NETGEAR SRXN3205 DATA SHEET

Download

24/7

TECHNICAL

SUPPORT *

25-user Ofﬁce Wireless VPN Firewall

ProSafe® Wireless-N VPN Firewall Data Sheet

SRXN3205

Optimal, Secure Connection for Your Network

NETGEAR’s SRXN3205 ProSafe® Wireless-N VPN Firewall offers two types of virtual private network (VPN) tunnels, Secure Sockets Layer (SSL) and IP security (IPsec), for optimal secure connection to your network. SSL VPN tunnels provide clientless remote access to your corporate data for individual access anywhere and anytime without a software client. IPsec VPN tunnels deliver both secure site-tosite tunnels and legacy remote access support, connecting multiple ofﬁces together, as well as clientbased remote access. Backed by a sophisticated ﬁrewall, the SRXN3205 is a high-performance, SNMP-manageable security solution that furnishes multidimensional security including denial-ofservice (DoS) protection, stateful packet inspection (SPI), URL keyword ﬁltering, logging, reporting, and real-time alerts. Four Gigabit LAN ports in conjunction with an integrated dual band Wireless N Access Point keep your data moving at top speed.

Secure

Wireless Access

Easy to Use

The SRXN3205 Wireless-N VPN Firewall takes care of all your security needs, with support of up to 5 SSL VPN tunnels and 5 IPsec VPN tunnels simultaneously, hacker protection via SPI ﬁrewall, DoS attack protection, and multiple VPN pass-through. SYSLOG and email reporting enable thorough network monitoring. The SSL VPN tunnels support industry-strength encryption algorithms and features such as automatic cache cleanup after session termination to ensure protection and privacy of your sensitive data. The SRXN3205 Wireless-N VPN Firewall provides optimal value and defense against network security threats.

NETGEAR’s SRXN3205 Wireless-N VPN Firewall delivers the coverage and speed advantages of

802.11n wireless networks. Designed to deliver the superior wireless network that your clients want, the SRXN3205 makes it easy to move up to 802.11n. Operating in either 2.4 GHz or 5.0 GHz radio bands, the SRXN3205 provides the ﬂexibility to transition from legacy networks. Select the 2.4 GHz radio band to gain superior wireless connection while maintaining support for existing 802.11g and 802.11b networks. Wireless- N clients on this network will experience excellent throughput and range, while legacy clients will continue to function. For the full beneﬁts of Wireless-N, select the 5.0 GHz radio band to create an overlay network that does not interfere with the on-hand 802.11g and

802.11b devices such as older laptops, print servers, hand-held inventory scanners, and IP cameras. Selected clients that are upgraded to this N network will achieve the full capabilities such as:

- Up to 10x the coverage and 15x the speed of 802.11g networks

- Operating in 5 GHz radio band to avoid interference with b or g network devices

- Wireless access security features including WPA, WPA2, rogue AP detection and 802.1x with RADIUS support.

Auto Detect connects to your ISP quickly; the user-friendly Web-based ProSafe Control Center conﬁguration screen and install assistant reduce setup time. With SSL VPN tunnels, users can quickly and securely access company data with just a Web browser. The IPsec VPN wizard automates IPsec VPN conﬁguration and secure remote makes it simple to connect to multiple sites. Support for DHCP (client and server) as well as PPPoE allows for widespread deployment. The SRXN3205 is compatible with Windows

, UNIX®, Macintosh®, and Linux® OS.

1-888-NETGEAR (638-4327) Email: info@NETGEAR.com

http://www.mercadoactual.es

ProSafe® Wireless-N VPN Firewall SRXN3205

ProSafe Wireless-N

VPN Firewall

SRXN3205

Remoe Access via

SSL VPN Tunnel

Protocol Redirection

Remoe Access via

SSL Application Proxy

ProSafe Dual

WAN VPN Firewall

FVX538

ProSafe SSL VPN

Concentrator 25

SSL312

Users

Remote Office Main Office

Internet

Us e a s i m p l e We b b r o W s e r t o b U i l d a n ssl Vpn t U n n e l - n o s e p a r a t e c l i e n t s o f t W a r e n e e d e d !

