Neff B45C52N3GB User Manual

[en] Instruction manual

Built-in oven B45C52.3GB

Ú Table of contents

[en]Instruction manual

Important safety information..................................................... 4

Causes of damage .............................................................................5

Energy and environment tips....................................................5

Saving energy......................................................................................6

Environmentally-friendly disposal.....................................................6

Your new appliance .................................................................... 6

Control panel .......................................................................................6

Operating modes ................................................................................7

Your accessories ........................................................................ 7

Accessories .........................................................................................8

Inserting accessories .........................................................................8

Shelf positions .....................................................................................8

Optional accessories .........................................................................8

Before using the appliance for the first time ...........................8

Setting the water hardness range ...................................................9

Calibrating the altitude.......................................................................9

Setting the clock .................................................................................9

Cleaning the appliance......................................................................9

Operating the appliance ..........................................................10

Switching on the appliance............................................................ 10

Selecting operating mode and temperature............................... 10

Filling and emptying the water tank ............................................. 11

Switching off the appliance............................................................11

After each use with steam assistance ......................................... 12

Automatic safety cut-out ................................................................. 12

Changing the Basic settings ...................................................12

Electronic clock........................................................................13

Clock display .................................................................................... 13

Timer .................................................................................................. 13

Cooking time .................................................................................... 13

End of operation .............................................................................. 14

Preset operation...............................................................................14

Setting the clock .............................................................................. 14

Rapid heat up...................................................................................14

Checking, correcting or deleting settings ................................... 14

Childproof lock .........................................................................15

Lock....................................................................................................15

Permanent lock ................................................................................ 15

Baking .......................................................................................15

Baking on one level......................................................................... 15

Baking on two or more levels ....................................................... 16

Baking table......................................................................................16

Tips and tricks .................................................................................. 17

Roasting and braising.............................................................. 18

Roasting............................................................................................. 18

Braising..............................................................................................18

Tables for roasting and braising...................................................18

Tips and tricks .................................................................................. 20

Low-temperature cooking .......................................................20

Using Low-temperature cooking ................................................... 20

Table for Low-temperature cooking ............................................. 21

Tips and tricks .................................................................................. 21

Grilling.......................................................................................21

Circo-roasting ...................................................................................22

Radiant grilling.................................................................................. 22

Grilling table......................................................................................22

CircoTherm® eco......................................................................23

Reheat - warming using steam ...............................................24

Defrost.......................................................................................25

Defrosting with CircoTherm® ........................................................ 25

Defrost................................................................................................ 25

Yoghurt...................................................................................... 26

AquaAssist - steam-assisted cooking.................................... 26

Switching on AquaAssist................................................................26

AquaAssist table .............................................................................. 26

Cleaning and care ....................................................................28

Cleaning the appliance exterior .................................................... 28

Cleaning the cooking compartment.............................................28

Descaling........................................................................................... 29

Self-cleaning surfaces.....................................................................30

Oven cleaning................................................................................... 30

Removing and fitting the appliance door....................................30

Cleaning the door panels............................................................... 31

Cleaning the hook-in racks ............................................................ 32

Faults and repairs ....................................................................33

Replacing the oven light bulb........................................................ 34

Changing the door seal..................................................................34

After-sales service ...................................................................34

E number and FD number ............................................................. 34

Test dishes................................................................................ 35

Produktinfo

Additional information on products, accessories, replacement parts and services can be found at www.neff-

international.com and in the online shop www.neff- eshop.com

: Important safety information

Read these instructions carefully. Only then will you be able to operate your appliance safely and correctly. Retain the instruction manual and installation instructions for future use or for subsequent owners.

This appliance is only intended to be fully fitted in a kitchen. Observe the special installation instructions.

Check the appliance for damage after unpacking it. Do not connect the appliance if it has been damaged in transport.

Only a licensed professional may connect appliances without plugs. Damage caused by incorrect connection is not covered under warranty.

This appliance is intended for domestic use only. The appliance must only be used for the preparation of food and drink. The appliance must be supervised during operation. Only use this appliance indoors.

