NEC V461, LCD4215, V321 User Manual

User’s Manual

MultiSync V321
MultiSync V461
MultiSync LCD4215

Downloaded From TV-Manual.com Manuals

(R)

Index

Important Information ................................................................................................................................... English-1

Warning, Caution................................................................................................................................ English-1

Registration Information ...............................................................................................................................English-1

Safety Precautions, Maintenance & Recommended Use ............................................................................ English-3

Contents ....................................................................................................................................................... English-4

Installation ....................................................................................................................................................English-5

Parts Name and Functions .......................................................................................................................... English-8

Control Panel...................................................................................................................................... English-8

Terminal Panel.................................................................................................................................... English-9

Wireless Remote Control ................................................................................................................... English-10

Operating Range for the Remote Control........................................................................................... English-11

Handling the remote control ........................................................................................................... English-11

Setup.............................................................................................................................................................English-12

Connections ................................................................................................................................................. English-14

Wiring Diagram................................................................................................................................... English-14

Connecting a Personal Computer ...................................................................................................... English-14

Connecting a DVD Player with HDMI out ........................................................................................... English-15

Basic Operation ........................................................................................................................................... English-16

Power ON and OFF Modes ................................................................................................................ English-16

Power Indicator .................................................................................................................................. English-17

Using Power Management ................................................................................................................. English-17

Selecting a video source .................................................................................................................... English-17

Picture Size ........................................................................................................................................ English-17

Picture Mode ...................................................................................................................................... English-17

Information OSD................................................................................................................................. English-18

OSD (On-Screen-Display) Controls ............................................................................................................. English-18

PICTURE............................................................................................................................................ English-19

ADJUST ............................................................................................................................................. English-19

AUDIO ................................................................................................................................................ English-20

SCHEDULE ........................................................................................................................................ English-20

PIP...................................................................................................................................................... English-20

OSD.................................................................................................................................................... English-20

MULTI DISPLAY .................................................................................................................................English-21

DISPLAY PROTECTION .................................................................................................................... English-21

ADVANCED OPTION ......................................................................................................................... English-22

Controlling the LCD monitor via RS-232C Remote Control ......................................................................... English-24

Controlling the LCD monitor via LAN Control (V321 and V461 only) ........................................................... English-25

Features .......................................................................................................................................................English-28

Troubleshooting ........................................................................................................................................... English-29

Specifications - V321 ................................................................................................................................... English-30

Specifications - V461 ................................................................................................................................... English-31

Specifications - LCD4215

Pin Assignment ............................................................................................................................................English-33

Manufacturer’s Recycling and Energy Information ...................................................................................... English-34

(R) .......................................................................................................................... English-32

Downloaded From TV-Manual.com Manuals

www.necdisplaysolutions.com

Important Information

WARNING

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT
USE THIS UNIT’S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS
THE PRONGS CAN BE FULLY INSERTED.

REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED FROM

WALL SOCKET. TO FULLY DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT THE
POWER CORD FROM THE AC OUTLET. DO NOT REMOVE COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol warns user that uninsulated voltage within the unit may have sufficient magnitude to cause
electric shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit.

This symbol alerts the user that important literature concerning the operation and maintenance of this unit
has been included. Therefore, it should be read carefully in order to avoid any problems.

CAUTION: Please use the power cord provided with this display in accordance with the table below. If a power cord is not
supplied with this equipment, please contact your supplier. For all other cases, please use a power cord that matches the
AC voltage of the power outlet and has been approved by and complies with the safety standard of your particular country.

Plug Type North America

European

Continental

U.K. Chinese Japanese

English

Plug Shape

Region

Voltage

*When operating the MultiSync LCD monitor with its AC 125-240V power supply, use a power supply cord that matches the

power supply voltage of the AC power outlet being used.

NOTE: This product can only be serviced in the country where it was purchased.

U.S.A./Canada

120* 230 220 100230

U.K. China JapanEU (except U.K.)

Registration Information

Declaration

Declaration of the Manufacturer

We hereby certify that the color monitor MultiSync
V321 (L329N8)/MultiSync V461 (L469NA)/MultiSync
LCD4215 (L429N9) are in compliance with

Council Directive 2006/95/EC:

– EN 60950-1

Council Directive 2004/108/EC:

– EN 55022
– EN 61000-3-2
– EN 61000-3-3
– EN 55024

and marked with

NEC Display Solutions, Ltd.

4-13-23, Shibaura,

Minato-Ku

Tokyo 108-0023, Japan

Downloaded From TV-Manual.com Manuals

English-1

Canadian Department of Communications Compliance Statement

DOC: This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations according to CAN/CSA C22.2 No. 60950-1.

FCC Information

1. Use the attached specified cables with the MultiSync V321 (L329N8)/MultiSync V461 (L469NA)/MultiSync LCD4215
(L429N9) color monitor so as not to interfere with radio and television reception.

(1) Please use the supplied power cord or equivalent to ensure FCC compliance.
(2) Please use the supplied shielded video signal cable, Mini D-SUB 15 pin to Mini D-SUB 15 pin.

2. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult your dealer or an experienced radio/TV technician for help.
If necessary, the user should contact the dealer or an experienced radio/television technician for additional suggestions.

The user may find the following booklet, prepared by the Federal Communications Commission, helpful: “How to Identify
and Resolve Radio-TV Interference Problems.” This booklet is available from the U.S. Government Printing Office,
Washington, D.C., 20402, Stock No. 004-000-00345-4.

Declaration of Conformity

This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions. (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.

U.S. Responsible Party: NEC Display Solutions of America, Inc.
Address: 500 Park Boulevard, Suite 1100

Itasca, Illinois 60143

Tel. No.: [phone]

Type of Product: Display Monitor
Equipment Classification: Class B Peripheral
Model: MultiSync V321 (L329N8)

MultiSync V461 (L469NA)
MultiSync LCD4215 (L429N9)

We hereby declare that the equipment specified above

conforms to the technical standards as specified in the FCC Rules.

Windows is a registered trademark of Microsoft Corporation. NEC is a registered trademark of NEC Corporation.
All other brands and product names are trademarks or registered trademarks of their respective owners.

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

Downloaded From TV-Manual.com Manuals

English-2

Safety Precautions, Maintenance & Recommended Use

FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE

FOLLOWING WHEN SETTING UP AND USING

THE MULTI-FUNCTION MONITOR:

• DO NOT OPEN THE MONITOR. There are no user
serviceable parts inside and opening or removing covers
may expose you to dangerous shock hazards or other risks.
Refer all servicing to qualified service personnel.

• Do not spill any liquids into the cabinet or use your monitor
near water.

• Do not insert objects of any kind into the cabinet slots, as
they may touch dangerous voltage points, which can be
harmful or fatal or may cause electric shock, fire or
equipment failure.

• Do not place any heavy objects on the power cord.
Damage to the cord may cause shock or fire.

• Do not place this product on a sloping or unstable cart,
stand or table, as the monitor may fall, causing serious
damage to the monitor.

• The power supply cord you use must have been approved
by and comply with the safety standards of your country.
(Type H05VV-F 3G 1mm

• In UK, use a BS-approved power cord with molded plug
having a black (13A) fuse installed for use with this monitor.

• Do not place any objects onto the monitor and do not use
the monitor outdoors.

The lamps in this product contain mercury. Please

•

2

should be used in Europe)

dispose according to state, local or federal law.

• Do not bend, crimp or otherwise damage the power cord.

• If glass is broken, handle with care.

• Do not cover vent on monitor.

• Do not use monitor in high temperature, humid, dusty, or
oily areas.

• If monitor or glass is broken, do not come in contact with the
liquid crystal and handle with care.

• Allow adequate ventilation around the monitor, so that heat
can properly dissipate. Do not block ventilated openings or
place the monitor near a radiator or other heat sources.
Do not put anything on top of the monitor.

• The power cable connector is the primary means of
detaching the system from the power supply. The monitor
should be installed close to a power outlet, which is easily
accessible.

•

Do not move or mount this product by hanging a rope or wire
to the backside handle.
Do not mount or secure this product by using the backside
handle. It may fall and cause personal injury.

• Handle with care when transporting. Save packaging for
transporting.

• Do not touch LCD panel surface while transporting,
mounting and setting. Applying pressure on the LCD panel
can cause serious damage.

• Please clean the holes of back cabinet to reject dirt and
dust at least once a year because of set reliability.

• If using the cooling fan continuously, it’s recommended to
wipe holes a minimum of once a month.

• When using a LAN cable, do not connect to a peripheral
device with wiring that might have excessive voltage.

Immediately unplug your monitor from the wall outlet and refer
servicing to qualified service personnel under the following
conditions:

• When the power supply cord or plug is damaged.

• If liquid has been spilled, or objects have fallen into the
monitor.

• If the monitor has been exposed to rain or water.

• If the monitor has been dropped or the cabinet damaged.

• If you notice any structural damage such as cracks or
unnatural wobbling.

• If the monitor does not operate normally by following
operating instructions.

Recommended Use

• For optimum performance, allow 20 minutes for warm-up.

• Rest your eyes periodically by focusing on an object at least
5 feet away. Blink often.

• Position the monitor at a 90° angle to windows and other
light sources to minimize glare and reflections.

• Clean the LCD monitor surface with a lint-free, non-abrasive
cloth. Avoid using any cleaning solution or glass cleaner!

• Adjust the monitor’s brightness, contrast and sharpness
controls to enhance readability.

•Avoid displaying fixed patterns on the monitor for long
periods of time to avoid image persistence (after image
effects).

• Get regular eye checkups.

Ergonomics

To realize the maximum ergonomic benefits, we recommend
the following:

• Use the preset Size and Position controls with standard
signals.

• Use the preset Color Setting.

• Use non-interlaced signals.

• Do not use primary color blue on a dark background, as it is
difficult to see and may produce eye fatigue due to
insufficient contrast.

Cleaning the LCD Panel

• When the liquid crystal panel is stained with dust or dirt,
please wipe with soft cloth gently.

• Please do not rub the LCD panel with hard material.

• Please do not apply pressure to the LCD surface.

• Please do not use OA cleaner as it will cause deterioration
or discolor on the LCD surface.

