TS700
Intruder Alarm Control Panel
Starburst User Operating
Instructions
1A
D
C
B
2
3
7
6
5
4
8 9
0
ENT
ESC
_
~
SILENTZONE OMIT
CHIMENEW CODE 24 Hr OMIT
WALK TESTBELL TESTPart Set
Part Set
PartSet
RESET
1
A
B
C
D
2 3
4 5 6
7
ENT ESC
809
Sett ing th e Syst em
Ent er your pas scode XXXX
then leav e th e pr otec ted area.
Unsetti ng the System
Go di rect ly to the ke ypad and
ente r y our p assc ode X XXX .
Resetti ng
Ent er your pas scode XXXX foll owed
by EN T the n 3. Tele phon e y our a larm
com pany and fo llow their instr uct ions.
!
See Use r Manual
FULLS ET
OPEN
Glossary Of Terms
Bell Test - Afacilityto test the operation oftheexternal bells, strobesand theinternal
sounder.
Chime - An optional facility which allows detectors or door contact devices to
generate a two-tone “chime” if activated whilst the system is unset.
Digicom - (Digital Communicator) A remote signalling device fitted to the system
which will transmit alarm information via the telephone line to the alarm
receiving centre.
Duress - A means of entering a passcode (first two digits of a passcode reversed)
which will generate a “silent” alarm via the remote signalling device (if
fitted) to the alarm receiving centre.
Exit/Entry Route - The route which must be used for entering or leaving the protected
premises when the system is being set or unset.
Entry Time - Apreset time delay toallow the user to enter the protected premises and
access the remote keypad without causing an alarm.
Exit Time - A preset time delay to allow the user to leave the protected premises or
area when the system is being set by the timed exit method.
Exit Terminator - An external push button switch used to complete the setting of the alarm
system.
Full set - State of the system when it is protecting all of the premises.
Final Exit - The doorordetectorthatisused forleaving and enteringthepremises.
Log - A record of system activity (200 events) which is stored in memory.
Master User - The person in overall charge of the system i.e., the person who allocates
the passcodes to all other users.
Night Circuit - Acircuit that armed when the system isfullsetorpartset(if programmed).
Omit - To intentionally exclude the monitoring of one or more detection circuits
when setting the alarm system.
Part Set - The state of the system when it is protecting part of the premises.
Passcode - A unique four digit code number allocated to each user by the master
user which must be entered before the system can be operated.
P.A.(Panic Alarm) - An emergency push button switch used to trigger an alarm. The alarm
signal will also be transmitted to the alarm receiving centre if a remote
signalling device is fitted.
Remote Keypad - A device located away from the main control panel that is used to
operate the alarm system.
Reset - Action required to return the system to its normal state after an alarm.
Tamper Alarm - An alarm caused by the system being physically interfered with.
unset - State ofthesystem when itis notmonitoring the activity ofNight circuits.
Users - Those people allocated a passcode which allows them to operate the
alarm system.
Walk Test - A facility for testing circuits without sounding the external sounder.
24hr Circuit - A circuit that is continuously monitored.
Contents
System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Operating the System
1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2 Full Setting the System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3 Part Setting the System (Users 1 - 9) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
4 Part Setting the System using Part Set codes . . . . . . . . . . . . . . . . . . . . . . . 3
5 setting with Circuits Omitted . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
6 Silent setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
7 Setting and unsetting with a Keyswitch . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
8 Unsetting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
9 Unsetting after an Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
10 Resetting after an Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
User Menus Quick reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
User menus
11 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
12 Bell Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
13 Walk Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
14 Change Passcode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
15 Enable Chime . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
16 Omit 24hr Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
17 User Menu 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
18 View Circuits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
19 Change Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
20 Change Date. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
21 Setup New Users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
22 Configure Chime Circuits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
23 Configure 24hr Omit Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
24 Print System Log. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
25 Configure Part Set Groups. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
26 View System Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Table 1. Log and Display Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Service Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
User Record. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
System Configuration Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Circuit Designation Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
System Overview
The TS700 intruder alarm control system uses state of the art electronics to provide a
comprehensive but flexible protection for both domestic and commercial premises. The
system comprises a number of components linked to a central control unit which is concealed
from view but accessible formaintenance. All system operations arecarried out from one of the
remote keypads (up to four may be connected). Detection devices such as door contacts or
movement sensors are allocated to detection circuits which are identified on the remote
keypad displays. Each alarm installation is specific to the site and its occupier, and may differ
from other TS700 installations. This manual describes in detail all the functions and procedures
available to the user. To avoid unnecessary operating errors please discuss the details of the
system with your installation company before attempting to use it.
