the Internet at any time with this device. Make sure you have an Internet connection before using the email service. In the Home Screen, tap the Applications shortcut to display all applications and then tap the Email icon to launch the e-mail application.

Setup Email Account

First you need to setup an E-mail account for receiving or sending emails. (1) Start up the email application by tapping the Email application icon and you are

prompted to setup an account.

(2) Input your email address and login password. You can set the account as default

by selecting the option “Send email from this account by default”. (3) Tap “Manual Setup” to set the email server information. (4) Choose the server type from POP3, IMAP or Exchange for incoming emails. To

know what type of your email server is, you can consult the service provider,

network administrator or search for information in the Internet. (5) Input required information (server, port etc.). You can obtain the information from

the service provider, network administrator or the Internet. (6) Choose the server type for outgoing emails, and input required server information. (7) Click “Next” to continue. Your tablet will check the server settings. When it prompts

you that “Your account is set up, and email is on its way”, your account is set up

successfully. (8) Input your name and then tap on “Done” to finish.

Note: If you have more than one account, every time when you start up the email application, you enter the

default email account.

Manage Accounts

You can setup more than one account and manage these accounts by checking information about the account, adding another account or deleting an account.

Page 20

Refresh

Compose

Compose a new email.

Folders

Accounts

View all email accounts.

Account Settings

Add another Account Following these steps to add another account if you want.

(1) Launch the email application and then tap on the Menu icon to display the

menu item. Choose “Accounts” to display accounts.

(2) Tap on the Menu icon to display the menu item, and then choose “Add

account”. (3) Follow the steps of setting up a Email Account to add an account.

Delete an Email Account

(1) When you are in the email box, tap on the Menu icon to display the menu

items. (2) Tap on “Accounts” to display all email accounts. (3) Hold your tap on the account that you want to delete until a menu pop up.

(4) Tap on “Remove Account”，and then tap on “OK” to confirm.

Check the Account Setting

(1) When you are in the email box, tap on the Menu icon to display the menu

items. (2) Tap on “Accounts” to display all email accounts. (3) Hold your tap on the account that you want to check until a menu pop up.

(4) Tap “Account settings”，and then you should see all setting information about the

account. You can edit these settings as you want.

View Emails

You should enter your mailbox when you start up the email application.

 In the mailbox, you can slide your finger up and down to scroll through the email

list.

 Tap on an email to open it.  Holding your tap on the email can display a menu. With the menu, you can open,

reply, forward or delete the email.

Email Menu Items

In the email list, tap on the Menu icon to display the menu.

Refresh the emails.

Go back to email box.

Check your account settings.

Page 21

HDMI Output

The device features a HDMI interface with which you can connect the device to digital televisions. HDMI connection can deliver high-definition audio and video quality. To use the HDMI function on digital televisions,

(1) Make sure the HDMI under Settings is turned on. (2) Turn on the digital television, and switch its Source mode to HDMI. (3) Connect the device to the digital television through HDMI cable. Once the

(4) Optionally, you can set the image quality with the “HDMI Switch” setting.

Note: HDMI interface is only for HDMI cable. Error may occur if you insert other connectors (for example, USB connector) into the HDMI port.

connection is made, the digital TV shows content synchronized with the device, and then you can enjoy the sharpest image quality on the wide screen of television.

Managing 3rd Party Applications

Your device provides support to many useful third-party applications. You can purchase the applications to add more functions to your device. They are available online at the Internet or directly on your product.

Pre-installed Applications

The device has pre-installed applications when it was manufactured. You can see them by tapping the Applications icon . They are video player, audio player, browser, alarm clock, calculator etc.

Install Applications

You can install applications manually following these steps: (1) Download the installation file directly from the built-in application library (e.g.

Google Play) or Internet. Make sure the file is in format of .apk which is supported

by your Internet Tablet system. (2) Copy the installation file to your Internet Tablet by USB connection. (3) Turn on your Internet Tablet and locate the installation file with the FileBrowser. (4) Once the application is installed successfully, you can find it in the application tab.

Page 22

Uninstall Applications

(1) Tap the Settings shortcut in the Home Screen to

display all system settings. (2) Select “Apps”. (3) Tab on the application that you want to uninstall. (4) Tab on “Uninstall” to uninstall the application.

Note:

 You cannot uninstall the pre-installed applications.  Some of the applications developed for Android mobile might not run properly in the Device. Please

consult the respective software developer for further information.

Close Recent Applications

Your device can remember applications that you used recently. That’s very useful when you want to go back to a window you opened recently. Also, you can close these applications to enhance system performance. (1) Tap to display applications that you used recently.

(2) Hold your tap on the application that you want to stop, and then select “Remove

from list”.

Managing Tasks

Your Internet Tablet can handle multiple tasks at the same time. For example, you can view photos while listening to music. Multitasking is helpful but inefficient if too many tasks are running. In order to save system memory and enhance system performance, you can end some tasks that you don’t use at the moment.

Page 23

(3) Tap “KILL selected apps” to end the task.