Cleaning the Cabinet

• Unplug the power supply

• Gently wipe the cabinet with a soft cloth

•To clean the cabinet, dampen the cloth with a neutral
detergent and water, wipe the cabinet and follow with a dry
cloth.

NOTE: The surface of the cabinet is composed of many types

of plastic. DO NOT clean with benzene thinner, alkaline
detergent, alcoholic system detergent, glass cleaner,
wax, polish cleaner, soap powder, or insecticide.
Rubber or vinyl should not be in contact with the cabinet
for an extended period of time. These types of fluids
and materials can cause the paint to deteriorate, crack
or peel.

English

Downloaded From TV-Manual.com Manuals

English-3

Contents

Your new MultiSync monitor box* should contain the following:

• LCD monitor

• Power Cord*

•Video Signal Cable

• Setup Manual

•Wireless Remote Control and AAA Batteries

1

Video Signal Cable

(Mini D-SUB 15 pin to

Mini D-SUB 15 pin)

• Main switch cover

• Clamp x 2

• Screw for clamp (M4 x 8) x 2

• Screw for main switch cover (3 x 10) x 2

• CD-ROM

Power Cord*

Screw for clamp

(M4 x 8) x 2

1

Screw for main switch

cover (3 x 10) x 2

Clamp x 2

Main switch cover

Setup Manual

CD-ROM

Setup Manual

*1Type and number of power cords included will depend on the where the LCD monitor is to be shipped. When more than

one power cord is included, please use a power cord that matches the AC voltage of the power outlet and has been
approved by and complies with the safety standard of your particular country.

* Remember to save your original box and packing material to transport or ship the monitor.

Wireless Remote Control

and AAA Batteries

Downloaded From TV-Manual.com Manuals

English-4

Installation

This device cannot be used or installed without the Tabletop
Stand or other mounting accessory for support. For proper
installation it is strongly recommended to use a trained,
NEC authorized service person. Failure to follow NEC
standard mounting procedures could result in damage to the
equipment or injury to the user or installer. Product warranty
does not cover damage caused by improper installation.
Failure to follow these recommendations could result in
voiding the warranty.

Mounting

DO NOT mount the monitor yourself. Please ask dealer.
For proper installation it is strongly recommended to use a
trained, qualified technician. Please inspect the location
where the unit is to be mounted. Mounting on wall or ceiling
is the customer’s responsibility. Not all walls or ceilings are
capable of supporting the weight of the unit. Product
warranty does not cover damage caused by improper
installation, remodelling, or natural disasters. Failure to
comply with these recommendations could result in voiding
the warranty.

DO NOT block ventilated openings with mounting
accessories or other accessories.

For NEC Qualified Personnel:

To insure safe installation, use two or more brackets to
mount the unit. Mount the unit to at least two points on the
installation location.

Please note the following when mounting
on wall or ceiling

• When using mounting accessories other than those that
are NEC approved, they must comply with the VESA­compatible (FDMlv1) mounting method.

• NEC strongly recommends
using size M6 screws
(9-10 mm + thickness
of bracket in length).
If using screws longer
than 9-10 mm, check
the depth of the hole.
(Recommended Fasten
Force: 310 - 410 N•cm)
NEC recommends mounting
interfaces that comply with
UL1678 standard in North
America.

• Prior to mounting, inspect the installation location to
insure that it is strong enough to support the weight of
the unit so that the unit will be safe from harm.

• Refer to the instructions included with the mounting
equipment for detailed information.

Weight of LCD assembly:

- MultiSync V321: 14.3 kg/31.5 lbs

- MultiSync V461: 24.0 kg/52.9 lbs

- MultiSync LCD4215

(R): 21.6 kg/47.6 lbs

Unit

9-10 mm

Screw length should equal
depth of hole (9-10 mm) + the
thickness of mounting bracket.

Mounting
Bracket

Screw

Thickness
of Bracket

Orientation

• When using the display in the portrait position, the
monitor should be rotated clockwise so that the left side
is moved to the top and the LED indicator light is on the
bottom. This will allow for proper ventilation and will
extend the lifetime of the monitor. Improper ventilation
may shorten the lifetime of the monitor.

Mounting location

• The ceiling and wall must be strong enough to support
the monitor and mounting accessories.

• DO NOT install in locations where a door or gate can hit
the unit.

• DO NOT install in areas where the unit will be subjected
to strong vibrations and dust.

• DO NOT install near where the main power supply
enters the building.

• Do not install where people can easily grab and hang
onto the unit or the mounting apparatus.

• When mounting in a recessed area, as in a wall, leave at
least 4 inches (10cm) of space between the monitor and
the wall for proper ventilation.

• Allow adequate ventilation or provide air conditioning
around the monitor, so that heat can properly dissipate
away from the unit and mounting apparatus.

Mounting on ceiling

• Ensure that the ceiling is sturdy enough to support the
weight of the unit and the mounting apparatus over time,
against earthquakes, unexpected vibrations, and other
external forces.

• Be sure the unit is mounted to a solid structure within the
ceiling, such as a support beam. Secure the monitor
using bolts, spring lock washers, washer and nut.

• DO NOT mount to areas that have no supporting internal
structure. DO NOT use wood screws or anchor screws
for mounting. DO NOT mount the unit to trim or to
hanging fixtures.

Maintenance

• Periodically check for loose screws, gaps, distortions, or
other problems that may occur with the mounting
apparatus. If a problem is detected, please refer to
qualified personnel for service.

• Regularly check the mounting location for signs of
damage or weakness that may occur over time.

English

Downloaded From TV-Manual.com Manuals

English-5

Attaching Mounting Accessories

The display is designed for use with the VESA mounting
system.

2. Using optional table top stand

CAUTION: Installing and removing the stand must be done

by two or more people.

1. Attach Mounting Accessories

Be careful to avoid tipping monitor when attaching
accessories.

V321

VESA Mounting Interface

200 mm
400 mm

NOTE: Regarding VESA mounting interface patterns on

V321, it is not centered over the Vertical Centerline
of screen as the above figure.

V461 and LCD4215(R)

VESA Mounting Interface

Installing and removing optional table top stand

To install, follow those instructions included with the stand or
mounting apparatus. Use only those devices recommended
by the manufacturer.

Handle with care when mounting LCD monitor stand and
avoid pinching your fingers.

Optional table top stand

200 mm

115 mm 85 mm

Table

Protective Sheet

NOTE: ST-3215 is for V321. Use the Thumbscrews

included with ST-3215.
ST-4020 is for V461 and LCD4215(R). (V461 and
LCD4215(R) are not mentioned in ST-4020 manual).
Before using optional table top stand, remove
installed thumbscrews from the display first.
Please use a screwdriver for removing
thumbscrews as necessary.

200 mm
400 mm

Mounting accessories can be attached with the monitor in
the face down position. To avoid damaging the screen face,
place the protective sheet on the table underneath the LCD.
The protective sheet was wrapped around the LCD in the
original packaging. Make sure there is nothing on the table
that can damage the monitor.

When using mounting accessories other than NEC
compliant and approved, they must comply with the VESA­compatible mounting method.

3. Ventilation Requirements

When mounting in an enclosed space or recessed area,
leave adequate room between the monitor and the
enclosure to allow heat to disperse, as shown below.

200 mm

Allow adequate ventilation or provide air conditioning around
the monitor, so that heat can properly dissipate away from
the unit and mounting apparatus; especially when you use
monitors in a multiple screen environment.

Downloaded From TV-Manual.com Manuals

English-6

4. Prevent Tipping

When using the display with the Tabletop Stand fasten the
LCD to a wall using a cord or chain that can support the
weight of the monitor in order to prevent the monitor from
falling. Fasten the cord or chain to the monitor using the
provided clamp and screw.

V321: 360 mm
V461: 490 mm

LCD4215(R): 475 mm

Screw Holes

English

Clamp

Screw

Cord or chain

Before attaching the LCD monitor to the wall, make sure
that the wall can support the weight of the monitor.

Be sure to remove the cord or chain from the wall before
moving the LCD.

Downloaded From TV-Manual.com Manuals

English-7

Parts Name and Functions

Control Panel

OFF ON

POWER button ( )

Switches the power on/off. See also page 16.

MUTE button

Switches the audio mute ON/OFF.

INPUT button

Acts as SET button within OSD menu. Shows Input select
menu for [DVI], [VGA], [RGB/HV], [HDMI], [DVD/HD],
[S-VIDEO], [VIDEO1], [VIDEO2].

PLUS (+) button

Acts as (+) button to increase the adjustment with OSD menu.
Increases the audio output level when the OSD menu is
turned off.

MINUS (-) button

Acts as (-) button to decrease the adjustment with OSD menu.
Decreases the audio output level when the OSD menu is
turned off.

UP ( ) button

Acts as button to move the highlighted area up to select
adjustment items within OSD menu.

DOWN ( ) button

Acts as button to move the highlighted area down to
select adjustment items within OSD menu.

EXIT button

Activates the OSD menu when the OSD menu is turned-off.
Acts as EXIT button within the OSD to move to previous
menu.

Remote control sensor and Power Indicator

Receives the signal from the remote control (when using the
wireless remote control). See also page 10.
Glows green when the LCD monitor is in active mode.
Glows red when the LCD is in POWER OFF mode.
When the LCD monitor is in POWER SAVE mode, it will
glow both green and red. When SCHEDULE is enabled, it
will blink green and glow red. See page 17. When a
component failure is detected within the monitor, the
indicator will blink red.

Main Power Switch

On/Off switch to turn main power ON/OFF. See also page 16.

Control Key Lock Mode

This control completely locks out access to all Control Key
functions. To activate the control key lock function, press both

and and hold down simultaneously for more than
3 seconds. To resume user mode, press both and and
hold simultaneously for more than 3 seconds.

Downloaded From TV-Manual.com Manuals

English-8

Terminal Panel

English

AC IN connector

Connects with the supplied power cord.

DVI IN (DVI-D)

To input digital RGB signals from a computer or HDTV
device having a digital RGB output.

* This connector does not support analog input.

VGA IN (mini D-Sub 15 pin)

To input analog RGB signals from a personal computer or
from other RGB equipment.

