Netgear SC101T Reference Guide
Storage Central T urbo Model SC101T
and Storage Central Model SC101
User Manual
NETGEAR, Inc.
4500 Great America Parkway
Santa Clara, CA 95054 USA
202-10174-01
December 2006
© 2006 by NETGEAR, Inc. All rights reserved. FullManual.
Technical Support
Please register to obtain technical support. Please retain your proof of purchase and warranty information.
To register your product, get product support or obtain product information and product documentation, go to
http://www.netgear.com. If you do not have access to the World Wide Web, you can register your product by filling
out the registration card and mailing it to NETGEAR customer service.
You will find technical support information at:
http://www.netgear.com/support/main.asp through the customer service area. If you want to contact technical
support by telephone, see the support information card for the correct telephone number for your country.
Trademarks
NETGEAR is a registered trademark of NETGEAR, INC. Windows is a registered trademark of Microsoft Corporation.
Other brand and product names are trademarks or registered trademarks of their respective holders. Information is
subject to change without notice. All rights reserved.
Hard Drive Not Included
A hard drive is not included with this NETGEAR product. You are solely responsible for the selection, purchase and
installation of your own hard drive. By using this NETGEAR product, you understand and agree that (i) NETGEAR is
not warranting your hard drive or its contents; and (ii) NETGEAR is not responsible under any circumstances for any
damage to or loss of contents that results from the misuse or failure of any hard drive with the NETGEAR product,
regardless of the cause of such damage or loss. In certain circumstances data loss may be permanent and unrecoverable
and therefore you are highly encouraged to separately maintain a backup copy of any data that you store on such hard
drive(s).
Statement of Conditions
In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to
make changes to the products described in this document without notice. NETGEAR does not assume any liability that
may occur due to the use or application of the product(s) or circuit layout(s) described herein.
Federal Communications Commission (FCC) Compliance Notice:
Radio Frequency Notice
Storage Central Turbo SC101T and Storage Central SC101
Tested to Comply
with FCC Standards
Note: Changes or modifications not expressly approved by NETGEAR, Inc. could void the user's authority to operate
this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
• This device may not cause harmful interference.
ii
FOR HOME OR OFFICE USE
v1.0, December 2006
• This device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation.
Product and Publication Details
Model Number: SC101T and SC101
Publication Date: December 2006
Product Family: storage area network
Product Name: Storage Central Turbo SC101T and Storage Central SC101
Home or Business Product: Home
Language: English
Publication Part Number: 202-10174-01
v1.0, December 2006
iii
iv
v1.0, December 2006
Contents
About This Manual
Conventions, Formats and Scope .....................................................................................v
How to Use This Manual .................................................................................................. vi
How to Print this Manual ...................................................................................................vii
Chapter 1
About the Storage Central
Hard Drive Not Included .................................................................................................1-1
SC101T Front Panel and LEDs ......................................................................................1-2
SC101T Rear Panel ........ .... ... ... ... .... ... ... ... .... ... ... .......................................... ... ... .... ... ... ..1-3
SC101 Front Panel and LEDs ........................................................................................1-4
SC101 Rear Panel ..........................................................................................................1-4
Chapter 2
Installation
Preparing for Installation .................................................................................................2-1
Requirements ............................................ .......................................... ..................... 2-1
Package Contents ....................................................................................................2-2
Planning a Location for the Storage Central ............................................................2-2
Installing the Storage Central Manager Utility ................................................................2-3
Using the Status Bar and Context-Sensitive Help .................................................... 2-4
Installing the Storage Central Turbo SC101T Hardware .................................................2-5
Installing a Disk and Connecting the SC101T ..........................................................2-5
Installing the Storage Central SC101 Hardware .............................................................2-7
Verifying the Hard Disk “Cable Select” Setting .........................................................2-8
Installing a Hard Disk and Connecting the SC101 ................................................... 2-8
Chapter 3
Working with Network Drives
Creating a Network Drive with the Wizard .......................... ... .... ... ... ... .... ... ... ... ... .... ... ... ..3-1
Attaching a Shared Drive to Other PCs .............................. ... .... ... ... ...............................3-3
Managing Existing Drives ...................................... ... .... ... ... ... .... ... ... ... .... ... ... ..................3-3
v1.0, December 2006
i
Chapter 4
Managing Your Data Storage
Storage Central File Format ...........................................................................................4-1
Understanding Network Connection Speed ....................................................................4-2
File Transfer Performance ..............................................................................................4-3
Tips for File Transfers ..............................................................................................4-3
Restricting Access to Your Data .....................................................................................4-4
Storage Central Administrator Password .................................................................4-4
Organizing Your Data Storage ........................................................................................4-4
Mapping Drive Letters to the Hard Disks .................................................................4-5
Identifying Which Disk is Which ...............................................................................4-5
Checking Storage Central Status ....................................................................................4-5
Advanced Configuration Options ....................................................................................4-6
