Neovo X-19E User Guide
X-15E, X-17E & X-19E LED-Backlit Display
User Manual
TABLE OF CONTENTS
Safety Information
FCC Declaimers ....................................................................................................................................... 4
WEEE ....................................................................................................................................................... 5
Precautions
Notice ....................................................................................................................................................... 6
Cautions When Setting Up ....................................................................................................................... 6
Cautions When Using ............................................................................................................................... 7
Cleaning and Maintenance ....................................................................................................................... 7
Notice for the LCD Display ....................................................................................................................... 8
Chapter 1: Product Description
1.1 Package Contents .............................................................................................................................. 9
1.2 Wall Mounting Installation Preparation ............................................................................................... 10
1.2.1 Wall Mounting .......................................................................................................................... 10
1.2.2 Removing the Base Stand....................................................................................................... 10
1.3 LCD Display Overview ....................................................................................................................... 11
1.3.1 Front View and Keypad Buttons .............................................................................................. 11
1.3.2 Rear View ................................................................................................................................ 12
Chapter 2: Making Connections
2.1 Connecting the Power ........................................................................................................................ 13
2.2 Connecting Input Source Signals ....................................................................................................... 14
2.2.1 Connecting a Computer .......................................................................................................... 14
Using VGA Cables ......................................................................................................................... 14
Using DVI Cables ........................................................................................................................... 14
Using DisplayPort Cables .............................................................................................................. 15
Connecting an Audio Device .......................................................................................................... 15
2.2.2 Connecting a Video Device ..................................................................................................... 16
Using HDMI Cables ........................................................................................................................ 16
Chapter 3: Using the LCD Display
3.1 Turning on the Power ......................................................................................................................... 17
3.2 Selecting the Input Source Signal ...................................................................................................... 17
3.3 Adjusting the Volume .......................................................................................................................... 18
3.4 Locking the OSD Menu ...................................................................................................................... 18
3.5 Using Picture-in-Picture (PIP) ............................................................................................................ 19
3.5.1 PIP Options ............................................................................................................................. 19
3.5.2 PIP Swap ................................................................................................................................. 20
3.6 Using Auto Adjustment Function ........................................................................................................ 20
Chapter 4: On Screen Display Menu
4.1 Using the OSD Menu ......................................................................................................................... 21
4.2 OSD Menu Tree ................................................................................................................................. 23
2
TABLE OF CONTENTS
Chapter 5: Adjusting the LCD Display
5.1 BRIGHTNESS .................................................................................................................................... 26
5.2 COLOUR TEMP. ................................................................................................................................. 28
5.3 IMAGE SETTING ............................................................................................................................... 29
5.4 ASPECT RATIO .................................................................................................................................. 32
5.5 PIP SETTING ..................................................................................................................................... 33
5.6 ANTI-BURN-IN ................................................................................................................................... 35
5.7 OSD SETTING ................................................................................................................................... 36
5.8 AUDIO SETTING ................................................................................................................................ 37
5.9 SYSTEM ............................................................................................................................................. 38
5.10 ECO SMART .................................................................................................................................... 40
5.11 INPUT SELECT ................................................................................................................................ 41
Chapter 6: Appendix
6.1 Warning Messages ............................................................................................................................. 42
6.2 Troubleshooting .................................................................................................................................. 43
6.3 Transporting the LCD Display ............................................................................................................ 45
Chapter 7: Specications
7.1 Display Specications ........................................................................................................................ 46
7.2 Display Dimensions ............................................................................................................................ 47
7.2.1 X-15E Dimensions..................................................................................................................... 47
7.2.2 X-17E Dimensions..................................................................................................................... 47
7.2.3 X-19E Dimensions..................................................................................................................... 47
3
SAFETY INFORMATION
Safety Information
This FCC Class-B compliant digital device
complies with the Interference-Causing
Equipment Regulations of Canada.
FCC Declaimers
This device complies with Section 15 of the FCC listing. The
operation procedures must meet the following conditions: (1)
the device must not cause any damaging interference; and (2)
this device must accept any received interference, including any
unpredictable interference that may possibly occur.
Dear users,
This device has passed the Class B digital service regulations and
complies with Section 15 of the FCC listing; these are intended to
provide reasonable warranty against damaging interference for
home use. This device will produce, use, and emit radio frequency
energy; therefore, installation or use without following the instructions
given may cause damaging interference to radio communication.
Nonetheless, it is not possible to state with certainty that interference
will occur from specic installations. If this device has caused
damaging interference to radio or TV signals (simply turn the device
on and off to check if such interference is caused by the device), we
recommend that you x the interference using the following methods:
• Readjust the direction or location of the antenna.
• Increase the distance between this device and the receiver.
• Consult your local dealer or an experienced radio/TV technician.
Warning:
Making changes or modications to
the device without the permission
from an authorized dealer may void
the warranty of this device.
4
SAFETY INFORMATION
WEEE
Information for users applicable in European Union countries.
