High-performance, cost effective projectors
VE303X / VE303
VE303X
ANSI lumens
3,000
XGA 5.8lbs 5.8lbs
VE303
3,000 ANSI lumens SVGA
Bright high contrast images can be easily viewed in most applications. The excellent price performance ratio makes these
projectors especially suitable for classrooms and mid-sized meeting rooms.
Benefits
Great Picture Quality and Integrated Audio
High contrast images from the latest Texas Instruments DLP(R) engine featuring Brilliant
Color(TM) provides excellent detail and color accuracy. Also, features 2W built-in speaker.
Easy Connections
VE Series projectors are easily connected to computers and AV sources via HDMI, video, VGA
and audio inputs.
Free download of multi-display management software*
Innovative ECO Functions
Extended lamp life with ECO Mode(TM) technology increases lamp life up to 6,000 hours,
while lowering power consumption.
SmartSource™ 3D Ready
The projector can support the following 3D formats.
- HDMI 3D
- 120 Hz 3D (only available if your PC can output 120 Hz)
- HQFS 3D
This software is an all-in-one remote support solution that runs from a central location and provides monitoring, asset management and control functionality for a majority
of NEC display devices. It is ideal for multi-display installations over larger infrastructures.
*NaViSet Administrator 2
Specifications
UNIQUE FEATURES
Built-in wall color correction.
Advanced AccuBlend(TM) ensures detailed images when non-native
resolution sources are connected to the projector.Built-in closed captioning
enables decoding and display of text information from a video.
Kensington lock slot enables security cable to be attached to projector.
Filter-free design eliminates the hassle and time spent monitoring and / or
changing filters.
Image magnification with location control.
WARRANTY
Registered owners receive a 3 year parts and labor warranty including
InstaCare next business day exchange. The lamp is covered for one year or
1,000 hours, whichever comes first.
SHIPS WITH
Remote control, batteries, RGB cable, power cord, user’s manual on CD-ROM,
quick start guide and product registration card.
ACCESSORIES
NP01CM universal ceiling mount
SCP200 suspended ceiling plate for use with
NEC ceiling mounts
NP215CASE projector carrying case
NP40LP replacement lamp
RMT-PJ36 replacement remote control
NP02GL DLP-Link active shutter 3D Glasses
NP01MR
to control PC and MAC functions
IR mouse receiver enables PJ remote
ORDERING MODEL NUMBERS
NP-VE303
NP-VE303X
VE303X / VE303
Display Technology 0.55" DMD
Maximum input resolution 1920 x 1080 (1080p)
Native Resolution XGA 1024 x 768 / SVGA 800 x 600
Lens
Light source (Lamp)
Lamp life
Image size 30 to 300 inches
Light output
Quietness (ECO / ECO mode off ) 30 dB / 34 dB
Contrast ratio (white / black) 10,000:1 with dynamic contrast on, 2,000:1 native contrast
Synchronization range
Vertical keystone correction Manual: ± Max 40 degrees
Input terminals
Control terminals D-sub 9 pin × 1
USB port Service × 1
Built-in speaker 2 W monaural
Usage environment
Power requirements 100 to 240 V AC, 50 Hz / 60 Hz
Input current 2.5 A to 1.1 A
Power consumption (100 to 130 V
AC / 200 to 240 V AC)
Dimensions (W × H × D) 324 x 101 x 250 mm (12.8" x 4.0" x 9.9")
Weight 2.6kg / 5.8lbs
ECO mode 160 W
ECO mode off 195 W
ECO mode 6,000 H
ECO mode off 4,500 H
ECO mode off 3,000 ANSI lumens
ECO mode Approx. 85% of ECO off
Horizontal 15 kHz to 100 kHz (RGB: 24 kHz or over )
Vertical 50 Hz to 120 Hz (24 Hz: Blu-ray 24P)
Computer Mini D-sub 15 pin × 1
Video RCA × 1
HDMI HDMI × 1
Audio Stereo mini jack × 1
Operational
temperature
Storage
temperature
ECO mode off 237 W / 232 W
ECO mode 198 W / 192 W
Standby
(Normal )
Manual zoom (×1.1) / Manual focus, F = 2.41 - 2.55, f = 21.8 - 24.0 mm, Throw ratio =
1.95 - 2.15
5°C to 40°C, up to 80% humidity 41 to 104 degrees F (no condensation)
-10°C to 50°C, up to 80% humidity -4 to 122 degrees F (no condensation)
0.23 W / 0.33 W
Remote control Options Terminals
NP40LPRMT-PJ36 NP02GL
HDMI IN COMPUTER IN PC CONTROL AUDIO IN
SERVICE VIDEO IN
Replacement lamp
Advanced AccuBlend, AutoSense and ECO Mode are trademarks of NEC Display Solutions. HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC. All other brand or product names are trademarks or registered trademarks of their respective holders. Product specifications subject to change.
©2017 NEC Display Solutions of America, Inc. and the NEC logo are registered trademarks of NEC.
Cat.No. 25.NEC.80.GL.UN.221 | Rev. 12.12.2017
3D Glasses
www.necdisplay.com
