1.0 Introduction

1.1 Purpose

The purpose of this document is to provide the method syntax of each command to communicate with the CONEX-LDS autocollimator

in assembly Newport.CONEXLDS.CommandInterface.dll. This .Net assembly is designed and developed by Newport. This DLL is used by CONEX-LDS applet to communicate with the CONEX-LDS autocollimator.

exposed

1.2 Overview

Command Interface DLL is a generic name that refers to a DLL used to communicate with an instrument. Typically this DLL exposes all the commands the instrument supports. These commands are exposed as function calls of the Command Interface DLL.

Newport.CONEXLDS.CommandInterface.dll is the assembly used for communicating with the CONEX-LDS autocollimator. This assembly is installed with the CONEX-LDS applet.

Each function name is defined with the command code “AA”.

For more information on each command function, refer to the CONEX-LDS programmer’s manual.

NOTES

1 EDH0333En1022 — 12/18

CONEX-LDS Command Interface Manual

1.3 Location

Newport.CONEXLDS.CommandInterface.dll is located with the following path: \Newport\MotionControl\CONEXLDS\Bin\Newport.CONEXLDS.CommandInterface.dll

1.4 Possible uses of Newport.CONEXLDS.CommandInterface.dll

Newport.CONEXLDS.CommandInterface.dll is used by CONEX-LDS applet for communicating with the CONEX-LDS autocollimator. The same DLL can be used as a reusable software component for creating Python scripts or LabVIEW VIs.

EDH0333En1022 — 12/18 2

CONEX-LDS Command Interface Manual

2.0 Command Interface

2.1 Constructor

CONEXLDS() The constructor is used to create an instance of the CONEX-LDS device.

2.2 Functions

2.2.1 General

• OpenInstrument

Syntax

int OpenInstrument(string strDeviceKey)

string strDeviceKey: the device key is a serial COM port

return: 0 = successful or -1 = failure

Decription

This function allows opening communication with the selected device. If the opening failed, the returned code is -1.

• CloseInstrument

Syntax

int CloseInstrument() return: 0 = successful or -1 = failure

Decription

This function allows closing communication with the selected device. If the closing failed, the returned code is -1.

• GetDevices

Syntax

string[] GetDevices() return: list of strings that contains the accessible COM ports

Decription

This function returns the list of connected devices available to communicate.

3 EDH0333En1022 — 12/18

CONEX-LDS Command Interface Manual

• WriteToInstrument

Syntax

int WriteToInstrument(string command, ref string resp, int stage)

command: Instrument command resp: Response of the command stage: Instrument Stage

return: function error

Decription

This Overridden function Queries or writes the command issued by the user to the instrument.

2.2.2 Commands

CD

Syntax

int CD(int controllerAddress, out string FactoryCalibrationInformation, out string errstring)

controllerAddress: controllerAddress FactoryCalibrationInformation: FactoryCalibrationInformation errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous CD Get command which is used to Get factory calibration information. Refer to the Controller's User’s Manual for further information..

EDH0333En1022 — 12/18 4

CONEX-LDS Command Interface Manual

GP

Syntax

int GP(int controllerAddress, out double PositionX, out double PositionY, out double LaserPower, out string errstring)

controllerAddress: controllerAddress PositionX: PositionX PositionY: PositionY LaserPower: LaserPower errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous GP Get command, which is used to Get positions and power. Refer to the CONEX-LDS User’s Manual for more detailed information on the command..

GX_Get

Syntax

int GX_Get(int controllerAddress, out double GainX, out string errstring)

controllerAddress: controllerAddress GainX: GainX errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous GX Get command which is used to Get gain for analog image of X channel. Refer to the CONEX-LDS User’s Manual for more information on this command

GX_Set

Syntax

int GX_Set(int controllerAddress, double GainX, out string errstring)

controllerAddress: controllerAddress GainX: GainX errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous GX Set command which is used to Set gain for analog image of X channel. Refer to the CONEX-LDS User’s Manual for more information on this command

