Data Sheet | RR3312 / RR4312 X
ReadyNAS 3312/4312X Series Network Attached Storage
State-of-the-art Performance
and Data Protection
ReadyNAS 3312 and 4312X are best-inclass high performance network attached
storage systems. The RR4312X has two
built-in 10 Gigabit Ethernet interfaces
to further meet the storage demands
of next generation business networks.
Featuring an architecture powered by
blazing fast quad-core 5th generation
Intel Xeon processors along with DDR4
ECC memory that is expandable up to
64GB, the RR3312 and RR4312 are the
no compromise, high performing data
storage systems of choice for businesses
that need the very best in capacity,
performance and security.
ReadyNAS brings state-of-the-art data
storage and protection technologies in
an affordable and easy-to-use system to
the SMB. All ReadyNAS are built on the
revolutionary ReadyNAS OS 6 operating
system and next-gen BTRFS le system.
A best-in-class 5 levels of data protection
- X-RAID, Unlimited Snapshots, Bit rot
protection, real-time anti-virus and easy
offsite replication work in concert to securely
protect your data from common risks.
All ReadyNAS systems utilize proprietary
ReadyCLOUD technology. With
ReadyCLOUD, remotely accessing and
Key Business Features and Solutions
• Automatic Backup & Sync: Using the
ReadyCLOUD app for PC, scheduled
protection is easier than ever before
• Bit Rot Protection: A proprietary
technology protecting your les from
unplanned degradation
• Unlimited Snapshots: Unlimited data
snapshot capability for on-box
protection and exible data recovery
• X-RAID & Instant Provisioning: Easily
expand capacity and feel condent
knowing that data is always protected
• Cloud-managed Replication: Maintain
data sets in multiple locations or ensure
protection of data from remote
or branch ofce locations
• iSCSI and Thin Provisioning: Powerful
tools for a businesses taking advantage
of virtual infrastructures
• Anti-virus & Encryption: Keep data
protected from outside threats and safe
from prying eyes
• Modern GUI and ReadyCLOUD
Management: Sleek, modern interface
that puts the tools you need, where and
when you need them
sharing les in your own secure private
cloud has never been easier. No VPN
setup, no port forwarding, no dynamic
DNS required. Designed specically
for the unique needs of business users,
RR3312 and RR4312X are virtualizationready with iSCSI support, thin provisioning
capability and VMware certied.
To maximize storage capacity, an SAS
expansion card (RRSASEXP-10000S) can
be purchased separately for expansion
support. Expansion chassis from
NETGEAR, EDA2000 and EDA4000, offer
12 and 24 bay expansion, respectively.
• File Server: Unied storage platform for
sharing les between Windows, Mac
and Linux-based computers
• Backup: RAID redundancy with
automatic expansion and unlimited data
snapshots for point-in-time restore
• Disaster Recovery: Cloud-managed
replication for maintaining multiple sets
of data and performing easy restores in
case of disaster
• Virtualization: Thin provisioning, iSCSI
support and certied with VMware
PAGE 1 of 9
Data Sheet | RR3312 / RR4312 X
ReadyNAS 3312/4312X Series Network Attached Storage
ReadyNAS Rackmount Comparison
Hardware ReadyNAS 3312 ReadyNAS 4312S ReadyNAS 4312X
Intel Xeon E3-1225v6
3.3GHz
CPU-10000S
CPU-20000S
Memory 8GB DDR4 ECC 16GB DDR4 ECC 16GB DDR4 ECC
Memory Expansion 64GB DDR4 64GB DDR4 64GB DDR4
Drive Bays 12 12 12
Drive Types Supported SATA/SSD 2.5” or 3.5” SATA/SSD 2.5” or 3.5” SATA/SSD 2.5” or 3.5”
Hot Swappable Drives Yes Yes Yes
eSATA Ports 2 2 2
SAS Ports for Expansion Chassis (sold separately) 2 2 2
Gigabit LAN Ports 4 4 4
10Gbps LAN Optical SFP+ 0 2 0
10Gbps LAN Copper 10GBase-T 0 0 2
USB Ports 2x USB3.0 2x USB3.0 2x USB3.0
Power Supply
Chassis Warranty
Fan (mm) 3 x 80 3 x 80 3 x 80
Dimensions DxWxH (mm) 707 x 445 x 88 707 x 445 x 88 707 x 445 x 88