1
TS700 Starburst User Operating Instructions
Operating the System
1. Introduction
System operation can only be carried out after entering your
passcode. Up to twelve passcodes can be allocated and they
can only be defined by the “master user” (user 1). Users A, B and
C can only set and unset their respective areas. Entering a
passcode with the first two digits reversed will cause a “Duress
Alarm”. Each key press isacknowledged by thekeypad sounder.
Pressing the [ESC] key takes the user back to the previous step in
the menu. Whenthesystem isnotbeing used thekeypad display
shows the current time. The “ENGINEER ON SITE” message is
displayed after an engineer has left his menu and is cleared the
next time a user passcode is entered.
2. Full Setting the System
Ensure that all monitored areas are secured. Enter your
passcode (users 1 to 9 only) and the display will show
"FUNCTION". After five seconds the display will show how much
time is left before the system is set and the sounder makes a
continuous tone. Leave via the normal exit route and close the
final exit door (pressing the Exit Terminator button if fitted). The
system isfullsetwhen the exit sounder stops, the display will show
"SET" for five seconds then reverts to showing the current time.
WARNING: If an attempt is made to set the system whilst any
circuits are active (such as a door being open), the display will
indicate the circuits that are in fault and the internal sounder
generates an interrupted tone. The fault must be cleared before
the setting procedure can be completed. If the system is set by
‘Timed Exit’ and the fault is still present at the end of the exit time
an internal alarm will be generated. If fitted, the external strobe
light will flash indicating the system has failed to set. To prevent
this alarm simply re-enteryourpasscode before the time expires.
3. Part Setting the System (users 1 To 9)
Ensure that all monitored areas are secured. Enter your
passcode (users 1 to 9 only) and within 5 seconds press [A] or [B]
or [C] (depending upon the part set area required). If the five
seconds is exceeded the system will full set. The display shows
the selected group/area that will be omitted and the sounder
makes a continuous tone. If required leave via the normal exit
route and close the final exit door, (pressing the Exit Terminator
buttoniffitted). The system is part setwhen the exit sounder stops,
the display will alternate between the group/area that is omitted
and the current time.
2
TS700 Starburst User Operating Instructions
22.34
This is the normal display when
the system is set or unset. The
time is displayed and the "dot"
segment flashes
ENGINEER
ON-SITE
Enter user passcode to clear
FUNCTION
User passcode entered
9999
This figure indicates the time to
set in secs. 9999 indicates the
system is being set by Last Exit or
Exit Terminator. Any other figure
is timed exit.
SET
The display will show set for 5
seconds, then revert to only
displaying the time.
FUNCTION
User passcode entered
OMIT A
Omit button [A] is pressed.
BC
SET
The display shows the group
that has been omitted (A).
4. Part Setting using Part Set Codes
Ensure that all monitored areas are secured. Enter your
passcode, the exit sounder will make a continuous tone. If
required leave via the normal exit route and close the final exit
door, (pressing the Exit Terminator button if fitted). The system is
part set when the exit sounder stops, the display will alternate
between thegroup/area which has been armedandthecurrent
time.
5. Setting with Circuits Omitted
It may sometimes be desirable to omit a circuit when full or part
setting the system.
1. Enter your passcode (users 1-9) and press [ within 5
seconds.
2. Press 7 and the display will show the circuit number
followed byits omit status.N =notomittedandY =omitted.
3. Press 0 tochange the status of thecircuit and [ toconfirm
the change. A low tone will indicate that the circuit cannot
be omitted or a high pitch multi-tone indicates that the
change has been accepted. Continue with the next circuit
if required.
4. Press ] toquitto“user menu1"and continue with setting by
pressing 0 for full-set or A orB or C for part-set (see 2 and
3).
6. Silent Setting
The system can be full set or part set silently except for the final
system set sound. Enter your passcode (users 1-9) and for full set
press 8 within 5 seconds. For part set press A or B or C then
press 8 .
Alternatively
Enter your passcode (users 1-9) and press [ within 5 seconds.
Press 8 and the display will show "SILENT -". Enter 0 for silent full
set or A or B or C for silent part set.
7. Setting and Unsetting With a Keyswitch
Operate the keyswitch (or door lock) and leave via the exit route.
The system will be full set or part set when the exit sounder stops.