This appliance may be used by children over the age of 8 years old and by persons with reduced physical, sensory or mental capabilities or by persons with a lack of experience or knowledge if they are supervised or are instructed by a person responsible for their safety how to use the appliance safely and have understood the associated hazards.

Children must not play with, on, or around the appliance. Children must not clean the appliance or carry out general maintenance unless they are at least 8 years old and are being supervised.

Keep children below the age of 8 years old at a safe distance from the appliance and power cable.

Always slide accessories into the cooking compartment correctly. See "Description of accessories in the instruction manual.

Risk of fire!

■

Combustible items stored in the cooking compartment may catch fire. Never store combustible items in the cooking compartment. Never open the appliance door if there is smoke inside. Switch off the appliance and unplug it from the mains or switch off the circuit breaker in the fuse box.

Risk of fire!

■

Risk of electric shock!

■

A defective appliance may cause electric shock. Never switch on a defective appliance. Unplug the appliance from the mains or switch off the circuit breaker in the fuse box. Contact the after-sales service.

Risk of burns!

The appliance will become very hot on the outside during the cleaning function. Never touch the appliance door. Allow the appliance to cool down. Keep children at a safe distance.

Causes of damage

Caution!

■ Accessories, foil, greaseproof paper or ovenware on the

cooking compartment floor: do not place accessories on the cooking compartment floor. Do not cover the cooking compartment floor with any sort of foil or greaseproof paper. Do not place ovenware on the cooking compartment floor if a temperature of over 50 ºC has been set. This will cause heat to accumulate. The baking and roasting times will no longer be correct and the enamel will be damaged.

■ Water in a hot cooking compartment: do not pour water into

the cooking compartment when it is hot. This will cause steam. The temperature change can cause damage to the enamel.

■ Moist food: do not store moist food in the cooking

compartment when it is closed for prolonged periods This will damage the enamel.

■ Fruit juice: when baking particularly juicy fruit pies, do not

pack the baking tray too generously. Fruit juice dripping from the baking tray leaves stains that cannot be removed. If possible, use the deeper universal pan.

■ Cooling with the appliance door open: only allow the cooking

compartment to cool when it is closed. Even if the appliance door is only open a little, front panels of adjacent units could be damaged over time.

■ Very dirty door seal: If the door seal is very dirty, the

appliance door will no longer close properly when the appliance is in use. The fronts of adjacent units could be damaged.Always keep the door seal clean.

■ Appliance door as a seat, shelf or worktop: Do not sit on the

appliance door, or place or hang anything on it. Do not place any cookware or accessories on the appliance door.

■ Inserting accessories: depending on the appliance model,

accessories can scratch the door panel when closing the appliance door. Always insert the accessories into the cooking compartment as far as they will go.

■ Carrying the appliance: do not carry or hold the appliance by

the door handle. The door handle cannot support the weight of the appliance and could break.

■ Aluminium foil: Aluminium foil in the cooking compartment

must not come into contact with the door glass. This could cause permanent discolouration of the door glass.

■ Baking tins: Ovenware must be heat and steam resistant.

Silicone baking tins are not suitable for combined operation with steam.

■ Ovenware with areas of rust: Do not use any ovenware which

displays areas of rust. Even the smallest spots of rust can lead to corrosion in the cooking compartment.

■ Hot water in the water tank: Hot water can damage the pump.

Only fill the water tank with cold water.

■ Descaling solution: Do not allow descaling solution to come

into contact with the control panel or other sensitive surfaces. These will damage the surfaces. If this does happen, remove the descaling solution immediately with water.

■ Cleaning the water tank: Do not clean the water tank in the

dishwasher. Otherwise, the water tank will be damaged. Clean the water tank with a soft cloth and standard washingup liquid.

Energy and environment tips

Here you can find tips on how to save energy when baking and roasting and how to dispose of your appliance properly.

Note: For this appliance, an energy consumption value has been established that meets DIN EN 50304/DIN EN 60350.

This energy consumption value is 30% below that for energy efficiency class A.

Depending on the appliance equipment, the additional NeffLight® lighting was switched off while measuring (see section: Switching off NeffLight®).