RGB/HV IN [R, G, B, H, V] (BNC)

To input analog RGB signals or signals from other RGB
equipment.
This is also to connect equipment such as a DVD player,
HDTV device and Set-Top-Box.
This input can be used with an RGB, DVD/HD or Video
source. Please select signal type in TERMINAL SETTING
on ADVANCED MENU.

RGB/HV RGBHV
DVD/HD Pr Y Pb
VIDEO2

RGBHV

VIDEO

RGB OUT (mini D-Sub 15 pin)

To output the signal from the VGA and RGB/HV IN
connector to an input on a separate device.

HDMI Connector

To input digital HDMI signals.

AUDIO IN 1, 2, 3

To input audio signal from external equipment such as a
computer, VCR or DVD player.

AUDIO OUT

To output the audio signal from the AUDIO IN 1, 2 and 3
jack to an external device (stereo receiver, amplifier, etc.).

VIDEO INPUT/OUTPUT Connector

VIDEO IN connector (BNC): To input a composite video

signal.
VIDEO OUT connector (BNC): To output the composite
video signal from the VIDEO IN connector.
S-VIDEO IN connector (Mini DIN 4 pin): To input the
S-VIDEO (Y/C separate signal).

EXTERNAL CONTROL (D-Sub 9 pin)

IN connector: Connect RS-232C input from external

equipment such as a PC in order to control RS-232C
functions.
OUT connector: Connect RS-232C output. To connect
multiple MultiSync monitors via RS-232C daisy Chain.

EXTERNAL SPEAKER TERMINAL

To output the audio signal from AUDIO 1, 2, 3.
Note: This speaker terminal is for optional speaker.
SP-3215 for MultiSync V321, SP4020-4620 for MultiSync
LCD4215

(R), SP-4615 for MultiSync V461.

When you use SP4020-4620 for LCD4215(R), please use
SP4020-4620 with large extension blocks (included in
speaker), as if being mounted on LCD4620. (LCD4215(R) is
not mentioned in SP4020-4620 manual).

LAN port (RJ-45) (V321 and V461 only)

LAN connection. See page 25.

Kensington Lock (V461 and LCD4215(R) only)

For security and theft prevention.

Downloaded From TV-Manual.com Manuals

English-9

Wireless Remote Control

PIP (Picture In Picture) button

ON/OFF button: Toggle switches between PIP and POP

(Picture Out Picture). See page 20.

INPUT button: Selects the “picture in picture” input signal.
CHANGE button: Replaces to the main picture and sub

picture.
NOTE: The “PIP” and “POP” modes do not function when
the screen size is “CUSTOM” or “REAL”.

DVI VGA RGB/HV HDMI DVD/HD VIDEO1 VIDEO2 S-VIDEO

DVI - -

VGA -- -

RGB/HV -- - -

HDMI - -

DVD/HD - - -

VIDEO1 ---

Main picture

VIDEO2 -- ----

S-VIDEO

PIP POP OFF

Sub picture

SBS

ASPECT

---

SBS

FULL

STILL button

ON/OFF button: Activates/deactivates still picture mode.
STILL CAPTURE button: Captures still picture.

POWER button

Switches the power on/off.

INPUT button

Shows Input select menu for [DVI], [VGA], [RGB/HV],
[HDMI], [DVD/HD], [S-VIDEO], [VIDEO1], [VIDEO2].

AUDIO INPUT button

Selects audio input source [AUDIO:1], [AUDIO:2], [AUDIO:3].

SIZE button

Selects picture size, [FULL], [NORMAL], [CUSTOM],
[DYNAMIC] and [REAL]. See page 17.

PICTURE MODE button

Selects picture mode, [HIGHBRIGHT], [STANDARD],
[sRGB], [CINEMA]. See page 17.

HIGHBRIGHT: for moving images such as DVD
STANDARD: for images
sRGB: for text based images
CINEMA: for movies.

MUTE button

Turns on/off mute function.

DISPLAY button

Turns on/off the information OSD. See page 17.

AUTO SETUP button

Enters auto setup menu. See page 19.

MENU button

Turns on/off the menu mode.

UP/DOWN button

Acts as

button to move the highlighted area up or down
to select adjustment items within OSD menu.
Small screen which adjusted “PIP” mode moves up or down.

MINUS/PLUS (-/+) button

Increases or decreases the adjustment level within OSD
menu settings.
Small screen which adjusted “PIP” mode moves left or right.

SET button

Makes selection.

EXIT button

Returns to previous menu within OSD menu.

C. C. button (V321 and V461 only)

Activates closed captioning.
Note: VIDEO1, VIDEO2, S-VIDEO inputs only.

VOLUME UP/DOWN button

Increase/decrease audio output level.

Downloaded From TV-Manual.com Manuals

English-10

Operating Range for the Remote Control

Point the top of the remote control toward the LCD monitor’s
remote sensor during button operation.

Use the remote control within a distance of about 7 m (23 ft.)
from the front of the LCD monitor’s remote control sensor or
at a horizontal and vertical angle of within 30° within a
distance of about 3.5 m (10 ft.)

Caution: Important, the remote

control system may
not function when
direct sunlight or strong
illumination strikes the remote control
sensor of the LCD monitor, or when there is
an object in the path.

English

Handling the remote control

• Do not subject to strong shock.

• Do not allow water or other liquid to splash the remote
control. If the remote control gets wet, wipe it dry
immediately.

•Avoid exposure to heat and steam.

• Other than to install the batteries, do not open the
remote control.

Downloaded From TV-Manual.com Manuals

English-11

Setup

1. Determine the installation location

CAUTION: Installing your LCD display must be done by a

qualified technician. Contact your dealer for
more information.

CAUTION:

CAUTION: Do not mount or operate the display upside

CAUTION: This LCD has a temperature sensor and cooling

MOVING OR INSTALLING THE LCD MONITOR
MUST BE DONE BY TWO OR MORE PEOPLE.
Failure to follow this caution may result in injury if
the LCD monitor falls.

down, face up, or face down.

fan. If the LCD becomes too hot, the cooling fan
will turn on automatically. If the LCD becomes
overheated while the cooling fan is running, a
“Caution” warning will appear. If the “Caution”
warning appears, discontinue use and allow the
unit to cool. Using the cooling fan will reduce the
likelihood of early circuit failure and may help
reduce image degradation and “Image
Persistance”.
If the LCD is used in an enclosed area or if the
LCD panel is covered with a protective screen,
please check the inside temperature of the
monitor by using the “HEAT STATUS” control in
the OSD (see page 21). If the temperature is
higher than the normal operating temperature,
please turn the cooling fan to ON within the
SCREEN SAVER menu within the OSD (see
page 21).

NEC recommends the following battery use:

• Place “AAA” size batteries matching the (+) and (-) signs
on each battery to the (+) and (-) signs of the battery
compartment.

• Do not mix battery brands.

• Do not combine new and old batteries. This can shorten
battery life or cause liquid leakage of batteries.

• Remove dead batteries immediately to prevent battery
acid from leaking into the battery compartment.

• Do not touch exposed battery acid as it may injure skin.

NOTE: Remove the batteries if you do not intend to use the

remote control for a long period of time.

3. Connect external equipment

(See pages 14-15)

•To protect the external equipment; turn off the main
power before making connections.

• Refer to your equipment user manual for further
information.

4. Connect the supplied power cord

• The equipment should be installed close to an easily
accessible power outlet.

• Fully insert the prongs into the power outlet socket.
A loose connection may cause image degradation.

NOTE: Please refer to the “Safety Precautions and

Maintenance” section of this manual for proper
selection of AC power cord.

IMPORTANT: Lay the protective sheet, which was wrapped

around the LCD monitor when it was
packaged, beneath the LCD monitor so as
not to scratch the panel.

2. Install the remote control batteries

The remote control is powered by two 1.5V AAA batteries.
To install or replace batteries:

A. Press and slide to open the cover.
B. Align the batteries according to the (+) and (–)

indications inside the case.

C. Replace the cover.
CAUTION: Incorrect usage of batteries can result in leaks

or bursting.

Downloaded From TV-Manual.com Manuals

English-12

5. Switch on the power of all the attached
external equipment

When connected with a computer, switch on the power of
the computer first.

6. Operate the attached external
equipment

Display the signal from the desired input source.

7. Adjust the sound

Make volume adjustments when required.

8. Adjust the screen (See pages 19 and 20)

Make adjustments to the screen display position when
necessary.

9. Adjust the image (See page 19)

Make adjustments such as brightness or contrast when
required.

10. Recommended Adjustments

To reduce the risk of the “Image Persistence”, please adjust
the following items based on the application being used:
“POWER SAVE”, “SCREEN SAVER” (See page 21),
“SIDE BORDER COLOR” (See page 22), “DATE AND TIME”,
“SCHEDULE” (See page 20).

English

11.To prevent the main power switch from

being changed

To prevent use of the main power switch, please attach the
main switch cover, which is enclosed as an accessory.

NOTE: With the main power switch cover in place, the main

power switch cannot be turned off. Remove main
power switch cover in order to switch off the display.

Screw

Main switch cover

Downloaded From TV-Manual.com Manuals

English-13

Connections

NOTE: Do not connect/disconnect cables when turning on the monitor or other external equipment as this may result in a

loss of the monitor image.

NOTE: Use an audio cable without a built-in resistor. Using an audio cable with a built-in resistor turns down the sound.

Before making connections:

* First, turn off the power of all attached equipment and make connections.
* Refer to the user manual included with each separate piece of equipment.

Wiring Diagram

Stereo Amplifier

Computer (Analog) Computer (Digital)

*: Multiple monitors that are daisy-chained have a limit to the connectable monitors.

VCR Player

DVD Player

DVD player

with HDMI out

Second monitor*

Connected
equipment

Connecting

terminal

DVI (DVI-D)

HDMI

AV

DVD/HD (5BNC)

S-VIDEO

VIDEO1 (BNC)

VIDEO2 (5BNC)

DVI (DVI-D)

PC

VGA

RGB/HV (5BNC)

*1: depend on signal type.

• AUDIO IN 1, 2 and 3 can be used for audio input. To select audio source [IN1], [IN2] or [IN3] by pressing the AUDIO

INPUT button (remote control).

