Netopia 3347W/3357W-ENT ADSL Wireless Router



Status Lights.................................................................

2-5

Chapter 3 — Connecting to Your Local Area Network .................

3-1

Readying Computers on Your Local Network.....................

3-1

Connecting to an Ethernet Network .................................

3-2

Chapter 4 — Configuring TCP/IP...............................................

4-5

Configuring TCP/IP on Windows-based Computers............

4-5

Microsoft Windows.........................................................

4-5

Configuring TCP/IP on Macintosh Computers ...................

4-7

Macintosh MacOS 8 or higher or Mac OS X......................

4-7

Chapter 5 — Telnet-Based Management ....................................

5-1

Connecting through a Telnet Session...............................

5-2

Configuring Telnet software ...................................

5-2

Navigating through the Telnet Screens.............................

5-3

Chapter 6 — Easy Setup ...........................................................

6-1

Easy Setup Telnet Screens .............................................

6-1

Accessing the Easy Setup Telnet screens...............

6-1

Quick Easy Setup Connection Path..................................

6-2

1. DSL Line Configuration .....................................

6-4

2. Easy Setup Profile ............................................

6-5

3. IP Easy Setup ..................................................

6-6

4 Getting Started Guide

4. Easy Setup Security Configuration .....................

6-8

Chapter 7 — Wireless LAN Configuration...................................

7-1

Wireless Configuration ...................................................

7-1

Appendix A — Technical Specifications and Safety Information ..

A-1

Description....................................................................

A-1

Power requirements .............................................

A-1

Environment ........................................................

A-1

Software and protocols.........................................

A-1

Agency approvals...........................................................

A-2

Regulatory notices ...............................................

A-2

Manufacturer’s Declaration of Conformance ....................

A-3

Important Safety Instructions .........................................

A-4

FCC Part 68 Information.................................................

A-5

FCC Requirements ...............................................

A-5

FCC Statements...................................................

A-5

Electrical Safety Advisory ...............................................

A-6

Introduction 1-5

Chapter 1

Introduction

Overview

The Netopia 3347W/3357W-ENT ADSL Wireless Router is a full-featured, ADSL router for connecting both wired and wireless local area networks (LANs) to the Internet and other remote networks. The Netopia 3347W/3357W-ENT ADSL Wireless Router connects easily to your ADSL service to provide your whole network with a high-speed connection to the outside world.

This section covers the following topics:

“Features and Capabilities” on page 1-5

“How to Use this Guide” on page 1-6

Features and Capabilities

The Netopia 3347W/3357W-ENT ADSL Wireless Router provides the following features:

LAN interface: four port 10/100BaseTX RJ-45 Ethernet switch with Auto-crossover support, Wi-Fi CERTIFIED™ 802.11b wireless support for high-speed wireless LAN connections

Point-to-Point Protocol (PAP/CHAP authentication)

PPP over Ethernet Gateway

PPP over Ethernet pass-through

Transparent bridging option

Support for IP routing for Internet connectivity

Numbered or unnumbered WAN interface

Support for Ethernet LANs with up to eight LAN IP subnets

NAT/NAPT, Multi-NAT, and DHCP (client, server, and relay) for security and convenience

DNS proxy

IP Multicast Forwarding, IGMP V1, V2

RIP1 and RIP2, static routes

IP QoS: TOS bit prioritization

VPN Pass-through for PPTP and IPSec

Built-in VPN gateway features offer support for up to 15 PPTP or IPSec VPN tunnels

1-6 Getting Started Guide

IPSec implementation supports DES or 3DES encryption, MD5 or SHA1 encapsulation, and manual or IKE keying

Built-in stateful firewall and packet-filtering firewall features protect LAN resources from Internet intruders

Backup Default Gateway feature with an external router enables high-availability solutions

Menu-driven or CLI interfaces via Telnet

Easy Setup with menu-driven interface

Tiered Access, 2 levels of configuration access

Configuration Management, up to 3 backup configurations

TFTP download/upload of new firmware and configuration files

System diagnostics and logs

SNMP V1 and V2 (read/write access)

Management utilities: ICMP ping, trace route, Telnet client, and Syslog client

Status lights (LEDs) for easy monitoring and troubleshooting

Wall-mountable, Bookshelf (Side-stackable), or Desktop-stackable design for efficient space usage

How to Use this Guide

In addition to the documentation contained in the accompanying Firmware User’s Guide, this guide is designed to get you up and running and connected to your local area network and the Internet. It is intended to be viewed on-line, using the powerful features of the Adobe Acrobat Reader. The information display has been deliberately designed to present the maximum information in the minimum space on your screen. You can keep this document open while you perform any of the procedures described, and find useful information about the procedure you are performing.