Saving energy

Only preheat the oven if this is specified in the recipe or in the operating instruction tables.

Use dark, black lacquered or enamelled baking tins. They absorb the heat particularly well.

Open the appliance door as little as possible during cooking, baking or roasting.

It is best to bake several cakes one after the other. The cooking compartment is still warm. This may reduce the baking time for the second cake.

Your new appliance

In this section, you will find information on

■ the control panel

■ the operating modes

Control panel

(OHFWURQLFFORFN

WHDPDVVLVWHGFRRNLQJ

For longer cooking times, you can switch the oven off 10 minutes before the end of the cooking time and use the residual heat to finish cooking.

Environmentally-friendly disposal

Dispose of packaging in an environmentally-friendly manner.

This appliance is labelled in accordance with European Directive 2012/19/EU concerning used electrical and electronic appliances (waste electrical and electronic equipment - WEEE). The guideline determines the framework for the return and recycling of used appliances as applicable throughout the EU.

7HPSHUDWXUHGLVSOD\

:DWHUWDQN

&ORFNIXQFWLRQEXWWRQ 5RWDU\VHOHFWRU 7HPSHUDWXUHVHOHFWRU,QIREXWWRQ

Symbol Use / meaning

Electronic clock (rapid heat up)

VarioSteam (steam-assisted cooking)

Í Î

• ž Ÿ

Operating mode selector Switching the appliance on and off

Selects the desired operating mode

Water tank For steam-assisted applications (see section: Filling and emptying the water tank)

Clock function button Selects the required clock function or Rapid heat up

Rotary selector Makes settings within a clock function or activates Rapid heat up (see section: Elec-

Pumping out remaining water

Descaling

Filling the water tank

Steam intensity low

Steam intensity medium

Steam intensity high

(see section: Electronic clock)

tronic clock)

The evaporator system and into the water tank.

Note: Do not remove the water tank until the

When the (see section: Descaling)

When this symbol tank (e.g. during descaling)

If this symbol tank as far as it will go

When this symbol

When these symbols

2SHUDWLQJPRGHVHOHFWRU

Ì symbol lights up when the remaining water is being pumped back out of the

Í symbol flashes, the appliance needs descaling

6WRS

6WDUW

%XWWRQV

Ì symbol has gone out.

Î lights up, fill the water tank or change the water in the water

Î flashes, the water tank has not been fully pushed in. Slide in the

• lights up, the steam intensity is set to low

• ž light up, the steam intensity is set to medium

• ž Ÿ light up, the steam intensity is set to high

Symbol Use / meaning

Temperature display (Basic settings)

Buttons

Ÿ Í

ƒ „

Pop-out operating knob

The rotary, temperature and operating mode selectors can all be popped out. Push the required operating knob to pop it in or out.

Info button Press briefly: displays the temperature during the heating up phase

Press and hold: calls up the Basic settings menu (see section: Changing the Basic settings)

Temperature selector sets the temperature

Changes the settings in the Basic settings menu (see section: Changing the Basic settings)

VarioSteam button Sets the required steam intensity: low, medium or high

(see section: VarioSteam - steam-assisted cooking)

Descaling button Descales the appliance

Start button Starts operation

Stop button Short press: stops operation (pause)

Press and hold: ends operation

Operating modes

Here is an overview of the operating modes of your appliance.

Operating mode Used for

3 % 0 4 + ( $

/ “ z

CircoTherm® For baking and roasting on one or more levels

Top/bottom heat For baking and roasting on one level. Especially suitable for cakes with moist toppings

(e.g. cheesecake)

CircoTherm intensive For pre-prepared frozen products and dishes which require a lot of heat from under-

neath (see section: Baking)

Circo-roasting For poultry and larger pieces of meat

Full-surface grill For large amounts of flat, small items for grilling (e.g. steaks, sausages)

Centre-area grill For small amounts of flat, small items for grilling (e.g. steaks, bread)

Bottom heat For food and baked items on which you want a crust to form, or which need more

browning on the underside. Only activate bottom heat for a short while at the end of the baking time.

Low-temperature cooking For tender pieces of meat, that are to be cooked medium/medium-rare or à point

CircoTherm® eco* For energy-efficient baking and roasting on one level, without the need to preheat.

