Nextar m930 User Manual

DEAR CUSTOMER:

Selecting fine audio equipment such as the unit you have just purchased is only the start
of your musical enjoyment. Now it is time to consider how you can maximize the fun and
excitement your equipment offers.
We hope you get the most out of your equipment by playing it at a safe level.
One that lets the sound come through loud and clear without annoying blare or distortion,
and, more important, without affecting your sensitive hearing.
Sound can be misled. Over time your hearing " comfort level " adapts to higher volumes
of sound. So what sounds " normal " can actually be loud and harmful to your hearing.
Guard against this by setting your equipment at a safe level BEFORE your hearing
adapts.

To establish a safe level:
Start your volume control at the lowest setting , then slowly increase the sound until you
can hear it comfortably and clearly, and without distortion we want you listening for a
lifetime.

Once you have established a comfortable sound level:
Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing damage or loss in the
future. After all, we want you listening for a lifetime.

ABOUT THIS MANUAL
This product features a number of sophisticated functions ensuring superior reception
and
operation. All are designed for the easiest possible use, but many are not
self-explanatory.
This operation manual is intended to help you benefit fully from their potential and to
maximize your listening enjoyment.

We recommend that you familiarize yourself with the functions and their operation by
reading through the manual before you begin using this product. In this operation manual,
the Basic Operation for each sound source is outlined at the beginning of its explanation,
covering simple operation for that source, such as merely playing music.

Remark:
In addition to normal audio CD, this unit can play CD-R and CD-R/W disc that contain
audio tracks as well; however, depending on the conditions of the recording equipment,
recording program or the CD-R as well as CD-R/W disc itself, some CD-R or CD-R/W
may not play.
When making music CD with CD-R or CD-R/W disc, too high recording speed may
result in poor signal quality and therefore, it is recommendable to select 24x or lower
speed for CD-R recording and 4x or lower speed for CD-R/W recording.

E 1

LOCATION AND FUNCTION OF CONTROLS

10

1

2

24

REL

9

3

+

SEL

SCN

6

-

RDM

4

RPT

3

INT

2

TOP

1

5

4

7 8

5

6

COMPACT

DIGITAL AUDIO

A.P

MODE

12 13

1415 16 17 18 19 20

11

EJECT

CLK

ST

BND

LUD

MU

1. REL BUTTON

To remove the front control panel from the main body, press the REL button.

2.3.4. SEL BUTTON (Select) AND V.UP(+)/V.DN(-)BUTTONS

a) Press the SEL button briefly, it is activated as selecting each mode of E. VOL.

-> VOLUME ->BASS ->TREBLE -> BALANCE -> FADER ->
In each mode, the waiting time is about 5 seconds, and the time waiting time is
over, it returns to the last display mode of tuner or CDP mode.
VOLUME CONTROL

1) The volume can be adjusted at any time by pressing the audio level V.UP(+)
or V.DN(-) button as select mode has been initially defaulted at volume mode.

2) The volume can be also obtained by continuously pressing the SEL button
until the character VOL appear on the LCD display, then press the V.UP(+) or
V.DN(-) button to adjust the volume.

BASS CONTROL

1) Press SEL button to select the bass mode until BAS appears on the display.

2) Press the V.UP(+) or V.DN(-) button to adjust the bass.

TREBLE CONTROL

1) Press SEL button to select the treble mode until TRE appears on the display.

2) Press the V.UP(+) or V.DN(-) button to adjust the treble.

BALANCE CONTROL

1) Press SEL button to select the balance mode until BAL appears on the display.

2) Press the V.UP(+) or V.DN(-) button to adjust the left/right speaker balance.

FADER CONTROL

1) Press SEL button to select the balance mode until FAD appears on the display.

2) Press the V.UP(+) or V.DN(-) button to adjust the front/rear speaker balance.

E 2

22

21

23

b) When pressed longer 2 seconds, it is activated as cyclical mode of following

functions for user s selection.