5 EDH0333En1022 — 12/18

CONEX-LDS Command Interface Manual

GY_Get

Syntax

int GY_Get(int controllerAddress, out double GainY, out string errstring)

controllerAddress: controllerAddress GainY: GainY errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous GY Get command which is used to Get gain for analog image of Y channel. Refer to the CONEX-LDS User’s Manual for more information on this command

GY_Set

Syntax

int GY_Set(int controllerAddress, double GainY, out string errstring)

controllerAddress: controllerAddress GainY: GainY errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous GY Set command which is used to Set gain for analog image of Y channel. Refer to the CONEX-LDS User’s Manual for more information on this command

ID_Get

Syntax

int ID_Get(int controllerAddress, out string ControllerIdentifier, out string errstring)

controllerAddress: controllerAddress ControllerIdentifier: ControllerIdentifier errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous ID Get command which is used to Get controller identifier. Refer to the CONEX-LDS User’s Manual for more information on this command

EDH0333En1022 — 12/18 6

CONEX-LDS Command Interface Manual

ID_Set

Syntax

int ID_Set(int controllerAddress, string ControllerIdentifier, out string errstring)

controllerAddress: controllerAddress ControllerIdentifier: ControllerIdentifier errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous ID Set command which is used to Set controller identifier. Refer to the CONEX-LDS User’s Manual for more information on this command

LB_Get

Syntax

int LB_Get(int controllerAddress, out int LaserState, out string errstring)

controllerAddress: controllerAddress LaserState: LaserState errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous LB Get command which is used to Power ON/ Power OFF the laser. Refer to the CONEX-LDS User’s Manual for more information on this command

LB_Set

Syntax

int LB_Set(int controllerAddress, int LaserState, out string errstring)

controllerAddress: controllerAddress LaserState: LaserState errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous LB Set command which is used to Power ON/ Power OFF the laser. Refer to the CONEX-LDS User’s Manual for more information on this command

7 EDH0333En1022 — 12/18

CONEX-LDS Command Interface Manual

LF_Get

Syntax

int LF_Get(int controllerAddress, out float Frequency, out string errstring)

controllerAddress: controllerAddress Frequency: Frequency errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous LF Get command which is used to Get the low pass filter frequency. Refer to the CONEX-LDS User’s Manual for more information on this command

LF_Set

Syntax

int LF_Set(int controllerAddress, float Frequency, out string errstring)

controllerAddress: controllerAddress Frequency: Frequency errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous LF Set command which is used to Set the low pass filter frequency. Refer to the CONEX-LDS User’s Manual for more information on this command

PW_Get

Syntax

int PW_Get(int controllerAddress, out int ConfigurationState, out string errstring)

controllerAddress: controllerAddress ConfigurationState: ConfigurationState errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous PW Get command which is used to Enter/Leave the CONFIGURATION state. Refer to the CONEX-LDS User’s Manual for more information on this command

EDH0333En1022 — 12/18 8

CONEX-LDS Command Interface Manual

PW_Set

Syntax

int PW_Set(int controllerAddress, int ConfigurationState, out string errstring)

controllerAddress: controllerAddress ConfigurationState: ConfigurationState errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous PW Set command which is used to Enter/Leave the CONFIGURATION state. Refer to the CONEX-LDS User’s Manual for more information on this command

PX_Get

Syntax

int PX_Get(int controllerAddress, out double CalibrationCoefficientX, out string errstring)

controllerAddress: controllerAddress CalibrationCoefficientX: CalibrationCoefficientX errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous PX Get command which is used to Get the calibration value for X channel. Refer to the CONEX-LDS User’s Manual for more information on this command

PX_Set

Syntax

int PX_Set(int controllerAddress, double CalibrationCoefficientX, out string errstring)

controllerAddress: controllerAddress CalibrationCoefficientX: CalibrationCoefficientX errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous PX Set command which is used to Set the calibration value for X channel. Refer to the CONEX-LDS User’s Manual for more information on this command

9 EDH0333En1022 — 12/18

CONEX-LDS Command Interface Manual

PY_Get

Syntax

int PY_Get(int controllerAddress, out double CalibrationCoefficientY, out string errstring)

controllerAddress: controllerAddress CalibrationCoefficientY: CalibrationCoefficientY errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous PY Get command which is used to Get the calibration value for Y channel. Refer to the CONEX-LDS User’s Manual for more information on this command

