Netopia 4752 User Manual

Netopia™ 4752 SDSL Integrated Access Device

Administration Guide

This manual and any associated artwork, software, and product designs are copyrighted with all rights reserved. Under the copyright laws such materials may not be copied, in whole or part, without the prior written consent of Netopia, Inc. Under the law, copying includes translation to another language or format.

Netopia, Inc. 2470 Mariner Square Loop Alameda, CA 94501-1010 U.S.A.

Part Number

For additional copies of this electronic manual, order Netopia par t number 6161089-00-01.

CCCCoooonnnntttteeeennnnttttss

Contents iii

Part I: Getting Started

Chapter 1 — Introduction.......................................................... 1-1

Overview ....................................................................... 1-1

Features and Capabilities ............................................... 1-1

How to Use This Guide ................................................... 1-2

Chapter 2 — Setting Up Internet Services .................................2-1

Finding an Internet Service Provider ................................ 2-1

Unique requirements............................................ 2-1

Pricing and support.............................................. 2-2

Endorsements ..................................................... 2-2

Deciding on an ISP Account ............................................ 2-2

Setting up a Netopia 4752 account....................... 2-2

Obtaining an IP address ....................................... 2-2

Obtaining Information from the ISP.................................. 2-3

Local LAN IP address information to obtain............ 2-3

Chapter 3 — Making the Physical Connections.......................... 3-1

Find a Location .............................................................. 3-1

What You Need .............................................................. 3-2

Identify the Connectors and Attach the Cables ................. 3-3

Netopia 4752 Status Lights............................................ 3-4

Chapter 4 — Sharing the Connection......................................... 4-1

Conﬁguring TCP/IP on Windows-based Computers............ 4-2

Dynamic conﬁguration (recommended) .................. 4-2

Static conﬁguration (optional) ............................... 4-3

Conﬁguring TCP/IP on Macintosh Computers ................... 4-5

Dynamic conﬁguration (recommended) .................. 4-5

Static conﬁguration (optional) ............................... 4-6

Chapter 5 — Connecting to Your Local Network.........................5-1

Readying Computers on Your Local Network..................... 5-2

Connecting to an IP and Telephone Network..................... 5-3

iv Administration Guide

Chapter 6 — Console-Based Management ................................. 6-1

Connecting through a Telnet Session............................... 6-2

Conﬁguring Telnet software ................................... 6-2

Connecting a Console Cable to Your Device ..................... 6-3

Navigating through the Console Screens.......................... 6-5

Chapter 7 — Easy Setup ...........................................................7-1

Easy Setup Console Screens .......................................... 7-1

Accessing the Easy Setup console screens............ 7-1

Quick Easy Setup Connection Path.................................. 7-3

SDSL Line Conﬁguration ....................................... 7-5

Voice Easy Setup ................................................. 7-8

Easy Setup Proﬁle................................................ 7-9

IP Easy Setup .................................................... 7-10

Easy Setup Security Conﬁguration ....................... 7-11

Chapter 8 — Voice Conﬁguration...............................................8-1

Introduction................................................................... 8-1

Explanation of terms ............................................ 8-1

Conﬁguring the Voice Features........................................ 8-2

Part II: Advanced Configuration

Chapter 9 — WAN and System Conﬁguration .............................9-1

WAN Conﬁguration ......................................................... 9-2

Multiple ATM Permanent Virtual Circuit Support ............... 9-5

Multiple ATM PVC overview ................................... 9-5

Multiple ATM PVC conﬁguration............................. 9-6

Changing a circuit ................................................ 9-7

Adding a circuit.................................................... 9-9

Monitoring multiple virtual circuits....................... 9-10

Creating a New Connection Proﬁle................................. 9-12

The WAN Default Proﬁle................................................ 9-15

IP Parameters (Default Proﬁle) screen ................. 9-16

Contents v

The ATMP/PPTP Default Proﬁle ..................................... 9-17

System Conﬁguration Screens ..................................... 9-17

Navigating through the System Conﬁguration

screens............................................................. 9-17

System Conﬁguration Features ..................................... 9-18

IP setup ............................................................ 9-19

Filter sets.......................................................... 9-19

IP address serving ............................................. 9-19

Date and time ................................................... 9-19

Console conﬁguration......................................... 9-20

SNMP (Simple Network Management Protocol)..... 9-21

Security............................................................. 9-21

Upgrade feature set ........................................... 9-21

Logging ............................................................. 9-22

Installing the Syslog client .................................. 9-22

Chapter 10 — IP Setup ........................................................... 10-1