Downloaded From TV-Manual.com Manuals

Setting in Terminal Mode

DVI MODE: DVI-HD

RAW/EXPAND*

1

BNC MODE: COMPONENT

-

­BNC MODE: VIDEO
DVI MODE: DVI-PC

-

BNC MODE: RGB

English-14

Input signal

name

DVI

HDMI

DVD/HD

S-VIDEO

VIDEO1
VIDEO2

DVI

VGA

RGB/HV

Connecting

Audio terminal

AUDIO IN1, IN2, IN3

HDMI
AUDIO IN1, IN2, IN3
AUDIO IN1, IN2, IN3
AUDIO IN1, IN2, IN3
AUDIO IN1, IN2, IN3
AUDIO IN1, IN2, IN3
AUDIO IN1, IN2, IN3
AUDIO IN1, IN2, IN3

Connecting a Personal Computer

Connecting your computer to your LCD monitor will enable you to display your computer’s screen image.
Some video cards with a pixel clock over 165 MHz may not display an image correctly.
Your LCD monitor displays proper image by adjusting the factory preset timing signal automatically.

<Factory preset signal timing>

Resolution

640 x 480 31.5 kHz 60 Hz

800 x 600 37.9 kHz 60 Hz
1024 x 768 48.4 kHz 60 Hz
1280 x 768 48 kHz 60 Hz
1360 x 768 48 kHz 60 Hz Recommended resolution

1280 x 1024 64 kHz 60 Hz Compressed image
1600 x 1200 75 kHz 60 Hz Compressed image Compressed image
1920 x 1080 66.6 kHz 60 Hz Compressed image Recommended resolution

• If you use with a Macintosh PowerBook, set “Mirroring” to Off on your PowerBook.
Refer to your Macintosh’s owner’s manual for more information about your computer’s video output requirements and any

special identification or configuration your monitor’s image and monitor may require.

• Input TMDS signals conforming to DVI standards.

•To maintain display quality, use a cable that conforms to DVI standards.

Scanning frequency

Horizontal Vertical V321/LCD4215(R) V461

Remarks

Connecting a DVD Player with HDMI out

• Please use an HDMI cable with HDMI logo.

• It may take a moment for the signal to appear.

• PC-DVI signals are not supported.

English

Downloaded From TV-Manual.com Manuals

English-15

Basic Operation

Power ON and OFF Modes

The LCD monitor power indicator will turn green while powered on and will turn red while powered off.
NOTE: The Main Power Switch must be in the ON position in order to power up the monitor using the remote control or the

Power Button on the front of the LCD.

Power Button

OFF

ON

Using the remote control

Main Power Switch

Downloaded From TV-Manual.com Manuals

English-16

Power Indicator

Status
Power ON Green
Power OFF Red
Power Standby when Red On
“SCHEDULE” is enabled Green Blinking
Power Standby Red, Green
Diagnosis (Detecting failure) Red Blinking

* See troubleshooting on page 29

Using Power Management

The LCD monitor follows the VESA approved DPM Power
Management function.
The power management function is an energy saving
function that automatically reduces the power consumption
of the display when the keyboard or the mouse has not been
used for a fixed period.
The power management feature on your new display has
been set to the “ON” mode. This allows your display to enter
a Power Saving Mode when no signal is applied. This could
potentially increase the life and decrease the power
consumption of the display.

NOTE: Depending on the PC and video card used, this

function may not operate.

NORMAL: Displays the aspect ratio the same as it is sent
from the source.

FULL: Fills entire screen.
DYNAMIC: Expands a 4:3 pictures to fill the entire screen

with non-linearity. Some of the outside image area will be
cut off due to expansion.

CUSTOM (ZOOM)

The image can be expanded beyond the active display area.
The image which is outside of active display area is not
shown.

ZOOM

ZOOM

REAL: Image will be displayed 1 by 1 pixel.

Picture Mode

DVI, VGA, RGB/HV

STANDARD sRGB HIGHBRIGHT

HDMI, DVD/HD, S-VIDEO, VIDEO1, VIDEO2

STANDARD CINEMA HIGHBRIGHT

Information OSD

English

Selecting a video source

To view a video source:

Use the input button to set [HDMI], [VIDEO1], [VIDEO2] or
[S-VIDEO].

Use the COLOR SYSTEM menu to set [AUTO], [PAL],
[NTSC], [PAL60], [4.43NTSC], [SECAM], according to your
video format.

Picture Size

DVI, VGA, RGB/HV

FULL NORMAL CUSTOM REAL

HDMI, DVD/HD, S-VIDEO, VIDEO1, VIDEO2

FULL NORMAL DYNAMIC CUSTOM REAL

Aspect ratio

of image

4:3

Squeeze

Unchanged view*

*1 Grey areas indicate unused portions of the screen.

1

Recommended selection

for picture size*

NORMAL

DYNAMIC

FULL

1

DVI, VGA, RGB/HV

VGA
1024 x 768
48kHz 60Hz
AUDIO : 1
SIZE : FULL

)

DVD/HD

DVD/HD
60HZ
AUDIO : 2
SIZE : FULL

VIDEO

S-VIDEO
60HZ
NTSC
AUDIO : 3
SIZE : NORMAL

PIP or POP

Main: VGA
Sub: S-VIDEO

VGA
1024 x 768
48kHz 60Hz
AUDIO : 1
S-VIDEO
NTSC
60HZ
SIZE : FULL

)

Video Input mode
Input signal Information
Audio input mode

Picture Size mode

Video Input mode

Audio input mode
Picture Size mode

Video Input mode

Input Signal Colour System mode
Audio input mode
Picture Size mode

Main picture information

Sub picture information

Main picture Size mode

Downloaded From TV-Manual.com Manuals

English-17

OSD (On-Screen-Display) Controls

Remote Control

Press MENU button to
open Main menu.

Control Panel

Press EXIT button to open
Main menu and press “+”, “-”
button to select Main menu.
Then press Up, Down button
to enter Sub menu.

EXIT button
Then, “+”, “-”,
Up, Down
button

Press “+”, “-” button to
select Main menu, and
press Up, Down button
to enter Sub menu.

Press INPUT button to
enter next menu to
adjust.

Press SET Button
to enter next menu
to adjust.

OR

Press +, - button to make setting to be
adjusted.

Press Up, Down or “+”, “-”
button to select function, or
setting to be adjusted.

INPUT button Up, Down or

Press Up, Down or “+”, “-”
button to select function,
or setting to be adjusted.

“+”, “-” button

Press MENU or EXIT
button to exit.

Press EXIT button to exit.

EXIT button

OR

OSD screen

Press MENU button to open Main menu.
Press +, - button to select Main menu.
Press down or up to enter Sub menu.

Main menu icon

Main menu

Sub menu

Press +, - button to make setting to be
adjusted.

Press +, - button to make setting to be adjusted.

Press SET button to enter next menu to adjust.

Press MENU or
EXIT button to exit.

Press Up, Down or “+”, “-” button to select
function or setting to be adjusted.

Downloaded From TV-Manual.com Manuals

English-18

Setting Default


BRIGHTNESS Adjusts the overall image and background brightness.

CONTRAST Adjusts the image brightness in relation to the input signal.

SHARPNESS Adjusts the crispness of the image.

BLACK LEVEL Adjusts the image brightness in relation to the background.

TINT Adjusts the tint of the screen.

INPUT HDMI, DVD/HD, S-VIDEO, VIDEO1, VIDEO2 only

COLOR Adjusts the color depth of the screen.

INPUT HDMI, DVD/HD, S-VIDEO, VIDEO1, VIDEO2 only

NOTE: sRGB picture mode is standard and cannot be changed.

English

COLOR TEMPERATURE Adjusts the color temperature of the entire screen. A low color temperature will make the screen reddish.

A high color temperature will make the screen bluish.

USER COLOR Select the USER COLOR SETTING feature ON/OFF.

USER COLOR SETTING Adjusts the levels of the Red, Yellow, Green, Cyan, Blue and Magenta.

Note: The sRGB picture mode is standard and cannot be changed.
It can be adjusted only when USER COLOR is selected ON.

GAMMA SELECTION Select a display gamma for best picture quality.

NATIVE Gamma correction is handled by the LCD panel.

2.2 Typical display gamma for use with a PC.

2.4 Good for video (TV, DVD, etc.)

S GAMMA Special gamma for certain types of movies. Raises the dark parts and lowers the light parts of the image.

NOTE: sRGB picture is standard and cannot be changed.

NOISE REDUCTION Adjusts the amount of noise reduction.

INPUT S-VIDEO, VIDEO1, VIDEO2 only

FILM MODE Selects Film mode function. ( AUTO)

INPUT HDMI, DVD/HD, S-VIDEO, VIDEO1, VIDEO2 only

This mode is better suited for movies, which is converted 24 Frames/sec source to DVD Video.

PICTURE RESET Resets the all settings within the PICTURE menu back to factory setting.

ADJUST

AUTO SETUP Press “SET” button to automatically adjust screen size, horizontal position, vertical position, clock, clock phase,

INPUT VGA, RGB/HV only white level and black level.

AUTO ADJUST Selecting ON when changing the timing, the horizontal position, vertical position and clock phase will adjust

INPUT VGA, RGB/HV only automatically.

H POSITION Controls the horizontal position of the image within the Display area of the LCD.

ALL inputs except DVI, HDMI Press + to move right. Press - to move left.

V POSITION Controls the vertical position of the image within the Display area of the LCD.

ALL inputs except DVI, HDMI Press + to move up. Press - to move down.

CLOCK Press + to expand the width of the image on the right of the screen.

INPUT VGA, RGB/HV only Press - to narrow the width of the image on the left.

CLOCK PHASE Adjusts the visual “noise” on the image.

INPUT VGA, RGB/HV only

ZOOM MODE You can select “FULL”, “NORMAL”, “DYNAMIC”, “CUSTOM” and “REAL”.

NOTE: DYNAMIC is INPUT HDMI, DVD/HD, S-VIDEO, VIDEO1, VIDEO2 only.
Selecting DYNAMIC expands 4:3 picture to fill the screen. Some of the image is lost due to expansion.
Selecting “REAL” image will be displayed 1 by 1pixel.

