Netopia 3356-ENT, 3346-ENT User Manual

1

Quickstart Guide

Copyright © 2003, Netopia, Inc. All rights reserved. Netopia, Cayman and the Netopia logo are
registered trademarks and Making Broadband Work is a trademark of Netopia, Inc. All other
trademarks are the property of their respective owners.

Making Broadband Work

™

V. 24/07/03

Cayman®3346-ENT
Cayman

®

3356-ENT

ADSL

Router

LAN 2

LAN 1

C

N

Y

Power

L S

LAN 4

S

LAN 3

D

Check your package contents:

1. Unpack the Netopia Cayman

CD-ROM and Quickstart Guide

RJ-11 Telephone Cable

(lavender)

RJ-45 Ethernet Cable

(yellow)

Netopia Router: Cayman 3346-ENT

or Cayman 3356-ENT

Power Supply

and Power Cord

2

1. After unpacking your Cayman Router shipping carton, decide where you want
to locate the Router.

You should install the Netopia Cayman near your computer or another location
that permits easy access and visibility. You can lay the Netopia Cayman flat, or
mount it on a wall. Make sure any Ethernet cables are kept away from power
cords, fluorescent lighting fixtures, and other sources of electrical interference.
Put the Netopia Cayman in a location where air can circulate freely around it.

2. Connect the Power Supply to the power jack on the back panel of the Netopia
Cayman. Connect the Power Cord to the Power Supply and plug it into an
appropriate electrical outlet.

Turn on the power using the power switch. The Power light should come on
solid green.

2. Set up the Netopia Cayman

LAN 4

Power

LAN 3

LAN 2

LAN 1

DSL SYNC

3

E
N
G

L

I
S
H

3. Connect the Router to the phone wall jack that supports your ADSL service.

Insert one end of the lavender telephone cable in the DSL port on the Cayman
Router back panel. Insert the other end of the telephone cable into the tele­phone jack connected to your ADSL service. The DSL SYNC indicator light should
blink for up to two minutes and then come on solid green.

4. Connect the Netopia Cayman to create your Ethernet local area network (LAN).

Connect the yellow Ethernet cable to your first computer and to a LAN port on
the back of the Cayman Router. The LAN light for the port where you connected
the cable should blink briefly and come on solid green.

Note about connecting y

our network:

After you have connected your first computer, please finish configuring your
router and Internet access before connecting any other computer or device.

When your router is configured and your Internet access is up and running,
connect each additional computer or device to a switch port on the back of the
Cayman Router with an Ethernet cable (maximum length 100 meters). If you
need more than four ports, connect a hub or a switch to the Netopia Cayman
using a standard Ethernet cable.

When all of your connections are made, the status LEDs on the front of your
Netopia Cayman will light, according to the following diagram:

Cayman 3346-ENT & Cayman 3356-ENT Front Panel

2. Set up the Netopia Cayman (continued)

Power

Off / On

LAN

DSL

4

12

3

to the phone wall jack
(ADSL filter or splitter)

to the
power

jack

3

4

2

Power - Green when power is on.

DSL SYNC -

Flashes green when training
Solid green when trained.

LAN 1, 2, 3, 4 -

Solid green when connected to each
port on the LAN.
Flashes green when there is activity
on each port.

Ethernet hub

or switch

C

N

Y

Power

L S

LAN 4

S

LAN 3

D

LAN 2

LAN 1

The following instructions assume that you want to use the automatic configuration
and address sharing features of the Router to provide IP information to devices on
your local Ethernet network.

1. Configure your computer to use an IP address on the same TCP/IP network as
the Cayman Router:

> Windows 95, 98 and ME

On your computer, go to:

Open the network window by
double-clicking the Network Icon.

(Windows ME users: if the network icon
is hidden, click on the “View All Control
Panel Options” - a link at the left-side of
the control panel window)

In the list of network components,
highlight the entry that says

“TCP/IP (your Ethernet card here)”

and click

In the window that pops up,

select and click

Click the tab, select and click

Click the tab, remove any installed Gateways and click

Click the button again. When prompted, restart your computer.

Proceed to the next section “3. Configure the Netopia Cayman”.

Configure your Computer for Dynamic Addressing

4

DNS Configuration

Disable DNS

Gateway

5

E
N
G

L

I
S
H

> Windows 2000 and XP

• Right click on the My Network Places icon on your Windows desktop
and select Properties from the drop-down menu.

• Right click on your Local Area Connection and select Properties.

