Nevion ETH1000-SFP User Manual

ETH1000-SFP

Gigabit Ethernet Media Converter

User manual

Rev. A

Nevion

Nordre Kullerød 1
3241 Sandefjord
Norway
Tel: [phone]

nevion.com

ETH1000-SFP Rev. A

Nevion Europe
P.O. Box 1020

3204 Sandefjord, Norway
Support phone 1: [phone]
Support phone 2: [phone]

Nevion USA

1600 Emerson Avenue

Oxnard, CA 93033, USA

Toll free North America: [phone]

Outside North America: [phone]

E-mail: [e-mail]

See http://www.nevion.com/support/ for service hours for customer support globally.

Rev.

Repl.

Date

Sign

Change description

A - 2014-09-22

AJM

First version

Nevion Support

Revision history

Current revision of this document is the uppermost in the table below.

nevion.com | 2

ETH1000-SFP Rev. A

Contents

Revision history ........................................................................................................ 2

1 Product overview ................................................................................................... 4

2 Specifications ........................................................................................................ 5

2.1 General ......................................................................................................................... 5

2.2 Optical ports .................................................................................................................. 5

2.3 Ethernet ........................................................................................................................ 5

3 Configuration ......................................................................................................... 6

3.1 DIP control .................................................................................................................... 6

3.2 Multicon Gyda configuration .......................................................................................... 7

4 Connector module ................................................................................................. 9

4.1 Mounting the connector module .................................................................................... 9

4.2 Terminal format support ...............................................................................................10

5 Module status ...................................................................................................... 11

5.1 Front panel – Status monitoring ...................................................................................11

6 Laser safety precautions ..................................................................................... 12

General environmental requirements for Nevion equipment .................................. 13

Product Warranty.................................................................................................... 14

Appendix A Materials declaration and recycling information .................................. 15

A.1 Materials declaration ....................................................................................................15

A.2 Recycling information ...................................................................................................15

nevion.com | 3

ETH1000-SFP Rev. A

Physical
Interface
Ethernet

Optical transmitter

Optical reciver

Microcontroller

Status LED

DIP switch

Optical

output

Optical

input

Remote

control

10/100/1000Mbps

Twisted pair

Ethernet

1 Product overview

The Flashlink ETH1000-SFP is a 10/100/1000Base-T to 1000Base-X media converter
module. The optical part of the card is based on SFP that makes the optical part
exchangeable in field. The module converts a 10/100/1000Mbps Ethernet signal on copper
to 1000Mbps optical on fibre suitable for medium haul applications. The module has one
electrical Ethernet port, and one optical fibre transceiver port (receiver fibre connector and
transmit fibre connector). The speed on the electrical connector is dependent of the DIP
switch setting or Multicon GYDA control. Speed will upon link connection automatically be
set at the highest possible speed. User can independently enable or disable 10Mbps,
100Mbps or 1000Mbps. The fibre link can be used in one or two fibre installations, or occupy
two wavelengths in a WDM, CWDM or DWDM installation.

Figure 1

Figure 2

nevion.com | 4

ETH1000-SFP Rev. A

2 Specifications

2.1 General

Power +5V DC / 2.0W typical with SFP
+5V DC / 0.6W typical without SFP

Control Control system for access to setup and module status with

BITE (Built-In Test Equipment)

Temp. range 0 to +40 °C

2.2 Optical ports

Number of inputs 1
Number of outputs 1
Transmission circuit fiber Single mode 9/125um
Connector SC/UPC, single mode
Optical wavelength ~1260-1620nm
Optical sensitivity See manual for installed SFP
Optical overload See manual for installed SFP
Detector damage threshold See manual for installed SFP
Optical power See manual for installed SFP
Optical wavelength See manual for installed SFP

2.3 Ethernet

10BaseT/100BaseTx/1000BaseT on RJ-45 connectors. Compliant with IEEE 802.3, IEEE

802.3u, IEEE 802.3ab and IEEE 802.3z. Auto speed sensing and MDI/MDI-X.

nevion.com | 5