SSL VPN tunnel built through a dissolvable browser-based client on the taskbar

http://www.mercadoactual.es

ProSafe® Wireless-N VPN Firewall SRXN3205

Technical Speciﬁcations

Client System Requirements•

2.4 GHz 802.11n draft speciﬁcations or –

2.4 GHz 802.11b/g wireless adapter Microsoft Windows Vista –

, XP, 2000,

98, Me, Apple OSX, UNIX, Linux Internet Explorer 6.0, Mozilla Firefox –

Wireless •

IEEE 802.11n draft 2.0 spec, 2.4 GHz – and 5.0 GHz

IEEE 802.11a 5.0 GHz – IEEE 802.11g, IEEE 802.11b, 2.4 GHz – Wi-Fi Protected Access –

(WPA, WPA2)

with TKIP and AES Wired Equivalent Prviacy (WEP) 64 bit, –

128-biy encryptions for IEEE 802.11b and 802.11g

IEEE 802.1x RADIUS authentication with – EAP TLS, TTLS, PEAP

2 dipole antennas – 1 patch antenna – Three (3) reverse SMA antenna connectors –

SPI Firewall•

Stateful packet inspection –

- prevents DoS attacks

- stealth mode

- user support: unrestricted Keyword ﬁltering on: –

- address

- service (FTP, SMTP, HTTP, RPL, SNMP, DNS, ICMP, NNTP, POP3, SSH)

- protocol

- Web UTL port / service blocking

- ActiveX, Java, Javascript Port/Service Blocking –

IPsec VPN Functionality•

5 dedicated IPsec VPN tunnels – Manual and Internet Key Exchange –

Security Association (IKE SA) assignment

- preshared key signature

- RSA/DSA signature Key life & IKE lifetimes time settings – Perfect forward secrecy – Difﬁe-Hellman groups 1 and 2 – Oakley Support – Operating modes –

- main

- aggressive Fully qualiﬁed domain name (FQDN support) –

for dynamic IP address VPN connections

1.5

IPsec Support•

DES (56 bit), 3DES(168 bit), AES – (256 bit) encryption algorithm

MD5 or SHA-1 hashing algorithm – ESP support – PKI features with x.509 v.3 certiﬁcate –

support remote access VPN (client-to-site), –

site-to-site VPN IPsec NAT traversal (VPN pass-through) –

SSL VPN Functionality•

5 dedicated SSL VPN tunnels – SSL version support: SSLv3 and TLS1.0 – SSL encryption support: DES, 3DES, –

ARC4, AES (ECB, CBC, XCBC, CNTR) 128/256 bit

SSL message integrity: MD5, SHA-1, – MAC-MDS/SHA-1, HMAC-MD5/SHA-1

Certiﬁcate Support: –

- RSA

- Difﬁe-Hellman

- Self-signed

Routing Modes of Operation•

Many-to-one Multi-network Address – Translation (NAT)

Classical routing –

IP Address Assignment•

Static IP address assignment – Internal DHCP server of LAN – DHCP client on WAN – PPoE client support –

Throughput•

LAN-to-WAN: 60 Mbps – Connections: 20,000 concurrent –

sessions VPN throughput: 20 Mbps –

HW Speciﬁcations•

Dimensions: 252.7 x 179.5 x 35.1 mm – (9.95 x 7.07 x 1.38 in)

Weight: 1.34 kg (2.95 lb) – Processor speed: 300 MHz – Memory: 64 MB RAM, 16 MB ﬂash – Power supply: Output 12V/18W –

Environmental Speciﬁcations•

Operating temperature: 0° - 40° C – (32° - 104° F)

Operating humidity: 90% maximum – relative humidity

Physical Interfaces•

1 Gigabit Ethernet RJ45 WAN – 4 Gigabit Ethernet RJ45 LAN –

Management Features

Administration Interface•

SNMP (v2c) support – Web graphic user interface – Secure Sockets Layer (SSL) remote –

management User name and password protected – Secure remote management support –

authenticated through IP address (or IP address range) and password

Conﬁguration changes/upgrades – through Web GUI

Logging•

SYSLOG – Email alerts –

Functions•

VPN Wizard to simplify conﬁguration of – IPsec VPNs

Auto Detect to automatically detect ISP – address type (static, dynamic, PPPoE)

Port range forwarding – Port triggering – Enable/disable WAN ping – DNS proxy – MAC address cloning/spooﬁng – Network Time Protocol NTP support – Diagnostic tools (ping, DNS lookup, –

trace route, other) Port/service – Auto-Uplink on switch ports – L3 Quality of Service (QoS) –

LAN-to-WAN and WAN-to-LAN (ToS) –

Package Contents

ProSafe Wireless-N VPN Firewall – (SRXN3205)

Two (2) 5 dBi antennas and one (1) – 3 dBi antenna

Ethernet cable – Power adapter – User guide – Resource CD with single-user ProSafe –

VPN Client Software license Waranty/support information card –

http://www.mercadoactual.es

ProSafe® Wireless-N VPN Firewall SRXN3205