To unset the system, operate the keyswitch (or lock) again.
3
TS700 Starburst User Operating Instructions
0015
User passcode B entered.
Group/area B will set in 15
seconds.
B
SET
Group/area B is now armed.
USER 1-
“User menu 1" selected.
CCT 01 - N
Circuit 01 will not be omitted.
CCT 01 - Y
Press [0] to change the status.
Circuit 01 will now be omitted.
SILENT -
Press [0] for silent full set or [A] or
[B] or [C] for silent part set.
USER 1 -
“User menu 1" selected.
8. Unsetting
Enter the premises via the normal entry route and go directly to
the keypad. Enter your passcode. The display will show “OPEN”
and then revert to displaying the current time. The sounder will
sound at entry and will stop when the system is unset. If the entry
time is exceeded an internal alarm is generated and the entry
timer is restarted. If at the end of the second entry timer the
system has not been unset a full alarm will occur.
9. Unsetting after an Alarm
Enter the premises via the normal entry route and go directly to
the keypad. Enter yourpasscode. The sounder will sound at entry
and will stop when the passcode isentered. The display will show
the circuit thatcaused the alarm andthesystem must bereset.
10. Resetting after an Alarm
Your system is programmed as EITHER User Reset or Engineer
reset, consult your installation company if you are not sure.
User Reset
1. Enter your passcode.
2. Press ] within 5 seconds.
3. The display will show “OPEN” and then revert to the current
time.
Engineer Reset
1. Enter your passcode.
2. Press ] within 5 seconds.
3. The “CALL ENGINEER” message is displayed and the
engineer must now be called to reset the system.
Remote Reset
1. Enter your passcode followed by [ within 5 seconds.
2. The display will show “USER 1-”.
3. Press 3, the display will show a four digit "seed" code.
4. Telephone your central station or installation company and
quote the “seed” code. They will quote you a four digit
“Reset” code in return.
5. Enter the “Reset” code and press [. A low tone indicates
the “Reset” code was either incorrect or incorrectly entered.
A high tone indicates the code was accepted.
6. Press ] to return to the “OPEN” condition.
4
TS700 Starburst User Operating Instructions
0023
Enter passcode before entry
timer expires.
OPEN
System is now unset (OPEN).
ALARM 03
Circuit Alarm 03.
OPEN
System is now reset.
CALL
ENGINEER
System requires an engineer to
reset or Remote Reset.
USER 1-
“User Menu 1" selected.
8302
The four digit “seed” code.
Note: This code is only an
example.
2843
The four digit “Reset” code
entered.
User Menus Quick Reference
] Return To Open - Abandons “User Menu 1" and returnsthesystem to the unset
(OPEN) condition.
1 Bell Test - Allows the internal sounders, external sounder and strobe to
be tested
2 Walk Test - Allows all detection circuits to be tested without generating
an alarm.
3 Remote Reset - Reset the system by exchange of 4 digit codes.
4 Change Passcode - Change your passcode.
5 Enable Chime - Enable or disable the chime option.
6 Omit 24 Hour Group - Omit a pre-defined group of 24 Hour circuits.
7 Omit Circuits - Select circuits to be omitted before setting the system.
8 Silent set - Select “silent” full set or part set.
0 Full Set - Full set the system.
A Part Set Group A - Part set the system with group A omitted.
B Part Set Group B - Part set the system with group B omitted.
C Part Set Group C - Part set the system with group C omitted.
[ User Menu 2 - Select “User Menu 2" (master user only).
1 View Circuits - View the status of all detection circuits.
2 Change Time - Set the system clock.
3 Change Date - Set the system date.
4 Setup New Users - Setup and delete user passcodes.
5 Change Chime Circuits - Select circuits that will chime.
6 Change 24hr Group - Setup a group of 24hr circuits so that can be omitted.
7 Print System Log - Print the contents of the system log (200 events).
8 Configure Part Set Groups - Configure part set groups A, B & C.
9 View System Log - View the contents of the system log.
] User Menu 1 - Return to “User Menu 1".
+
Options 4, 5, 6, 7, 8 & 9 in "User Menu 2" are only available if programmed by the
installation company.
5
TS700 Starburst User Operating Instructions
11.58
The system is unset, the display shows the
current time. Enter user passcode.
FUNCTION
The display shows “Function”. Press [ within 5
seconds to select “User Menu 1".
USER 1-
“User Menu 1" selected.