PY_Set

Syntax

int PY_Set(int controllerAddress, double CalibrationCoefficientY, out string errstring)

controllerAddress: controllerAddress CalibrationCoefficientY: CalibrationCoefficientY errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous PY Set command which is used to Set the calibration value for Y channel. Refer to the CONEX-LDS User’s Manual for more information on this command

RG_Get

Syntax

int RG_Get(int controllerAddress, out int Range, out string errstring)

controllerAddress: controllerAddress Range: Range errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous RG Get command which is used to Get the range value. Refer to the CONEX-LDS User’s Manual for more information on this command

EDH0333En1022 — 12/18 10

CONEX-LDS Command Interface Manual

RG_Set

Syntax

int RG_Set(int controllerAddress, int Range, out string errstring)

controllerAddress: controllerAddress Range: Range errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous RG Set command which is used to Set the range value. Refer to the CONEX-LDS User’s Manual for more information on this command

RS

Syntax

int RS(int controllerAddress, out string errstring)

controllerAddress: controllerAddress errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous RS Set command which is used to Reset the controller. Refer to the CONEX-LDS User’s Manual for more information on this command

RS485

Syntax

int RS485(int controllerAddress, out string errstring)

controllerAddress: controllerAddress errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous RS## Set command which is used to Reset the controller’s address to 1. Refer to the CONEX-LDS User’s Manual for more information on this command

11 EDH0333En1022 — 12/18

CONEX-LDS Command Interface Manual

SA_Get

Syntax

int SA_Get(int controllerAddress, out int Address, out string errstring)

controllerAddress: controllerAddress Address: Address errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous SA Get command which is used to Get the controller’s RS-485 address. Refer to the CONEX-LDS User’s Manual for more information on this command

SA_Set

Syntax

int SA_Set(int controllerAddress, int Address, out string errstring)

controllerAddress: controllerAddress Address: Address errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous SA Set command which is used to Set the controller’s RS-485 address. Refer to the CONEX-LDS User’s Manual for more information on this command

SL_Get

Syntax

int SL_Get(int controllerAddress, out int LowlevelPowerThreshold, out string errstring)

controllerAddress: controllerAddress LowlevelPowerThreshold: LowlevelPowerThreshold errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous SL Get command which is used to Get low level power threshold for valid measurements. Refer to the CONEX-LDS User’s Manual for more information on this command

EDH0333En1022 — 12/18 12

CONEX-LDS Command Interface Manual

SL_Set

Syntax

int SL_Set(int controllerAddress, int LowlevelPowerThreshold, out string errstring)

controllerAddress: controllerAddress LowlevelPowerThreshold: LowlevelPowerThreshold errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous SL Set command which is used to Set low level power threshold for valid measurements. Refer to the CONEX-LDS User’s Manual for more information on this command

SR_Get

Syntax

int SR_Get(int controllerAddress, out int HighlevelPowerThreshold, out string errstring)

controllerAddress: controllerAddress HighlevelPowerThreshold: HighlevelPowerThreshold errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous SR Get command which is used to Get high level power threshold for valid measurements. Refer to the CONEX-LDS User’s Manual for more information on this command

SR_Set

Syntax

int SR_Set(int controllerAddress, int HighlevelPowerThreshold, out string errstring)

controllerAddress: controllerAddress HighlevelPowerThreshold: HighlevelPowerThreshold errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous SR Set command which is used to Set high level power threshold for valid measurements. Refer to the CONEX-LDS User’ s Manual for more information on this command

13 EDH0333En1022 — 12/18

CONEX-LDS Command Interface Manual

SU_Get

Syntax

int SU_Get(int controllerAddress, out string Units, out string errstring)

controllerAddress: controllerAddress Units: Units errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous SU Get command to set the the measurement units. Refer to the CONEX-LDS User’s Manual for more information on this command

SU_Set

Syntax

int SU_Set(int controllerAddress, string Units, out string errstring)

controllerAddress: controllerAddress Units: Units errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous SU Set command to set the the measurement units. Refer to the CONEX-LDS User’s Manual for more information on this command

TB

Syntax

int TB(int controllerAddress, string inError, out string outError, out string errString)

controllerAddress: Address of Controller inError: inError. outError: outError errString: The failure reason

return: 0 in success and -1 on failure

Decription

This function is used to process synchrounous TB Get command which explains the meaning of the error string. Refer to the CONEX-LDS Controller’s manual to get the command description.