Weight (diskless) (kg) 11.96 11.96 11.96
Software and Functionality ReadyNAS 3312 ReadyNAS 4312S ReadyNAS 4312X
Certication and Compatibility
Cloud-discovery, Setup and Management Yes Yes Yes
Data Protection with Unlimited Snapshots Yes Ye s Ye s
Web-managed Replication for Disaster Recovery Yes Yes Yes
Real-time Antivirus Yes Yes Yes
iSCSI and Thin Provisioning Yes Yes Yes
Quad Core Processor,
Max Turbo Speed
3.7GHz
Intel Xeon E3-1225v6
3.3GHz, Max Turbo
Speed 3.7GHz
Dual Redundant
Internal 550 W; input
100-240V AC,
50-60Hz
5 years including
5 years Next
Business Day hard-
ware replacement
VMware vSphere
ESXi 6.0
Intel® Xeon E31245v6 3.5GHz
Quad Core, Hyper
Threaded Processor,
Max Turbo Speed
3.9GHz
Intel Xeon E3-1245v6
3.5GHz, Max Turbo
Speed 3.9GHz
Dual Redundant
Internal 550 W; input
100-240V AC,
50-60Hz
5 years including
5 years Next
Business Day hard-
ware replacement
VMware vSphere
ESXi 6.0
Intel® Xeon E31245v6 3.5GHz
Quad Core, Hyper
Threaded Processor,
Max Turbo Speed
3.9GHz
Intel Xeon E3-1245v6
3.5GHz, Max Turbo
Speed 3.9GHz
Dual Redundant
Internal 550 W; input
100-240V AC,
50-60Hz
5 years including
5 years Next
Business Day hard-
ware replacement
VMware vSphere
ESXi 6.0
PAGE 2 of 9
Technical Specications
Data Protection (Backup & Replication)
• Unlimited block-based snapshots for continuous data protection
• Restore Snapshots to any point in time
• Restore Snapshot data from local admin GUI, ReadyCLOUD, or native Windows File Explorer
• Scheduled and manual snapshots
• File Synchronization (rsync)
• Encrypted Remote Replication
• Data compression
• Cloud managed Remote Replication (ReadyNAS to ReadyNAS). No licenses required for ReadyNAS OS 6
devices.
• AES 256-bit volume based encryption
• X-RAID (automatic single volume online expansion)
• Single Disk, JBOD
• RAID Levels: 0, 1, 5, 6, 10, 50, 60
• RAID Global Hot Spare
• Backup to external storage (USB/eSATA)
• Apple Time Machine support
• Amazon Cloud Drive synchronization (requires Amazon account)
• ReadyNAS Vault™ Cloud backup (optional service)
• Dropbox™ le synchronization (requires Dropbox account)
• Real-time Anti-Virus scanning using signature and heuristic algorithms. (No end-user licenses required)
Protec tion for viruses, malware, worms, and Trojans.
• Bitrot automatic detection & correction for degraded media
Storage Area Networks (SAN), Virtualization
• Unlimited iSCSI LUN Snapshot
• Thin or thick provision LUNs
• Multi-LUN per target
• LUN mapping and masking
• SPC-3 Persistent Reservation (iSCSI)
• MPIO and MC/S (iSCSI)
• Max # iSCSI Target: 256
• Max # iSCSI LUN: 256
• VMware vSphere 6
• Citrix XenServer 6
• Windows Server 2008 Hyper-V
• Windows Server 2008 Failover Clustering
• Windows Server 2012 R2
Data Sheet | RR3312 / RR4312 X
ReadyNAS 3312/4312X Series Network Attached Storage
PAGE 3 of 9
ReadyNAS 3312/4312X Series Network Attached Storage
ReadyCLOUD (cloud access to ReadyNAS
• ReadyCLOUD portal based data access and management
• Upgrade rmware remotely
• VPN qualit y remote data transfer and management
• Share data with friends & co-workers directly from portal
• Share le via email link
ReadyCLOUD Client Applications
• ReadyCLOUD client applications for Apple OS X, Microsoft Windows, Android, and Apple iOS
• VPN qualit y remote data transfer and management
• Simple remote access through ReadyCLOUD client (no rewall or router conguration needed)
• Sync les/folders between PC (Mac/Windows) & ReadyNAS
• Sync les/folders between multiple PCs and ReadyNAS
• Sync les/folders between multiple users and ReadyNAS
• Backup les/folders from PC to ReadyNAS
File System & Transfer Protocols
• ReadyNAS OS 6.5 or later
• Linux 4.x
• Internal File System: BTRFS
• External File System: EXT3, EXT4, NTFS, FAT32, HFS+
• Copy-on-write le system
• Microsoft Network (CIFS/SMB 3)
• Apple OS X (AFP 3.3)