The symbol on the product or its packaging signies that this product has to be
disposed separately from ordinary household wastes at its end of life. Please
kindly be aware that this is your responsibility to dispose electronic equipment at
recycling centers so as to help conserve natural resources. Each country in the
European Union should have its collection centers for electrical and electronic
equipment recycling. For information about your recycling drop off area, please
contact your local related electrical and electronic equipment waste management
authority or the retailer where you bought the product.
5
PRECAUTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Symbols used in this manual
This icon indicates the existence of a potential hazard that could result in personal injury
or damage to the product.
This icon indicates important operating and servicing information.
Notice
• Read this User Manual carefully before using the LCD display and keep it for future reference.
• The product specications and other information provided in this User Manual are for reference only. All
information is subject to change without notice. Updated content can be downloaded from our web site at
http://www.agneovo.com.
• To register online, go to http://www.agneovo.com.
• To protect your rights as a consumer, do not remove any stickers from the LCD display. Doing so may
affect the determination of the warranty period.
Cautions When Setting Up
Do not place the LCD display near heat sources, such as a heater, exhaust vent, or in direct
sunlight.
Do not cover or block the ventilation holes in the housing.
Place the LCD display on a stable area. Do not place the LCD display where it may subject
to vibration or shock.
Place the LCD display in a well-ventilated area.
Do not place the LCD display outdoors.
Do not place the LCD display in a dusty or humid environment.
Do not spill liquid or insert sharp objects into the LCD display through the ventilation holes.
Doing so may cause accidental re, electric shock or damage the LCD display.
6
PRECAUTIONS
Cautions When Using
Use only the power cord supplied with the LCD
display.
The power outlet should be installed near the LCD
display and be easily accessible.
If an extension cord is used with the LCD display,
ensure that the total current consumption plugged
into the power outlet does not exceed the ampere
rating.
Do not allow anything to rest on the power cord. Do
not place the LCD display where the power cord
may be stepped on.
If the LCD display will not be used for an indenite
period of time, unplug the power cord from the
power outlet.
To disconnect the power cord, grasp and pull by the
plug head. Do not tug on the cord; doing so may
cause re or electric shock.
Do not unplug or touch the power cord with wet
hands.
Warning:
Unplug the power cord
from the power outlet and
refer to qualied service
personnel under the following
conditions:
♦ When the power cord is
damaged.
♦ If the LCD display has been
dropped or the housing has
been damaged.
♦ If the LCD display emits smoke
or a distinct odor.
Cleaning and Maintenance
The LCD display comes with NeoVTM Optical
Glass. Use a soft cloth lightly moistened with a mild
detergent solution to clean the glass surface and the
housing.
Do not rub or tap the surface of the glass with sharp
or abrasive items such as a pen or screwdriver. This
may result in scratching the surface of the glass.
Do not attempt to service the LCD display yourself,
refer to qualied service personnel. Opening or
removing the covers may expose you to dangerous
voltage or other risks.
Warning:
Ceiling mount or mount
on any other horizontal
surface overhead are not
advisable.
Installation in contravention of
the instructions may result in
undesirable consequences,
particularly hurting people and
damaging property. Users who
have already mounted the
display on the ceiling or any
other horizontal surface overhead
are strongly advised to contact
AG Neovo for consultations and
solutions to help ensure a most
pleasurable and fullling display
experience.
7
PRECAUTIONS
Notice for the LCD Display
In order to maintain the stable luminous performance, it is recommended to use low brightness setting.
Due to the lifespan of the lamp, it is normal that the brightness quality of the LCD display may decrease
with time.
When static images are displayed for long periods of time, the image may cause an imprint on the LCD
display. This is called image retention or burn-in.
To prevent image retention, do any of the following:
• Set the LCD display to turn off after a few minutes of being idle.
• Use a screen saver that has moving graphics or a blank white image.
• Switch desktop backgrounds regularly.
• Adjust the LCD display to low brightness settings.
• Turn off the LCD display when the system is not in use.
Things to do when the LCD display shows image retention:
• Turn off the LCD display for extended periods of time. It can be several hours or several days.
• Use a screen saver and run it for extended periods of time.
• Use a black and white image and run it for extended periods of time.
When the LCD display is moved from one room to another or there is a sudden change from low to high
ambient temperature, dew condensation may form on or inside the glass surface. When this happens, do
not turn on the LCD display until the dew disappears.
Due to humid weather conditions, it is normal for mist to form inside the glass surface of the LCD display.
The mist will disappear after a few days or as soon as the weather stabilizes.
There are millions of micro transistors inside the LCD display. It is normal for a few transistors to be
damaged and to produce spots. This is acceptable and is not considered a failure.
8
CHAPTER 1: PRODUCT DESCRIPTION
Chapter 1: Product Description
1.1 Package Contents
When unpacking, check if the following items are included in
the package. If any of them is missing or damaged, contact your
dealer.