Oven cleaning For regeneration of the self-cleaning surfaces in the cooking compartment

* Type of heating used to determine the energy efficiency class in accordance with EN50304.

Reheat For plated meals and baked items

Cooked food is gently reheated using steam. The food does not dry out.

Your accessories

In this section, you will find information on

■ Your accessories

■ the correct way to insert the accessories into the cooking

compartment

■ the shelf positions

■ the optional accessories

Accessories

The following accessories are included with your appliance:

Wire rack for baking in baking tins, roasting in roasting dishes and grilling

When inserting the baking tray or the universal pan, check

■ that the lug (a) is in the rear part of the of the accessory

■ that the sloping edge of the accessory faces towards the

appliance door when it is inserted

Universal pan, enamelled for baking moist cakes, roasting, grilling and collecting drops of liquid during cooking

Insert grid for roasting and grilling

Note: The wire insert is always used together with the universal pan. In this combination, the wire insert is placed in the universal pan.

Note: The baking tray and universal pan may become distorted when the appliance is in operation. This is caused by the considerable temperature differences acting on the accessories. These differences may occur if only a part of the accessory is covered with food, or if frozen items such as pizza are placed on the accessory.

Inserting accessories

The accessories are equipped with a locking function. The locking function prevents the accessories from tilting when they are pulled out. The accessories must be inserted into the cooking compartment correctly for the tilt protection to work properly.

When inserting the wire rack, check

■ that the lug (a) is pointing downwards

■ that the lug (a) is in the rear part of the wire rack

Shelf positions

The cooking compartment has four shelf heights. The shelf heights are counted from the bottom up.

Note: Do not use shelf height 2 when baking and roasting with 3 CircoTherm®. This will adversely affect air circulation and your baking and roasting results will not be as good.

Optional accessories

You can purchase optional accessories from the after-sales service or specialist retailers. You will find a comprehensive range of products for your appliance in our brochures and on our website.

Optional accessories Order no.

System steamer N8642X3

Grill set Z1240X2

Glass pan Z1262X0

Extra-deep pan, enamelled Z1272X0

Baking tray, non-stick Z1343X0

Roasting tray, enamelled, two-piece Z1512X0

CLOU® 1x telescopic shelf Z1701X2

CLOU® 3x telescopic shelf Z1742X2

CLOU® 4x telescopic shelf with full extension

Before using the appliance for the first time

Once your new appliance has been connected, ™…„ appears in the temperature display. Before you can use your appliance, you must make a few settings:

■ Set the water hardness range

■ Calibrate the altitude

■ Set the clock

■ Clean the appliance before using it for the first time

Note: You can correct these settings at any time. For information about changing the water hardness range and the altitude difference, see chapter: Changing the basic settings; and for information about setting the clock, see chapter: Electronic clock.

Z1755X2

Setting the water hardness range

Caution!

The appliance may become damaged due to the use of unsuitable liquids.

Do not use distilled water, highly chlorinated tap water (> 40 mg/l) or other liquids.

Only use cold, fresh tap water, softened water or uncarbonated mineral water.

The water hardness “hard“ ( the setting if the water is softer.

You can determine the water hardness with the test strips supplied or ask your water supplier.

Notes

■ If your water is very hard, we recommend that you use

softened water.

■ If you use only softened water, you can, in this case, set your

appliance to the softened water hardness range.

■ If you use mineral water, then set the water hardness range to

hard.

■ If you use mineral water, then it must be non-carbonated (see

chapter: Filling and emptying the water tank).

1. Use the temperature selector to set the water hardness

range.

™…„) is the default setting. Change

Setting the clock

Note: When you press the KJ clock function button, you have

3 seconds to set the clock using the rotary selector. Should this have been insufficient for you, you can amend the clock time later.

‹:‹‹ flashes in the clock display.

1. Briefly press the KJ clock function button to go to the

setting mode.

KJ and 3 symbols light up. ‚ƒ:‹‹ appears in the

The clock display.

2. Set the current time using the rotary selector.

Your setting is accepted after 3 seconds.