Creating or Managing Drives ...................................................................................4-8
Viewing and Attaching an Available Drive ................................................................4-8
Chapter 5
Maintenance and Troubleshooting
Restarting Your Network .................................................................................................5-1
Rebooting or Resetting the Storage Central .......................... .... ... ... ... .... ... ... ... ... .... ... ... ..5-2
Windows Removable Disk Message ........................................................................5-2
Receiving Product Updates ............................................................................................5-3
Using the Firmware Upgrade Feature ......................................................................5-3
Locating the Serial Number ............................................................................................5-4
Ejecting a Hard Disk from the Storage Central Turbo SC101T .......................................5-4
Removing Storage Central Software from a PC .............................................................5-5
Automatic Installation Screen When Rebooting a PC ..............................................5-5
Basic Functioning ...........................................................................................................5-5
Checking Power .......................................................................................................5-5
Power LED Error Codes ...........................................................................................5-6
Accessing the Storage Central .......................................................................................5-6
Frequently Asked Questions About Accessing Drives ...................................................5-7
Common Problems and Solutions ..................................................................................5-9
Cannot Create a Mirror .................................................................................................5-10
Removing Mirroring from a Drive ..................................................................................5-11
ii
v1.0, December 2006
Appendix A
Specifications and Storage Technology Standards
Factory Default Settings ................................................................................................ A-1
Technical Specifications ................................................................................................ A-2
Understanding Storage Technology Standards ..................... .... ... ... ... .... ... ... ... ... .... ... .... A-2
Self-Certifying File System (SFS) ........................................................................... A-2
New Technology File System (NTFS) ..................................................................... A-3
SAN and Network Attached Storage (NAS) ............................................................ A-3
Appendix B
Related Documents
v1.0, December 2006
iii
iv
v1.0, December 2006
About This Manual
The Storage Central Turbo Model SC101T and Storage Central Model SC101 User Manual
describes how to install, configure and troubleshoot the Storage Central Turbo SC101T and
Storage Central SC101. The information in this manual is intended for readers with intermediate
computer and Internet skills.
Conventions, Formats and Scope
The conventions, formats, and scope of this manual are described in the following paragraphs:
• Typographical Conventions. This manual uses the following typographical conventions:
Italics Emphasis, books, CDs, URL names
Bold User input
Fixed Screen text, file and server names, extensions, commands, IP addresses
• Formats. This manual uses the following formats to highlight special messages:
Note: This format is used to highlight information of importance or special interest.
Tip: This format is used to highlight a procedure that will save time or resources.
Warning: Ignoring this type of note may result in a malfunction or damage to the
equipment.
Danger: This is a safety warning. Failure to take heed of this notice may result in
personal injury or death.
v1.0, December 2006
v
Storage Central Turbo Model SC101T and Storage Central Model SC101 User Manual
• Scope. This manual is written for the Storage Central according to these specifications:
Product Version Storage Central Turbo SC101T and Storage Central SC101
Manual Publication Date December 2006
For more information about network, Internet, firewall, and VPN technologies, see the links to the
NETGEAR website in Appendix B, “Related Documents”.
Note: Product updates are available on the NETGEAR, Inc. website at
http://kbserver.netgear.com/products/SC101T.asp and
http://kbserver.netgear.com/products/SC101.asp.
How to Use This Manual
The HTML version of this manual includes the following:
• Buttons, and , for browsing forwards or backwards through the manual one page
at a time
• A button that displays the table of contents and an button. Double-click on a
link in the table of contents or index to navigate directly to where the topic is described in the
manual.
• A button to access the full NETGEAR, Inc. online knowledge base for the product
model.
• Links to PDF versions of the full manual and individual chapters.
vi
v1.0, December 2006
Storage Central Turbo Model SC101T and Storage Central Model SC101 User Manual
How to Print this Manual
To print this manual you can choose one of the following several options, according to your needs.
• Printing a Page in the HTML View.
Each page in the HTML version of the manual is dedicated to a major topic. Use the Print
button on the browser toolbar to print the page contents.
• Printing a Chapter.
Use the PDF of This Chapter link at the top left of any page.
– Click the PDF of This Chapter link at the top left of any page in the chapter you want to
print. The PDF version of the chapter you are viewing opens in a browser window.
– Your computer must have the free Adobe Acrobat reader installed in order to view and
print PDF files. The Acrobat reader is available on the Adobe Web site at
http://www.adobe.com.
– Click the print icon in the upper left of the window.
Tip: If your printer supports printing two pages on a single sheet of paper, you can
save paper and printer ink by selecting this feature.
• Printing the Full Manual.
Use the Complete PDF Manua l link at the top left of any page.
– Click the Complete PDF Manual link at the top left of any page in the manual. The PDF
version of the complete manual opens in a browser window.
– Click the print icon in the upper left of the window.
Tip: If your printer supports printing two pages on a single sheet of paper, you can
save paper and printer ink by selecting this feature.
v1.0, December 2006
vii
Storage Central Turbo Model SC101T and Storage Central Model SC101 User Manual
viii
v1.0, December 2006
Chapter 1
About the Storage Central
You can use the Storage Central to increase storage, share files, or back up files.
• Disk storage: Expand the amount of disk storage available to one or more PCs on you network.
• Share files: Share music, pictures, or movies with members of your household.