LCD Display
Quick Start Guide
X-15E, X-17E & X-19E
Quick Start Guide
X-15E, X-17E & X-19E LED-Backlit Display
www.agneovo.com
X-15E/X-17E/X-19E_Quick Guide_V010
Power cord
Audio cable
Power adapter
VGA cable
Warranty card
Note:
Must use only the supplied power
adapter:
♦ Lite-on Technology Corporation
Model no.: PA-1041-81
Rating: 12V/3.33A
Note:
♦ The pictures are for reference
only. Actual items may vary
upon shipment.
9
PRODUCT DESCRIPTION
mm
1.2 Wall Mounting Installation Preparation
1.2.1 Wall Mounting
1 Remove the base stand.
See procedures below.
2 Wall mount the LCD display.
Screw the mounting bracket to the VESA holes at
the rear of the LCD display.
100
mm
100
mm
75
mm
1.2.2 Removing the Base Stand
1 Carefully place the
product screen side
down on a cushioned
surface that will
protect product and
screen from damage.
2 Remove the screws
securing the base
stand from the LCD
display.
3 Detach the base
stand.
4 Lock screws back.
75
Note:
To protect the glass panel, place a
towel or soft cloth before laying the
LCD display down.
Warning:
Ceiling mount or mount
on any other horizontal
surface overhead are not
advisable.
Installation in contravention of
the instructions may result in
undesirable consequences,
particularly hurting people and
damaging property. Users who
have already mounted the
display on the ceiling or any
other horizontal surface overhead
are strongly advised to contact
AG Neovo for consultations and
solutions to help ensure a most
pleasurable and fullling display
experience.
Note:
Take measures to prevent the
LCD display from falling down
and lessen possible injury and
damage to the display in case of
earthquakes or other disasters.
♦ Use only the 75 x 75 mm and
100 x 100 mm wall mount kit
recommended by AG Neovo.
♦ Secure the LCD display on a
solid wall strong enough to bear
its weight.
10
PRODUCT DESCRIPTION
1.3 LCD Display Overview
1.3.1 Front View and Keypad Buttons
2
3
1
Display screen
1
The LCD display screen is protected by
TM
NeoV
SOURCE
2
• Press repeatedly to select the input signal
MENU
3
• Press to display the OSD menu.
• Press again to hide the OSD menu.
UP
4
• Press repeatedly to select PIP option.
• During OSD menu selection, press to move
DOWN
5
• Press to swap the PIP main and sub picture.
• During OSD menu selection, press to move
Optical Glass.
source.
up a menu or submenu.
up a menu or submenu.
10
LEFT
6
• Press to decrease the volume.
• During OSD menu selection, press to adjust the
settings.
RIGHT
7
• Press to increase the volume.
• During OSD menu selection, press to select an
option and adjust the settings.
AUTO
8
• For VGA input signal source, press to perform
auto adjustment.
• During OSD menu selection, press to close the
OSD menu or exit a submenu.
POWER / LED indicator
9
• Press to turn the power on or off.
Green - Power on
Amber - Standby mode
Off - Power off
EcoSmart sensor: Detect ambient lighting
10
conditions and automatically adjust the
brightness levels. Refer to page 40 “ECO
SMART” for more information.
4
5
6
7
8
9
11
PRODUCT DESCRIPTION
1.3.2 Rear View
AUDIO INDVIDC IN HDMIDisplayPortVGA
1 2 3 5 64
DC power input
1
Use to connect the power adapter.
DVI connector
2
Use to connect a PC using DVI cable
for digital input signal.
HDMI connector
3
Use to connect an input device using
HDMI cable for digital input signal.
DisplayPort connector
4
Use to connect a PC or video device using a
displayport cable for digital input signal.
VGA connector
5
Use to connect a PC using a VGA cable for
analogue input signal.
Audio port
6
Use to connect an audio cable for the PC’s
audio input.
12
CHAPTER 2: MAKING CONNECTIONS
2.1 Connecting the Power
1 Connect the power cord to the power adapter.
2 Connect the power adapter to the DC power input at the rear of the LCD display.
3 Connect the power cord plug to a power outlet or a power supply.
DC IN
Caution:
♦ Make sure that the LCD display is
not connected to the power outlet
before making any connections.
Connecting cables while the power
is ON may cause electric shock or
personal injury.
Caution:
♦ When unplugging the power cord,
hold the power cord by the plug
head. Never pull by the cord.
13
MAKING CONNECTIONS
2.2 Connecting Input Source Signals
2.2.1 Connecting a Computer
Using VGA Cables
Connect one end of a D-sub cable to the VGA connector of the LCD display and the other end to the D-sub
connector of the computer.
VGA
Using DVI Cables
Connect one end of a DVI cable to the DVI connector of the LCD display and the other end to the DVI
connector of the computer.
DVI
14
MAKING CONNECTIONS
Using DisplayPort Cables
Connect one end of a DisplayPort cable to the DisplayPort connector of the LCD display and the other end to
the DisplayPort connector of the computer.
DisplayPort
Connecting an Audio Device
Connect one end of an audio cable to the audio port at the rear of the LCD display and the other end to the
audio out port of the computer.
AUDIO IN
15
Loading...