Changing the clock To subsequently change the time, press the button repeatedly until the Change the time with the rotary selector.

KJ and 3 symbols light up again.

KJclock function

Water hardness range Setting symbol (temperature dis-

softened

soft

medium

hard

2. Press and hold the ± info button for 3 seconds.

Your setting is saved. display.

play)

™…‹ ™…‚ ™…ƒ ™…„

™†‚ appears in the temperature

Calibrating the altitude

The altitude difference range “0 - 300 m“ (™†‚) is the default setting. Change this setting if the location of the appliance is higher or lower than this.

1. Use the temperature selector to set the altitude difference

range.

Altitude difference range

Under 0 m

0 - 300 m

300 - 600 m

600 - 900 m

900 - 1200 m

1200 - 1500 m

1500 - 1800 m

1800 - 2100 m

2100 - 2400 m

above 2400 m

2. Press and hold the ± info button for 3 seconds.

Your setting is saved.

Setting symbol (temperature display)

™†‹ ™†‚ ™†ƒ ™†„ ™†… ™†† ™†‡ ™†ˆ ™†‰ ™†Š

Cleaning the appliance

Clean your appliance before using it for the first time.

1. Remove the accessories from the cooking compartment.

2. Completely remove any residual packaging (e.g. bits of

polystyrene) from the cooking compartment.

3. Clean the accessories and cooking compartment with hot

soapy water (see chapter: Cleaning and care).

4. Fill water tank with 400 ml water (see chapter: Filling and

emptying the water tank).

5. Slide in the water tank all the way.

6. Using the operating mode selector set % Top/bottom

heating (see chapter: Operating the appliance).

7. Use the temperature selector to set the temperature to

240 °C.

8. Press the Ÿ AquaAssist button repeatedly until the• ž Ÿ

symbols light up (see chapter: AquaAssist - steam-assisted cooking).

9. Press the ƒ start button.

10.Switch off the appliance if the water tank is empty. To do

this, turn the operating mode selector back to the off position

Û and retract it.

The remaining water will be pumped out of the evaporator system. The

11.Emptying the water tank (see chapter: Filling and emptying

the water tank)

12.Afterwards, wipe the cooled cooking compartment with hot,

soapy water.

Note: Remove limescale with a cloth soaked in vinegar, then wipe with clean water and rub dry with a soft cloth.

13.Clean the outside of the appliance with a soft, damp cloth

and soapy water.

Ì symbol lights up.

Operating the appliance

In this section, you can read about

■ how to switch your appliance on and off

■ how to select an operating mode and temperature

■ how to fill and empty the water tank

■ when your appliance switches off automatically

Switching on the appliance

Press the operating mode selector to make it pop out.

This switches on the appliance, and it is now ready for use.

~ symbol lights up.

The

Selecting operating mode and temperature

: Risk of scalding!

by hot water. The water in the water tank may become hot. Empty the water tank before starting operating modes that are not steam-assisted.

Notes

■ You can only start the / Low-temperature cooking operating

mode when the oven has cooled down. There must be no residual heat (

■ For steam-assisted applications, you must fill the water tank

(see section: Filling and emptying the water tank).

1. Switch on the appliance.

2. Turn the operating mode selector until the desired operating

mode is selected.

• or œ) showing in the temperature display.

Operating mode Default temper-

3 CircoTherm®* % Top/bottom heat* 0 Circotherm intensive* 4 Circo-roasting* + Full-surface grill + Full-surface grill (inten-

sive)**

( Centre-area grill ( Centre-area grill (inten-

sive)**

$ Bottom heat / Low-temperature cooking “ CircoTherm® eco z Oven cleaning ä Reheating

* You can activate steam for this operating mode

** Turn the temperature selector beyond 275 °C.

in the temperature display

Changing the operating mode

1. Turn the operating mode selector until the desired operating

mode is selected.

2. Turn the temperature selector to change the temperature.

3. Press the ƒ Start button.

ature in °C

160 40 - 220

170 50 - 275

220 50 - 275

170 50 - 250

220 50 - 275

Fixed setting

180 50 - 275

Fixed setting

200 50 - 225

Fixed setting

160 40 - 200

Fixed setting

120 80 - 180

Temperature range in °C

ü ü ü

‹

‚Ÿ£ appears

3. Turn the temperature selector to change the default

temperature.