IP Setup...................................................................... 10-2

IP subnets......................................................... 10-4

Static routes ..................................................... 10-6

IP Address Serving .................................................... 10-10

IP Address Pools.............................................. 10-13

DHCP NetBIOS Options .................................... 10-15

More Address Ser ving Options.................................... 10-17

Conﬁguring the IP Address Server options ......... 10-18

DHCP Relay Agent...................................................... 10-23

Connection Proﬁles .................................................... 10-25

Chapter 11 — Multiple Network Address Translation ...............11-1

Overview ..................................................................... 11-1

Features ........................................................... 11-1

Supported trafﬁc ............................................... 11-5

MultiNAT Conﬁguration ................................................. 11-6

Easy Setup Proﬁle conﬁguration .......................... 11-6

vi Administration Guide

Server Lists and Dynamic NAT conﬁguration......... 11-6

IP setup ............................................................ 11-7

Modifying map lists.......................................... 11-12

Moving maps................................................... 11-14

Adding Server Lists.................................................... 11-16

Modifying server lists ....................................... 11-19

Deleting a server ............................................. 11-21

Binding Map Lists and Server Lists ............................. 11-22

IP proﬁle parameters........................................ 11-22

IP Parameters (WAN Default Proﬁle) .................. 11-24

NAT Associations....................................................... 11-26

MultiNAT Conﬁguration Example.................................. 11-28

Chapter 12 — Virtual Private Networks (VPNs)........................12-1

Overview ..................................................................... 12-1

About PPTP Tunnels ..................................................... 12-3

PPTP conﬁguration ............................................. 12-4

About IPsec Tunnels..................................................... 12-7

Conﬁguration ..................................................... 12-7

IP Proﬁle Parameters........................................ 12-10

Advanced IP Proﬁle Options .............................. 12-11

Interoperation with other features ..................... 12-12

Encryption Support .......................................... 12-12

ATMP/PPTP Default Answer Proﬁle .............................. 12-13

VPN QuickView .......................................................... 12-14

Dial-Up Networking for VPN ......................................... 12-15

Installing Dial-Up Networking............................. 12-15

Creating a new Dial-Up Networking proﬁle .......... 12-16

Conﬁguring a Dial-Up Networking proﬁle............. 12-17

Installing the VPN Client ............................................. 12-18

Windows 95 VPN installation ............................ 12-18

Windows 98 VPN installation ............................ 12-19

Connecting using Dial-Up Networking................. 12-20

Contents vii

About ATMP Tunnels................................................... 12-20

ATMP conﬁguration .......................................... 12-20

Allowing VPNs through a Firewall ................................. 12-23

PPTP example.................................................. 12-24

ATMP example................................................. 12-27

Chapter 13 — Security ...........................................................13-1

Suggested Security Measures....................................... 13-1

User Accounts ............................................................. 13-1

Telnet Access .............................................................. 13-3

About Filters and Filter Sets.......................................... 13-4

What’s a ﬁlter and what’s a ﬁlter set? ................. 13-4

How ﬁlter sets work ........................................... 13-4

How individual ﬁlters work .................................. 13-6

Design guidelines ............................................ 13-10

Working with IP Filters and Filter Sets.......................... 13-11

Adding a ﬁlter set............................................. 13-12

Viewing ﬁlter sets ............................................ 13-15

Modifying ﬁlter sets.......................................... 13-16

Deleting a ﬁlter set .......................................... 13-16

A sample IP ﬁlter set........................................ 13-16

Firewall Tutorial ......................................................... 13-19

General ﬁrewall terms ...................................... 13-19

Basic IP packet components............................. 13-20

Basic protocol types......................................... 13-20

Firewall design rules ........................................ 13-21

Filter basics..................................................... 13-23

Example ﬁlters................................................. 13-24

LAN IP Filtersets .............................................. 13-27

RADIUS Client Support............................................... 13-30

RADIUS client conﬁguration .............................. 13-30

Warning alerts................................................. 13-32

viii Administration Guide

Chapter 14 — Monitoring Tools ...............................................14-1

Quick View Status Overview.......................................... 14-1

General status................................................... 14-2

Current status ................................................... 14-3

Status lights...................................................... 14-3

Statistics & Logs ......................................................... 14-4

Event Histories ............................................................ 14-4

WAN Event History ............................................. 14-5

Device Event History .......................................... 14-6

Voice Logs................................................................... 14-7