• Select Internet Protocol [TCP/IP].

• Click the Properties button.

• Click the Obtain IP address automatically radio button and the
Obtain DNS server address automatically radio button.
Click the OK button.

• Restart your PC.

• Proceed to the next section “3. Configure the Netopia Cayman”.

> Macintosh Mac OS

Your Macintosh must be using Mac OS 7.6.1 or higher.

• Select Control Panels from the Apple menu.

• Open the TCP/IP Control Panel.

• Choose Connect: Via Ethernet.

• Choose Configure: Using DHCP Server. Save and close the
“Control Panels” window. You do not have to restart the Macintosh.

• Proceed to the next section “3. Configure the Netopia Cayman”.

> Mac OS X users

• Launch System Preferences from the Dock or from the Apple Menu.

• Select the Network Preference Pane.

• Choose Show: Built-in Ethernet.

• Click the TCP/IP tab.

• Choose Configure: Using DHCP.

• Quit System Preferences. You do not have to restart the Macintosh.

• Proceed to the next section “3. Configure the Netopia Cayman”.

2. To connect additional computers that will use the address sharing features of
the Netopia Cayman, repeat step 1.

Configure your Computer for Dynamic Addressing (continued)

6

3. Configure the Netopia Cayman

1. Run a Telnet application from the computer on the same network as the Router.

•W

indows users: click on the Start menu, select Run, and in the resulting

entry box, type telnet 192.168.1.1

• Macintosh OS X users:

launch the Terminal application, either from the

Dock or from the Utilities folder, and type telnet 192.168.1.1

• Classic Macintosh OS users:

you need to install the NCSA Telnet
application, included on the Netopia CD, or freely available from user groups
or other freeware sources. Then launch NCSA Telnet and type 192.168.1.1

In the Telnet screens, move from field to field with the arrow keys. Select/execute
items with the Return key, and toggle items (Yes/No, On/Off, ...) with the Ta b key
followed by Return.

A/ The Telnet window displays the Main Menu.

B/ The ADSL Line Configuration screen appears.

> If your ISP uses PPPoE, toggle PPP over Ethernet to On with the Ta b key followed

by Return. If necessary, change the VPI and VCI to match those used by your ISP.

> If your ISP uses PPPoA, toggle Data Link Encapsulation to PPP and configure the

PPPoA default profile.

Cayman Router

Easy Setup...
WAN Configuration...
System Configuration...
Utilities & Diagnostics...
Statistics & Logs...
Quick Menus...
Quick View...

Return/Enter goes to Easy Setup -- minimal configuration.
You always start from this main screen.

ADSL Line Configuration

Trellis Coding Enabled: On
Fast Retrain Enabled: On

Wiring Type AutoSense
Data Link Encapsulation RFC 1483
RFC 1483 Mode Bridged 1483
PPP over Ethernet (PPPoE) Off

Data Circuit VPI (0-255) 8
Data Circuit VCI (32-65535) 35

PREVIOUS SCREEN NEXT SCREEN

Return/Enter takes you back to previous screen.

Select Easy Setup
and press Return.

Make any changes
that your ISP
requires.

If necessary, turn
on PPPoE or
PPPoA.

Select NEXT SCREEN
and press Return.

7

E
N
G

L

I
S
H

3. Configure the Netopia Cayman (continued)

If your ISP uses PPPoA, follow the instructions (the example below is based on
ADSL “Wires Only” in the UK - parameters may change according to your ISP):

If necessary, toggle PPP Mode from VC Multiplexed to LLC SNAP and change the
VPI and VCI to match those used by your Internet Service Provider.

Please note:

This example is based on ADSL “Wires Only” in the UK. ADSL “Wires Only” uses
PPPoA and different VPI/VCI than those by default. As a result, you need to set
Data Link Encapsulation to PPP, VPI to 0 and VCI to 38. PPP Mode remains VC
Multiplexed by default. Parameters may change according to your ISP!

Proceed to the next screen.

C/ The Connection Profile 1: Easy Setup Profile screen appears.
The example below is based on IP Easy Set Up using NAT by default.

Set the Remote IP Address to 127.0.0.2 - this will allow the Netopia Cayman to
automatically pick up the IP address of the remote gateway of your Internet Service
Provider. If you know this address, you can also enter it here.
Set PPP Authentication to the mode used by your ISP. In the BT Wires Only example
this would be CHAP mode. In the Send Host Name and Send Secret fields, enter
the login and password supplied by your ISP. Proceed to the next screen.