Note: If no default temperature is displayed, the temperature of your selected operating mode is set permanently. You cannot change this temperature.

4. Press the ƒ Start button.

Notes

■ Depending on the operating mode that you have selected,

you will hear a pumping noise after the operation has started. The appliance is checking whether the pumps are working correctly.

■ If you cannot start a steam-assisted application, check

whether the water tank has been filled and fully inserted.

Current temperature

Press the 3 seconds.

Note: The current temperature can only be displayed with operating modes with a default temperature.

Heating indicator

The heating indicator displays the rising temperature in the cooking compartment.

■ Temperature reached (figure A)

■ Appliance reheating (figure B)

± info button. The current temperature appears for

$ %

Filling and emptying the water tank

: Risk of injury and risk of fire!

Only fill the water tank with water or with the descaling solution that is recommended by us.

Do not pour any flammable liquids (e.g. alcoholic drinks) into the water tank.

Due to hot surfaces, vapours from flammable liquids may catch fire in the cooking compartment (explosion). The appliance door may spring open. Hot steam and jets of flame may escape.

Caution!

The appliance may become damaged due to the use of unsuitable liquids.

Do not use distilled water, highly chlorinated tap water (> 40 mg/l) or other liquids.

Only use cold, fresh tap water, softened water or uncarbonated mineral water.

Notes

■ If you use mineral water, set the water hardness to hard.

■ For hygiene reasons, a reminder message will appear after

the appliance is switched off if the water tank has not been emptied. The reminder message goes out once the water tank is empty.

Filling the water tank

Fill the water tank before each use with steam assistance.

1. Press lightly on the centre of the lower edge of the water tank

(picture A).

2. Pull out the water tank (picture B).

$ %

3. Fill the water tank with cold water up to the "max" mark

(picture C).

Emptying the water tank

Empty the water tank after each steam-assisted use of the appliance.

1. Turn the operating mode selector back to the Û off position

and push it in. The remaining water in the evaporator system is pumped

back into the water tank. The appears in the temperature display. (pumping-out). When the pumping out cycle is complete, a signal sounds and the symbol flashes.

2. Pull out the water tank slowly and level.

Î symbol goes out.

The

3. Remove the cover (Picture A).

4. Empty the water tank (Picture B).

$ %

5. Dry the tank shaft and water tank thoroughly.

6. Slide in the water tank.

The

Switching off the appliance

: Risk of scalding!

When opening the appliance door, hot steam may escape. After cooking, only open the appliance door carefully.

Note: The appliance has a cooling fan. After the appliance is switched off, the cooling fan may continue to run.

1. Turn the operating mode selector back to the off position Û.

2. Press on the operating mode selector until it retracts.

The appliance switches off. The

Note: If the appliance is switched off after steam-assisted operation, you will hear a pumping sound. The appliance is pumping the remaining water out of the evaporator system back into the water tank. During this time the Only empty the water tank when the

You can see in the temperature display whether there is high or low residual heat in the cooking compartment.

~ symbol goes out.

Ì symbol is lit.

Ì symbol is no longer lit.

4. Slide in the water tank all the way.

Note: If the

pushed in fully.

Topping up the water tank

If the water tank is empty, a signal sounds and the lights up. Steam-assisted operation is interrupted.

1. Pull out the water tank.

2. Fill the water tank up to the "max" mark and slide it in fully.

The steam-assisted operation continues.

Î symbol flashes, the water tank has not been

Î symbol

Temperature display

• œ

Ending an operation Press and hold the current operation. The appliance is not switched off. You can now start another operating mode.

Interrupting and continuing an operation (Pause) Briefly press the current operation. Press the operation.

Meaning

Residual heat high (above 120 °C)

Residual heat low (between 60 °C and 120 °C)

„ Stop button. The appliance turns off the

„ Stop button. The appliance interrupts the

ƒ Start button to continue the

+ 25 hidden pages
