NetAlly AR5BHB112 User Manual

AirMagnet 3x3 PCI Express Card

READ ME FIRST

Fluke Networks AirMagnet 802.11 a/b/g/n Wireless PCI Express Card

The AirMagnet 802.11a/b/g/n Wireless PCI Express
Card (C1096) is an 802.11n compliant wireless client
(based on the Atheros AR9380-AL1A using 3Tx/3Rx
architecture) for your notebook PC with an available
ExpressCard/34 (34 mm wide) slot .

Whether deploying a new 802.11n network, or
integrating 802.11n technology into an existing
infrastructure, AirMagnet solutions (AirMagnet WiFi
Analyzer and AirMagnet Survey) are critical for
measuring the impact of 802.11n,modeling deployment
scenarios, and optimizing ongoing security and
performance management. The products let
organizations effectively deploy the latest 3 x 3 802.11n
networks by offering the only independent view of the
access points, client and surrounding environment.

The AirMagnet 802.11a/b/g/n Wireless PCI Express Card has been optimized for use with the
AirMagnet Mobile products for efficient and accurate 802.11n deployment, monitoring and
troubleshooting.

This card supports 3 x 3 configuration allowing users to design, deploy and troubleshoot Wi-Fi networks
that employ APs with three spatial streams and deliver performance at data rates up to 450 Mbps.

Supported Operating Systems

Microsoft® Windows 7™ Professional/Ultimate/Enterprise (64-bit).

Supported Standards

 802.11b – Max 11Mbps (2.4 GHz)
 802.11g – Max 54Mbps (2.4 GHz)
 802.11a – Max 54Mbps (5 GHz)
 802.11n – Max 450 Mbps(2.4 GHz and 5 GHz, 20 MHz and 40 MHz bandwidth)

Frequency Range

 USA: 2.400 ~ 2.483GHz, 5.15 ~ 5.35GHz, 5.725 ~ 5.825GHz
 Europe: 2.400 ~ 2.483GHz, 5.15 ~ 5.35GHz, 5.47 ~ 5.725GHz

AirMagnet 3x3 PCI Express Card

Read Me First

06/2013

AirMagnet 3x3 PCI Express Card

READ ME FIRST

Host Interface

PCI Express interface in 3Tx/3Rx design

Temperature

 Operation temperature: 0 to 60 degrees Celsius
 Storage temperature: -20 to 80 degrees Celsius

Operation Voltage

3.3V +/- 5%

Installation

1. Attach the included antennas and cable to the 3x3 card.

2. Use the included velcro strip to adhere the 3x3 card to the laptop .

3. Plug the cable into the PCI adapter.

4. Insert the PCI adapter into the PCI slot on the laptop.

5. Download and run the AirMagnet driver installation package. The AirMagnet driver installation

package is located at the Fluke Networks web site after signing-in to your My AirMagnet account.

https://airmagnet.flukenetworks.com/my_airmagnet/public/documents/.

Technical Support

Fluke Networks’ Gold Support is our comprehensive support and maintenance program that offers

expanded coverage for all AirMagnet products.

Benefits of the Gold Support program include:

 Access to live 24 X 7 technical support.
 Highly trained technical experts to help with product installation, configuration, best practices &

troubleshooting on call 24 hrs a day including weekends and through the night.

 Multilingual technical support team.
 Free software updates/upgrades (new features and product enhancements) when available
 Hardware support, repair and replacement for AirMagnet products*

* Must meet terms and conditions as defined in the hardware warranty

 Free access to “AirMagnet Certified Professional” web-based training for certain AirMagnet

products.

 MAC Address Reset assistance.

Contact Customer Support

 Sign-in to MyAirMagnet to access the “Exclusive” Gold-member only phone numbers for

your region.