CUSTOM ZOOM “CUSTOM ZOOM” will be selected when you select “CUSTOM” on the screen “ZOOM” mode.

ZOOM Expands the horizontal and the vertical size simultaneously.

H ZOOM Expands the horizontal size only.

V ZOOM Expands the vertical size only.

H POSITION Moves to the right with + button. Moves to the left with - button.

V POSITION Moves up with + button. Moves down with - button.

Downloaded From TV-Manual.com Manuals

English-19

H RESOLUTION Adjusts the horizontal size of the image.

INPUT VGA, RGB/HV only Press + button to expand, and press - button to narrow the width of the image on the screen.

V RESOLUTION Adjusts the vertical size of the image.

INPUT VGA, RGB/HV only Press + button to expand, and press - button to narrow the width of the image on the screen.

INPUT RESOLUTION Selects to decision of input signal timings 1024x768, 1280x768, 1360x768 and 1366x768 if there is a detection

INPUT VGA, RGB/HV only problem. If no problem is detected, the only available option will be “AUTO”.

ADJUST RESET Resets the all settings within the ADJUST menu back to factory setting.

AUDIO

BALANCE Adjust the balance of L/R volume.

TREBLE To accentuate or reduce the high frequency sound. Press + to increase, press - to decrease.

BASS To accentuate or reduce the low frequency sound. Press + to increase, press - to decrease.

AUDIO RESET Resets the all settings within the AUDIO menu back to factory setting.

SCHEDULE

OFF TIMER Sets the monitor to power off after a length of time.

A time between 1 to 24 hours is available.

SCHEDULE Creates a working schedule for the monitor to use.

(See “NOTE 1” on page 23 for further information).

DATE AND TIME Sets the date, time, and daylight saving region.

Setting item: YEAR/MONTH/DAY/HOUR/MINUTE/DAYLIGHT SAVING TIME
Date & time must be set in order for the “SCHEDULE” function to operate.

SCHEDULE RESET Resets the all settings within the SCHEDULE menu back to factory setting except DATE AND TIME setting.

PIP

PIP MODE Selects Picture-in-Picture mode. See page 10.

OFF Normal mode.

PIP Picture in Picture mode.

POP Picture out picture mode.

SBS ASPECT Side by side (split screen) mode, with keep aspect.

SBS FULL Side by side (split screen) mode, with full screen.

PIP SIZE Selects the size of sub-picture used in “Picture-in-Picture” (PIP) mode.

PIP AUDIO Selects the sound source in PIP mode.

PIP H-POSITION Determines where the PIP appears on the screen.

PIP V-POSITION Determines where the PIP appears on the screen.

TEXT TICKER

(V321 and V461 only)

“LARGE”, “MIDDLE” and “SMALL” are available.

MODE Enables Text Ticker and allows you to set Horizontal or Vertical direction.

POSITION-H Selects the horizontal location of the Text Ticker on the screen.

POSITION-V Selects the vertical location of the Text Ticker on the screen.

SIZE Determines the size of the Text Ticker in relationship to the overall screen size.

BLEND Sets the transparency of the Text Ticker (10: transparent, 100: opaque).

DETECT Enables auto-detection of the Text Ticker.

FADE IN Enables fade-in of the text ticker when DETECT is AUTO.

SUB INPUT Selects sub picture input signal.

PIP RESET Resets the all settings within the PIP menu back to factory setting.

OSD

LANGUAGE Selects the language used by the OSD from seven languages.

ENGLISH/DEUTSCH/FRANÇAIS/ESPAÑOL/ITALIANO/SVENSKA/

OSD TURN OFF Turns off the OSD after a period of inactivity. The preset choices are 5 - 120 seconds.

Downloaded From TV-Manual.com Manuals

English-20

OSD H-POSITION Adjusts the horizontal position of the OSD menu.

OSD V-POSITION Adjusts the vertical position of the OSD menu.

INFORMATION OSD Selects the information OSD displays or not. The information OSD will display when input signal or source

MONITOR INFORMATION

CLOSED CAPTION* Activates closed captioning.

INPUT DVD/HD, S-VIDEO, VIDEO1, VIDEO2 only

OSD RESET Resets the all settings within the OSD menu back to factory setting.

change or warning message like as no-signal or out-of range.
A time between 1 to 10 seconds is available.

Indicates the model and serial number of your monitor.

MULTI DISPLAY

MONITOR ID Sets the monitor ID number from 1-26. Monitor ID is used for RS-232C control only.

IR CONTROL Selects the infrared wireless remote controller mode.

NORMAL The monitor will be controlled normally by wireless remote controller.

LOCK Disables the monitor control by infrared wireless remote controller.

TILE MATRIX Allows one image to be expanded and displayed over multiple screens (up to 16) through a distribution

H MONITORS Selects number of monitors arranged vertically.

V MONITORS Selects number of monitors arranged horizontally.

POSITION Selects which section of the tiled image to be displayed on the monitor.

TILE COMP Turns the TILE COMP feature on.

The item in this menu will become effective by pressing “SET” button on the selected item.

Keep pressing “DISPLAY” button during 5 sec or more, this setting will return to “NORMAL”.

amplifier. When screen size is “Real”, this function does not operate.

English

ENABLE Enables the Tile Matrix.

POWER ON DELAY Adjusts the delay time between being in “standby” mode and entering “power on” mode.

EXTERNAL CONTROL*

CONTROL Selects the control interface, RS-232C or LAN.

LAN RESET Resets the LAN settings.

MULTI DISPLAY RESET Resets the all settings within the MULTI DISPLAY menu back to factory setting.

PIP and STILL will be disabled when “TILE MATRIX” is activated.

“POWER ON DELAY” time is selectable from OFF, 2, 4, 6, 8, 10, 20, 30, 40 and 50 sec.

DISPLAY PROTECTION

POWER SAVE Sets how long the monitor waits to go into power save mode after a lost signal.

RGB Selecting “ON”, the monitor will go to power management mode when DVI, VGA, RGB/HV sync is lost.

VIDEO Selecting “ON”, the monitor will go to power management mode after about 10 minutes when DVD/HD and

HEAT STATUS Information of status for COOLING FAN, BRIGHTNESS and TEMPERATURE. COOLING FAN runs when

SCREEN SAVER Use the SCREEN SAVER function to reduce the risk of Image Persistence.

GAMMA The display gamma is changed and fixed when “ON” is selected.

Note: When connecting DVI, video card might not stop sending digital data even if image has disappeared.
In this case the monitor does not get to power management mode.

HDMI, S-VIDEO, VIDEO1, VIDEO2 input signal is lost.

inside temperature is over a guaranteed limit. In this case warning is displayed on the screen.

(See “NOTE 2” on page 23 for further information).

COOLING FAN The built in cooling fan is always on when set “ON”.

BRIGHTNESS The brightness is decreased when “ON” is selected.

MOTION Image is slightly expanded and moves 4 directions (UP, DOWN, RIGHT, LEFT) periodically (Need setting the

time for movement).
Movement area is approximately +/- 10 mm from original position;
Please locate the important information such as text within 90% area of screen image.
PIP and STILL will be disabled when “MOTION” is active.

*: V321 and V461 only.

Downloaded From TV-Manual.com Manuals

English-21

SIDE BORDER COLOR Adjusts the color of the side borders when a 4:3 image is displayed.

Press + button, the bar will become lighter.
Press - button, the bar will become darker.

DISPLAY PROTECTION Resets the all settings within the DISPLAY PROTECTION menu back to factory setting.
RESET

ADVANCED OPTION

INPUT CHANGE Sets input change speed.

NOTE: When “QUICK” is selected, picture may be distorted when signal input is changed.
This function should be chosen after all adjustment options have been made for the input.

TERMINAL SETTING

DVI MODE Selects the kind of DVI-D equipment which is connected to the DVI input. Select “DVI-PC” when PC or other

computer equipment is connected. Select “DVI-HD” when DVD player, which has DVI-D output, is connected.

BNC MODE Selects the kind of equipment which is connected to the BNC input.

RGB: Analog input (R, G, B, H, V)
COMPONENT: Component (Cr/Pr, Cb/Pb, Y)
VIDEO: Composite video (VIDEO2)

HDMI SIGNAL RAW: Disable the expanded feature.

EXPAND: Expand image contrast and increase detail in the dark and bright areas.

SCAN CONVERSION Selects IP (Interlace to Progressive) converter function.

INPUT HDMI, DVD/HD, S-VIDEO, VIDEO1, VIDEO2 only

PROGRESSIVE Enables the IP function, to convert interlace signal to progressive. Normally use this.

INTERLACE Disables the IP function.

NOTE: This mode is better suited for motion pictures, but it is in danger of image retention.

COLOR SYSTEM Selects color system depend on your video format of the input signal.

INPUT

S-VIDEO, VIDEO1, VIDEO2

only (AUTO/PAL/NTSC/PAL60/4.43NTSC/SECAM)

AUTO: Selects color system setting automatically base on input signal.

SCAN MODE Changes the display area of the image.

INPUT DVD/HD, HDMI, S-VIDEO, VIDEO1, VIDEO2 only

OVER SCAN Set to display area about 95%

UNDER SCAN Set to display area about 100%

ADVANCED OPTION Resets the all settings within the ADVANCED OPTION menu back to factory setting.
RESET

FACTORY RESET Selecting “YES” allows you to reset PICTURE, ADJUST, AUDIO, PIP, OSD, MULTI DISPLAY,

DISPLAY PROTECTION and ADVANCED OPTION will be back to factory settings (except LANGUAGE and
DATE AND TIME).
Select “YES” and press “SET” button to restore the factory preset data.
Press “EXIT” button to cancel and return the previous menu.

