Whole Home AC3000 Tri-band WiFi System
Data Sheet
RBK52W
Overview
This Orbi WiFi System comes with an Orbi
WiFi Router and two Orbi Wall Plug Satellites
that deliver unparalleled WiFi coverage. It
covers homes up to 5,500 square feet with
strong WiFi signals. Innovative Tri-band WiFi
helps maximize the Internet speeds available
in your home.
Enjoy better WiFi. Everywhere.
Features
Single Network Name.
One WiFi name and seamless
roaming for your whole home
to enjoy.
Your Home & Yard. Covered.
This kit of an AC3000 Router &
two AC2200 Satellites covers up
to a 5,500 sq † home with highperformance WiFi.
Max Internet Speeds.
Innovative Tri-band WiFi helps
deliver fast Internet speeds even
as more devices connect.
Easy Setup.
Use the Orbi app or a web browser
to create secure whole home WiFi in
minutes. With no accounts to setup.
PAGE 1 OF 5
Whole Home AC3000 Tri-band WiFi System
House Diagram
5,500 Square Feet of Orbi WiFi Coverage
> 150 Mbps
Internet speed over
5,500sq range
1
Orbi Wal l Plug
Satellite
DE DI CAT ED TR I- BA ND CO NNE CT IO N
DE DI CAT ED TR I- BA ND CO NNE CT IO N
Orbi Rou ter
Orbi Wal l Plug
Satellite
Data Sheet
RBK52W
INTERNET
Dedicated Tri-band Connection ensures devices connect directly to maximum Internet speeds
1
Internet plan and devices that support these speeds are required.
Simple setup from your
smartphone or tablet.
Use the Orbi app to set up and manage
your network. To find the app, scan one
of the following QR codes or search for
NETGEAR Orbi in the Apple App Store
or Google Play Store.
INTERNET
PAGE 2 OF 5
Whole Home AC3000 Tri-band WiFi System
S
existing modem
enabled devices
Data Sheet
RBK52W
Orbi Router (RBR50)
Orbi Wall Plug Satellite (RBW30)
ync button USB 2.0 port
Plugs into
Plugs into Ethernet-
Power button
PAGE 3 OF 5
Whole Home AC3000 Tri-band WiFi System
Data Sheet
RBK52W
What Do I Need for Orbi to Work?
• High-speed Internet connection
• Connect to existing modem or gateway
What’s In the Box?
• One (1) Orbi Router (RBR50)
• Two (2) Orbi Wall Plug Satellites (RBW30)
• One (1) 2m Ethernet cable
• One (1) 12V/3.5A power adapter
• Quick start guide
Physical Specifications
• Orbi Router (RBR50)
- Dimensions: 6.7 x 3.1 x 8.89 in
- Weight: 1.96 lb
• Orbi Wall Plug Satellites (RBW30)
- Dimensions: 3.3 x 3.0 x 6.34 in each
- Weight: 0.67 lb each
PAGE 4 OF 5
Whole Home AC3000 Tri-band WiFi System
Data Sheet
RBK52W
Wireless Connectivity
• Single WiFi SSID
• Guest WiFi SSID available
• Orbi Router
AC3000 Simultaneous Tri-Band WiFi
- WiFi Band 1: 400Mbps @ 2.4GHz
- WiFi Band 2: 866Mbps @ 5GHz
- WiFi Band 3: 1733Mbps @ 5GHz (dedicated
backhaul)
Tx/Rx: 2x2 (2.4GHz) + 2x2 (5GHz) + 4x4 (5GHz)
dedicated backhaul
IEEE® 802.11a/b/g/n/ac
• Orbi Wall-plug Satellites (2)
AC2200 Simultaneous Tri-Band WiFi
- WiFi Band 1: 400Mbps @ 2.4GHz
- WiFi Band 2: 866Mbps @ 5GHz
- WiFi Band 3: 866Mbps @ 5GHz (dedicated
backhaul)
Tx/Rx: 2x2 (2.4GHz) + 2x2 (5GHz) + 2x2 (5GHz)
dedicated backhaul
IEEE® 802.11a/b/g/n/ac
• MU-MIMO capable for simultaneous data
streaming
• Implicit & Explicit Beamforming for 2.4GHz & 5GHz
bands
• WiFi Security- WPA/PSK2
• Processor Router & Satellites
Powerful Quad-Core 710MHz processor
• Memory
Router: 4GB flash and 512MB RAM
Satellites: 128MB flash and 256MB RAM
• Antenna
Router: Six (6) high-performance internal antennas
with high-power amplifiers
Satellite: Four (4) high-performance internal
antennas
• Ports – Orbi Router
Four (4) 10/100/1000Mbps Gigabit Ethernet
ports
- One (1) WAN & three (3) LAN
- One (1) 2.0 USB port
• Router power on/o switch
• Push button WPS support
This product comes with a limited warranty that is valid only if purchased from a NETGEAR authorized reseller.
*
90-day complimentary technical support following purchase from a NETGEAR authorized reseller.
†
Maximum wireless signal range derived from IEEE standard 802.11 specifications. Actual data throughput and data over distance will vary. Network conditions and
environmental factors, including volume of network traffic, building material and construction, and network overhead, result in lower actual data throughput rate and
wireless coverage.
1
Internet plan and devices that support these speeds are required.
For regulatory compliance information, visit http://www.NETGEAR.com/about/regulatory
For indoor use only.
NETGEAR, the NETGEAR Logo, and Orbi are trademarks and/or registered trademarks of NETGEAR, Inc. Any other trademarks mentioned herein are for reference purposes only.
©2017 NETGEAR, Inc.
NETGEAR, Inc. 350 E. Plumeria Drive, San Jose, CA 95134-1911 USA, www.NETGEAR.com/support D-RBK52W-2
PAGE 5 OF 5