EDH0333En1022 — 12/18 14

CONEX-LDS Command Interface Manual

TE

Syntax

int TE(int controllerAddress, out string LastCommandError, out string errstring)

controllerAddress: controllerAddress LastCommandError: LastCommandError errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous TE Get command which is used to Get the last command error. Refer to the CONEX-LDS User’s Manual for more information on this command

TS

Syntax

int TS(int controllerAddress, out string ErrorCode, out string StatusCode, out string errstring)

controllerAddress: controllerAddress ErrorCode: ErrorCode StatusCode: StatusCode errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous TS Get command which is used to Get the positioner error and current controller state. Refer to the CONEX-LDS User’s Manual for more information on this command

VE

Syntax

int VE(int controllerAddress, out string ControllerVersion, out string errstring)

controllerAddress: controllerAddress ControllerVersion: ControllerVersion errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous VE Get command which is used to Get controller revision information. Refer to the CONEX-LDS User’s Manual for more information on this command

15 EDH0333En1022 — 12/18

CONEX-LDS Command Interface Manual

ZT

Syntax

int ZT(int controllerAddress, out List<string> ConfigurationParameters, out string errstring)

controllerAddress: controllerAddress ConfigurationParameters: ConfigurationParameters errString: The failure reason

return: 0 in success and -1 on failure

Description

This function is used to process synchrounous ZT Get command which is used to Get all controller parameters. Refer to the CONEX-LDS User’s Manual for more information on this command

EDH0333En1022 — 12/18 16

CONEX-LDS Command Interface Manual

3.0 Python example

#========================================================================= # Newport Proprietary and Confidential Newport Corporation @2012 # # No part of this file in any format, with or without modification # shall be used, copied or distributed without the express written # consent of Newport Corporation. # # Description: This is a Python Script to access CONEX-LDS library #========================================================================= = # Initialization Start # The script within Initialization Start and Initialization End is needed for # properly initializing Command Interface for Conex-LDS instrument. # The user should copy this code as is and specify correct paths here.

import sys

# Command Interface DLL can be found here.

print "Adding location of Newport.CONEXLDS.CommandInterface.dll to sys.path" sys.path.append(r'C:\Program Files\Newport\MotionControl\CONEX-LDS\Bin')

# The CLR module provide functions for interacting with the underlying # .NET runtime

import clr

# Add reference to assembly and import names from namespace

clr.AddReferenceToFile("Newport.CONEXLDS.CommandInterface.dll") from CommandInterfaceConexLDS import *

import System

#=========================================================================

# Constant

ON = 1 OFF = 0

#************************************************* # Procedure to open communication with instrument. #*************************************************

def CONEXLDS_Open (instrumentKey):

# Create a CONEX-LDS instance

LDS = ConexLDS()

print 'Instrument Key=>', instrumentKey ret = LDS.OpenInstrument(instrumentKey) print 'OpenInstrument => ', ret

return LDS

#************************************************* # Procedure to close communication. #*************************************************

def CONEXLDS_Close(LDS): LDS.CloseInstrument()

#************************************************* # Procedure to get the controller version (VE) #*************************************************

def CONEXLDS_GetControllerVersion (LDS, address, flag):

17 EDH0333En1022 — 12/18

CONEX-LDS Command Interface Manual

result, version, errString = LDS.VE(address) if flag == 1: if result == 0 : print 'CONEX-LDS firmware version => ', version else: print 'VE Error => ',errString return result, version

#************************************************* # Procedure to get the laser status (GP Command) #*************************************************

def CONEXLDS_GetPositionsAndLightLevel (LDS, address, flag):