• Linux/Unix (NFS v4)
• Internet (HTTP)
• Secure Internet (HTTPS)
• File Transfer Protocol (FTP)
• FTP over SSL / TLS (explicit)
• FTP Passive mode with por t range setup
• FTP Bandwidth control
• FTP Anonymous
• FTP Transfer Log
• Secure Shell (SSH)
• Web Authoring (WebDAV)
• Storage Array Net work (iSCSI)
• File Synchronization (rsync)
• Local web le manager
Data Sheet | RR3312 / RR4312 X
PAGE 4 of 9
Users/Groups
Management
System Monitoring
Data Sheet | RR3312 / RR4312 X
ReadyNAS 3312/4312X Series Network Attached Storage
• Max # Users: 8192
• Max # User Groups: 8192
• Max # Share Folder: 1024
• Max # Concurrent Connections: 1024
• Share Folder Level ACL Support
• Advanced Folder Permissions with Subfolder ACL support for CIFS/SMB, AFP, FTP
• Microsoft Active Directory (AD) Domain Controller Authentication
• Local access list
• ReadyCLOUD based ACL
• Domain user login via CIFS/SMB, AFP, FTP
• ReadyCLOUD cloud based discovery and management
• RAIDar local discovery agent (Windows/Mac)
• Save and restore system conguration (clone devices)
• Local event log
• Local Graphical User Inter face (GUI) Languages: English, German, French, Japanese, Chinese (Traditional &
Simplied), Russian, Swedish, Portuguese, Italian, Spanish, Polish, Czech, Dutch, Korean
• Unicode support
• Volume Management
• Thin provision Shares and LUNs
• Instant Provisioning/Expansion with data protection
• Restore to factory default
• Operating Systems suppor ted: Microsoft Windows 7, 8/8.1, 10, Microsoft Windows Server 2008 R2/2012,
Apple OS X, Linux/Unix, Solaris, Apple iOS, Google Android
• Supported Web Browsers (Microsoft Internet Explorer 9+, Microsof t Edge, Mozilla Firefox 14+, Google
Chrome 50+, Apple Safari 5+)
• Device capacity, performance, resource and health monitoring
• Bad block scan
• Hard Drive S.M.A.R.T.
• File System Check
• Disk Scrubbing
• Disk Defragment
• Volume balance
• Alerts (SMTP email, SNMP, local log)
• Auto-shutdown (hard drive, fan, UPS)
• Auto-restart on power recover y
PAGE 5 of 9
Networking Protocols
• TCP/IP
• IPv4
• IPv6
• Static IP Address
• Dynamic IP Address
• Multiple IP Settings
• DHCP Client
• UPnP Discovery
• Bonjour Discovery
• Link Aggregation IEEE 802.3ad
• Port Trunking (balanced round robin, ac tive backup, balance xor, broadcast, 802.3ad link aggregation LACP,
• Hash Types IEEE 802.3ad LACP or XOR (Layer 2, Layer3, Layer 4)
• Jumbo Frames
• Static routes
• Secure Shell (SSH)
• Simple Net work Management Protocol v2, v3
• Network Time Protocol (NTP
Media
• ReadyDLNA (UPnP DLNA Media Server)
• ReadyDLNA streams to any compliant device including Playstation and Xbox
• ReadyDLNA mobile clients for remote media streaming (iOS, Android)
• ReadyDLNA suppor ted music formats (wav, wma, pcm, ogg, mp3, m4a, ac, aac)
• ReadyDLNA supported photo formats (jpg, jpeg)
• ReadyDLNA suppor ted video formats (3gp, mp4, wmv, xvid, vob, ts, tivo, mts, mpeg, mpg, mp4, mov, mkv,
• ReadyDLNA suppor ted playlist formats (pls, m3u)
• ReadyNAS Surveillance (free trial, license required) supports over 70 brands and 1600 models of IP cameras
• iTunes Server
• iTunes supported audio formats (mp3, m4a, m4p, wav, aif)
• iTunes supported video formats (m4v, mov, mp4)
• iTunes supported playlist formats (m3u, wpl)
• TiVo Archiving
• Plex Media Server streams to DLNA and Plex clients (mobile, desk top, Android TV, Roku, Samsung & LG TVs)
Data Sheet | RR3312 / RR4312 X
ReadyNAS 3312/4312X Series Network Attached Storage
transmit load balancing, adaptive load balancing)
m4v, m4p, m2t, m2ts, v, c, a, divx, avi, asf)
PAGE 6 of 9
Hardware
Compliance
Data Sheet | RR3312 / RR4312 X
ReadyNAS 3312/4312X Series Network Attached Storage
CPU
• ReadyNAS 3312: Intel® Xeon E3-1225v5 3.3GHz Quad Core Processor, Max Turbo Speed 3.7GHz
• ReadyNAS 4312S: Intel® Xeon E3-1245v5 3.5GHz Quad Core, Hyper Threaded Processor, Max Turbo Speed
