Netopia 4500 Series
Business-class Broadband Routers for Small and Medium Enterprises
Built-in business-class features mean
performance and value for the small
4500 Series
Business-class
Robust routing, security, and
management features optimized
for the business user
VPN Ready
Built-in and standard VPN features
Cost-effective
Application specific architecture
designed for the small business
budget
and medium enterprise
The Netopia 4500 Series is a family of business-class
routers designed for the needs of small and medium
enterprises and teleworkers. The 4500 Series combines
powerful routing features, built-in VPN capabilities, and
enterprise-class management tools into a single, all in
one device.
The 4500 Series supports the main access technologies
for today’s business marketplace. Carriers, ISPs, and
managed service providers (MSPs) will appreciate the
broad technology coverage, with WAN options for ADSL
Annex A, ADSL Annex B, SHDSL, SDSL, IDSL and T1.
High-performance routing features power businessclass applications for the network-savvy small business
or teleworker. Server hosting, video-conferencing, and
sophisticated routing schemes are easy to configure
and manage.
The Netopia 4500s are the only routers in their class to
combine a firewall with standards-based VPN features,
all at no extra cost. With no complicated feature keys or
software upgrades to manage, the 4500 Series is both
an IP router and a security appliance in one.
NETOPIA BROADBAND GATEWAYS
Only Netopia offers affordable Broadband Gateways for every connection type -- from DSL to T1. Perfect for homes, home
offices, teleworkers, small businesses and corporate branch offices, Netopia Broadband Gateways bring high speed
broadband Internet access to every computer. Built-in security protects data, applications and gateways without the need to
purchase separate software or hardware. Advanced features support growth while protecting your investment. Quick setup,
comprehensive management and high reliability make Netopia both powerful and easy to use.
For the network-centric small and medium enterprise,
the 4500 Series delivers the right combination of
business-class performance, simplicity and value.
Netopia 4500 Series
Business-class Broadband Routers for Small and Medium Enterprises
Technical
Specifications
4500 Series Part Numbers
4522: T1 Router
4522-XL: T1 VPN Router
45412: ADSL (POTS) Router
45413: ADSL (POTS) Router
4542: ADSL (ISDN) Router
4552: SDSL/IDSL Router
4553: SHDSL Router
Hardware Features
WAN Interface
4522/4522-XL: T1 CSU/DSU
Quality of Service
c
ATM: UBR, CBR
c
IP: TOS bit prioritization
45412: ADSL Annex A (POTS), G.lite, DMT, RJ-11 interface
45413: ADSL Annex A (POTS), G.lite, DMT, RJ-11 interface
4542: ADSL Annex B (ISDN), RJ-11 interface
4552: SDSL/IDSL, RJ-48 interface
4553: SHDSL, RJ-48 interface
LAN Interface
4522/4522-XL: 10/100BaseT Ethernet port
45412: 10/100BaseT Ethernet port
45413: 10BaseT 4-port Ethernet hub
4542: 10/100BaseT Ethernet port
4552: 10/100BaseT Ethernet port
4553: 10/100BaseT Ethernet port
Management Interface
Console port, DE9 DTE
Acceleration
4522-XL: VPN Acceleration Module
ATM
c
ATM Adaptation Layer 5 (AAL5)
c
Up to 8 ATM Permanent Virtual Circuits (PVCs)
c
Bridged or routed Ethernet encapsulation, LLC/SNAP
and VC Multiplexing
c
DHCP Client
c
I.610 OAM F5 Loopback
Frame Relay
c
HDLC packet-based format link layer
c
ANSI T1.617 and ANSI T1.618 Annex D, Annex A,
and Cisco HDLC
c
Up to 32 Data-link Connection Identifiers (DLCIs)
c
Multiprotocol interconnect over Frame Relay
c
DHCP Client
PPP
c
Point-to-Point Protocol (PAP/CHAP authentication)
c
PPP over Ethernet Gateway
c
PPP over ATM Gateway: LLC and VC Multiplexing
c
PPP over Ethernet pass-thru
c
PPP over Frame Relay
Routing Function
c
Numbered or unnumbered WAN interface
c
Up to 8 subnets on the LAN, with DHCP server associations
c
RIP1 and RIP2, static routes
c
Network Address Translation (NAT), NAPT, and MultiNAT
c
IP Multicast Forwarding, IGMP V1, V2
c
DHCP Server and Relay
c
DNS Proxy
c
VPN Pass-thru for PPTP and IPSec
c
Transparent bridging option
Copyright © 2003, Netopia, Inc. All rights reserved.
Netopia and the Netopia logo are registered trademarks and Making Broadband Work is a trademark of Netopia, Inc.
All other trademarks are the property of their respective owners.
High Availability
c
Backup Default Gateway via an external router
c
Dial back-up via a console attached modem
Security
c
Built-in firewall, packet filtering on source/destination
address, service, and protocol; up to 255 rules in up to
8 filter sets
c
Network Address Port Translation (NAPT)
c
IPSec VPN Gateway, Tunnel Mode
- DES and 3DES encryption
- Manual key and IKE
- AH and ESP: MD5 and SHA1
c
PPTP VPN Gateway, client or server termination
c
Up to 15 PPTP or IPSec VPN security associations
c
VPN acceleration for IPSec, DES and 3DES applications
Management
c
Management via menu-driven or CLI interfaces with
console or Telnet access
c
Easy Setup with menu-driven interface
c
WebUI (ADSL models only)
c
Console Tiered Access, 2 levels of configuration access
c
Configuration Management, up to 3 backup configurations
c
System diagnostics and logs
c
SNMP V1 and V2
c
TFTP or X-Modem download/upload of new firmware and
configuration files
c
Utilities: ICMP ping, trace route, Telnet client, and
Syslog client
c
LEDs: power, WAN, and Ethernet; link, status,
activity indications
Regulatory
c
FCC Part 68, Part 15, Class B
c
UL Listed, CSA Approved
c
European EMC & Immunity
c
TS-001 Australian Safety
Environmental
c
Operating: 0 to +40C°
c
Storage: 0 to +70C°
c
Power: North America: 120VAC nominal, 60HZ, .25A;
Europe: 100-240 VAC, 50/60 HZ, 0.6A
Weight and Dimensions
c
Weight: 1 lb 14 oz (851g)
c
Dimensions: 9.45" (240mm) W, 2.25" (57.2mm) H,
x 7.95" (202mm) L
