Page 1
KALEA
PLUS
SLEEK DESIGN
AND HIGH PERFORMANCE
Page 2
KALEA PLUS:
HIGH SPEED, HIGH PERFORMANCE,
TOP QUALITY.
User-friendly
KALEA PLUS is easy to use, by staff and
in self-service mode. Just a touch, and
anybody can get a high quality drink.
High quality drinks
KALEA PLUS offers high-quality espresso
based drinks combined with fresh milk, thanks
to the proven Z4000 brewer and the option of
the self adjusting grinders.
Barista feeling
KALEA PLUS can be fitted with a professional
steam wand, which enables the barista to
make perfect cappuccino foam.
IoT Connectivity
KALEA PLUS has an embedded WiFi/Bluetooth
module and is 3G compatible.
Fast espresso deliveries
KALEA PLUS is fitted with a professional
rotating pump, capable of satisfying even the
busiest locations.
Page 3
KALEA PLUS
2 ES + 1 IN +
FRESH MILK
KALEA PLUS
ES + 2 IN
16 g espresso brewer
Self adjusting grinders available as an
option
Independent hot water outlet
Automatic milk frother
2 Boilers
Steam wand available as an option
2 Coffee beans hoppers (1200 g each)
1 Soluble canister (1.5 L)
Recommended daily output: 200 drinks
KALEA PLUS
ES + 2 IN +
FRESH MILK
16 g espresso brewer
Self adjusting grinders available as an
option
Independent hot water outlet
1 Boiler
1 Coffee beans hopper (1200 g)
2 Soluble canisters (1.5 L each)
Recommended daily output: 200 drinks
16 g espresso brewer
Self adjusting grinders available as an
option
Independent hot water outlet
Automatic milk frother
2 Boilers
Steam wand available as an option
1 Coffee beans hopper (1200 g)
2 Soluble canisters (1.5 L each)
Recommended daily output: 200 drinks
Page 4
Fridge (H 500 x W 290 x D 380 mm)
Fridge with cup warmer (H 550 x W 290 x D 410 mm)
Slim cup warmer with 3 shelves (H 646 x W 189 x D 400 mm)
Wooden base cabinet (H 850 x W 700 x D 600 mm)
Coffee waste discharge kit
Milk system detergent (1 L)
788 mm
586 mm
138 mm
332 mm
368 mm
603.7 mm
30
374 mm
APPROX. WEIGHT: 47 KG
ELECTRICAL CONFIGURATION: 230 / 240 V - 50 HZ
POWER: 3000 W
ACCESSORIES
Evoca S.p.A. reserves the right to alter specifications without notice.
170Max
75Min
24030 Valbrembo (BG) • Italy
www.evocagroup.com
EVOCA S.p.A.
Via Roma 24
Ph +39 035 606 111
Fax +39 035 606 560
ISO 9001: 2015
ISO 14001: 2015
BS OHSAS 18001:2007
L543K0