You can also print out all of the manual, or individual sections, if you prefer to work from hard copy rather than on-line documentation. The pages are formatted to print on standard 8 1/2 by 11 inch paper. We recommend that you print on 3-hole punched paper, so that you can put the pages in a binder for future reference.

This guide is organized into chapters describing the Netopia 3347W/3357W-ENT ADSL Wireless Router’s advanced features. You may want to read each chapter’s introductory section to familiarize yourself with the various features available.

Use the guide’s table of contents and index to locate informational topics.

Making the Physical Connections 2-1

Chapter 2

Making the Physical Connections

This section tells you how to make the physical connections to your Netopia 3347W/3357W-ENT ADSL Wireless Router. This section covers the following topics:

“Find a Location” on page 2-1

“What You Need” on page 2-1

“Identify the Connectors and Attach the Cables” on page 2-3

“Netopia 3347W/3357W-ENT ADSL Wireless Router Status Lights” on page 2-5

Find a Location

When choosing a location for the Netopia ADSL Wireless Router, consider:

Available space and ease of installation

Physical layout of the building and how to best use the physical space available for connecting your Netopia ADSL Wireless Router to the LAN

Available wiring and jacks

Distance from the point of installation to the next device (length of cable or wall wiring)

Ease of access to the front of the unit for configuration and monitoring

Ease of access to the back of the unit for checking and changing cables

Cable length and network size limitations when expanding networks

What You Need

Locate all items that you need for the installation.

Included in your router package are:

The Netopia 3347W/3357W-ENT ADSL Wireless Router

A power adapter and cord

One Yellow RJ-45 Category 5 Ethernet cable

One Lavender RJ-11 DSL telephone cable

The Netopia CD containing software and documentation

2-2 Getting Started Guide

You will need:

A Windows–based PC or a Macintosh computer with Ethernet connectivity for configuring the Netopia 3347W/3357W-ENT. This may be built-in Ethernet or an add-on card, with TCP/IP installed and configured. See “Configuring TCP/IP” on page 4-5.

A phone jack to which your ADSL provider is providing ADSL service. (Your phones and ADSL service generally use the same phone line.)

Important Safety Instructions

POWER SUPPLY INSTALLATION

Connect the power supply cord to the power jack on the Cayman Gateway. Plug the power supply into an appropriate electrical outlet.

CAUTION: Depending on the power supply provided with the product, either the direct plug-in power supply blades, power supply cord plug or the appliance coupler serves as the main power disconnect. It is important that the direct plug-in power supply, socket-outlet or appliance coupler be located so it is readily accessible.

CAUTION (North America Only): For use only with a CSA Certified or UL Listed Limited Power Source or Class 2 power supply, rated 12Vdc, 1.5A.

CAUTION (Europe Only): For use only with a GS approved Limited Power Source, rated 12Vdc, 1.5A. (Sweden) Apparaten skall anslutas till jordat uttag när den ansluts till ett nätverk

(Norway) Apparatet må kun tilkoples jordet stikkontakt.

TELECOMMUNICATION INSTALLATION CAUTIONS

When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following:

1.Do not use this product near water, for example, near a bathtub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

2.Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electrical shock from lightning.

3.Do not use the telephone to report a gas leak in the vicinity of the leak.

SAVE THESE INSTRUCTIONS

Making the Physical Connections 2-3

Identify the Connectors and Attach the Cables

Identify the connectors on the back panel and attach the necessary Netopia Router cables.

Netopia 3347W/3357W-ENT back panel

DSL

4

3 LAN 2

1

Power

Off / On

DSL port

Ethernet

Power port

ports

Wireless antenna

.

Port

Description









DSL port

An RJ-11 jack labeled DSL to connect to your DSL wall outlet.

