ITEM #: QTY: PROJECT:
heated food merchandiser
model : GS1405
This compact heated food merchandiser
makes it easy to grab a quick snack.
AIA FILE NO.
FUNCTIONAL FEATURES
• Adjustable thermostat
• Temperature range to above 150°F
• Non Humidified
CONSTRUCTION FEATURES
• Acrylic display
• Dual front doors
• Stainless steel base
• Overhead illumination
• 2 removable racks
It can accommodate a variety of food
products such as pretzels, cheese cups,
cookies, wrapped sandwiches,burritos,
pastries, and many more.
Thank you for your purchase | 301 Meuse Argonne Hicksville, OH 43526 • 800.782.6761 • f: 419.542.6690 • www.nemcofoodequip.com
PART NUMBER
UNLESS OTHERWISE SPECIFIED:
GLOBAL SOLUTIONS GS1405
FINISH
.005
PART DESCRIPTION
MATERIAL
.010
L:\Eng\Models\GS1405\CAD Soli dWorks\GS1405\Rev Origina l\
GS1405 SELL SHEET
FOUR PLACE DECIMAL
TOLERANCES ARE IN INCHES
FRACTIONAL 1/64
ANGULAR: 1
ONE PLACE DECIMAL .030
TWO PLACE DECIMAL .020
THREE PLACE DECIMAL
WISCO INDUSTRIES, INC.
955 MARKET ST.
OREGON, WI 53575
DEPTH
TOOLING RADIUS .008"
ALL BENDS 90 UNLESS NOTED
PART NUMBER
UNLESS OTHERWISE SPECIFIED:
GLOBAL SOLUTIONS GS1405
PART DESCRIPTION
L:\Eng\Models\GS1405\CAD Soli dWorks\GS1405\Rev Origina l\
GS1405 SELL SHEET
TOLERANCES ARE IN INCHES
FRACTIONAL 1/64
ANGULAR: 1
ONE PLACE DECIMAL .030
TOOLING RADIUS .008"
ALL BENDS 90 UNLESS NOTED
PRODUCT SHEET: GS1405
heated food merchandiser
model : GS1405
AIA FILE NO.
SPECIFICATIONS:
Width .............................................12.25"
Depth .............................................13.25"
Height ............................................18.25"
Upper Rack ............................... 11.5" x 9"
Lower Rack ...........................11.5" x 11.5"
Shipping Dimensions ............. 16" x 16" x 23"
Shipping Weight ..............................23 lbs
Voltage........................................... 120
Wattage ......................................... 300
Amps .............................................. 2.5
• Best when operated on an individual
branch circuit
• 6-ft power cord length
WIDTH
HEIGHT
DEPTH
Printed in the U.S.A. | 0217
Thank you for your purchase | 301 Meuse Argonne Hicksville, OH 43526 • 800.782.6761 • f: 419.542.6690 • www.nemcofoodequip.com