3.9GHz
• ReadyNAS 4312X: Intel® Xeon E3-1245v5 3.5GHz Quad Core, Hyper Threaded Processor, Max Turbo Speed
3.9GHz
Memory
• ReadyNAS 3312: 8GB DDR4 ECC
• ReadyNAS 4312S:16GB DDR4 ECC
• ReadyNAS 4312X:16GB DDR4 ECC
• Memory Expansion: 64GB DDR4
• Flash: 256MB for OS
• 12 Hot Swappable Drive Bays
• Drive Types Supported: SATA /SSD 2.5” or 3.5”
• Two e SATA por t s
• Two USB3.0 por ts
• Total solution capacity: 120TB w/o expansion 600TB w/ 2 x EDA4000
• RR4312X: dual 10GbE copper ports
• RR4312S: dual 10GbE SFP+ por ts
• Quad Gigabit Ethernet por ts with link aggregation and failover
• LEDs: Power, System, 4 x LAN
• Three 80mm fans
• Dimensions (DxWxH):707mm x 445mm x 88mm
• Weight (diskless): 11.96 kg
• Dual 550 watt redundant power supplies
• Power cord localized to country of sale
• Rackmount sliding rail included
• ENGR 10049 EST Environmental Stress Test Guideline
• ENGR 10045 EVT Engineering Validation Test Guideline
• ENGR 10048 CVT Compliance Validation Test Guideline
• ENGR 10046 System Validation Test Guideline
• ENGR 10023 HALT Accelerated Life Test Guideline
• ENGR 10036 CDG Component Derating Guideline
PAGE 7 of 9
Environment
ProSUPPORT
Accessories
Add-on Applications
Data Sheet | RR3312 / RR4312 X
ReadyNAS 3312/4312X Series Network Attached Storage
• Noise levels: <49dBA @ 25C
• Operating Temperature: 0-45C
• Operating Humidity: 20-80% relative humidity, non-condensing
• Smart Fan
• Scheduled Power on/off
• UPS Support
• Network UPS with SNMP Management
• Wake on LAN
• Hard drive disk spin down
• Auto-power on (after shutdown)
• AC Input Power Voltage 100V to 240V
• Power Frequency: 50Hz to 60Hz, Single Phase
• Power Consumption (Max /Wake on LAN) RR3312: 210/9.2 watts
• Power Consumption (Max /Wake on LAN) RR4312S: 210/9.2 watts
• Power Consumption (Max /Wake on LAN) RR4312X: 210/9.2 watts
• Certication: FCC Class A, CE Class A, RoHS, VCCI Class A
• MTBF: 70,723 hours
• OnCall 24x7 (1-year: PMB0314, 3-year: PMB0334, 5-year: PMB0354)
• RTRAY04-10000S: Replacement/additional 3.5” or 2.5” hard drive tray
• RFAN04-10000S: Replacement 80mm fan
• RRAIL03-10000S: Replacement/additional sliding rack mount rail
• RPSU03-10000S: Replacement/additional 550W power supply unit
• RMEM04-10000S: Replacement 8GB memory module for RR3312 and RR4312X
• RMEM05-10000S:16GByte DDR4 ECC U-DIMM 2R x8 Memory Expansion, applicable to RR3312, RR4312X and
RR4312S
• RRSASEXP-10000S: SAS Expansion card
• One click installation of add-on applications direc tly through local GUI
• Application available for productivity, media, backup, surveillance, and many others
• NETGEAR applications include Sur veillance, Photo Sharing, Advanced conguration tools
• Partner applications include BitTorrent Sync, Plex, Memeo, DVBlink
• Communit y applications include Transmission, ownCloud, qBittorent, MySQL, VPN server, Syslog,
Wordpress, joomla, Media Wiki, and others
• Application availability subject to change
• Applications may impact overall performance
• Software Development Kit (SDK) available for 3rd party developers
PAGE 8 of 9
Data Sheet | RR3312 / RR4312 X
ReadyNAS 3312/4312X Series Network Attached Storage
Industry-leadIng 5-year Hardware warranty
5-year next-business-day replacement,
90 day complimentary technical support
NETGE AR, the NETGEAR Logo, ProSUPPORT, ReadyNAS, ReadyCLOUD, ReadyNAS Vault, and X-RAID are trademarks of NETGEAR, Inc. in the United States and/or other
countries. Other brand names mentioned herein are for identication purposes only and may be trademarks of their respective holder(s). Information is subject to change
without notice. © 2019 NETGEAR, Inc. All rights reserved.
NETGE AR, Inc. 350 E. Plumeria Drive, San Jose, CA 95134-1911 USA, 1-888-NETGEAR (638-4327), E-mail: info@NETGEAR.com, www.NETGEAR.com
DS -3312 /4312S/4 312X -16Oc t19
PAGE 9 of 9
Loading...