Main CPU frequency: 1GHz

DDR

1GB

Hardware

IBM PC or compatible PC, Note-book or Macintosh with USB port

Internal Memory

8GB

Operation System

Windows2000/XP/Vista/windows 7/Linux2.4/ MAC OS 10.6.7 above

Connection Agreement

WiFi (802.11 b/g/n)

G-sensor

Support 360 rotation

File Format

EPUB/TXT/FB2/ RTF

EPUB Format: .Open

TXT / FB2/ RTF Format: .Open

JPEG(Baseline) :8000*8000 pixels (Max.)

BMP: 8000*8000 pixels (Max.)

GIF (Static）: 6000x 4500 pixels (Max. )

PNG: 8000x8000 pixels (Max.)

File Format

MP3/WAV/OGG/FLAC/APE/AAC/

DIVX3/4/H2.63: Max. 720x480p @ 30fps

(1) Tap “Task Killer” application.

(2) Tap the task that you want to end.

Troubleshooting

Reset this device

 In the event that the device freezes, you can force the device to shut down by

holding the Power button for about 8 seconds.

Specifications

Item Description

CPU

Built-in operating system Android OS 4.0

Memory Card type Micro-SD card: up to 32GB (card not provided)

Interface

Based on AML8726-M3 Cortex A9

USB2.0 High speed SD (compatible SDHC)

3.5mm Earphone

E-Book

Photo Format

Audio

Video

Coding Format

MP3 (MPEG1/2/2.5 Audio Layer 1/2/3）: 8～48KHZ/8～320Kbps,CBR and VBR

Coding Format

File Format AVI, 3GP, MP4, RM, RMVB, F LV, MOV, W MV, ASF

Coding Format

WAV (MS-ADPC M, IMA-ADPCM, PCM): 8～48KHZ OGG (Q1- Q10): 8～48KHZ FLAC(Compress Level 0～8): 8～48KHZ APE (Version 3.95,3.97,3.98,3.99,normal and fast) : 8～48KHZ AAC(ADIF, ATDS Header AAC-LC and AAC-HE): 8～48KHZ

AVI

MPEG4 ASP, XVID, DIVX5, H.264,VC-1, WMV3：Max 1920*1080pixels/30FPS

Page 24

Video Codec: H.263,H.264 AVC, MPEG4

1920*1080pixels/30FPS

Video Codec: H.264, MPEG4,WMV3

AC Adapter: AC Input 100-240V～50/60Hz, DC Output 5V/2A

Ambient Temp.

0℃ ～ +40℃

Operation Relative Humidity

20% ～ 90%（40℃）

Video Codec: MPEG4 ASP, XVID, DIVX3/4/5, H.263, H.264,VC-1, WMV3 Audio Codec: MP2, MP3, AC3, AAC, PCM, DTS, AMR-NB, WMA

3GP/MP4

RM/RMV B

FLV

MOV

MKV

MPG/DAT/VOB

WMV/ASF

Battery Charge Time About 4 Hours

Battery Life

Display 7.0-inch TFT LCD, Touchpad (capacitive touch pad), 800X600 pixels. SNR >=75dB Frequency Response Range 20Hz—20KHz

Power Supply

Storage Temp. -20℃ ～ +65℃

About 6 hours of music playback; About 5 hours of video playback; About 5 hours of web browsing.

Rechargeable lithium-ion polymer battery;

1920*1080pixels/30FPS

Audio Codec：AAC, AMR-NB 1280*720pixels/30FPS Video Codec: Real video 8/9/10/ Audio Codec Cook/AAC 1920*1080pixels/30FPS Video Codec: Sorenson H.263, VP8, H.264 AVC Audio Codec：MP3,PCM, AAC 1920*1080pixels/30FPS

Video Codec: H.263, H.264 AVC,MPEG4 Audio Codec: AAC

Audio Codec: MP2/MP3/AC3/AAC/PCM 1920*1080pixels/30FPS Video Codec:MPEG1/2 Audio Codec：MP2/MP3 1920*1080pixels/30FPS Video Codec: WMV3 Audio Codec: WMA2/ 3

Storage Relative Humidity 20% ～ 93%（40℃）

FCC Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

Page 25

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

Caution: Any changes or mod ifications to this d evice not explicitly approved by manufacturer

could void your author ity to operate this equipment.

USA

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause

undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

Canada:

This device complies with Industry Canada licence-exempt RSS standards(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and 2) this device must accept any interference, including interference and that may cause undesired operation of the device.

FCC RF warning statement:

The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

Page 26

Other names of systems and products mentioned in these instructions are usually the registered trademarks or trademarks of the manufacturers who developed the system or product concerned.

™

and ® marks are not used to identify registered trademarks and trademarks in these

The instructions. This manual was correct and complete at the time of printing. However, new specifications and updates can occur at any time without prior notice. No part of this manual may be copied, republished, reproduced, transmitted or distributed in any way without prior written consent of E Fun. Any unauthorized distribution of this manual is expressly forbidden.

E Fun may find it necessary to modify, amend or otherwise change or update this manual. We reserve the right to do this at any time, without any prior notice. All specifications and features are subject to change without notice. All screen shots shown are simulated and may not represent the actual screen on production units sold to consumers.

For instruction manuals, updated drivers or other information, be sure to visit our website at:

www.nextbookusa.com

Or write to us at:

E Fun

136 N. Grand Avenue # 148

West Covina, CA 91791

USA