USER 2-
“User Menu 2" selected.
User Menus
11. Introduction
In addition to setting and unsetting the system, users 1 - 9 may
carry out other operations. These are selected via two user
menus, “User Menu 1" isavailable tousers 1- 9 and ”User Menu 2"
which is only available to the master user. To access “User Menu
1" enter your passcode and then press [ within 5 seconds.
Pressing] returnstheuser tothepreviouspositioninthe menu.
12. Bell test
This test allows the user to test the bells, sounders and strobes.
1. Ensure that “User Menu 1" is selected.
2. Press 1 to select the Bell Test option.
3. The sounders, bells and strobes will operate sequentially for
9 seconds each.
4. Testing may bestopped by pressing ] oradvanced tonext
test by pressing [.
5. Press ] to return to the “OPEN” condition.
13. Walk Test
This test allows the user to test the function of individual circuits
withoutcreating an alarm.Aseach circuitis activated its number
and status are displayed and the internal sounder generates a
two-tone sound. As more circuits are tested they are added in
turn to a scrolling display showing the status of each tested
circuit.
1. Ensure that “User Menu 1" is selected.
2. Press 2 to select the Walk Test option.
3. Activate circuits in turn by opening doors with contacts and
walking in front of detectors.
4. Checkthedisplay toverify which circuitshave been tested.
5. On completion press ] to quit the Walk Test option.
6. Press ] to return to the “OPEN” condition.
6
TS700 Starburst User Operating Instructions
ON-9
Count down display for Bell Test.
USER 1-
Test completed. “User Menu 1"
selected.
x NONE x
Walk Test selected, but no
circuits have been tested.
CCT 05-A
Circuit 05 is now active
CCT 05-H
Circuit 05 is now healthy
14. Change Passcode
All users can change their own passcode.
1. Ensure that “User Menu 1" is selected.
2. Press 4 to select the Change Passcode option.
3. Enter your new passcode and press [.
4. A high pitched multi-tone indicates that the new passcode
has been accepted. A low tone indicates that the
passcode is already in use and has not been accepted. Try
again with a different number.
5. Press ] to return to the “OPEN” condition.
15. Enable Chime
The enable chime option allows a user to switch the chime
facility on or off. This will only affect circuits that have been
programmed as chime in “User Menu 2" option 5.
1. Ensure that “User Menu 1" is selected.
2. Press 5 to select the Chime option.
3. Press 0 to toggle the Chime ON or OFF.
4. Press [ to accept.
16. Omit 24hr Group
This option allows 24Hour, circuitstobe omitted when the system
is unset so that they will not alarm if activated but will alarm if
tampered with. Only thecircuits programmed bytheengineer or
master user (“User Menu 2" option 6) will be omitted.
1. Ensure that “User Menu 1" is selected.
2. Press 6 to select the 24hr Omit option.
3. The display will show “CIRCUITS OMITTED”.
4. Enter your passcode to reinstate the omitted circuits.
17. User Menu 2 (master user only)
The masteruser may accessthismenu bypressing [ when“User
Menu 1" is selected. Options 4 to 9 are only available to the
master user if programmed by the installation company.
7
TS700 Starburst User Operating Instructions
OFF
The Chime option is off. Press [0]
to change.
ON
The Chime option is on.
CIRCUITS
OMITTED
24hr circuit isolated. Enter
passcode to cancel.
USER 2-
‘User Menu 2’ selected.
----
Waiting for new passcode.
2305
New passcode 2305 entered.
Press [ENT] to accept.
18. View Circuits
This option allows the user to view the status of each detection
circuit. The circuit status conditions are H=Healthy, A=Active,
S=Shorted or T=Tamper.
1. Ensure that “User Menu 2" is selected.
2. Press 1 to select the View Circuits option.
3. Circuit status will be displayed.
4. Select circuits either by entering the number or by pressing
[ to scroll through the circuits.
5. Press ] to leave this option and return to ‘User Menu 2’.
6. Press ] twice to return to the “OPEN” condition.
19. Change Time
The system clock may bechanged using 24hour clock format.
1. Ensure that “User Menu 2" is selected.
2. Press 2 to select the Change Time option.
3. Enter the time in 24 hour notation (e.g., 1805).
4. Press [ to accept.
5. Press ] twice to return to the “OPEN” condition.
20. Change Date
The system calendar may be changed by entering the date as
four digits representing the day and month e.g., 0207 is the 2nd
July.