Downloaded From TV-Manual.com Manuals

English-22

NOTE 1: CREATING A SCHEDULE

Using the “SCHEDULE” function allows you to set up to seven different scheduled time intervals when the LCD Monitor will be activated.
You can select the time the monitor turns on and turns off, the day of week the monitor is activated, and which input source the monitor will
use for each scheduled activation period. A check mark in the box next to the number of the schedule indicates that the selected schedule
is in effect.
To select which schedule to set, use the up/down arrows to move the number (1 to 7) of the schedule.
Use the (+) and (-) buttons to move the cursor horizontally within the particular schedule. The “SET” button is used to make a selection.
If you create a schedule but do not want to use a power on time, select “--” in the “ON” time slot.
If you do not want to use a power off time select “--” in the OFF time slot.
If there is no input selected (“--” showing in the input spot) the input from the previous schedule will be used.
The selection of EVERY DAY within a schedule takes priority over other schedules that are set up to operate weekly.
After the schedule is programmed, press the “MENU” button to close the OSD and make the set schedule available.
When schedules are overlapping, scheduled Power ON time has priority over scheduled Power OFF time.

Note: If schedules are overlapping then the schedule with the highest number will have priority over the schedule with the lowest number.
For example schedule #7 will have priority over schedule #1.
ON time should be earlier than OFF time. If OFF time is earlier than ON time, schedule function is not working properly.
If you would like to set the monitor power on at 23:00 and power off at 6:00 next morning, you should set 2 settings. First setting is ON
time is “23:00” and OFF time is “--”, next setting is ON time is “--” and OFF time is “06:00”.

NOTE 2: IMAGE PERSISTENCE

Please be aware that LCD Technology may experience a phenomenon known as Image Persistence. Image Persistence occurs when a
residual or “ghost” image of a previous image remains visible on the screen. Unlike CRT monitors, LCD monitors’ image persistence is not
permanent, but constant images being displayed for a long period of time should be avoided.
To alleviate image persistence, turn off the monitor for as long as the previous image was displayed. For example, if an image was on the
monitor for one hour and a residual image remains, the monitor should be turned off for one hour to erase the image.
As with all personal display devices, NEC DISPLAY SOLUTIONS recommends displaying moving images and using a moving screen
saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.

Please set “SCREEN SAVER”, “DATE AND TIME” and “SCHEDULE” functions to further reduce the risk of Image persistence.

English

For long life use as Public Display

< Image Sticking of LCD Panel >

When an LCD panel is operated continuously for long hours, a trace of electric charge remains near the electrode inside LCD, and residual
or “ghost” image of previous image may be observed. (Image Persistence)
Image Persistence is not permanent, but when fixed image is displayed for long period, ionic impurities inside LCD are accumulated along
the displayed image, and may be permanent. (Image Sticking)

< Recommendations >

To prevent Image Sticking, and for longer life usage of LCD, the following are recommended.

1. Fixed image should not be displayed for long period. Change fixed images after short intervals.

2. When not in use, please turn off the monitor by remote control, or use Power Management or use Schedule Functions.

3. Lower environmental temperatures prolong the lifespan of the monitor.
When Protective surface (glass, acrylic) is installed over the LCD surface, the LCD surface is located in an enclosed space, the monitor
are stacked, utilize the temperature sensors inside monitor.
To reduce the environmental temperature, use the Cooling Fan, Screen Saver and Low Brightness.

4. Please use “Screen Saver Mode” of monitor.

Downloaded From TV-Manual.com Manuals

English-23

Controlling the LCD monitor via RS-232C Remote Control

This LCD monitor can be controlled by connecting a personal computer with a RS-232C terminal.
Functions that can be controlled by a personal computer are:

• Power ON or OFF

• Switching between input signals

Connection

MultiSync

LCD Monitor + PC

OUT

IN

PC (Out)

RS-232C (IN)

RS-232C Cable

MultiSync MultiSync

RS-232C (IN)RS-232C (OUT) RS-232C (OUT)

MultiSync

RS-232C Cable

NOTE: If your PC is equipped only with a 25-pin serial port connector, a 25-pin serial port adapter is required. Contact your

dealer for details.

* In order to function, the RS-232C OUT terminal can only be connected to another monitor of the same model.

Do not connect to other types of equipment.

To control monitor or multiple monitors that are daisy-chained together please use the control command. Instructions for the
control command can be found on the CD included with the display. The file is called “External_control_****.pdf”.

1) Interface

PROTOCOL RS-232C
BAUD RATE 9600 [bps]
DATA LENGTH 8 [bits]
PARITY BIT NONE
STOP BIT 1 [bit]
FLOW CONTROL NONE

This LCD monitor uses RXD, TXD and GND lines for RS-232C control.
The reverse type cable (null modem cable) (not include) should be used for RS-232C control.

2) Control command diagram

Please see file “External_Control_****.pdf” on the CD-ROM.

Downloaded From TV-Manual.com Manuals

English-24

Controlling the LCD monitor via LAN Control (V321 and V461 only)

Connecting to a Network

Using a LAN cable allows you to specify the Network Settings and the Alert Mail Settings by using an HTTP server function.
NOTE: When you use this function, EXTERNAL CONTROL should be “LAN” (See page 21).

To use a LAN connection, you are required to assign an IP address.

Example of LAN connection:

Server

NOTE: Use a category 5 or higher LAN cable.

Hub

LAN cable

(not supplied)

English

Network Setting by Using an HTTP Browser

Overview

Connecting the monitor to a network allows for monitor control from a computer via the network.
To perform the monitor control from a web browser, you must have an exclusive application installed on your computer.
The IP address and subnet mask of the monitor can be set on the Network Setting screen of the web browser by using an

HTTP server function. Please be sure to use “Microsoft Internet Explorer 6.0” or a higher version for the web browser.
(This device uses “JavaScript” and “Cookies” and the browser should be set to accept these functions. The setting method will
vary depending on the version of browser. Please refer to the help files and the other information provided in your software.)

Access is gained to the HTTP server function by starting the Web browser on the computer via the network connected to the
monitor and entering the following URL.

Network Setting

http://<the Monitor’s IP address>/index.html
TIP: The default IP address is “192.168.0.10”.

The exclusive application can be downloaded from our website.

NOTE: If the MONITOR NETWORK SETTINGS screen does not appear in the web browser, press the Ctrl+F5 keys to

refresh your web browser (or clear the cache).

The display or button’s response can be slowed down or operation may not be accepted depending the settings of
your network.

Should this happen, consult your network administrator.

The LCD monitor may not respond if its buttons are repeatedly pressed in rapid intervals. Should this happen, wait a
moment and repeat.

If you still can’t get a response, turn off and back on the monitor.

Downloaded From TV-Manual.com Manuals

English-25

Preparation Before Use

Connect the monitor to a commercially available LAN cable before engaging in browser operations.
Operation with a browser that uses a proxy server may not be possible depending on the type of proxy server and the setting

method. Although the type of proxy server will be a factor, it is possible that items that have actually been set will not be
displayed depending on the effectiveness of the cache, and the contents set from the browser may not be reflected in
operation. It is recommended that a proxy server not be used unless it is unavailable.

Handling of the Address for Operation via a Browser

Regarding the actual address that is entered for the address or entered into the URL column when operation of the monitor is
via a browser, the host name can be used as it is when the host name corresponding to the IP address of the monitor has
been registered to the domain name server by a network administrator, or the host name corresponding to the IP address of
the monitor has been set in the “HOSTS” file of the computer being used.

Example 1: When the host name of the monitor has been set to “pd.nec.co.jp”, access is gained to the network setting by

specifying

Example 2: When the IP address of the monitor is “192.168.73.1”, access is gained to the mail alert settings by specifying

http://192.168.73.1/index.html

http://pd.nec.co.jp/index.html

for the address or the entry column of the URL.

for the address or the entry column of the URL.

Network Settings

http://<the Monitor’s IP address> /index.html

DHCP

IP ADDRESS

SUBNET MASK

DEFAULT GATEWAY

DNS (PRIMARY)

DNS (SECONDARY)

UPDATE

Enabling this option automatically assigns an IP address to the monitor from your DHCP server.
Disabling this option allows you to register the IP address or subnet mask number obtained from
your network administrator.
NOTE: The IP address of the monitor is required to change the network setting.

The IP address will not be displayed on the Monitor’s menu.
Consult your network administrator for the IP address when [ENABLE] is selected for
[DHCP].

Set your IP address of the network connected to the monitor when [DISABLE] is selected for
[DHCP].

Set your subnet mask number of the network connected to the monitor when [DISABLE] is selected
for [DHCP].

Set your default gateway of the network connected to the monitor when [DISABLE] is selected for
[DHCP].

Set your primary DNS settings of the network connected to the monitor.

Set your secondary DNS settings of the network connected to the monitor.

Reflect your settings.
NOTE: Close the browser after clicking [UPDATE].

The monitor will automatically update your settings.

Downloaded From TV-Manual.com Manuals

English-26

Alert Mail Setting

http://<the Monitor’s IP address>/lanconfig.html

English

This option notifies your computer of an error message via e-mail when using wired LAN. An error message notification will be
sent when an error occurs in the monitor.

HOST NAME

DOMAIN NAME

ALERT MAIL

SENDER’S ADDRESS

SMTP SERVER NAME

RECIPIENT’S
ADDRESS 1 to 3

APPLY

EXECUTE

STATUS

NOTE: • If you execute a test, you may not receive an Alert mail.

Should this happen, check if the network settings are correct.

• If you entered an incorrect address in a test, you may not receive an Alert mail.
Should this happen, check if the Recipient’s Address is correct.

Type in the hostname of the network connected to the monitor.
Up to 60 alphanumeric characters can be used.

Type in the domain name of the network connected to the monitor.
Up to 60 alphanumeric characters can be used.

Checking [ENABLE] will turn on the Alert Mail feature.
Checking [DISABLE] will turn off the Alert Mail feature.

Type in the senders address. Up to 60 alphanumeric and symbols characters can be used.

Type in the SMTP server name to be connected to the monitor.
Up to 60 alphanumeric characters can be used.

Type in your recipient’s address. Up to 60 alphanumeric and symbols characters can be used.

Click this button to reflect the above settings.

Click this button to send a test mail to check if your settings are correct.

A reply to a test mail will be displayed.

TIP: The Alert Mail settings will not be affected even when [RESET] is done from the menu.

For Control command diagram, please see file “External_Control.pdf” on the CD-ROM.