-> BEEP (2nd/ALL/OFF) ->SEEK1/ 2 -> DSP(OFF/POP/ROCK/CLASSIC/
FLAT)-> VOL LAST/VOL ADJ mode.
After selecting the desired mode, press the V.UP(+) or V.DN(-) button shortly
to select one setup item of the desired mode.
BEEP 2ND, BEEP ALL, BEEP OFF MODE
The situation of beep sound is selected. The 3 mode is selected as also V.UP
(+) or V.DN(-) button.

- Beep 2nd mode:
The beep is only generated when an allotted double key is pressed long (1
second).

- Beep all mode:
The beep is generated when every key is pressed.

- Beep off mode:
The beep sound is disabled when a key is pressed.
SEEK 1/SEEK 2 mode:( Only available during radio operation)
SEEK 1: Press and hold the UP(^) or DOWN(v) button to seek up or down for
the strong signal stations. And the seek stops when received a strong
signal station.
SEEK 2: Press and hold the UP(^) or DOWN(v) button to seek up or down for
the strong signal stations. But the seek does not stop when received
a strong signal stations excepting release the UP(^) or DOWN(v)
button.
VOL LAST/VOL ADJ
VOL LAST: The radio switches on at the actual volume it had when it was last
switched off.
VOL ADJ: Pressing the V.UP(+) or V.DN(-) button you can pre-select a
constant switch on volume.

5. POWER ON/OFF
When the unit is power off, the unit comes to ON by pressing any button on the
front panel (except the OPEN key or the EJ key). It also can turn on the unit to
insert a disc into CD slot. When the unit is power on, press and hold the power
button for more than 0.5 seconds, the unit goes into power off mode.

6. LCD (Liquid Crysta l Display)

7. CD SLOT

8. EJECT KEY

In the power on state, the loaded disc can be ejected by pressing the EJ key.

9. 10. TUNE, SEEK, TRACK, SKIP UP) / DOWN BUTTONS
a) During RADIO mode:
Press the UP(^) or DOWN(v) button shortly to manual tune up/down for the
desired radio station frequency with step by step.
Press and hold the UP(^) or DOWN(v)button for longer 0.5 seconds, to auto­ matically tune up/down for the radio station frequency of strong signal.

E 3

b) During CD/MP3 playback mode:
Press theUP(^) button briefly to play next track. Press the DOWN(v) button
once to play the current track from the beginning of the current track.
Press the DOWN(v) button twice continuously to play the previous track.
When the UP(^) or DOWN(v) button is pressed long (more than 1 seconds)
for skip forwards or backwards.

11. BAND BUTTON

Press the BND button briefly to select the radio broadcasting band you would
like to hear. The MW/FM band is toggled cyclically through the tuning bands

->FM 1-> FM 2 -> FM 3 -> MW 1->MW 2 ->.

12. MODE BUTTON

1) When a CD/MP3 disc is existed inside the CD slot, press the MODE button
shortly to change between CD/MP3 and RADIO mode each other.
The LCD display appears radio reception information when you change it
to radio mode; The LCD display appears CD/MP3 playback information when
you change it to CD/MP3 playback mode.

2) When there is no a disc inside the CD slot, the button has not the function of
mode changing.

13. MUTE BUTTON

This button serves to switch the MUTED state on/off.
Press the MUTE button to suppress the loudspeaker temporarily, and press
again to resume listening. The muted state will be also released when the
MODE, BAND, SEL and VOL(+), VOL(-) button on the front panel is pressed.

14. A.P BUTTON (Auto-storage /Preset scan)

During radio mode:

1) when long pressing for more than 1 seconds, the radio searches from the
current frequency and checks the signal strength level until 1 cycle search
is finished. And then 6 strongest stations frequency are preset to the cor­ responding preset memory numbered bank. The auto-storage operation is
implemented in the each selected band. When the auto-storage operation
is finished, the radio execute the Preset Scan

2) when short pressing, the radio searches for each preset station in the
current band. When the field strength level is more than the threshold level
of stop level, the radio is holding at that preset number for 5 seconds with
releasing mute, and than search again.
During MP3 mode:
Press the A.P button short, it is activated as cyclical selecting song mode as
following: -> TRACK SEARCH -> DIRECTORY SEARCH -> THE FIRST
CHARACTER SEARCH ->

1) In TRACK SEARCH selecting song mode, the MP3 T 000 will be visible on
the LCD display and the hundreds digit 0 that the MP3 disc contain will flash.
Press the V.UP(+) or V.DN(-) button to select and enter the number on the
flashing digit place from 1 to 9.
Then press the SEL button to confirm the entered number and the 0 on the
tens digit will be flashing.