Connection Profile 1: Easy Setup Profile

Address Translation Enabled: Yes
IP Addressing... Unnumbered

Remote IP Address: 127.0.0.2
Remote IP Mask: 255.255.255.255

PPP Authentication... CHAP
Send Host Name: login
Send Secret: password_

PREVIOUS SCREEN NEXT SCREEN

Return/Enter brings you to next screen.

Enter basic information about your WAN connection with this screen.

Make any
changes
required.

Select NEXT
SCREEN and
press Return.

ADSL Line Configuration

Trellis Coding Enabled: On
Fast Retrain Enabled: On

Wiring Type AutoSense
Data Link Encapsulation PPP
PPP Mode VC Multiplexed

Data Circuit VPI (0-255) 0
Data Circuit VCI (32-65535) 38

PREVIOUS SCREEN NEXT SCREEN

Return/Enter takes you back to previous screen.

Make any
changes
that your
ISP requires.

Select NEXT
SCREEN and
press Return.

8

D/ The IP Easy Setup screen appears. Configure your LAN parameters here.

The example below is based on IP Easy Set Up using NAT and DHCP Server.

The Domain Name and the IP addresses of your Primary and Secondary Domain
Name Server are dynamically acquired by the router when connecting to the
Internet. However, we recommend that you enter manually these information as
supplied by your ISP. The other parameters allow you to change, if necessary, the
default settings and the DHCP Server features of your Cayman Router.

E/ The Easy Setup Security Configuration screen appears.

Enter a Name and Password to limit access to the Router’s configuration screens.
Be sure to remember what you have typed because you will be prompted for it each
time you configure your Router. Select RESTART DEVICE and press Return.

2. The Cayman Router will then restart and your settings will take effect.
Congratulations! Your installation is complete. You can now surf to your favourite

Web sites. If you have any questions or encounter problems, refer to the detailed
documentation on the Netopia CD, or contact our technical support. Answers to
many frequently asked product-related questions are also available on-line at:
http://www. netopia.com/support

Easy Setup Security Configuration

It is strongly suggested that you password-protect configuration
access to your Netopia. By entering a Name and Password pair here,
access via serial, Telnet and Web server will be password protected.
Be sure to remember what you have typed here, because you will be
prompted for it each time you configure this Netopia.

Write Access Name:
Write Access Password:

PREVIOUS SCREEN TO MAIN MENU RESTART DEVICE

Configure a Configuration Access Name and Password here.

3. Configure the Netopia Cayman (continued)

IP Easy Setup

Ethernet IP Address: 192.168.1.1
Ethernet Subnet Mask: 255.255.255.0

Domain Name: ______
Primary Domain Name Server: 0.0.0.0
Secondary Domain Name Server: 0.0.0.0

Default IP Gateway: 127.0.0.2

IP Address Serving: On

Number of Client IP Addresses: 100
1st Client Adress: 192.168.1.100

PREVIOUS SCREEN NEXT SCREEN

Enter an IP address in decimal and dot form (xxx. xxx. xxx. xxx).
Set up the basic IP & IPX attributes of your Netopia in this screen.

Make any
changes
required.

The default IP
gateway must
match the
Remote IP add­ress value that
you set on the
Connection
Profile screen

Select NEXT
SCREEN and
press Return.

Netopia Europe

2, rue du Docteur Lombard

92130 Issy-Les-Moulineaux

FRANCE

tel: [phone]

fax: [phone]

[e-mail]

Netopia UK

c/o M. Nathan-Amissah

58 Poulton Avenue

Sutton

Surrey SM1 3PY

UNITED KINGDOM

[e-mail]

Netopia Deutschland

Am Fuchsberg 4

D-21423 WINSEN

DEUTSCHLAND

[e-mail]

Netopia Nederland

Becanusstraat 13

Suite B04

6216 BX Maastricht

NEDERLAND

[e-mail]

Internet

www.netopia.com

www.netopia-europe.com

www.netopia.co.uk

www.netopia.fr

www.netopia.de

www.netopiaAG.ch

www.netopia.it

Hotline

> in English

[phone]

[e-mail]

> en français (0,15 Euros HT/min)

N° local France : 0825 06 2424
DOM TOM : [phone]

[e-mail]

> auf Deutsch (für Swisscom &

Bluewin Kunden)

[phone] (2,5 CHF/min)

[e-mail]

Netopia Part Number 6180061-00-01

EU-ENT_3346-3356_QSG-240703