Ethernet ports

Four RJ-45 10/100Base-T Ethernet jacks. You can use one of these to configure the



Netopia 3347W/3357W-ENT. You can either connect your computer directly to an



Ethernet port using the supplied Category 5 Ethernet cable, or connect both your



computer and the Netopia 3347W/3357W-ENT to an existing LAN environment. The



Ethernet ports are auto-sensing, eliminating the need for a crossover cable.





Power port

A DC power adapter cable connection.





Wireless antenna

An 802.11b wireless antenna to send and receive traffic from your wireless LAN



computers.





2-4 Getting Started Guide

Connect your computer, DSL line, and power source as shown.

Ethernet



4

DSL

DC Power

DSL





4 3 LAN 2 1

Power Off / On



2

1

3



1.For a direct computer to router Ethernet connection, use the standard Ethernet cable included with your router.

2.Use the supplied RJ-11 telephone cable to connect the router to your DSL wall outlet.

3.Connect the supplied power brick to a power outlet and the connector end to the router.

4.Each computer using the wireless network requires its own Wi-Fi CERTIFIED™ 802.11b adapter to be installed in the computer.

This may be purchased from any Wi-Fi CERTIFIED™ manufacturer for your particular computer. See “Connecting to Your Local Area Network” on page 3-1.

You should now have: the power adapter plugged in; the Ethernet cable connected between the router and your computer; and the telephone cable connected to its appropriate wall jack.

Netopia 3347W, 3357W-ENT User Manual

Making the Physical Connections 2-5

Netopia 3347W/3357W-ENT ADSL Wireless Router Status Lights

The figure below represents the Netopia 3347W/3357W-ENT status light (LED) panel.

Netopia 3347W/3357W-ENT status indicator lights

Power:

Solid green when the power is on

DSL Sync -

Flashes green when training

Solid green when trained

Flashes green for DSL traffic

LAN 1, 2, 3, 4 -

Solid green when connected to each port on the LAN. Flash green when there is activity on each port.

Wireless Link -

Flashes green when there is activity on the wireless LAN.

2-6 Getting Started Guide

Connecting to Your Local Area Network 3-1

Chapter 3

Connecting to Your Local Area Network

This chapter describes how to physically connect the Netopia 3347W/3357W-ENT to your local area network (LAN). Before you proceed, make sure the Netopia 3347W/3357W-ENT is properly configured. You can customize the router’s configuration for your particular LAN requirements using console-based management (see “Telnet-Based Management” on page 5-1).

This section covers the following topics:

“Readying Computers on Your Local Network” on page 3-1

“Connecting to an Ethernet Network” on page 3-2

Readying Computers on Your Local Network

PC and Macintosh computers must have certain components installed before they can communicate through the Netopia 3347W/3357W-ENT. The following illustration shows the minimal requirements for a typical PC or Macintosh computer.

Application software

TCP/IP stack

Ethernet Driver

Your PC

or Macintosh computer

To the Netopia

Application software: This is the software you use to send e-mail, browse the World Wide Web, read newsgroups, etc. These applications may require some configuration. Examples include the Eudora e-mail client and the Web browsers Microsoft Internet Explorer and Netscape Navigator.

TCP/IP stack: This is the software that lets your PC or Macintosh computer communicate using Internet protocols. TCP/IP stacks must be configured with some of the same information you used to configure the Netopia 3347W/3357W-ENT. There are a number of TCP/IP stacks available for PC computers. Windows 95 includes a built-in TCP/IP stack. Macintosh computers use either MacTCP or Open Transport. See “Configuring TCP/IP on Windows-based Computers” on page 4-5. Macintosh computers use either MacTCP or Open Transport. See “Configuring TCP/IP on Macintosh Computers” on page 4-7.

3-2 Getting Started Guide

Ethernet: Ethernet hardware and software drivers enable your PC or Macintosh computer to communicate on the LAN.

Once the Netopia 3347W/3357W-ENT is properly configured and connected to your LAN, PC and Macintosh computers that have their required components in place will be able to connect to the Internet or other remote IP networks.

Connecting to an Ethernet Network

You can connect a standard 10/100Base-T Ethernet network to the Netopia 3347W/3357W-ENT using any of its Ethernet ports.

Netopia 3347W/3357W-ENT back panel

DSL

4

3 LAN 2

1

Power

Off / On

Loading...
+ 30 hidden pages