Downloaded From TV-Manual.com Manuals

English-27

Features

Reduced Footprint: Provides the ideal solution for environments requiring superior image quality but with size and weight

limitations.
Color Control Systems: Allows you to adjust the colors on your screen and customize the color accuracy of your monitor to

a variety of standards.
sRGB Color Control: A new optimized color management standard which allows for color matching on computer displays

and other peripherals. The sRGB standard, which is based on a calibrated color space, allows for optimal color representation
and backward compatibility with other common color standards.

OSD (On-Screen-Display) Controls: Allow you to quickly and easily adjust all elements of your screen image via simple to
use on-screen menus.

Plug and Play: The Microsoft
monitor to send its capabilities (such as screen size and resolutions supported) directly to your computer, automatically
optimizing display performance.

IPM (Intelligent Power Manager) System: Provides innovative power-saving methods that allow the monitor to shift to a
lower power consumption level when on but not in use, saving two-thirds of your monitor energy costs, reducing emissions
and lowering the air conditioning costs of the workplace.

FullScan Capability: Allows you to use the entire screen area in most resolutions, significantly expanding image size.
VESA Standard (FDMIv1) Mounting Interface: Allows users to connect their LCD monitor to any VESA standard (FDMIv1)

third party mounting arm or bracket. Allows for the monitor to be mounted on a wall or an arm using any third party compliant
device. NEC recommends using mounting interface that comply with TÜV-GS and/or UL1678 standard in North America.

DVI-D: The digital-only subset of DVI ratified by the Digital Display Working Group (DDWG) for digital connections between
computers and displays. As a digital-only connector, analog support is not provided for a DVI-D connector. As a DVI-based
digital only connection, only a simple adapter is necessary for compatibility between DVI-D and other DVI-based digital
connectors such as DFP and P&D. The DVI interface of this display supports HDCP.

TILE MATRIX, TILE COMP: Shows one image over multiple screens with accuracy while compensating for bezel width.
ZOOM: Expands image size for horizontal and vertical direction.
Self-diagnosis: If an internal error should occur, a failure state will be indicated.

®

solution with the Windows® operating system facilitates setup and installation by allowing the

Downloaded From TV-Manual.com Manuals

English-28

Troubleshooting

No picture

• The signal cable should be completely connected to the
display card/computer.

• The display card should be completely seated in its slot.

• Front Power Switch and computer power switch should
be in the ON position.

• Check to make sure that a supported mode has been
selected on the display card or system being used.
(Please consult display card or system manual to
change graphics mode.)

• Check the monitor and your display card with respect to
compatibility and recommended settings.

• Check the signal cable connector for bent or pushed-in
pins.

Power Button does not respond

• Unplug the power cord of the monitor from the AC outlet
to turn off and reset the monitor.

Image persistence

• Please be aware that LCD Technology may experience a
phenomenon known as Image Persistence. Image
Persistence occurs when a residual or “ghost” image of a
previous image remains visible on the screen. Unlike
CRT monitors, LCD monitors’ image persistence is not
permanent, but constant images being displayed for a
long period of time should be avoided. To alleviate image
persistence, turn off the monitor for as long as the
previous image was displayed. For example, if an image
was on the monitor for one hour and a residual image
remains, the monitor should be turned off for one hour to
erase the image.

NOTE: As with all personal display devices, NEC DISPLAY

SOLUTIONS recommends displaying moving
images and using a moving screen saver at regular
intervals whenever the screen is idle or turning off
the monitor when not in use.

Image is unstable, unfocused or swimming is apparent

• Signal cable should be completely attached to the
computer.

• Use the OSD Image Adjust controls to focus and adjust
display by increasing or decreasing the fine adjustment.
When the display mode is changed, the OSD Image
Adjust settings may need to be re-adjusted.

• Check the monitor and your display card with respect to
compatibility and recommended signal timings.

• If your text is garbled, change the video mode to non­interlace and use 60Hz refresh rate.

Image of component signal is greenish

• Check to see if the DVD/HD input connector is selected.

LED on monitor is not lit
(no green or red color can be seen)

• Power Switch should be in the ON position and power
cord should be connected.

• Make certain the computer is not in a power-saving
mode (touch the keyboard or mouse).

RED LED on monitor is blinking

•A certain failure might have occurred, please contact
your nearest authorized NEC DISPLAY SOLUTIONS
service facility.

Display image is not sized properly

• Use the OSD Image Adjust controls to increase or
decrease the coarse adjustment.

• Check to make sure that a supported mode has been
selected on the display card or system being used.
(Please consult display card or system manual to
change graphics mode.)

Selected resolution is not displayed properly

• Use OSD Display Mode to enter Information menu and
confirm that the appropriate resolution has been
selected. If not, select corresponding option.

No Sound

• Check to see if speaker cable is properly connected.

• Check to see if mute is activated.

• Check to see if volume is set at minimum.

Remote Control is not available

• Check the Remote Control’s batteries status.

• Check if batteries are inserted correctly.

• Check if the Remote Control is pointing at the monitor’s
remote sensor.

• Check the Remote Control (IR Control) Mode status.

• The remote control system may not function when direct
sunlight or strong illumination strikes the remote control
sensor of the LCD monitor, or when there is an object in
the path.

“SCHEDULE”/“OFF TIMER” function is not working
properly

• The “SCHEDULE” function will be disabled when the
“OFF TIMER” is set.

• If the “OFF TIMER” function is enabled and the power to
the LCD monitor is turned off when the power supply is
interrupted unexpectedly, then the “OFF TIMER” will be
reset.

RS-232C or LAN control is not available

• Check RS-232C or LAN cable connection.

• Check “CONTROL” setting in “EXTERNAL CONTROL”.

English

Either light vertical or horizontal stripes may appear, depending on the specific display pattern. This is no product fault or
degradation.

Downloaded From TV-Manual.com Manuals

English-29

Specifications - V321

Product Specifications

LCD Module 32"/80.0 cm diagonal

Pixel Pitch: 0.511 mm
Resolution: 1366 x 768 dots

Color: Over 16 million colors (depending on video card used)

Brightness: 450 cd/m

Contrast Ratio: 3000:1

Viewing Angle: 89° (typ) @ CR>10

Design View Distance: 875 mm

Frequency Horizontal: 15.625/15.734 kHz, 31.5 kHz - 91.1 kHz

Vertical: 50.0 - 85.0 Hz

Pixel Clock 25.0 MHz - 165.0 MHz

Viewable Size 697.7 x 392.3 mm

Input Signal

DVI DVI-D 24pin Digital RGB DVI (HDCP)

VGA 15pin Mini D-sub Analog RGB 0.7 Vp-p/75 ohm

Sync Separate: TTL level (Pos./Neg.)

2

RGB/HV*

HDMI HDMI Connector Digital RGB HDMI

DVD/HD*

S-VIDEO Mini DIN 4 pin S-VIDEO Y: 1.0 Vp-p/75 ohm C: 0.286 Vp-p/75 ohm (NTSC), 0.3 Vp-p/75 ohm (PAL/SECAM)

VIDEO1 BNC Composite 1.0 Vp-p/75 ohm
VIDEO2*2BNC NTSC/PAL/SECAM/4.43NTSC/PAL60

Output Signal

RGB 15pin Mini D-sub Analog RGB 0.7 Vp-p with 75 ohm terminated

VIDEO BNC Composite 1.0 Vp-p with 75 ohm terminated

AUDIO

AUDIO RCA (L/R) X2 Analog Audio Stereo L/R 0.5 Vrms
Input STEREO Mini Jack

AUDIO RCA (L/R) Analog Audio Stereo L/R 0.5 Vrms
Output

Speaker Output External Speaker Jack 7 W + 7 W (8 ohm)

Control RS-232C In: 9 Pin D-sub

Power Supply 1.4 - 0.6 A @ 100-240VAC, 50/60Hz

Operational Environment Temperature: 5 - 40°C (landscape), 5 - 35°C (portrait)

Storage Environment Temperature: -20 - 60°C

Dimension Net: 789 (W) x 476.3 (H) x 133 (D) mm

Weight 14.3 kg/31.5 lbs

VESA compatible arm mounting interface 200 mm x 200 mm (4 Holes)

Power Management VESA DPM

Plug & Play VESA DDC2B, DDC/CI

Accessories Setup manual, Power Cord, Video Signal Cable, Remote Control, AAA Battery x 2, Clamp x 2,

NOTE: Technical specifications are subject to change without notice. *1: Compressed image

BNC (R,G,B,H,V) Analog RGB 0.7 Vp-p/75 ohm

Sync Separate: TTL level (Pos./Neg.)

2

BNC (Y, Cb/Pb, Cr/Pr) Component Y: 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm

RS-232C Out: 9 Pin D-sub (with daisy chain)

LAN: RJ-45 10/100 BASE-T

Humidity: 20 - 80% (without condensation)

Altitude: 0 - 3000 m

Humidity: 10 - 90% (without condensation)/ 90% - 3.5% x (Temp - 40°C) regarding over 40°C

2

(Typ.)

VGA60, SVGA60, XGA60, WXGA60, SXGA60*1, UXGA60*1, 1920 x 1080*1 (60Hz)

VGA60, SVGA60, XGA60, WXGA60, SXGA60*1, UXGA60*1, 1920 x 1080*1 (60Hz)

VGA60, SVGA60, XGA60, WXGA60, SXGA60*1, UXGA60*1, 1920 x 1080*1 (60Hz)

1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz

HDTV/DVD: 1080i@60Hz*1, 1080p@60Hz*1, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz

NTSC/PAL/SECAM/4.43NTSC/PAL60

Separate HV sync: TTL level (Pos. / Neg.)

Screw for Main switch cover x 2, Screw for Clamp x 2, CD-ROM, Main switch cover

*2: Exclusive use

Downloaded From TV-Manual.com Manuals

English-30

Specifications - V461

Product Specifications

LCD Module 46"/116.8 cm diagonal

Pixel Pitch: 0.530 mm
Resolution: 1920 x 1080 dots

Color: Over 16 million colors (depending on video card used)

Brightness: 450 cd/m

Contrast Ratio: 3000:1

Viewing Angle: 89° (typ) @ CR>10

Design View Distance: 1300 mm

Frequency Horizontal: 15.625/15.734 kHz, 31.5 kHz - 91.1 kHz

Vertical: 50.0 - 85.0 Hz

Pixel Clock 25.0 MHz - 165.0 MHz

Viewable Size 1018.08 x 572.67 mm

Input Signal

DVI DVI-D 24pin Digital RGB DVI (HDCP)

VGA 15pin Mini D-sub Analog RGB 0.7 Vp-p/75 ohm

Sync Separate: TTL level (Pos./Neg.)