Voice Log .......................................................... 14-7

Voice Accounting Log.......................................... 14-7

IP Routing Table........................................................... 14-9

Served IP Addresses.................................................. 14-10

General Statistics ...................................................... 14-11

System Information.................................................... 14-13

SNMP ....................................................................... 14-13

The SNMP Setup screen................................... 14-14

SNMP traps..................................................... 14-15

Chapter 15 — Utilities and Diagnostics ...................................15-1

Ping ............................................................................ 15-2

Trace Route................................................................. 15-4

Telnet Client ................................................................ 15-5

Disconnect Telnet Console Session............................... 15-6

Factory Defaults .......................................................... 15-6

Transferring Conﬁguration and Firmware Files with TFTP.. 15-7

Updating ﬁrmware .............................................. 15-7

Downloading conﬁguration ﬁles ........................... 15-8

Uploading conﬁguration ﬁles ............................... 15-9

Transferring Conﬁguration and Firmware Files with

XMODEM................................................................... 15-10

Updating ﬁrmware ............................................ 15-10

Contents ix

Downloading conﬁguration ﬁles ......................... 15-11

Uploading conﬁguration ﬁles ............................. 15-12

Restarting the System ............................................... 15-12

Part III: Appendixes

Appendix A — Troubleshooting.................................................. A-1

Conﬁguration Problems .................................................. A-1

Console connection problems ............................... A-2

Network problems................................................ A-2

How to Reset the Netopia 4752 to Factory Defaults......... A-3

Power Outages .............................................................. A-3

Technical Suppor t .......................................................... A-4

How to reach us .................................................. A-4

Appendix B — About SDSL........................................................B-1

Appendix C — Understanding IP Addressing ..............................C-1

What is IP?.................................................................... C-1

About IP Addressing ....................................................... C-1

Subnets and subnet masks .................................. C-2

Example: Using subnets on a Class C IP internet ... C-3

Example: Working with a Class C subnet................ C-5

Distributing IP Addresses ............................................... C-5

Technical note on subnet masking ........................ C-6

Conﬁguration ....................................................... C-7

Manually distributing IP addresses ........................ C-8

Using address serving.......................................... C-8

Tips and rules for distributing IP addresses ........... C-9

Nested IP Subnets....................................................... C-11

Broadcasts.................................................................. C-13

Packet header types .......................................... C-13

Appendix D — Binary Conversion Table......................................D-1

Appendix E — Further Reading .................................................. E-1

x Administration Guide

Appendix F — Technical Speciﬁcations and Safety Information ... F-1

Description.................................................................... F-1

Power requirements ............................................. F-1

Environment ........................................................ F-1

Software and protocols ........................................ F-1

Agency Approvals........................................................... F-2

Regulatory notices ............................................... F-2

Important Safety instructions ............................... F-4

Netopia 4752 Speciﬁcations .......................................... F-5

Physical interface ................................................ F-5

Data features ...................................................... F-5

Hardware speciﬁcations ....................................... F-7

Voice features ..................................................... F-7

Glossary

Index

Limited Warranty and Limitation of Remedies

PPPPaaaarrrrtttt IIII:::: GGGGeeeettttttttiiiinnnngggg SSSSttttaaaarrrrtttteeeedd

Administration Guide

Introduction 1-1

CCCChhhhaaaapppptttteeeerrrr 11

IIIInnnnttttrrrroooodddduuuuccccttttiiiioooonn

OOOOvvvveeeerrrrvvvviiiieeeeww

The Netopia 4752 Voice/Data Integrated Access Devices (IADs) make it possible for small businesses to take advantage of the advanced communications technologies previously limited to larger organizations. By integrating multiple voice connections and high-speed Internet access on one DSL line, businesses can squeeze the most out of their communications budget.

The Netopia 4752 SDSL Integrated Access Device combines a complete telephone system with a business-class data router to deliver a customized package of business communications services over DSL. The Netopia 4752 supports the broad array of phone features of fered through your service provider and uses your existing analog telephone equipment. The Netopia 4752 includes Netopia's sophisticated data routing engine optimized for small and medium size business needs. These business-class features include IP routing, ﬁrewall, NAT, MultiNAT, DHCP and both PPTP and IPSec VPN functionality.

This section covers the following topics:

■

“Features and Capabilities” on page 1-1

“How to Use This Guide” on page 1-2

■

FFFFeeeeaaaattttuuuurrrreeeessss aaaannnndddd CCCCaaaappppaaaabbbbiiiilllliiiittttiiiieeeess

Ofﬁce telephone systems are commonly one of two types, PBX (Private Branch Exchange) or Centrex (Central Ofﬁce Exchange). Technically, Centrex is a subset of PBX.