1. Ensure that “User Menu 2" is selected.
2. Press 3 to select the Change Date option.
3. Enter the date as four digits.
4. Press [ to accept.
5. Press ] twice to return to the “OPEN” condition.
21. Setup New Users
Up to 12 users can be allocated to operate the alarm system.
The master user (user 1) can change all user passcodes. If a
passcode is entered with the first two digits reversed, a “Duress
Alarm” is generated. If this facility is not required ensure that the
1st and 2nd digits are the same, (e.g., 1123). If a passcode is
entered with the last two digits reversed, the “Access Control”
outputisoperated. Ifthisfacility isnot requiredensure that the 3rd
and 4th digits are the same, (e.g., 1233).
1. Ensure that “User Menu 2" is selected.
8
TS700 Starburst User Operating Instructions
----
Waiting for date entry.
0207
Date entered (02 July)
----
Waiting for time entry.
1805
Time entered 1805 (6:05 pm)
CCT 03-H
Circuit 03 is Healthy
CCT 03-A
Circuit 03 is Active.
2. Press 4 to select the Setup New Users option.
3. Enter the user number (1 to 9 or A,B,C).
4. Enter the new passcode then press [ to accept.
5. A high tone will indicate acceptance. A low tone sound will
indicate that the passcode is already in use.
6. Press ] twice to return to the “OPEN” condition.
To delete a user passcode from the system, select the user
number you wish to delete at step 3, then enter your own
passcode (master user) at step 4.
Passcode Types
Master User Code (1)
-
This passcode allows setting and unsetting of the system and
allows entry to both user menus.
Standard User Codes (2-7)
-
These passcodes allow setting and unsetting of the system and
entry to “User Menu 1".
Cleaner Code (8)
-
This passcode allows only setting of the system and entry to “User
Menu 1".
Holiday Code (9)
- This passcode allows setting and unsetting of the system and
allows entry to “User Menu 1". The code is erased from the system
when the master user code is next used to unset the system.
Part Set Code A (A)
- This passcode allows the setting and unsetting of group A.
Part Set Code B (B)
- This passcode allows the setting and unsetting of group B.
Part Set Code C (C)
- This passcode allows the setting and unsetting of group C.
22. Configure Chime Circuits
This option is used to select the circuits that will chime.
1. Ensure that “User Menu 2" is selected.
2. Press 5 to select the Chime Circuits option.
3. Circuits will be displayed as Y to chime or N not to chime.
Change status by pressing 0 (“toggle” action).
4. Press [ to accept (high tone)and go tonext circuit. Circuits
may be selected by number. Press ] to quit.
5. Press ] twice to return to the “OPEN” condition.
23. Configure 24hr Omit Group
This option allows the master user to select the 24 hour circuits
that will be omitted when the 24 hour omit option is selected in
“User Menu 1" option 6.
1. Ensure that “User Menu 2" is selected.
2. Press 6 to select the 24Hour Omit Group option.
9
TS700 Starburst User Operating Instructions
CCT 01-N
Circuit 01 will not chime. Press
[0] to change.
CCT 01-Y
Circuit 01 will chime. Press [ENT]
to accept.
----
Waiting for new passcode to be
entered.
5750
New passcode 5750 entered.
Press [ENT] to accept.
USER -
Waiting for passcode type [1] [9] or [A] or [B] or [C].
3. Circuits will be displayed as O=Omitted or A=Armed. Press
0 to change (“toggle” action).
4. Press [ to accept (high note) and go to next circuit. A low
tone indicates that the circuit cannot be omitted.
5. Circuits may be selected by number. Press ] to quit.
6. Press ] twice to return to the “OPEN” condition.
24. Print System Log
A printer may be connected to produce a print-out of the last 200 system events.
1. Ensure that “User Menu 2" is selected.
2. Press 7 to select the Print Log option.
3. Enter the number of events to be printed.
4. Press [ to start printing. To stop printing select the menu
againandenter000asthenumberofevents tobeprinted.
5. Press ] twice to return to the “OPEN” condition.
25. Configure Part Set Groups
When the system is part set certain circuits are omitted. This
option allows the master user to select those circuits to be
omitted when part-set A or B or C is selected.
1. Ensure that “User Menu 2" is selected.
2. Press 8 to select the Part Set Groups option.
3. Select the part-set group A or B or C.
4. Circuits will be displayed as O=Omitted or A=Armed. Press
0 to change (“toggle” action).