E 4

Press the V.UP(+) or V.DN(-) button to select and enter the number on the
flashing digit from 1 to 9.
Then press the SEL button to confirm the entered number and the 0 on the
units place digit will be flashing.
Press the V.UP(+) or V.DN(-) button to select and enter the number on the
flashing digit from 1 to 9.
After finishing enter all the number of the song serial number on the flashing
digit, press the SEL button to play the corresponding track.

2) In DIRECTORY SEARCH selecting song mode, the root folder will be visible
on the LCD will display. (If there is not a root folder in the current MP3 disc,
you will found a root named ROOT.)
Then press the V.UP(+) or V.DN(-) button to select a desired folder.
And then press the UP(^) or DOWN(v) button to select a desired track in the
folder. Finally press the SEL button to play the selected track.

3) In the FIRST CHARACTER SEARCH selecting song mode, the A--......, will

be visible on the LCD display. (If there are files names its first character are

A, the......is the first file name its first character is A by the order of A~Z and

0~9; otherwise, the ......is NONE.)

Press the V.UP(+) or V.DN(-) button to select files that the first character by
the order of A~Z and 0~9.
Then press the UP(^) or DOWN(v) button to select one file its first character
is the selected one. Finally press the SEL button to play the selected file.

15-20. PRESET STATION MEMORY AND TOP/ >||, INT, RPT, RDM BUTTONS

a) During radio mode:
When pressed short, these buttons select a preset station directly.
If the six buttons are pressed for more than 2 seconds, the station
currently being listened to is memorized into the selected preset button.
b) During CD/MP3 mode:
Press the TOP/>|| button briefly to interrupt the playback of the disc.
Press again to resume normal playback of the CD/MP3.
Press the TOP/>|| button and hold for approximately 0.5 seconds to play
the first track of the current disc.
Press the INT button to play the first 10 seconds part of each track.
Press again to stop scan, while the currently selected track will be played.
During MP3 mode, press the INT button and hold for more than 0.5 seconds
to play the first 10 seconds part of each track in current folder.
Press the RPT button to play the current track repeatedly.
Press again to cancel this function.
During MP3 mode, press the RPT button and hold for more than 0.5 seconds
to play the current folder repeatedly. Press again to cancel this function.
Press the RDM button to play all tracks on disc in random order.
Press again to cancel this function.
During MP3 mode, Press the RDM button and hold for more than 0.5 seconds to

play the track in random order in the current folder.
Press again to cancel this function.
c) During the normal playback of CDs in MP3 format:
Press the radio preset button 6 and 5 to move up and down10 tracks at a time.

E 5

21.ST/MO BUTTON

In radio mode, press the ST briefly to select stereo or mono sound mode.

22. CLOCK BUTTON

Press the CLK button briefly to display time for 5 seconds on the display, and
then returns to its previous display unless the button is pressed again.
Then press the CLK button and hold for more than 1 seconds until the real time
flashes on the display.
Then you can adjust HOUR or MINUTE by pressing the V.UP(+) and V.DN(-)
button, respectively.

23. LOUDNESS BUTTON

When press shortly, the LOUD mode is turned on, its to enhance the bass sound
effect when the volume level is low. Press again to cancel the loudness effect.

24. SCAN BUTTON

Press the SCN button to scan the radio frequency. If a valid signal has
detected, the current frequency will be hold and blinked for 5 seconds,
then press SCN again to stop scan and remain the current frequency;
otherwise, the radio will go on to scan the other radio frequency fiver

seconds later.

Note:

1.Make sure use a speaker with 4 ohm load impedance.

2.Do not make the auto antenna wire and ground touch each other

.

E 6