PBX users share a certain number of outside lines for making telephone calls external to the PBX. Most medium-sized and larger companies use a PBX because it's much less expensive than connecting an external telephone line to every telephone in the organization. In addition, it's easier to call someone within a PBX because the number you need to dial is typically just 3 or 4 digits.

Centrex is a newer variation on the PBX. It is a PBX with all switching occurring at a local telephone of ﬁce instead of at the company's premises. Typically, the telephone company owns and manages all the communications equipment necessary to implement the PBX and then sells various services to the company.

Small- to medium-sized businesses need two kinds of services: Internet presence and voice telephony. But they don't need the additional burden of maintaining switching equipment or administering IP and voice services for their ofﬁces. An Integrated Access Device (IAD) that offers high-speed Symmetric (same speed upload and download) DSL for IP connectivity and a PBX that somebody else (the phone company) administers is the simple solution.

At the phone company's central ofﬁce, where all the big switch gear is, there are two kinds of switches for the two kinds of services, voice and data. The voice switch is called a Voice Gateway and the data switch is called a Digital Subscriber Line Access Multiplexer (DSLAM) or access concentrator. Both the voice and data signals are concentrated at the DSLAM and forwarded either to a data router or to the Voice Gateway. Both kinds of switches are manufactured by a variety of companies. The IAD must be capable of communicating with a wide array of possible combinations of Voice Gateways and DSLAMs.

1-2 Administration Guide

An IAD combines the voice telephony features of a telephone PBX system with the data routing features of an IP data router. The device uses a single outside line connection to carry all voice and data transmissions. If the device uses a DSL interface, it can carr y all of these ser vices over a single existing copper telephone line by using the different frequency ranges available on the copper wire for voice and data trafﬁc.

The Netopia 4752 SDSL Integrated Access Device is that device: a Centrex-based PBX system combined with an SDSL internet router.

The Netopia 4752 SDSL Integrated Access Device provides the following features:

Support for ordinary analog phone equipment.

Works with the same FXS analog phone sets and key systems

that small businesses use today. No expensive handsets to order, no new interface to learn.

Centrex support.

Advanced telephone features enabled by your service provider's telephone switch such as

call forwarding or conferencing operate exactly as they did before.

Netopia data routing engine.

Provides the same advanced, business-class data routing features used by leading DSL service providers around the world. Includes advanced data functionality such as ﬁrewall, VPN client and server (including PPTP and IPSec), DHCP automated address assignment, and Network Address Translation (NAT and MultiNAT).

Physical features include:

SDSL WAN Interface interoperable with major ATM- and Frame Relay-based DSL equipment.

■

A 10/100 Ethernet LAN Port.

■

Eight analog telephone ports (local extensions).

One DB-9 serial console port.

■

Front panel status lights.

■

Setup and conﬁguration management via console menu.

HHHHoooowwww ttttoooo UUUUsssseeee TTTThhhhiiiissss GGGGuuuuiiiiddddee

This guide is designed to be your source for information about your Netopia 4752 SDSL Integrated Access Device. It is intended to be viewed on-line, using the powerful features of the Adobe Acrobat Reader. The information display has been deliberately designed to present the maximum information in the minimum space on your screen. You can keep this document open while you per form any of the procedures described, and ﬁnd useful information about the procedure you are performing.

If you prefer to work from hard copy rather than on-line documentation, you can also print out all of the manual, or individual sections. The pages are formatted to print on 8 1/2 by 11 inch paper. We recommend that you print on three-hole punched paper, so you can put the pages in a binder for future reference. For your convenience, a printed copy can be purchased from Netopia. Order par t number TEP708/Doc.

This guide is organized into chapters describing the Netopia 4752’s advanced features. You may want to read each chapter’s introductory section to familiarize yourself with the various features available.

Use the guide’s table of contents and index to locate informational topics.

Setting Up Internet Services 2-1

CCCChhhhaaaapppptttteeeerrrr 22

SSSSeeeettttttttiiiinnnngggg UUUUpppp IIIInnnntttteeeerrrrnnnneeeetttt SSSSeeeerrrrvvvviiiicccceeeess

This chapter describes how to obtain and set up Internet services.

This section covers the following topics:

■

“Finding an Internet Service Provider” on page 2-1

“Deciding on an ISP Account” on page 2-2

■

“Obtaining Information from the ISP” on page 2-3

■

Note:

Some companies act as their own ISP. For example, some organizations have branch of ﬁces that can use the Netopia 4752 to access the Internet via the main ofﬁce in a point-to-point scenario. If you install the Netopia 4752 in this type of environment, refer to the following sections for speciﬁc information you must receive from the network administrator to conﬁgure the Netopia 4752 properly.