2

RGB/HV*

HDMI HDMI Connector Digital RGB HDMI

DVD/HD*

S-VIDEO Mini DIN 4 pin S-VIDEO Y: 1.0 Vp-p/75 ohm C: 0.286 Vp-p/75 ohm (NTSC), 0.3 Vp-p/75 ohm (PAL/SECAM)

VIDEO1 BNC Composite 1.0 Vp-p/75 ohm
VIDEO2*2BNC NTSC/PAL/SECAM/4.43NTSC/PAL60

Output Signal

RGB 15pin Mini D-sub Analog RGB 0.7 Vp-p with 75 ohm terminated

VIDEO BNC Composite 1.0 Vp-p with 75 ohm terminated

AUDIO

AUDIO RCA (L/R) X2 Analog Audio Stereo L/R 0.5 Vrms
Input STEREO Mini Jack

AUDIO RCA (L/R) Analog Audio Stereo L/R 0.5 Vrms
Output

Speaker Output External Speaker Jack 7 W + 7 W (8 ohm)

Control RS-232C In: 9 Pin D-sub

Power Supply 2.4 - 1.0 A @ 100-240VAC, 50/60Hz

Operational Environment Temperature: 5 - 40°C (landscape), 5 - 35°C (portrait)

Storage Environment Temperature: -20 - 60°C

Dimension Net: 1121.5 (W) x 664.7 (H) x 129.8 (D) mm

Weight 24.0 kg/52.9 lbs

VESA compatible arm mounting interface 200 mm x 200 mm (4 Holes)

Power Management VESA DPM

Plug & Play VESA DDC2B, DDC/CI

Accessories Setup manual, Power Cord, Video Signal Cable, Remote Control, AAA Battery x 2, Clamp x 2,

NOTE: Technical specifications are subject to change without notice. *1: Compressed image

BNC (R,G,B,H,V) Analog RGB 0.7 Vp-p/75 ohm

Sync Separate: TTL level (Pos./Neg.)

2

BNC (Y, Cb/Pb, Cr/Pr) Component Y: 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm

RS-232C Out: 9 Pin D-sub (with daisy chain)

LAN: RJ-45 10/100 BASE-T

Humidity: 20 - 80% (without condensation)

Altitude: 0 - 3000 m

Humidity: 10 - 90% (without condensation)/ 90% - 3.5% x (Temp - 40°C) regarding over 40°C

2

(Typ.)

VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*1, 1920 x 1080 (60Hz)

VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*1, 1920 x 1080 (60Hz)

VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*1, 1920 x 1080 (60Hz)

1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz

HDTV/DVD: 1080i@60Hz*1, 1080p@60Hz*1, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz

NTSC/PAL/SECAM/4.43NTSC/PAL60

Separate HV sync: TTL level (Pos. / Neg.)

Screw for Main switch cover x 2, Screw for Clamp x 2, CD-ROM, Main switch cover

*2: Exclusive use

English

Downloaded From TV-Manual.com Manuals

English-31

Specifications - LCD4215(R)

Product Specifications

LCD Module 42"/106.7 cm diagonal

Pixel Pitch: 0.681 mm
Resolution: 1366 x 768 dots

Color: Over 16 million colors (depending on video card used)

Brightness: 500 cd/m

Contrast Ratio: 800:1

Viewing Angle: 89° (typ) @ CR>10

Design View Distance: 1100 mm

Frequency Horizontal: 15.625/15.734 kHz, 31.5 kHz - 91.1 kHz

Vertical: 50.0 - 85.0 Hz

Pixel Clock 25.0 MHz - 165.0 MHz

Viewable Size 930.25 x 523.01 mm

Input Signal

DVI DVI-D 24pin Digital RGB DVI (HDCP)

VGA 15pin Mini D-sub Analog RGB 0.7 Vp-p/75 ohm

Sync Separate: TTL level (Pos./Neg.)

2

RGB/HV*

HDMI HDMI Connector Digital RGB HDMI

DVD/HD*

S-VIDEO Mini DIN 4 pin S-VIDEO Y: 1.0 Vp-p/75 ohm C: 0.286 Vp-p/75 ohm (NTSC), 0.3 Vp-p/75 ohm (PAL/SECAM)

VIDEO1 BNC Composite 1.0 Vp-p/75 ohm
VIDEO2*2BNC NTSC/PAL/SECAM/4.43NTSC/PAL60

Output Signal

RGB 15pin Mini D-sub Analog RGB 0.7 Vp-p with 75 ohm terminated

VIDEO BNC Composite 1.0 Vp-p with 75 ohm terminated

AUDIO

AUDIO RCA (L/R) X2 Analog Audio Stereo L/R 0.5 Vrms
Input STEREO Mini Jack

AUDIO RCA (L/R) Analog Audio Stereo L/R 0.5 Vrms
Output

Speaker Output External Speaker Jack 7 W + 7 W (8 ohm)

Control RS-232C In: 9 Pin D-sub

Power Supply 2.1 - 0.85 A @ 100-240VAC, 50/60Hz

Operational Environment Temperature: 5 - 40°C (landscape), 5 - 35°C (portrait)

Storage Environment Temperature: -20 - 60°C

Dimension Net: 1022.9 (W) x 613.5 (H) x 133 (D) mm

Weight 21.6 kg/47.6 lbs

VESA compatible arm mounting interface 200 mm x 200 mm (4 Holes)

Power Management VESA DPM

Plug & Play VESA DDC2B, DDC/CI

Accessories Setup manual, Power Cord, Video Signal Cable, Remote Control, AAA Battery x 2, Clamp x 2,

NOTE: Technical specifications are subject to change without notice. *1: Compressed image

BNC (R,G,B,H,V) Analog RGB 0.7 Vp-p/75 ohm

Sync Separate: TTL level (Pos./Neg.)

2

BNC (Y, Cb/Pb, Cr/Pr) Component Y: 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm

RS-232C Out: 9 Pin D-sub (with daisy chain)

Humidity: 20 - 80% (without condensation)

Altitude: 0 - 3000 m

Humidity: 10 - 90% (without condensation)/ 90% - 3.5% x (Temp - 40°C) regarding over 40°C

2

(Typ.)

VGA60, SVGA60, XGA60, WXGA60, SXGA60*1, UXGA60*1, 1920 x 1080*1 (60Hz)

VGA60, SVGA60, XGA60, WXGA60, SXGA60*1, UXGA60*1, 1920 x 1080*1 (60Hz)

VGA60, SVGA60, XGA60, WXGA60, SXGA60*1, UXGA60*1, 1920 x 1080*1 (60Hz)

1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz

HDTV/DVD: 1080i@60Hz*1, 1080p@60Hz*1, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz

NTSC/PAL/SECAM/4.43NTSC/PAL60

Separate HV sync: TTL level (Pos. / Neg.)

Screw for Main switch cover x 2, Screw for Clamp x 2, CD-ROM, Main switch cover

*2: Exclusive use

Downloaded From TV-Manual.com Manuals

English-32

Pin Assignment

RS-232C input

Pin No Name

1 connected to 7&8
2 RXD
3 TXD

4 connected to 6
5GND
6 connected to 4
7 connected to 1&8
8 connected to 1&7
9NC

This LCD monitor uses RXD, TXD and GND lines for RS-232C control.

1

6

English

D-SUB 9P

5

9

Downloaded From TV-Manual.com Manuals

English-33

Manufacturer’s Recycling and Energy Information

NEC DISPLAY SOLUTIONS is strongly committed to environmental protection and sees recycling as one of the company’s
top priorities in trying to minimize the burden placed on the environment. We are engaged in developing environmentally­friendly products, and always strive to help define and comply with the latest independent standards from agencies such as
ISO (International Organisation for Standardization) and TCO (Swedish Trades Union).

Disposing of your old NEC product

The aim of recycling is to gain an environmental benefit by means of re-use, upgrading, reconditioning or reclamation of
material. Dedicated recycling sites ensure that environmentally harmful components are properly handled and securely
disposed. To ensure the best recycling of our products, NEC DISPLAY SOLUTIONS offers a variety of recycling
procedures and gives advice on how to handle the product in an environmentally sensitive way, once it has reached the end
of its life.

All required information concerning the disposal of the product and country-specific information on recycling facilities can be
found on our following websites:

http://www.nec-display-solutions.com/greencompany/ (in Europe),
http://www.nec-display.com (in Japan) or
http://www.necdisplay.com (in USA).

Energy Saving

This monitor features an advanced energy saving capability. When a VESA Display Power Management Signalling (DPMS)
Standard signal is sent to the monitor, the Energy Saving mode is activated. The monitor enters a single Energy Saving mode.

Power consumption

Max

(with optional

speaker)

Normal Operation

(without optional speaker,

with factory settings)

Energy Saving Mode*

Off Mode

* “RS-232C” is selected in EXTERNAL CONTROL for V321/V461.

140 W (V321)
240 W (V461)

210 W (LCD4215

100 W (V321)
185 W (V461)

160 W (LCD4215

Less than 2 W
Less than 1 W

LED colour

Green

(R))

Green

(R))

Red and Green

Red

WEEE Mark (European Directive 2002/96/EC)

Within the European Union

EU-wide legislation, as implemented in each Member State, requires that waste electrical and electronic
products carrying the mark (left) must be disposed of separately from normal household waste. This includes
monitors and electrical accessories, such as signal cables or power cords. When you need to dispose of your
NEC display products, please follow the guidance of your local authority, or ask the shop where you
purchased the product, or if applicable, follow any agreements made between yourself and NEC.

The mark on electrical and electronic products only applies to the current European Union Member States.

Outside the European Union

If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local
authority so as to comply with the correct disposal method.

Downloaded From TV-Manual.com Manuals

English-34