5. Press [ to accept displayed status (high tone) and go to
next circuit. Circuits may be selected by number.
6. Press ] to go to step 2 and ] again to go back to “User
Menu 2".
7. Press ] twice to return to the “OPEN” condition.
26. View System Log
The time, date and nature of the last 200 events on the system
may be viewed starting with the most recent event.
1. Ensure that “User Menu 2" is selected.
2. Press 9 to select the View Log option.
3. The most recent event will be displayed (see Table 1)
4. Press A to scroll backwards and C to scroll forward.
10
TS700 Starburst User Operating Instructions
ALARM 01
Log event showing ‘Circuit Alarm
01’. Press [A] to scroll back or [C]
to scroll forward. Press [B] to view
time and date.
CCT 01-A
Circuit 01 will remain Armed for
the selected part set group.
Press [0] to change.
CCT 01-O
Circuit 01 will be omitted for the
selected part set group. Press
[ENT] to accept.
---
Enter the number of events to
be printed. Press [ENT] to start.
P. SET -
Enter part set group A, B or C.
CCT 02-A
Circuit 02 will remain Armed .
Press [0] to change.
CCT 02-O
Circuit 02 will be omitted. Press
[ENT] to accept.
5. Press B to show the time of the event (first press), the date
(second press) the time in minutes and seconds (third press)
the event again (fourth press).
6. Press ] to quit.
7. Press ] twice to return to the “OPEN” condition.
ALM SENT
Actionalarm (Alarm output activated)
LID TAMP
Lidtamper,Auxtamper orSAB tamper
ACC'SS xx
Access passcode (user code
**entered with the last two digits
reversed)
SYS OPEN
System open (unset)
DELAY xx
Alarm delayed (the system is part set
and circuit ** was activated)
OMIT REM
Omitted circuits reinstated
AUX xx
Auxiliary alarm from circuit **
PA.ALM xx
PA alarm from circuit **
BATT FLT
Battery Fault
A.C. OFF
Power failure (remote power LED
flashes)
BELL TST
Bell test operated
A.C. ON
Power restored
ALARM xx
Circuit alarm from circuit **
P.SET x
Part set (area *)
COMS OKcc
Comms successful
C.TMP xx
Code tamper (from remote keypad
**)
COMS FLT
Comms failed
RE-ARME
D
System re-armed
24HR OM'T
Circuits isolated (24 hour circuits)
REM RST
System reset by REMOTE CODE RESET
OMIT'D xx
Circuit ** omitted
R.REM xx
Remote Keypad ** removed or lost
DATE CHG
Date changed
R.TMP xx
Remote Keypad ** case tamper
DEFLT 01
Default user code 1 to 5678
SET FAIL
System failed to set
DUR'SS xx
Duress alarm from user code **
SITE. RST
System on-site reset (LK1 open on
power up)
EN.ALM xx
Entry alarm from circuit **
W.SET x
Area * set using part set codes
ENTRY xx
Entry from circuit **
KEY.SW xx
Part set keyswitch ** operated
FIRE xx
Fire alarm from circuit **
TAMP'R xx
Tamper alarm from circuit **
FUSE 01
Auxiliary fuse blown
TIME CHG
Time changed
FIRST xx
First knock from circuit **
T.FAIL xx
Circuit ** failed test
FACT.RST
Factoryreset(LK1 closed onpower up)
TEST OFF
All circuits on test removed from test
FULL SET
Full set
UNSET x
Area * unset using part set codes
LINE FLT
Telephone line fault
USER xx
User code ** entered
LINE OK
Telephone line restored
NO EVENT
No event
Table 1. Event Log Codes
11
TS700 Starburst User Operating Instructions
Service Record
Date Engineer Action
Installation Company:
Address:
For Service Telephone:
For Remote Reset Telephone:
12
TS700 Starburst User Operating Instructions
User Record
User No. User Type User Name
01 Master
02 Standard
03 Standard
04 Standard
05 Standard
06 Standard
07 Standard
08 Cleaner Code
09 Holiday
10 (A) Part-set A
11 (B) Part-set B
12 (C) Part-set C
System Configuration Record
Entry Time:
Exit Time:
Bell Delay:
Bell Duration:
System Reset By: Engineer
User Remote Reset
13
TS700 Starburst User Operating Instructions
Circuit Designation Record
No. Location Omit Chime A B C
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
18833 Drg No. 33:2159:00 Issue 01. Doc 04. August 98
Loading...