FFFFiiiinnnnddddiiiinnnngggg aaaannnn IIIInnnntttteeeerrrrnnnneeeetttt SSSSeeeerrrrvvvviiiicccceeee PPPPrrrroooovvvviiiiddddeeeerr

The Netopia 4752 SDSL Integrated Access Device provides its high speed symmetric (two-way) digital connection to the Internet through a Local Exchange Carrier (LEC) -- a type of mini phone company. The CLEC uses a compatible type of switching equipment known as a Digital Subscriber Line Access Multiplexer (DSLAM). The DSLAM that you connect to with your Netopia Router must be capable of handling these symmetric connections. The Netopia 4752 is certiﬁed for use with DSLAMs manufactured by Nokia , Lucent, Paradyne, Nortel networks, and Copper Mountain.

If you have purchased your Netopia Router through a Netopia ISP par tner, you can be sure that an account that supports SDSL connections will be available.

If your area has more than one ISP, the following considerations will help you decide which ISP is best suited for your requirements.

In determining which Internet ser vice provider (ISP) to establish your account with, make sure that your ISP supports connections via a CLEC that also supports voice services.

Use an ISP that provides Internet access through a Symmetric Digital Subscriber Line (SDSL) and that suppor ts the Netopia 4752 SDSL Integrated Access Device. If you would like to use an ISP that you already have a relationship with but that is not familiar with the Netopia 4752, call us at 1-800-NETOPIA. Our representative can call your ISP and introduce them to the product. If necessar y, we will provide them with the technical background they need to support the product.

UUUUnnnniiiiqqqquuuueeee rrrreeeeqqqquuuuiiiirrrreeeemmmmeeeennnnttttss

Make sure the ISP can meet any unique requirements you may have, such as:

Dynamic or static IP addressing

■

Class C IP address

2-2 Administration Guide

■

Custom domain name

Multiple e-mail addresses

■

Web site hosting

PPPPrrrriiiicccciiiinnnngggg aaaannnndddd ssssuuuuppppppppoooorrrrtttt

Compare pricing, service, and technical support service among various ISPs.

EEEEnnnnddddoooorrrrsssseeeemmmmeeeennnnttttss

Consider recommendations from colleagues and reviews in publications. Netopia lists Netopia Cer tiﬁed ISPs on our Web site at

http://www.netopia.com

DDDDeeeecccciiiiddddiiiinnnngggg oooonnnn aaaannnn IIIISSSSPPPP AAAAccccccccoooouuuunnnntt

Your ISP may offer various Internet access account plans. Typically, these plans vary by usage charges and the number of host IP addresses supplied. Evaluate your networking needs and discuss them with your ISP before deciding on a plan for your network.

SSSSeeeettttttttiiiinnnngggg uuuupppp aaaa NNNNeeeettttooooppppiiiiaaaa 4444777755552222 aaaaccccccccoooouuuunnnntt

Check whether your ISP has the Netopia 4752 on its list of supported products that have been tested with a particular conﬁguration. If the ISP does not have the Netopia 4752 on such a list, describe the Netopia 4752 in as much detail as needed, so your ISP account can be optimized. As appropriate, refer your ISP to Netopia’s Web site www.netopia.com for more information.

OOOObbbbttttaaaaiiiinnnniiiinnnngggg aaaannnn IIIIPPPP aaaaddddddddrrrreeeessssss

Typically, each network computer that requires Internet access requires its own unique IP address. If some or all network computers require simultaneous Internet access, obtain a block of IP host addresses large enough for each computer to have its own address, plus one for the Netopia 4752.

Consider expected growth in your network when deciding on the number of addresses to obtain. Alternatively, you can use the Network Address Translation feature of SmartIP.

SSSSmmmmaaaarrrrttttIIIIPP

The Netopia 4752 SDSL Integrated Access Device supports Multiple Network Address Translation (MultiNAT).

Network Address Translation provides Internet access to the network connected to the Netopia 4752 using only a single IP address. These routers translate between the internal or local area network (LAN) addresses and a single external IP address, and route accordingly. MultiNAT is a means of mapping one or more IP addresses and/or IP service ports into different values. This

■

For more information on Network Address Translation, see Chapter 11, “Multiple Network Address Translation.”

mapping

It allows the addresses of many computers on a LAN to be represented to the public Internet by only one or a few addresses, saving you money.