• Back up data: Back up data from multiple computers to a Storage Central unit then use a
backup system to conveniently create safe backup copies of all your data and software:
– Windows backup: Use Windows back up features to back up your data or th e Windows
system files on the Storage Central disk. Then, back up the data on the Storage Central to
other media such as tape or DVD. See Windows help for instructions.
– Use a dedicated backup system: Use a dedicated backup system that uses media that can
be easily stored, and easily used to restore information form your backup. Examples
include tape or DVD medial that provide inexpensive and flexible mass data storage
formats suitable for backup and storing in a safe location
Hard Drive Not Included
A hard drive is not included with this NETGEAR product. You are solely responsible for the
selection, purchase and installation of your own hard drive. By using this NETGEAR pro duct, you
understand and agree that (i) NETGEAR is not warranting your hard drive or its contents; and (ii)
NETGEAR is not responsible under any circumstances for any damage to or loss of contents that
results from the misuse or failure of any hard drive with the NETGEAR product, regardless of the
cause of such damage or loss. In certain circumstances data loss may be permanent and
unrecoverable and therefore you are highly encouraged to separately maintain a backup copy of
any data that you store on such hard drive(s).
1-1
v1.0, December 2006
Storage Central Turbo Model SC101T and Storage Central Model SC101 User Manual
SC101T Front Panel and LEDs
The front panel of the Storage Central Turbo SC101T is shown and described in the following
table.
SC101T Front Panel LED Description
Power (green) • Off: No power.
• On: Power is on and the power-on self-test is
finished.
• For Power LED error codes, see “Power LED
Error Codes” in Chapter 5.
Hard disk (blue) • Off: No activity or turned off.
• On: Disk activity.
Ethernet (green) • Off: No power or no activity
• On: Powered on but no data traffic
Figure 1-1
• Blink: Data traffic
1-2
v1.0, December 2006
Storage Central Turbo Model SC101T and Storage Central Model SC101 User Manual
SC101T Rear Panel
The Storage Central Turbo SC101T rear panel is shown and described in the following table.
SC101T Rear Panel Item Description
Power
connector
Ethernet
port with LEDs
latches
Reset
button
On/Off
button
Power connector Connects to the SC101T power adapter
Ethernet port with
LEDs
Reset button You can use the rest button to reboot the Storage
Figure 1-2
On/Off button Turn the Storage Central on or off.
Use this port to connect to an Ethernet LAN.
The port has a green LED and a yellow LED to
indicate Ethernet LAN Link Activity.
• Green off: No power, or connected to 10/100Mbps
Ethernet LAN.
• Green on: Connected to 1Gbps Ethernet LAN.
• Green blinking: Data traffic on the 1Gbps
Ethernet LAN.
• Yellow off: No power, or connected to 1Gbps
Ethernet LAN.
• Yellow on: Connected to 10/100Mbps Ethernet
LAN.
• Yellow blinking: Data traffic on the 10/100Mbps
Ethernet LAN.
Central, or to reset it to factory default settings.
• Reboot: Push and release to reboot.
• Reset: Push and hold for eight or more seconds to
reset the Storage Central to factory defaults. This
restores the password for administrator to
“password”, and detaches all drives.
v1.0, December 2006
1-3
Storage Central Turbo Model SC101T and Storage Central Model SC101 User Manual
SC101 Front Panel and LEDs
The Storage Central SC101 front panel and LEDs are shown and described in the following table.
Use a coin or screwdriver to open the spring loaded front cover lock by turning it clockwise.
SC101 Front Panel LED Description
Hard Disk (red) • Off: No activity or turned off.
• On: Disk activity.
• On: Power is on and it has completed its
power on self test diagnostic.
• For Power LED error codes, see “Power LED
Error Codes” in Chapter 5
• On: Powered on but no data traffic
• Blink: Data traffic
Figure 1-3
front
cover
lock
Power (green) • Off: No power.
Ethernet (green) • Off: No power or no activity
SC101 Rear Panel
The Storage Central SC101 rear panel is shown and described in the following table.
SC101 Rear Panel Item Description
Power connector Connects to the SC101T power adapter
Power
connector
Figure 1-4
1-4
Ethernet port with
LEDs
Reset button You can use the rest button to reboot the Storage
Reset
button
Ethernet
port with LEDs
v1.0, December 2006
Use this port to connect to an Ethernet LAN.
The port has a green LED and a yellow LED to indicate
Ethernet LAN Link Activity.
• Green off: No power or no Ethernet link detected.
• Green on: Ethernet link detected.
• Yellow off: No power or no Ethernet link detected.
• Yellow blink: Data traffic on the Ethernet LAN
Central, or to reset it to factory default settings.
• Reboot: Push and release to reboot.
• Reset: Push and hold for eight or more seconds to
reset the Storage Central to factory defaults. This
restores the password for administrator to “password”,
and detaches all drives.
Storage Central Turbo Model SC101T and Storage Central Model SC101 User Manual
v1.0, December 2006
1-5
Storage Central Turbo Model SC101T and Storage Central Model SC101 User Manual
1-6
v1.0, December 2006
Loading...
