ProSAFE Gigabit Quad WAN SSL VPN Firewall SRX5308
Reference Manual
April 2013
202-10536-05
350 East Plumeria Drive
San Jose, CA 95134
USA
ProSAFE Gigabit Quad WAN SSL VPN Firewall SRX5308
Support
Thank you for selecting NETGEAR products.
After installing your device, locate the serial number on the label of your product and use it to register your product
at https://my.netgear.com. You must register your product before you can use NETGEAR telephone support.
NETGEAR recommends registering your product through the NETGEAR website. For product updates and web
support, visit http://support.netgear.com.
Phone (US & Canada only): 1-888-NETGEAR.
Phone (Other Countries): Check the list of phone numbers at
http://support.netgear.com/general/contact/default.aspx.
Trademarks
NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered trademarks of
NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries. Information is subject to change
without notice. © NETGEAR, Inc. All rights reserved.
Revision History
Publication
Part Number
202-10536-05 – April 2013 Added the following features:
202-10536-04 1.0 July 2012 A major revision. Added the following features:
Version Publish Date Comments
• Auto-rollover support with failure detection for IPv6 WAN
interfaces (see Configure Auto-Rollover for IPv6 Interfaces
and Create an IPv6 Gateway-to-Gateway VPN Tunnel with
the Wizard)
• Multicast pass-through with alternate networks (see Configure
Multicast Pass-Through for IPv4 Traffic)
• SNMP access from the WAN and SNMP trap events (see Use
a Simple Network Management Protocol Manager)
• Option to define what constitutes a UCP flood attack (see
Attack Checks)
• Authentication and encryption for the PPTP server (see
Configure the PPTP Server)
• Authentication for the L2TP server (see Configure the L2TP
Server)
• Option to select a gateway when you ping or send a trace
packet and option to select a VPN policy when you ping or
send a trace packet through a VPN tunnel (see Send a Ping
Packet and Trace a Route)
• Support for IPv6 with multiple IPv6 features, including a new
general menu structure that provides both IPv4 and IPv6
radio buttons (very extensive revisions throughout the
manual)
• IPSec VPN autoinitiate support (see Manually Add or Edit a
VPN Policy)
• SNMPv3 support (see Use a Simple Network Management
Protocol Manager)
• Option to reboot with a different firmware version (see Select
the Firmware and Reboot the VPN Firewall)
• Extensive list of factory default settings (see Appendix A,
Default Settings and Technical Specifications)
2
ProSAFE Gigabit Quad WAN SSL VPN Firewall SRX5308
202-10536-03 1.0 November 2011 Incorporated nontechnical edits only (there are no feature
changes).
202-10536-02 1.0 July 2011 Added new features that are documented in the following
sections:
• Configure WAN QoS Profiles
• Inbound Rules (Port Forwarding) and Create LAN WAN
Inbound Service Rules
• Attack Checks
• Set Limits for IPv4 Sessions
• Create IP Groups
• Use the NETGEAR VPN Client Wizard to Create a Secure
Connection
• Manually Create a Secure Connection Using the NETGEAR
VPN Client
• Configure the ProSafe VPN Client for Mode Config Operation
• Configure Date and Time Service
• Configure and Enable the LAN Traffic Meter
202-10536-01 1.0 April 2010 Initial publication of this reference manual.
3