It can be used as a security feature by obscuring the true addresses of impor tant machines from potential hackers on the Internet.

serves two functions:

Setting Up Internet Services 2-3

OOOObbbbttttaaaaiiiinnnniiiinnnngggg IIIInnnnffffoooorrrrmmmmaaaattttiiiioooonnnn ffffrrrroooommmm tttthhhheeee IIIISSSSPP

After your account is set up, the ISP should send you the IP parameter information that will help you conﬁgure the Netopia 4752.

LLLLooooccccaaaallll LLLLAAAANNNN IIIIPPPP aaaaddddddddrrrreeeessssssss iiiinnnnffffoooorrrrmmmmaaaattttiiiioooonnnn ttttoooo oooobbbbttttaaaaiiiinn

Your ISP will need to provide you with the following information:

The default gateway IP address (same as remote IP address in most cases)

■

Local WAN IP address and subnet mask

■

Primary and secondary domain name server (DNS) IP addresses

Domain name (usually the same as the ISP’s domain name unless you have registered for your own

■

individual domain name)

Note:

The default gateway, WAN address and mask, DNS, and domain name are all obtainable via WAN DHCP, if your ISP supports it.

WWWWiiiitttthhhh NNNNeeeettttwwwwoooorrrrkkkk AAAAddddddddrrrreeeessssssss TTTTrrrraaaannnnssssllllaaaattttiiiioooonn

If you are using MultiNAT, you should obtain the following:

If you are connecting to a remote site using Network Address Translation on your router, your provider will

■

not deﬁne the IP address information on your local LAN. You can deﬁne this information based on an IP conﬁguration that may already be in place for the existing network. Alternatively, you can use the default IP address range used by the router.

WWWWiiiitttthhhhoooouuuutttt NNNNeeeettttwwwwoooorrrrkkkk AAAAddddddddrrrreeeessssssss TTTTrrrraaaannnnssssllllaaaattttiiiioooonn

If you are not using Network Address Translation, you will need to obtain all of the local LAN IP address information from your ISP.

If you are not using SmartIP (NAT), you should obtain:

■

The number of Ethernet IP host addresses available with your account and the ﬁrst usable IP host address in the address block

The Ethernet IP address for your Netopia 4752

■

The Ethernet IP subnet mask address for your Netopia 4752

2-4 Administration Guide

Making the Physical Connections 3-1

CCCChhhhaaaapppptttteeeerrrr 33

MMMMaaaakkkkiiiinnnngggg tttthhhheeee PPPPhhhhyyyyssssiiiiccccaaaallll CCCCoooonnnnnnnneeeeccccttttiiiioooonnnnss

This section tells you how to make the physical connections to your Netopia 4752 SDSL Integrated Access Device. This section covers the following topics:

■

“Find a Location” on page 3-1

■

“What You Need” on page 3-2

“Identify the Connectors and Attach the Cables” on page 3-3

■

“Netopia 4752 Status Lights” on page 3-4

Find a Location

Note:

Before connecting your Netopia 4752, be sure to read the impor tant safety information contained in

Appendix F, “Technical Speciﬁcations and Safety Information.”

When choosing a location for the Netopia Router, consider:

■

Available space and ease of installation

Physical layout of the building and how to best use the physical space available for connecting your Netopia

■

Router to the LAN

■

Available wiring and jacks

■

Distance from the point of installation to the next device (length of cable or wall wiring)

■ Ease of access to the front of the unit for conﬁguration and monitoring

■ Ease of access to the back of the unit for checking and changing cables

■ Cable length and network size limitations when expanding networks

For small networks, install the Netopia 4752 near one of the LANs. For large networks, you can install the Netopia 4752 in a wiring closet or a central network administration site.

3-2 Administration Guide

What You Need

Locate all items that you need for the installation.

Included in your package are:

■ The Netopia 4752 SDSL Integrated Access Device

■ A power adapter and cord with a mini-DIN8 connector

■ One 6 ft. RJ45 10/100 Ethernet cable

■ One 6 ft. RJ45 SDSL WAN (or Line) cable

■ A DB-9 to DB-9 console cable

■ Printed Installation guide

■ The Netopia CD containing Adobe Acrobat Reader for Windows and Macintosh, ZTerm terminal emulator

software (for Classic MacOS and MacOSX) and NCSA Telnet for Macintosh, and documentation

You will need:

■ A Windows 95 or 98–based PC or a Macintosh computer with Ethernet connectivity for conﬁguring the

Netopia 4752. This may be built-in Ethernet or an add-on card, with TCP/IP installed and conﬁgured. See

“Sharing the Connection” on page 4-1.