# Get X, Y positions and light level Using GP Command

result, posX, posY, lightLevel, errString = LDS.GP(address) if flag == 1: if result == 0 : print 'Position X => ', posX print 'Position Y => ', posY print 'Light level => ',lightLevel, "%" else: print 'GP Error => ',errString return result, posX, posY, lightLevel

#************************************************* # Procedure to get the laser status (LB? Command) #*************************************************

def CONEXLDS_GetLaserStatus (LDS, address, flag): result, laserStatus, errString = LDS.LB_Get(address) if flag == 1: if result == 0 : print 'Laser status => ', laserStatus else: print 'LB_Get Error => ',errString return result, laserStatus

#************************************************* # Procedure to set the laser status (LB Command) #*************************************************

def CONEXLDS_SetLaserStatus (LDS, address, laserStatus, flag): result, errString = LDS.LB_Set(address, laserStatus) if flag == 1: if result != 0 : print 'LB_Set Error => ',errString return result

#************************************************* # Main #*************************************************

# Initialization

instrument="COM19" displayFlag = 1 address = 1

# Create a CONEX-LDS interface and open communication.

LDS = CONEXLDS_Open(instrument)

# Get controller revision information

result, version = CONEXLDS_GetControllerVersion(LDS, address, displayFlag)

# Get laser status

result, iLaserStatus = CONEXLDS_GetLaserStatus(LDS, address, displayFlag) if result == 0 :

# If the laser is OFF then turn the laser ON

EDH0333En1022 — 12/18 18

CONEX-LDS Command Interface Manual

# Check and refresh the laser status

if iLaserStatus == OFF: print 'Laser is OFF' result = CONEXLDS_SetLaserStatus(LDS, address, ON, displayFlag) result, iLaserStatus = CONEXLDS_GetLaserStatus(LDS, address, displayFlag)

# Get positions

if iLaserStatus == ON: print 'Laser is ON' # Get X, Y positions and light level returnValue, positionX, positionY, lightLevel = CONEXLDS_GetPositionsAndLightLevel(LDS, address, displayFlag)

# close communication.

CONEXLDS_Close(LDS)

print 'End of script'

19 EDH0333En1022 — 12/18

CONEX-LDS Command Interface Manual

Service Form

Your Local Representative

Tel.: __________________

Fax: ___________________

Name: _________________________________________________ Return authorization #: ____________________________________

Company:_______________________________________________

Address: ________________________________________________ Date: __________________________________________________

Country: ________________________________________________ Phone Number: __________________________________________

P.O. Number: ____________________________________________ Fax Number: ____________________________________________

Item(s) Being Returned: ____________________________________

Model#: ________________________________________________ Serial #: ________________________________________________

Description: ________________________________________________________________________________________________________

Reasons of return of goods (please list any specific problems): ________________________________________________________________

__________________________________________________________________________________________________________________

(Please obtain prior to return of item)

21 EDH0333En1022 — 12/18

e-mail: service@newport.com

Visit Newport Online at:

North America & Asia

Newport Corporation 1791 Deere Ave. Irvine, CA 92606, USA

Sales

Tel.: (800) 222-6440 e-mail: sales@newport.com

Technical Support

Tel.: (800) 222-6440 e-mail: tech@newport.com

Service, RMAs & Returns

Tel.: (800) 222-6440

www.newport.com

Europe

MICRO-CONTROLE Spectra-Physics S.A.S 9, rue du Bois Sauvage 91055 Évry CEDEX France

Sales

Tel.: +33 (0)1.60.91.68.68 e-mail: france@newport.com

Technical Support

e-mail: tech_europe@newport.com

Service & Returns

Tel.: +33 (0)2.38.40.51.55

Newport CONEX-LDS Command Interface Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

1.0 Introduction

1.1 Purpose

1.2 Overview

1.3 Location

1.4 Possible uses of Newport.CONEXLDS.CommandInterface.dll

2.0 Command Interface

2.1 Constructor

2.2 Functions

2.2.1 General

2.2.2 Commands

3.0 Python example

Service Form