■ An SDSL wall outlet wired for a connection to a Local Exchange Carrier (LEC) who suppor ts Symmetric

Digital Subscriber Line connections.

Making the Physical Connections 3-3

Identify the Connectors and Attach the Cables

Identify the connectors on the back panel and attach the necessary Netopia cables.

The ﬁgure below displays the back of the Netopia 4752 SDSL Integrated Access Device.

Netopia 4752 back panel

12345 786

Telephone Extension ports

Extensions

DSLTelephone

DSL Line port

10/100

Ethernet

Console Power

Console port Power port

10/100 Ethernet port

The following table describes all the Netopia 4752 SDSL Integrated Access Device back panel ports.

Port Description

Telephone extension

Eight RJ-11 telephone jacks for connecting your phone extensions.

ports DSL port An RJ-45 10Base-T-style jack labeled DSL for your DSL connection. Ethernet port An RJ-45 10/100Base-T Ethernet jack. You will use this to conﬁgure the Netopia

4752. For a new installation, use the Ethernet connection. Alternatively, you can use the console connection to run console-based management using a direct serial connection. You can either connect your computer directly the Ethernet port using a crossover cable, or connect both your computer and the Netopia 4752 to an existing Ethernet hub on your LAN.

Console port A DB-9 console port for a direct serial connection to the console screens. You

can use this if you are an experienced user. See “Connecting a Console Cable

to Your Device” on page 6-3.

Power port A mini-DIN8 power adapter cable connection.

1. Connect the mini-DIN8 connector from the power adapter to the power port, and plug the other end into an

electrical outlet.

2. Connect one end of the RJ-45 cable to the DSL port, and the other end to your DSL wall outlet.

3. Connect the Ethernet cable to the Ethernet por t on the unit and the other end to your Ethernet hub.

You should now have: the power adapter plugged in; the Ethernet cable connected between the router and your Ethernet hub; and the DSL cable connected between the router and the DSL wall outlet.

3-4 Administration Guide

Netopia 4752 Status Lights

The ﬁgure below represents the Netopia 4752 status light (LED) panel.

Netopia 4752 LED front panel

Power

Management

SDSL

23 45 67

Ready

Data

Voice

10/100 Mbit

Trafﬁc Ethernet

Trafﬁc/Link

The following table summarizes the meaning of the various LED states and colors:

When this happens... the LEDs...

The power is off (button is not pressed in) 1 is dark. The power is on (button pressed in) 1 is green. The power-on self-test fails 1 is red. The WAN interface is training 3 ﬂashes red; then ﬂashes green. The WAN interface is operational 3 is green. Data is transmitted or received 4 ﬂashes yellow. No trafﬁc is being transmitted or received 4 is dark. Voice is operational 5 is green. Voice trafﬁc is transmitted or received 5 is yellow. The Ethernet inter face is connected at 10Base-T speed 6 is dark. The Ethernet inter face is connected at 100Base-T speed 6 is green. The Ethernet hub has no link 7 is dark. The Ethernet hub has link 7 is green.

Sharing the Connection 4-1

CCCChhhhaaaapppptttteeeerrrr 44

SSSShhhhaaaarrrriiiinnnngggg tttthhhheeee CCCCoooonnnnnnnneeeeccccttttiiiioooonn

Once you have set up your physical local area network, you will need to conﬁgure the TCP/IP stack on each client workstation connected to your Netopia 4752. This chapter describes how to conﬁgure TCP/IP for both Windows-based and Macintosh computers.

This chapter explains the following topics:

■ “Conﬁguring TCP/IP on Windows-based Computers” on page 4-2

■ “Conﬁguring TCP/IP on Macintosh Computers” on page 4-5

4-2 Administration Guide

Conﬁguring TCP/IP on Windows-based Computers

Conﬁguring TCP/IP on a Windows computer requires the following:

■ An Ethernet card (also known as a network adapter)

■ The TCP/IP protocol must be “bound” to the adapter or card

Dynamic conﬁguration (recommended)

To conﬁgure your PC for dynamic addressing do the following:

1. Go to the Start Menu/Settings/Control Panels and double click the Network icon. From the Network components list, select the Conﬁguration tab.

2. Select TCP/IP-->Your Network Card. Then select

Properties. In the TCP/IP Properties screen, select the IP Address tab. Click “Obtain an IP Address automatically”.

3. Click on the DNS Conﬁguration tab. Click Disable DNS. DNS will be assigned by the router with DHCP.

4. Click OK in this window and the next window. When prompted, reboot the computer.

Note: You can also use these instructions to conﬁgure other computers on your network to accept IP addresses served by the Netopia 4752.

Sharing the Connection 4-3

Static conﬁguration (optional)

If you are manually conﬁguring for a ﬁxed or static IP address, per form the following:

1. Go to Start Menu/Settings/Control Panels and double click the Network icon. From the Network components list, select the Conﬁguration tab.

2. Select TCP/IP-->Your Network Card. Then select Properties. In the TCP/IP Proper ties screen, select the IP Address tab. Click “Specify an IP Address.”

Enter the following:

IP Address: 192.168.1.2 Subnet Mask: 255.255.255.0, or for 12-user models 255.255.255.240

This address is an example of one that can be used to conﬁgure the router. Your ISP or network administrator may ask you to use a different IP address and subnet mask.

4-4 Administration Guide

3. Click on the Gateway tab (shown below). Under “New gateway,” enter

192.168.1.1. Click Add. This is the Netopia 4752’s pre-assigned IP address.

4. Click OK in this window and the next window. When prompted, reboot the computer.

Click on the DNS Conﬁguration tab. Click Enable DNS. Enter the following information:

Host: Type the name you want to give to this computer.

Domain: Type your domain name. If you don't have a domain name, type your ISP's domain name; for example, netopia.com.

DNS Server Search Order: Type the

primary DNS IP address given to you by your ISP. Click

Add. Repeat this process for the secondary DNS.

Domain Sufﬁx Search Order: Enter the same domain

name you entered above.

Note: You can also use these instructions to conﬁgure other computers on your network with manual or static IP addresses. Be sure each computer on your network has its own IP address.

Sharing the Connection 4-5

Conﬁguring TCP/IP on Macintosh Computers

The following is a quick guide to conﬁguring TCP/IP for MacOS computers. Conﬁguring TCP/IP in a Macintosh computer requires the following:

■ You must have either Open Transport or Classic Networking (MacTCP) installed.

Note: If you want to use the Dynamic Host Conﬁguration Protocol (DHCP) server built into your Netopia 4752 to assign IP addresses to your Macintoshes, you must be running Open Transport, standard in MacOS 8 and optional in earlier system versions. You can have your Netopia 4752 dynamically assign IP addresses using MacTCP; however, to do so requires that the optional AppleTalk kit be installed which can only be done after the router is conﬁgured.

■ You must have built-in Ethernet or a third-par ty Ethernet card and its associated drivers installed in your

Macintosh.

Dynamic conﬁguration (recommended)

The Dynamic Host Conﬁguration Protocol (DHCP), which enables dynamic addressing, is enabled by default in the router. To conﬁgure your Macintosh computer for dynamic addressing do the following:

1. Go to the Apple menu. Select Control Panels and then TCP/IP.

2. With the TCP/IP window open, go to the Edit menu and select User Mode. Choose Basic and click OK.

3. In the TCP/IP window, select “Connect via: Ethernet” and “Conﬁgure: Using DHCP Server.”

Note: You can also use these instructions to conﬁgure other computers on your network to accept IP addresses served by the Netopia 4752.

4-6 Administration Guide

Static conﬁguration (optional)

If you are manually conﬁguring for a ﬁxed or static IP address, perform the following:

1. Go to the Apple menu. Select Control Panels and then TCP/IP or MacTCP.

2. With the TCP/IP window open, go to the Edit menu and select User Mode. Choose Advanced and click OK.

Or, in the MacTCP window, select Ethernet and click the More button.

3. In the TCP/IP window or in the MacTCP/More window, select or type information into the ﬁelds as shown in the following table.

Option: Select/Type:

Connect via: Ethernet Conﬁgure: Manually IP Address: 192.168.1.2 Subnet mask: 255.255.255.0, or for 12-user models

255.255.255.240 Router or Gateway address: 192.168.1.1 Name server address: Enter the primar y and secondar y name ser ver

addresses given to you by your ISP

Implicit Search Path: Starting domain name:

Enter your domain name; if you do not have a domain name, enter the domain name of your ISP

4. Close the TCP/IP or MacTCP control panel and save the settings.

5. If you are using MacTCP, you must restar t the computer. If you are using Open Transport, you do not need to restart.

Sharing the Connection 4-7

Note: You can also use these instructions to conﬁgure other computers on your network with manual or static IP addresses. Be sure each computer on your network has its own IP address.

More information about conﬁguring your Macintosh computer for TCP/IP connectivity through a Netopia 4752 can be found in Technote NIR_026, “Open Transport and Netopia Routers,” located on the Netopia Web site.

4-8 Administration Guide
